User Manual
MD-RT468WEDMX02
MD-RT468WEDMX06

1

2

1.5 Warnings for placement
1 4 Warnings for using.
3
Do not arbitrarily disassemble or reconstruct the refrigerator, nor
damage the refrigerant circuit; maintenance of the appliance must
be conducted by a specialist
Damaged power cord must be replaced by the manufacturer, its
maintenance department or related professionals in order to avoid
danger.
The gaps between refrigerator doors and between doors and
refrigerator body are small, be noted not to put your hand in these
areas to prevent from squeezing the finger. Please be gentle when
close the refrigerator door to avoid falling articles.
Do not pick foods or containers with wet hands in the freezing
chamber when the refrigerator is running, especially metal
containers in order to avoid frostbite.
Do not allow any child to get into or climb the refrigerator; otherwise
suffocation or falling injury of the child may be caused.
Do not place heavy objects on the top of the refrigerator considering
that objects may fall when close or open the door, and accidental
injuries might be caused.
Please pull out the plug in case of power failure or cleaning. Do not
connect the refrigerator to power supply within five minutes to
prevent damages to the compressor due to successive starts.
Do not put flammable, explosive, volatile and highly corrosive items
in the refrigerator to prevent damages to the product or fire
accidents.
Do not place flammable items near the refrigerator to avoid fires.
The refrigerator is intended for household use, such as storage of
foods; it shall not be used for other purposes, such as storage of
blood, drugs or biological products, etc.

1.6 Warnings for energy
Freezing chamber
1.7 Warnings for disposal
4
Do not store beer, beverage or other fluid contained in bottles or
enclosed containers in the freezing chamber of the refrigerator; or
otherwise the bottles or enclosed containers may crack due to
freezing to cause damages.
Warning for energy
1)Refrigerating appliances might not operate consistently (possibility of defrosting of contents or
temperature becoming too warm in the frozen food compartment) when sited for an extended period
of time below the cold end of the range of temperatures for which the refrigerating appliance is
designed.
2)The fact that effervescent drinks should not be stored in food freezer compartments or cabinets or
in low-temperature compartments or cabinets, and that some products such as water ices should not
be consumed too cold;
3)The need to not exceed the storage time(s) recommended by the food manufacturers for any kind
of food and particularly for commercially quick-frozen food in food-freezer and frozen-food storage
compartments or cabinets;
4)The precautions necessary to prevent an undue rise in the temperature of the frozen food while
defrosting the refrigerating appliance, such as wrapping the frozen food in several layers of
newspaper.
5)The fact that a rise in temperature of the frozen food during manual defrosting, maintenance or
cleaning could shorten the storage life.
6)The necessity that, for doors or lids fitted with locks and keys, the keys be kept out of the reach of
children and not in the vicinity of the refrigerating appliance, in order to prevent children from being
locked inside.
Refrigerant and cyclopentane foaming material used for the refrigerator are
flammable. Therefore, when the refrigerator is scrapped, it shall be kept away from
any fire source and be recovered by a special recovering company with
corresponding qualification other than be disposed by combustion, so as to prevent
damage to the environment or any other harm.
When the refrigerator is scrapped, disassemble the doors, and remove gasket of
door and shelves; put the doors and shelves in a proper place, so as to prevent
trapping of any child.
Correct Disposal of this product：
This marking indicates that this product should not be disposed with other
household wastes. To prevent possible harm to the environment or human health
from uncontrolled waste disposal, recycle it responsibly to promote the sustainable
reuse of material resources. To return your used device, please use the return and
collection systems or contact the retailer where the product was purchased. They
can take this product for environmental safe recycling.

2 1 Placement.
2 Proper use of refrigerators
5
Before use, remove all packing materials, including bottom
cushions, foam pads and tapes inside of the refrigerator; tear off the
protective film on the doors and the refrigerator body.
Keep away from heat and avoid direct sunlight. Do not place the
freezer in moist or watery places to prevent rust or reduction of
insulating effect.
Do not spray or wash the refrigerator; do not put the refrigerator in
moist places easy to be splashed with water so as not to affect the
electrical insulation properties of the refrigerator.
The refrigerator is placed in a well-ventilated indoor place; the
ground shall be flat, and sturdy (rotate left or right to adjust the
wheel for levelling if unstable).
The top space of the refrigerator shall be greater than 30cm, and
the refrigerator should be placed against a wall with a free distance
more than 10cm to facilitate heat dissipation.
Precautions before installation:
Before installation or adjusting of accessories, it shall be ensured that the refrigerator is
disconnected from power.
Precautions shall be taken to prevent fall of the handle from causing any personal injury.

2.2 Leveling feet
Schematic diagram of the leveling feet
Adjusting procedures:
a. Turn the feet clockwise to the refrigerator;
b. Turn the feet counterclockwise to lower the refrigerator;
c. Adjust the right and left feet based on the procedures above to a horizontal level.
raise
2.3 Door Right-Left Change(Optional)
6
(The picture above is only for reference.The actual configuration will depend on the physical product
or statement by the distributor)
1)Please power off this appliance before conduct this operation. Remove all food from door shelves.
Fix the door by tapes.
List of tools to be provided by the user

7
Right hinge
Right hinge cover
Signal line C
Signal line D
Signal line E
Signal line B
Signal line A
Sensor
Signal line F
Sleeve pipe
Middle hinge
Hole cap
2)Please dismantle the fitting screws of top cover, and lift the top cover up a little,then disconnect the
connection of signal line A and B,take out the sensor, and separate the right hinge cover from top
cover; disconnect the connection of signal line E and D, then remove the fitting screws of right hinge
and remove the freezer door.
3)Dismantle the fitting screws of middle hinge, remove the middle hinge and sleeve pipe, remove the
two hole caps of other side, and uplift the door of refrigerating compartment upwards.
Top cover

8
Sleeve pipe
Bottom hinge
Levelling foot B
Levelling foot A
Levelling foot C
Shaft
Levelling foot C
Levelling foot B
Levelling foot ASleeve pipe&shaft
4)Dismantle the lower hinge assembly and levelling foot C, then dismantle the sleeve pipe and hinge
shaft, move levelling foot B to right hole,Install the hinge shaft and sleeve pipe to the left hole of
lower hinge, and then install the lower hinge to the lower left corner of the refrigerator.
Finally, install the levelling foot C to the lower right corner of the refrigerator.
assembly
After completing the assembly.

9
Right decorative cover
Hole cap
sleeve pipe
Left decorative cover
Signal line E
Left self-locking
Right self-locking
Stopper
5)Dismantle the stoppers and self-locks of both refrigerator door and freezer door, and take out the
spare left self-locks from accessory bag, and install the said stoppers and spare left self-locks on left
corners of both doors; exchange the installation position of sleeve pipe and hole cap of refrigerator
door;dismantle the upper end cover of freezer door, and move the signal line E from right side to left
together with the sleeve pipe; take out the spare right decorative cover from accessory bag and install
the end cover and right decorative cover, the left decorative cover shall be kept for future use.
6)Put the refrigerator door on lower hinge vertically, install the middle hinge on left side and two hole
caps on right side.
End cover

10
(The picture above is only for reference.The actual configuration will depend on the physical product
or statement by the distributor)
Signal line C
Signal line D
Signal line B
Signal line A
Signal line E
Signal line F
Sensor
Left hinge cover
8)After completing the installation
7)Move the decorative cover of top cover from left side to right side,take out the left hinge cover from
accessory bag, and fix it on left side of top cover; put the freezer door on middle hinge vertically,
connect the signal line E to signal line F, connect the signal line A to signal line B, connect the signal
line C to signal line D; take out the left upper hinge from accessory bag and fix it on left top side of
cabinet, fix the sensor on the original position of top cover; finally to install the top over by fitting
screws.
Decorative cover
Left upper hinge

2 4 the Light. Changing
2.6 Energy saving tips
2 5. Starting
11
The appliance should be located in the coolest area of the room, away from heat producing
appliances or heating ducts, and out of the direct sunlight.
Let hot foods cool to room temperature before placing in the appliance. Overloading the appliance
forces the compressor to run longer. Foods that freeze too slowly may lose quality, or spoil.
Be sure to wrap foods properly, and wipe containers dry before placing them in the appliance.This
cuts down on frost build-up inside the appliance.
Appliance storage bin should not be lined with aluminum foil, wax paper, or paper toweling. Liners
interfere with cold air circulation, making the appliance less efficient.
Organize and label food to reduce door openings and extended searches. Remove as many items
as needed at one time, and close the door as soon as possible.
Any replacement or maintenance of the LED lamps is intended to be made by the manufacturer, its
service agent or similar qualified person.
Before putting any fresh or frozen foods, the refrigerator shall have run
for 2-3 hours, or for above 4 hours in summer when the ambient
temperature is high.
Spare enough space for convenient opening of the doors and drawers or
statement by the distributor.
Before initial start, keep the refrigerator still for two hours before connecting it to
power supply.
1078mm
700mm
1226mm
600mm
125°

3.1Key components
3 Structure and functions
Refrigerating chamber
Freezing chamber
12
(The picture above is only for reference.The actual configuration will depend on the physical
product or statement by the distributor)
The low temperature freezing chamber may keep food fresh for a long time and it is mainly used
to store frozen foods and making ice.
The freezing chamber is suitable for storage of meat, fish, rice balls and other foods not to be
consumed in short term.
Chunks of meat are preferably to be divided into small pieces for easy access. Please be noted
food shall be consumed within the shelf time.
Door tray
Door tray
LED light
Fruits and
vegetables box
shelf
LED light
shelf
The Refrigerating Chamber is suitable for storage of a variety of fruits, vegetables, beverages
and other food consumed in the short term.
Cooking foods shall not be put in the refrigerating chamber until cooled to room temperature.
Foods are recommended to be sealed up before putting into the refrigerator.
The glass shelves can be adjusted up or down for a reasonable amount of storage space and
easy use.
For better use of the refrigerator, it is recommended to push the slider of manual air damper to
right side; if it is not enough cool in refrigerator room, please check this slider and try to push it
to right side if not .
If push the slider of humidity controlling glass shelf to "Vegetables", the humidity inside the
crisper will be highest, if push the slider to "Fruit", the humidity inside the crisper will be lowest.
Humidity controlling
glass shelf
Manual air damper
Deoderizer
Temperature control

3 2 Functions.
13
(The picture above is only for reference.The actual configuration will depend on the physical product
or statement by the distributor)
1)Key
A.Temperature setting button of refrigerator compartment
2)Display screen
①setting 1：8℃
②setting 2：6℃
③setting 3：4℃
④setting 4：2℃
setting 1 setting 2 setting 3 setting 4
Fault Code
Indicator setting 1 and setting 2
Fault Description
Indicator setting 1 and setting 3
Indicator setting 1 and setting 4
.
A
①
②
③
④
4)Temperature setting
Each time the temperature setting button A is pressed once,the temperature setting changes one
time. After the temperature setting has been completed, the refrigerator will run according to the set
value after 15s.
The shift regulation is:
Refrigerator temperature sensor
Freezer defrost sensor
Ambient temperature sensor
5)Lock/Unlock
When the temperature control panel is in lock state, it needs to long press temperature setting key
for 3 seconds for unlocking the panel, all LEDs will blink for 2 seconds when panel is unlocked.
When the temperature control panel is in unlock state, if there is no operation on control panel within
15 seconds, it will enter into lock state automatically.
3)Display
when electrify the refrigerator for first time,the display screen shines fully for 3 seconds, and then
the refrigerator runs according to setting 3. In case of a failure, the corresponding LED blinks. In
case of no failures, it shows the temperature setting of refrigerator.

14
4. Maintenance and care of the refrigerator
4.1 Overall cleaning
Please unplug the refrigerator for defrost and cleaning.
deterge nt
4.2 the glass shelfCleaning
Dusts behind the refrigerator and on the ground shall be timely cleaned to improve the cooling
effect and energy saving. The interior of the refrigerator should be cleaned regularly to avoid odor.
Soft towels or sponge dipped in water and non-corrosive neutral detergents are suggested for
cleaning. The freezer of shall be finally cleaned with clean water and dry cloth. Open the door for
natural drying before the power is turned on.
Do not use hard brushes, clean steel balls, wire brushes, abrasives,
such as toothpastes, organic solvents (such as alcohol, acetone,
banana oil, etc.), boiling water, acid or alkaline items clean
refrigerator considering that this may damage the fridge surface
and interior.
Do not rinse with water so as not to affect the electrical insulation
properties.
Remove the drawer on the glass shelf;
Lift up the front of glass shelf(about 60°), and then pull out;
Remove the glass shelf and clean as needed;
The reverse operation is for installation of glass shelf.
4.4 How to take out the humidity controlling glass shelf
1)Open the door of refrigerator room, hold the upper right corner of door gasket, pull it outwards
smoothly until it is separated from the upper right corner of door liner, then hold the upper side and
right side of door gasket and pull the gasket outwards until the gasket is separated from the door;
2)Take out the two fruit and vegetable boxes;
3)Remove the fixing tape on the backside of humidity controlling shelf, then use hand to push the
backside of glass upwards,until the backside is separated from the shelf frame with about 10°，and
take out the glass with tremendous care;
4)Hold the front edge of humidity controlling shelf and lift up it about 20° ,then take out the humidity
controlling shelf;
Please don't try to the take out the humidity controlling glass shelf, If it needs to be removed due to
cleaning or other reasons, please follow the steps as shown as below:
4 3 Defrosting.
The refrigerator is made based on the air-cooling principle and thus has automatic defrosting
function. Frost formed due to change of season or temperature may also be manually removed by
disconnection of the appliance from power supply or by wiping with a dry towel.

15
4 5 Out of operation.
The appliance shall run continuously once it is started. Generally, the operation of
the appliance shall not be interrupted;otherwise the service life may be impaired.
Power failure: In case of power failure, even if it is in summer, foods inside the appliance can be
kept for several hours; during the power failure, the times of door opening shall be reduced, and no
more fresh food shall be put into the appliance.
Long-time nonuse: The appliance shall be unplugged and then cleaned; then the doors are left
open to prevent odor.
Moving: Before the refrigerator is moved, take all objects inside out, fix the glass partitions,
vegetable holder, freezing chamber drawers and etc. with tape, and tighten the levelling feet;
close the doors and fix them with tape. During moving, the appliance shall not be laid upside down
or horizontally, or be vibrated; the inclination during movement shall be no more than 45°.
5)The reverse operation is for assembly;
NOTE: for gasket assembly, please press the upper right corner of gasket into the upper right corner
of door liner, then press the upper side and right side of gasket into the door liner, finally to press the
left side and lower side of gasket into door liner. After completing the assembly, please check wether
the assembly is firm or not(try to pull out the gasket gently to check ), and make sure the surface of
gasket is flat.

5 Trouble shooting
16
You may try to solve the following simple problems by yourself. If them cannot be solved,
please contact the after-sales department.
Water pan overflows
There is too much food in the chamber or food stored contains
too much water,resulting in heavy defrosting.
The doors are not closed properly, resulting in frosting due to entry
of air and increased water due to defrosting.
Failed operation
Check whether the appliance is connected to power or whether the plug
is in well contact .
Check whether the voltage is too low.
Check whether there is a power failure or partial circuits have tripped.
Door seal fails to
be tight
Remove foreign matters on the door seal.
Heat the door seal and then cool it for restoration (or blow it with an
electrical drier or use a hot towel for heating).
Hot housing
Abnormal noise
Long operation of the refrigerator is normal in summer when the ambient
temperature is high.
It is not recommended having too much food in the appliance at the same time.
Food shall get cool before being put into the appliance.
The doors are opened too frequently.
Long-time operation
of the compressor
The door is stuck by food packages.
The refrigerator is tilted.
Doors cannot be
properly closed
Surface condensation
Condensation on the exterior surface and door seals of the refrigerator is
normal when the ambient humidity is too high. Just wipe the condensate
with a clean towel.
Buzz: The compressor may produce buzzes during operation, and the buzzes
are loud particularly upon start or stop. This is normal.
Creak: Refrigerant flowing inside of the appliance may produce creak, which
is normal.
Heat dissipation of the built-in condenser via the housing, which is normal.
When housing becomes hot due to high ambient temperature and
storage of too much food,it is recommended to provide sound ventilation
to facilitate heat dissipation.
Odor
Odorous foods shall be tightly wrapped.
Check whether there is any rotten food.
Clean the inside of the refrigerator.
Check whether the refrigerator is connected to power supply and whether
the illuminating light is damaged.
Light fails to get lit
Loud noise
Check whether the floor is level and whether the refrigerator is placed stably.
Check whether accessories are placed at proper locations.
