Medion LIFE X14020 User manual

X14020 (MD 31420) / X14321 (MD 31421) / X15022 (MD 31422) / X15523 (MD 31423) / X16524 (MD 31424) /
X15080 (MD 31380) / X15581 (MD 31381) / X16582 (MD 31382)
MEDION®LIFE®
Ultra HD Smart TV
Operating instructions

2
Contents
1. Information about these operating instructions............................................................... 4
1.1. Key to symbols..........................................................................................................................................4
1.2. Proper use...................................................................................................................................................5
1.3. Ultra HD.......................................................................................................................................................5
1.4. Package contents.....................................................................................................................................6
2. Safety information ............................................................................................................... 7
2.1. Operating safety.......................................................................................................................................7
2.2. Installation location ................................................................................................................................8
2.3. Ambient temperature ............................................................................................................................9
2.4. Repairs .........................................................................................................................................................9
2.5. Safety when connecting ....................................................................................................................10
2.6. Handling batteries................................................................................................................................ 11
3. EU – Declaration of Conformity ......................................................................................... 12
4. Device overview.................................................................................................................. 13
4.1. Front ..........................................................................................................................................................13
4.2. Rear and right-hand side.................................................................................................................... 14
4.3. Remote control...................................................................................................................................... 15
5. Getting started ................................................................................................................... 17
5.1. Unpacking ............................................................................................................................................... 17
5.2. Mounting ................................................................................................................................................. 18
5.3. Inserting batteries in the remote control..................................................................................... 19
5.4. Connecting the antenna .................................................................................................................... 19
5.5. Connecting the power supply .........................................................................................................20
5.6. Switching the Smart TV on and o................................................................................................. 20
5.7. Using the multimedia connections................................................................................................ 20
5.8. Station search after switching on for the first time .................................................................. 23
6. Operation ............................................................................................................................ 26
6.1. Channel selection ................................................................................................................................. 26
6.2. Sound settings.......................................................................................................................................26
6.3. Screen settings.......................................................................................................................................26
6.4. Displaying information....................................................................................................................... 27
6.5. Opening the favourites list................................................................................................................27
6.6. Selecting the source ............................................................................................................................28
6.7. Wireless display .....................................................................................................................................28
7. Teletext................................................................................................................................ 29
7.1. Using the teletext .................................................................................................................................29
8. Using the On-Screen Display menu (OSD menu) ............................................................. 30
8.1. Navigating in the menu...................................................................................................................... 30
9. The menu system in detail ................................................................................................. 30
9.1. Home page.............................................................................................................................................. 30
9.2. Source menu...........................................................................................................................................37
9.3. Applications menu ............................................................................................................................... 37
9.4. Settings menu........................................................................................................................................ 38
9.5. TV menu................................................................................................................................................... 57
9.6. Media browser menu ..........................................................................................................................60
10. HbbTV system ..................................................................................................................... 62
11. MEDION® Life Remote app................................................................................................. 62
12. Data protection MEDION® Smart TV ................................................................................. 64

EN
3
13. Troubleshooting ................................................................................................................. 65
13.1. Do you need more help?.................................................................................................................... 67
13.2. Smart TV pixel faults ............................................................................................................................67
14. Cleaning .............................................................................................................................. 68
15. Storing the device when not in use................................................................................... 68
16. Disposal............................................................................................................................... 69
17. Technical specifications ..................................................................................................... 70
17.1. Product data sheet ...............................................................................................................................76
17.2. Trademark information.......................................................................................................................77
18. Service information............................................................................................................ 78
19. Legal Notice......................................................................................................................... 79
20. Index .................................................................................................................................... 80

4
1. Information about these operating instructions
Thank you for choosing our product. We hope you enjoy using this device.
Read the safety instructions carefully before using the device for the first time. Note the
warnings on the device and in the operating instructions.
Always keep the operating instructions close to hand. If you sell the device or give it away,
please ensure that you also pass on these operating instructions. They are an essential component
of the product.
1.1. Key to symbols
If a block of text is marked with one of the warning symbols listed below, the hazard described in
that text must be avoided to prevent the potential consequences described there from occurring.
DANGER!
Warning: risk of fatal injury!
WARNING!
Warning: risk of possible fatal injury and/or serious irreversible injuries!
CAUTION!
Warning: risk of minor and/or moderate injuries!
NOTICE!
Follow with these instructions to prevent damage to the device!
More detailed information about using the device.
Comply with the notes in the operating instructions.
Due to the 5 GHz frequency range of the wireless LAN solution used, the device may
only be used inside buildings in the EU.
WARNING!
Warning: risk of electric shock!
WARNING!
Warning: danger due to loud volume!
• Bullet point/information on steps when the device is in use
Instruction to be carried out
Declaration of Conformity (see "EU declaration of conformity" section): Products that feature
this symbol meet the requirements of the EC directives.

EN
5
Protection class II
Electrical devices in protection class II are devices that have double and/or reinforced in-
sulation throughout, and do not have the option of connecting a protective earth. The
housing of an electrical device in protection class II, with surrounding insulating material,
may either form all of the additional or reinforced insulation, or part of it.
Symbol for direct current
Symbol for AC current
1.2. Proper use
This is an entertainment electronics device and is also suitable for multimedia applications. This de-
vice is designed to receive and play back television channels. The various connection options ena-
ble the additional extension of the reception and playback sources (receiver, DVD player, DVD re-
corder, video recorder, PC etc.). Your device can be used in a variety of ways.
The device is only intended for private use and not for industrial/commercial use.
• Please note that we shall not be liable in cases of improper use.
• Do not modify the device without our express agreement and do not use any accessories that
have not been supplied or approved by us.
• Only use replacement parts or accessories that we have supplied or approved.
• Comply with all the information in these operating instructions, especially the safety information. Any other
use is considered improper and can cause personal injury or property damage.
• Do not use the device in extreme environmental conditions.
• This device is only suitable for use in dry interior rooms.
• This device is not suitable for use as a data monitor for office workstations.
1.3. Ultra HD
Your Smart TV features“Ultra HD” technology. This means that it can play back high-resolution im-
ages with four times the resolution of Full HD. An Ultra HDTV signal is required.
1.3.1. HDR (High Dynamic Range)
HDR technology provides a greater dynamic range in terms of the brightness of the colours shown.
That means that every colour value reproduced can be displayed in 1024 shades instead of the pre-
vious maximum of 256. This fourfold increase in the dynamic range makes the darkest areas of the
picture even darker and the brightest areas even brighter. It creates a more realistic impression and
makes details visible that were previously unrecognisable with a smaller brightness range. The sta-
tion, streaming service or hardware of the connected device must support HDR and Blu-ray must
be supported.
If HDR content is to be played back, select the HDMI inputs in the SOURCES > SOURCE
SETTINGS menu and then the ENHANCED setting.

6
1.4. Package contents
Please check your purchase to ensure that all items are included. If anything is missing, contact us
within 14 days of purchase. Also contact us in the event of defective or partly defective delivery.
The following items are supplied with your product:
• Ultra HD Smart TV
• Remote control (RC1818) incl. 2 x LR03 (AAA) 1.5 V batteries
• Feet incl. fixing screws
• Operating instructions and warranty card
DANGER!
Risk of choking and suffocation!
Packaging film can be swallowed or used improperly, creating a risk of choking and
suffocation.
Keep packaging material such as plastic film or plastic bags away from children.

EN
7
2. Safety information
2.1. Operating safety
−Before using the device for the first time, check the device for damage. A defective or
damaged device may not be operated.
−This device may be used by children over the age of 8 and by persons with limited
physical, sensory or mental abilities or by those without experience and knowledge, if
they are supervised or have been instructed in the safe use of the device and have un-
derstood the dangers that result from it.
−Children must not be allowed to play with the device. Cleaning and maintenance by
purchasers must not be carried out by children unless they are supervised.
DANGER!
Risk of choking and suffocation!
The packaging material is not a toy! Packaging film can be swallowed or used im-
properly, creating a risk of choking and suffocation.
Keep packaging material such as plastic film or plastic bags away from children.
DANGER!
Risk of electric shock!
Risk of electric shock, short circuit and fire!
Never open the housing of the Smart TV and do not push objects inside the
Smart TV through the slots and openings.
WARNING!
Overheating! Risk of fire!
Overheating may result in damage to the Smart TV and the risk of fire!
The slots and openings on the TV set are for ventilation purposes. Do not cover
these openings, for example with newspapers, table cloths, curtains etc.
−Do not subject the display to pressure. There is a risk of the screen glass breaking.
−The remote control has a Class 1 infrared diode. Never use optical equipment to look
at the LED.
CAUTION!
Risk of injury!
Risk of injury due to broken display!
Do not touch the display with fingers or sharp objects to avoid damage.
Use protective gloves when wrapping up cracked parts.
Wash your hands with soap afterwards, as the risk of chemicals escaping cannot be ex-
cluded.
Send the broken parts to your Service Centre for proper disposal.
Disconnect the device from the mains supply immediately and only use it again after it
has been checked by a qualified person or customer services. It is an emergency situation
if, for example, the device produces smoke or unusual noises, water has penetrated the
device, the mains cable or housing is damaged.
Contact customer services if:
−the mains cable is burnt or damaged
−liquid has penetrated the device
−the device is not operating correctly

8
−the device has fallen or its housing is damaged
−The device produces smoke
2.2. Installation location
−Place the TV set on a sturdy, level surface. Some aggressive varnishes can corrode the rub-
ber feet on the device.
−When used for the first time, new devices may give off a typical, unavoidable but com-
pletely harmless odour. This will fade over time. We recommend you ventilate the
room regularly to help dissipate this odour. We have taken appropriate measures during
the development of this product to ensure that levels are well below legal limits.
−Keep your Smart TV and all connected devices away from moisture and avoid dust,
heat and direct sunlight. Non-compliance with these instructions can cause faults or
damage to the Smart TV.
−Do not use the device outdoors as it could be damaged by weather such as rain, snow
etc.
−The device may not be exposed to water droplets or spray. Do not place any liquid-filled
containers (vases or similar) on or next to the device. Such containers could tip over and
the liquid could impair the electrical safety of the device.
NOTICE!
Risk of damage!
Risk of injury due to candles and other open flames.
Keep candles and other open flames away from this product at all times, to pre-
vent fire from spreading.
−Make sure that there is enough clearance between the device and any surrounding
furniture or walls. Ensure a minimum clearance of 10 cm around the device for suffi-
cient ventilation.
−Avoid glare, reflections and extreme dark-light contrasts to protect your eyes.
−The optimal viewing distance is 3 times the screen diagonal.
DANGER!
Risk of injury! Risk of fatal injury!
Only place the TV set on stable surfaces. Falling televisions may cause serious inju-
ries and even death. Many injuries, particularly for children, can be avoided by tak-
ing the following precautions.
Only operate the Smart TV and its components on a sturdy, level and vibra-
tion-free surface to prevent it from falling.
−Only use the TV with the supplied feet and screws.
−Only use furniture that ensures that the TV is positioned safely.
−Take care to ensure that the TV does not protrude over the edges of the furniture.

EN
9
−Do not place the TV on suspended furniture, such as wall cupboards or shelves, with-
out safely and securely fixing both the furniture and the TV set. Take care to ensure
that the furniture is mounted correctly and do not exceed its maximum load.
−Do not place any covers or similar beneath the TV to ensure that it is securely posi-
tioned.
−Warn children of the dangers of climbing on furniture when trying to reach the TV set
or its controls.
If you store or change your TV, also observe the safety instructions specified above.
2.3. Ambient temperature
−The device can be operated at an ambient temperature of +5 °C to +35 °C and at a rel-
ative humidity of 20% to 85% (non-condensing).
−When switched off, the Smart TV can be stored at temperatures of between -20 °C and
+60 °C.
−Keep the device at least one metre away from sources of high-frequency or magnetic
interference (televisions, loudspeakers, mobile telephones, etc.) to avoid malfunctions.
−Remove the plug from the mains outlet and the antenna cable from the antenna sock-
et during a thunderstorm or if the device is not going to be used for a long period.
NOTICE!
Risk of damage!
Major changes in temperature or fluctuations in humidity can cause moisture to
build up within the Smart TV due to condensation – this can cause an electrical
short circuit.
After transporting the Smart TV, wait until it has reached ambient temperature
before switching it on.
2.4. Repairs
−Repairs to your Smart TV should only be carried out by qualified specialists.
−If a repair must be carried out, please contact only our authorised service partners.
−Take care to ensure that only spare parts specified by the manufacturer are used. The
use of unsuitable spare parts can cause damage to the device or the risk of fire.

10
2.5. Safety when connecting
2.5.1. Power supply
−Even when deactivated, some of the device components are live. To disconnect the
power to your Smart TV or to completely isolate the device from voltage sources, dis-
connect the device from the power supply completely. To do so, remove mains plug
from the socket.
DANGER!
Risk of electric shock!
Risk of death due to electric shock when the housing is open.
Do not open the device housing. It does not contain any parts for maintenance
by the user.
−Only operate the Smart TV from an earthed 220 to 240 V~ 50 Hz socket. Contact your
local energy supplier if you have any questions about the power supply at the installa-
tion location.
−The socket must always be easily accessible so that the plug can be quickly removed
from the socket in an emergency.
−To disconnect the power supply from your TV, pull the plug from the socket.
−For additional safety, we recommend using a surge protection device to protect your
Smart TV against damage due to voltage spikes or lightening strike from the power
supply.
−Position the cables so that no one can tread on them or trip over them.
−Do not place any objects on the cables as they may be damaged.
−Never touch the plug with wet hands.
−Always hold the housing and never pull on the cable when removing the plug from
the socket.
−Please note that the TV set continues to use power when in standby mode (see also
the relevant standby consumption in the “Product data sheet” section on page 76).
If the device switches off and restarts due to electrical discharge while in USB mode
(media player), optional HbbTV mode or optional LAN/WLAN mode (media player/
portal), it may not be able to independently restore the last operating mode. Please
start the respective media or applications again.
The last user settings entered may not be restored following an electrical discharge
that causes the TV to switch off because these settings are only saved 5 minutes af-
ter switching channels.
All multimedia devices that can be connected to the corresponding connections of
the TV must comply with the requirements of the Low Voltage Directive.
