Microedge Instruments DSP-1 User manual

©2010-2021 Microedge Instruments Inc. Rev 1.0
Quick Start
for Site USB Device Server Pro
DSP-1

1
Please refer to the instructions of SiteView, SiteView-Web and Pluto for basic
communication with a USB Device Server.
1. Unbox DSP-1
DSP-1 comes with an USB cable. Please:
Connect DSP-1 to a 5VDC power supply
via the enclosed USB cable.
Connect DSP-1 to your local network
with an Ethernet cable.
Connect data loggers to the USB ports of
DSP-1.
Wait for TWO minutes. This will allow
the system to recognize the plugged data logger(s).
2. Find DSP-1 and Create Connection from SiteView
Launch SiteView software in PC side and click “USB Server” tab:
Click “Search” button:
In the pop-up dialog click “OK” button to continue.

2
SiteView will search for Site USB
Device Servers under the same
network and the found ones will be
added to the list automatically.
3. Communicate with Remote Data Logger
Double click the new created
connection; the data logger icon
will be listed under it:
Double click the logger icon to
show the status. Now you can
download data, view real-time readings and more…
If the above method can’t find the Device Server, you can click Others -> Find Device in
LAN button to find the IP address of the Device Server based on its MAC address which
is printed on the board.
4. Change Access Settings from Admin Portal
In the above steps, we assume DSP-1’s settings are: Port: 5678, Password: 12345.
You can change these default settings from the admin’s portal web page by entering the
admin’s address in the address box of a web browser:
http://[IP Address of the DSP-1]:8864
Enter ‘admin’for both the Username and
the Password.
Scroll down to ‘USB Device Server
Properties’panel and change any of the
below settings.

3
If you have changed the above settings for a DSP-1 and you want to communicate with
it from SiteView, SiteView-Web or Pluto, you must use the same settings when you
create a connection for it.
