Mazda 2006 RX-8 Service manual

Title Section
GENERAL INFORMATION 00
ENGINE 01
SUSPENSION 02
DRIVELINE/AXLE 03
BRAKES 04
TRANSMISSION/TRANSAXLE 05
STEERING 06
HEATER, VENTILATION &
AIR CONDITIONING (HVAC) 07
RESTRAINTS 08
BODY & ACCESSORIES 09
CONTENTS
2006
Mazda
RX-8
Service
Highlights
FOREWORD
This manual explains components, system
operations and functions for the Mazda RX-8.
Forproperrepairandmaintenance,athorough
familiarization with this manual is important,
and it should always be kept in a handy place
for quick and easy reference.
All the contents of this manual, including
drawings and specifications, are the latest
available at the time of printing.
As modifications affecting repair or
maintenance occur, relevant information
supplementary to this volume will be made
available at Mazda dealers.
This manual should be kept up-to-date.
Mazda Motor Corporation reserves the right to
alter the specifications and contents of this
manual without obligation or advance notice.
Allrightsreserved.No part of thisbook maybe
reproduced or used in any form or by any
means, electronic or mechanical—including
photocopyingandrecordingandtheuseofany
kind of information storage and retrieval
system—without permission in writing.
Mazda Motor Corporation
HIROSHIMA, JAPAN
APPLICATION:
This manual is applicable to vehicles
beginning with the Vehicle Identification
Numbers (VIN), and related materials shown
on the following page.
©2005 Mazda Motor Corporation
PRINTED IN U.S.A., OCTOBER 2005
Form No. 3409–1U–05J
Part No. 9999–95–102F–06

VEHICLE IDENTIFICATION NUMBERS (VIN)
JM1 FE173✻6# 200001—
JM1 FE17N✻6# 200001—
RELATED MATERIALS
Material Name MNAO Part No.Mazda Material No.
2004 Mazda RX-8 Service Highlights 9999–95–102F–04 3378–1U–03C
2005 Mazda3, Mazda MX-5 Miata/MX-5, MAZDASPEED MX-5,
Mazda MPV, Mazda RX-8 Service Highlights 9999–95–MODL–05 3400–1U–04H
1995, 1996, 1997, 1998, 1999, 2000 OBD-II Service Highlights 9999–95–OBD2–00 3344–1U–99K
2006 Mazda RX-8 Workshop Manual 9999–95–064B–06 1857–1U–05J
Engine Workshop Manual 13B-MSP 9999–95–E13B–MSP 1773–1U–03C
Manual Transmission Workshop Manual Y16M-D 9999–95–T15M–D 1774–1U–03C
Automatic Transmission Workshop Manual RC4A-EL 9999–95–RC4A–EL 1775–1U–03C
2004 Mazda RX-8 Bodyshop Manual 9999–95–120F–04 3379–1U–03D
2006 Mazda RX-8 Wiring Diagram 9999–95–040G–06 5650–1U–05J

00
GENERAL INFORMATION
00–00–1
SECTION 00–00
Toc of SCT
GENERAL INFORMATION . . . .00-00
Toc of SCT
00–00 GENERAL INFORMATION
VEHICLE IDENTIFICATION NUMBER
(VIN) CODE . . . . . . . . . . . . . . . . . . . . . .00–00–1
VEHICLE IDENTIFICATION NUMBER
(VIN) . . . . . . . . . . . . . . . . . . . . . . . . . . . .00–00–1
UNITS . . . . . . . . . . . . . . . . . . . . . . . . . . . .00–00–2
Conversion to SI Units (Système
International d'Unités) . . . . . . . . . . . . 00–00–2
Rounding Off . . . . . . . . . . . . . . . . . . . . 00–00–2
Upper and Lower Limits . . . . . . . . . . . . 00–00–2
SAE STANDARD . . . . . . . . . . . . . . . . . . . 00–00–3
End of Toc
VEHICLE IDENTIFICATION NUMBER (VIN) CODE EHU000000000105
End Of Sie
VEHICLE IDENTIFICATION NUMBER (VIN) EHU000000000106
JM1 FE173*6# 200001—
JM1 FE17N*6# 200001—
End Of Sie
J M 1 F E 1 7 N * 6 # 1 2 3 4 5 6
Serial No.
0= Hiroshima
1= Hofu
4=2004, 5=2005...
N= 13B-Standard power
3= 13B-High power
FE= Mazda RX-8
1=Driver, Passenger Airbag,
Side Airbag, Curtain Airbag
7= Coupe
JM1= Mazda/passenger car
*=0 to 9, X
Plant
Model year
Check Digit
Engine
Body style
Restraint system
Carline, series
World manufacturer identification
EHU000ZW8008

GENERAL INFORMATION
00–00–2
UNITS EHU000000000103
Conversion to SI Units (Système International d'Unités)
•All numerical values in this manual are based on SI units. Numbers shown in conventional units are converted
from these values.
Rounding Off
•Converted values are rounded off to the same number of places as the SI unit value. For example, if the SI unit
value is 17.2 and the value after conversion is 37.84, the converted value will be rounded off to 37.8.
Upper and Lower Limits
•When the data indicates upper and lower limits, the converted values are rounded down if the SI unit value is
an upper limit and rounded up if the SI unit value is a lower limit. Therefore, converted values for the same SI
unit value may differ after conversion. For example, consider 2.7 kgf/cm2in the following specifications:
210—260 kPa {2.1—2.7 kgf/cm2, 30—38 psi}
270—310 kPa {2.7—3.2 kgf/cm2, 39—45 psi}
•The actual converted values for 2.7 kgf/cm2are 265 kPa and 38.4 psi. In the first specification, 2.7 is used as
an upper limit, so the converted values are rounded down to 260 and 38. In the second specification, 2.7 is
used as a lower limit, so the converted values are rounded up to 270 and 39.
End Of Sie
Electrical current A (ampere)
Electric power W (watt)
Electric resistance ohm
Electric voltage V (volt)
Length mm (millimeter)
in (inch)
Negative pressure kPa (kilo pascal) mmHg (millimeters of mercury)
inHg (inches of mercury)
Positive pressure
kPa (kilo pascal)
kgf/cm2(kilogram force per square
centimeter)
psi (pounds per square inch)
Torque
N·m (Newton meter)
kgf·m (kilogram force meter)
kgf·cm (kilogram force centimeter)
ft·lbf (foot pound force)
in·lbf (inch pound force)
Volume
L (liter)
US qt (U.S. quart)
Imp qt (Imperial quart)
ml (milliliter)
cc (cubic centimeter)
cu in (cubic inch)
fl oz (fluid ounce)
Weight g (gram)
oz (ounce)

GENERAL INFORMATION
00–00–3
00–00
SAE STANDARD EHU000000000104
•In accordance with new regulations, SAE (Society of Automotive Engineers) standard names and abbreviations
are now used in this manual. The table below lists the names and abbreviations that have been used in Mazda
manuals up to now and their SAE equivalents.
#1: Diagnostic trouble codes depend on the diagnostic test mode.
#2: Controlled by the PCM
#3: Device that controls engine and powertrain
#4: Directly connected to exhaust manifold
End Of Sie
SAE Standard Remark SAE Standard Remark
Abbreviation Name Abbreviation Name
AP Accelerator Pedal MAP Manifold Absolute Pressure
APP Accelerator Pedal Position MAF sensor Mass Air Flow Sensor
ACL Air Cleaner MFL Multiport Fuel Injection
A/C Air Conditioning OBD On-board Diagnostic System
BARO Barometric Pressure OL Open Loop
B+ Battery Positive Voltage OC Oxidation Catalytic Converter
CMP sensor Camshaft Position Sensor O2S Oxygen sensor
CAC Charge Air Cooler PNP Park/Neutral Position
CLS Closed Loop System PSP Power Steering Pressure
CTP Closed Throttle Position PCM Powertrain Control Module #3
CPP Clutch Pedal Position PAIR Pulsed Secondary Air Injection Pulsed
injection
CIS Continuous Fuel Injection System
CKP sensor Crankshaft Position Sensor AIR Secondary Air Injection Injection
with air
pump
DLC Data Link Connector
DTM Diagnostic Test Mode #1
DTC Diagnostic Test Code(s) SAPV Secondary Air Pulse Valve
DI Distributor Ignition SFI Sequential Multiport Fuel
Injection
DLI Distributorless Ignition
EI Electronic Ignition #2 3GR Third Gear
ECT Engine Coolant Temperature TWC Three Way Catalytic Converter
EM Engine Modification TB Throttle Body
EVAP Evaporative Emission TP sensor Throttle Position Sensor
EGR Exhaust Gas Recirculation TCC Torque Converter Clutch
FC Fan Control TCM Transmission (Transaxle) Control
Module
FF Flexible Fuel
4GR Fourth Gear TR Transmission (Transaxle) Range
GEN Generator TC Turbocharger
GND Ground VSS Vehicle Speed Sensor
HO2S Heated Oxygen Sensor With
heater VR Voltage Regulator
VAF sensor Volume Air Flow Sensor
IAC Idle Air Control WU-TWC Warm Up Three Way Catalytic
Converter #4
IAT Intake Air Temperature
KS Knock Sensor WOP Wide Open Throttle
MIL Malfunction Indicator Lamp

01–00–1
01
ENGINE
SECTION
01–00
2006 Mazda RX-8 Service Highlights (3409–1U–05J)
Revised 4/2006 (Ref. No. R027/06)
To c o f S C T
OUTLINE . . . . . . . . . . . . . . . . . . 01-00
ON-BOARD DIAGNOSTIC . . . .01-02
INTAKE-AIR SYSTEM . . . . . . . 01-13
To c o f S C T
01–00 OUTLINE
ENGINE ABBREVIATIONS . . . . . . . . . . . 01–00–1
ENGINE FEATURES . . . . . . . . . . . . . . . . 01–00–1
ENGINE SPECIFICATIONS. . . . . . . . . . . 01–00–2
End of Toc
ENGINE ABBREVIATIONS EHU010002000101
End Of Sie
ENGINE FEATURES EHU010002000102
End Of Sie
A/C Air Conditioner
APV Auxiliary Port Valve
CCM Comprehensive Component Monitor
DC Drive Cycle
CSERS Cold Start Emission Reduction Strategy
FP1 Front Primary 1
KOEO Key On Engine Off
KOER Key On Engine Running
L/F Leading Front
L/R Leading Rear
MT Manual Transmission
RP1 Rear Primary 1
SSV Secondary Shutter Valve
SW Switch
T/F Trailing Front
T/R Trailing Rear
VDI Variable Dynamic Effect Intake
VFAD Variable Fresh Air Duct
To meet OBD-II regulations •Modes 01, 02, 03, and 06 of diagnostic test modes changed

OUTLINE
01–00–2
2006 Mazda RX-8 Service Highlights (3409–1U–05J)
ENGINE SPECIFICATIONS EHU010002000103
Item
Specification
2006MY Mazda RX-8 2005MY Mazda RX-8
13B-MSP
(Standard
power)
13B-MSP
(High
power)
13B-MSP
(Standard
power)
13B-MSP
(High
power)
MECHANICAL
Engine type Rotary ←
Rotor arrangement and number In-line 2-rotor, longitudinal ←
Combustion chamber type Bathtub ←
Displacement (ml {cc, cu in}) 654 {654, 40.0}×2←
Compression ratio 10.0 ←
Compression pressure (kPa {kgf/cm2, psi} [rpm]) 830 {8.5, 120}[250] ←
Port timing
IN
Open
Primary port
ATDC
3°←
Secondary port 12°←
Auxiliary port – 38°←
Close
Primary port
ABDC
60°65°←
Secondary port 45°36°←
Auxiliary port – 80°←
EX Open BBDC 40°50°←
Close BTDC 3°←
LUBRICATION SYSTEM
Type Force-fed type ←
Oil pump
Type Trochoid gear ←
Relief valve opening pressure
(approx. quantity)
(kPa {kgf/cm2, psi}
)
441—490
{4.5—5.0, 64.0—71.0} ←
Oil filter
Type Full-flow ←
Relief valve opening pressure
(approx. quantity)
(kPa {kgf/cm2, psi}
)
78—118
{0.8—1.2, 11.4—17.1} ←
Oil pressure (approx.
quantity)
[oil temperature 100°C
{212°F}]
(kPa {kgf/cm2, psi} [rpm] ) 350 {3.57, 50.8} [3,000] ←
Oil capacity
(approx. quantity)
Oil replacement 3.3 {3.5, 2.9} ←
Oil and oil filter replacement 3.5 {3.7, 3.1} ←
(L {US qt, lmp qt}) Engine overhaul 4.7 {5.0, 4.1} ←
Total (dry engine) 5.7 {6.0, 5.0} 6.4 {6.7, 5.6} ←
Recommended oil
API service SL ←
SAE viscosity 5W–20 ←
ILSAC GF–3 ←
COOLING SYSTEM
Type Water-cooled, forced
circulation ←
Coolant capacity (L {US qt, lmp qt}) 9.8 {10.4, 8.6} ←
Water pump Centrifugal, V-ribbed belt-
driven ←
Thermostat
Ty p e Wa x ←
Opening temperature (°C {F°}) 80—84 {176—183} ←
Full-open temperature (°C {F°}) 95 {203} ←
Full-open lift (mm {in}) 8.5 {0.33} or more ←
Radiator Type Corrugated fin ←
Cooling system cap Cap valve opening pressure 73.3—103.3 {0.748—
1.053, 10.63—14.98}
←
(kPa {kgf/cm2, psi} ) ←

OUTLINE
01–00–3
01–00
Cooling fan
Type Electronic ←
Number of blades Cooling fan No.1: 5,
Cooling fan No.2: 7 ←
Outer diameter (mm {in}) 300 {11.8} ←
FUEL SYSTEM
Injector Type Multiple hole design ← Type of fuel delivery Top-feed ←
Type of drive Electronic ←
Pressure regulator control
pressure (kPa {kgf/cm2, psi}) Approx. 390 {3.98, 56.6} ←
Fuel pump type Electric ←
Fuel tank capacity (approx.
quantity) (L {US gal, lmp gal}) 60 {15.9, 13.2} ←
Fuel type Unleaded premium (unleaded high-octane)
gasoline ←
EMISSION SYSTEM
AIR system Air pump, air control valve ←
Catalyst type Three-way catalyst
(monolithic) ←
EVAP control system Canister design ←
PCV system Closed design ←
CHARGING SYSTEM ←
Battery Voltage (V) 12 ←
Type and capacity
(5 hour rate) (A·h) 75D23L (52) 50D20L (40), 55D23L (48) 75D23L (52), 75D26L (52)
Generator Out-put (V–A) 12—100 ← Regulated voltage (V) Controlled by PCM ←
Self diagnosis function ←
IGNITION SYSTEM
Ignition system
Type Distributorless Ignition
(DLI) ←
Spark advance Electronic ←
Firing order
When idling:
T/F-L/F-T/R-L/R
Except for idling:
L/F-T/F-L/R-T/R
(Independent ignition
control)
←
Spark plug Type
Leading side N3H5 18 110 (RE7C-L)*1,
N3Y8 18 110 (RE7C-L)*1,
N3Y9 18 110 (RE6C-L)*2
N3H2 18 110C
(RE7A-L)*1,
N3Y2 18 110 (RE7A-L)*1,
N3Y3 18 110 (RE6A-L)*2,
N3H5 18 110 (RE7C-L)*1,
N3Y8 18 110 (RE7C-L)*1,
N3Y9 18 110 (RE6C-L)*2
Trailing side N3H1 18 110C (RE9B-T)*1,
N3Y1 18 110 (RE9B-T)*1 ←
STARTING SYSTEM
Starter Type Coaxial reduction ←
Output (kW) 2.0 AT: 1.8*3, MT: 1.4*3
2.0*4
Item
Specification
2006MY Mazda RX-8 2005MY Mazda RX-8
13B-MSP
(Standard
power)
13B-MSP
(High
power)
13B-MSP
(Standard
power)
13B-MSP
(High
power)

OUTLINE
01–00–4
*1 : Standard equipment
*2 : Hot type plug: Available only for customers who often drive their car at very low speed which causes the plugs
to foul easily.
*3 : Applied VIN (Assumed)
JM1 FE173*5# 100001–150736
JM1 FE17N*5# 100001–150736
*4 : Applied VIN (Assumed)
JM1 FE173*5# 150737–
JM1 FE17N*5# 150737–
End Of Sie
CONTROL SYSTEM
Neutral switch (MT) ON/OFF ←
CPP switch (MT) ON/OFF ←
SSV switch ON/OFF ←
APV position sensor – Hall element ←
ECT sensor Thermistor ←
IAT sensor Thermistor ←
TP sensor Hall element ←
APP sensor Hall element ←
MAF sensor (Inside MAF) Hot-wire ←
Front HO2S Zirconia element (all range
air/fuel ratio sensor) ←
Rear HO2S Zirconia element (Stoichiometric air/fuel
ratio sensor) ←
BARO sensor Piezoelectric element ←
KS Piezoelectric element ←
Eccentric shaft position sensor Magnetic pickup ←
Metering oil pump switch ON/OFF ←
Brake switch ON/OFF ←
Throttle valve actuator DC motor ←
APV motor – DC motor ←
Fuel injector (primary 1) Multiple hole type (12
holes) ←
Fuel injector (secondary) Multiple hole type (4 holes) ←
Fuel injector (primary 2) – Multiplehole type
(4 holes) ←
Stepping motor (in metering oil pump) Stepping motor ←
Item
Specification
2006MY Mazda RX-8 2005MY Mazda RX-8
13B-MSP
(Standard
power)
13B-MSP
(High
power)
13B-MSP
(Standard
power)
13B-MSP
(High
power)

ON-BOARD DIAGNOSTIC
01–02–1
01–02
01–02 ON-BOARD DIAGNOSTIC
ON-BOARD DIAGNOSTIC OUTLINE . . . 01–02–1
Features. . . . . . . . . . . . . . . . . . . . . . . . 01–02–1
ON-BOARD DIAGNOSTIC
WIRING DIAGRAM . . . . . . . . . . . . . . . . 01–02–2
DIAGNOSTIC TEST MODE. . . . . . . . . . . 01–02–4
On-board system readiness test . . . . . 01–02–4
OBD-II Freeze Frame Data
(Mode 02). . . . . . . . . . . . . . . . . . . . . . 01–02–4
OBD-II Diagnostic Trouble Code
(Mode 03) . . . . . . . . . . . . . . . . . . . . . .01–02–5
OBD-II Diagnostic Monitoring System
Test Results (Mode 06) . . . . . . . . . . . .01–02–8
DTC DETECTION LOGIC AND
CONDITIONS . . . . . . . . . . . . . . . . . . . . .01–02–8
KOEO/KOER SELF-TEST . . . . . . . . . . . .01–02–9
PID/DATA MONITOR AND RECORD. . . .01–02–12
SIMULATION TEST . . . . . . . . . . . . . . . . .01–02–14
End of Toc
ON-BOARD DIAGNOSTIC OUTLINE EHU010200000101
Features
End Of Sie
To meet OBD-II regulations •Modes 02, 03, and 06 of diagnostic test modes changed

ON-BOARD DIAGNOSTIC
01–02–2
ON-BOARD DIAGNOSTIC WIRING DIAGRAM EHU010200000107
PCM
4E
5AC
5AF
4Q
5H
4C
4F
2O
4P
4U
5V
2N
1D
4W
4Z
2R
2E
5P
4M
2M
2G
2J
2D
3A
3D
2AD
2AC
2AA
2Z
2W
2AB
2V
2Y
5A
STARTER RELAY
IG1 IG2
ACC
START
MAIN RELAY
IGNITION RELAY
DRIVE-BY-WIRE RELAY
CPP SWITCH *
2
NEUTRAL SWITCH *
2
BRAKE SWITCH *
3
CRUISE CONTROL SWITCH *3
METERING OIL PUMP SWITCH
SSV SWITCH
REFRIGERANT PRESSURE SWITCH
OIL LEVEL SWITCH
OIL-PRESSURE SWITCH
HI, LO
MIDDLE
A/C
AMPLIFIER
ab
5J
FUEL PUMP RELAY
FUEL PUMP
SPEED CONTROL RELAY
FUEL PUMP RESISTOR
FUEL INJECTOR (FP)
FUEL INJECTOR (FS)
FUEL INJECTOR (RP)
FUEL INJECTOR (RS)
FUEL INJECTOR (FP2) *
1
FUEL INJECTOR (RP2) *
1
IGNITION COIL (T/F)
METERING OIL PUMP
EVAP SYSTEM
LEAK DETECTION
PUMP
4H
4D
*
1
: 13B-MSP (HIGH POWER)
*
2
: MT
*
3
:WITH CRUISE CONTROL SYSTEM
4T
COOLANT LEVEL SWITCH
IGNITION COIL (T/R)
IGNITION COIL (L/F)
IGNITION COIL (L/R)
c
BATTERY
d
EHU140ZT8003

ON-BOARD DIAGNOSTIC
01–02–3
01–02
End Of Sie
PCM
5U
5K
5N
5S
4K
1T
1F
1G
1J
2F
1M
5Z
1W
1L
2P
1O
2I
2T
5W
5AA
5X
5AD
2K
ab
ECT SENSOR
IAT SENSOR
MAF SENSOR
BARO SENSOR
KS
APP SENSOR
TP SENSOR
THROTTLE ACTUATOR
APV
POSITION
SENSOR
APV MOTOR
ECCENTRIC SHAFT POSITION SENSOR
FRONT HO2S
REAR HO2S
VFAD SOLENOID VALVE *1
VDI SOLENOID VALVE
SSV SOLENOID VALVE
PURGE SOLENOID VALVE
AIR SOLENOID VALVE
AIR PUMP RELAY
AIR PUMP
GENERATOR
A/C AMPLIFIER
A/C RELAY
COOLING FAN RELAY NO.1
COOLING FAN RELAY NO.2
COOLING FAN RELAY NO.3
OTHER MODULE
·EPS CONTROL MODULE
·TCM
·ABS HU/CM
·DSC HU/CM
·KEYLESS CONTROL MODULE
·TPMS CONTROL MODULE
·STEERING ANGLE SENSOR
·INSTRUMENT CLUSTER
4X
5C
5AB
4Y
5F
5AE
1Q
1C
1B
2X
2H
2B
3J
3G
3B
1S
2U
2C
1V
2Q
2A
4O
5O
5R
5T
4A
4J
5D
4V
4S
1U
APV MOTOR *1
THROTTLE BODY
*1: 13B-MSP (HIGH POWER)
CAN_H
CAN_L
NO.1
NO.2
NO.1
NO.2
ccd
EHU140ZT8004

ON-BOARD DIAGNOSTIC
01–02–4
DIAGNOSTIC TEST MODE EHU010200000102
•The diagnostic test mode is essentially carried over from that of the 2005 MY except for following.
—To meet OBD-II regulations, modes 02, 03, and 06 have been changed.
On-board system readiness test
•The items supported by the on-board system readiness test are shown below.
Continuous monitoring system
—HO2S heater
—Thermostat
—Fuel system
—Misfire
—CCM
Intermittent monitoring system
—HO2S
—AIR system
—Catalyst
—EVAP system
—Engine cooling system
—CSERS
OBD-II Freeze Frame Data (Mode 02)
•Differences between the 2006 MY and 2005 MY Freeze Frame Data monitor items are shown below.
Freeze Frame Data monitor table X: Applicable
—: Not applicable
Diagnostic test mode Item
Mode 01 Sending diagnostic data (PID data monitor/On-board system readiness test)
Mode 02 Sending freeze frame data
Mode 03 Sending emission-related malfunction code (DTC)
Mode 04 Clearing/resetting emission-related malfunction information
Mode 06 Sending intermittent monitoring system test results (DMTR)
Mode 07 Sending continuous monitoring system test results (pending code)
Mode 08 On-board device control (simulation test, active command mode)
Mode 09 Request vehicle information
2006 MY 2005 MY Full names Unit
X X DTC that caused required Freeze Frame Data storage —
X X Fuel system status Refer to list below.
X X Calculated LOAD Value %
X X Engine Coolant Temperature °C°F
X X Short term fuel trim %
X X Long term fuel trim %
X X Engine RPM rpm
X X Vehicle Speed Sensor km/h mph
X X Ignition Timing Advance °
X X Intake Air Temperature °C°F
X X Air Flow Rate from Mass Air Flow Sensor g/s
XXAbsoluteThrottle Position %
X X Commanded Secondary Air Status —
X — Rear HO2S %
X X Time since engine start s
X X Commanded Evaporative Purge %
X X Fuel Level Input %
X X Number of warm-ups since DTCs cleared —
X X Distance travelled since DTCs cleared km miles
X X Barometric Pressure kPa
X X Catalyst Temperature °C°F
X X Control module voltage V
X X Absolute load value %

ON-BOARD DIAGNOSTIC
01–02–5
01–02
Meaning of fuel system loop status
•The following information is displayed on the tester.
—Feedback operating: HO2S being used for feedback is normal.
—Feedback stops: ECT is lower than the determined feedback zone.
—Feedback stops: Open loop due to driving condition.
—Feedback stops: Open loop due to detected system fault.
OBD-II Diagnostic Trouble Code (Mode 03)
•The following DTCs have been adopted.
—P0116, P0134, P0137, P0411, P050A
•Differences between the 2006 MY and 2005 MY DTCs are shown below.
DTC table ×: Applicable
—: Not applicable
X X Commanded Equivalence Ratio —
X X Relative Throttle Position %
X X Ambient air temperature °C
X X Absolute Throttle Position No.2 %
X X Accelerator Pedal Position No.3 %
X X Accelerator Pedal Position No.4 %
X X Commanded Throttle Actuator Control %
2006 MY 2005 MY Full names Unit
DTC No. Condition MIL DC Monitor
item*1 Self -test type*4 Memory
function
2006 MY 2005 MY
P0030 ←Front HO2S heater control circuit problem ON 2 HO2S heater C, O, R ×
P0031 ←Front HO2S heater control circuit low ON 2 HO2S heater C, O, R ×
P0032 ←Front HO2S heater control circuit high ON 2 HO2S heater C, O, R ×
P0037 ←Rear HO2S heater control circuit low ON 2 HO2S heater C, O, R ×
P0038 ←Rear HO2S heater control circuit high ON 2 HO2S heater C, O, R ×
P0076 ←VDI solenoid valve control circuit low OFF 2 Other C, O, R ×
P0077 ←VDI solenoid valve control circuit high OFF 2 Other C, O, R ×
P0101 ←MAF sensor circuit range/performance problem ON 2 CCM C ×
P0102 ←MAF sensor circuit low input ON 1 CCM C, O, R ×
P0103 ←MAF sensor circuit high input ON 1 CCM C, O, R ×
P0107 ←BARO sensor circuit low input ON 1 CCM C, O, R ×
P0108 ←BARO sensor circuit high input ON 1 CCM C, O, R ×
P0111 ←IAT sensor circuit range/performance problem ON 2 CCM C ×
P0112 ←IAT sensor circuit low input ON 1 CCM C, O, R ×
P0113 ←IAT sensor circuit high input ON 1 CCM C, O, R ×
P0116*3 —Engine coolant temperature circuit range/
performance ON 2 Engine
cooling
system C×
P0117 ←ECT sensor circuit low input ON 1 CCM C, O, R ×
P0118 ←ECT sensor circuit high input ON 1 CCM C, O, R ×
P0122 ←TP sensor No.1 circuit low input ON 1 CCM C, O, R ×
P0123 ←TP sensor No.1 circuit high input ON 1 CCM C, O, R ×
P0125 ←Insufficient coolant temperature for closed loop fuel
control ON 2 Engine
cooling
system C×
P0126 ←Insufficient coolant temperature for stable operation ON 2 Thermostat C ×
P0130 ←Front HO2S circuit problem ON 2 HO2S C, O, R ×
P0131 ←Front HO2S circuit low voltage ON 2 HO2S C, O, R ×
P0132 ←Front HO2S circuit high voltage ON 2 HO2S C, O, R ×
P0133 ←Front HO2S circuit slow response ON 2 HO2S C ×
P0134*3 — Front HO2S no activity detected ON 2 HO2S C, R ×
P0137*3 — Rear HO2S circuit low input ON 2 HO2S C ×
P0138 ←Rear HO2S circuit high voltage ON 2 HO2S C, R ×

ON-BOARD DIAGNOSTIC
01–02–6
P0139 ←Rear HO2S circuit slow response ON 2 HO2S C, R ×
P0171 ←System too lean ON 2 Fuel system C, R ×
P0172 ←System too rich ON 2 Fuel system C, R ×
P0222 ←TP sensor No.2 circuit low input ON 1 CCM C, O, R ×
P0223 ←TP sensor No.2 circuit high input ON 1 CCM C, O, R ×
P0300 ←Random misfire detected Flas
h/ON 1 or 2Misfire C ×
P0301 ←Front rotor misfire detected Flas
h/ON 1 or 2Misfire C ×
P0302 ←Rear rotor misfire detected Flas
h/ON 1 or 2Misfire C ×
P0327 ←KS circuit low input ON 1 CCM C, O, R ×
P0328 ←KS circuit high input ON 1 CCM C, O, R ×
P0335 ←Eccentric shaft position sensor circuit problem ON 1 CCM C ×
P0336 ←Eccentric shaft position sensor circuit range/
performance problem ON 1 CCM C, R ×
P0410 ←Secondary air injection system problem ON 2 AIR system C, R ×
P0411*3 —Secondary air injection system incorrect upstream
flow ON 2 AIR system C ×
P0420 ←Catalyst system efficiency below threshold ON 2 Catalyst C ×
P0441 ←EVAP system incorrect purge flow ON 2 EVAP system C, R ×
P0442 ←EVAP system leak detected (small leak) ON 2 EVAP system C, R ×
P0443 ←Purge solenoid valve circuit problem ON 2 CCM C, R ×
P0446 ←EVAP system vent control circuit problem ON 2 EVAP system C, R ×
P0455 ←EVAP system leak detected (large leak) ON 2 EVAP system C, R ×
P0456*2 ←EVAP system leak detected (very small leak) ON 2 EVAP system C, R ×
P0461 ←Fuel gauge sender unit circuit range/performance
problem ON 2 CCM C ×
P0462 ←Fuel gauge sender unit (main) circuit low input ON 2 CCM C, O, R ×
P0463 ←Fuel gauge sender unit (main) circuit high input ON 2 CCM C, O, R ×
P0480 ←Cooling fan No.1 control circuit problem OFF 2 Other C, O, R ×
P0481 ←Cooling fan No.2 control circuit problem OFF 2 Other C, O, R ×
P0500 ←VSS circuit problem ON 2 CCM C ×
P0505 ←Idle air control system problem OFF — — R —
P0506 ←Idle air control system RPM lower than expected ON 2 CCM C ×
P0507 ←Idle air control system RPM higher than expected ON 2 CCM C ×
P050A*3 — Cold start idle air control system performance ON 2 CSERS C ×
P0562 ←System voltage low (KAM) ON 1 CCM C, O, R ×
P0564 ←Cruise control switch input circuit problem OFF 1 Other C, O, R ×
P0571 ←Brake switch input circuit problem OFF 1 Other C, O, R ×
P0601 ←PCM memory check sum error ON 1 CCM C, O, R ×
P0602 ←PCM programming error ON 1 CCM C, O, R ×
P0604 ←PCM random access memory error ON 1 CCM C, O, R ×
P0610 ←PCM vehicle options error ON 1 CCM C, O, R ×
P0638 ←Throttle actuator control circuit range/performance
problem ON 1 CCM C ×
P0661 ←SSV solenoid valve control circuit low ON 2 CCM C, O, R ×
P0662 ←SSV solenoid valve control circuit high ON 2 CCM C, O, R ×
P0703 ←Brake switch input circuit problem ON 2 CCM C ×
P0704*3 ←CPP switch input circuit problem ON 2 CCM C ×
P0850*3 ←Neutral switch input circuit problem ON 2 CCM C ×
P1260 ←Immobilizer system problem OFF 1 Other C, O —
P1686 ←Metering oil pump control circuit low flow side
problem ON 1 CCM C, R ×
DTC No. Condition MIL DC Monitor
item*1 Self -test
type*4 Memory
function
2006 MY 2005 MY

ON-BOARD DIAGNOSTIC
01–02–7
01–02
P1687 ←Metering oil pump control circuit high flow side
problem ON 1 CCM C, R ×
P1688 ←Metering oil pump control circuit initial check
problem ON 1 CCM C, R ×
P2004*3 ←APV stuck open ON 2 CCM C, O, R ×
P2006*3 ←APV motor control driver IC problem ON 2 CCM C ×
P2009*3 ←APV motor control circuit low ON 2 CCM C, O, R ×
P2010*3 ←APV motor control circuit high ON 2 CCM C, O, R ×
P2016*3 ←APV position sensor circuit low ON 2 CCM C, O, R ×
P2017*3 ←APV position sensor circuit high ON 2 CCM C, O, R ×
P2067 ←Fuel gauge sender unit (sub) circuit low input ON 2 CCM C, O, R ×
P2068 ←Fuel gauge sender unit (sub) circuit high input ON 2 CCM C, O, R ×
P2070 ←SSV stuck open ON 2 CCM C, O, R ×
P2096 ←Target A/F feedback system too lean ON 2 Fuel system C, R ×
P2097 ←Target A/F feedback system too rich ON 2 Fuel system C, R ×
P2102 ←Drive-by-wire relay control circuit low ON 1 CCM C, O, R ×
P2103 ←Drive-by-wire relay control circuit high ON 1 CCM C, O, R ×
P2106 ←Throttle actuator control system-forced limited
power ON 1 CCM C ×
P2107 ←Throttle actuator control module processor error ON 1 CCM C, O, R ×
P2108 ←Throttle actuator control module performance error ON 1 CCM C ×
P2109 ←TP sensor minimum stop range/performance
problem ON 1 CCM C ×
P2112 ←Throttle actuatorcontrol systemrange/performance
problem ON 1 CCM C ×
P2119 ←Throttle actuator control throttle body range/
performance problem ON 2 CCM C, O, R ×
P2122 ←APP sensor No.1 circuit low input ON 1 CCM C, O, R ×
P2123 ←APP sensor No.1 circuit high input ON 1 CCM C, O, R ×
P2127 ←APP sensor No.2 circuit low input ON 1 CCM C, O, R ×
P2128 ←APP sensor No.2 circuit high input ON 1 CCM C, O, R ×
P2135 ←TP sensor No.1/No.2 voltage correlation problem ON 1 CCM C, O, R ×
P2136 ←TP sensor No.1/No.3 (calculation value in PCM)
voltage correlation problem ON 1 CCM C, O, R ×
P2138 ←TP sensor No.3 (calculation value in PCM)/No.4 (calculation value in PCM) voltage correlation
problem ON 1 CCM C, O, R ×
P2195 ←Front HO2S signal stuck lean ON 2 HO2S C, R ×
P2196 ←Front HO2S signal stuck rich ON 2 HO2S C, R ×
P2257 ←AIR pump relay control circuit low ON 2 AIR system C, O, R ×
P2258 ←AIR pump relay control circuit high ON 2 AIR system C, O, R ×
P2259 ←AIR solenoid valve control circuit low ON 2 AIR system C, O, R ×
P2260 ←AIR solenoid valve control circuit high ON 2 AIR system C, O, R ×
P2270 ←Rear HO2S signal stuck lean ON 2 HO2S C, R ×
P2271 ←Rear HO2S signal stuck rich ON 2 HO2S C, R ×
P2401 ←EVAP system leak detection pump control circuit
low ON 2 EVAP system C, O, R ×
P2402 ←EVAP system leak detection pump control circuit
high ON 2 EVAP system C, O, R ×
P2404 ←EVAP system leak detection pump sense circuit
range/performance problem ON 2 EVAP system C ×
P2405 ←EVAP system leak detection pump sense circuit
low ON 2 EVAP system C, O, R ×
P2407 ←EVAP system leak detection pump sense circuit
intermittent/erratic problem ON 2 EVAP system C, O, R ×
DTC No. Condition MIL DC Monitor
item*1 Self -test
type*4 Memory
function
2006 MY 2005 MY

ON-BOARD DIAGNOSTIC
01–02–8
*1 : Indicates the applicable item in the On-Board System Readiness Test as defined by CARB.
*2 : California emission regulation applicable model
*3 : 13B-MSP (HIGH POWER)
*4 : C: CMDTC self-test, O: KOEO self-test, R: KOER self-test
OBD-II Diagnostic Monitoring System Test Results (Mode 06)
•Differences between the 2006 MY and 2005 MY diagnostic monitoring system test results are shown below.
DMTR table
*1 : California emission regulation applicable model
End Of Sie
DTC DETECTION LOGIC AND CONDITIONS EHU010200000103
•The following DTCs have been adopted detection condition.
—P0116, P0134, P0137, P0411, P050A
•The following DTCs have been changed detection condition.
—P0030
•Detection conditions are shown below.
P0030 Front HO2S heater control circuit problem
•The PCM monitors the front HO2S impedance when under the front HO2S heater control for 190 s. If the
impedance is more than 44 ohms while PCM turns front HO2S heater on, the PCM determines that there is a
front HO2S heater control circuit problem.
P0116 Engine coolant temperature circuit range/performance
•The PCM monitors the maximum value and minimum value of engine coolant temperature when the engine is
started and 5 min have been passed after leaving the vehicle 6 h or more. If difference between maximum and
minimum values of engine coolant temperature is below 5.6 °C {42.1 °F} the PCM determines that there is an
ECT circuit range/performance problem.
P2502 ←Charging system voltage problem OFF 1 Other C, R ×
P2503 ←Charging system voltage low OFF 1 Other C, R ×
P2504 ←Charging system voltage high OFF 1 Other C, R ×
DTC No. Condition MIL DC Monitor
item*1 Self -test
type*4 Memory
function
2006 MY 2005 MY
Test ID Description Related system
2006 MY 2005 MY
10:01:80 ←Response lean to rich
HO2S (front HO2S)
10:01:81 ←Response rich to lean
10:01:82 — Response lean to rich delayed
10:01:83 — Response rich to lean delayed
10:02:03 ←Low sensor voltage for switch time calculation HO2S (rear HO2S)10:02:04 ←High sensor voltage for switch time calculation
10:02:05 ←Rich to lean sensor switching time
10:21:80 ←Front and rear HO2S switching time ratio Catalyst
10:3A:80 ←Large leak check
EVAP system
10:3B:80 ←Small leak check
10:3C:80*1 ←Very small leak check
10:3D:80 ←Purge flow monitor
10:71:80 ←Secondary airflow test 1 (secondary air functional check) AIR system
10:71:81 — Secondary airflow test 2 (secondary airflow rate check)
10:A2:0B ←Exponentially weighted moving average misfire counts for
last 10 driving cycles
Misfire
10:A2:0C ←Misfire counts for last/current driving cycles
10:A3:0B ←Exponentially weighted moving average misfire counts for
last 10 driving cycles
10:A3:0C ←Misfire counts for last/current driving cycles
10:E1:81 ←ECT Thermostat

ON-BOARD DIAGNOSTIC
01–02–9
01–02
P0134 Front HO2S no activity detected
•The PCM monitors the front HO2S element impedance when the following conditions are met. If the front
HO2S element impedance is 50 ohms or more, the PCM determines that front HO2S is not activated.
MONITORING CONDITIONS
—HO2S, HO2S heater and TWC Repair Verification Drive Mode
—Following conditions are met
•Time from engine start is above 40 s (ECT when engine start is 20 °C {68 °F}).
P0137 Rear HO2S circuit low input
•The PCM monitors input voltage from rear HO2S. If the input voltage from the rear HO2S is below 0.1 V for
35.2 s the PCM determines that circuit input is low.
MONITORING CONDITIONS
—HO2S, HO2S heater and TWC repair verification drive mode
—Following conditions are met.
•Engine speed is above 1,500 rpm.
•Engine coolant temperature is above 70 °C {158 °F}.
•Fuel injector control in rear HO2S closed loop control.
•The PCM monitors the input voltage from the rear HO2S when the following conditions are met. Under the
following monitoring conditions, if the input voltage from the rear HO2S does not even exceed 0.1 V though
the short term fuel trim is controlled, the PCM determines that sensor circuit input is low.
P0411 Secondary air injection system incorrect upstream flow
•The PCM monitors the front HO2S output current when the Secondary air injection system is operating. If the
output current is less than the specification, the PCM determines that there is a Secondary air injection system
problem.
P050A Cold start idle air control system performance
•The PCM monitors actual idle speed while fast idle up correction operating. If the idle speed is out of specified
range, the PCM determines that the idle air control has performance problem.
End Of Sie
KOEO/KOER SELF-TEST EHU010200000104
•Differences between the 2006 MY and 2005 MY KOEO/KOER self-test items are shown below.
KOEO/KOER self-test table ×: Applicable
—: Not applicable
DTC No. Condition Test condition
2006 MY 2005 MY KOEO KOER
P0030 ←Front HO2S heater control circuit problem ××
P0031 ←Front HO2S heater control circuit low ××
P0032 ←Front HO2S heater control circuit high ××
P0037 ←Rear HO2S heater control circuit low ××
P0038 ←Rear HO2S heater control circuit high ××
P0076 ←VDI solenoid valve control circuit low ××
P0077 ←VDI solenoid valve control circuit high ××
P0101 ←MAF sensor circuit range/performance problem — —
P0102 ←MAF sensor circuit low input ××
P0103 ←MAF sensor circuit high input ××
P0107 ←BARO sensor circuit low input ××
P0108 ←BARO sensor circuit high input ××
P0111 ←IAT sensor circuit range/performance problem — —
P0112 ←IAT sensor circuit low input ××
P0113 ←IAT sensor circuit high input ××
P0116 — Engine coolant temperature circuit range/performance — —
P0117 ←ECT sensor circuit low input ××
P0118 ←ECT sensor circuit high input ××
P0122 ←TP sensor No.1 circuit low input ××
P0123 ←TP sensor No.1 circuit high input ××
P0125 ←Insufficient coolant temperature for closed loop fuel control — —
P0126 ←Insufficient coolant temperature for stable operation — —
P0130 ←Front HO2S circuit problem ××
P0131 ←Front HO2S circuit low voltage ××
P0132 ←Front HO2S circuit high voltage ××

ON-BOARD DIAGNOSTIC
01–02–10
P0133 ←Front HO2S circuit slow response — —
P0134 — Front HO2S no activity detected — ×
P0137 — Rear HO2S circuit low input — —
P0138 ←Rear HO2S circuit high voltage — ×
P0139 ←Rear HO2S circuit slow response — ×
P0171 ←System too lean — ×
P0172 ←System too rich — ×
P0222 ←TP sensor No.2 circuit low input ××
P0223 ←TP sensor No.2 circuit high input ××
P0300 ←Random misfire detected — —
P0301 ←Front rotor misfire detected — —
P0302 ←Rear rotor misfire detected — —
P0327 ←KS circuit low input ××
P0328 ←KS circuit high input ××
P0335 ←Eccentric shaft position sensor circuit problem — —
P0336 ←Eccentric shaft position sensor circuit range/performance problem — ×
P0410 ←Secondary air injection system problem — ×
P0411 — Secondary air injection system incorrect upstream flow — —
P0420 ←Catalyst system efficiency below threshold — —
P0441 ←EVAP system incorrect purge flow — ×
P0442 ←EVAP system leak detected (small leak) — ×
P0443 ←Purge solenoid valve circuit problem — ×
P0446 ←EVAP system vent control circuit problem — ×
P0455 ←EVAP system leak detected (large leak) — ×
P0456 ←EVAP system leak detected (very small leak) — ×
P0461 ←Fuel gauge sender unit circuit range/performance problem — —
P0462 ←Fuel gauge sender unit (main) circuit low input ××
P0463 ←Fuel gauge sender unit (main) circuit high input ××
P0480 ←Cooling fan No.1 control circuit problem ××
P0481 ←Cooling fan No.2 control circuit problem ××
P0500 ←VSS circuit problem — —
P0505 ←Idle air control system problem — ×
P0506 ←Idle air control system RPM lower than expected — —
P0507 ←Idle air control system RPM higher than expected — —
P050A — Cold start idle air control system performance — —
P0562 ←System voltage low (KAM) ××
P0564 ←Cruise control switch input circuit problem ××
P0571 ←Brake switch input circuit problem ××
P0601 ←PCM memory check sum error ××
P0602 ←PCM programming error ××
P0604 ←PCM random access memory error ××
P0610 ←PCM vehicle options error ××
P0638 ←Throttle actuator control circuit range/performance problem — —
P0661 ←SSV solenoid valve control circuit low ××
P0662 ←SSV solenoid valve control circuit high ××
P0703 ←Brake switch input circuit problem — —
P0704 ←CPP switch input circuit problem — —
P0850 ←Neutral switch input circuit problem — —
P1260 ←Immobilizer system problem ×—
P1686 ←Metering oil pump control circuit low flow side problem — ×
P1687 ←Metering oil pump control circuit high flow side problem — ×
P1688 ←Metering oil pump control circuit initial check problem — ×
P2004 ←APV stuck open ××
DTC No. Condition Test condition
2006 MY 2005 MY KOEO KOER
