1 General information
This manual contains important instructions for the safe operation of the product. Read and
follow the safety instructions and all other instructions. Keep the manual for future reference.
Make sure that it is available to all those using the product. If you sell the unit, please make
sure that the buyer also receives this manual.
Our products are subject to a process of continuous development. Thus, they are subject to
change.
General information
speaker stand
4

1.1 Further information
On our website (www.thomann.de) you will find lots of further information and details on the
following points:
Download This manual is also available as PDF file for you to download.
Keyword search Use the search function in the electronic version to find the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the
customer service will gladly assist you.
General information
BS-2222 Pro Set
5

1.2 Notational conventions
This manual uses the following notational conventions:
The individual steps of an instruction are numbered consecutively. The result of a step is
indented and highlighted by an arrow.
Example:
1. Switch on the device.
2. Press [Auto].
ðAutomatic operation is started.
3. Switch off the device.
1.3 Symbols and signal words
In this section you will find an overview of the meaning of symbols and signal words that are
used in this manual.
Instructions
General information
speaker stand
6

Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
CAUTION! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in minor injury if it
is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – danger zone.
General information
BS-2222 Pro Set
7

2 Safety notes
This speaker stand is used for stable fixing and height-adjustable installation of loudspeaker
cabinets. Use the product only as described in this user manual. Any other use or use under
other operating conditions is considered to be improper and may result in personal injury or
property damage. No liability will be assumed for damages resulting from improper use.
This product may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
product only if they are supervised or instructed by a person who is responsible for their safety.
Intended use
Safety notes
speaker stand
8

DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are properly disposed of and are not in
the reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the product. They could swallow the pieces and choke!
Never let children play unattended with the product.
CAUTION!
Danger of tipping when transported under load
If the stand is moved without having removed the installed device, the stand may
tip over and cause injuries and property damage.
Remove the installed device before transporting the stand.
Safety
Safety notes
BS-2222 Pro Set
9

CAUTION!
Danger of tipping on unsuitable surfaces
When the speaker stand is installed on soft or uneven ground, the stand may tip
over and cause injuries and property damage.
Install the stand only on even and solid surfaces.
CAUTION!
Danger of tipping due to overload
In case of overload, the stand may tip over and cause injuries and property
damage.
Never exceed the maximum load capacity specified for the stand.
Safety notes
speaker stand
10

3 Features
Special characteristics:
nProfessional steel speaker stand
n2-pcs. set including carrying bag
nExtendible up to a height of about 2 m
nCentric load capacity up to 40 kg
n35 mm pipe diameter at the pole mount
nTransport length when folded: 1.30 m
Features
BS-2222 Pro Set
11

4 Operating
Unpack and check carefully there is no transportation damage before using the product. Keep
the equipment packaging. To fully protect the product against vibration, dust and moisture
during transportation or storage use the original packaging or your own packaging material
suitable for transport or storage, respectively.
CAUTION!
Danger of tipping due to overload
In case of overload, the stand may tip over and cause injuries and property
damage.
Never exceed the maximum load capacity specified for the stand.
Operating
speaker stand
12

CAUTION!
Danger of tipping on unsuitable surfaces
When the speaker stand is installed on soft or uneven ground, the stand may tip
over and cause injuries and property damage.
Install the stand only on even and solid surfaces.
CAUTION!
Danger of tipping when transported under load
If the stand is moved without having removed the installed device, the stand may
tip over and cause injuries and property damage.
Remove the installed device before transporting the stand.
Operating
BS-2222 Pro Set
13

NOTICE!
Possible staining
The plasticiser contained in the rubber feet of this product may possibly react
with the coating of your parquet, linoleum, laminate or PVC floor and after some
time cause permanent dark stains.
In case of doubt, do not put the rubber feet directly on the floor, but use felt-pad
floor protectors or a carpet.
Operating
speaker stand
14

Follow the procedure described below for each of both tripods:
1. Unfold the feet of the tripod until the cross braces are in a horizontal position.
2. Fix this position with the safety screw on the slider to which the three feet are attached.
3. Press the locking lever and loosen the locking screw on the extension tube.
4. Pull out the extension tube to the desired height and release the locking lever so that it
can snap into the corresponding grid hole.
5. Fix the position of the extension tube with the safety bolt on the extension tube.
6. Flange the speaker box on top of the extension tube. The weight of the speaker box to
be set up must not exceed the maximum centric load of 40 kg.
Setting up
Operating
BS-2222 Pro Set
15

1. Remove the speaker box.
2. Press the locking lever while loosening the locking screw on the extension tube.
3. Slide the extension tube all the way down and let the locking lever snap into the corre‐
sponding grid hole.
4. Fix the position of the extension tube with the safety bolt on the extension tube.
5. Loosen the safety screw on the slider to which the three feet are attached.
6. Fold up the feet of the tripod.
Dismounting
Operating
speaker stand
16

5 Technical specifications
Permitted centric loadability 40 kg per tripod
Minimum support height 130 cm
Maximum support height 200 cm
Tripod flange 35 mm diameter
Weight 3.6 kg per tripod
Transport length when folded 130 cm
Colour Black
Technical specifications
BS-2222 Pro Set
17

6 Protecting the environment
For the transport and protective packaging, environmentally friendly materials have been
chosen that can be supplied to normal recycling.
Ensure that plastic bags, packaging, etc. are properly disposed of.
Do not just dispose of these materials with your normal household waste, but make sure that
they are collected for recycling. Please follow the notes and markings on the packaging.
Disposal of the packaging mate‐
rial
Protecting the environment
speaker stand
18
