Millennium MICRO-SSX User manual

1
Millennium RC presents…Build Kit
TM
Biplane
Flying weight: Approx. 6 -7oz. (with recommended setup)
Wing Span: 21 1/2"
Wing Area: 240 sq. inches
Wing Loading: 3.6 oz./ sq. ft.
Length: 18”
Introduction:
The MicroSSX™Biplane Build Kit is a fun-to-fly and build classic biplane version of the popular Millennium
R/C MicroSSX airplane. The MicroSSX™Biplane has the same wing span and length as the original Micro
SSX™, and is similar in that it is aerobatic and can handle the wind fairly well, but the Biplane is capable of
sustaining slower flight due to its lower wing loading.
Adult supervision recommended for children 15 and under. R/C Airplanes should be flown following safety
guidelines provided by the AMA (Academy of Model Aeronautics).
CAUTION: This is not a toy!
Recommendations:
1. Read through each step before starting assembly.
2. After removing all the pieces from packaging, inspect to make sure there are no broken or missing parts.
3. Check off each completed step to help keep from losing your place.
©2008 Millennium R/C All Rights reserved

List of Provided Kit Parts:
1. 1 decal set
2. 4 balsa sticks 3/32x3/32x24
3. 4 balsa sticks 1/16x3/32x24
4. 2 sheets 1/8 balsa laser cut parts
5. 2 sheets 1/16 balsa laser cut parts
6. 1 sheet 1/32 balsa laser cut parts
7. 3 sheets plywood laser cut parts
8. 6Dubro micro control horns
9. 2 Dubro micro light wheels
10. 2 Dubro wheel retainers
11. 3 1-foot pieces of .031” piano wire for push
rods, aileron linkage and tail skid
12. Preformed wire landing gear
13. 6 control horns
14. 2 micro light wheels
15. 2 micro wheel retainers
16. 15” Wrapped carbon fuselage
17. Carbon fiber struts
18. Velcro pads
19. Velcro “One Wrap” Battery strap (RED)
20. Double-stick foam tape (Used to hold speed
control in position)
21. 8 # 0 -¼ sheet metal screws (Servos & wing
adjustment)
22. 2 # 1 – ¼ sheet metal screws (Motor)
Additional Items Required:
1. Cyanoacrylate or CA Glue (thin and thick)
2. Hobby knife
3. 220-grit sandpaper
4. Sanding block
5. Hinge tape (recommend 3M Scotch ™¾”
Transparent Tape)
6. Ruler
7. Square
8. Razor saw
9. Hand drill or small drill with #56 (.046”) drill
bit.
10. 1/16” drill bit.
11. Micro screwdriver set
12. Micro-receiver (recommend Castle Creations
Berg)
13. Motor (recommend Hacker A10-12S brushless
outrunner motor, 2900 Kv)
14. Speed control (recommend Hacker X-5, 5 amps,
or equivalent)
15. Propeller (as recommended by motor
manufacturer)
16. Four servos (less than 7 grams each,
recommended. Ideal is 4 grams)
17. Battery (recommend 2-cell lithium polymer
battery, 300-480 mAh) Please adhere to
manufacturer’s safety guidelines.
Recommendations:
1. Read through each step before starting assembly.
2. After removing all the pieces from packaging,
inspect to make sure there are no broken or
missing parts.
3. Check off each completed step to help keep
from losing your place.
Check out the Micro SSX Biplane build thread
on R/C Groups with full-color pictures and
instruction updates.
http://www.rcgroups.com/millennium-rc-510/
Disclaimer:
Millennium R/C assumes no
responsibility for any accident or
injury to persons or damage to
property.
MicroSSX™Biplane Build Kit Assembly Instructions Rev. 2

3
IMPORTANT:
DO NOT GLUE UNTIL INSTRUCTED TO DO SO!
Assembly Instructions:
1. Cut-don’t break, the balsa and plywood parts from
the parts sheets. Breaking the parts out of the sheets
can damage the parts. The top of each wing is
identified by the installation of the main spar. The
main spar is always installed from the TOP. You
may sand away excess material from break-away. If
desired, may also sand away any laser burn.
2. Build 2 W1B ribs from W1B, W1b and W1bb.
(Glue) Fig 1
Figure 1
3. Build 2 W2B ribs from W2B, W2b and W2bb.
(Glue) Fig 2
Figure 2
4. Build 2 frames from LE, TE and W2C. (Glue) Fig 3
Figure 3
5. Install Ribs W1A, W1B, W6 and W7 and Ply wood
pieces P11/P11A, P9 and P10 for the bottom wing
(No Glue) Fig 4
Figure 4
6. Install Ribs W2A, W2B, W6 and W7 Ply wood
pieces P22/P16, P9 and P10 for the top wing. (No
Glue) Fig 5
If you should find a part missing or damaged, or have any questions about assembly, please contact us at the address below:
Millennium R/C
12859 Lower River Blvd., Orlando, FL 32828
Phone: [phone] / Fax: [phone]
E-mail: [email protected]

4
Figure 5
7. Install spar crutch W10 and remaining stringers.
Tack glue ribs to TE. Set wings on flat surface,
square all parts and glue with thin CA. Fig 6
Figure 6
8. Install wing tips.W8 and W9. Slice the two parts in
half to install. It will be necessary to bevel W9
where it joins with W8. (Glue) Fig 7
Figure 7
9. Install 1/32 deck D2 on upper wing top. (Glue) Fig 8
Figure 8
10. Install 1/32 deck D3 on lower wing top. Fig. 9
(Glue)
Figure 9
11. Install 1/32 deck D1 on lower wing bottom. Fig. 10
(Glue)
Figure 10

5
12. Build Vertical/horizontal stabilizer and
rudder/elevator as shown in Fig11 and 12 on
attached sheet. (See BP-HS.WMF and BP-
VS.WMF) 2 Plywood pieces “PS1” should be
doubled-up to make the leading edge of the elevator.
13. Bevel bottom elevator 45 °, one side of rudder and
bottom of ailerons. Remember to mirror the ailerons.
14. Using a fine sandpaper, sand all tail surfaces, round
all edges, and taper leading edges of all control
surfaces, including ailerons.
15. Cover wings and tail with light model covering such
as Solite or World Models Lightex. Apply decals as
desired.
16. Cut openings in covering. Gray areas indicate
uncovered openings. Fig 13, 14 and 15. Make sure
wings are true and flat after covering. A twisted
wing can be corrected withopposite twist.
Figure 13
Figure 14
Figure 15
17. Assemble receiver hatch. Fig 16 H1,H2 and H3
Figure 16
18. Assemble tail mount. Fig 17 P1 P2 and P3
Figure 17
19. Build the battery mount and two servo mounts.
Make sure parts are square. Fig 18 P5, P17 and P18

6
Figure 18
20. Assemble landing gear block. Fig 19 P19 P20 and
P21
Figure 19
21. The biplane has 8-0.060” diameter carbon struts. 4
wing struts, 2 front and 2 center cross struts.
a. Wing struts: 4.840”
b. Front struts: 2.675”
c. Center cross struts: 5.000” (May need to be
trimmed during installation)
To cut the carbon rods, use a sharp Exacto knife
and a rolling action.
The cross struts are installed last.
Make sure they bottom out in the slots. Also
make sure each set is exactly the same length.
Do not install them until all warps are ironed out
of the wings and told to do so in the instructions.
Set them aside for now.
Final Assembly
22. Tape a length of Scotch tape™ along the rear
trailing edge of the horizontal stabilizer and secure
with your finger (either side is fine). Now, flip the
stabilizer and place on a work surface. See diagram
below:
23. Now, take the elevator. You will see that the
elevator has a ‘beveled’ edge. This is important in
creating the hinge. Ensure that the beveled edge is
pointing up, and while holding at a 45° angle, place
up against the trailing edge of the horizontal
stabilizer and secure the hinge tape to the elevator
with your finger. See diagrams below:
24. Turn the stabilizer assembly over, and carefully fold
the elevator back onto the stabilizer.
25. Tape another length of Scotch tape™ along the
bottom hinge line and secure with your finger.
26. Fold the elevator back to normal position. Test the
hinge by pulling gently on the control surface. Cut
off any excess tape overhanging the stabilizer sides.
27. Repeat the steps 21. thru 26. for the rudder and
ailerons.

7
28. Build the servo tray. Fig 20
Figure 20
Figure 21
29. (Fig 21) Slide P12A onto the fuselage stick and
glue 6-1/4” from the tail end. Slide P12 onto the
fuselage and leave it loose. Slide the tail mount
onto the fuselage end and align it so that it is
square with the flat edge of P12A. Glue it and
allow the glue to dry. Secure P12 to P12A with
2 #0-1/4 screw. Do not glue P12 to P12A. Slide
the servo assembly onto the front of the
fuselage, align it so that it is square with the flat
edge of P12A and glue it with CA glue.
30. Slide the fuselage assemblythrough the front
lower wing mount. P12 should be glued into the
slot on the trailing edge of the wing. Align the
wing so that it is parallel to the tail mount. Glue
the tail section vertical and horizontal stabilizer
together so they are square. Glue the tail
assembly to the tail mount. Make sure it is
parallel with the wing. Fig 22, 23 and 24
Figure 22
Figure 23
Figure 24
31. Slide the landing gear assembly onto the
fuselage. Align it parallel to all other
components. It should be 2-1/32” from the front
end of the fuselage. Fig 25

8
Figure 25
32. Install four 4.840” carbon wing struts. Make
sure struts are fully inserted into the wing before
gluing with thin CA. Fig 24
33. Install two 2.675” front struts. Make sure struts
are fully inserted before gluing with thin CA.
Fig 25
34. Install upper wing,making sure struts are fully
inserted into the wing before gluing with thin
CA. Also install the carbon cross struts. Fig 26
Figure 26
Millennium R/C
12859 Lower River Blvd. Orlando, FL 32828
Phone: [phone]
Fax: [phone]
www.millenniumrc.com
[email protected]
More detailed motor and radio configurations may be
available on our RCgroups build thread and on our
website.
35. Install battery mount. Fig 27
Figure 27
36. Install motor mount. The kit includes mounts to
accommodate different motor types. Fig. 27
37. Install wheels, tail skid, control horns, pushrods
and radio equipment.
38. The model should be balanced at the CG 1.2”
back from the top wing spar. Incidence must be
adjusted to “0” using the adjustable rear wing
saddle P12.
Control throws: Rudder Full deflection
Elevator 20 degrees
Ailerons 20 degrees
More extreme throws can be used as desired.
ENJOY YOUR NEW MICRO SSX
BIPLANE FROM MILLENNIUM R/C!
