Maytag JET CLEAN II JDB1100AW User manual

Jet Clean II
Stainless Steel
Dishwashers
This Base Manual covers general information
Refer to individual Technical Sheet
for information on specific models
This manual includes, but is
not limited to the following:
Maytag
MDB8750AW
MDB9750AW
Service
This manual is to be used by qualified appliance
technicians only. Maytag does not assume any
responsibility for property damage or personal
injury for improper service procedures done by
an unqualified person.
16022783
January2004
Jenn-Air
JDB1060AW
JDB1100AW
JDB2100AW
JDB2150AWP

2 16022783 Rev.0 ©2004 Maytag Appliances Company
Important Notices for Servicers and Consumers
Maytag will not be responsible for personal injury or property damage from improper service procedures. Pride and
workmanship go into every product to provide our customers with quality products. It is possible, however, that
during its lifetime a product may require service. Products should be serviced only by a qualified service technician
who is familiar with the safety procedures required in the repair and who is equipped with the proper tools, parts,
testing instruments and the appropriate service information. IT IS THE TECHNICIANS RESPONSIBLITY TO
REVIEW ALL APPROPRIATE SERVICE INFORMATION BEFORE BEGINNING REPAIRS.
!WARNING
To avoid risk of severe personal injury or death, disconnect power before working/servicing on appliance to avoid
electrical shock.
To locate an authorized servicer, please consult your telephone book or the dealer from whom you purchased this
product. For further assistance, please contact:
Customer Service Support Center
CAIR Center
Web Site Telephone Number
WWW.AMANA.COM ............................................... 1-800-843-0304
WWW.JENNAIR.COM ............................................ 1-800-536-6247
WWW.MAYTAG.COM............................................. 1-800-688-9900
CAIR Center in Canada.......................................... 1-800-688-2002
Amana Canada Product .......................................... 1-866-587-2002
Recognize Safety Symbols, Words, and Labels
DANGER
!
DANGER—Immediate hazards which WILL result in severe personal injury or death.
WARNING
!
WARNING—Hazards or unsafe practices which COULD result in severe personal injury or death.
CAUTION
!
CAUTION—Hazards or unsafe practices which COULD result in minor personal injury, product or property
damage.
Important Information

©2004 Maytag Appliances Company 16022783 Rev.0 3
Table of Contents
Will Not Wash .................................................... 18
Will Not Drain ..................................................... 18
Will Not Dry ........................................................ 18
ManualFunction Test ......................................... 18
FieldServiceTest ............................................... 18
TroubleshootingFlowChart
InstallationIssues ............................................... 19
Leak Issues Page 1 ............................................ 20
Leak Issues Page 2 ............................................ 21
No Function OperationIssues Page 1................. 22
No Function OperationIssues Page 2................. 23
Wash Performance / Staining Issues Page 1 ...... 24
Wash Performance / Staining Issues Page 2 ...... 25
DryPerformance Page1..................................... 26
DryPerformance Page2..................................... 27
Noise Issues Page 1........................................... 28
Noise Issues Page 2........................................... 29
Serviceand DisassemblyProcedures
FrontSupportandToePanel Removal ................ 30
Inner DoorPanel Removal ................................... 31
Detergent / RinseAid Disp.................................. 31
Wax Motor Detergent / RinseAid Disp................ 32
Vent.................................................................... 32
WireCover .......................................................... 32
Door Latch & Switch HolderAssembly................ 33
PCBoard............................................................ 34
TechnicalSheet .................................................. 34
Control Panel ...................................................... 34
DoorLatch Strike ................................................ 34
DoorGasket ....................................................... 35
OuterDoor .......................................................... 35
DoorHingeAndSupport ..................................... 36
DoorSpring ......................................................... 36
DoorSpringAnd ComponentReplacement.......... 37
OverPressure Filter ............................................ 37
Top WashArm .................................................... 37
Manifold .............................................................. 38
DockingStation .................................................. 38
LowerWashArm ................................................ 38
Float ................................................................... 39
HeatingElement ................................................. 40
Thermostats ....................................................... 41
Water Valve ........................................................ 41
Air Water Inlet and Vent...................................... 42
UpperRackRemoval .......................................... 43
TubWheels ........................................................ 43
TurbiditySensor.................................................. 43
DrainPump ........................................................ 44
Wash Motor Assembly ....................................... 45
AppendixA
InstallationInstructions ....................................... A-2
ImportantInformation
ImportantNotices forConsumers andServicers .... 2
Recognize Safety Symbols, Words, and Labels ... 2
ImportantSafetyInformation
GeneralInformation...............................................4
RelatedPublications .............................................4
GeneralPrecautions andWarnings.......................4
ProductWarning Labels
JunctionBox Warning...........................................5
SupportPanel Warning .........................................5
ControlCoverWarning ..........................................6
Electrical Equipment & Testing
Electrical Test Equipment .....................................7
ApplianceTestMeter ............................................7
ContinuityTesting .................................................7
DigitalTest Meter..................................................7
Voltage Checks ..............................................8
MotorTest Cord ....................................................8
GroundingPolarity ................................................8
Electrical Tests
Water Valve ..........................................................9
Detergent / RinseAid Disp Wax Mtr Check ..........9
Cycles & Options
Cycles ................................................................ 10
Options............................................................... 11
Display ............................................................... 12
Control Style by Model........................................ 13
Troubleshooting
Will Not Fill......................................................... 15
Overflows ............................................................ 15
PoorWater Circulation........................................ 15
PoorWashability ................................................ 16
Will Not Drain ..................................................... 16
Continuesto Drain .............................................. 16
PoorDrying ........................................................16
Water Leaks ....................................................... 17
Noise .................................................................. 17
Will Not Start or Program .................................... 17
Will Not Fill......................................................... 17

4 16022783 Rev.0 ©2004 Maytag Appliances Company
Important Safety Information
WARNING
!
To avoid personal injury or death from improper
servicing, make sure you read and understand the
descriptions and meaning of various safety symbols,
words and labels used in this manual, before
attempting any procedures described in the manual.
Failure to understand and comply with safety
information may result in severe personal injury or
death.
General Information
This Service Manual describes the operation,
disassembly,troubleshooting, and repair ofMaytag®
Dishwashers.It is intended foruse by authorized
servicer’swho troubleshootand repair theseunits.
NOTE: It is assumed that users of this manual are
familiar with the use of tools and equipment used
totroubleshoot and repairelectrical, and
mechanical systems; and understand the
terminology used to describe and discuss them.
Related Publications
This is a base service manual, covering a range of
similar models. It is intended to be used in conjunction
with the Parts Manual and Technical Sheet covering
specific model being serviced.
General Precautions and Warnings
•Disposeof discarded appliance and shippingor
packingmaterial properly.
•Do not allow children to play in or on dishwasher.
•Do not abuse, sit, stand or play on door or racks of a
dishwasher.
•Useonly detergents and rinse agentsrecommended for
use in a dishwasher.
•Storedishwasher detergent and rinse agentsout of the
reachof children.
•Ifthe dishwasher drains into a food disposer, make
suredisposer is completely empty before running
dishwasher.
•Repairsshould be done by a qualified technician.
•Do not tamper with controls.
•Do not touch the heating element during or immediately
afteruse.
•Load sharp knives with the handles up to reduce the
risk of cut-type injuries or damaging seal.
To avoid risk of personal injury or death due to
electrical shock:
•Groundingwires andwires coloredlike grounding
wires are NOT to be used as current carrying
conductors.
•Standardaccepted color codingfor ground wires
is green or green with a yellow stripe.
•Groundingwires shouldnot beremoved from
individualcomponents while servicing,unless
componentis tobe removed andreplaced.
•Replaceallremoved groundingwiresbefore
completingservice.
WARNING
!
To avoid death, severe personal injury, fire or
electrical shock when using dishwasher observe
the following:
• Observe all local codes and ordinances.
•Disconnectelectrical powerto dishwasherbefore
servicing.
•Connectdishwasher toa grounded metal,
permanentwiring system.
•DONOT ground togas line.
•DO NOT ground to cold water pipe if pipe is
interrupted by plastic, non-metallic gaskets, or
otherinsulating (non-conducting)materials.
•Check with a qualified electrician if you are not
surethis appliance isproperly grounded.
•Thisdishwasher is designedto operate on
regular house current (120 V, 60 Hz). Use a
circuit equipped with a 15 ampere fuse or circuit
breaker.Use a 20 ampere fuse if dishwasher is
connectedwith a foodwaste disposer.
•Undercertain conditions, hydrogengas may be
produced in a hot water system that has not
beenused for 2 weeks ormore. HYDROGEN
GAS IS EXPLOSIVE. If hot water system has
notbeen used forsuch a period, beforeusing
dishwasher, turn on all hot water faucets and let
waterflow fromeach for severalminutes. This will
releaseany accumulatedhydrogen gas.
HYDROGEN GAS IS FLAMMABLE. Do not
smoke or use an open flame during this time.
•Do not store or use combustible materials,
gasolineor otherflammable vaporsand liquids in
the vicinity of this or any other appliance.
•Do not wash plastic items unless marked
"dishwashersafe" orthe equivalent. Ifnot
marked,check withmanufacturer for
recommendations.Items that arenot dishwasher
safe may melt and create a potential fire hazard.
•To avoidentrapmentand/orsuffocation,remove
dooror door latch mechanismfrom any
dishwasher that is discarded or not in use.
WARNING
!

©2004 Maytag Appliances Company 16022783 Rev.0 5
Important Safety Information
PRECAUCIÓN:
Desconecte la
energía eléctrica
antes de darie
servicio.
ATENCIÓN:
Solamente use
conductores de
cobre. Use cables de
suministro adecuados
para 75° (167°F).
CAUTION: Disconnect electrical power
before servicing.
ATTENTION: Use copper conductors only.
Use supply wires suitable for 75°C (167°F).
ATTENTION: Débrancher de
l'alimentation électrique avant tout dépannage.
ATTENTION: Utiliser des conducteurs en
cuivre uniquement. Utiliser des fils
d'alimentation pouvant supporter une
température de 75°C (167°F).
GROUNDING: This unit must
be grounded in accordance with local
and/or national electric codes.
WARNING: The heating
element, drain pump, harness clip,
dispenser mount, and water valve are
intentionally not grounded and may
present a risk of electrical shock only
during servicing. Discharge motor
capacitior before servicing. Failure to
follow these instructions can result in
death, serious injury, fire, or electrical
shock.
MISE Á LA TERRE: Cet appareil
doit être relié à la terre conformément aux
codes électriques locaux et/ou nationaux.
AVERTISSEMENT: La résistance,
la pompe de vidange, l'attache du hamais, la
monture de distributeur et l'électrovanne ne
sont pas reliés à la terre intentionnellement et
peuvent présenter des risques d'électrocution
uniquement en cas d'intervention de service
aprés-vente. Décharger le condensateur
avant toute intervention. Le non-respect de
ces consignes peut entrainer la mort, des
blessures graves, l'incendie ou l'électrocution.
CONEXIÓN A TIERRA: Esta
unidad debe estar conectada a tierra de
acuerdo con los códigos eléctricos locales y
nacionales.
ADVERTENCIA: El elemento calentador,
la bomba de drenado, el sujetador del arnés,
el montaje del surtidor y la válvula de
agua están sin conectar a tierra
intencionalmente podrían presentar un riesgo
de descargas eléctricas cuando se les da
servicio solamente. El no seguir estas
instrucciones podría causar la muerte, lesiones
graves, incendios o descargas eléctricas.

6 16022783 Rev.0 ©2004 Maytag Appliances Company
WARNING:
Disconnectpowerbeforeservicing.Electroniccontroliseergizedatalltimesuntil
powerisdisconnected.Capacitorsoncontrolmayremainactiveafterelectricalpowerisdisconnected.
Failuretofollowtheseintructionscanresultindeath,seriousinjury,fire,orelectricalshock.
ADVERTENCIA:
Desconectelaenergíantesdedarleservicio.Elcontrolelectrónicoestá
energizadotodoeltiempohastaquesedesconectalaenergía.Loscapacitoresdelcontrolpodrían
permaneceractivosdespuésdedesconectarlaenergíaeléctrica.Elnoseguirestasinstrucciones
podrícausarlamuerte,lesionesgraves,incendiosodescargaseléctricas.
AVERTISSEMENT:
Débrancheravanttouteintervention.Lacommandeélectroniqueest
constammentsoustensionàmoinsquel'appareilnesoitdébranché.Lescondensateursdela
commandepeuventrestersoustensionunefoisl'appareildébranché.Lenon-respectdecesconsignes
peutentraînerlamort,desblessuresgraves,l'incendieoul'électrocution.
Important Safety Information
WARNING: Disconnect power before servicing. Electronic control is energized at all times until
power is disconnected. Capacitors on control may remain active after electrical power is disconnected.
Failure to follow these instructions can result in death, serious injury, fire, or electrical shock.
ADVERTENCIA: Desconecte la energí antes de darle servicio. El control electrónico está
energizado todo el tiempo hasta que se desconecta la energía. Los capacitores del control podrían
permanecer activos después de desconectar la energía eléctrica. El no seguir estas instrucciones
podrí causar la muerte, lesiones graves, incendios o descargas eléctricas.
AVERTISSEMENT: Débrancher avant toute intervention. La commande électronique est
constamment sous tension à moins que l'appareil ne soit débranché. Les condensateurs de la
commande peuvent rester sous tension une fois l'appareil débranché. Le non-respect de ces consignes
peut entraîner la mort, des blessures graves, l'incendie ou l' électrocution.

©2004 Maytag Appliances Company 16022783 Rev.0 7
Electrical Equipment & Testing
Electrical Test Equipment
Theequipment requiredto servicethese modelsdepends
largelyupon the conditionencountered. Locating a
malfunctionwill often require theuse of electrical testing
equipment such as:
ApplianceTestMeter
Clamp-OnAmmeter
MotorTest Cord
Appliance Test Meter
AnAppliance Test Meter is a multi-purpose tester
combininganAC/DC voltagetesterwith a multi-range
ohmmeter.
The easiest means of testing electrical components is
"Continuity Testing" with an appliance meter. Continuity
is a complete or continuous path from one point in an
electrical circuit to another.
Theobvious advantagesof being able to checkelectrical
componentsand circuits without power appliedis one of
thefeatures of the Ohmmeter. Multiple rangesallow
accuratedetermination of resistancesof both single
components and entire circuit paths. Resistance is
measuredin "Ohms."
To avoid risk of personal injury or death due to
electrical shock:
Alwaysbe sure the power has been disconnected
beforemaking resistance measurements. Failureto
do so will also result in damage to your meter!
Internalbatteries provideall thepower neededto
make resistance checks. They should be checked
at least once a year and replaced as needed.
Continuity Testing: is a process of eliminating electrical
componentsinvolved in a given functionof theappliance,
until the inoperative part is found. By reviewing the list of
possibleelectrical problems under a givencondition, and
thenperforming appropriate continuitychecks of theparts
involved,you should be ableto locate the electrical
componentwhich is inoperative.
NOTE: When checking components or circuit paths for
continuity, external wiring should be disconnected to
eliminatefalse readings through external paths.Isolate
what you want to test.
Digital Test Meter
can be used to check for open
or closed circuits, measure
resistance,AC and DC volts,
andtemperature.
Analog Test Meter
can be used to check for
open or closed circuits,
measureresistance,AC and
DCvolts, and temperature.
WARNING
!

8 16022783 Rev.0 ©2004 Maytag Appliances Company
VOLTAGE CHECKS
Generally, these checks will consist of taking readings
at the wall receptacle in order to determine the
availability of voltage to the product. Voltage checks on
individualcomponents ofa product are not
recommended due to the possibility of electrical shock.
Componentpart testing is bestaccomplished through
continuity checks with anAppliance Test Meter.
NOTE: Use of the meter on voltage higher than the
indicatedrange may causepermanent damage to the
meter. To prevent damage, first select highest range and
thenlower the rangefor readings whichfall within the
lowerscale.
Clamp-On Ammeter
can be used to detect shorts.
Overloadson thecircuit breaker
or fuse can be traced
toeither the appliance
or circuit breaker by
checking the current
draw.
Each circuit in an appliance has a "Normal" current
draw, whichis an indication of the performance of that
circuit. Current draw levels of less than or more than
normalgive clues to possiblemalfunctions. The clamp-
onammeter measures these circuitswithout breaking
the circuit by measuring the strength of the magnetic
fielddeveloped aroundeach conductor. Currentis read
by separating the conductors and clamping the jaws of
theammeter around each conductoron which current is
read. Lowamperage readings indicate problems, such
asdamaged heating elements, etc. Highamperage
readingsindicate the unit beingtested is operating under
anincreased mechanical or electricalload.
NOTE: Overloadson a circuit breaker or fuse can be
traced to the product being tested or the circuit breaker
(or fuse) by checking the products current draw. If the
amperagereading is lessthan the breaker reading, the
breaker or fuse box is at fault.
Use of Ammeter on dishwasher:
1. Motor Current - the reading can be taken at the
leads on the motor start relay or at the male connec-
tor.
2. Heating Element Current - The reading can be
taken using either lead to the element.
Motor Test Cord
A motor test cord may be used to electrically check
operationof thevarious electrical components without
removing them from the unit. Testing in this manner
merelydetermines whether or notthe part will function
independentlyof other electricalcomponents. In order to
make accurate tests, proper connection of the motor test
cord is important. With the aid of the drawings under
Drive Motor Test, installation of the motor test cord may
be done quickly and accurately.
Grounding and Polarity
Thereceptacle used forall Maytag productsoperating on
120VACmust be properlygrounded and polarized.
Thepower cord usedon the appliancesshould be
equippedwith a three(3) prongpolarized groundingplug
To avoid risk of personal injury or death due to
electrical shock:
•Disconnectelectrical powerto dishwasherbefore
servicing.
•Always plug test cord into a properly grounded
receptacle.
DANGER
!
To avoid risk of personal injury or death due to
electrical shock:
•Donot cut orremove the groundingprong from any
plug.
DANGER
!
•Alwaysmake connection tocomponents before
plugging test cord into receptacle.
ELECTRICAL EQUIPMENT & TESTING

©2004 Maytag Appliances Company 16022783 Rev.0 9
forprotection against shock hazardand should be
pluggeddirectly intoa properlygrounded and polarized
receptacle.
It is the responsibility of the person installing the
applianceto assure it is adequately grounded and
polarized at the point of installation, taking into
considerationlocal conditions andrequirements. In
caseswhere only a two(2) prong receptacle isavailable,
it is the personal responsibility of the consumer to have it
replacedwith a properlygrounded three(3) prong
receptacle. Allgroundingand wiring shouldbe done in
accordance with National, State, and Local codes. DO
NOT USE AN ADAPTER PLUG WITH THIS
APPLIANCE.
ELECTRICAL TESTS
To avoid risk of personal injury or death due to
electrical shock:
•Disconnectelectrical powerto dishwasherbefore
servicing.
•Always plug test cord into a properly grounded
receptacle.
•Alwaysmake connection tocomponents before
plugging test cord into receptacle.
WATER VALVE TEST
TheWaterValve may be checkedwithout removing itfrom
theDishwasher.
To check the Water Valve for operation, hook up the test
cordas follows:
Wax Motor Check
Detergent / Rinse Aid Dispenser
A single Wax Motor is used to activate both the release of
theDetergent CupCover and therinse aid from the
reservoir.
Tocheck the operation ofthe WaxMotor,removal from
theDispenser Retaineror InnerDoor is not necessary.
First, snap the Detergent Cup Door shut. Then, connect
a Power Test Cord across the two terminals of the Wax
Motor. Plug the Power Test Cord into a 120 VAC
receptacle. The plunger in the center of the Wax Motor
should "push out" and actuate the Dispenser in
approximately45-60 seconds. Removevoltage to the
Wax Motor and allow the plunger to retract into the Wax
Motor. Apply voltage to the Wax Motor again and observe
forproper liftingofthe rinse aidplunger.
WARNING
!
Electrical Equipment & Testing

10 16022783 Rev.0 ©2004 Maytag Appliances Company
Cycles & Options
Cycle Description
AutoClean Designed to auto select the number of fills and length of wash time based on soil level
of the dish load. Water usage ranges from 3 to 8 gallons.
HeavyWash Designedto provide alonger cycle for washing items with heavy
food soils. Water usage is 8 gallons.
NormalWash Designed to wash loads containing dishes with normal amounts of food soils.
Water usage ranges from 3 to 6 gallons.
Light Wash Designed to wash loads containing dishes that are lightly soiled. Water usage is 5
gallons.
Quick Wash Designed for light food soils. The cycle ends with a rinse and does not include drying.
Water usage is 4 gallons.
Rinse Only Rinses dishes being held until the dishwasher is full, and another
cycle is selected. This cycle helps reduce the potential for development of odors.
Water usage is 2 gallons.
SeeUser's Guidefor specific operation.
MDB9750Only
Heavy
Wash Normal
Wash Light
Wash Rinse
Only Auto
Clean START/
Cancel DELAY
1-9 Sanitize Tough
Scrub
Extra
Rinse
Heated
Dry
3
QuietSeries300
Heating Delay
Sanitized
Washing
Drying
Clean Options
Cycles
Auto
Clean Heavy
Wash Normal
Wash Light
Wash Rinse
Only Quick
Wash Heated
Dry
3Sanitize Extra
Rinse Tough
Scrub
Plus 160°
Wash
Options
Cycles Clean
Sanitized
Coversall other models

©2004 Maytag Appliances Company 16022783 Rev.0 11
Option Description
Tough Scrub™ This option adds fills, heat and/or wash time to the
Tough Scrub Plus™ wash cycle.
Sanitize This option monitors cycles for sanitization.
Extra Rinse This option adds an extra rinse to the cycle which helps in hard water situations.
160° Wash This option raises temperature in the final rinse to 160° F.
HeatedDry This option improves drying resultsby turning theheating element onand off during
the dry portion of the cycle.
Delay Delays the start of the dishwasher based on user input.
ControlLock Lock's the control touch pads from unwanted usage. This option does not lock the
door.
MDB9750Only
SeeUser's Guidefor specific operation.
Auto
Clean Heavy
Wash Normal
Wash Light
Wash Rinse
Only Quick
Wash Heated
Dry
3Sanitize Extra
Rinse Tough
Scrub
Plus 160°
Wash
Options
Cycles Clean
Sanitized
Heavy
Wash Normal
Wash Light
Wash Rinse
Only Auto
Clean START/
Cancel DELAY
1-9 Sanitize Tough
Scrub
Extra
Rinse
Heated
Dry
3
QuietSeries300
Heating Delay
Sanitized
Washing
Drying
Clean Options
Cycles
Cycles & Options
Coversall other models

12 16022783 Rev.0 ©2004 Maytag Appliances Company
Display Description
Clean The "Clean" light illuminates at the end of the cycle and remains on until the door has
beenopen continuously for30 seconds.
Drying The "Drying" light illuminates until the cycle is complete.
Washing The "Wash" light illuminates through all the rinse and wash portions of the cycle.
HeatingDelay The "Heating Delay" light illuminates when the cycle is being extended to heat the
water.
Clean/Sanitized These two lights illuminate from the end of cycle until the next cycle is selected,
orthe door has been open continuously for 30 seconds.
Delay The "Delay" light will illuminate whenever a delay count down is in progress, or until
the "Delay" pad is pressed again.
MDB9750Only
Heavy
Wash Normal
Wash Light
Wash Rinse
Only Auto
Clean START/
Cancel DELAY
1-9 Sanitize Tough
Scrub
Extra
Rinse
Heated
Dry
3
QuietSeries300
Heating Delay
Sanitized
Washing
Drying
Clean Options
Cycles
Cycles & Options
Coversall other models
Auto
Clean Heavy
Wash Normal
Wash Light
Wash Rinse
Only Quick
Wash Heated
Dry
3Sanitize Extra
Rinse Tough
Scrub
Plus 160°
Wash
Options
Cycles Clean
Sanitized
QuietSeries300
START/
Cancel DELAY
1-9

©2004 Maytag Appliances Company 16022783 Rev.0 13
MDB8750
Heavy
Wash Normal
Wash Light
Wash Rinse
Only Auto
Clean START/
Cancel DELAY
1-9 Sanitize Tough Extra
Rinse
Heated
Dry
3
QuietSeries200
Heating Delay
Sanitized
Washing
Drying
Clean Options
Cycles
Scrub
Plus
Auto
Clean Heavy
Wash Normal
Wash Light
Wash Rinse
Only Quick
Wash Heated
Dry
3Sanitize Extra
Rinse Tough
Scrub
Plus 160°
Wash
Options
Cycles Clean
Sanitized
QuietSeries300
START/
Cancel DELAY
1-9
MDB9750
Heavy
Wash Normal
Wash Light
Wash Rinse
Only START/
Cancel DELAY
2-4-6 Sanitize Tough
Scrub
Extra
Rinse
Heated
Dry
3
Sanitized
Washing
Drying Clean Options
Cycles
2
4
6
ENN-AIR
JDB1060
Cycles & Options

©2004 Maytag Appliances Company 16022783 Rev.0 14
Electrical-Mechanical Troubleshooting
Will Not Fill
Water Access Valve
Checkto determine if the valve isturned on and water is
availableto theDishwasher. Checkwater pressure.
Circuit Breaker/Fuse
Checkfor tripped breaker or blown fuse. Reset or replace
as necessary.
Door Latch
Check door switches for continuity. With door switches
engaged,no continuity,replace switch.
Float
Check float position. If in the up position, check for
obstructionor disengagement from theFloat SwitchArm.
Float Switch
If the float is in the down position, check the switch for
continuity. If no continuity, replace the Float Switch.
Water Valve
Check Solenoid for continuity. No continuity, replace
Water Valve. Check Inlet Screen for restrictions. Clean
screen or replace Water Valve as necessary. (See section
5).
Wiring/Electrical Connections
Checkfor loose orfrayed wire terminal connections.
Checkfor broken wirewithin harness. Repair orreplace
as necessary.
NOTE: Lowwater pressure can result in failure of the
Water Valve to close properly.
Float
Ensure that the Float isn't stuck in the down position.
Checkfor sediment buildup. Cleanand/or replace as
necessary.
Float Switch Actuator Lever
Check the actuator lever on the bracket. It must be able
to move freely. Repair or replace as necessary. (See
section 5).
Float Switch
Check Float Switch for continuity with the Float in the up
position. If continuity is present and Float moves up and
downfreely,replace Float Switch.
!WARNING
To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit and discharge
capacitorthrough a 10,000ohm resistor before attemptingto service, unless testprocedures require power to be
connected.Ensure allground wires areconnected before certifyingunit asrepaired and/or operational.
CAUTION
!
Units covered in this manual are polarized. Reversing polarity of a unit or any of its components will cause
damage.Toavoid reversingpolarity,any wiresdisconnected orremoved during servicemust be reconnectedto the
samelocation.To ensure wiresare reconnected to the properlocation, tagor otherwise mark the wiresbefore
disconnectingorremoving.
POOR WATER CIRCULATION
Water Level - Too Low
Normalwater fill shouldbe at level depictedby arrows.
PumpAssembly
Checkassembly for obstructionsor restricted movement
of parts. Repair and/or replace parts as necessary.
Overflows
Water Valve
Checkthat water continues toflow when electrical power
is turned off. If the water continues to flow without
electricalpower, replace WaterValve.

15 16022783 Rev.0 ©2004 Maytag Appliances Company
Filters
Checkfor blockageof Strainer, OverPressure Filter.
Repairas necessary.
Poor Washability
Spray Arms
Check all SprayArms for blockage of water ports or
cracks.Check forproper rack loadingto avoid interference
withSprayArms during washaction. Check for proper
sealing,fastening, andmovement of SprayArms. Repair
as necessary.
Filters
Checkfor blockage of Strainer, PrimaryFilter, and Filter
Support.Repair asnecessary.
Detergent Cup Cover
Checkspringhinge operationof DetergentCupCover.
Repairas necessary.
Detergent Cup
Check operation of Detergent CupAssembly, Wax Motor,
Actuator,Linkage, andCover Latch. Repair and/orreplace
parts as necessary. Note: For testing of Wax Motor, see
Section 2.
RinseDispenser
Checklevel of rinseaid in reservoir.Check rinse aid
dispensersetting.
Will Not Drain
Inadequate Drainage
CheckDrain Pumpfor proper operation.Check the drain
pipeconnections and repairas needed. Ifdraining into the
garbagedisposal, check forunprocessed food wasteat
drainhose connection to disposer. Clean outas needed.
Drain Hose
Check drain hose for kink or restrictions. Reroute or
removeany restrictionof drain hoseas needed.
PumpAssembly
Check pump assembly for obstructions or restricted
parts. Repair or replace parts as necessary.
Wiring/Electrical Connections
Checkfor loose orfrayed wire terminal connections.
Checkfor broken wirewithin harness. Repair orreplace
as necessary.
Electrical-Mechanical Troubleshooting
!WARNING
To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit and discharge
capacitorthrough a 10,000ohm resistor before attemptingto service, unless testprocedures require power to be
connected.Ensure allground wires areconnected before certifyingunit asrepaired and/or operational.
Continues To Drain
Control Board
CheckControlBoard forproper operation.
Wash Delivery System
Checkmanifold and DockingStationforgood seal and no
leaks.
Poor Drying
Water Temperature
Checkfor lowwater temperature. Temperatureshould be
between120 -150 degrees Fahrenheit. Ifnot, advise
consumerto adjust water heater setting. Encourage
consumerto purge water lines to the dishwasherarea
priorto startingthe dishwasher.
CycleOptions
Adviseconsumer useof optionsavailable ondishwasher
thatimprove drying. Options thatimprove drying are
Heated Dry, and 160° Wash.
Detergent
Checkwater hardness. Instruct consumer on detergent
usage,one teaspoonof detergentper grain ofwater
hardness.
RinseDispenser
Checklevel ofrinse aid inreservoir. Check dispenser
settingunder cap. Use "MAX"for hard water conditions.
Improper Rack Loading
Check how the consumer loads the dishes into the racks.
Improperloading of some typesof dishes can trapwater
which causes dishes not to dry.
Heating Element
Check load readings listed on Technical Sheet located
behindToePanel.

©2004 Maytag Appliances Company 16022783 Rev.0 16
Thermostat
Check mating surface of the High Limit Thermostat face
to surface of tub enclosure. Contact area must be flat.
Adjust the thermostat placement if necessary. See
TechnicalSheet, located behindToe Panel forthermostat
data.
Water Leaks
Installation
CheckDishwasherfor properleveling andsquareness in
cabinet.
Door Alignment
Checkproper alignment ofDoor Liner toDoor Gasket.
DoorGasket
Checkfor torn or damaged Door Gasket. Repair or
replace as necessary.
Hoses
Check for loose hose clamps or hoses that leak. Tighten
hose clamps or replace hoses as needed.
Spray Arms / Manifold
Check for cracks and replace as necessary.
Detergent / Rinse Aid Dispenser Seal
CheckRinseAid Dispenser Sealfor proper positioningor
cracking.Reposition or replaceas needed.
Water Valve
CheckWaterValve body for damage and leaks. Replace if
necessary. Also, check plumbing connections to Water
Valve.
Wash Motor Assembly
Check for water leak between PumpAssembly and tub.
Drain Pump Assembly
Check PumpAssembly Housing for cracks. Check Drain
Pump "O" ring for leaks.
Electrical Mechanical Troubleshooting
!WARNING
To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit and discharge
capacitorthrough a 10,000ohm resistor before attemptingto service, unless testprocedures require power to be
connected.Ensure allground wires areconnected before certifyingunit asrepaired and/or operational.
Noise
Banging
Checkfor loose SprayArms.Check for dishes interfering
withSprayArmrotation. Seeloading information in the
User's Guide at the end of this manual.
Hammering/Chattering
CheckWaterValvefor,noise, lowvoltage,or highvalve
coil resistance. Replace Water Valve if needed. Also,
check incoming water supply line for proper size and
pressure. Make sure the supply line is secured.
Grinding
Check for objects in PumpAssembly. If objects are
found, inspect PumpAssembly for damage. Repair as
needed.
Vibration
Checkcomponents forsource of vibration. Adjustand/or
tightenas needed.
Will Not Start Or Program
Control Board
Checkincoming voltageto Control Board.
Membrane Switch
Checkfor properoperation ofMembrane Switch. See
membranereadings on theTechnical Sheet located
behindtoe panel.
NOTE: Makesure the pin connectorsare making proper
contact with pins on the Control Board. If the
voltageis correct into the Control Board, and the
boardwill notactivate, replace board.
Will Not Fill
Water Valve
Check Water Valve circuit. See Technical Sheet for water
valvedatalocated behindtoe panel.
NOTE: Makesure the pin connectorsare making proper
contact with pins on the Control Board.

17 16022783 Rev.0 ©2004 Maytag Appliances Company
Will Not Wash
Wash Motor
Check Wash Motor circuit. See data listed on the
TechnicalSheet, located behindtoe panel.
Electrical Mechanical Troubleshooting
!WARNING
To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit and discharge
capacitorthrough a 10,000ohm resistor before attemptingto service, unless testprocedures require power to be
connected.Ensure allground wires areconnected before certifyingunit asrepaired and/or operational.
Will Not Drain
Drain Motor
Check Drain Motor circuit. See data listed on the
TechnicalSheet, located behindToe Panel.
Will Not Dry
VentAssembly
CheckVentAssembly for properoperation.
Heating Element
Check Heating Element circuit. See data listed on the
TechnicalSheet, located behindToe Panel.
Manual Function Test
SeeTechnical Sheet, located behindToePanel.
Field Service Test
SeeTechnical Sheet, located behindToePanel.

Troubleshooting Flow Chart
©2004 Maytag Appliances Company 16022783 Rev. 0 18
Is the power turned
on to the unit at the
breaker panel or
fuse box?
Verify wiring
is connected
correctly at
junction box
and turn on
power
Does the cycle start
when the start/
cancel key is
pressed?
Are any of the
indicator lights for
cycle and options
illuminated?
Go to No
Fuction
flow chart
Is the water turned
on to the unit?
Yes
No
Turn water
on
Yes
No
Yes
No
Yes
No
Does it fill properly?
Is there 105VAC
(minimum) at
junction box?
Yes
No
Go to No
Fuction
flow chart
Correct
home
wiring issue
Go to No
Fuction
flow chart
Yes
No
Starting Problem Fill Problem
Does it drain
properly?
Are the drain line
and air break
operating correctly?
No
Yes
No
Go to No
Fuction
flow chart
Repair or
reconfigure
drain
system
Yes
Drain Problem
Are there any leaks? Is it noisy?
Go to Leak
Issues flow
chart
Go to
Noise
Issues flow
chart
Yes
No
Yes
No
Leak Problem Noise Problem
It is
extremely
important to
LEVEL the
unit
Do all 4 levelling
legs touch the floor?
Adjust to
touch floor
and
recheck
levelness
Yes
No
Yes
No
Does it look correct
in the installation?
No
Yes
Are the trim strips
installed on each
side and top?
Install trim
strips
No
Yes
Complete
Are the cabinets
level and plumb?
Repair
cabinets
Yes
No
Appearance Problem
Complete
Is the unit level left
to right and front
to back?

Troubleshooting Flow Chart
16022783 Rev. 0 ©2004 Maytag Appliances Company19
Istherealeakatthe
top ofthe door?
Doesitleakwhen
you open the door?
Normal
Operation
Can you see foam
materialinthe vent
eyelets?
Adjustfoam
sealand
recheck
Yes
No
Yes
No
Yes
No
Check
forleaks
aftereach
manual
operation
below
Isthe rectangular
foamsealcorrectly
installed between
ventand control
panel?
Install new
foamseal
No
Yes
Complete
Top oftheDoor
Leaks

Troubleshooting Flow Chart
©2004 Maytag Appliances Company 16022783 Rev. 0 20
B
Isthe incoming
waterunderthe sink
leaking?
Isthe drainhose
going intothe
plumbing leaking?
Repair
connection
Complete
Yes Yes
No
No
Isthe drainpumpto
drainhoseleaking?
Isthe drainhose
clamptight?
Tighten the
clamp
Replace
the hose
No
YesNo
Yes
Isthe fill hose
leaking ateither
end?
Isthe watervalve
clampfullyseated?
No
Yes
L
o
o
s
e
n
c
l
a
m
p
,
p
u
s
h
f
i
l
l
h
o
s
e
o
n
a
n
d
f
u
l
l
y
r
e
s
e
a
t
c
l
a
m
p
No
Yes
Iswatersplashing
outofthe air/water
inlet?
I
s
t
h
e
a
i
r
/
w
a
t
e
r
i
n
l
e
t
f
o
a
m
i
n
p
l
a
c
e
?
R
e
s
e
a
t
/
r
e
