Meijer HYWN-23 User manual

ELECTRIC FIREPLACE MANTEL
OWNERS MANUAL
Model HYWN-23
ONLY use this fireplace mantel and insert as described in this manual. Any other
use is not recommended by the manufacturer, and may cause fire, electric shock, or
other personal injury.
WARNING! Read and understand this entire owner’s manual, including
all safety
information, before plugging in or using the insert. Failure to do so could result in fire,
electric shock, serious personal injury, or death.
WARNING!INDOOR use only! NEVER use this product outdoors!
SAVE THESE INSTRUCTIONS!
CAUTION! Keep this owner’s manual for future reference. If you sell or give this product
away, make sure this manual accompanies this product.
Meijer.com

2
IMPORTANT SAFETY INFORMATION!
WARNING
ALWAYS keep electric cords, home furnishings, drapes, clothing, papers, or other
combustibles at least 3 feet (0.9m) away from the front of this insert, and away from the
bottom, sides, and rear of this insert.
DO NOT place the insert near a bed because objects such as pillows or blankets can fall off
the bed and be ignited by the insert.
DO NOT COVER this insert or block the air vents at all. Doing so could cause a fire.
AVOID fire or electric shock! NEVER insert or allow any foreign objects to enter the
ventilation or exhaust openings of this insert.
Prevent Fire! Keep all flammable liquids, like gasoline or paint, away from this insert. This
insert produces arcing sparks that could ignite flammable liquids.
DO NOT cover this insert in any manner. Doing so could block the air flow and cause the
unit to overheat, or could ignite the material covering the insert.
NEVER run the power cord under carpet, rugs, runners, or any other covering. Doing so
could cause the cord or materials covering the cord to overheat.
AVOID FIRE! Regularly inspect all air vents to make sure they are free from dust, lint, or other
blockage. Unplug the unit and clean with a vacuum ONLY. DO NOT rinse or get wet.
WARNING
For residential use only! NOT for commercial use! NEVER use this fireplace for other than
its intended purpose.
Use extreme caution if using this insert near children, or where children may be present.
NEVER leave this insert unattended. ALWAYS unplug this insert when not in use.
NEVER sit, stand, or climb on the mantel or insert. Doing so could cause it to fall over or
break.
This insert is hot when in use. AVOID INJURY! DO NOT TOUCH hot surfaces, or attempt
to move this insert while it is hot.
ALWAYS turn this insert off before unplugging it from the outlet.
AVOID INJURY! Keep the cord from crossing traffic areas to avoid tripping.
NEVER modify this fireplace. Doing so could result in personal injury or property damage.
Modification of this fireplace completely voids all warranties.
Discontinue use if this fireplace malfunctions or is dropped or damaged in any manner.
Meijer.com

3
WARNING
Risk of electric shock! DO NOT OPEN! No user-serviceable parts inside!
ALWAYS disconnect this unit from the power supply before performing any assembly or
cleaning, or before relocating the electric fireplace.
ALWAYS store this insert in a dry location. NEVER use the fireplace if it has become wet.
NEVER use this insert in bathrooms, laundry rooms, or any other location where the insert
could fall into a bathtub or pool, become damp or come in contact with water.
NEVER operate this insert if the power cord or plug has become damaged, or if the
grounding pin is damaged or missing.
Place the insert near a wall outlet so an extension cord is not needed. If an extension cord is
needed, the gauge of the cord must be at least 14AWG, and the rating must be at least
1875 Watts. NEVER use a smaller gauge cord with a lower rating. Doing so may result in
fire or electric shock.
ONLY use this insert on a 110~120 Volt 15 Amp grounded circuit. NEVER overload the
circuit. If this insert trips the circuit breaker, unplug all other appliances on the same circuit
before the next use. Avoid plugging other appliances into the same circuit as this insert.
NEVER plug this insert into an outlet that is old, cracked, or has any loose wires or
connections. Plugging this insert into a faulty outlet could result in electric arcing within the
outlet that could cause the outlet to overheat or catch fire.
ALWAYS check your insert cord and plug connections with each use!
i) MAKE SURE the plug fits tight in the outlet! Faulty wall outlet connections or loose plugs
can cause the outlet to overheat.
ii) Inserts draw more current than small appliances. Overheating may occur even if it
has not occurred with the use of other appliances.
iii) During use check frequently to see if the plug outlet or faceplate is HOT!
iv) If the outlet or faceplate is HOT, discontinue use immediately and have a qualified
electrician inspect and/or replace the faulty outlets.
•The cord supplied with the insert
has a
plug with two blades (live and neutral) and
one round pin (ground). If a 3-slot
receptacle is not available, an adapter
MUST be used. The adapter MUST be
properly grounded to the outlet box (see
figure at right).
Meijer.com

4
PREPARATION
A complete electric fireplace consists of two parts; the mantle and the electric fireplace insert.
Each is packed in a separate carton. Always use the electric insert with the matching mantle.
Remove all parts from the carton and place them on a clean, soft, dry surface. Check the parts list to
make sure nothing is missing. Dispose of packaging materials properly. Please recycle.
PARTS & HARDWARE
Electric Insert (not shown) 1
A Hearth 1
B Left Side Panel 1
C Right Side Panel 1
D Left Front Panel 1
E Right Front Panel 1
F Header 1
G Mantel 1
J M4x25 Wood Screws 20
K Insert Mounting Clips 4
L Insert Mounting Screws 4
H
ANTI-TIP SAFETY KIT
Wall Anchors (H1) 2
Brackets (H2) 2
5/8” Screws (H3) 2
1-3/8” Screws (H4) 2
Cable Tie (H5) 1
Note: A Phillips screwdriver is required for assembly, but is not included.
A
F
E
D
B
C
G
H
Meijer.com

5
ASSEMBLY
STEP 1. Thread wood screw (J) through bottom connector on left side panel (B) and into hole in
hearth (A).Secure with Phillips screwdriver. DO NOT over-tighten. Repeat for right side panel (C).
STEP 2. Thread screws (J) through connectors in right side panel (C) and into right front panel (E).
Thread screw (J) through connector on right front panel (E) and into hearth (A). Secure with Phillips
screwdriver. DO NOT over-tighten. Repeat for left front panel (D).
C
B
A
You will need:
J x 8
B
J
You will need:
J x 2
J
C
A
D
E
Rear
Rear
Front
Front
Meijer.com

6
STEP 3. From behind, thread screws (J) through holes in header (F) and into holes in left and right
front panels (D/E). Secure with Phillips screwdriver. DO NOT over-tighten.
STEP 4. Set mantel (G) on top of hearth assembly. Thread screws (J) through holes in side panels
(B/C) and header (F) and into mantel (G). Secure with Phillips screwdriver. DO NOT over-tighten.
C
J
D
E
A
C
2
B
You will need:
J x 4
You will need:
J x 6
F
E
D
A
B
J
F
G
Front
Rear
Rear
Front
Meijer.com

7
ANT-TIP SAFETY KIT INSTALLATION
A. Secure one bracket (H2) to an inside rear surface of the mantel with two 5/8” screws (H3).
Tighten the screws with a Phillips screwdriver. DO NOT over-tighten. B. Position the mantel in the
desired location and mark the wall where the second bracket will be mounted.
A. Secure the second bracket (H2) with two 1-3/8” screws (H4). Screw directly into the wall studs. [If
no studs are available, drill two holes and tap the anchors (H1) into the holes. Then screw the two
screws through the bracket into the anchors.] B. Tighten all screws with a Phillips screwdriver. DO
NOT over-tighten. C.
Loop the cable tie (H5) through the two brackets and lock the ends together.
Tug on the cable tie and brackets to make sure they are secure.
WARNING! This cable may reduce possible risk of injury if the fireplace is improperly
handled. But, it is not a substitue for proper adult supervision.
WARNING! This anti-tip safety kit is only a deterrent. It is not a substitute for proper
adult supervision. NEVER leave children unattended near this product!
Mantel
H3
H2
Mark the
wall
H3
H3
H3
H5
H5
H2
H2
H4
H4
H1
H1
Meijer.com

8
Limited Warranty
This warrants to the original purchaser that this product is free from defects in material and
workmanship as of the date of purchase and that it will, under normal use and proper care, remain so
for one year from the date of purchase. Missing or initially defective parts will be replaced free of
charge during the period of this limited warranty. The original dated sales receipt is required for all
warranty claims. This warranty does not cover damage which has occurred during transport from the
point of purchase to the consumer’s home. This warranty does not cover glass, light bulbs, remote
controls, or batteries.
This product is for residential use only. Any and all commercial use of this product voids all
warranties, and frees the manufacturer from all liability. The following will void this warranty: Damage
caused from tampering with, modifying, or altering the fireplace insert in any manner; Damage due to
incorrect assembly, improper care, misuse, or abuse; Damage from being used with the wrong power
source; Water damage; Damage caused from this insert being used outdoors; Damage caused from
this insert being used for excessive periods of time; Damage caused by the insert being used in a
commercial application; Damage from use as a primary heat source; Other misuse or abuse not
specifically listed herein. This product is not intended to be used as a primary heat source.
VENDOR DEVELOPMENT GROUP, INC.(HEREAFTER, VDG), ITS DIRECTORS, OFFICERS, OR
AGENTS, WILL NOT BE LIABLE TO THE PURCHASER OR ANY THIRD PARTY, WHETHER IN
CONTRACT, IN TORT, OR ON ANY OTHER BASIS, FOR ANY INDIRECT, SPECIAL, PUNITIVE,
EXEMPLARY, CONSEQUENTIAL, OR INCIDENTAL LOSS, COST, OR DAMAGE ARISING OUT OF
OR IN CONNECTION WITH THE SALE, MAINTENANCE, USE, OR INABILITY TO USE THIS
PRODUCT, EVEN IF VDG, OR ITS DIRECTORS, OFFICERS, OR AGENTS HAVE BEEN ADVISED
OF THE POSSIBILITY OF SUCH LOSSES, COSTS OR DAMAGES, OR IF SUCH LOSSES, COSTS,
OR DAMAGES ARE FORESEEABLE. IN NO EVENT WILL VDG, OR ITS OFFICERS, DIRECTORS,
OR AGENTS BE LIABLE FOR ANY DIRECT LOSSES, COSTS, OR DAMAGES THAT EXCEED
THE PURCHASE PRICE OF THE PRODUCT.
Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, so
the above limitation or exclusion may not apply to the purchaser. This limited warranty gives you
specific legal rights, and you may also have other rights which vary from jurisdiction to jurisdiction.
Thank you for purchasing this Electric Fireplace! If you need assistance with assembly, have
questions about the use of this product, or have missing or defective parts, please e-mail us at
customerserv[email protected]
Or, call us toll-free (M-F 8:30 AM to 4:30 PM Central Standard Time) at
1-866-561-0731
Vendor Development Group, Inc.
Minneapolis, MN 55401
Made in China
