Medion LIFE P15511 User manual

User Manual
P15010 (MD 31710) / P15511 (MD 31711) / P16512 (MD 31712)
Ultra HD TV
MEDION® LIFE®

2
Contents
1. Information about these operating instructions ...................................... 4
1.1. Explanation of symbols.......................................................................................4
1.2. Proper use................................................................................................................5
2. Package contents......................................................................................... 6
3. Safety instructions ...................................................................................... 7
3.1. Operating safety .................................................................................................... 7
3.2. Set-up location ...................................................................................................... 9
3.3. Repairs.....................................................................................................................11
3.4. Environmental temperature............................................................................11
3.5. Safety when connecting...................................................................................12
3.6. Handling batteries ..............................................................................................13
4. EU - Declaration of conformity ................................................................. 15
5. Device overview......................................................................................... 16
5.1. Front.........................................................................................................................16
5.2. Rear ..........................................................................................................................18
5.3. Remote control ....................................................................................................19
6. Getting started .......................................................................................... 22
6.1. Unpacking..............................................................................................................22
6.2. Mounting ..............................................................................................................22
6.3. Inserting the batteries in the remote control ...........................................23
6.4. Connecting the antenna ..................................................................................23
6.5. Common Interface (CI)......................................................................................24
6.6. Connecting the power supply........................................................................24
6.7. Switching the LCD TV on and off...................................................................24
6.8. Channel search after switching on for the first time..............................25
7. Multimedia connections ........................................................................... 29
7.1. Use of the multimedia connections .............................................................29
8. Operation ................................................................................................... 32
8.1. Channel selection ...............................................................................................32
8.2. Sound settings .....................................................................................................32
8.3. Screen settings.....................................................................................................32
8.4. Displaying channel information ....................................................................33
8.5. Opening the favourites list ..............................................................................33
8.6. Selecting the source...........................................................................................34
9. Teletext....................................................................................................... 35
9.1. Using the teletext................................................................................................35
9.2. Selecting a page ..................................................................................................35
9.3. Useful teletext functions ..................................................................................36
10. Menu navigation........................................................................................ 37
10.1. Channel menu......................................................................................................38

3
EN
10.2. Picture menu.........................................................................................................49
10.3. Sound menu .........................................................................................................50
10.4. Time menu.............................................................................................................51
10.5. Lock menu .............................................................................................................52
10.6. Option menu ........................................................................................................53
11. Media player .............................................................................................. 58
11.1. Accessing the media player.............................................................................58
11.2. Main menu for the media player...................................................................58
11.3. Displaying photos...............................................................................................59
11.4. Playing back music.............................................................................................60
11.5. Playing back videos............................................................................................61
11.6. Displaying text .....................................................................................................61
12. EPG – programme guide ........................................................................... 62
13. Troubleshooting ........................................................................................ 63
13.1. Do you need more help?..................................................................................64
13.2. LCD TV pixel faults ..............................................................................................65
14. Cleaning ..................................................................................................... 66
15. Storage when not in use............................................................................ 66
16. Disposal...................................................................................................... 67
17. Technical specifications ............................................................................ 68
18. Product Data Sheet.................................................................................... 71
19. Service information................................................................................... 72
20. Legal Notice ............................................................................................... 73
21. Privacy statement...................................................................................... 74
22. Index ........................................................................................................... 75

4
1. Information about these operating
instructions
Thank you for choosing our product. We hope you enjoy using it.
Read the safety instructions carefully before using the device for the first
time. Note the warnings on the device and in the operating instructions.
Always keep the operating instructions close to hand. If you sell the device or give it
away, please ensure that you also pass on these operating instructions. They are an
essential component of the product.
1.1. Explanation of symbols
If a block of text is marked with one of the warning symbols listed below, the hazard
described in that text must be avoided to prevent the potential consequences de-
scribed there from occurring
DANGER!
Warning of immediate mortal danger!
WARNING!
Warning of possible risk of fatal injury and/or serious
irreversible injuries!
CAUTION!
Warning: risk of minor or moderate injuries!
NOTICE!
Please follow the instructions to avoid property dam-
age!
Additional information on using the device!
NOTICE!
Please follow the instructions in the operating instructions!

5
EN
WARNING!
Warning of risk of electric shock!
WARNING!
Warning: danger due to loud volume!
• Bullet point/information on steps during operation
Instructions to be carried out
Declaration of conformity (see section “EU - Declaration of conform-
ity”): Products that feature this symbol meet the requirements of the
EC directives.
Safety class II
Electrical appliances in protection class II are electrical appliances that
permanently have double or reinforced insulation and do not have
any connection options for a protective earth. The housing of an elec-
trical appliance in protection class II that is enclosed in insulated ma-
terial can partially or fully act as the additional or reinforced insula-
tion.
1.2. Proper use
This is an information technology device and is also suitable for multimedia applica-
tions. This device is used to receive and play back television programmes. The range
of different connections supplied makes it possible to expand the input and output
sources (receiver, DVD player, DVD recorder, video recorder, PC, etc.). Your device of-
fers a number of options for usage.
The device is intended for private use only and not for industrial/commercial use.
• Please note that we shall not be liable for damage caused by improper use.
• Do not modify the device without our consent and do not use any auxiliary
equipment that we have not approved or supplied.
• Use only spare parts and accessories that we have supplied or approved.
• Heed all the information in these operating instructions, especially the safety in-
formation. Any other use is deemed improper and can cause personal injury or
property damage.
• Do not use the device in extreme environmental conditions.
• This device is intended for use in dry, indoor areas only.
• This device is not designed to be used as a data monitor for office workplaces.

6
