Miele K 1911 SF User manual

NOTE: Drawing is not to scale.
SPECIFICATION SHEETS 011108
Product and Cut-out Dimensions
K1911SF / K1901SF
36"
24" min.
35 3/4"
83 1/2" - 85 3/8"
10 1/4"
23 1/2"
84"
1 1/8"
E
Notes
5 foot - 120 Volt - 15 Amp 3-wire molded plug power
supply connects lower left rear.
Standard NEMA 5-15 Outlet - locate less than 9" above
finished floor
1/4" flexible water line - tape to floor
E -
O -
W -
• All Installations must be done in accordance with local codes
Location Codes
3 1/2" - 5 3/8"
O
W

NOTE: Drawing is not to scale.
SPECIFICATION SHEETS 011108
Top View
K1911SF / K1901SF
36" Cutout Width
35 3/4" Housing Width
36 1/2" Frame Width
1 1/8"
3 1/2"
23 1/2" Installed Depth
24" Cutout Depth

NOTE: Drawing is not to scale.
SPECIFICATION SHEETS 011108
Hinging Details
90° Door 115° Door
Door Swing
39 3/16"
3 9/16"
Door Swing
18"
MAX
