Midwest MENADS 198-6243 User manual

Approximate Weight: 1,400 lbs
www.midwestmanufacturing.com
Approximate Size: 1' 2" H × 4' 2¾" W × 4' 2¾" D
INCINDIO FIRE PIT
Autumn Blend: 198-6243
Quarry Gray: 198-6240
Sienna: 198-6241
Tan: 198-6242

2
S
Tumbled Belgian Wall
M
Tumbled Belgian Wall
L
Tumbled Belgian Wall
PRODUCT
L Tumbled Belgian Wall
M Tumbled Belgian Wall
S Tumbled Belgian Wall
QUANTITY
32
24
24
CONCRETE BLOCK MATERIALS
ADDITIONAL MATERIALS
PRODUCT
Fire Pit Adhesive
3' Square Fire Pit Insert
DESCRIPTION
10 oz Tube
Steel
QUANTITY
5
1
SKU#
638-4313
259-5313
BELGIAN WALL BLOCKS
Autumn Blend
179-3731
179-3732
179-3733
179-3734
SMALL
COLOR DESCRIPTION
Color of Choice
Color of Choice
Color of Choice
LARGE
179-3650
179-3648
179-3653
179-3640
Quarry Gray
Sienna
Tan
179-3721
179-3722
179-3723
179-3724
MEDIUM

3
A solid foundation is necessary to prevent settling and tiling of each project. We recommend using a
leveling pad, unless local building code requires you to pour a concrete foundation or build another type
of foundation.***Fire rings should be placed on stone, dirt, or sand surfaces. Pavers or concrete can be
installed around fire rings, but should not be under fire rings. Fire Rings should not be placed on wood
or composite decking surfaces.
FOUNDATION:
• Choose the location for the completed project; place and mark the position of the base layer of blocks.
Once marked, remove the blocks and the organic top soil within the marked area.
• If applicable to your area, create a leveling pad with a non-frost susceptible, well graded, compacted
angular gravel-sand mixture with fines (GW as per ASTM D248). The leveling pad should be a minimum
of 4" to 6" thick. For leveling pads greater than 8” thick, the fill material shall be placed in more than
one lift. Each layer or lift of fill material shall be leveled and compacted to a 95% Standard Proctor
density before moving on.
• Once the top layer of fill material is compacted and level, place the base layer of blocks. The base layer
should sit 1" to 2" below grade to help further prevent shifting. Use additional fill material to level the
base layer as needed.
* If a concrete slab is required, prepare a leveling pad using the procedures listed in the paragraphs above. The concrete
shall have a minimum compressive strength of 2500 psi. A 4" thick concrete slab should be more than sufficient.
A thickened edge and reinforcement of the leveling slabs may be required. Please consult a professional engineer for
specific requirements.
TIPS FOR BUILDING LEVELING PADS:
It is the responsibility of the owner to ensure compliance with all applicable laws, codes and regulations for
any project. Proper safety precautions must be taken prior to and during the construction of each project.
Please follow standard safety guidelines and wear necessary protective equipment when building and using
your new backyard addition.
RESPONSIBILITIES:
• Please research and
follow local building codes
prior to the excavation,
construction and assembly
of your project.
• Exercise caution when you
work with concrete block
designs. Wear protective
safety equipment such as
safety glasses, dust masks,
gloves and a hard hat.
• Whether you plan to build
the project yourself or to
hire a professional, every
project requires a call to
mark your utility lines.
BEFORE YOU BEGIN:
Rubber Mallet
Level
Utility Knife
Caulk Gun
Protective Equipment
Tape Measure
TOOL CHECK LIST:

4
1' 2"
4' 2¾"
4' 2¾"
FIRE PIT DIMENSIONS
TABLE OF CONTENTS
Materials List
Tool Check List
Foundation Guidelines
Level 1 - Level 4
Level 5 - Complete
Finished ELevations
Use & Care Instructions
2
3
3
5
6
7
8
TECHNIQUES
Fasten each layer of block together with
¼” - ⅜” bead of construction adhesive on
all adjacent block faces unless otherwise
noted. Refer to the construction adhesive’s
application instructions for proper use.
Follow suggestions on page 3 to build a proper foundation before starting your new project. If not
already set, place the first level of block 1”- 2” below grade, level and fill in any gaps. Use Level 1
as a reference to place the blocks for all remaining levels.
Refer to the illustrations on the following pages to guide you through each step. Prior to adhering
each level to the previously laid block, place the entire level of blocks and check to make sure the
fire pit insert fits properly. Remove small sections at a time to place the adhesive.
Once all levels are complete, position the insert into the finished pit. Wait a minimum of two days
before starting a fire.
INSTALLATION INSTRUCTIONS
* Do not over apply adhesive. It may reduce effectiveness.
Use mineral spirits to remove any unwanted adhesive.

5
(8) L Belgian Wall
(6) M Belgian Wall
(6) S Belgian Wall
LEVEL 1 LEVEL 2
LEVEL 4
LEVEL 3
(8) L Belgian Wall
(6) M Belgian Wall
(6) S Belgian Wall
(8) L Belgian Wall
(6) M Belgian Wall
(6) S Belgian Wall
(8) L Belgian Wall
(6) M Belgian Wall
(6) S Belgian Wall

6
LEVEL 5
COMPLETE
(1) 36” Square Fire Ring

7
ELEVATION PERSPECTIVES
Left View
Front View
Top View
Back View
Right View

8
With proper use and maintenance you can enjoy this new addition to your
landscape for years to come.
FIRE PIT USE:
• When using your fire pit, always following burning regulations in your area and never
leave a fire unattended.
• Keep the fire within the metal insert; any exposure of the flames directly to the concrete
blocks may cause blackening or cracking of the blocks.
USE & MAINTENANCE
FIRE PIT MAINTENANCE:
• Clean your fire pit often.
• Wait until the fire has burned out completely and all ashes have cooled before
cleaning the fire pit.
• Begin by removing the larger pieces of debris; the remaining ash can be scooped out
and/or lightly sprayed with a hose to rinse away.
