MicaSense RedEdge-M Quick setup guide
RedEdge-M/MX™
OEM Dual Camera Kit
INTEGRATION GUIDE
Note: This kit is intended as an aid for custom integrations. It provides power,
communication, and ensures that the cameras are properly spaced for accurate data
collection. It does NOT provide a solution to attach the mount to the drone itself nor does it
provide a DLS2 mounting solution.
Rev 01 - March 2020 P/N: 900-00020
Table of Contents
Thank you for your purchase! 2
What’s needed for the integration? 3
What’s Required? 4
Let’s get started! 4
Custom mounting DLS 2 guidelines 5
Attaching the RedEdge-M/MX, RedEdge-MX Blue and the OEM Dual Camera Mount 6
Attaching the Dual Camera Kit and DLS 2 to the drone 8
Support 9
Rev 01 - March 2020
PAGE 1
Thank you for your purchase!
These instructions show how to use the OEM Dual Camera Kit to help integrate MicaSense
RedEdge-M, RedEdge-MX and RedEdge-MX Blue on non-DJI drones or unique integrations. It
covers attaching mounting brackets included in the kit and guidelines for custom integrating
the DLS2.
NOTE: This kit does NOT provide a means of attaching the OEM Dual Camera Kit to
the drone. This kit is intended to provide power, communication, and to ensure that
the cameras are properly spaced for accurate data collection.
Warning: This kit is not intended for any other RedEdge models other than the
RedEdge-M/MX. Damage will occur if any other RedEdge model is connected.
Both the RedEdge-M/MX and RedEdge-MX Blue need to be updated to the latest
firmware. The system will not operate if the firmware versions do not match. You can
find the latest firmware at: https://www.micasense.com/firmware-updates
Rev 01 - March 2020
PAGE 2
What’s needed for the integration?
1. OEM Dual Camera Mount (Qty 1)
2. 6-pin 60cm cable (Qty 2)
3. Dual Camera System Cable (Qty 2)
4. 2-prong mount (Qty 1)
5. Circuit Board w/ heat shrink (Qty 1)
6. VHB tape (Qty 3)
7. M3 X 10mm black-oxide Screws
(Qty 6)
8. M2 X 8mm Screws (Qty 2)
9. M3 Lock Washers (Qty 6)
10. Hex Key 2.5mm (Qty 1)
11. Loctite threadlocker (Qty 1)
12. Zip Ties (Qty 6)
13. 2-pin DF-13 power cable (Qty 1)
14. Alcohol Wipe (Qty 1)
Images shown are not to scale
Notes: Kit content may differ as hardware may already be installed.
Dual camera configuration requires the use of a DLS 2; a RedEdge-M can be used, but
an upgrade to the DLS 2 is required for software compatibility and support.
Rev 01 - March 2020
PAGE 3
What’s Required?
●#1 Phillips Screwdriver
●Cutting tool - such as scissors or diagonal cutter
●1.5 mm hex wrench
●2 mm hex wrench
●2.5 mm hex wrench
Notes: Tools included in your kit may vary depending on the drone model selected when kit
was purchased.
Let’s get started!
Warning: Installation of this kit into a drone should be done by an experienced person, in
adherence with all recommendations and guidelines of the drone manufacturer. Before
assembling this kit, ensure the drone is not powered, has the battery removed, and the
rotor blades removed. Failure to follow these instructions can result in injury, death
and/or damage to the drone, or RedEdge-M/MX/MX Blue sensors.
MicaSense recommends checking all fasteners periodically and tightening as needed.
Both the RedEdge-MX and RedEdge-MX Blue need to be updated to the latest firmware.
The system will not operate if the firmware versions do not match. You can find the latest
firmware available at https://www.micasense.com/firmware-updates
Rev 01 - March 2020
PAGE 4
Custom mounting DLS 2 guidelines
The OEM Dual Camera Kit does not come with a DLS2 mounting solution, however the general
DLS2 mounting guidelines should be followed when integrating the DLS2 sensor. These
guidelines can be found in the DLS2 Integration Guide on the MicaSense Knowledge Base.
The DLS 2 should always be the highest object on the aircraft in order to avoid shadows or
reflections. It contains an integrated GPS receiver that may be utilized for geotagging of the
MicaSense sensor imagery if system GPS signals are not provided to the sensor by other
means. Install the module where it will have a clear view of the sky, far away from any devices
that could cause interference (such as a data link or video transmitters).
When the DLS 2 starts up, the sensor attempts to calibrate which requires it to be still and
motionless. Ensure that there is no vibration or movement until the DLS 2 has completed this
procedure, indicated by normal LED status lights (shown in the User Guide).
Rev 01 - March 2020
PAGE 5
Attaching the RedEdge-M/MX, RedEdge-MX
Blue and the OEM Dual Camera Mount
Note: Dual configuration requires the use of a DLS 2; a RedEdge-M can be used, but an
upgrade to the DLS 2 is required for software compatibility and support.
1. Locate the M3 x 10 mm black-oxide screws, M3 lock washers, and OEM Dual Camera
Mount.
2. Using the screw holes, attach the mount to the back of both the RedEdge-MX and the
RedEdge-MX Blue. Add a drop of loctite to the threads of the screws. The order of the
components is:
Black-oxide screw → Lock Washer → Dual Cam Mount → Camera
3. The RedEdge-MX (Red camera) should be in the front of the dual camera mount when
the system is properly installed. Also, only one WIFI dongle should be installed in the
Red camera and not in the Blue camera. The extra WIFI dongle should only be used for
advanced configurations.
Rev 01 - March 2020
PAGE 6
4. Connect the provided Dual Camera harness to the “PWR/TRG” and “DLS” ports on
both cameras. The RedEdge-M/MX (Red camera) should be the Main camera in the
configuration. Connect the Main cables and connectors to the RedEdge-MX and the
Auxiliary cables and connectors to the RedEdge-MX Blue camera.
Connection between OEM Dual Camera Kit Mount, RedEdge-M/MX and RedEdge-MX
Blue
5. Connect the 8-pin JST connector on the Dual Camera cable to the 8-pin JST connector
on the circuit board.
6. Connect the 2-pin DF-13 cable to the circuit board. Use this cable to power the Dual
Camera Kit by attaching to a power source. RedEdge-MX requires 5.0 volts DC for
operation, with a maximum operating voltage of 15.8V. The supply must be able to
provide 10W (2A@5V) peak. RedEdge-MX powering guidelines are outlined in the
“How do I power the RedEdge-M/MX” article.
Circuit board diagram and pinout for power
Rev 01 - March 2020
PAGE 7
7. Double-sided VHB tape is included in the kit as an option to help secure the circuit
board in place on a custom integration.
Attaching the Dual Camera Kit and DLS 2 to the drone
This kit is intended as an aid for custom integrations. It provides power, communication, and
ensures that the cameras are properly spaced for accurate data collection. It does NOT
provide a solution to attach the mount to the drone itself nor does it provide a DLS2 mounting
solution.
1. As noted above, this kit provides a mount to hold both RedEdge-M/MX and
RedEdge-MX Blue cameras and to allow communication between all components, but
the means for attaching the mount to the drone is up to the customer. Included in the
kit is a 2-prong Go-Pro mount adapter, if you are looking to integrate with a Go-Pro
mount.
2. Use the provided 6-pin 60cm cable to connect the DLS2 and the camera sensors. Plug
the DLS 2 cable from the DLS 2 port to the 6-pin JST port on the circuit board.
3. When attached, the cameras should be tilted forward slightly to compensate for the tilt
of the aircraft while flying.
Warning: Failure to properly secure loose wires may lead to interference with the
aircraft propellers. This may damage the drone, RedEdge-MX/Altum, or both.
Rev 01 - March 2020
PAGE 8
Support
For other RedEdge-MX or Altum associated integration guides, please visit
our Knowledge Base at support.micasense.com
For additional questions, please contact [email protected]
MicaSense RedEdge-M/MX & RedEdge-MX Blue OEM Dual Camera Integration Instructions.
The contents of this manual are subject to change without notice.
MicaSense, Inc. assumes no liability for incidental or consequential damages arising from the
use of this product, and any claims by a third party.
Copying of the contents of this manual, in whole or in part, as well as the scanner applications
is prohibited under the copyright law.
DISCLAIMER OF WARRANTIES AND LIMITATION OF LIABILITY
MICASENSE MAKES NO REPRESENTATION OR WARRANTY, EXPRESS OR IMPLIED, WITH
RESPECT TO MICASENSE ACCESSORIES. MICASENSE DISCLAIMS ANY LIABILITY FOR
INDIRECT, CONSEQUENTIAL, PUNITIVE, OR SPECIAL DAMAGES, INCLUDING WITHOUT
LIMITATION DAMAGES FOR LOST DATA, LOST REVENUE, LOST PROFITS, OR
REPLACEMENT PRODUCT COSTS ARISING OUT OF THE PURCHASE, USE, OR
PERFORMANCE OF THE MICASENSE ACCESSORIES, UNDER ANY THEORY OF LIABILITY,
EVEN IF MICASENSE HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
MICASENSE DISCLAIMS ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE, AND DISCLAIMS ANY IMPLIED WARRANTY ARISING FROM A
COURSE OF PERFORMANCE, DEALING, USAGE, OR TRADE PRACTICE. THE PRICE OF
PRODUCTS DISTRIBUTED BY MICASENSE OR ITS AUTHORIZED DEALERS REFLECTS THE
ALLOCATION OF RISK ARISING FROM THE WARRANTY EXCLUSIONS AND THIS
DISCLAIMER AND LIMITATION OF LIABILITY.
Rev 01 - March 2020
PAGE 9
It’s simple to plan a successful mission
FLY
The MicaSense sensors low weight, low power requirements, and ability to
capture RGB and narrowband spectral bands simultaneously means you can
gather the data you need in fewer flights. Have multiple UAVs? MicaSense
sensors quickly integrate with many different drone platforms.
PROCESS
With MicaSense sensors, you own your data. You’re not limited to a particular
processing platform. You can choose whichever platform is best for you, your
customer, or your project.
ANYWHERE
We know you need tools you can rely on. That’s why we built the sensors we
wanted in the field—predictable, tough, and reliable—so you can gather the data
you need when you need it.
ANALYZE
RedEdge-MX and RedEdge-MX Blue have 10 distinct bands that our research
showed were optimal for sensing. It simply shows you more. And with analytics
applications you can see many different analytical layers and compare these
outputs across time.
Rev 01 - March 2020
PAGE 10
SIGN UP
Visit atlas.micasense.com to create your free MicaSense Atlas
account.
DOWNLOAD
Download MicaSense Sensor user manuals, integration guides
and support resources via your Atlas account.
CONTACT
[email protected] US-based MicaSense support is here
to help.
Located in Seattle, Washington, MicaSense delivers integrated solutions for data gathering,
processing, and analytics across the global agriculture market. With decades of expertise in
widely varied UAV applications, the MicaSense team is redefining remote sensing technology
and pioneering new ways to collect and analyze information.
RedEdge-M/MX & RedEdge-MX Blue OEM Dual Camera Integration Guide Rev 01 – March
2020
P/N: 900-00020
Rev 01 - March 2020
PAGE 11
Revision History
Revision
Description
Date
01
Initial Release
19 March 2020
Rev 01 - March 2020
PAGE 12
