McHale Pro Glide B9000 Assembly instructions

McHale
Ballinrobe
Co. Mayo
F31 K138 Ireland
Tel: [phone]
Email: [email protected]
Website: www.mchale.net
CLT01145_0.01
55
ISO 9001:2015
Pro Glide B9000
Butterfly Disc Mower
Operator Instruction Manual
Issue 1

ENVIRONMENT: Reduce paper consumption
Think before printing documents! Is a PDF on a laptop or tablet
sufficient? If a printed copy is required, always select ‘Print on both sides
of paper’ and always try to limit the number of printed pages by selecting
a specific page range or just select ‘Current page’ if that is sufficient.
This is the original operator manual with ‘Original Instructions’. The English
language version of the operator manual is the source document for all
translations.
If there is any conflict as to the accuracy or content, of any translation, the English
source manual remains the authorised document.
No part of this manual may be reproduced, distributed or translated, in any form or
by any means, without prior written permission by McHale.

McHale Pro Glide B9000 Butterfly Disc Mower
3
Thank you for buying this McHale machine, you have chosen wisely!
Given proper care and attention, you can expect it to provide you with
years of dependable service.
It is important to quote the machine serial number when ordering spare parts or
requesting technical assistance. Space is provided below to record machine details.
(See ‘Description of the serial number plate’)
If you require further copies of this instruction manual,
please quote part number: CLT01145
Due to a policy of continuous product development and improvement, McHale
Engineering reserves the right to alter machine specifications, including the contents of
this manual, without prior notice or any obligation to make changes or additions to the
equipment previously sold. Images and screenshots used in this manual may differ in
appearance from the actual product.
It is vital to replace defective parts of the machine immediately and to use only genuine
McHale spare parts, as these are designed and manufactured to the same standard
as the original machine. Spare parts can be obtained from your McHale dealer.
Throughout this manual there are links to other relevant sections of the manual, to
guide the reader to additional information to convey the complete message. These
links are in (grey italic font). See the example above i.e. the link to the description of
the serial number plate. When you click on the link in the PDF document, the page will
jump automatically to the linked section. With Adobe Reader, you can go back to the
page on which you clicked the link, by clicking on the ‘Previous view’ button (or by
holding ‘Alt’ and pressing the ‘left arrow’).
Warranty/Guarantee
Attention End User!
Please ensure your machine is fully registered with McHale,
by your dealer, at the time of delivery.
Failure of the dealer to register the machine will render your warranty void!
You can check the registration of your machine by visiting www.mchale.net.
Serial number:
Year of manufacture:
Date of delivery:

McHale Pro Glide B9000 Butterfly Disc Mower
4
Table of contents
1 Introduction 6
2 Product information 7
2.1 Designated use of the machine 7
2.2 Front view 8
2.3 General specifications 9
2.4 Tractor specifications 9
2.5 Machine specifications 9
3 General safety 10
3.1 Be aware of all safety information 10
3.2 Follow all safety instructions 10
3.3 Store all items carefully 11
3.4 Personal protective equipment (PPE) 11
3.5 In case of emergencies 11
3.6 Stay clear of rotating elements 11
3.7 Trained operator criteria 12
3.8 Operating the machine 12
3.9 In the event of a fire 13
3.10 General safety warnings 13
4 Specific safety warnings 18
4.1 Hydraulic safety warnings 18
4.2 Noise level 18
4.3 Fire precautions 19
4.4 Special safety devices/instructions 19
4.5 Safety instruction decal locations 20
4.6 Safety warnings & instructions explained 21
4.7 Description of the serial number plate 24
4.8 Machine lifting guidelines 25
5 Tractor requirements & preparation 26
5.1 Tractor requirements 26
5.2 Attaching to linkage 27
5.3 Attaching the machine to a 1,000 rpm PTO 27
5.4 Making connections to the tractor 28
5.5 Lighting system 29
6 Machine requirements & preparation 30
6.1 Side guard latch (LH & RH) 30
6.2 Blade replacement (LH & RH) 30
6.3 Gearbox oil 33
6.4 Leg stands 36
6.5 PTO Shaft adjustment & maintenance 37
7 Road traffic safety & operation 38

McHale Pro Glide B9000 Butterfly Disc Mower
5
7.1 Before travelling on any public roadway 38
8 Field operation & machine adjustments 40
8.1 Cutting height 40
8.2 Conditioner adjustment (LH & RH) 42
8.3 Swath width adjustment (LH & RH) 42
8.4 Lift/lower latch (LH & RH) 43
8.5 Overlap and offset adjustment 44
9 Machine maintenance 45
9.1 Maintenance intervals 45
9.2 Tightening torque values 48
10 Storage 49
10.1 End of season 49
10.2 Start of season 49
11 Certification & Warranty 51
11.1 Declaration of Conformity 51
11.2 PDI form 51
11.3 Change of ownership pre-checks 51
11.4 Limited Warranty 51
12 Appendix 56
12.1 Adjusting the PTO shaft to the tractor 56
12.2 Unit conversion tables 57

McHale Pro Glide B9000 Butterfly Disc Mower
6
1
Introduction
The McHale Pro Glide B9000 is an innovative Butterfly Disc Mower which combines
both left-hand (LH) and right -hand (RH) rear disc mowers in one machine. This mower
must be used in conjunction with a 3 metre wide front disc mower, such as a McHale
F3100 or equivalent. The design has been developed based on years of extensive
research and development in the field of mowers and balers. Given proper care and
attention, the machine will provide years of reliable and dependable performance.
Please do not assume that you know how to operate and maintain your machine before
reading this manual carefully. In order to prevent misuse, damage and accidents, it is
very important that everybody who will operate the machine is a fully trained operator.
(See ‘Trained operator criteria’). They must read and fully understand all of the contents
of this manual, before operating the machine, paying particular attention to the following:
Safety instructions
Functions
Controls (hydraulic & electrical)
It is highly recommended to get acquainted with any new machinery slowly. Take time
to learn and understand all of the features of the machine. Proficiency will increase as
more experience is obtained.
If you have any questions in relation to the instructions in the manual, please contact
your McHale dealer. It is highly recommended that training be sought from your local
McHale dealer.
The operator is solely responsible for the safe use and maintenance of the machinery,
in accordance with this manual. Keep this manual safe and make sure it remains with
the machine, at all times.
ENVIRONMENT: Reduce paper consumption
Think before printing documents! Is a PDF on a laptop or tablet
sufficient? If a printed copy is required, always select ‘Print on both sides
of paper’ and always try to limit the number of printed pages by selecting
a specific page range or just select ‘Current page’ if that is sufficient.

McHale Pro Glide B9000 Butterfly Disc Mower
7
2
Product information
The machine is protected against many dangers to itself while being operated.
However, it is of the utmost importance for the safety of the operator and for others,
that the operator pays attention to all warnings and instructions given in this manual. In
particular all safety devices, decals, guards and controls must be in place and in fully
functioning condition. Never try to clear any malfunction when the tractor is switched
on or while the machine is running. Keep the ‘Danger Zone’ (an area around the
machine) free of all persons and animals at all times, while the machine is in operation
(See ‘Danger Zone’). This manual must be read and fully understood by anyone who
will operate the machine.
2.1 Designated use of the machine
The machine is exclusively designed for normal use in agricultural applications. The
machine has been designed to mow grass and other forage crops for agricultural
harvesting. It also conditions the mown crop through a flailed rotor into loose swaths,
which helps to speed up the drying process by 30 - 40%. This designation includes the
movement of the machine, between fields by track or road, incidental to the machine’s
main use. The field or pasture being mown should be even and smooth and free of
stones. The manufacturer will not be held responsible for any loss or damage resulting
from machine applications other than those specified above. Any other use the
machine may be put to is entirely at the owner/operator’s risk.
The designated use of the machine includes that:
The operating, maintenance and repair instructions given by the manufacturer
will be strictly fulfilled
Exclusively persons who are familiar with it and instructed about the risks are
entitled to operate, maintain and/or repair the machine
The relevant health and safety requirements, that may be in force in the
country of use, will be strictly followed
No other equipment or accessories, other than released by McHale, are
installed in the machine. The use of any other equipment or accessory is
entirely at the owner/operator’s risk. In such cases, unauthorised
modifications/changes exclude any liability of the manufacturer.
WARNING: Loss of machine validity
By any alteration of safety equipment, the declaration of conformity and
the CE sign loses its validity for this machine.

McHale Pro Glide B9000 Butterfly Disc Mower
8
2.2 Front view
LH mower omitted for clarity, as mirror image of RH mower.
No. Machine function
1Swath plate adjustment (RH)
2Conditioner adjustment (RH)
3Right hand guard & curtain
4Lift/lower latch (RH)
5CAT 2/3 lower link pins
6Leg stands
7Lift ram (RH)
8PTO stand
9Lift/lower latch (LH)
10 Blade replacement lever
11 Suspension pressure gauge
12 Rear lights
13 Conditioner gearbox adjustment (RH)
2
3
1
456785
6
10
12
13
1
11
9
6

McHale Pro Glide B9000 Butterfly Disc Mower
9
2.3 General specifications
Units are given in both metric and UK imperial values, with the latter shown in brackets.
*Measured from ground level
2.4 Tractor specifications
2.5 Machine specifications
Transport length 2.2 m (87”)
Transport/working width 2.98 m (117”) / 8.15 m - 8.75 m (321” - 345”)
Transport height 4 m (158”) with lift arms set at 550 mm (22”)*
Working height 1.4 m (55”) with lift arms set at 650 mm (26”)*
Transport weight 2,760 kg (6,085 lbs)
Tractor capacity 224 kW (300 HP) minimum
Linkage CAT 2 or CAT 3 (rear) 3-point linkage & front linkage
PTO speed 1,000 rpm
Lighting 12 V / 7-pin socket
Hydraulic systems
3 x double-acting hydraulic supply with float (minimum)
& single-acting hydraulic supply (optional)
Minimum pressure 180 bar (2,610 psi)
Minimum flow rate 40 l/min (8.79 gal/min) @ 180 bar (2,610 psi)
Cutting width 8.15 m - 8.75 m (321” - 345”)
Swath width 1.3 m - 2.3 m (51” - 91”) (LH & RH)
Number of cutting discs 14
Total number of blades 28 (2 x 14)
Cutting height 25 mm - 75 mm (1” - 3”) (without skids)
Cutting disc speed 3,200 rpm
Conditioner speed 700 / 1,000 rpm
Operation speed 10 - 12 km/h (6 - 7 mph)
Capacity 10.5 ha/h (26 acres/h) (including front mower)

McHale Pro Glide B9000 Butterfly Disc Mower
10
3
General safety
3.1 Be aware of all safety information
Follow all safety precautions and practice safe operation of machinery, at all times.
Warning, caution, note & environment messages:
When reading this manual, pay particular attention when you see the symbols below
i.e. warning, caution, note and environment. They will be used at various points in this
manual and may also appear on safety decals on the machine. The purpose of these
messages is to ensure that the most important information stands out from the rest of
the text.
WARNING: This symbol indicates a potentially hazardous
situation, that if not avoided could result in machinery
damage, personal injury or even death.
CAUTION: This symbol indicates a potentially hazardous
situation, that if not avoided could result in machinery
damage or personal injury.
NOTE: This symbol is used to identify special instructions or
procedures which, if not followed strictly, could result in
machinery damage.
ENVIRONMENT: This symbol reminds you to respect the
environment in relation to the correct disposal of waste
material.
3.2 Follow all safety instructions
Using this manual, read all safety instructions and
messages, and be aware of the meanings of all safety
decals (See ‘Safety warnings & instructions explained’).
The spare part codes for each decal are also listed, which
are available from your McHale dealer. If safety decals are
damaged or missing due to wear and tear or component
replacement, ensure that they are replaced.

McHale Pro Glide B9000 Butterfly Disc Mower
11
As with all machinery, learn all operations and use controls by reading this manual
thoroughly. Do not attempt to let anyone operate this machine without being fully
instructed.
3.3 Store all items carefully
Store all attachments in a secure and safe manner so as to
prevent items from falling. Keep storage areas clear of
bystanders and children.
3.4 Personal protective equipment (PPE)
The following PPE should be worn, at all times, when
carrying out maintenance work on this machine, to help
prevent health and safety hazards:
Safety glasses
Ear muffs
Safety boots
Gloves
Tight fitting clothing
Use of mobile phones or radio/music headphones are
strictly forbidden while operating machinery and driving, as
these impair the operator’s attention.
3.5 In case of emergencies
In the event of any accident, emergency equipment should
be kept close at hand. A first aid kit and fire extinguisher
along with emergency phone numbers should always be
available to machine operators.
3.6 Stay clear of rotating elements
Serious injury or death can result from entanglement of clothing or body parts with PTO
shafts, drivelines and other rotating and moving components.
Keep all guards in place at all times, only wear close fitting clothing and ensure that the
tractor engine has stopped, the key has been removed and that the PTO has stopped
turning before carrying out any adjustments, connections or cleaning of PTO driven
equipment.

McHale Pro Glide B9000 Butterfly Disc Mower
12
3.7 Trained operator criteria
3.8 Operating the machine
In order to avoid serious injury or even death by being pulled into the machine:
Disengage the PTO, apply handbrake, shut the tractor engine off and remove
the key from the ignition.
Age related requirements General requirements
18 +
The operator needs to be fully
trained in the use of this machine
and have a valid tractor driver’s
licence.
The operator must be in full
control of his/her senses and
must not be under the influence
of any alcohol or drugs,
prescribed or otherwise.
The operator must have read
and understood all aspects of the
operator manual in order to
operate, maintain and clean the
machine. Ideally, they should
also receive training from their
McHale Dealer.
It is only acceptable to have
more than one person in the
tractor cab, if it has a second
seat.
16 - 18
An operator between the age of 16
and 18 years old must have a
provisional licence and must be
accompanied by an experienced
driver/operator, at all times, even
during maintenance and cleaning!
< 16
Persons younger than 16 years of
age are not allowed to operate,
clean or carry out maintenance on
this machine, under any
circumstances!
WARNING : Never clear a blockage while the machine is in operation!
Never attempt to clear a blockage while the machine is in operation. You
could be severely injured or pulled in by the rotating tines!
WARNING : Stand well clear of the machine while it is in operation!
Stand well clear of the machine and tractor when the machine is
operating. Objects such as loose tines, stones and other debris may be
discharged from the machine.

McHale Pro Glide B9000 Butterfly Disc Mower
13
3.9 In the event of a fire
In the event of a fire, it is the operator’s decision to
determine the seriousness and hence the solution to the
situation. The following is given only as a guideline
procedure:
1. Move the tractor and machine away from the flammable material.
2. Disengage the PTO, turn off the tractor and remove the key from the ignition.
3. Remove all hosing and electrical looms from the machine, assuming it is safe
to do so.
4. With all connections removed, disengage the machine from the tractor.
5. Drive the tractor away from the machine.
6. Using a suitable fire extinguisher, put out all the fires or call the fire brigade.
3.10 General safety warnings
It is important to be aware of the potential hazards associated with the operation of farm
machinery. Numerous research studies have shown that the majority of machinery-
related accidents occur as the result of human negligence, including taking shortcuts
to save time, lack of or improper maintenance, ignoring warnings, failing to read the
operator's manual, lack of or improper instruction and failure to follow safety rules.
Read and understand this operator manual before using the machine. If any of the
instructions appear unclear do not hesitate to contact your McHale dealer.
Only competent persons who have read and fully understood this manual are qualified
to operate this machine. (See ‘Trained operator criteria’). The owner of this machine is
obliged, by law, to ensure that every operator understands all of the functions, controls,
working processes and safety warnings, before operating the machine.
Safety devices
All safety devices such as guards, protection parts and safety controls must
be in place and in fully functioning condition. It is forbidden to operate this
machine with defective or incomplete safety devices.
WARNING: Fire prevention
It is recommended that the machine be kept reasonably clean and free of
build-ups of crop, lubricants, etc. This will help to reduce the risk of fires.

McHale Pro Glide B9000 Butterfly Disc Mower
14
Danger Zone
The ‘Danger Zone’ is the area all around the mower of 50 m radius.
It is the operator’s responsibility to ensure that there is no person in the
‘Danger Zone’ while operating the machine, especially during start up.
Before repair or reassembly
Safe lifting gear of sufficient capacity must be used for machine assembly. All
chains and slings used must be in good condition.
Before operation
Never operate farm machinery while under the influence of drugs or alcohol.
The physiological effects of drugs and alcohol impair performance and can
lead to operators taking risks or putting others at risk. This includes over-the-
counter cold/flu and allergy medications or prescription drugs that are not
recommended to be taken whilst driving a car or operating machinery.
The operator must ensure that the manufacturer’s instructions for attaching
and detaching the machine are followed. This includes the 3-point linkage, the
hydraulic lines and in particular the lighting system.
The operator must ensure that all covers are closed and all safety devices are
in operating mode.
The operator must ensure that there is no person in the ‘Danger Zone’. (See
‘Danger Zone’)
NOTE: ‘Danger Zone’ can vary in size
The operator must be aware of the ‘Danger Zone’ which can vary in size,
depending on operating conditions, i.e. hilly terrain.

McHale Pro Glide B9000 Butterfly Disc Mower
15
Always be familiar with the health and safety requirements that may be in
force in the country of use.
During operation
While operating this machine on hilly or sloping ground the operator must take
extra precautions, in particular the ‘Danger Zone’ is increased in such
conditions. (See ‘Danger Zone’)
The operator must ensure that there is a minimum of 4 m clearance between
the machine and any obstacle above, in particular electrical high voltage lines.
Never operate the machine with guards or safety devices damaged or
missing.
Avoid contact with the knives/blades.
Particular care must be taken, if the machine is left idle for any extended
period, to ensure that all sensors and safety features are working correctly.
Before travelling on public roads
The owner of this machine is obliged by law to ensure that every operator has
a valid driving licence and is familiar with the road traffic regulations relating to
the country of use.
Always ensure that the hydraulic supply is switched off.
Always ensure that the side guards are fully retracted.
Ensure the machine is in the correct transport position.
Ensure that additional lighting is provided if any of the tractor lights are hidden
or obstructed by the machine.
The operator must ensure that there is a minimum of 1 m clearance between
the machine and any obstacle above, like low bridges, arches or tunnels. But
in the case of electrical high voltage lines a minimum clearance of 4 m should
be allowed.
Performing maintenance
Maintenance and repair work on the machine should always be carried out in
accordance with this manual.
Maintenance and repair work exceeding the content of this manual should
only be carried out by qualified persons or your McHale dealer.
WARNING: Do not carry people or animals on the machine
The operator must ensure that no persons or animals are carried on the
machine at any time or are hidden under the machine (on the tractor
persons are only allowed to sit on the relevant seats).

McHale Pro Glide B9000 Butterfly Disc Mower
16
When conducting maintenance work tie long hair behind your head. Do not
wear a necktie, necklace, scarf or loose clothing when you work near the
machine or moving parts. Rotating machinery parts can entangle loose
clothing, long hair or dangling jewellery faster than a victim can react. If these
items were to get caught, severe injury could result.
Before working on this machine or altering any setting, the operator must
ensure the following:
(a) The tractor has definitely stopped moving
(b) The hand brake is applied
(c) The engine is shut down
(d) The ignition key is removed
(e) PTO shaft is removed from PTO stub
(f) Hydraulic oil supply is switched off
When conducting maintenance work always support the machine properly.
Where possible, lower the attachment or implement to the ground before you
work on the machine. If it is not possible to lower the machine or attachment
to the ground, always securely support the machine or attachment. Do not
work under a machine that is solely supported by a jack. Never support the
machine with props that may break or crumble under continuous load.
Never disable any electrical safety circuits, tamper with safety devices or carry
out any unauthorised modification to the machine.
Replace any electrical or hydraulic devices immediately, at the first sign of
malfunction or failure, as these components affect the functionality, sequencing
and thus safety of operation. Never use a machine where a malfunction exists!
Contact your McHale dealer to achieve a solution. Always think ‘Safety First’!
Avoid heating near pressurised fluid lines, as pressurised lines can be
accidentally damaged when heat goes beyond the immediate flame area.
Regular clean down is recommended in order to maintain the machine in a
safe and reliable working condition. McHale recommend that the machine be
blown down with an air line, as opposed to a pressure washer, due to the
dangers involved with pressure washing and to protect the overall paint work
on the machine. If, despite our advice, a pressure washer is used then take
extreme caution and operate from ground level only. Never climb onto any
part of the machine, while pressure washing, due to the fact that all metal
surfaces become extremely wet and slippery and always ensure that the
tractor has been shut down, with the ignition key removed.
CAUTION: Before carrying out work on this machine
It is forbidden to open any safety guards or to carry out any work on the
machine, unless the above specified precautions have been carried out.

McHale Pro Glide B9000 Butterfly Disc Mower
17
During inspection
If on the rare occasion that it is necessary for an inspection to be carried out
within the ‘Danger Zone’ while the machine is running (extremely dangerous
and not recommended!), there shall be a fully trained and competent second
person operating both the tractor and machine controls. The tractor hand
brake shall be applied and the controls shall be in manual mode. The machine
shall be on level ground with all guards closed. Communication is key. The
operator shall inform the inspector before any machine function is activated.
The inspector shall remain in the field of vision of the operator at all times and
inform the operator of their intended actions. If communication is lost with the
operator, or they move within 1.1 m of moving parts or parts that have the
potential to move, all tractor power shall be turned off immediately.
Child safety on farms
All adults working or present on farms are required, by law, to do everything
reasonably practical to ensure the safety and health of children and young
people on the farm.
Children must be supervised at all times! Remember, farms are not
playgrounds!
Store farm machinery with safety & stability in mind.
Always exclude children from potentially dangerous areas (they will often get
into apparently inaccessible places). Do not allow them in farm yards on busy
days. Contractors should always be made aware of the presence of children.
Never leave children alone in a tractor cab as they can interfere with controls
and many children have been killed falling from the door or rear window of a
tractor.
Children under 16 years of age should never operate power-driven
machinery. Keys should be removed from vehicles and controls left in neutral.
Lower any implements or loaders to the ground and apply the hand brake.
Do not allow children to use bales of any description for playing. It is very easy
to fall from stacked bales resulting in serious injury, or fall between them
leading to suffocation. Make sure there is no evidence of children burrowing
under stacked bales. Keep matches in a safe place.
Children under 16 should never handle chemicals. Always keep them in their
correct containers and securely stored out of sight under lock and key.
Keep matches in a safe place.
Danger of lightning strike
If there is a risk of lightning in the area, stop all work.
If there is a risk of lightning when travelling, find a safe place to pull over and
stop the tractor.
Do not leave the tractor cab or start work until the risk of lightning has passed.

McHale Pro Glide B9000 Butterfly Disc Mower
18
4
Specific safety warnings
4.1 Hydraulic safety warnings
The maximum pressure in the hydraulic system of this machine should not
exceed 210 bar.
Always ensure the system is not under pressure before working on the
machine. Oil under pressure can penetrate the skin and cause injury. Beware
of pipes under accumulator pressure, depressurise lines by unthreading
connections extremely slowly.
Hydraulically actuated devices must be blocked mechanically against
movement, before working on the machine.
If any hoses are removed or replaced ensure they are marked and re-installed
to the correct position during re-assembly.
Check hoses monthly for signs of leakage or wear. Use a piece of card when
checking for leaks. Fine jets of hydraulic fluid can penetrate the skin. Never
use your fingers or face to check for leaks. If in doubt always replace. The
recommended maximum working time of hoses should not exceed 5 years.
Only use exact specification McHale genuine replacement parts.
Do not work on hydraulic systems unless you are qualified to do so. This work
should only be carried out by qualified persons or your McHale dealer.
4.2 Noise level
The European directive 2003/10/EC directs employers and employees to
control the noise level at work. The noise level at field work may differ
according to the tractor, ground, crops and other environmental conditions.
In normal conditions, whilst driving the machine, the noise level to the driver’s
ear does not exceed 70 dB (A) with the rear screen of the tractor cabin open.
The common noise level of the machine and the tractor is primarily influenced
by the tractor noise (radio is an additional noise source). It is recommended to
operate this machine with closed cabin windows.

McHale Pro Glide B9000 Butterfly Disc Mower
19
4.3 Fire precautions
Be aware that crops are easily inflammable.
Do not smoke or make use of any open fire next to the machine.
A functioning fire extinguisher should always be available on the tractor.
The machine is to be kept clear of oil, grease, crops, string, plastic or any
other flammable material at all times.
Do not continue to work with overheated parts, cables or pipes, unless you
have identified and eliminated the reason for overheating.
Equipment being refuelled should have its engine turned off before refuelling.
Personnel should be instructed on how to properly refuel equipment: do
periodic maintenance checks on the tank, pump, hose and nozzle; and abide
by safety rules, such as not smoking when around the refuelling area.
4.4 Special safety devices/instructions
When maintenance or repair work has to be carried out on the machine, the
hand brake must be applied, engine shut down with ignition key removed. The
PTO shaft must be removed from the PTO stub, with the hydraulic and electric
power supply disconnected. It is forbidden to open any safety guards or carry
out any work on the machine unless the specified precautions have been
carried out.
Always use protective clothing and gloves when working with blades or sharp
objects.
WARNING: Shut down engine before performing maintenance!
Ensure the engine has been shut down and PTO has been disconnected
before carrying out maintenance on the machine. Never attempt to go
near the machine until it and the tractor have both come to a complete
stop. This is extremely important when checking/replacing blades, where
there is a risk of mutilation.

McHale Pro Glide B9000 Butterfly Disc Mower
20
4.5 Safety instruction decal locations
LH mower omitted for clarity, as mirror image of RH mower.
