Maytag MDB4000AWB Manual

Repair
Parts
List
MODEL NUMBER
MDB4000AWB
When requesting service or ordering parts, always
provide the following information:
- Product Type - Part Number
- Model Number - Part Description
DISHWASHER
©2005 Maytag Services

Section: CONTROL PANEL
DW11-50
Model: MDB4000AWB
1

CONTROL PANEL
No. Part No. Description
Section:
Series Qty
1 99001755 PANEL, CONTROL (BLK) 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, PANEL 10 4
2 99001780 KNOB, TIMER Note: KNOB, TIMER (BLK) 10 1
3 99001855 SWITCH, CONTROL (6-BUTTON) 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, SWITCH 10 2
4 99001946 TIMER 18 1
4 99001853 TIMER 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, TIMER 10 3
4 99001920 TIMER (6 & 8 BUTTON) 14 1
5 99001077 HOLDER, DOOR SWITCH 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, SWITCH HOLDER 10 1
6 99001545 BARRIER, CONTROL PANEL 10 1
7 903115 LOCK LIGHT Note: LIGHT, INDICATOR 10 2
8 99001860 LENS, INDICATOR LIGHT 10 2
9 903086 SWITCH,DOOR 10 2
10 99001078 HANDLE, LATCH (BLK) 10 1
- 99001402 FOAM, LATCH HANDLE 10 2
- 99001401 PAD, LATCH 10 1
11 99002045 HARNESS, WIRE--++*** 10 1
- N 16000327 GUIDE, QUICK REF. - MAYTAG Note: GUIDE, QUICK REFERENCE 10 1
- 99001825 MANUAL, USE & CARE (FRCH) Note: MANUAL, USE & CARE (FRCH) 10 1
- 99001822 MANUAL, USE & CARE 10 1
- 16009270 MANUAL, SERVICE-NO REFUND 10 1
2
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: DOOR
DW12-34
Model: MDB4000AWB
3

DOOR
No. Part No. Description
Section:
Series Qty
- 99001446 SCREW, DECORATOR PANEL (BLK) 10 2
- DAX2000AXE PANEL ACCESSORY KIT (WHT) 10 1
- DAX2000AXM PANEL ACCESSORY KIT (ALM) Note: (KITS INCLUDE #1 & #12) 10 1
1 99001417 PANEL, DECORATOR (BLK) 10 1
2 99001415 FILLER, FRONT PANEL 10 1
3 99001892 DOOR, OUTER 13 1
3 99001419 DOOR, OUTER Note: (MUST ORDER 99001880 ALSO) 10 1
- 99001688 GROUND WIRE, REINFORCEMENT 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD 10 2
4 912666 RETAINER, WIRE 10 1
5 99001899 HINGE (RT) 13 1
5 99001898 HINGE (LT) 13 1
- 99001075 SCREW Note: SCREW, HINGE 10 6
5 903070 HINGE (LT) 10 1
5 903071 HINGE (RT) 10 1
6 912652 SPRING, DOOR 10 2
7 912669 INSULATION, DOOR 10 1
- 99001807 MOTOR, WAX 10 1
- 99001805 GROMMET, VENT 10 1
- 99001806 RETAINER, GROMMET 10 1
- 912620 SCREW 10 7
- 99001783 SEAL, VENT BACK 10 1
8 99001775 DOOR, INNER (W/VENT ASSY)--SUB 10 1
9 912668 BAR, REINFORCEMENT 10 1
10 912836 INSULATION, ACCESS PANEL 10 2
11 912653 LINK, DOOR SPRING 10 2
12 99001412 PANEL, ACCESS (BLK) Note: (BLK) 10 1
- 912366 SCREW --++*** Note: SCREW, ACCESS PANEL (BLK) 10 4
13 903233 FOAM STRIP, INSULATION 10 1
- 912266 STRAP, CABLE--++*** 10 1
- 912366 SCREW --++*** Note: SCREW, TUB SHIELD 10 1
14 99001414 SHIELD, TUB 10 1
15 99001444 STRAP, HARNESS 10 1
- 912365 SCREW Note: SCREW, STRAP 10 1
4
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: RINSE AID & SOAP DISPENSER
DW17-10
Model: MDB4000AWB
5

RINSE AID & SOAP DISPENSER
No. Part No. Description
Section:
Series Qty
1 902899 MOTOR,WAX 10 1
2 903184 KNOB, RINSE AID (GRAY) Note: KNOB, RINSE AID 10 1
3 913060 NUT, RESERVOIR Note: NUT, RESERVOIR 10 1
4 913191 GROMMET, DISPENSER 10 1
5 99001288 RETAINER Note: RETAINER, MOTOR & SLIDER 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD 10 2
6 99001291 LATCH, DISPENSER Note: LATCH, LID 10 1
7 99001289 SLIDER Note: LATCH, SLIDER 10 1
8 912676 SPRING, DISPENSER LATCH 10 1
9 903656 RESERVOIR, RINSE AID Note: RESERVOIR, RINSE AID 10 1
10 903124 PLUNGER ASSEMBLY Note: PLUNGER ASSEMBLY 10 1
11 913061 GASKET, RESERVOIR Note: GASKET, RESERVOIR 10 1
12 99001290 ACTUATOR, RINSE AID Note: ACTUATOR, RINSE AID 10 1
13 903108 LID, DETERGENT CUP 10 1
14 912547 SPRING, CUP LID Note: SPRING, SOAP DISPENSER 10 1
15 912679 PIN, HINGE (SHORT) Note: PIN (SHORT) 10 1
16 912678 PIN, HINGE (LONG) Note: PIN (LONG) 10 1
17 99001287 PIVOT 10 1
6
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: TRACK & RACK ASSEMBLY
DW15-53
Model: MDB4000AWB
7

TRACK & RACK ASSEMBLY
No. Part No. Description
Section:
Series Qty
1 99001507 RACK ASSEMBLY (UPR) Note: (INCLUDES #903093) 10 1
2 903093 WHEEL ASSEMBLY (UPR) Note: WHEEL ASSEMBLY (UPR) 10 4
3 99001487 RACK ASSEMBLY (LWR) Note: (INCLUDES #903095) 10 1
4 903095 WHEEL ASSEMBLY (LWR) Note: WHEEL ASSEMBLY (LWR) 10 6
5 912709 CLIP, ADJUSTABLE PEG Note: CLIP, ADJUSTABLE PEG (LWR) 10 2
6 99001751 BASKET, SILVERWARE (W/COVER) 10 1
7 902990 SHELF, RACK (LWR) Note: SHELF, RACK (LWR) 10 1
8 99001485 TINE, BOWL (FRT) 10 1
- 912710 SLEEVE, FOLDING TINES 10 2
9 99001486 TINE, BOWL (REAR) 10 1
- 912710 SLEEVE, FOLDING TINES 10 2
10 99001533 TOWER, SPRAY (W/SHAFT-GRAY) 10 1
11 99001442 DIVERTER, SPRAY (GRAY) 10 1
12 99001443 CAP, SPRAY DIVERTER (GRAY) 10 1
13 99001426 NUT, DISCHARGE HOUSING 10 1
14 912545 TRACK, RACK 10 2
15 912548 WHEEL, TUB 10 8
16 912549 SHAFT, TUB WHEEL 10 8
17 912798 WASHER, TUB WHEEL 10 8
18 912546 STOP, RACK 10 4
19 99001508 SHELF, RACK (UPR) 10 1
- 99002017 CAP, RACK (LIGHT GRAY) 10 1
- 99002016 CAP, RACK (WHT) 10 1
8
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: TUB
DW13-79
Model: MDB4000AWB
9

TUB
No. Part No. Description
Section:
Series Qty
1 902894 SEAL, DOOR--++*** 10 1
2 99001359 VALVE, WATER 10 1
- 912365 SCREW Note: SCREW, WATER VALVE 10 2
3 911856 CLAMP, SPRING Note: CLAMP, INJECTOR HOSE 10 1
4 912633 HOSE, INJECTOR 10 1
5 912533 INJECTOR, WATER 10 1
6 904030 CLAMP, HOSE (1 1/4") Note: CLAMP, HOSE 10 1
7 912640 PANEL, TOE (BLK) Note: PANEL, TOE (BLK) 10 1
- 912366 SCREW --++*** Note: SCREW, TOE PANEL (BLK) 10 2
- 912650 RETAINER, LATCH 10 1
8 903098 DOOR LATCH HOOK ASSY Note: DOOR LATCH HOOK ASSEMBLY 10 1
- 912648 SPRING, LATCH 10 1
- 99001355 HOOK, LATCH 10 1
- 912873 SCREW, LATCH Note: SCREW, LATCH HOOK 10 1
9 912647 HOSE, TOP SHOWER Note: HOSE, TOP SHOWER 10 1
10 913095 VENT, INLET 10 1
11 910069 WASHER, TUB TOP Note: WASHER, TOP SHOWER HOSE 10 1
12 912014 LEVER, ACTUATOR 10 1
13 912015 PIN, LEVER PIVOT 10 1
14 912686 RING, LOCKING 10 1
15 99001885 DEFLECTOR, WATER 11 2
- 99001008 CLIP, THERMOSTAT 10 2
16 99001852 THERMOSTAT, LIMITING 10 1
16 99001005 THERMOSTAT, BOOST (36TX02) 10 1
17 913096 TUBE, INLET 10 1
18 912651 BRACKET, ADJUSTING 10 2
19 912613 SCREW, ADJUSTING BRACKET Note: SCREW, BRACKET 10 2
20 912645 NUT, HEATING ELEMENT 10 2
- 99001333 SLEEVE, INSULATING Note: SLEEVE, INSULATING 10 1
- 912622 SCREW 10 1
21 912659 CAP, AIR INLET 10 1
22 913079 O-RING, HEATER Note: WASHER, HEATING ELEMENT 10 2
23 99001773 ELEMENT, HEATING (830W/650W) Note: ELEMENT, HEATING 10 1
24 912541 BRACKET, HEATING ELEMENT 10 2
25 911265 PALNUT, FLOAT 10 1
26 912579 LEG, LEVELING 10 4
- 400321 CLAMP, CABLE Note: CLAMP, CABLE 10 1
27 912563 BOX, TERMINAL 10 1
- 912365 SCREW Note: SCREW, BOX 10 2
28 99001922 FLOAT (SHORT STEM) 18 1
28 99001918 FLOAT 14 1
28 99001004 FLOAT 10 1
29 900882 SWITCH, WATER LEVEL 10 1
- 912012 SCREW Note: SCREW, WATER LEVEL SWITCH 10 1
- 912365 SCREW 10 1
30 912656 BRACKET, WATER LEVEL SWITCH 10 1
31 912799 SCREW, CABINET MOUNT 10 2
32 911917 FASTENER, INSULATION Note: FASTENER, INSULATION 10 4
- 99001076 STRAP, INSULATION 10 1
- 99001057 FASTENER, PANEL 10 2
33 912655 INSULATION, TUB 10 1
34 912790 HOOK, DRAIN HOSE Note: HOOK, DRAIN HOSE 10 1
35 912644 SEAL RING, INJECTOR 10 1
- 912365 SCREW Note: SCREW, STRAP 10 2
36 912654 STRAP, SUPPORT 10 1
10
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: PUMP & MOTOR
DW14-29
Model: MDB4000AWB
11

PUMP & MOTOR
No. Part No. Description
Section:
Series Qty
1 99001787 NOZZLE, JUMP UP (GRAY) 10 1
2 99001788 ARM ASSY., WASH (LWR-GRAY) 10 1
3 912313 RING, SEAL Note: SEAL, RING 10 2
4 99001789 FILTER ASSY., SECONDARY 10 1
5 99001790 SCREW, SECONDARY FILTER 10 3
6 99001791 FILTER, PUMP Note: FILTER, PUMP 10 1
7 99001748 ARM ASSY., RINSE 10 1
8 99001426 NUT, DISCHARGE HOUSING 10 1
9 99001422 SUPPORT, SPRAY ARM 10 1
10 12001489 PUMP MODULE REPAIR PACKET 10 1
11 99001792 HOUSING, DISCHARGE (UPR) 10 1
12 910654 SCREW, IMPELLER Note: SCREW, IMPELLER 10 1
13 910934 SEAL, O-RING Note: SEAL, O-RING 10 1
14 902461 IMPELLER ASSEMBLY Note: IMPELLER, PUMP 10 1
15 99001793 PLATE, SUCTION 10 1
16 99001794 SUPPORT, FILTER 10 1
17 912510 O-RING Note: O-RING 10 1
18 912310 DISC, CUTTER Note: DISC, CUTTER 10 1
19 99001081 SCREW Note: SCREW, CHOPPER PLATE 10 6
20 99001795 COVER, DRAIN 10 1
21 912317 DRAIN IMPELLER Note: IMPELLER, DRAIN 10 1
22 903304 DRAIN IMPELLER ASSEMBLY Note: DRAIN IMPELLER ASSEMBLY 10 1
23 903303 ASSEMBLY, SEAL SEAT Note: SEAL SEAT ASSEMBLY 10 1
24 902882 SEAL, PUMP Note: SEAL, PUMP 10 1
25 912529 GASKET, PUMP Note: GASKET (W/FASTENERS) 10 1
26 99001934 MOTOR/PUMP HOUSING ASSY Note: (MUST ORDER JUMPER WIRE PART #99001917 ON SERIES
12 THRU 14)
10 1
27 912383 SCREW Note: SCREW, DISCHARGE HOUSING (UPR) 10 3
28 99001782 HOSE, DRAIN 10 1
29 99001774 CLAMP, HOSE (1 3/8") Note: CLAMP, DRAIN HOSE 10 1
30 99001425 RELAY, MOTOR 10 1
- 913156 BRACKET, RELAY 10 1
31 912681 RETAINER, SNAP SPRAY 10 1
32 912680 OUTLET, SNAP 10 1
33 12001446 UPPER SPRAY ARM/RETAINER ASSY Note: SPRAY ARM ASSEMBLY (UPR) 10 1
34 99001428 CAP, WASH ARM (GRAY) 10 1
35 912895 SHIELD, RADIANT 10 2
36 99001796 GUARD, FILTER (GRAY) 10 1
37 99001797 O-RING 10 1
38 99001326 GASKET, DISCHARGE HSNG (UPR) 10 1
39 99001798 BALL, CHECK 10 1
40 99001799 FLAPPER, VALVE 10 1
41 99001800 CLIP, RETAINER 10 1
- 99001979 O-RING, PUMP THERMOSTAT 16 1
42 99001981 THERMOSTAT, BOOST 16 1
12
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: WIRING INFORMATION
15002235
Model: MDB4000AWB
13

Section: WIRING INFORMATION
15002685
Model: MDB4000AWB
14
