Maytag MMV4203DB00 User manual

CONTROL PANEL PARTS
1
For Models: MMV4203DW00, MMV4203DB00, MMV4203DS00, MMV4203DQ00
(White) (Black) (Stainless) (Bisque)
4−09 Litho in U.S.A. (rek) (eeb) Part No. W10270436 Rev. A
MICROWAVE OVEN/HOOD
2.0 Cu. Ft.
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature
W10188231 U & C Guide
W10188234 Tech Sheet, Slim
W10188232 Label, Cook Guide
W10188238 Install, Instruct
2 Panel Asy, Control
Membrane, Lens and
Bracket
W10258188 Black
W10258189 White
W10258190 Stainless
W10258191 Bisque
3
W10258165 Bracket, Control
4
W10258171 Microcomputer
5 Complete Door
W10258192 Black
W10258193 White
W10258194 Stainless
W10258196 Bisque
6 Handle, Door
W10258181 Black
W10258184 White
W10258185 Stainless
W10258196 Bisque
7 Grille Assembly
W10258215 Black
W10258216 White
W10258217 Stainless
W10258218 Bisque

CABINET AND AIR FLOW PARTS
2
For Models: MMV4203DW00, MMV4203DB00, MMV4203DS00, MMV4203DQ00
(White) (Black) (Stainless) (Bisque)
W10270436
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 4713−001013 Lamp
2
DE47−00006A Holder, Lamp
3
DE59−50002A Capacitor, Motor
4
W10250842 Cover, Lamp
5
W10258160 Assy, Duct Upper
6
DE47−20059A Thermostat
7
W10181452 Motor, Fan Assy
8
DE63−00367D Filter, Charcoal
9
DE96−00218A Cord, Power
10
DE92−90508A Holder Nut, Assy
11 Case, Outer
W10187744 Black
W10192096 White
W10199858 Bisque
12
W10197773 Plate, Damper
13
DE72−40022A Damper, Assembly
14
DE70−00378A Plate, Mounting
15
W10258198 Main Harness
16
DE92−90505E Install, Hardware
Following Parts Not Illustrated
W10188741 Template, Wall
W10188240 Template, Upper

INTERIOR AND VENTILATION PARTS
3
For Models: MMV4203DW00, MMV4203DB00, MMV4203DS00, MMV4203DQ00
(White) (Black) (Stainless) (Bisque)
W10270436

INTERIOR AND VENTILATION PARTS
4
For Models: MMV4203DW00, MMV4203DB00, MMV4203DS00, MMV4203DQ00
(White) (Black) (Stainless) (Bisque)
W10270436
Illus. Part
No. No. DESCRIPTION
1 DE61−00115A Bracket, Capacitor
2
2501−001016 Capacitor
3
DE91−70063D Diode, H.V.
4
W10250841 Motor, Fan
5
DE31−90051A Blade, Fan
6
W10260124 Spring, Blade
7
W10197780 Guide, Suction
8
DE96−00400B Filter, Noise
9 Plate, Bottom
W10192477 Black
W10192097 White
10
W10258237 Rack, Cooking
11 Holder, Glass
DE63−00137B Black
DE63−00137C White
12
DE64−00911A Glass, Lamp
13
4713−001013 Lamp
14
DE47−00006A Holder, Lamp
15
DE66−90106B Lever, Switch
16
3405−001033 Switch, Micro
17
3405−001034 Switch, Micro
18
DE66−00168A Latch Board
19
W10187747 Plate, Base
20
DE47−20059A SW−Thermo
21
DE47−20034A Thermostat
22
W10250839 Transformer, H.V.
23
W10197689 Duct, Magnetron
24
W10126786 Magnetron
25
DE47−20007A Thermostat
26
W10197680 Cover, Front
27
DE31−10172A Motor, Turntable
28
DE67−00213A Coupler
29
DE97−00637A Guide, Tray
30
DE74−20002A Tray, Cooking
31
DE71−60121A Cover, Stirrer
32
DE66−20095B Button, Lock
33
W10250840 Stirrer, Assembly
34
DE31−10173A Motor, Drive
35
DE63−00196A Filter, Air
36
DE61−00407A Bracket, Lamp
37
DE61−00375A Holder, Rack
