Mazda MX-5 2021 User manual

Thank you for choosing a Mazda. We at Mazda design and build vehicles with complete
customer satisfaction in mind.
To help ensure enjoyable and trouble-free operation of your Mazda, read this manual
carefully and follow its recommendations.
An Authorized Mazda Dealer knows your vehicle best. So when maintenance or service is
necessary, that's the place to go.
Our nationwide network of Mazda professionals is dedicated to providing you with the best
possible service.
We assure you that all of us at Mazda have an ongoing interest in your motoring pleasure
and in your full satisfaction with your Mazda product.
Mazda Motor Corporation
HIROSHIMA, JAPAN
Important Notes About This Manual
Keep this manual in the trunk as a handy reference for the safe and enjoyable use of your Mazda. Should you
resell the vehicle, leave this manual with it for the next owner.
All specifications and descriptions are accurate at the time of printing. Because improvement is a constant goal
at Mazda, we reserve the right to make changes in specifications at any time without notice and without obliga‐
tion.
Air Conditioner and the Environment
Your Mazda's genuine air conditioner is filled with a refrigerant that has been found not to damage the earth's
ozone layer. If the air conditioner does not operate properly, consult an Authorized Mazda Dealer.
Perchlorate
Certain components of this vehicle such as [air bag modules, seat belt pretensioners, lithium batteries,…] may
contain Perchlorate Material-- Special handling may apply for service or vehicle end of life disposal. See
www.dtsc.ca.gov/hazardouswaste/perchlorate.
Please be aware that this manual applies to all models, equipment and options. As a result, you may find
some explanations for equipment not installed on your vehicle.
©2021 Mazda Motor Corporation
September 2021 (Print1)
A Word to Mazda Owners
MX-5_8KH8-EA-21K_Edition1_old 2021-9-1 11:05:15

We want to help you get the most driving
pleasure from your vehicle. Your owner's
manual, when read from cover to cover,
can do that in many ways.
Illustrations complement the words of the
manual to best explain how to enjoy your
Mazda. By reading your manual, you can
find out about the features, important
safety information, and driving under
various road conditions.
The symbol below in this manual means
“Do not do this” or “Do not let this
happen”.
Index: A good place to start is the Index,
an alphabetical listing of all information in
your manual.
You'll find several WARNINGs,
CAUTIONs, and NOTEs in the manual.
WARNING
A WARNING indicates a situation in which
serious injury or death could result if the
warning is ignored.
CAUTION
A CAUTION indicates a situation in which
bodily injury or damage to your vehicle, or
both, could result if the caution is ignored.
NOTE
A NOTE provides information and
sometimes suggests how to make better
use of your vehicle.
The following symbol, located on some
parts of the vehicle, indicates that this
manual contains information related to the
part.
Please refer to the manual for a detailed
explanation.
How to Use This Manual
MX-5_8KH8-EA-21K_Edition1_old 2021-9-1 11:05:15

Table of Contents
Pictorial Index
Interior, exterior views and part identification of your Mazda.
1
Essential Safety Equipment
Important information about safety equipment, including seats, seat belt
system, child-restraint systems and SRS air bags.
2
Before Driving
Use of various features, including keys, doors, mirrors and windows.
3
When Driving
Information concerning safer driving and stopping.
4
Interior Features
Use of various features for ride comfort, including air-conditioning system
and audio system.
5
Maintenance and Care
How to keep your Mazda in top condition.
6
If Trouble Arises
Helpful information on what to do if a problem arises with the vehicle.
7
Customer Information and Reporting Safety Defects
Important consumer information including warranties and add-on
equipment.
8
Specifications
Technical information about your Mazda.
9
Index
10
MX-5_8KH8-EA-21K_Edition1_old 2021-9-1 11:05:15

1Pictorial Index
Interior, exterior views and part identification of your Mazda.
Interior Overview..............................1-2
Interior Equipment (View A)........1-2
Interior Equipment (View B)........1-3
Interior Equipment (View C)........1-4
Interior Equipment (View D)........1-5
Exterior Overview.............................1-7
Convertible Top (Soft Top)...........1-7
Convertible Top (Hardtop)........... 1-8
1-1
MX-5_8KH8-EA-21K_Edition1_old 2021-9-1 11:05:15

Interior Equipment (View A)
①Door-lock knob..................................................................................................... page 3-18
②Turn and lane-change signal..................................................................................page 4-51
③Lighting control.....................................................................................................page 4-45
④Wiper and washer lever.........................................................................................page 4-52
⑤DSC OFF switch................................................................................................... page 4-69
⑥Lane Departure Warning System (LDWS) OFF switch........................................page 4-82
⑦Outside mirror switch............................................................................................page 3-27
⑧Door-lock switch................................................................................................... page 3-17
⑨Power window lock switch................................................................................... page 3-30
⑩Power window switches........................................................................................page 3-30
Pictorial Index
Interior Overview
1-2 The equipment and installation position varies by vehicle
MX-5_8KH8-EA-21K_Edition1_old 2021-9-1 11:05:15

Interior Equipment (View B)
①Audio control switches..........................................................................................page 5-21
②Dashboard illumination knob................................................................................page 4-16
③Instrument cluster..................................................................................................page 4-12
④Cruise control switches.......................................................................................page 4-109
⑤Push button start......................................................................................................page 4-4
⑥Retractable hardtop switch....................................................................................page 3-41
⑦Hazard warning flasher switch..............................................................................page 4-58
⑧Seat warmer switches............................................................................................page 2-12
⑨Steering shift switches...........................................................................................page 4-38
⑩Lock release lever................................................................................................... page 2-5
⑪Trunk release button..............................................................................................page 3-19
⑫Hood release handle.............................................................................................. page 6-17
Pictorial Index
Interior Overview
The equipment and installation position varies by vehicle
1-3
MX-5_8KH8-EA-21K_Edition1_old 2021-9-1 11:05:15

Interior Equipment (View C)
①SRS air bags.......................................................................................................... page 2-36
②Climate control system............................................................................................page 5-2
③Rear window defogger switch...............................................................................page 4-56
④Mazda Connect......................................................................................................page 5-14
⑤Accessory socket...................................................................................................page 5-36
⑥External input terminal..........................................................................................page 5-14
⑦Drive selection switch........................................................................................... page 4-70
⑧Commander switch................................................................................................page 5-19
⑨Shift lever/Selector lever............................................................................. page 4-32, 4-35
⑩Fuse block (Left side)............................................................................................page 6-47
Pictorial Index
Interior Overview
1-4 The equipment and installation position varies by vehicle
MX-5_8KH8-EA-21K_Edition1_old 2021-9-1 11:05:15

Interior Equipment (View D)
▼Convertible Top (Soft Top)
①Windblocker.......................................................................................................... page 5-44
②Seat side box......................................................................................................... page 5-42
③Cup holders........................................................................................................... page 5-38
④Console box...........................................................................................................page 5-42
⑤Interior light.......................................................................................................... page 5-35
⑥Rearview mirror.................................................................................................... page 3-28
⑦Sunvisor.................................................................................................................page 5-35
⑧Vanity mirror......................................................................................................... page 5-35
⑨Parking brake........................................................................................................ page 4-63
⑩Seat..........................................................................................................................page 2-5
⑪SRS air bag............................................................................................................page 2-36
⑫Back trim storage boxes........................................................................................ page 5-43
⑬Seat belt.................................................................................................................page 2-13
Pictorial Index
Interior Overview
The equipment and installation position varies by vehicle
1-5
MX-5_8KH8-EA-21K_Edition1_old 2021-9-1 11:05:15

▼Convertible Top (Hardtop)
①Windblocker.......................................................................................................... page 5-44
②Seat side box......................................................................................................... page 5-42
③Cup holders........................................................................................................... page 5-38
④Console box...........................................................................................................page 5-42
⑤Interior light.......................................................................................................... page 5-35
⑥Rearview mirror.................................................................................................... page 3-28
⑦Sunvisor.................................................................................................................page 5-35
⑧Vanity mirror......................................................................................................... page 5-35
⑨Parking brake........................................................................................................ page 4-63
⑩Seat..........................................................................................................................page 2-5
⑪SRS air bag............................................................................................................page 2-36
⑫Back trim storage box........................................................................................... page 5-43
⑬Seat belt.................................................................................................................page 2-13
Pictorial Index
Interior Overview
1-6 The equipment and installation position varies by vehicle
MX-5_8KH8-EA-21K_Edition1_old 2021-9-1 11:05:15

Convertible Top (Soft Top)
①Hood......................................................................................................................page 6-17
②Windshield wiper blades....................................................................................... page 6-25
③Convertible Top (Soft Top)................................................................................... page 3-33
④Door and key.........................................................................................................page 3-14
⑤Fuel-filler lid......................................................................................................... page 3-25
⑥Wheels and Tires...................................................................................................page 6-34
⑦Exterior lights........................................................................................................page 6-38
⑧Trunk Lid...............................................................................................................page 3-19
⑨Outside mirror....................................................................................................... page 3-27
Pictorial Index
Exterior Overview
The equipment and installation position varies by vehicle
1-7
MX-5_8KH8-EA-21K_Edition1_old 2021-9-1 11:05:15

Convertible Top (Hardtop)
①Hood......................................................................................................................page 6-17
②Windshield wiper blades....................................................................................... page 6-25
③Convertible Top (Hardtop)....................................................................................page 3-38
④Door and key......................................................................................................... page 3-14
⑤Fuel-filler lid......................................................................................................... page 3-25
⑥Wheels and Tires...................................................................................................page 6-34
⑦Exterior lights........................................................................................................page 6-38
⑧Trunk Lid...............................................................................................................page 3-19
⑨Outside mirror....................................................................................................... page 3-27
Pictorial Index
Exterior Overview
1-8 The equipment and installation position varies by vehicle
MX-5_8KH8-EA-21K_Edition1_old 2021-9-1 11:05:15

2Essential Safety Equipment
Important information about safety equipment, including seats, seat
belt system, child-restraint systems and SRS air bags.
Seats.................................................... 2-2
Seat Precautions............................2-2
Seat............................................... 2-5
Head Restraints...........................2-11
Seat Warmer.................................... 2-12
Seat Warmer
*
..............................2-12
Seat Belt Systems.............................2-13
Seat Belt Precautions..................2-13
Seat Belt......................................2-16
Seat Belt Warning Systems.........2-17
Seat Belt Pretensioner and Load
Limiting Systems........................2-18
Seat Belt Extender...................... 2-19
Child Restraint................................ 2-21
Child-Restraint Precautions........2-21
Child-Restraint System
Installation.................................. 2-25
Child-Restraint System Suitability
for Various Seat Positions
Table........................................... 2-27
Installing Child-Restraint
Systems.......................................2-29
SRS Air Bags....................................2-36
Supplemental Restraint System
(SRS) Precautions.......................2-36
Supplemental Restraint System
Components................................2-42
How the SRS Air Bags Work..... 2-43
SRS Air Bag Deployment
Criteria........................................2-46
Limitations to SRS Air Bag........2-47
Passenger Occupant Classification
System........................................ 2-49
Constant Monitoring...................2-55
*Some models. 2-1
MX-5_8KH8-EA-21K_Edition1_old 2021-9-1 11:05:15

Seat Precautions
WARNING
Make sure the adjustable components of a seat are locked in place:
Adjustable seats and seatbacks that are not securely locked are dangerous. In a sudden stop
or collision, the seat or seatback could move, causing injury. Make sure the adjustable
components of the seat are locked in place by attempting to slide the seat forward and
backward and rocking the seatback.
Never allow children to adjust a seat:
Allowing children to adjust a seat is dangerous as it could result in serious injury if a child's
hands or feet become caught in the seat.
Do not drive with the seatback unlocked:
All of the seatbacks play an important role in your protection in a vehicle. Leaving the
seatback unlocked is dangerous as it can allow passengers to be ejected or thrown around
and baggage to strike occupants in a sudden stop or collision, resulting in severe injury. After
adjusting the seatback at any time, even when there are no other passengers, rock the
seatback to make sure it is locked in place.
Adjust a seat only when the vehicle is stopped:
If the seat is adjusted while the vehicle is being driven, the seating posture may become
unstable and the seat could move unexpectedly resulting in injury.
Do not modify or replace the seats:
Modifying or replacing the seats such as replacing the upholstery or loosening any bolts is
dangerous. The seats contain air bag components essential to the supplemental restraint
system. Such modications could damage the supplemental restraint system and result in
serious injury. Consult an Authorized Mazda Dealer if there is any need to remove or reinstall
the seats.
Do not drive with damaged seats:
Driving with damaged seats, such as seat cushions torn or damaged down to the urethane, is
dangerous. A collision, even one not strong enough to inate the air bags, could damage the
seats which contain essential air bag components. If there was a subsequent collision, an air
bag may not deploy which could lead to injuries. Always have an Authorized Mazda Dealer
inspect the seats, seat belt pretensioners and air bags after a collision.
Essential Safety Equipment
Seats
2-2
MX-5_8KH8-EA-21K_Edition1_old 2021-9-1 11:05:15

Do not drive with either seats reclined:
Sitting in a reclined position while the vehicle is moving is dangerous because you do not get
the full protection from seat belts. During sudden braking or a collision, you can slide under
the lap belt and suer serious internal injuries. For maximum protection, sit well back and
upright.
Do not place an object such as a cushion between the seatback and your back:
Putting an object such as a cushion between the seatback and your back is dangerous
because you will be unable to maintain a safe driving posture and the seat belt cannot
function at its full capacity in a collision, which could result in a serious accident, injury or
death.
Do not place objects under the seat:
The object could get stuck and cause the seat to not be xed securely, and result in an
accident.
Do not stack cargo higher than the seatbacks:
Stacking luggage or other cargo higher than the seatbacks is dangerous. During sudden
braking or a collision, objects can y around and become projectiles that may hit and injure
passengers.
Make sure luggage and cargo is secured before driving:
Not securing cargo while driving is dangerous as it could move or be crushed during sudden
braking or a collision and cause injury.
Additionally, if the air bags deploy, the cargo may scatter which could result in serious injury
or death.
Always leave your car locked and keep the car keys safely away from children:
Leaving your car unlocked or the keys in reach of children is dangerous. Children who nd
their way into the trunk through an open trunk can become accidentally locked in the trunk.
This could result in death or brain damage from heat prostration, particularly in the summer.
Always lock the doors and the trunk.
Essential Safety Equipment
Seats
2-3
MX-5_8KH8-EA-21K_Edition1_old 2021-9-1 11:05:15

CAUTION
When operating a seat, be careful not to put your hands or ngers near the moving parts of
the seat or on the side trim to prevent injury.
When moving the seats, make sure there is no cargo in the surrounding area. If the cargo
gets caught it could damage the cargo.
When moving the seats forward and rearward or returning a rear-reclined seatback to its
upright position, make sure you hold onto the seatback with your hand while operating. If
the seatback is not held, the seat will move suddenly and could cause injury.
When inserting your hand under the seat to clean the cabin or pick up something you
dropped under the seat, be careful not to hurt yourself. If you contact the moving parts of
the seat rail or seat frame, it could result in injury.
Essential Safety Equipment
Seats
2-4
MX-5_8KH8-EA-21K_Edition1_old 2021-9-1 11:05:15

Seat
▼Adjusting the Driver's Seat
Using the driving position set up procedure recommended by Mazda allows you to maintain
a relaxed posture, drive the vehicle for longer periods without feeling tired, and make quick
operations naturally.
Also, you can be assured of a clear view in the forward direction to help you drive more
safely and comfortably.
The adjustments for the driving position recommended by Mazda are done using the
following procedures.
1. Moving the steering wheel and seat to their default positions.
2. Adjusting the seatback angle.
3. Adjusting the seat position forward and back.
4. Adjusting the steering wheel position.
Seat Slide
To move a seat forward or backward, raise the lever and slide the seat to the desired position
and release the lever.
Make sure the lever returns to its original position and the seat is locked in place by
attempting to push it forward and backward.
Height Adjustment for Front Edge of Seat Bottom
To adjust the height for front edge of the seat bottom, rotate the dial to the desired position.
Seat Recline
To change the seatback angle, lean forward slightly while raising the lever. Then lean back
to the desired position and release the lever.
Make sure the lever returns to its original position and the seatback is locked in place by
attempting to push it forward and backward.
Essential Safety Equipment
Seats
2-5
MX-5_8KH8-EA-21K_Edition1_old 2021-9-1 11:05:15

Before making adjustments to the driving position recommended by Mazda
Before making adjustments, move the steering wheel and seat to their default positions.
How to move the steering wheel to its default position
WARNING
Never adjust the steering wheel while the vehicle is moving:
Adjusting the steering wheel while the vehicle is moving is dangerous. Moving it can very
easily cause the driver to abruptly turn to the left or right. This can lead to loss of control or an
accident.
After adjusting the steering wheel position, make sure it is securely locked by trying to move it
up and down:
Driving with the steering wheel not securely locked in position is dangerous. If the steering
wheel moves unexpectedly while driving, you could lose control of the steering resulting in an
accident.
Lower the lever, move the steering wheel to the lowest position, and then push it down and
all the way back.
Lock release lever
How to move a driver’s seat to its default position
1. Slide the seat all the way back.
2. Sit squarely in the seat and rest your back against the seatback.
Essential Safety Equipment
Seats
2-6
MX-5_8KH8-EA-21K_Edition1_old 2021-9-1 11:05:15

Seat adjustment procedure for the driving position recommended by Mazda
Adjusting the seatback angle (reclining)
Adjust the seatback to the angle providing a comfortable seated posture.
1. With your posture slightly slouched, move the seatback forward to the angle where your
waist feels slightly cramped.
2. Move the seatback backward to a comfortable seated posture without any feeling of
cramping in your waist.
Essential Safety Equipment
Seats
2-7
MX-5_8KH8-EA-21K_Edition1_old 2021-9-1 11:05:15

Adjusting the seat position forward and back (sliding)
Adjust the seat to the position best for operating the accelerator and brake pedals.
1. Place your left foot on the footrest, your right foot between the accelerator and brake
pedals, and position your heel to the position allowing easy switching between the
pedals.
2. With your heel set on the floor, set your right foot on the brake pedal and move the seat
forward as far as possible until you feel a slight cramping in your ankle.
3. With your right foot set on the brake pedal, move the seat back until you no longer feel
cramping in your ankle.
4. With your heel set on the floor, make sure you can move your foot between the brake
pedal and accelerator pedal smoothly.
5. Depress the accelerator pedal completely with your heel set on the floor and make sure
that your ankle does not feel over-stretched.
Essential Safety Equipment
Seats
2-8
MX-5_8KH8-EA-21K_Edition1_old 2021-9-1 11:05:15

Adjusting the steering wheel position
Adjust the steering wheel to the position where it can be operated easily and the gauges can
be viewed easily.
1. With your back resting against the seatback, extend both arms, place them on the top of
the steering wheel, and pull the steering wheel towards you to the position of your
wrists.
2. Adjust the steering wheel height so that the gauges can be viewed easily.
3. Raise the lever to securely lock the steering wheel.
Essential Safety Equipment
Seats
2-9
MX-5_8KH8-EA-21K_Edition1_old 2021-9-1 11:05:15
