LEGENDARY MAYTAG DEPENDABILITY
Maximizing your equipment investment for over a half century.
MICROPROCESSOR CONTROLS
Maytag®microprocessor controls offer 15 preprogrammed cycles,
plus the capability to create multiple unique cycles. Also, one-touch
cycle selection and multilingual readouts make these controls easy
for everyone to operate.
CHEMICAL INJECTION SYSTEM
Designed to make chemical installation faster, simpler and more
precise, the Maytag®Commercial Laundry Chemical Injection System
features easy-access connections on the outside of the machine.
This eliminates the need for having to open up the washer on routine
visits. The system also provides chemical supply companies and
the machine’s users with clear visibility on how detergent, bleach,
softener and other chemicals are being dispensed.
BIG-LOAD PERFORMANCE, FLEXIBLE INSTALLATION
Maytag®soft-mount, high-speed extractors feature a suspension
system that allows for more flexibility and does not require special
foundations for installations.
FOR YOUR OPERATION:
• Slimline Model Fits Through A 36" Door Opening
• Inverter Drive Technology For Longer Life
• Up To 350 G’s In Final Spin, Reducing Dry Time
• Easy-To -Operate Microprocessor Controls
• Adjustable Water Temperatures And Levels
• Manual 3-Bay Detergent And Softener Dispenser
• 8 Chemical Supply Signals
• Extra-Large Door And Handle
BUILT-TO-LAST™FEATURES:
• Heavy-Duty Latch And Door Handle
• Durable Sealed Bearings
• Rugged Frame And Cabinet
• Easy Service Access
MFS55PNA
MAYTAG®COMMERCIAL
ENERGY ADVANTAGE™
SOFT-MOUNT, HIGH-SPEED EXTRACTOR
CLP824
EASY TO USE EXTERNAL HOOKUPS
FOR CHEMICAL INJECTION
SPINS UP TO
350 G'S TO EXTRACT MORE WATER
visit maytagcommerciallaundry.com

MAYTAG®LIMITED WARRANTY
3 YEARS — ALL PARTS; 5 YEARS — SHELL, WELDED FRAME
ASSEMBLY, BASKET, SHAFT ASSEMBLY, BEARINGS AND SEALS
For a period from the date of original purchase through the time listed above, the designated parts
that fail in normal commercial use will be repaired or replaced free of charge for the part itself,
with the owner paying all other costs, including labor, transportation and customs duty. Chemical
damage is excluded from all warranty coverage. See complete warranty for details.
At Maytag, we believe durable goods should remain just that.
That’s why every Maytag®product is constructed of the
highest-quality materials and with the utmost in precision
craftsmanship. It’s also why we stand behind our equipment
with solid service and support from our professional Maytag
laundry suppliers. Simply put, when you choose Maytag®
products, you ensure your peace of mind.
OUR COMMITMENT
TO DEPENDABLE QUALITY
6/13
MFS55PNA
MAYTAG®COMMERCIAL
ENERGY ADVANTAGE™
SOFT-MOUNT,
HIGH-SPEED
EXTRACTOR
Maytag®Energy Advantage™Soft-Mount, High-Speed Extractor
MICROPROCESSOR CONTROL
WASHER SPECIFICATIONS
MODEL MFS55PNA
MOTOR
Inverter drive •
Variable speed •
HP (kw) 4 (3)
Voltage 208 – 240V
Three-Phase
BREAKER SIZE — amps 20
SPEED
Wash speed — rpm 42
Extract speed — maximum rpm 915
Extract speed — maximum g-force 350
WATER INLET/HOSE
Water inlet — in. (mm) .75 (19)
Operating pressure — psi (mpa) 43 – 73 (0.3 – 0.5)
Drain size — in. (mm) 3.0 (76) O.D.
CAPACITY
Lbs. (kg) 55 (22)
Cylinder volume — cu. ft. (liters) 7.8 (221)
Cylinder diameter — in. (mm) 29.5 (750)
Cylinder depth — in. (mm) 19.6 (498)
CABINET
Stainless Steel •
APPROXIMATE WEIGHT
Crated — lbs. (kg) 1522 (690)
Uncrated — lbs. (kg) 1433 (650)
DIMENSIONS
A) Height — in. (mm) 56.5 (1435)
B) Width — in. (mm) 35.4 (900)
C) Depth — in. (mm) 43.9 (1115)
D) Floor to drain outlet center — in. (mm) 5.51 (140)
E) Side to drain outlet center — in. (mm) 28.34 (720)
See specific instructions for proper installation. Because of continuous product improvement, Maytag reserves the right
to change specifications without notice.
B
Front View
A
Air Vent
Drain Outlet
D
C
Side View
E
Back View
