MEGWR TF-X1 User manual

DOG
Training Collar
MODEL:TF-X1
MEGWR
Retail price
$199.99
The product is designed to foster good habits in pets, not punish them.
Do not overuse this product on pets.
NOTE: PLEASE READ THE MANUAL CAREFULLY BEFORE USE AND SAVE FOR FUTURE REFERENCE!

（EN) USER MANUAL >>
MEGWR
>> SAFETY INSTRUCTIONS
1. Use of this product on aggressive dogs is prohibited. Aggressive dogs can cause
serious injury or death to their owners or others. If you are not sure whether the
product is suitable for your dog, consult a professional training Dog trainer.
2. Do not allow children to play with this product. Please put the product out of reach
of children
Safe use statement
1. Make sure your dog is healthy before using the product. If you are unsure about
this, consult your veterinarian.
3. If skin and sores are found on the wearing area, please stop using this product
until the skin is healthy.
2. When the device is turned on, the human body should avoid contact with the
electric shock contact of the product.
Electric shock safety statement
1.Keeping you and your dog safe while training is vital. Your dog will need a strong
lead to prevent overreaction during training and to hold him tightly to prevent him
from running around.
3.This product is suitable for dogs weighing over 7lb and aged over 6 months.
2. The wearing time of the dog trainer should not exceed 12 hours a day, and please
adjust the wearing position every 1-2 hours.
4.Do not use this product as a matching collar for pet leash.
5.Check whether the contact area of the electric shock contact on the neck of the
dog is rashes and sores are very important.
6.It is okay to cut the long coat around the throat, but it is not recommended to
shave it completely.
Safety Statement for wearing and training
01/Page01/Page

（EN) USER MANUAL >>
MEGWR
>> COMPONENTS
7.Before playing with the dog, please remove the device to avoid triggering it by
mistake.
8.The 1P67 standard indicates that the equipment can be placed in water up to one
meter deep for half an hour, and the internal part of the product will not enter water,
but also prevent dust.
Note: The IP67 standard is the result of static laboratory tests.
① Transmitter * 1 ② Receiver (including collar) * 1
③ Test board * 1 ④
Long/Short E-shock Contactors *2 Set
⑤ Silicone protective sleeve* 2 set ⑥ Lanyard * 1
⑦ Magnetic charging cable * 1 ⑧ User manual * 1
Transmitter * 1
1
Charging cable * 2
7User manual * 1 8
Test board * 1
3
4
Silicone protective sleeve* 1 set
(Receiver has installed 1set)
5
Lanyard * 1
6
Receiver (including collar) * 1
2
E-shock Contactors * 1 set
(Receiver has installed 1set)
02/Page

（EN) USER MANUAL >>
MEGWR
>> PARAMETER
Receiver collar is IP67 waterproof and dustproof, the remote control is not waterproof.
Remote control enhanced visual design with digital display
• Strap Size:8-25in
• 4 modes: beep, vibration, E-shock,Dog Finder
• 18 levels of electric shock and 8 levels of vibration
• Remote can be paired with 3 receivers simultaneously
• Fast charging, both of the remote and receiver battery power display
• 2500Ft range and IP67 waterproof receiver (remote not waterproof)
Transmitter
Battery 420mAh/3.7V lithium battery DC5V/1A
45 Days(Trigger 20 times a day) 2500FT
No Waterproof -10°C~+50°C
2.68oz -20°C~+50°C
5.19*1.7*0.6inch 433.92MHz
Input voltage
Wireless distance
Service temperature
Storage temperature
Wireless frequency
Standby time
Waterproof Grade
Net weight
Product size
Receiver
Battery 300mAh/3.7V lithium battery DC5V/1A
30 Days(Trigger 20 times a day) 25in/62cm
IP67 -10°C~+50°C
2.3oz -20°C~+50°C
2.83*1.45*0.9inch 433.92MHz
Input voltage
Collar length
Service temperature
Storage temperature
Wireless frequency
Standby time
Waterproof Grade
Net weight
Product size
Function
03/Page

（EN) USER MANUAL >>
MEGWR
>> RECEIVER INTRODUCTION
Power key Slip buckle
Lock clasp
Lndicator light
Magnetic charging port
E-shock contactor
Test contact
Color screen
Dog search key
Sound key Vibrating key
Setting key Channel key
Lock key switch
Power key
Charging port
Dog search indication
Transmitter power indicator Receiver power indicator
Electric shock Channel 123
Training level
Warning sound
Vibration
Lock key indication
+ key
- key
Shock key
Test lamp
Status light
Collar strap
>> Transmitter Introduction
04/Page

（EN) USER MANUAL >>
MEGWR
>> User operation
When the transmitter is charging, the battery column icon flashes
water. The charging time is 1.5-2 hours. Battery charge after full,
battery column icon long bright.
When charging the receiver, the red light of the status light is on
for a long time, and the charging time is 1.5-2 hours. When the
battery is fully charged, The status indicator is steady green.
1. Charge the product before using it
2. Turn it on/off
3. Remotely shut down
4. Switch channel setting
Long press the receiver key for 2 seconds, the screen is
lit up, indicating successful startup operation;In the startup
state, the green light of the status indicator blinks once
every 5 seconds (the operation status indicator will turn off
after 10 minutes of display). Hold down the key for 2
seconds and the screen darkens, indicating successful
shutdown.
①The default channel for a single receiver is channel 1, and
channel switching will be turned off. If you need channel
switching, please turn on the channel switching function first.
②In standby mode, press and hold the key of the transmitter for
5 seconds to turn on and off the channel switching function.
③When the channel switching function is turned on, the channel
icon will gradually light up; when the channel switching function is
turned off, the channel icon will go out station by station.
05/Page

（EN) USER MANUAL >>
MEGWR
>> User operation
Blue light flashes 5 times
• When the channel switching function is enabled, press the key of the
transmitter to switch between channel 1, Channel 2 and channel 3; When the
receiver receives the channel switching instruction of the transmitter, the cyan
light of the prompt lamp flashes 5 times.
• When the channel switching function is off, press the key of the
transmitter to switch between the paired channels,When the receiver receives
the channel switching instruction of the transmitter, the cyan light of the
prompt lamp flashes 5 times.
• Flip down the lock key switch to open the lock key function,The lock key icon
lights up. When any key is pressed, the transmitter has no function response
and the lock key icon flashes，Pull the lock button up to disable the lock
button function.
• When the screen is on, short press the button or button to
adjust the shock level.The shock level is adjustable from 0-18,0
is off.
5.Channel setting
6.Lock key
7.Set the shock level
8.Vibration level setting
06/Page
①When the screen is on, press the button of the transmitter
and the vibration icon flashes to enter the screen for setting
the vibration level.
②Short press keys or key to adjust the vibration level.
③Vibration is adjusted at levels 1-8.
④The vibration icon will automatically exit the vibration level
setting after flashing for 5 seconds.

（EN) USER MANUAL >>
MEGWR
>> User operation
9.Dog Finder
10.Train the operation
White light flash fast RGB breathing light
Chirp for 1 second
Vibration 1 second
① In the standby state, press the transmitter button to turn on the
receiver dog search function and press the indicator light for the first
time，The white light blinks quickly, and the transmitter dog icon
blinks. 10 minutes later, the transmitter automatically shuts down.
②Press the key again to switch the breathing light display to the
prompt light, and the transmitter search dog icon lights up.
③Short press the key for the third time to turn off the receiver dog
search function.
• In the standby state, short press the key , the receiver receives the
instruction with a preset shock level shock once; When the key is
long pressed, the transmitter will be shocked for 5 times and then shut
down.
07/Page
• In the standby state, press the key and the receiver will chirp for 1
second after receiving the instruction; Long press the key , the
receiver continuously chirps 10 times before closing.
• In the standby state, press the key and the receiver will vibrate for 1
second at the preset vibration level after receiving the instruction; Long
press the key , the receiver vibrates for 10 times and then turns off.

（EN) USER MANUAL >>
MEGWR
Blue light flashing
The blue light stays on for 3 seconds
① When the receiver is turned on, briefly press the key twice
to enter the pairing state. At this time, the blue light flashes.
② When the transmitter switches to the channel to be
paired, only one receiver can be paired for each channel.
At the same time, press the key of the transmitter
for 2 seconds, and the transmitter sends the pairing
command to the receiver, and the channel number of the
transmitter flashes.
③ Matching successful, the receiver prompt light blue light
will be on for 3 seconds.
④ In the pairing state, if the pairing is not successful for
more than 30 seconds, the receiver will automatically exit
the pairing state
>> User operation
11.Matching
08/Page

（EN) USER MANUAL >>
MEGWR
>> User operation
12.Transmitter Factory Reset
13.Low battery power
Within 15 seconds of restarting, press and hold the
key for 2 seconds, and the backlight flashes for
5 times to indicate that the factory is successfully
restored
When the battery electric shock of the receiver is less
than 1 grid, the red light of the status indicator blinks
once every 5 seconds, indicating that the receiver will
automatically shut down after 20 minutes.
When the battery electric shock of the receiver is less
than 1 grid, the red light of the status indicator blinks
once every 5 seconds, indicating that the receiver will
automatically shut down after 20 minutes.
(Flashes once in 5 seconds)
09/Page

（EN) USER MANUAL >>
MEGWR
>> Setting Guide
>> Install receiver
14.Setup guide
Install the silicone protective sleeve
Install the E-shock contactors
Choose the right gear according to the dog's temper and tolerance for shock. Start
training at the lowest gear.
For example, if the dog responds to the shock gear with ear twitching, tongue licking,
neck tightening, etc., this is the right gear. The shock range varies according to training
conditions, and if the dog is highly inattentive, a strong level is needed to stimulate him.
According to the actual use, select the long/short E-shock contactors and install them on the back
of the product.
Then choose long/short conductive silicone protective sleeve to directly cover the E-shock contact,
which can effectively reduce the physical damage of the shock contact to the dog's skin.
Please use appropriate force, otherwise the device will be damaged.
①Choose contacts
① Choose protective sleeve ② Directly put on ③ OK!
②Rotary tightening contacts ③OK!
11-22lb 22-33lb 33-55lb 55-77lb 77-110lb
Voice
Vibration
Electric shock off off 1+ 2+ 3+
1~2 2~3 3~4 5~6 6~7
Default Default Default Default Default
Dog
10/Page

（EN) USER MANUAL >>
MEGWR
① Short press the key of the transmitter to test the
sound, and the receiver will beep for 1 second.
②Short press the key of the transmitter for vibration
test, and the receiver will vibrate for 1 second
according to different vibration levels.
③ Press the test board on the shock column of the
receiver, short press the key of the transmitter to
carry out the shock test, and the light on the test
board will be lit. The higher the shock level, the
brighter the light.
>> Functional testing
After assembly, functional testing is recommended. Follow these steps to test.
Chirp for 1 s
Vibration 1 s
11/Page

（EN) USER MANUAL >>
MEGWR
>> The wearing of receiver
>> Troubleshooting
The neck circumference ranges from 8 "to 25". Before putting on the collar, adjust the buckle and
slip buckle so that the collar is the right size. Make sure that the shock contact is firmly attached to
your dog's neck.
Q: Why does the receiver not work when the transmitter is shocked?
A: There are 3 possible reasons for this problem. The first is that the transmitter and receiver are
not paired, so try repairing. Second, the shock contact does not touch the skin, so please try
again to adjust the tightness of the collar to ensure good skin contact. Third, the level setting is
not high enough, so try it increase the output level of the shock function
Q: Is the product safe and humane?
A: All means of receiving do not cause any direct harm to the nothingies, but make them feel very
uncomfortable. Even if this is the case, do not overuse this product on objects. Please refer to
the manual for all safety statements.
Q: Receiver and transmitter not working?
A: There may be one reason for this problem. Firstly, the transmitter and receiver are not powered
on. Please refer to the manual for startup operation. Secondly, the battery of the transmitter and
receiver is exhausted. Please charge the receiver and transmitter. The charging time is about 2
hours.
12 3 4
FAQ
Unable to turn on
1.Low battery
2.Cannot start after charging
1. The receiver red light does not
light up or the transmitter screen
does not light up during charging
2. When charging, the receiver red
light is on or the transmitter screen
is on, but the battery cannot be
charged
1. Check whether the machine is
turned on
2. Check whether the channel
number is selected incorrectly
3. Check whether the transmitter
and receiver are not paired
4. The receiver is damaged
1. Turn on the receiver
2. Please adjust the channel
number
3. Please pair transmitter and
receiver again
4. Please contact the seller for
replacement
1. Please check whether the
charging line interface is in
good contact
2. Please contact the seller for
exchange
1. Please charge and try again
after full charge
2. Please contact the seller for
exchange
Unable to charge
The receiver does not respond
when thetransmitter is operating
Cause analysis Exclusion methodFault Phenomenon
12/Page

（EN) USER MANUAL >>
MEGWR
>> Terms of Use & Limitation of Liability
>> Certification Statements
Terms of Use & Limitation of Liability
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1.Terms of Use
Your use of the product constitutes your acceptance of all the terms, conditions and statements
contained in this Manual
2. Use it correctly
The product is designed for pets that need training. Proper use includes checking the product's
instruction manual and any specific "safety" and "care" statements.
3. Prohibit illegal use and prohibit use
This product is suitable for pets. This training device is not intended to harm or annoy pets.
Failure to follow the instructions may violate local laws.
4. Scope of responsibility
The Manufacturer shall not be liable for any direct, indirect, punitive, non-material and other
indirect losses arising from the incorrect use or misuse of the Products, and the buyer shall
assume all risks and liabilities for the use of the products.
5. Terms and conditions modification
The manufacturer reserves the right to change the terms relating to certain products. Conditions
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause
undesired operation.
Warning: Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
13/Page

（EN) USER MANUAL >>
MEGWR
Please observe the regulations for electronic and electrical devices to be disposed of in the
respective country. In some countries or regions, this device must be recycled. If this device is no
longer required, it must not be disposed of with normal municipal waste. Separate collection of
spent batteries is required in many regions; check the regulations in your area before discarding
spent batteries. For more recycling information, please refer to local regulations.
Recycling Information&Battery Disposal
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communica-tions.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
14/Page

MANUFACTURER: Quanzhou Purplebox Electronics Co.,LTD
ADDRESS:Floor 3&4, No.41 Wan Rong Street, Wansheng Community, Wan’ an,
Luojiang, Quanzhou, Fujian, China
Email:[e-mail]
Website:www.megwr.com
