Memphis MME10TSP User manual
MEMPHIS MARINE
MME10TSP & MME10T24
MARINE GRADE BASS SYSTEM & ENCLOSURE
Specifications
Features
MME10T24 // NON POWERED ENCLOSURE
• HDPE Rotomolded enclosure
• Die cast aluminum mounting feet
• Dual 10” passive radiator for increased low end output
• Integrated RGB lighting
• Impact resistant ABS grills
• FLEXTM Selectable Impedance Technology 2Ω or 4Ω
MME10TSP // POWERED ENCLOSURE
• HDPE Rotomolded enclosure
• Die cast aluminum mounting feet
• Dual 10" passive radiator for increased low end output
• Integrated RGB lighting
• Impact resistant ABS grills
• Internal 400W amplifier
MME10T24 // NON POWERED ENCLOSURE MME10TSP // POWERED ENCLOSURE
MME10TSP & MME10T24
Memphis Audio built a 50 year legacy in the audio industry by engineering the highest quality products to produce
the best possible listening experience for our fans and loyal supporters. To fully appreciate our products we
recommend taking the time to read and follow the instructions in this manual. As always, we recommend all the
installations and services to be performed by an authorized Memphis Audio dealer.
For optimal performance, Memphis recommends using only Memphis Connection accessories. Outfitting
your system with properly sized Memphis Connection wire and accessories will dramatically boost your
listening experience and increase the durability of your Memphis Audio products.
300/600
86
48
W 15.45 x H 14.1 x L 13.87
RMS/PEAK (w)
Sensitivity (dB)
Magnet Size
Dimensions
400
86
48
W 15.45 x H 14.1 x L 13.87
Amplified Power (w)
Sensitivity (dB)
Magnet Size
Dimensions
When troubleshooting your amp, speaker and speaker wires should be tested first.
If you are uncertain or uncomfortable proceeding with your installation, please contact your local
authorized Memphis Audio Dealer
Memphis Audio recommends the installation of our products to be performed by an Authorized dealer. Attempting
an installation project on your own or through an unauthorized source may result in damage to your products and
may potentially void your warranty.
Marine enclosures should be mounted in areas that receive adequate ventilation. These enclosures are water and
element resistant but should be mounted in areas that do not receive excessive direct contact with water. These
units are not intended to be submerged and care should be used when determining a mounting location.
Be certain the power is disconnected prior to starting your installation. Failure to disconnect the electrical system
prior to installation may result in injury, damage to your unit, or damage to your vehicle.
Take time to inspect the area you plan on installing your Memphis Marine Enclosure. Check the area for any potential
hazards like electric lines, fuel lines, hydraulic lines or any other potential hazards.
Be certain you are installing your Memphis Marine Enclosure in a safe location that will not interfere with your ability
to safely operate your vehicle.
Confirm the mounting location is a stable and secure location. You will be screwing the unit directly into the
mounting location using the (8) provided screws. Be certain the location is able to accept the screws and that the
screws will not cause any cosmetic, structural or mechanical damage to your vehicle.
No Output
•Confirm all wiring is firmly connected. Both +12V and REM terminals must have +12 Volts present and GND must be
connected to chassis’ ground or to the negative battery terminal.
•Confirm the signal source is connected and supplying an output signal. To confirm the amp is working, connect an
RCA patch cord to the line inputs of the amplifier (do not connect the other end of the patch cord). Briefly tap the
center pin of each disconnected RCA with your finger. This should produce a noise (brief static or hum) in the
speakers.
The Amp Is Hot
Check the speaker impedance or load. The total minimum impedance of all speakers should not be lower than the
rating of the amp.
Only One Channel Works
• Confirm the speaker terminal strip connections are firmly connected.
• Check “balance” control on your signal source.
• If using RCA Low-Level inputs, reverse the input plugs at the amplifier. If the channel that is silent reverses
position, the problem is in the source unit or connecting cable.
Weak Output
• Check input sensitivity control adjustment.
Unwanted Noise
• Whine that increases and decreases with engine speed - confirm the Amp & Source unit are grounded properly.
• Clicking or popping noise at a rate that follows engine speed - this is often induced by the vehicles ignition system.
Confirm that the vehicle is equipped with resistor spark plugs and wires. The ignition system may need service.
• Noise can be caused by routing speaker input wires too close to the light wires and other accessory wires in the
vehicle. Re-route wires to avoid unwanted interference.
• If above steps do not improve/reduce noise, the system should be checked by a professional audio installer at a
Memphis Authorized Dealer.
Red LED is Illuminated
• Speaker or wire is shorted
• Battery voltage too high
• Amplifier has overheated due to improper ventilation
• Battery voltage too low
Troubleshooting
Warning
Installation Information
Use conventional stranded copper wire for all connections. Tinned Copper Memphis marine grade wire is
recommended for corrosion resistance in powersports and marine applications. Finish the ends of the wires at the
amp and vehicle with proper size terminals. Poorly made connections and/or inadequate wire size will generate
excessive heat and may lead to equipment failure.
12 Volt + Connection
make the 12V+ connection directly at the positive battery post using the proper wire size and fuse listed below, The
fuse should be installed within 18” of the battery for standard applications and withing 7” of the battery for marine
applications*. This fuse is vital to protecting the vehicle from damage in the case of a dead short. The fuse value at
the battery should be at least equal to the total fuse value of all the amplifiers being used.
Ground Connection:
For marine applications connect the ground to the negative battery terminal. For non-marine applications ground
connection directly to the chassis of the vehicle as close to the amp as possible. Make sure this connection is made
with the same wire size as used for the 12 volt connection. Ensure that all dirt, grease, paint and coatings are
removed prior to attaching the ground wire to chassis.
Remote Turn On
Remote turn on should be connected to the source unit’s remote turn on lead. 18 gauge wire should be ran from
the remote turn on lead on your source unit to the terminal labeled REM on your amplifier.
MME10TSP POWERED ENCLOSURE ONLY!
POWER CONNECTIONS
ONLY APPLY TO MME10TSP
AMPLIFIED ENCLOSURES
Install the fuse at the battery last!
TO SOURCE UNIT’S
REMOTE TURN-ON LEAD
FUSE HOLDER
(18” FROM BATTERY)
GROUND DIRECTLY TO BATTERY
FOR MARINE APPLICATIONS
*NOTE: Seven inches is the standard distance under U.S. Coast Guard CFR33 for placement of fuses or
breakers as required by law for new boat manufacturing. It is recommended that you adhere to this standard
in an installation. Not adhering to this regulation puts the safety of boat passengers at risk in the event of a
power wire shirt circuit.
RED WIRE
The RED wire should be connected directly to the battery’s positive terminal and fused with a 30A fuse.
BLACK WIRE
The BLACK wire should be directly connected to the battery’s negative terminal
BLUE WIRE
The BLUE wire needs to be connected to 12v+ accessory circuit of your vehicle or remote turn-on out put of your
source/head unit.
RCA INPUTS
Connect the RCA inputs to the signal source of your choice.
GAIN SETTING
The gain control is NOT a volume control. The gain control adjusts the amount of signal required to drive the
amplifier to full output. With the gain at full clockwise rotation, less signal voltage is required to drive the amp to
full output. With the gain at full counter clockwise rotation, more signal voltage is required to drive the amp to full
output. For optimal performance, set the gain control to minimum
the bass level desired.
Low Pass Filter (LPF)
The Lowpass crossover/filter is designed to remove high frequency information from a speaker. This is generally
used to prevent mid bass speakers or subwoofers from trying to reproduce mid and high frequency information
that they are not designed to reproduce. The crossover frequency is adjustable from 50Hz to 200Hz. To adjust the
LPF turn the pot clockwise to raise the frequency and counter clockwise lowers the frequency. Most subwoofers
should be set between 80Hz and 100Hz depending on how low the mid-bass or midrange drivers are capable of
playing.
BASS KNOB
The included bass knob can be connected and mounted to a desired location to allow easy trim adjustment of the
bass level after the gain has been set.
Wiring Instructions
GAIN
LPF
POWER
MIN MAX
50Hz 200Hz
DESIGNED & DEVELOPED
IN THE UNITED STATES
RCA INPUT
RGB WIRE
GROUND WIRE
3.5MM CONNECTOR FOR REMOTE
POSITIVE POWER WIRE W/ FUSE HOLDER
REMOTE WIRE
LOW PASS FILTER
GAIN SETTING
WIRING MME10T24 ONLY (NON-POWERED)
RGB WIRING
The MME10T24 is a non amplified loaded enclosure. You must connect your own amplifier to this unit to provide
power. To do so, connect the included wires from the back of your MME10T24 enclosure to your amplifier of
choice. Connect the RED wire to the + terminal and the black wire to the - Terminal. Follow your amplifiers wiring
instructions to complete your installation.
Once you have your MME10T24 connected to your amplifier, you can now adjust your impedance using the
included Memphis FLEXTM Selectable Impedance Technology terminal located on the back of the enclosure. This
simple system allows you to effortlessly adjust your impedance to maximize your systems performance by
adjusting the color coded jumper cables to a predefined location on the terminal.
This impressively engineered design allows you to effortlessly change the impedance of your subwoofer to match
the needs of your system. Simply reconfigure your existing sub by repositioning the color coded jumper to the
correct impedance setting and you are ready to play.
2Ω WIRING 4Ω WIRING
HARD WIRING
To hard wire your LED’s to emit one of 7 different colors. To hard wire a specific color, wire the BLACK wire from the
harness directly to the 12V+ from the battery. Be certain to wire a fuse in between the pigtail and the battery to
avoid accidental damage to your vehicle and audio system.
Choose the color you wish to emit from the chart below. Wire the correct wires from the chart to ground.
Example: For a YELLOW light you would wire the Red and Green wires to ground and not wire the blue wire. The
black wire would be wired to 12V+.
RGB CONTROLLER WIRING
If you want to be able to control and adjust light colors you can purchase a separate RGB controller. The RGB
controller would be wired directly to the battery of your vehicle and the harness would be wired directly to your
RGB controller.
RGB COLORS
None
x
Red
x
Green
x
Blue
xx
Yellow
x
x
Cyan
xx
Magenta
xx
x
White
RED GREEN BLUE EMITTED COLOR
MOUNTING
FEET INSTALLATION
Your Memphis Marine Enclosure includes (4) rugged feet. Align the feet with the pre-drilled threaded holes on the
unit. Each foot will use 2 Allen head bolts and 2 washers. Align the first washer with the first hole in the foot and
insert the screw and hand tighten. Repeat this process for each hole in the 4 feet. Once complete, tighten the
screws down until secure (Do NOT over-tighten).
SECURING TO YOUR VEHICLE
Once you’ve determined your mounting location, double check that your units feet will mount to the vehicle
securely on a flat even surface free from any hazards. Using the provided (8) screws, drill a pilot hole with a smaller
bit in the mounting holes of the feet. Using the included screws, screw the unit down to the surface of your vehicle.
Repeat this process for all the mounting holes on your unit.
End Panel Connections
Memphis Marine Audio Amplifier Limited Warranty
This product has a 2 year warranty from the date of purchase for defects in material or workmanship. This
warranty will be extended to 3 years when installed by a Memphis authorized dealer using Memphis Connection
products. The warranty is void if the product has been physically damaged by improper usage or abuse. If
repairs are attempted outside of a Memphis Audio facility, the warranty is void.
This warranty is limited to the original retail purchaser and does not cover any expenses incurred in the removal
or re-installation of the product. This warranty does NOT apply to product exterior and cosmetics. Memphis Audio
disclaims any liability for incidental or consequential damages caused by product defects. Memphis Audio liability
will not exceed the purchase price of the product and the warranty period specified.
What is NOT covered under warranty
• Damage due to improper installation
• Damage caused by exposure to moisture, excessive heat, chemical cleaners and/or UV radiation
• Damage through negligence, misuse, accident or abuse. (Repeated returns for the same damage may be abuse)
• Product damaged in accident and/or due to criminal activity
• Service performed by anyone other than Memphis Audio
• Subsequent damage to other components
• Any cost or expense related to the removal or re-installation of product
• Products with tampered, missing , altered or defaced serial numbers/labels
• Freight damage
• The cost of shipping product to Memphis Audio
• Return shipping on non-defective items
• Any product not purchased from an authorized Memphis Audio dealer
Some states do not allow the exclusion or limitation of incidental or consequential damages. The above limitations
or exclusions may not apply to you. This warranty gives you specific rights, you may have other rights which vary
from state to state.
If warranty service is required, a return authorization number is required to return the product to Memphis Audio.
Warranty shipments to Memphis Audio are the responsibility of the purchaser. Pack the product carefully in the
original carton if possible Memphis Audio will not be responsible for damages incurred in shipment or due to
improper packaging materials used by the purchaser.
If determined to be within warranty your product will be repaired or replaced at the discretion of Memphis Audio.
Warranty
Service/Returns
Please consult with your local authorized dealer if you experience issues with your unit. You may also contact
Memphis Audio customer service at 800-489-2300 or email tech support directly at:
for a Return Authorization number. Units received without an accompanying Return Authorization number will be
processed more slowly. Additionally, you must include a copy of your purchase receipt from an authorized dealer
for consideration of in-warranty service, otherwise repair charges will apply. Units received without a receipt will be
held for up to 30 days allowing us time to contact you and obtain a copy of the receipt. After 30 days all units will
be returned to you unrepaired.
RGB CONTROLLER WIRING
If you want to be able to control and adjust light colors you can purchase a separate RGB controller. The RGB
controller would be wired directly to the battery of your vehicle and the harness would be wired directly to your
RGB controller.
800.489.2300
www.memphiscaraudio.com
122 Gayoso Ave.
Memphis,TN, USA
@MEMPHISCARAUDIOUSA
@MEMPHISAUDIO
This manual suits for next models
1
Table of contents
Other Memphis Enclosure manuals
