Mercury PI845GVM-P User manual

i
Preface
Copyright
This publication, including all photographs, illustrations and software, is protected un-
der international copyright laws, with all rights reserved. Neither this manual, nor any
of the material contained herein, may be reproduced without written consent of the au-
thor.
Version 6.0
Disclaimer
The information in this document is subject to change without notice. The manufac-
turer makes no representations or warranties with respect to the contents hereof and
specifically disclaims any implied warranties of merchantability or fitness for any par-
ticular purpose. The manufacturer reserves the right to revise this publication
and to make changes from time to time in the content hereof without obligation of the
manufacturer to notify any person of such revision or changes.
Trademark Recognition
Microsoft, MS-DOS and Windows are registered trademarks of Microsoft Corp.
MMX, Pentium, Pentium-II, Pentium-III, Celeron are registered trademarks of Intel
Corporation.
Other product names used in this manual are the properties of their respective owners
and are acknowledged.
Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B digi-
tal device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not in-
stalled and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not oc-
cur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
− Reorient or relocate the receiving antenna.
− Increase the separation between the equipment and the receiver.
− Connect the equipment onto an outlet on a circuit different from that to which
the receiver is connected.
− Consult the dealer or an experienced radio/TV technician for help.
Shielded interconnect cables and a shielded AC power cable must be employed with
this equipment to ensure compliance with the pertinent RF emission limits governing
this device. Changes or modifications not expressly approved by the system's manu-
facturer could void the user's authority to operate the equipment.

ii
Declaration of Conformity
This device complies with part 15 of the FCC rules. Operation is subject to the follow-
ing conditions:
− This device may not cause harmful interference, and
− This device must accept any interference received, including interference
that may cause undesired operation.
Canadian Department of Communications
This class B digital apparatus meets all requirements of the Canadian Interference-
causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Réglement
sur le matériel brouilieur du Canada.
About the Manual
The manual consists of the following:
Chapter 1
Introducing the Motherboard
Describes features of the motherboard,
and provides a shipping checklist.
Go to ⇒page 1
Chapter 2
Installing the Motherboard
Describes installation of motherboard
components.
Go to ⇒page 6
Chapter 3
Using BIOS
Provides information on using the BIOS
Setup Utility.
Go to ⇒page 23
Chapter 4
Using the Motherboard Software
Describes the motherboard software.
Go to ⇒page 44

iii
T
TA
AB BL LE E O OF F C
CO
ON NT TE EN NT TS S
Preface i
CHAPTER 1 1
Introducing the Motherboard 1
Introduction ...................................................................................................1
Features........................................................................................................2
Choosing a Computer Case .........................................................................3
Motherboard Components............................................................................4
CHAPTER 2 6
Installing the Motherboard 6
Safety Precautions .......................................................................................6
Quick Guide..................................................................................................6
Installing the Motherboard in a Case ...........................................................7
Checking Jumper Settings ...........................................................................7
Setting Jumpers...................................................................................................7
Checking Jumper Settings ..................................................................................8
Jumper Settings...................................................................................................8
Connecting Case Components ....................................................................9
Front Panel Connector ......................................................................................11
Installing Hardware.....................................................................................12
Installing the Processor.....................................................................................12
Installing Memory Modules .............................................................................15
Installing a Hard Disk Drive/CD-ROM ...........................................................16
Installing a Floppy Diskette Drive ...................................................................17
Installing Add-on Cards....................................................................................18
Connecting Optional Devices...........................................................................20
Connecting I/O Devices..............................................................................22
CHAPTER 3 23
Using BIOS 23
About the Setup Utility................................................................................23
The Standard Configuration .............................................................................23
Entering the Setup Utility.................................................................................24
Updating the BIOS ...........................................................................................24
Using BIOS .................................................................................................25
Standard CMOS Features .................................................................................26
Advanced BIOS Setup Option .........................................................................28
Advanced Chipset Features Option..................................................................31
Integrated Peripherals Option...........................................................................33
Power Management Setup Option....................................................................36
PNP/PCI Configuration Option........................................................................39
PC Health Status Option...................................................................................40

iv
Frequency/Voltage Control...............................................................................41
Load Fail-Safe Defaults Option .......................................................................42
Load Optimized Defaults Option .....................................................................42
Set Supervisor/User Password..........................................................................42
Save & Exit Setup Option ................................................................................43
Exit Without Saving..........................................................................................43
CHAPTER 4 44
Using the Motherboard Software 44
About the Software CD-ROM.....................................................................44
Auto-installing under Windows 98/ME/2000/XP ........................................44
Running Setup ..................................................................................................45
Manual Installation .....................................................................................47
Utility Software Reference..........................................................................47

1
C
Ch ha ap pt te er r 1 1
Introducing the Motherboard
I
In nt tr ro od du uc ct ti io on n
Congratulations on purchasing this motherboard. This motherboard is a Micro-
ATX motherboard that uses a 4-layer printed circuit board and measures 244
mm x 200 mm. The motherboard is design to support the mPGA Socket 478
Intel P4 Willamette/Northwood/Prescott processors and the new Intel
845GL/845GV chipset.
With system bus speeds up to 533/400 MHz (845GV only), this motherboard
represents the most powerful desktop and cost-effective integrated solution
available today.
The motherboard has an advanced full set of I/O ports, such as dual channel
IDE interfaces, a floppy controller, a high-speed serial port, a VGA port, an
EPP/ECP capable bi-directional parallel port connector, four USB (Universal
Serial Bus) connectors, a PS/2 keyboard connector, mouse connector and
audio jacks for microphone, line-in, line-out. One ADD slot, three PCI local
bus slots and one communication and networking riser (CNR) slot provide
expandability for add-on peripheral cards.
In addition to its excellent performance and stability, the motherboard is highly
suited for Internet and rich multimedia applications, including streaming video
download and are ideal for workstations and high-end home use.

2
F
Fe ea at tu ur re es s
Processor The motherboard uses a micro PGA 478-pin socket that has
the following features:
• Accommodates Intel/P4 Willamette/Northwood/Prescott
478-pins CPU
NB SB FSB
845GL 82801(ICH4)
Supports 400 MHz front side
bus (FSB) with memory speed
of 266 MHz
845GV 82801(ICH4)
Supports 533/400 MHz front
side bus (FSB) with memory
speed of 333/266 MHz
Chipset Intel’s innovative 845GL/845GV (GMCH) and 82801DB (ICH4)
chipsets are based on an innovative and scalable architecture
with proven reliability and performance. A few of the advanced
features of the chipsets are:
• Supports system bus Dynamic Bus Inversion (DBI).
• Supports 266/333 MHz DDR SDRAM devices
• AGTL+ Host Bus with Integrated Termination supporting
32-Bits host addressing.
• Supports 3D / 2D graphic
• Supports up to 2 double-sided DIMM (4 device rows)
• PCI Rev. 2.2, 3.3V (5V Tolerant), 33 MHz interface com-
pliant and PCI to System Memory Data Streaming up to
132 MB/sec
• Upstream Hub Interface for access to the Intel GMCH.
• 2 Channel Ultra ATA/100 Bus Master IDE Controllers
• Supports six USB 2.0 ports for serial transfers at
480Mbits/sec
Additional key features include support for an AC’97 link for audio
and modem, hardware monitoring, and ACPI/OnNow power man-
agement.
Memory The motherboard accommodates two unbuffered 2.5V 184 pin
slots with a total maximum capacity of 2 GB.
AC’ 97 Audio
Codec
The AC’ 97 Audio CODEC is compliant with the AC’97 2.2
specification that meets the PC2001 requirements and sup-
ports S/PDIF Out. It also has a built-in buffer and internal PLL.
Features include support for analog switch for rear-out (share),
the line-in jack (share), center/bass (share), and MIC jack to
output 6 channels audio.
Expansion
Options
The motherboard comes with the following expansion options:
• One ADD slot
• Three 32-bit PCI slots
• A Communications Network Riser (CNR) slot (AC’97
interface only)
• Two IDE connectors which support four IDE channels
• One floppy disk drive interface
• One Onboard LAN (optional) chip and LAN port on top of
the USB port

3
The motherboard supports Ultra DMA bus mastering with
transfer rates of 100/66/33 MB/sec.
Integrated I/O The motherboard has a full set of I/O ports and connectors:
• Two PS/2 ports for mouse and keyboard
• One serial port
• One VGA port
• One parallel port
• Four USB ports
• One LAN port
Audio jacks for microphone, line-in and line-out
Onboard LAN
(optional)
The onboard LAN chipset is incorporated in the chipset provid-
ing the motherboard with integrated Fast Ethernet controller
capabilities and 10/100 mega bit per second (Mbps) Physical
Layer Transceivers for the PCI local bus.
BIOS
Firmware
This motherboard uses Award BIOS that enables users to
configure many system features including the following:
• Power management
• Wake-up alarms
• CPU parameters and memory timing
• CPU and memory timing
The firmware can also be used to set parameters for different
processor clock speeds.
Some hardware specifications and software items are subject to change
without prior notice.
C
Ch ho oo os si in ng g a a C Co om mp pu ut te er r C Ca as se e
There are many types of computer cases on the market. The motherboard
complies with the specifications for the Micro-ATX system case. Some fea-
tures on the motherboard are implemented by cabling connectors on the
motherboard to indicators and switches on the system case. Ensure that your
case supports all the features required. The motherboard can support one or
two floppy diskette drives and four enhanced IDE drives. Ensure that your
case has sufficient power and space for all the drives that you intend to install.
Most cases have a choice of I/O templates in the rear panel. Make sure that
the I/O template in the case matches the I/O ports installed on the rear edge
of the motherboard.
This motherboard has a Micro-ATX form factor of 244 mm x 200 mm. Choose
a case that accommodates this form factor.

4
M
Mo ot th he er rb bo oa ar rd d C Co om mp po on ne en nt ts s

5
Table of Motherboard Components
Label Component
AGP1 ADD slot
ATX1 Standard 20-pin ATX power connector
ATX12V Power connector
AUDIO1 Front panel MIC/Speaker Out header
AUXIN1 Auxilliary In header
CDIN1 Primary CD-in connector
CNR1 Communications and Networking Riser slot
CASFAN1 Case fan connector
CPUFAN1 Cooling fan for CPU
CPU Socket CPU socket (mPGA478)
DIMM1 ~ DIMM2 Two 184-pin DDR sockets
FDD1 Floppy disk drive connector
IDE1 Primary IDE channel
IDE2 Secondary IDE channel
JP1 Clear CMOS jumper
JP3 BIOS flash protect jumper
PANEL1 Panel connector for case switches and LEDs
PCI1 ~ PCI3 Three 32-bit add-on card slots
SPDIF SPDIF out header
SPEAKER1 Speaker header
USB2 Connector for front panel USB ports
This concludes Chapter 1. The next chapter explains how to install the moth-
erboard.

6
C
Ch ha ap pt te er r 2 2
Installing the Motherboard
S
Sa af fe et ty y P Pr re ec ca au ut ti io on ns s
Follow these safety precautions when installing the motherboard:
• Wear a grounding strap attached to a grounded device to avoid
damage from static electricity.
• Discharge static electricity by touching the metal case of a safely
grounded object before working on the motherboard.
• Leave components in the static-proof bags they came in.
• Hold all circuit boards by the edges. Do not bend circuit boards.
Q
Qu ui ic ck k G Gu ui id de e
This Quick Guide suggests the steps you can take to assemble your system
with the motherboards.
The following table provides a reference for installing specific components:
Locating Motherboard Components Go to page 4
Installing the Motherboard in a Case Go to page 7
Setting Jumpers Go to page 7
Installing Case Components Go to page 9
Installing the Processor Go to page 12
Installing Memory Go to page 15
Installing an HDD and CD-ROM Drive Go to page 16
Installing an FDD Go to page 17
Installing Add-on Cards Go to page 18
Connecting Options Go to page 20
Connecting Peripheral (I/O) Devices Go to page 22

7
I
In ns st ta al ll li in ng g t th he e M Mo ot th he er rb bo oa ar rd d i in n a a C Ca as se e
Refer to the following illustration and instructions for installing the mother-
board in a case:
This illustration shows an ex-
ample of a motherboard being
installed in a tower-type case:
Note: Do not overtighten
the screws as this
can stress the moth-
erboard.
Most system cases have
mounting brackets installed in
the case, which correspond to
the holes in the motherboard.
Place the motherboard over
the mounting brackets and
secure the motherboard onto
the mounting brackets with
screws.
Ensure that your case has an I/O template that supports the I/O ports and
expansion slots on your motherboard.
C
Ch he ec ck ki in ng g J Ju um mp pe er r S Se et tt ti in ng gs s
This section explains how to set jumpers for correct configuration of the moth-
erboard.
Setting Jumpers
Use the motherboard jumpers to set system configuration options. Jumpers
with more than one pin are numbered. When setting the jumpers, ensure that
the jumper caps are placed on the correct pins.
The illustrations below show a 2-pin jumper.
When the jumper cap is placed on both pins,
the jumper is SHORT. If you remove the
jumper cap, or place the jumper cap on just
one pin, the jumper is OPEN.
This illustration shows a 3-pin
jumper. Pins 1 and 2 are SHORT.
Short Open
123

8
Checking Jumper Settings
The following illustration shows the location of the motherboard jumpers. Pin 1
is labeled.
Jumper Settings
Jumper Type Description Setting
JP1 3-pin Clear CMOS
1-2: Normal
2-3: Clear CMOS
Before clearing the
CMOS, make sure to
turn off the system
JP1
1
JP3 2-pin
BIOS Write
Protect
Open: Write Enable
Short: Write Disable
JP3

9
C
Co on nn ne ec ct ti in ng g C Ca as se e C Co om mp po on ne en nt ts s
After you have installed the motherboard into a case, you can begin connect-
ing the motherboard components. Refer to the following:
1. Connect the CPU cool-
ing fan cable to
CPUFAN1.
2. Connect the case cool-
ing fan connector to
CASFAN1.
3. Connect the case
speaker cable to
SPEAKER1.
4. Connect the case
switches and indicator to
PANEL1.
5. Connect the standard
power supply connector
to ATX11.
6. Connect the Pentium 4
processor auxiliary case
power supply connector
to ATX12V1.
Note: When the system is heavily loaded,
you should install, at a minimum, an
ATX12V power supply with a 300W
capacity.
CPUFAN1/CASFAN1: FAN Power Connectors
Pin Signal Name Function
1 GND System Ground
2 +12V Power +12V
3 Sense Sensor
1You can either use the 5V or 12V ATX power; the mainboard can work properly on both power supplies.

10
SPEAKER1: Internal speaker
Pin Signal Name
1 Signal
2 Buzzer
3 NC
4 VCC
ATX1: ATX 20-pin Power Connector
Pin Signal Name Pin Signal Name
1 +3.3V 11 +3.3V
2 +3.3V 12 -12V
3 Ground 13 Ground
4 +5V 14 PS ON#
5 Ground 15 Ground
6 +5V 16 Ground
7 Ground 17 Ground
8 PWRGD 18 -5V
9 +5VSB 19 +5V
10 +12V 20 +5V
ATX12: ATX 12V Power Connector
Pin Signal Name
1 Ground
2 Ground
3 +12V
4 +12V

11
Front Panel Connector
The front panel connector (PANEL1) provides a standard set of switch and
LED connectors commonly found on ATX or micro-ATX cases. Refer to the
table below for information:
Pin Function Pin Function
1 Hard disk LED
(positive) 2 MSG LED [dual color or single color (+)]
3 Hard disk active LED
(negative) 4 MSG LED [dual color or single color (-)]
5 Reset Switch 6 Power Switch
7 Reset Switch 8 Power Switch
9 Reserved 10 No pin
Hard Drive Activity LED
Connecting pins 1 and 3 to a front panel mounted LED provides visual indica-
tion that data is being read from or written to the hard drive. For the LED to
function properly, an IDE drive should be connected to the onboard IDE inter-
face. The LED will also show activity for devices connected to the SCSI (hard
drive activity LED) connector.
Power / Sleep / Message Waiting LED
Connecting pins 2 and 4 to a single- or dual-color, front panel mounted LED
provides power on/off, sleep, and message waiting indication.
Reset Switch
Supporting the reset function requires connecting pins 5 and 7 to a momen-
tary-contact switch that is normally open. When the switch is closed, the board
resets and runs POST.
Power Switch
Supporting the power on/off function requires connecting pins 6 and 8 to a
momentary-contact switch that is normally open. The switch should maintain
contact for at least 50 ms to signal the power supply to switch on or off. The
time requirement is due to internal debounce circuitry. After receiving a power
on/off signal, at least two seconds elapses before the power supply recog-
nizes another on/off signal.

12
I
In ns st ta al ll li in ng g H Ha ar rd dw wa ar re e
Installing the Processor
Caution: When installing a CPU heatsink and cooling fan make sure that
you DO NOT scratch the motherboard or any of the surface-mount resis-
tors with the clip of the cooling fan. If the clip of the cooling fan scrapes
across the motherboard, you may cause serious damage to the mother-
board or its components.
On most motherboards, there are small surface-mount resistors near the
processor socket, which may be damaged if the cooling fan is carelessly
installed.
Avoid using cooling fans with sharp edges on the fan casing and the
clips. Also, install the cooling fan in a well-lit work area so that you can
clearly see the motherboard and processor socket.
Before installing the Processor
This motherboard automatically determines the CPU clock frequency and
system bus frequency for the processor. You may be able to change these
settings by making changes to jumpers on the motherboard, or changing the
settings in the system Setup Utility. We strongly recommend that you do not
overclock processors or other components to run faster than their rated
speed.
Warning: Overclocking components can adversely affect the reliability of
the system and introduce errors into your system. Overclocking can per-
manently damage the motherboard by generating excess heat in
components that are run beyond the rated limits.
This motherboard has an mPGA478 socket. When choosing a processor,
consider the performance requirements of the system. Performance is based
on the processor design, the clock speed and system bus frequency of the
processor, and the quantity of internal cache memory and external cache
memory.

13
CPU Installation Procedure
The following illustration shows CPU installation components:
Note: The pin-1 corner is marked with an arrow
Follow these instructions to install the Retention Module and CPU:
1. Install your CPU. Pull up
the lever away from the
socket and lift up to 90-
degree angle.
2. Locate the CPU cut
edge (the corner with the
pinhole noticeably miss-
ing). Align and insert the
CPU correctly.

14
3. Press the lever down.
4. Apply thermal grease on top of the CPU.
5. Put the CPU Fan down
on the retention module
and snap the four reten-
tion legs of the cooling
fan into place.
6. Flip the levers over to lock the heat sink in place.
7. Connect the CPU Cool-
ing Fan power cable to
the CPUFAN1 connec-
tor. This completes the
installation.
Notes: To achieve better airflow rates and heat dissipation, we suggest that you
use a high quality fan with 4800 rpm at least.
CPU fan and heatsink installation procedures may vary with the type of CPU
fan/heatsink supplied. The form and size of fan/heatsink may also vary.

15
Installing Memory Modules
This motherboard accommodates two 184-pin 2.5V unbuffered Double Data
Rate (DDR) SDRAM memory modules. The memory chips must be standard
or registered SDRAM (Synchronous Dynamic Random Access Memory).
When you installed DDR333 memory modules, the memory bus can run up to
166 MHz. If you have DDR266, this can operate over a 133 MHz. For
DDR200, it can only run up to 100 MHz.
You must install at least one module in any of the two slots. Each module can
be installed with 32 MB to 1 GB of memory; total memory capacity is 2 GB.
Do not remove any memory module from its antistatic packaging until
you are ready to install it on the motherboard. Handle the modules only
by their edges. Do not touch the components or metal parts. Always
wear a grounding strap when you handle the modules.
Installation Procedure
Refer to the following to install the memory modules.
1. This motherboard supports unbuffered DDR SDRAM only. Do not attempt
to insert any other type of DDR SDRAM into the slots.
2. Push the latches on each side of the DIMM slot down.
3. Align the memory module with
the slot. The DIMM slots are
keyed with notches and the
DIMMs are keyed with cutouts
so that they can only be in-
stalled correctly.
4. Check that the cutouts on the
DIMM module edge connector
match the notches in the
DIMM slot.
5. Install the DIMM module into
the slot and press it firmly
down until it seats correctly.
The slot latches are levered
upwards and latch on to the
edges of the DIMM.
6. Install any remaining DIMM modules.

16
Installing a Hard Disk Drive/CD-ROM
This section describes how to install IDE devices such as a hard disk drive
and a CD-ROM drive.
Your motherboard has a primary and secondary IDE channel interface (IDE1 and
IDE2). An IDE ribbon cable supporting two IDE devices is bundled with the moth-
erboard.
If you want to install more than two IDE devices, get a second IDE cable and
you can add two more devices to the secondary IDE channel.
You must orient the cable connector so that the pin 1 (color) edge of the
cable corresponds to the pin 1 of the I/O port connector.
IDE1: Primary IDE Connector
The first hard drive should always be connected to IDE1.
IDE2: Secondary IDE
The second drive on this controller must be set to slave mode. The configura-
tion is the same as IDE1.
