Miele M 7240 TC User manual

11196830-01
Installation
*INSTALLATION*
When installing the microwave oven,
ensure that there is adequate
ventilation to the front of the
appliance.
Do not obstruct the air vents with
any objects.
Lifting the microwave oven by the
door handle could cause damage to
the door.
Use the handle cut-outs on the side
of the casing to lift the appliance.
Installation dimensions
Dimensions are given in mm.
Tall unit installation
595
450
562
>550
_
+6
+2
Base unit installation
595
460
+2
>550
__
>550
_
>550
__
>550
_
>550
_
+6
562
_

11196830-01
Installation
*INSTALLATION*
Side view
455,5
451,5
333
111,5
22
22* / 23,3**
4min.2
* Glass
** Stainless steel

11196830-01
Installation
*INSTALLATION*
Tall unit connection
3
70
53
2
1
451,5
595
aFront view
bMains connection cable,
Length=1600mm
cNo connections permitted in this area

11196830-01
Installation
*INSTALLATION*
Base unit connection
3
70
53
2
1
451,5
595
aFront view
bMains connection cable,
Length=1600mm
cNo connections permitted in this area

11196830-01
Installation
*INSTALLATION*
Carrying out installation
The microwave oven must be built in
before it can be used.
Slide the microwave oven into the
niche. Feed the cable with the plug
through the back of the unit.
Position the appliance.
Open the appliance door and secure
the appliance onto the side walls of
the unit using the screws provided.
