Mercedes-Benz 2000 CLK 320 User manual

CLK Cabriolet
Operator’s Manual
CLK 320
CLK 430

Our company and staff congratulate you on the purchase of your new Mercedes-Benz.
Your selection of our product is a demonstration of your trust in our company name. Further, it exemplifies your desire
to own an automobile that will be as easy as possible to operate and provide years of service.
Your Mercedes-Benz represents the efforts of many skilled engineers and craftsmen. To ensure your pleasure of
ownership, and for your safety and that of your passengers, we ask you to make a small investment of your time:
•Please read this manual carefully before putting it aside. Then return it to your vehicle where it will be handy for
your reference.
•Please abide by the recommendations contained in this manual. They are designed to acquaint you with the
operation of your Mercedes-Benz.
•Please abide by the warnings and cautions contained in this manual. They are designed to help improve the safety
of the vehicle operator and occupants.
We extend our best wishes for many miles of safe, pleasurable driving.
DaimlerChrysler AG
2

Introduction Central locking switch 36 Antiglare night position 75
Product information 7 Automatic central locking 37 Exterior rear view mirrors 76
Operator’s manual 8 Emergency unlocking in case of accident 38 Instrument cluster 80
Where to find it 13 Trunk 39 Multifunction steering wheel,
Reporting Safety Defects 15 Trunk lid release switch 41 multifunction display 86
Antitheft alarm system 42 Trip and main odometer, vehicle
Instruments and controls Tow-away alarm 44 speed, FSS and engine oil level
Instruments and controls 18 Power seats, front 45 indicator 90
Center console 20 Front head restraints 50 Audio systems 91
Overhead control panel 21 Roll bar and head restraints, rear 51 Telephone 94
Backrest 53 Navigation system 99
Operation Multicontour seat 54 Trip computer 100
Vehicle keys 24 Heated seats 55 Malfunction message memory 102
Start lock-out 27 Seat belts and integrated restraint system 57 Individual settings 104
General notes on the central
locking system 27
Seat belts 57 Setting the audio volume 106
Central locking system 28 Seat belt nonusage warning system 58 Flexible service system (FSS) 107
Radio frequency and infrared
remote control 28
BabySmart™ airbag deactivation system 63 Engine oil level indicator 110
Locking and unlocking 30 Supplemental restraint system (SRS) 64 Engine oil consumption 111
Choosing global or selective mode
on remote control 31
Emergency tensioning retractor (ETR) 64 Exterior lamp switch 112
Opening the trunk 31 Airbags 65 Night security illumination 113
Opening and closing windows
from outside 32
Safety guidelines for the seat belt,
emergency tensioning retractor and airbag 70
Headlamp cleaning system 114
Panic button 33 Infant and child restraint systems 71 Combination switch 115
Mechanical keys 33 Adjusting telescoping steering column 74 Hazard warning flasher switch 117
Doors 34 Inside rear view mirror 75 Automatic climate control 118
3

Operation Audio and telephone 125 The first 1 000 miles (1 500 km) 171 Travelling abroad 200
Power windows 143 Maintenance 171 Cruise control 201
Interior lighting 146 Catalytic converter 172 Brake assist system (BAS) 204
Entrance lamps, exit lamps in doors 146 Emission control 173 Antilock brake system (ABS) 206
Sun visors 147 Tele Aid 174 Electronic stability program (ESP) 208
Illuminated vanity mirrors 147 Steering lock 180 What you should know at the
Interior 148 Starting and turning off the engine 182 gas station 211
Storage compartments, armrest and
cup holder
148 Automatic transmission 183 Check regularly and before a
long trip 213
Glove box 148 Parking brake 192
Ashtray 150 Driving instructions 192 Instrument cluster display
Lighter 151 Drive sensibly – save fuel 192 Malfunction and indicator
lamps in the instrument cluster 216
Cargo tie down rings 152 Drinking and driving 193 On-board diagnostic system
Parcel net in front passenger footwell 152 Pedals 193 Check engine malfunction
indicator lamp 216
Armrest, rear bench 152 Power assistance 193 Supplemental restraint system
(SRS) indicator lamp 218
Telephone, general 153 Brakes 193 Fuel reserve and fuel cap
Cellular telephone 153 Driving off 194 placement warning 218
Garage door opener 154 Parking 195 Electronic stability
program(ESP) — warning lamp 219
Soft top 158 Tires 195 BAS/ESP malfunction indicator
lamp 219
Wind screen 165 Snow chains 198 ABS malfunction indicator lamp 219
Winter driving instructions 198 Telescoping steering column –
indicator lamp
220
Driving Deep water 199 Seat belt warning lamp 220
Control and operation of radio transmitters 170 Passenger compartment 200
4

Malfunction and indicator lamps in the
center console 221
Practical hints Jump starting 263
AIRBAG OFF indicator lamp 221 First aid kit 238 Towing the vehicle 265
Roll bar warning lamp 221 Shelf below rear window 238 Transmission selector lever,
manually unlocking 268
Malfunction and warning messages in
the multifunction display 222
Stowing things in the vehicle 238 Bulbs 269
DISPLAY DEFECTIVE (engine
control unit) 223
Luggage cover 238 Adjusting headlamp aim 274
DISPLAY DEFECTIVE (several
systems) 223
Spare wheel, vehicle tools, storage
compartment 240
Changing batteries in the
electronic main key 277
BATTERY/ALTERNATOR 224 Vehicle jack 241 Raising soft top manually 280
ABS-SYSTEM 225 Fuses 242 Antenna 287
BRAKE ASSIST 225 Hood 244 Manual release for fuel filler
BRAKE LINING WEAR 226 Checking engine oil level 246 flap 287
BRAKE FLUID 226 Automatic transmission fluid level 247 Trunk lamp 288
PARKING BRAKE 227 Coolant level 247 Replacing wiper blade insert 288
ENGINE FAN 227 Adding coolant 248
COOLANT (coolant level) 228 Windshield washer / headlamp clean.system 249 Vehicle care
COOLANT TEMP. (coolant
temperature) 229
Windshield and headlamp washer fluid
mixing ratio 249
Cleaning and care of the vehicle 292
LIGHTING SYSTEM 230 Wheels 250 Engine cleaning 293
LIGHT SENSOR 231 Tire replacement 250 Vehicle washing 293
STEER. WHEEL ADJUST. 231 Rotating wheels 251 Power washer 293
OIL TEMP. 232 Spare wheel 252 Plastic and rubber parts 293
ENGINE OIL LEVEL 232 Changing wheels 254 Tar stains 294
ELEC. STABIL. PROG. (Electronic
stability program) 234
Tire inflation pressure 259 Window cleaning 294
WASHER FLUID 235 Battery 261
5

Headlamps, taillamps, turn signal
lenses 294
Technical data
Wiper blade 294 Spare parts service 300 Coolants 311
Seat belts 294 Warranty coverage 300 Consumer information 313
Headliner 294 Identification labels 301 Uniform tire quality grading 313
Instrument cluster 294 Layout of poly-V-belt drive 302 Index 315
Steering wheel and gear selector lever 295 Technical data 303
Hard plastic trim items 295 Fuels, coolants, lubricants etc. –
capacities 307
Upholstery 295 Engine oils 309
Ornamental moldings 295 Engine oil additives 309
Paintwork, painted body components 296 Air conditioner refrigerant 309
Light alloy wheels 296 Brake fluid 309
Soft top 297 Premium unleaded gasoline 310
Wind screen 298 Fuel requirements 310
Rubber weatherstrip 298 Gasoline additives 311
6

Introduction
Product information
Kindly observe the following in your own best interest:
We recommend using Mercedes-Benz original parts as well as conversion parts and accessories
explicitly approved by us for your vehicle model.
We have tested these parts to determine their reliability, safety and their special
suitability for Mercedes-Benz vehicles.
We are unable to make an assessment for other products and therefore cannot be held responsible
for them, even if in individual cases an official approval or authorization by governmental or other
agencies should exist. Use of such parts and accessories could adversely affect the safety, performance
or reliability of your vehicle. Please do not use them.
Mercedes-Benz original parts as well as conversion parts and accessories approved by us are available
at your authorized Mercedes-Benz Center where you will receive comprehensive information, also on
permissible technical modifications, and where proper installation will be performed.
7

Introduction
Operator’s manual
This Operator’s Manual contains a great deal of useful information. We urge you to read it carefully and familiarize
yourself with the vehicle before driving.
For your own safety and longer service life of the vehicle, we urge you to follow the instructions and warnings
contained in this manual. Ignoring them could result in damage to the vehicle or personal injury to you or others.
Vehicle damage caused by failure to follow instructions is not covered by the Mercedes-Benz Limited Warranty.
Your vehicle may have some or all of the equipment described in this manual. Therefore, you may find explanations
for optional equipment not installed in your vehicle. If you have any questions about the operation of any equipment,
your authorized Mercedes-Benz Center will be glad to demonstrate the proper procedures.
Service and warranty information
The Service and Warranty Information Booklet contains detailed information about the warranties covering your
Mercedes-Benz, including:
•New Car Limited Warranty,
•Emission System Warranty,
•Emission Performance Warranty,
•California, Massachusetts, and Vermont Emission Control System Warranty
(California, Massachusetts, and Vermont only),
•State Warranty Enforcement Laws (Lemon Laws).
8

Introduction
Important notice for California retail buyers of Mercedes-Benz automobiles
Under California law you may be entitled to a replacement of your vehicle or a refund of the purchase price, if
Mercedes-Benz USA, LLC or its authorized Mercedes-Benz Center fails to conform the vehicle to its express warranties
after a reasonable number of repair attempts during the period of one year or 12 000 miles from original delivery of
the vehicle. A reasonable number of repair attempts is presumed for a retail buyer (1) if the vehicle is out of service by
reason of repair of substantial nonconformities for a cumulative total of more than 30 calendar days or (2) the same
substantial non-conformity has been subject to repair four or more times and you have at least once directly
notified us in writing of the need to repair the non-conformity and have given us an opportunity to perform the
repair ourselves. Notifications should be sent to the nearest Mercedes-Benz Regional Office listed in the
Service and Warranty Information Booklet.
Maintenance
The Service Booklet describes all the necessary maintenance work which should be performed at regular intervals.
Always have the Service Booklet with you when you take the vehicle to your authorized Mercedes-Benz Center for
service. The service advisor will record each service in the booklet for you.
Roadside assistance
The Mercedes-Benz Roadside Assistance Program provides factory trained technical help in the event of a breakdown.
Calls to the toll-free Roadside Assistance number:
1-800-FOR-MERCedes (in the USA)
1-800-387-0100 (in Canada)
will be answered by Mercedes-Benz Client Assistance Representatives 24 hours a day, 365 days a year.
For additional information refer to the Mercedes-Benz Roadside Assistance Program brochure in your glove box.
9

Introduction
Change of address or ownership
If you change your address, be sure to send in the “Change of Address Notice” found in the Service and Warranty
Information Booklet, or simply call the Mercedes-Benz Client Assistance Center (in the USA) at 1-800-FOR-MERCedes,
or Customer Service (in Canada) at 1-800-387-0100. It is in your own interest that we can contact you should the need
arise.
If you sell your Mercedes, please leave all literature with the vehicle to make it available to the next operator.
If you bought this vehicle used, be sure to send in the “Notice of Purchase of Used Car” found in the Service and
Warranty Information Booklet, or call the Mercedes-Benz Client Assistance Center (in the USA) at
1-800-FOR-MERCedes, or Customer Service (in Canada) at 1-800-387-0100.
10

Introduction
Operating your vehicle outside the USA or Canada
If you plan to operate your vehicle in foreign countries, please be aware that:
•Service facilities or replacement parts may not be readily available,
•unleaded gasoline for vehicles with catalytic converters may not be available; the use of leaded fuels will damage
the catalysts,
•gasoline may have a considerably lower octane rating, and improper fuel can cause engine damage.
Certain Mercedes-Benz models are available for delivery in Europe under our European Delivery Program. For details,
consult your authorized Mercedes-Benz Center or write to:
In the USA: In Canada:
Mercedes-Benz USA, LLC
European Delivery Department
One Mercedes Drive
Montvale, NJ 07645-0350
Mercedes-Benz Canada, Inc.
European Delivery Department
849 Eglinton Avenue East
Toronto, Ontario M4G 2L5
11

Introduction
We continuously strive to improve our product, and ask for your understanding that we reserve the right to make
changes in design and equipment. Therefore, information, illustrations and descriptions in this Operator’s Manual
might differ from your vehicle.
Optional equipment is also described in this manual, including operating instructions wherever necessary. Since they
are special-order items, the descriptions and illustrations herein may vary slightly from the actual equipment of your
vehicle.
If there are any equipment details that are not shown or described in this Operator’s Manual, your authorized
Mercedes-Benz Center will be glad to inform you of correct care and operating procedures.
The Operator’s Manual and Service Booklet are important documents and should be kept with the vehicle.
12

Introduction
Where to find it
The Operator’s Manual is divided into eight sections:
• Instruments and controls: An overview of all the controls that can be operated from the driver’s seat.
• Operation: Information on the vehicle’s equipment and its operation.
•Driving:Important information on driving.
• Instrument cluster display: Displays and indicator lamps on the instrument cluster with brief instructions.
• Practical hints: Assistance and instructions in the event of an emergency.
•Carcare:Instructions on caring for your vehicle.
• Technical data: All the important technical data for your vehicle as well as consumer information such as fuels,
coolants, lubricants etc. is contained here.
•Index:Key terms to help you find a topic quickly.
Other documents may also be supplied, depending on your vehicle’s equipment.
Explanation of color used:
Warning notices for the protection of yourself and
others appear on red background.
13

Introduction
Problems with your vehicle
If you should experience a problem with your vehicle, particularly one that you believe may affect
its safe operation, we urge you to immediately contact your authorized Mercedes-Benz Center to
have the problem diagnosed and corrected if required. If the matter is not handled to your
satisfaction, please discuss the problem with the Mercedes-Benz Center management, or if
necessary contact us at the following addresses:
In the USA: Client Assistance Center
Mercedes-Benz USA, LLC
One Mercedes Drive
Montvale, NJ 07645-0350
In Canada: Customer Relations Department
Mercedes-Benz Canada, Inc.
849 Eglinton Avenue East
Toronto, Ontario, M4G 2L5
14

Introduction
For the USA only:
The following text is published as required of manufacturers under Title 49, Code of U.S. Federal Regulations,
Part 575 pursuant to the “National Traffic and Motor Vehicle Safety Act of 1966”.
Reporting Safety Defects
If you believe that your vehicle has a defect which could cause a crash or could cause injury or
death, you should immediately inform the National Highway Traffic Safety Administration
(NHTSA) in addition to notifying Mercedes-Benz USA, LLC.
If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety
defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA
cannot become involved in individual problems between you, your retailer, or Mercedes-Benz USA,
LLC.
To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1-800-424-9393
(or 366-0123 in Washington, D.C. area) or write to: NHTSA, U.S. Department of Transportation,
Washington, D.C. 20590. You can also obtain other information about motor vehicle safety from
the Hotline.
15

16

Instruments and controls
Instruments and controls 18
Center console 20
Overhead control panel 21
17

Instruments and controls
Technical
data
Instruments
and controls Operation Driving Instrument cluster display Practical hints Car care Index
Instruments and controls
18

Instruments and controls
Technical
data
Instruments
and controls Operation Driving Instrument cluster display Practical hints Car care Index
For more detailed descriptions see Index on page 315.
For adjustment of air outlets, refer to automatic climate
control, see page 118.
1Side air outlet, adjustable
2Air volume control for side air outlet
3Exterior lamp switch, see page 112
4Parking brake release, see page 192
5Parking brake pedal, see page 192
6Hood lock release, see page 244
7Combination switch, see page 115
8Cruise control switch, see page 201
9Multifunction steering wheel, see page 86
Horn (with electronic key in steering lock
position 1 or 2)
10 Instrument cluster, see page 80
11 Voice recognition system switch, see separate
operating instructions
12 Steering lock with ignition/starter
switch, see page 180
13 Center air outlets, adjustable
14 Air volume control for center air outlets
15 Left front seat heater switch, see page 55
16 Headlamp washer switch, see page 114
17 Roll bar switch, see page 52
Roll bar warning lamp
18 Hazard warning flasher switch, see page 117
19 Central locking switch, see page 36
20 Switch for tow-away alarm, see page 44
Indicator lamp for antitheft alarm system, see
page 42
21 Right front seat heater switch, see page 55
22 Automatic climate control, see page 118
Rear window defroster switch
23 Glove box (illuminated with electronic key in
steering lock position 1 or 2), see page 148
24 Audio system,
25 Storage compartment
26 Ashtray with lighter, see page 150
19

Instruments and controls
Technical
data
Instruments
and controls Operation Driving Instrument cluster display Practical hints Car care Index
Center console 1Soft top switch, see page 158
2ESP control switch, see page 209
3Program mode selector switch, see page 190
4Left power window switch (front), see page 143
5Right power window switch (front), see page 143
6Left power window switch (rear), see page 143
7Trunk lid release switch, see page 41
8Mirror adjustment switch, see page 76
9Right power window switch (rear), see page 143
10 Airbag Off indicator lamp, see page 221
ESP
P68.10-2191-27
10
1
23
6789
5
4
20
