MILLEN MEH 772 BL User manual

USER MANUAL
MEH 772 BL | MEH 902 BL | MEH 903 BL | MEH 904 BL
ELECTRIC HOB
EN AR

1
Dear Customer
Thank you for choosing a MILLEN product. We would like you to
be satisfied with our product, which has been produced in our highly
qualified, technological and modern facilities.
You can use your hob with pleasure and confidence for many
year by performing required maintenance and showing necessary
care.
Read the whole manual. Retain the manual during use of the
product. If you hand the product over to someone else, give them
the manual as well.
Attention
Before using the hob, we ask you to carefully read the instruction
manual and save it for future use. If you lose this instruction
manual, you can get a new one on the official website.
Warranty –3 years. Detailed information is provided in the warranty
card inside the package. Service life –10 years.

2
By placing a mark on this product, we are
confirming compliance to all relevant European safety,
health and environmental requirements which are
applicable in legislation for this product.
Safety Warnings
Your safety is important to us. Please read this
information before using your cooktop.
Installation
Electrical Shock Hazard
• Disconnect the appliance from the mains electricity
supply before carrying out any work or maintenance
on it.
• Connection to a good earth wiring system is
essential and mandatory.
• Alterations to the domestic wiring system must only
be made by a qualified electrician.
• Failure to follow this advice may result in electrical
shock or death.
Cut Hazard
• Take care - panel edges are sharp.
• Failure to use caution could result in injury or cuts.
Important safety instructions
• Read these instructions carefully before installing or
using this appliance.
• No combustible material or products should be
placed on this appliance at any time.

3
• Please make this information available to the person
responsible for installing the appliance as it could
reduce your installation costs.
• In order to avoid a hazard, this appliance must be
installed according to these instructions for
installation.
• This appliance is to be properly installed and earthed
only by a suitably qualified person.
• This appliance should be connected to a circuit
which incorporates an isolating switch providing full
disconnection from the power supply.
• Failure to install the appliance correctly could
invalidate any warranty or liability claims.
Operation and maintenance
Electrical Shock Hazard
• Do not cook on a broken or cracked cooktop. If the
cooktop surface should break or crack, switch the
appliance off immediately at the mains power supply
(wall switch) and contact a qualified technician.
• Switch the cooktop off at the wall before cleaning or
maintenance.
• Failure to follow this advice may result in electrical
shock or death.
Health Hazard
• This appliance complies with electromagnetic safety
standards.
Hot Surface Hazard
• During use, accessible parts of this appliance will

4
become hot enough to cause burns.
• Do not let your body, clothing or any item other than
suitable cookware contact the Induction glass until
the surface is cool.
• Metallic objects such as knives, forks, spoons and
lids should not be placed on the hob surface since
they can get hot.
• Keep children away.
• Handles of saucepans may be hot to touch. Check
saucepan handles do not overhang other cooking
zones that are on. Keep handles out of reach of
children.
• Failure to follow this advice could result in burns and
scalds.
Cut Hazard
• The razor-sharp blade of a cooktop scraper is
exposed when the safety cover is retracted. Use with
extreme care and always store safely and out of reach
of children.
• Failure to use caution could result in injury or cuts.
Important safety instructions
• Never leave the appliance unattended when in use.
Boilover causes smoking and greasy spillovers that
may ignite.
• Never use your appliance as a work or storage
surface.
• Never leave any objects or utensils on the appliance.
• Never use your appliance for warming or heating the
room.
• After use, always turn off the cooking zones and the
cooktop as described in this manual (i.e. by using the

5
touch controls).
• Do not allow children to play with the appliance or sit,
stand, or climb on it.
• Do not store items of interest to children in cabinets
above the appliance. Children climbing on the cooktop
could be seriously injured.
• Do not leave children alone or unattended in the
area where the appliance is in use.
• Children or persons with a disability which limits their
ability to use the appliance should have a responsible
and competent person to instruct them in its use. The
instructor should be satisfied that they can use the
appliance without danger to themselves or their
surroundings.
• Do not repair or replace any part of the appliance
unless specifically recommended in the manual. All
other servicing should be done by a qualified
technician.
• Do not use a steam cleaner to clean your cooktop.
• Do not place or drop heavy objects on your cooktop.
• Do not stand on your cooktop.
• Do not use pans with jagged edges or drag pans
across the Induction glass surface as this can
scratch the glass.
• Do not use scourers or any other harsh abrasive
cleaning agents to clean your cooktop, as these can
scratch the Induction glass.
• If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
•This appliance is intended to be used in household

6
and similar applications such as: -staff kitchen areas
in shops, offices and other working environments; -
farm houses; -by clients in hotels, motels and other
residential type environments; -bed and breakfast
type environments.
•WARNING: The appliance and its accessible parts
become hot during use.
Care should be taken to avoid touching heating
elements.
Children less than 8 years of age shall be kept away
unless continuously supervised.
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
•Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children
without supervision.
•WARNING: Unattended cooking on a hob with fat or
oil can be dangerous and may result in fire. NEVER
try to extinguish a fire with water, but switch off the
appliance and then cover flame e.g. with a lid or a fire
blanket.
•WARNING: Danger of fire: do not store items on the
cooking surfaces.
• Warning: If the surface is cracked, switch off the
appliance to avoid the possibility of electric shock, for

7
hob surfaces of glass-ceramic or similar material
which protect live parts
•A steam cleaner is not to be used.
•The appliance is not intended to be operated by
means of an external timer or separate remote-control
system.
Congratulations on the purchase of your new Ceramic Hob.
We recommend that you spend some time to read this Instruction / Installation Manual in
order to fully understand how to install correctly and operate it.
For installation, please read the installation section.
Read all the safety instructions carefully before use and keep this Instruction / Installation
Manual for future reference.

8
Product Overview
Model: MEH 772 BL
Top view
Control Panel
1. Heating zone selecting buttons
2. Timer button
3. Power/Timer regulating buttons
4. Dual / Triple ring button
5. Pause button (Stop & Go)
6. Lock / unlock button
7. ON/OFF button
6. Pause button (Stop & Go)
1. 2200/1000w zone
2. 1200w zone
3. 2300/1500/800w zone
4. 1800w zone
5. 1200w zone
6. Glass plate
7. Control panel

9
Model: MEH 902 BL
Top view
Control Panel
1. Heating zone selecting buttons
2. Timer button
3. Power / Timer regulating buttons
4. Dual/triple ring button
5. Pause button (Stop & Go)
6. Lock / unlock button
7. ON/OFF button
1. 2200/1000w zone
3. 1200w zone
4. 2300/1500/800w zone
4. 1800w zone
5. 1200w zone
6. Glass plate
7. Control panel

10
Model: MEH 903 BL
Top view
Control Panel
1. Heating zone selecting buttons
2. Timer button
3. Power / Timer regulating buttons
4. Dual/triple ring button
5. Pause button (Stop & Go)
6. Lock / unlock button
7. ON/OFF button
1. 2300/1500/800w zone
3. 1200w zone
4. 2000/1100w zone
4. 1800w zone
5. 1200w zone
6. Glass plate
7. Control panel

11
Model: MEH 904 BL
Top view
Control Panel
1. Heating zone selecting buttons
2. Timer button
3. Power / Timer regulating buttons
4. Dual/triple ring button
5. Pause button (Stop & Go)
6. Lock / unlock button
7. ON/OFF button
1. 2200/1000w zone
3. 1200w zone
4. 2700/1950/1050w zone
4. 1800w zone
5. 1200w zone
6. Glass plate
7. Control panel

12
Product Information
The microcomputer ceramic cooker hob can meet different kinds of cuisine demands
because of resistance wire heating, micro-computerized control and multi-power selection,
really the optimal choice for modern families.
The ceramic cooker hob centers on customers and adopts personalized design. The hob
has safe and reliable performances, making your life comfortable and enabling to fully
enjoy the pleasure from life.
Before using your New Ceramic Hob
• Read this guide, taking special note of the ‘Safety Warnings’ section.
• Remove any protective film that may still be on your ceramic hob.
Using the Touch Controls
• The controls respond to touch, so you don’t need to apply any pressure.
• Use the ball of your finger, not its tip.
• You will hear a beep each time a touch is registered.
• Make sure the controls are always clean, dry, and that
there is no object (e.g. a utensil or a cloth) covering them.
Even a thin film of water may make the controls difficult to
operate.
Choosing the right Cookware
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits flat against the glass, and is the same
size as the cooking zone. Always centre your pan on the cooking zone.

13
Always lift pans off the ceramic hob – do not slide, or they may scratch the glass.
Using your Ceramic Hob
To start cooking
1. Touch the ON/OFF control.
After power on, the buzzer beeps once, all displays show “ – “ or “ – – “,
indicating that the ceramic hob has entered the state of standby mode.
2. Place a suitable pan on the cooking zone that you wish to use.
• Make sure the bottom of the pan and the surface of the cooking zone
are clean and dry.
3. Touch the Heating zone selecting button of the objective zone, the power level indicator
next to the button will flash “0”.
4. Set a power level by touching the slider sensor from left to right or right to left.
5. Tips
a. If you don’t select a heat zone within 1 minute, the induction hob will automatically
switch off. You will need to start again from step 1.
b. You can modify the power level at any time during cooking.
6. Touch the heating zone selecting button, and then touch the Dual/ triple ring button by
pressing to start the dual or triple zone function. The power level and “ ” or
“ “ will flash alternately.

14
7. When double zone is working, touch the heating zone selection button and then the Dual
ring button to turn off double zone function.
When you have finished cooking
1. Touch the heating zone selecting button that you wish to switch off.
2. Turn the cooking zone off by touching the “0” on the slider.
3. Turn the whole cooktop off by touching the “ON/OFF” control.
4. Beware of hot surfaces
“H” will show which cooking zone is hot to touch. It will disappear when the surface has
cooled down to a safe temperature. It can also be used as an energy saving function if you
want to heat further pans, use the hotplate that is still hot.
Using the Pause function
Pause function makes the hob stop for a while and resume working as its previous setting.
1. When the hob is working, touch the Pause button , all cooking zone indicator will
show “ll”.
All buttons of the hob will be disabled except for ON/OFF, Lock/unlock and Pause buttons.
2. To cancel the pause status, touch the Pause button, the cooking zones will go back to
the previous power.

15
Locking the Controls
• You can lock the controls to prevent unintended use (for example children accidentally
turning the cooking zones on).
• When the controls are locked, all the controls except the ON/OFF control are disabled.
To lock the controls
Touch and hold the Lock/unlock button for 3 seconds
and the hob will be locked. The timer indicator will show
“Lo”.
To unlock the controls
1. Make sure the ceramic hob is turned on.
2. Touch and hold the Lock/unlock button for 3 seconds.
3. You can now start using your ceramic hob.
When the hob is in the lock mode, all the controls are disable except the ON/OFF ,
you can always turn the ceramic hob off with the ON/OFF control in an emergency, but you
shall unlock the hob first in the next operation.
Over-Temperature Protection
A temperature sensor equipped can monitor the temperature inside the ceramic hob. When
an excessive temperature is monitored, the ceramic hob will stop operation automatically.
Over-spillage Protection
Over-spillage protection is a safety protection function. It switch off the hob automatically
within 10s if the water flow to the control panel, while buzzer will beep 1 second.
Residual Heat Warning
When the hob has been operating for some time, there will be some residual
heat. The letter “ H ”appears to warn you to keep away from it.
Auto Shutdown
Auto shut down is a safety protection function for your ceramic hob. It shut down
automatically if ever you forget to turn off your cooking. The default working times for
various power levels are shown in the below table:
Power level
1
2
3
4
5
6
7
8
9
II
Default working timer (hour)
8
8
8
4
4
4
2
2
2
2
Using the Timer

16
You can use the timer in two different ways:
• You can use it as a minute minder. In this case, the timer will not turn any cooking zone
off when the set time is up.
• You can set it to turn one cooking zone off or more than one after the set time is up.
• You can set the timer for up to 99 minutes.
Using the Timer as a Minute Minder
If no cooking zone is selected
1. Make sure the cooktop is turned on.
Note: you can use the minute minder even if you’re not selecting any cooking zones.
2. Touch Timer button, the time indicator will show “00” and the left symbol “0” will start
flashing, touching the slider from left to right (10,20,30…90) or right to left (90,80,70…00)
within 5s to set the tens digit of timer.
Then touch Timer button again within 5s, the left symbol will stop flashing and the right
symbol “0” will start flashing, touching the slider from left to right (00,02,03…09) or right to
left (09,08,07…00) to set the units digit of timer.
3. Cancel the time by touching the Timer button, the left symbol of time indicator will start
flashing, touch the “0” on the slider within 5s. Then touch the Timer button again within 5s,
the left symbol will stop flashing and the right symbol of time indicator will start flashing,
touch the “0” on the slider within 5s.
4. When the time is set, it will begin to count down immediately. The display will show the
remaining time and the timer indicator will flash for 5 seconds.
5. Buzzer will beep for 30 seconds and the timer indicator shows “-
-” when the set time finished.

17
Setting the timer to turn one cooking zone off
1. Touch the Heating zone selecting button of objective zone.
2. Touch Timer button, the time indicator will show “30” and “3” will start flashing, touching
the slider from left to right (10,20,30…90) or right to left (90,80,70…00) within 5s to set the
tens digit of timer.
Then touch Timer button again within 5s, the left symbol of time indicator will stop flashing
and “0” will start flashing, touching the slider from left to right (00,02,03…09) or right to left
(09,08,07…00) to set the units digit of timer.
4. Cancel the timer, touch the Heating zone selecting button of objective zone, then touch
the Timer button, the left symbol of time indicator will start flashing, touch the “0” on the
slider within 5s. Then touch the Timer button again within 5s, the left symbol will stop
flashing and the right symbol of time indicator will start flashing, touch the “0” on the slider
within 5s.
5. When the time is set, it will begin to count down immediately. The
display will show the remaining time and the timer indicator flash for
5 seconds.
NOTE: The red dot next to power level indicator will illuminate
indicating that zone is selected.
6. When cooking timer expires, the corresponding cooking zone will be automatically
switch off and show “H”.
NOTE: If you want to change the time after setting a timer, start from step 1.

18
Setting the timer to turn more than one cooking zone off
1. If set timer to more than one heating zone, the time indicator will show the shortest one.
NOTE: There will be a red dot next to the power level indicators of those cooking zones
which have been set timer.
The red dot which is flashing means the time showed by indicator is for this zone.
If you want to check the remaining time, touch the Heating zone selecting button of
objective zone. The timer indicator shows its time immediately.
(set to 6 minutes)
(set to 2 minutes)
2. When cooking timer expires, the corresponding cooking zone will be switch off
automatically and show “H” .
Care and Cleaning
What?
How?
Important!
Everyday soiling on glass
(fingerprints, marks, stains
left by food or non-sugary
spillovers on the glass)
1. Switch the power to the cooktop
off.
2. Apply a cooktop cleaner while
the glass is still warm (but not
hot!)
3. Rinse and wipe dry with a clean
cloth or paper towel.
4. Switch the power to the cooktop
back on.
• When the power to the cooktop is
switched off, there will be no ‘hot
surface’ indication but the cooking
zone may still be hot! Take
extreme care.
• Heavy-duty scourers, some nylon
scourers and harsh/abrasive
cleaning agents may scratch the
glass. Always read the label to
check if your cleaner or scourer is
suitable.
• Never leave cleaning residue on
the cooktop: the glass may
become stained.

19
Boilovers, melts, and
hot sugary spills on
the glass
Remove these immediately with a
fish slice, palette knife or razor
blade scraper suitable for ceramic
glass cooktops, but beware of hot
cooking zone surfaces:
1. Switch the power to the cooktop
off at the wall.
2. Hold the blade or utensil at a 30°
angle and scrape the soiling or
spill to a cool area of the
cooktop.
3. Clean the soiling or spill up with
a dish cloth or paper towel.
4. Follow steps 2 to 4 for ‘Everyday
soiling on glass’ above.
• Remove stains left by melts and
sugary food or spillovers as soon as
possible. If left to cool on the glass,
they may be difficult to remove or
even permanently damage the glass
surface.
• Cut hazard: when the safety cover
is retracted, the blade in a scraper is
razor-sharp. Use with extreme care
and always store safely and out of
reach of children.
Spillovers on the
touch controls
1. Switch the power to the cooktop
off.
2. Soak up the spill
3. Wipe the touch control area with
a clean damp sponge or cloth.
4. Wipe the area completely dry
with a paper towel.
5. Switch the power to the cooktop
back on.
• The cooktop may beep and turn
itself off, and the touch controls may
not function while there is liquid on
them. Make sure you wipe the touch
control area dry before turning the
cooktop back on.
Hints and Tips
Problem
Possible causes
What to do
The cooktop
cannot
Be turned on.
No power.
Make sure the cooktop is connected to the
power supply and that it is switched on.
Check whether there is a power outage in
your home or area. If you’ve checked
everything and the problem persists, call a
qualified technician.
The touch
controls are
unresponsive.
The controls are locked.
Unlock the controls. See section ‘Using your
ceramic cooktop’ for instructions.
The touch
controls are
difficult to operate.
There may be a slight film of water
over the controls or you may be
using the tip of your finger when
touching the controls.
Make sure the touch control area is dry and
use the ball of your finger when touching the
controls.
The glass is being
scratched.
Rough-edged cookware.
Unsuitable, abrasive scourer or
cleaning products being used.
Use cookware with flat and smooth bases.
See ‘Choosing the right cookware’.
See ‘Care and cleaning’.
Some pans make
crackling or
clicking noises.
This may be caused by the
construction of your cookware
(layers of different metals vibrating
differently).
This is normal for cookware and
does not indicate a fault.
