MikroTik PWR-LINE PRO User manual

PWR-LINE PRO
PWR-LINE PRO
The PWR-LINE PRO allows Ethernet-like connectivity between supported devices over regular electrical power lines. When plugged into the same
electrical circuit, the device will establish Ethernet connectivity by using the HomePlug AV 2 standard. PWR-LINE PRO does not require any system
software or configuration, it's ready to use.
Connecting
Plug one PWR-LINE PRO device into a power socket.
Connect to one of the LAN ports of your MikroTik router to the PWR-LINE PRO Ethernet port.
Plug another PWR-LINE PRO unit (or any other compatible device) somewhere in the same electrical circuit.
Use the sync button to connect the devices and your local network will automatically be extended. Please see thePWR-LINE PRO#PWR
section on how to pair additional PWR-LINE PRO devices.connection button (sync)
PWR-LINE PRO supports PoE out from Ethernet port to power another Mikrotik device, this can be activated with a switch, please see PWR-LINE
section.PRO#LED lights and PoE switch
Mounting
PWR-LINE PRO can be mounted on the wall using four provided screws:
To access mounting points, remove a center screw, that is holding top cover, using PH2 screwdriver.
Mark four points for screw holes in the desired place on the wall for PWR-LINE PRO.
Drill using a 5 mm drill bit for dowel holes and insert them by slight tapping if necessary.
Mount PWR-LINE PRO and close top cover, center screw tightening force 0.5 – 0.7 Nm, attach provided 3M sticker to cover center screw.
Powering

1.
2.
3.
4.
5.
The device accepts power from a wall socket where it is plugged into.
100-240 V AC , ~50/60 Hz.
The power consumption under maximum load can reach 5 W. Max power consumption with PoE-Out 14 W.
Expansion slots and ports
One Gigabit Ethernet port, supporting 24 V PoE output by default settings is set to OFF.
Buttons and Jumpers
PWR connection button (sync)
Hold 0.5 – 3 seconds. For 120 seconds will try to communicate with another PWR-LINE PRO device. A blinking amber LED light indicates that it
is in search mode. You have to also do the same on the other PWR device, so they can synchronize. Press button again to cancel the search.
Hold 5 – 8 seconds. A new security key is generated. This is needed to remove a PWR-LINE PRO device from an existing PWR network.
Hold 10 – 15 seconds. Resets all PWR related settings.
In case of trouble to pair device, hold the SYNC button for 5 - 8 seconds to generate new network key and then re-attempt to pair it in PWR-LINE
PRO network again holding SYNC button for 0.5 – 3 seconds.
LED lights and PoE switch
Blue LED indicates device power ON state.
Amber LED indicates that the device is paired, blinking amber indicated that the device is in search mode. It can be activated with a sync button.
Please refer to the section.PWR-LINE PRO#PWR connection button (sync)
Green LED indicates Ethernet port connectivity.
Red LED indicates that PoE is active.
PoE switch default position is OFF. A standard ballpoint pen can be used to switch positions. The Red light will indicate that PoE is active.
In order to reach a speed of 600 Mbps, your electrical sockets needs to be grounded.
To connect with another PWR-LINE device, both need to be on the one electrical phase.

Accessories
Package includes the following accessories that come with the device:
K-62 fastening set.
EU/US power cord, D03+QT1 H03VV-F 0x0.75 mm2, 30 cm RoHS, White color.
Specifications
For more information about this product, specification and pictures please visit our web page: https://mikrotik.com/product/pl7510gi
