MFL G440BSW User manual

1
PROFESIONAL SHOW LIGHTING
USER MANUAL

2
***Please carefully read this user manual in its entirety and keep it safe for
future reference. It is essential to know the information and comply with the
instructions given in this manual to ensure the fitting is installed, used and
serviced or correctly and safely.
一：First, check the package:
Because the light in the purchase process must carry through the
process of long-distance transportation. To ensure that you receive the
light, please when receiving goods , please check the accessories of
light.
二、Lighting packaging accessories
Power cable *1
Signal cable *1
manual *1
Certificate *1（On the light）
SAFETY INFORMATION
• Minimum distance from flammable materials
The projector must be positioned so that any flammable materials are at least
0.20 meters (8") from every point on the surface of the fitting.
• Mounting surfaces
It is impermissible to mount the fitting on normally flammable surfaces.
• Protection against electrical shock
Connection must be made to a power supply system fitted with efficient
earthing (class I appliance according to standard EN 60598-1). It is, moreover,
recommended to protect the supply lines of the projectors from indirect contact
and/or shorting to earth by using appropriately sized residual current devices.
• Connection to mains supply
Connection to the electricity mains must be carried out by a qualified
electrical installer.
Check that the mains frequency and voltage correspond to those for which the
projector is designed as given on the electrical data label.

3
This label also gives the input power to which you need to refer to evaluate the
maximum number of fittings to connect to the electricity line, in order to avoid
overloading.
• Temperature of the external surface
The maximum temperature that can be reached on the external surface of the
fitting, in a thermally steady state, is 100°C (212°F).
• Maintenance
Before starting any maintenance work or cleaning the projector, cut off power
from the main supply.
After switching off, do not remove any parts of the fitting, to avoid getting burnt
for at least 35minutes. After this time the likelihood of the lamp exploding is
virtually nill.
The fitting is designed to hold in any splinters produced by a lamp
exploding.The lenses must be mounted and, if visibly damaged, they have to
be replaced with genuine spares.
MECHANICAL DETAILS
Specification
Manufacturer：Mingzhi
Brand：MFL.
Model：G440BSW
Input：100-240V 50HZ-60HZ
Power：700W
Light source：Yodn 380W Yodn 440W，OSRAM470W
Working lifetime：average lifetime 1500 hours
Color temperature：7800K
Total Output (Lumen)：23600LM
Control mode：DMX512,RDM，Sound，Auto，Master-slave
LCD display：LCD color touch display + button
DMX Channel：27/31 CH
XY: X540°Y270°16BIT Precise control +Fast and quiet 3-phase motors
＋stable and quiet
Dimmer：0-100% ,16-bit, mechanical dimming
Strobe：0.5-20 Hz ,synchronized, pulse effects
Beam angle：2.5°beam mode
Spot angle：3°-62°spot mode
Effect wheel：rainbow effect＋frost
CMY/CTO：CMY color mixing system，2 CTO（3200K and 2500K）
Focus: motorized focus

4
Prism：8 + 16-facet prism, CW/CCW rotation（Standard，customized is
availbale)Auto focusing when zooming
Color wheel：13 colors + open
Fixed gobo wheel：14 gobos + open（Gobo customized is available）
Rotating wheel：7 interchangeable gobos + open（Gobo customized is
available）
Animation wheel：3 animation wheel＋open (can make special dynamic
flame or water effect)
Electronic system: Switch the light bulb through the console，Electronic
automatic monitoring of reset failure，Detection of Fan Speed
Energy saving mode：When the light is closed, the power decreases
automatically.
Suitable：stage、perform，event ，culb，show etc.
DMX data input/output: Chassis 3-pin and 5-pin Neutrik XLR (in/out)
AC power: powerCon in and out.
Cooling cystem：High Speed Mute Fan with Multiple Flame Retardant
Rollers
Appearance: Superalloy Resistant Plastics
IP：IP20
N.W.：23KG
Product size：380*300*710MM
Display Description
MainMenu
Second Menu
Third Menu
Forth Menu
Settings
Dmx Address
1 - 512
Fixture Set
Dmx Mode
STD / EXT
Run Mode
DMX / Host
Pan Inverse
Close / Open
Tilt Inverse
Close / Open
Lamp Open
Close / Open
Display
Language
CH / EN
Display Flip
Close / Open
Display Mode
Show / 60s
Reset
Reset
Cance / Run
Factory
Cance / Run
Info
Time
Current Time
xxxH
Show Time
xxxH
Power Count
xxx
Sensor
xxxxxx
Software Version
Panel
Vx.xxx
Motor_XY
Vx.xxx

5
Motor
Vx.xxx
Manual
Pan
0 - 255
PanFine
0 - 255
Tilt
0 - 255
TiltFine
0 - 255
.
.
.
.
.
.
Factory
Password
0 - 255
Pan
0 - 255
Tilt
0 - 255
Dim
0 - 255
Cyan
0 - 255
Magenta
0 - 255
Yellow
0 - 255
Color
0 - 255
FixGobo
0 - 255
Effect
0 - 255
Rot Gobo
0 - 255
Gobo Rot
0 - 255
Color7
0 - 255
Frost
0 - 255
PrismZoo
0 - 255
Prism1
0 - 255
Prism1Ro
0 - 255
Prism2
0 - 255
Prism2Ro
0 - 255
Focus
0 - 255
Zoom
0 - 255
Channel Description
Standard
mode
Simple
mode
DMX
Value
Function
1
1
0-255
Pan
2
2
0-255
Pan Low
3
3
0-255
Tilt
4
4
0
-255
Tilt Low

6
5
5
0
-255
P/T Speed
6
6
Function
50－99
Reset
100－
149
Lamp Off
150－
199
Lamp On
7
7
Shutter
0-3
Closed
4-103
SLOW STROBE -> FAST
STROBE
104-10
7
Open
108-20
7
SLOW STROBE -> FAST
STROBE
208-21
2
Open
213-25
1
RANDOM STROBE SLOW
-> FAST
252-25
5
Open
8
8
Dimmer
0－255
Linear Dimmer
9
9
0-255
CMY open
10
10
0－255
CMY-C
11
11
0－255
CMY-M
12
12
0－255
CMY-Y
13
13
0－127
reserve
128－
255
CTO
14
14
0-255
CMY color Mixed
Macro Colour
0-4
white
5-9
Colour 1
10-14
Colour 2
15-19
Colour 3
20-24
Colour 4
25-29
Colour 5
30-34
Colour 6
35-39
Colour 7
40-44
Colour 8
45-49
Colour 9

7
15
15
50-54
Colour 10
55-59
Colour 11
60-64
Colour 12
65-69
Colour 13
70-74
Colour 14
75-79
Colour 15
80-84
Colour 16
85-89
Colour 17
90-94
Colour 18
95-99
Colour 19
100-10
4
Colour 20
105-10
9
Colour 21
110-11
4
Colour 22
115-11
9
Colour 23
120-12
4
Colour 24
125-12
9
Colour 25
130-13
4
Colour 26
135-13
9
Colour 27
140-19
4
FAST ROTATION - SLOW
ROTATION
195-20
0
STOP
201-25
5
SLOW ROTATION - FAST
ROTATION
16
/
0-255
Color Fine--Linear
Static Gobo
0-3
white
4-9
Gobo 1
10-15
Gobo 2
16-21
Gobo 3
22-27
Gobo 4
28-33
Gobo 5
34-39
Gobo 6
40-45
Gobo 7
46-51
Gobo 8

8
17
16
52-57
Gobo 9
58-63
Gobo 10
64-69
Gobo 11
70-75
Gobo 12
76-81
Gobo 13
82-87
Gobo 14
88-95
Gobo 1 Jitter
96-103
Gobo 2 Jitter
104-11
1
Gobo 3 Jitter
112-11
9
Gobo 4 Jitter
120-12
7
Gobo 5 Jitter
128-13
5
Gobo 6 Jitter
136-14
3
Gobo 7 Jitter
144-15
1
Gobo 8 Jitter
152-15
9
Gobo 9 Jitter
160-16
7
Gobo 10 Jitter
168-17
5
Gobo 11 Jitter
176-18
3
Gobo 12 Jitter
184-19
1
Gobo 13 Jitter
192-20
1
white
202-22
7
FAST ROTATION - SLOW
ROTATION
228-22
9
STOP
230-25
5
SLOW ROTATION - FAST
ROTATION
Animation Gobo
0-4
white
5-9
white
10-39
Gobo1
40-69
Gobo2

9
18
17
70-99
Gobo3
100-12
9
FAST ROTATION - SLOW
ROTATION
130-13
5
STOP
136-16
5
SLOW ROTATION - FAST
ROTATION
166-19
5
Gobo 1 Jitter
196-22
5
Gobo 2 Jitter
226-25
5
Gobo 3 Jitter
19
18
Rotation Gobo
0-9
white
10-19
Gobo 1
20-29
Gobo 2
30-39
Gobo 3
40-49
Gobo 4
50-59
Gobo 5
60-69
Gobo 6
70-79
Gobo 7
80-94
Gobo 1 Jitter
95-109
Gobo 2 Jitter
110-12
4
Gobo 3 Jitter
125-13
9
Gobo 4 Jitter
140-15
4
Gobo 5 Jitter
155-16
9
Gobo 6 Jitter
170-18
4
Gobo 7 Jitter
185-18
9
white
190-22
2
FAST ROTATION - SLOW
ROTATION
223-25
5
SLOW ROTATION - FAST
ROTATION
20
19
Rotation Gobo Rot
0－127
Rotation
128－
FAST ROTATION - SLOW

10
190
ROTATION
191－
192
STOP
193－
255
SLOW ROTATION - FAST
ROTATION
21
/
0-255
Gobo Rotation Fine Linear
22
20
Color7/Frost
0－127
White
128－
191
Frost
192－
255
Color7
23
21
0-255
Prism-zoom
24
22
Prism1
0－127
Reserve
128-25
5
Prism1
25
23
Prism-1 Rot
0－127
Rotation
128－
190
FAST ROTATION - SLOW
ROTATION
191－
192
STOP
193－
255
SLOW ROTATION - FAST
ROTATION
26
24
Prism2
0-127
Reserve
128-25
5
prism2
27
25
Prism-2 Rot
0－127
Rotation
128－
190
FAST ROTATION - SLOW
ROTATION
191－
192
STOP
193－
255
SLOW ROTATION - FAST
ROTATION
28
26
Foucs
0-255
Linear
29
/
0-255
Foucs Fine Linear
30
27
Zoom
0-255
Linear
31
/
0-255
Zoom Fine Linear

11
CLEANING AND MAINTENANCES
In order to ensure the fixture could work normally, it should be kept clean
always. It is recommended that the fans and ventilation inlet should be cleaned
every 15 days. The lens should be regularly cleaned and maintain an optimum
light output.
