Midea MSCK-TC60SS User manual

出口地区
客户型号
物料编码
材质
尺寸
颜色
其他要求
南非
MD-TC6004
单色印刷
变更记录
说明书技术要求
A0: 20170824
100g双胶纸
145x210 (MM)
警语部分所有大写字母>3mm，
小写字母使用同种字体

USER MANUAL
CONTENT
IMPORTANT SAFEGUARDS......................................................................... 1
........................................................................................................ 4
.......................................................................................... 9
..................................... 3
IMPORTANT NOTE: Please read the manual carefully before operating your
product. Retain it for future reference.
MSCK-TC60SS
Slow Cooker
Read this manual before operation of the appliance!
Cleaning and care
......................................................................................................... 10Storage
Operation

IMPORTANT SAFEGUARDS
Caution
For safety reasons and to avoid damage to the appliance or
injuries to people, please abide by all the safety instructions
below. Ignoring safety warnings may result in injuries.
This appliance does not take into consideration the following
situations:
--- Use by children or disabled people without supervision;
--- children treating it as a toy.
1. Read all instructions.
2. This appliance is for household use only. Do not use out-
doors.
3. This appliance is not intended for use by persons (includ-
ing children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their
safety.
4. Unplug from outlet when not in use and before cleaning.
Allow to cool before cleaning.
5. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified per-
sons in order to avoid a hazard.
6. Children should be supervised to ensure that they do not
play with the appliance
7. The use of accessory attachments not recommended by
the appliance manufacturer may cause injury.
8. Please turn off and unplug the appliance before cleaning,
maintenance or relocation and whenever it is not in use.
9. Do not let cord hang over edge of table or counter, or
touch hot surfaces.
10. Do not place on or near a hot gas or electric burner, or in
a heated oven.
11. Extreme caution must be used when moving an appliance
containing hot food, water or other hot liquids.
12. Do not use the appliance for other than intended use.
13. Lift and open cover carefully to avoid scalding, and allow
water to drip into unit.
14. To disconnect turn the control to OFF, then remove plug
from wall outlet.
15. Containers are designed for use with this appliance only.
They must never be used on a range top. Do not set a hot
container on a wet or cold surface. Do not use a cracked
container.
16. Appliances can be used by persons with reduced physi-
cal, sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved.
17. Do not immerse the appliance in water or any other liquid.
18. This appliance is intended to be used in household and
similar applications such as:
-staff kitchen areas in shops, offices and other working
environments;
-farm houses;
-by clients in hotels, motels and other residential type
environments;
-bed and breakfast type environments.
19. Children shall not play with the appliance.
The surfaces of the appliance are liable to get hot during
use.
20. To protect against electrical shock, do not immerse cord,
plug or appliance in water or other liquid.
21. The heating element surface is subject to residual heat
after use, do not touch.
1

For safety reasons and to avoid damage to the appliance or
injuries to people, please abide by all the safety instructions
below. Ignoring safety warnings may result in injuries.
This appliance does not take into consideration the following
situations:
--- Use by children or disabled people without supervision;
--- children treating it as a toy.
1. Read all instructions.
2. This appliance is for household use only. Do not use out-
doors.
3. This appliance is not intended for use by persons (includ-
ing children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their
safety.
4. Unplug from outlet when not in use and before cleaning.
Allow to cool before cleaning.
5. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified per-
sons in order to avoid a hazard.
6. Children should be supervised to ensure that they do not
play with the appliance
7. The use of accessory attachments not recommended by
the appliance manufacturer may cause injury.
8. Please turn off and unplug the appliance before cleaning,
maintenance or relocation and whenever it is not in use.
9. Do not let cord hang over edge of table or counter, or
touch hot surfaces.
10. Do not place on or near a hot gas or electric burner, or in
a heated oven.
11. Extreme caution must be used when moving an appliance
containing hot food, water or other hot liquids.
12. Do not use the appliance for other than intended use.
13. Lift and open cover carefully to avoid scalding, and allow
water to drip into unit.
14. To disconnect turn the control to OFF, then remove plug
from wall outlet.
15. Containers are designed for use with this appliance only.
They must never be used on a range top. Do not set a hot
container on a wet or cold surface. Do not use a cracked
container.
16. Appliances can be used by persons with reduced physi-
cal, sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved.
17. Do not immerse the appliance in water or any other liquid.
18. This appliance is intended to be used in household and
similar applications such as:
-staff kitchen areas in shops, offices and other working
environments;
-farm houses;
-by clients in hotels, motels and other residential type
environments;
-bed and breakfast type environments.
19. Children shall not play with the appliance.
The surfaces of the appliance are liable to get hot during
use.
20. To protect against electrical shock, do not immerse cord,
plug or appliance in water or other liquid.
21. The heating element surface is subject to residual heat
after use, do not touch.
Caution
IMPORTANT SAFEGUARDS
2

d) Indicator Lights (LOW,
MEDIUM, HIGH & WARM)
c) Cook Time Button
a) Digital Display
No. Description
1
2
3
Cooking Base
Handles
Electronic Control
b) Cook Mode
4 Glass Lid
5 Ceramic Casserole
Dear Customer,
The user manual:
Read this manual before operation of the appliance!
Please read this manual carefully before using your appliance for the first time
and then store it within easy reach for future reference. We trust you will enjoy
years of trouble free use.
This manual will provide you with information on how to safely operate and
care for your appliance in order that you gain the maximum benefit from it.
Pay particular attention to any safety instructions.
Controls and parts
3

Operation
1. Unpack and remove all parts and packaging materials from the carton.
2. DO NOT plug the power cord into any outlet before reading these instructions.
3. Wash the Casserole and Lid in warm, soapy water. Rinse and dry thoroughly.
4. Wipe the interior and exterior of the Base with a clean, damp cloth. Dry
thoroughly with a soft polishing cloth.
5. Place the Slow Cooker on a dry, level surface. Place Casserole in Base and
add 2 cups (500 ml) of water. Cover with Lid and plug cord into wall outlet.
Follow the instructions in the "How to Use the Slow
Cooker" section and allow the unit to cook on high for 30 minutes.
6. Once the time has elapsed, push the Off Button, unplug the Slow Cooker and
allow it to cool. Remove the Casserole and discard water.
7. Rinse Casserole and Lid. Dry thoroughly and place back in the Base.
Before Use
Note:
DO NOT use harsh detergents or abrasive cleansers on any parts of the
appliance. DO NOT immerse the Base or power cord and plug in water or
any other liquid.
USE: The Ceramic Casserole may be used in a conventional, convection, or
microwave oven so long as it is not heated under a broiler or top browning
element.
NEVER use the Glass Lid in any type of oven. Both the Glass Lid and Ceramic
Casserole can be cleaned in a dishwasher and also be used to store food in
the refrigerator or freezer.
CARE: Use only wooden or plastic utensils Metal utensils can scratch or mark
the ceramic. The Casserole can be washed by hand or in a dishwasher.
DO NOT allow the Ceramic Casserole to soak or stand in water for an extend-
ed period of time. Heating the Casserole after soaking may cause the surface
to crack. If scouring is required use only plastic or nylon pads with non-abra-
sive cleansers.
4

Operation
HOW TO USE THEGLASS LID
HOW TO USE THE SLOW COOKER
NEVER subject the Casserole to sudden temperature changes such as
moving it from the refrigerator directly into the oven or immersing it in water
when it is hot.
NEVER add cold water to a hot Ceramic Casserole.
NEVER place it in contact with direct intense heat such as on a range burner
or under a broiler element.
NEVER heat the Casserole when it is empty.
NEVER preheat the Base.
NEVER add cold food from the refrigerator directly to the Casserole.
NEVER unplug the Base and always allow the Casserole to cool before
cleaning.
IMPORTANT PRECAUTIONS:
The Glass Lid may shatter if exposed to direct heat or sudden temperature
changes. Chips, cracks or deep scratches may also weaken the Lid. If the Lid
becomes chipped, cracked or scratched, do not use it. Discard it and order a
replacement.
ALWAYS allow the Lid to cool on a dry heat resistant surface before handling.
NEVER place it on a cold or wet surface as this may cause it to crack or
shatter.
NEVER use the Glass Lid in a conventional, convection or microwave oven.
A Slow Cooker is easy to use but it is different from conventional cooking. This
booklet is intended to be used as a general guideline and contains several
suggestions and helpful hints for successful slow cooking.
One of the benefits of slow cooking is that meals can be prepared in advance
and the cooking time can be set so that the food is ready to serve at the
appropriate time.
There is an abundance of recipes specifically designed for slow cooking that
can be easily found on the internet or in recipe books at your local bookstore
or library.
5

Operation
HOW TO USE THE SLOW COOKER
1. Place the Slow Cooker on a dry, level surface. Add recipe ingredients to the
Ceramic Casserole and cover with Lid. Place Ceramic Casserole in Slow
Cooker base.
2. Plug unit into the wall outlet. The digital display will flash "- - - -".
3. Press the Cook Mode Button to select Low, Medium, High or Warm. (Press
once for Low, twice for Medium, 3 times for High and 4 times for Warm) The
default setting of 6 hours (6:00) will be shown in the Digital Display if you have
selected Low, Medium, High or Warm. After 3 seconds the Indicator Light will
illuminate beside Low, Medium, High or Warm, depending on your selected
setting.
4. Set the required amount of time by pressing the "Cook Time" Button. Each time
you press the Cook Time Button the time will increase by 30 minutes, to a
maximum of 10 hours. If you don't press the Cook Time Button for 3 seconds
the cooking time will be the time showing in the Display Window.
Note:
If you would prefer less cooking time than the default setting of 6 hours,
continue to press the Cook Time Button past 10 hours and the Cook Time
will display 30 minutes. Press to increase the time by 30 minute increments.
Note:
If you would prefer less warming time that the default 6 hours, continue to
press the Cook Time Button past 10 hours and Cook Time will display 30
minutes. Press to increase the time by 30 minute increments.
Note:
To stop heating during the cooking process, press the Off Button. The Digital
Display flashes "- - - -". Unplug the Slow Cooker.
5. Once the Cooking Time is finished, the unit will switch to "Warm." The default
time of the Warm cycle is 6 hours.
6. Once the 6 hours has elapsed, the slow cooker automatically switches Off. The
indicator lights will go out and the Digital Display shows "-----". Unplug the Slow
Cooker from the wall outlet.
6

Operation
HELPFUL HINTS USING THE SLOW COOKER
1. The Lid does not form a tight seal with the Casserole. However, it should be
centred on the Casserole for best results.
2. Stirring is not required while slow cooking. However, when cooking on High,
stirring occasionally will help distribute flavours.
3. For best results the Casserole should be at least half full.
4. For soups and stews, leave a 2" (5 cm) space between the food and the top to
allow ingredients to simmer. When cooking on the High setting, keep checking
from time to time as some soups and stews may come to a boil.
5. When slow cooking it is more appropriate to use less tender, cheaper cuts of
meat than the more expensive varieties. Remove excess fat before cooking
and if called for, brown the meat on a range top using a metal frying pan
before adding meat to the Casserole.
6. The greater the fat content in the meat the less liquid is required. When
cooking meat with high fat content, place thick slices of onion under the meat
so that it will not sit and cook in the fat.
Roasts, when cooked on Low, may be prepared without adding any liquid.
1. Use a meat thermometer to determine if the meat has been cooked to your
taste.
2. Fresh or thawed fish or seafood should be added to the Casserole only 1 hour
before serving as they may fall apart during prolonged cooking.
3. Since raw vegetables take longer to cook than meat, cut them into small
pieces 1/2" (12mm) diameter before adding to the Casserole.
4. Milk, sour cream or other dairy products should be added just before serving
as these tend to break down during prolonged cooking.
5. Rice and pasta may be cooked separately or added uncooked to the ingredi-
ents no more than two hours before serving. If the pasta is uncooked there
should be at least 2 cups (500 ml) of liquid in the Casserole. Stir occasionally
to prevent pieces from sticking together.
6. To thicken juices or make gravy at the end of the cooking cycle, make a
smooth mixture of 2 to 4 tbsps. (30 - 60 ml) of corn starch, 1/4 cup (60 ml) of
water, and 2 tbsp. (30 ml) of butter. Remove cooked food from Casserole. Add
the mixture to the juices remaining in the Casserole, set to High and stir until
liquid thickens.
7. Do not worry if the food remains in the Slow Cooker longer than planned. The
Slow Cooker cooks very slowly and will be very forgiving if you are running a
little late.
7

Operation
GENERAL RECIPE INSTRUCTIONS
1. Prepare recipe according to directions.
2. Place food in Ceramic Casserole and cover with Lid.
3. Use the following chart to help adapt your favourite recipes to the Slow
Cooker. These times are approximate and should be used only as general
guidelines.
4. Follow the instructions in the "How to Use the Slow Cooker" section.
5. Using a potholder or oven mitt, carefully remove Lid.
HELPFUL HINTS FOR ADAPTING RECIPES
1. The Low setting is recommended for all day cooking. Most meat and vegeta-
ble combinations require at least 7 hours on Low.
2. For best flavour use whole leaf herbs and spice during the initial preparation.
If ground herbs and spices are used, stir in during the last hour of cooking.
3. The time required to cook is affected by many factors. The water and fat
content of the food, its starting temperature, and the size of the pieces will all
affect the cooking time. For example, meat cut into pieces will
cook faster than a whole roast. Adjust the time accordingly.
4. Recipes for vegetable casseroles must contain liquid to prevent scorching of
the sides of the Casserole.
5. You may choose to substitute ingredients in a recipe. For example, a 12 oz.
can of chicken broth could be replaced by a 10 oz. can of tomato soup and 2
CAUTION:
When removing the Lid, grasp the knob and slowly lift the side that is away
from you to allow the steam to escape before setting the Lid aside. To avoid
burns, always hold the Lid so that escaping steam flows away from your
hands, arms and face.
Rugular cooking Slow Cooker Time
Time
30 minutes
35-60 minutes
1-3 hours
7-8 hours 3-4 hours
4-5 hours
5-6 hours
5-6 hours
6-7 hours
7-8 hours
8-9 hours
9-10 hours
Low Medium High
6. Using pot holders or oven mitts grasp the Ceramic Casserole by the handles
on either end and remove from the Base.
7. Always place a trivet under the Casserole before placing on table or coun-
tertop. Serve contents.
8

Operation
HELPFUL HINTS FOR ADAPTING RECIPES
Cleaning and care
1. This appliance should be cleaned after every use. Before cleaning, unplug
the Base and allow the appliance to cool. DO NOT use harsh detergents or
abrasive cleansers on any part of the appiiance.
2. Wash the Casserole and Lid in warm soapy water. Rinse well and dry. If food
sticks to the surface of the Casserole, fill it with warm soapy water and let it
stand for an hour before cleaning. Casserole and Lid may be washed in a
dishwasher. To prevent damage place them carefully in a rack so that they do
not touch each other or any other object during cleaning cycles.
3. Wipe the exterior and interior of Base with a soft damp cloth. Dry with a soft
cloth. DO NOT immerse the Base or power cord and plug in water or any
other liquid.
4. To remove any stains from the Ceramic Casserole, clean with a non-abrasive
cleanser or apply a thin paste of baking soda to the affected areas. To
oz. of another liquid such as water or grape juice.
6. Canned beans may be added directly to any recipe. However, dried beans
(especially red kidney beans) should be soaked in water and boiled first. After
boiling in 3 times their volume of unsalted water, discard water and add beans
to recipe.
Note:
Beans must be softened completely before they are combined with sugary
and/or acidic foods, as these have a hardening effect on beans. In this case,
beans should be allowed to simmer until tender after boiling (about 1-1/2
hours).
remove water spots or mineral deposits wipe with distilled white vinegar.
Clean in warm soapy water, rinse and wipe dry with a soft cloth.
5. Store all parts of the Slow Cooker only once they are clean and dry. Never
store when the Casserole is wet. To store, place the Casserole inside Base
and wrap Lid in a soft cloth or towel before storing upside down on the
Casserole. Never wrap the power cord around the Base.
CAUTION:
Never use petrol, solvents or abrasive cleaners, metal objects or hard
brushes to clean the appliance. Never put the appliance, base or power cord
in water or any other liquid.
9

If you do not plan to use the appliance for a long period of time, please
store it carefully.
Make sure the appliance is unplugged and completely dry.
Store the appliance in a cool, dry place.
Make sure the appliance is kept out of the reach of children.
Environmental note
Do not dispose of the appliance with norma household waste at the end of
its service life Consult your local authorities for disposa information and
facilities available. Help protect the environment by recycling used appliances.
Technical data
Model: MSCK-TC60SS
220-240V~ 50/60Hz 185-220W
Technical and design modifications reserved.
Cleaning and care
remove water spots or mineral deposits wipe with distilled white vinegar.
Clean in warm soapy water, rinse and wipe dry with a soft cloth.
5. Store all parts of the Slow Cooker only once they are clean and dry. Never
store when the Casserole is wet. To store, place the Casserole inside Base
and wrap Lid in a soft cloth or towel before storing upside down on the
Casserole. Never wrap the power cord around the Base.
Storage
10
