MILALOKO Sports DV Camera User manual

MILALOKO
•1•
Statement
This MILALOKO product will be free from
defects in material and workmanship for
one-year warranty from the date of purchase.
This warranty does not cover damage from
accident, neglect, misuse, alteration,
contamination, or abnormal conditions of
operation or handling. To obtain service during
the warranty period, contact MILALOKO from
AMAZON to obtain return authorization
information or other service.

MILALOKO
•2•
MILALOKO
Sports DV Camera
WiFi

MILALOKO
•3•
Table of Contents
1. Before Using
1.1 Product Structure -------------------------------5
1.2 Product Features --------------------------------6
1.3 Package Included -------------------------------7
2. Basic Instructions
2.1 How to charge -----------------------------------8
2.2 Charging While Recording --------------------9
2.3 Reset -----------------------------------------9
2.4 Power Off ----------------------------------10
2.5 Time Setting --------------------------------10
2.6 Connect to a computer ------------------------11

MILALOKO
•4•
3. Mode Instructions
3.1 Recording Mode -----------------------------14
3.2 Recording Infrared Mode ------------------15
3.3 Photographs-taking Mode ------------------15
3.4 Wi-Fi Mode -----------------------------------16
3.5 Infrared Mode under Wi-Fi Mode ---------17
3.6 USB --------------------------------------------17
4. Parameters
4.1 Relevant Parameters -------------------------19
4.2 Note --------------------------------------------20
4.3 Attention ---------------------------------------21
5. Service & Warranty
MILALOKO Electronics Warranty-------------23

MILALOKO
•5•
1. Before Using
►Red indicator light: Video function indication.
Blue indicator light: WIFI indication.
► Long press the switch key to enter the system initialization, the
red light is on. The camera default open WIFI mode. The blue light
is on. If there is SD card, the red light flashes once then bright all
the time. If there is no SD card, the red indicator light flashes. Long
press mode key 2 seconds on the standby mode to turn off Wi-Fi
function, the blue light is off. Then long press 2 seconds to open
Wi-Fi, the blue light is on. The camera will automatically shut
down if WIFI is off and no operation within 60 seconds under
standby mode.
► No SD card/No memory storage left: Turn off Wi-Fi, the red
light flashes 5 times and then turns off; Turn on Wi-Fi, the red light
flashes.
Low Power: The blue light is off, the red light turn off after 2 sec.

MILALOKO
•6•
1.1 Product Structure
1. Mini USB 2. TF Card Slot 3. Notch for Attachment
4. Camera port 5. Indicator Light 6. ON/OFF Button
7. M Button 8. Infrared IR Night Vision Lamps
1.2 Product Features
● HIGH RESOLUTION & SUPERIOR HD IMAGE. Lossless HD 1080P DV
DC.
● Come with versatile attachments, useful in different occasions.
● High capacity battery, supports up to 180min continuous recording.
● Mini size & portable design，easy to carry around.
● High solution recording in low lights.

MILALOKO
•7•
● Built-in 8 infrared lamps，support recording under night vision.
● Resolution：1920×1080P
● Photo Format：12M（4032×3024）
● High Speed Transmission USB Cable 2.0
● Support TF card max up to 32GB.
1.3 Package Included
• 1 * Mini Sports Camera
• 1 * USB Cable
• 1 * 32G Micro SD Card
• 1 * Mini Card Reader
• 1 * User Manual
• 3* Multifunctional Attachments

MILALOKO
•8•
2. Basic Instructions
2.1 How to charge
The camera built-in rechargeable lithium battery, please
charge it before the first using.
Methods:
1 Connect the camera to computer，charge it with
USB cable;
2 Charging while recording: Connect to external
USB 5V charger or mobile power supplement;
* The red indicator light is on and flashing normally
when you charge the camera. When the red indicator
light keeps on but stops flashing means charging is
completed.( Please charge for more than 30 minutes to
make sure the battery is fully charged.)
Note： When the battery power is low, The blue light is
off, the red light turn off after 2 seconds, the camera

MILALOKO
•9•
will shut-down automatically, enter into the protection
state (The recording file will save automatically), the
camera should be charged under this condition.
2.2 Charging While Recording
Insert Micro SD card, connect USB 5V charger or
mobile power supplement with USB cable, start
recording videos while charging the camera.
Click any button to stop recording. Or the camera will
keep recording until out of battery.
2.3 Reset
If the machine crashes, the button can not be used
normally, you can press the power key and the M key to
reset the machine, then it can be used normally.

MILALOKO
•10•
2.4 Power Off
If you want to shut down the camera under the video
recording, photo taking, motion detection mode. Press
ON / OFF button for about 6 seconds to shutdown the
camera. ( The indicator light is off.)
When the camera is under standby mode, the camera
will shut-down automatically after one minute without
any working mode.
2.5 Time Setting
The camera will automatically create a TXT text
document in the TF card directory.( As the pic )
Shutdown the camera, connect the camera to computer
with USB cable, open TIMEREST.txt document. Edit
and save the time you need in the document. ( Such as
“20160804174726 Y ”) Boot up the camera to shoot
videos, the video will show the time watermark you

MILALOKO
•11•
save in the txt document. You can use the same method
if you don’t need time watermark.
For example: 20150608192526 Y ( Have time watermark)
20150608192526 N ( Don’t have time watermark)
Notice:
①Be sure to insert the T-flash (Micro SD) card into the
product. If the card have not TF/SD card inside, the
camera can not be used normally when the red and blue
indicator light flash at the same time.
②Please keep the lens at the distance of 50cm or more
in the environment with sufficient lighting. This way
makes the images and videos stable with natural color,
and scenery is clear.
2.6 Connect to a computer

MILALOKO
•12•
The camera can be directly connected to the computer
under boot up, standby, or shutdown mode. It can be
used as normal U disk and you can copy/paste/delete the
file as usually do.
Connect the camera to the computer, after a few seconds
the computer will pop up the removable disk logo, when
the blue indicator light is on, means the computer can
identify the USB device and carry out data transmission,
the red light is on means the camera is charging, the red
light flashes for a long time means the camera is fully
charged.
Note:
1. After the unit is connected to the computer, if the
computer does not recognize it, or if the removable disk
is not ejected after 30 seconds, please reset it and try
again.

MILALOKO
•13•
2. It is recommended to use the SD card reader to read
the video file directly to play, if you directly use the
USB connection to save the machine built-in memory in
the video file, the transmission can not keep up because
of the data may be too large and resulting in playback is
not smooth.

MILALOKO
•14•
3. Mode Instructions
3.1 Recording Mode
1.Boot up the camera, enter the standby mode.( The
blue indicator light is on.)
2.Click the M button.( The red indicator light is flashing
slowly.) Start recording 1080P HD videos. Save the
video file, the red light is always on.
3.The video will safe video as segmented video every 5
minutes. The video will be loop covered if there is no
enough storage.
4.Click the power button again to stop recording, back
to standby mode.
5.Push the power button for a long time under the
recording mode will shut down the camera. Recording
file will be preserved automatically.

MILALOKO
•15•
3.2 Recording Infrared Mode
1. Boot up the camera, enter the standby mode.( The
blue indicator light is on.)
2. Push the power button.( The red indicator light is
flashing slowly.) Start recording 1080P HD videos.
3. Click the M button under the RECORDING MODE
to start infrared mode.( The red indicator light is
flashing slowly.)
4. Click the M button for 2 seconds again, back to
normal recording mode.( The red indicator light is
flashing quickly.)
3.3 Photographs-taking Mode
1. Boot up the camera, enter the standby mode.( The
blue indicator light is on.)
2. Click the switch button to start taking photographs.

MILALOKO
•16•
3. Every click on the power button is taking a pic.( The
red indicator light flashes with each clicking.)
4. Photos will be preserved automatically as 12M
(4032*3024)
5. Push the power button for a long time will shut down
the camera.
3.4 Wi-Fi
1.Wi-Fi connecting: Connect your phone or iPad to
Wi-Fi ( Name is begin with JH-7602B***); default
password is 12345678.
2. Indicator Light: If the blue light is always on that
means the Wi-Fi mode is open or connected; If the blue
light is flashing, that means the camera is transforming
image signal through Wi-Fi.
3. Shooting Videos/Photos: Under Wi-Fi mode, you can
choose to save recording files in your phone or in the

MILALOKO
•17•
SD card through APP; In the APP settings, the camera
video resolution is optional as well.
3.5 Infrared Mode under Wi-Fi Mode
1. Long press key button for 2 seconds under Wi-Fi
mode to open infrared mode. ( The blue light flashes
quickly, the red light flashes slowly.)
2. Long press key button for 2 seconds again to turn off
infrared mode. ( The blue light and the red light both
flash quickly.)
3.6 USB
You can connect to the computer with USB cable under
any mode. But Wi-Fi function is closed and can not be
open.

MILALOKO
•18•
3.7 Download APP
You can download and install the two-dimensional code
by scanning the QR code on manual or on the outer box.

MILALOKO
•19•
4. Parameters
4.1 Relevant Parameters
Item
Relevant Parameters
Video Format
AVI
Video Code
M-JPEG
Resolution
1920×1080P
Frame Rate
30fps
Proportion
16：9
Resolution
12M（4032×3024）
Picture Format
JPG
Motion Detection
Support
Battery type
Built-in high-capacity lithium
polymer
Battery capacity
450mAh
Working time
2.5 hours

MILALOKO
•20•
Voltage
DC-5V
Memory
Max up to 32GB
Speed
High speed USB2.0
Port
Mini 8pin USB
Support System
Windows me/2000/XP/2003/Vista;
Mac Os; Linux
Playing Software
Default Software
4.2 Notes
Each time you use the battery and then charge, about to
charge about 2-3 hours to fill, the indicator light is filled
as much as possible after 30 minutes to ensure that the
fully charged.
Because this product is the real HD DV, the product
power consumption is larger than the Purple, the shell
material using zinc alloy parts, and the use of the
