Milwaukee M18 FUEL F2LM18 User manual

OPERATOR'S MANUAL
Cat. No.
M18 F2LM18
WARNING
To reduce the risk of injury, user must read and understand operator's manual.
M18 FUEL™ 18" (457 MM) SELF-PROPELLED DUAL BATTERY
LAWN MOWER

2
IMPORTANT SAFETY
INSTRUCTIONS
WARNING
Read all safety warnings, instruc-
-
tions provided with this power tool. Failure to
follow all instructions listed below may result in
Save all
warnings and instructions for future reference.
The term "power tool" in the warnings refers to your
mains-operated(corded)powertoolorbattery-oper-
ated (cordless) power tool.
WORK AREA SAFETY
ELECTRICAL SAFETY
•Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
•Do not operate power tools in explosive atmo-
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
•Keep childrenandbystandersaway whileoperat-
ingapower tool.Distractionscancauseyoutolose
control.
PERSONAL SAFETY
•Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools.
reduce risk of electric shock.
•Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
•Do not expose power tools to rain or wet condi-
tions. Water entering a power tool will increase the
risk of electric shock.
•Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
movingparts.Damagedorentangledcordsincrease
the risk of electric shock.
•When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
•
•Stay alert, watch what you are doing and use
commonsensewhen operating apowertool. Do
notuseapower tool whileyouare tired orunder
A
moment of inattention while operating power tools
may result in serious personal injury.
•Use personal protective equipment. Always
wear eye protection. Protective equipment such
POWER TOOL USE AND CARE
•Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.
•Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
•
•If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
•Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignoretoolsafetyprinciples.Acarelessactioncan
cause severe injury within a fraction of a second.
•
•
Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions and
the work to be performed. Use of the power tool
result in a hazardous situation.
•Keep handles and grasping surfaces dry, clean
andfreefrom oilandgrease.Slipperyhandlesand
graspingsurfacesdo notallowforsafehandlingand
control of the tool in unexpected situations.
•Donot forcethepowertool.Usethecorrectpower
tool for your application. The correct power tool
will do the job better and safer at the rate for which
it was designed.
•Do not use the power tool if the switch does not
Any power tool that cannot be
controlledwiththeswitch is dangerousandmustbe
repaired.
•Disconnect theplugfrom the powersourceand/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools.
Suchpreventive safety measures reduce the risk of
starting the power tool accidentally.
•Store idlepowertoolsoutofthereach ofchildren
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
powertool.Powertoolsare dangerousinthe hands
of untrained users.
•Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition that
have the power tool repaired before use. Many
accidents are caused by poorly maintained power
tools.
If operating a power tool in a damp location is
unavoidable, use a residual current device
(RCD) protected supply. Use of a RCD reduces
the risk of electric shock.
Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
•Preventunintentionalstarting.Ensurethe switch
sourceand/or batterypack,pickinguporcarrying
the tool.
the switch or energising power tools that have the
switch on invites accidents.
as a dust mask, non-skid safety shoes, hard hat or
hearing protection used for appropriate conditions
will reduce personal injuries.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.

3
SERVICE
SPECIFIC SAFETY RULES FOR
LAWN MOWERS
DANGER
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
•Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorised service providers.
•When battery pack is not in use, keep it away
fromothermetal objects, likepaperclips,coins,
keys,nails,screwsor other smallmetalobjects,
that can make a connection from one terminal
to another. Shorting the battery terminals together
•Under abusiveconditions,liquid may beejected
from the battery; avoid contact. If contact ac-
cidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation
or burns.
•
•Followallcharginginstructionsanddonotcharge
the battery pack or tool outside the temperature
Charging
rangemaydamage thebatteryandincreasetherisk
Preparation
DANGER
Do not operate the mower unless
the grass bag, mulch plug, or rear-
side discharge are correctly installed and
functioningproperly. Checkfrequentlyfor signs
of wear or deterioration and replace as needed.
•Keep safety devices (rear door, discharge at-
tachment, bail, etc.) in place and working.
•Inspect area and remove debris before mowing.
Remove all stones, sticks, wires, bones, and
otherforeignobjects. Beware ofthrownobjects.
•Keep childrenout ofthe mowingarea andunder
the watchful care of a responsible adult other
than the operator.
•
•Never allow children to operate the machine.
•Use extracare whenapproachingblindcorners,
shrubs, trees, or other objects that may block
your view of a child.
DANGER
Keephandsand feetawayfrom the
blades. Do not reach under blade
guard. Keep clear of the discharge opening at
all times.
•Do notdirectdischarge material towardanyone.
•
Avoid discharging material against a wall or
obstruction. Material may ricochet back toward
the operator.
•Disengage theself-propelledmechanism before
starting the lawn mower blade.
•Never attemptto makeawheelheightadjustment
while the bail bar is pulled.
•
•Do notexpose towateroroperateon wetground.
Do not use in rain.
•Always wear eye protection and appropriate
footwear. Dress properly - Wear long pants and
boots.Donotwearshorts,sandals,orgobarefoot.
Operation
•
•Avoid holes, ruts, bumps, rocks, or other hid-
den hazards. Uneven terrain could overturn the
machine,orcause operator tolosetheir balance
or footing.
•Stop the blade when crossing gravel drives,
walks, or roads.
•
•
•
•
Do not use a battery pack or tool that is
damaged or modified. Damaged or modified
batteries may exhibit unpredictable behaviour
resulting in fire, explosion or risk of injury.
•Do not expose a battery pack or tool to fire or
excessive temperature. Exposure to fire or
temperature above 130°C (265°F) may cause explosion.
Be alert and turn the lawn mower off if a child
enters the area.
Do not pull the lawn mower backward unless
absolutely necessary. If you must back the lawn
mower away from a wall or obstruction, first look
down and behind you to avoid tripping or pulling
the lawn mower over your feet.
Mow only in daylight or in good artificial light.
Always be sure of footing; keep a firm hold on the
handle and walk, never run.
After striking a foreign object, stop the motor,
remove the battery packs, thoroughly inspect the
lawn mower for any damage, and repair the
damage (or take to an authorised service centre)
before restarting and operating the lawn mower.
Use extra care while operating machine with a
grass bag. A heavy grass bag can affect the
stability of the machine.
Shut the motor off and wait until the blade comes
to a complete stop before removing the grass bag
or before unclogging the rear side discharge
chute.
When using electric lawn mowers,
basic safety precautions should
always be followed to reduce the risk of serious
injury or death. User must read, understand,
and follow operator's manual and all labels on
the lawn mower carefully. Be thoroughly
familiar with the controls and the proper use of
the lawn mower before use. This cutting
machine is capable of amputating hands and
feet and throwing objects. Failure to observe all
safety instructions could result in serious injury
or death. If the lawn mower should start to vibrate
abnormally, stop the lawn mower and check
immediately for the cause. Vibration is
generally a warning of trouble.
BATTERY TOOL USE AND CARE
manufacturer.A chargerthatissuitablefor onetype
with another battery pack.
battery packs.
Objects struck by the lawn mower blade can be
thrown and cause severe injuries.
•
•Tragic accidents can occur if the operator is not
alert to the presence of children. Children are
often attracted to the machine and the mowing
activity. Never assume that children will remain
where you last saw them.
Keep bystanders away. Do not operate within
30 m of children, bystanders, or animals. Stop
the lawn mower if anyone enters the area.

4
Keep hands and feet away from the
blades.
Safety alert symbol
Objects may be thrown or ricochet
in all directions.
Read operator's manual
Wear eye protection
Do not operate in rain or wet
conditions
Do not reach under blade guard
Do not stare at the operating light
source.
Risk of electric shock
Start Blade button
•
•
•
•
•Close battery cover during use.
•Do not stare at LED lights.
Maintenance
•Check the blade and all assembly and adjust-
ment bolts and fasteners at frequent intervals
for proper tightness.
•
•
•
Inspect grass bag frequently and replace with
recommended replacement if there are signs of
wear or deterioration.
•
•
Use caution when servicing blades. Wrap the
blade(s) or wear gloves. Replace damaged
blades. Do not repair damaged blade or alter
blade mounting holes.
Sharpen a dull blade equally at each end to
maintain the balance.
Cleanthebladethoroughlyandcheckitsbalance
by supporting it horizontally on a nail through
its centre hole. The nail should also be in a
horizontal position. If either end of the blade
rotates downward, remove some metal from the
heavy or lower end until the blade is balanced.
It is balanced when neither end drops.
•
•
•
•
•
Do not leave the machine running unattended.
Always park on level ground and release the
bail bar.
Do not wash with a hose; avoid getting water in
the lawn mower and electrical connections.
Use identical MILWAUKEE®replacement
blades only.
Replace the blade if it is bent or cracked. An
unbalanced blade causes vibration that could
damage the lawn mower or cause personal
injury.
Store idle lawn mower indoors. When not in
use, lawn mower should be stored in an
indoor, dry, and locked-up place – out of reach
of children. Remove batteries for storage.
Always use common sense and be cautious
when using lawn mowers. It is not possible to
anticipate every situation that could result in a
dangerous outcome. Do not use this lawn mower
if you do not understand these operating
instructions or you feel the work is beyond your
capability; contact MILWAUKEE®Tool or a trained
professional for additional information or training.
Maintain labels and nameplates. These carry
important information. If unreadable or missing,
Do not operate within 30 m of
children, bystanders, or animals.
Do not wash with a hose; avoid
getting water in the lawn mower and
electrical connections.
• Operation on a Slope:
•Mow across slopes, not up and down. Do not
operate on steep slopes.
•Exercise extremecaution whenchanging direc-
tion on slopes.Avoid starting and stopping on
slopes.Avoidmaking suddenchanges inspeed
or direction. Make turns slowly and gradually.
•
•Do not operate machine under any condition
where traction, steering, or stability is in
question. Tyres could slide even if the wheels
are stopped.
Use caution while operating near dropoffs.
SYMBOLOGY
RPM
Volts
Direct Current
Revolutions per Minute
V
FOR FUTURE USE.
READ AND SAVE ALL INSTRUCTIONS
contact a MILWAUKEE®service facility for a
replacement.
ADDITIONAL BATTERY SAFETY RULES
WARNING
WARNING
To reduce the risk of fire, personal
injury, and product damage due to
a short circuit, never immerse your tool, battery
pack or charger in fluid or allow a fluid to flow inside
them. Corrosive or conductive fluids, such as
seawater, certain industrial chemicals, and bleach
or bleach-containing products, etc., can cause a
short circuit. Do not charge non-rechargeable
batteries.
Remove batteries before maintaining,
assembling, adjusting, cleaning, unclogging,
or when lawn mower not in use.
Use two people whenever it is necessary to lift
or carry the lawn mower. Lawn mower is heavy.
Lift with legs, not back.
Maintain lawn mower with care – Keep cutting
edges sharp and clean for best and safest
performance.
Mow across slopes, not up and
down. Do not operate on steep
slopes.
Disconnect battery before
maintenance

20
5
2
3
4
5
6
7
89
10
11
13
1
12
15
5
14
SPECIFICATIONS
Volts............................................................ 36V DC
Cat. No.............................................. M18 F2LM18
Battery Type.................................................M18™
Charger Type................................................M18™
Deck Size ......................................... 18" (457 mm)
Cutting Height Range.... 25 mm - 102 mm (1" - 4")
Blade RPM ......................................... 3,300-3,800
Recommended Ambient
Self-propel driving speed...................... 0-6.4 km/h
Weight ....................................................... 32.8 kg
Operating Temperature................... -17°C to 51°C
18" (457 mm) High Lift
Lawn Mower Blade............................... 49162787
MILWAUKEE®Lawn Mower Blades
High Lift mode ON/OFF button
LED Light ON/OFF button
Higher MAX Speed
Lower MAX Speed
Protected against splashing water.
IPX4
Two M18™ Battery Packs Required
Regulatory Compliance Mark
(RCM). This product meets
applicable regulatory requirements.
Do not dispose of electric tools
together with household waste
material. Electric tools and
electronic equipment that have
reached the end of their life must be
collected separately and returned to
an environmentally compatible
recycling facility.
Mower Blade......................................... 49162786
18" (457 mm) Lawn
FUNCTIONAL DESCRIPTION
1. LED light
2. Front lift handle
3. Battery compartment
4. Blade height adjustment lever (obscured)
5. Handle height locking pin
6. Handle locking knob
7. Start blade button
8. Bail bar
9. Variable speed self-propelled paddle
10.Handle
11.Self-propel speed dial
LED light On/Off button
High lift mode On/Off button12.
13.
14.Fuel gauge
15.Rear lift handle
16.Mulch plug
17.Rear side discharge chute
18.Grass bag frame
19.Grass bag
20.Rear door
6
19
18
16 17

6
ASSEMBLY
Unfolding/Folding the Handle
1. To unfold the handle, turn both handle height
locking pins (1) to the unlock position (freeing the
pins from the folded position holes).
1
2
Unlocked
Position
position holes (3).
3
2. Lift the handle towards an upright position (2).
3. Align the handle next to one of the three upright
position (engaging the pins).
4. Turn both handle height locking pins to the lock
4Locked
Position
5. To fold the handle, complete steps in reverse
order. Remove battery packs before storing.
Grass Bag
the frame; start with one side and work around,
shaping the bag as necessary.
2. Hook all four sides onto the frame. Hooks go
through frame opening and wrap outward.
Setting Blade Height
Beforeeachuse,setthecuttingpositionto the height
best suited for the lawn.
To adjust the blade height:
1. Remove battery packs.
2.
Installing Discharge Attachments
Mulch Plug
Alwaysusethemulchplugunlessanotherdischarge
attachment is being used (grass bag or rear side
discharge chute).
1. Remove battery packs.
2. Lift rear door.
3.
4. Lower the rear door; the rear door will fully close.
5.
To raise or lower the blade height, move the
height adjustment lever to the desired height
(increments of 13 mm) and set into the
corresponding notch.
Slide the mulch plug into the body of the lawn
mower.
To remove, lift rear door and pull plug away from
the lawn mower.
Higher
Maximum 102 mm (4")
Minimum 25 mm (1")
Lower

7
1.
2.
3.
Grass Bag
When using the grass bag, remove the mulch plug.
Inspect grass bag frequently and replace with rec-
ommended replacement if there are signs of wear
or deterioration.
5.
4.
6.
Lower the grass bag so bag covers the rear dis-
charge opening.
Lower the rear door; the rear door will rest on the
grass bag.
Toremove,liftreardoorandpullgrassbagupand
away from the lawn mower.
Rear Side Discharge Chute
When using the discharge chute, remove the mulch
plug.Inspectdischargechutefrequentlyandreplace
with recommended replacement if there are signs of
wear or deterioration.
4.
1. Remove battery packs.
2. Lift rear door.
3. Align the centre notch of the discharge chute to
5.
6.
7.
•
Fuel Gauge
Fuel Gauge totheUse remaining runpack's determine the lowest battery
time. When less than 10% of
place the
as battery pack on the charger and charge
Immediately after using the battery pack, the Fuel
needed.
times. When the battery reaches 0% charge, 1 light
-
tery packs.
If the Fuel Gauge doesn't appear to be working,
may display a lower charge than it will if
a few minutes later. The battery cells "re-
some of their charge after resting.
Gauge
checked
cover"
Gently push down on the discharge chute to
ensure it is fully seated.
the one on the lawn mower housing.
Slide the discharge chute into the body of the
lawn mower until the white embossed arrows of
the discharge chute are aligned with those on the
lawn mower housing.
Lower the rear door; the rear door will rest on the
discharge chute.
To remove, lift rear door and pull discharge chute
away from the lawn mower.
WARNING
Always remove the battery packs
Removing/Inserting the Batteries
To remove the batteries, push in the release
buttons and pull the battery packs away from the
lawn mower.
pack.
•If one battery pack is completely discharged, the
lawn mower will not function, even if the second
battery pack is charged.
any time the lawn mower is not in
use.
To insert the batteries, slide the packs into the
body of the lawn mower. Make sure they latch
securely into place.
NOTE: The lawn mower requires two charged
battery packs to operate.
•The lawn mower will not work with only one battery
Lights
Fuel Gauge SolutionDiagnosis
Lights 1 - 4
Solid Remaining run time Continue working
1 Light, Less than
10% run time
left
Prepare to charge
pack
1 Light, End of
discharge Charge pack
Remove battery packs.
Lift rear door.
Place the grass bag onto the lawn mower so the
bag's metal hooks rest on the metal bar of the
lawn mower housing.
For best results, use with (2) MILWAUKEE®
M18TM REDLITHIUM-ION HIGH OUTPUT 8.0AH
or 12.0AH Batteries.

8
WARNING
Read and follow all safety warn-
ings, instructions, illustrations,
death.
OPERATION
always wear proper eye
protection marked to comply with
AS/NZS 1337.1.
Wear appropriate personal protective equipment
including safety glasses and protective footwear.
Before Mowing
•
•
•
LED Light
Setting Self-Propel Speed Dial
•Ensure grass is dry and there is enough light
for good visibility.
•Inspect rear door, discharge attachment, bail,
etc.,forproperoperation,location,anddamage.
•Set the height adjustment.
•Ensure children and bystanders are at least
30 m away.
•Ensurethebladestopswhenbailbarisreleased.
•Ensure the self-propel stops when the self-
propel paddle is released.
•Set the speed dial at a speed that you can
comfortably follow when walking behind the
lawn mower. Start at a low speed. Be prepared
for sudden changes in speed when adjusting
the speed dial. You may lose control of the
lawn mower if the speed dial is set at a speed
that is too fast for your walking pace.
High Lift Mode
High Lift Mode increases blade speed for
better bagging or mulching job. Press the
High Lift Mode button to toggle between ON/OFF.
TheLEDnext to the button will light when in High Lift
mode.
Start Blade Button
bar against the handle.
1. To start the blade, pull and hold the bail
2. Rotate the dial to set the maximum speed of the
Mowing
self-propel feature, from "1" for minimum speed
up to "5" for the maximum speed.
When using the self-propel feature,
ensure that the speed dial is set at a
speed that you can comfortably
follow when walking behind the
lawn mower.
1. Start at a low speed. Be prepared
for sudden changes in speed
when adjusting the speed dial.
WARNING
Keep hands and feet away
2.
3.
4.
from the blades. Do not
reach under blade guard. Keep clear of
the discharge opening at all times.
•
•
•
•
•Do notdirectdischarge material towardanyone.
Avoid discharging material against a wall or
obstruction. Material may ricochet back toward
the operator.
•
•
•
4.
5.
1. Insert battery packs. The fuel gauge LEDs will
light and display the batteries' remaining charge.
2. Set the maximum self-propel speed (1-5).
3. Set the blade speed (Low/High).
6.
7.
9.
8. To stop the blade, release the bail bar.
Turn the LED light on, if needed.
To starttheblade,pull and holdthebailbaragainst
the handle and press the Start Blade button.
To engage the self-propel feature, press down on
the self-propel paddle. Press less for a slower
speed, or more for a faster speed, up to the
maximum speed set by the self-propel speed
dial. To disengage the self propel feature, release
the paddle.
NOTE: The self-propel feature is available for
manoeuvring whenever the lawn mower is
powered; the blade does not need to be running.
If necessary, adjust blade speed or maximum
self-propel speed. When adjusting maximum
self-propel speed (1-5), be prepared for a sudden
change in speed.
WARNING
Press the Start Blade button. The blade
will start and the button will lock inward.
To stop the blade, release the bail bar. The blade
will stop and the button will unlock.
If the blade will not start, check battery charge
and that the lawn mower is in proper operating
position.
When finished mowing, remove batteries for
storage.
WARNING
To reduce the risk of injury,
Look down and behind before and while mov-
ing backwards. Do not mow in reverse unless
absolutely necessary.
Always be sure of footing; keep a firm hold on
the handle and walk, never run.
Avoid holes, ruts, bumps, rocks, or other
hidden hazards. Uneven terrain could overturn
the lawn mower, or cause operator to lose their
balance or footing.
Stop the blade when crossing gravel drives,
paths, or roads or if someone enters the area.
After striking a foreign object, stop the motor,
remove the battery packs, thoroughly inspect
the lawn mower for any damage, and repair the
damage before restarting and operating the
lawn mower.
If the lawn mower should start to vibrate
abnormally, stop the lawn mower and check
immediately for the cause. Vibration is
generally a warning of trouble.
Shut the motor off and wait until the blade
comes to a complete stop before removing the
grass bag or before unclogging the rear side
discharge chute.
Ensure enough light for good visibility; lights
may not provide sufficient visibility in all
conditions. Press the LED Light button to
toggle between ON/OFF.
Check the area and clear it of objects that can
be thrown by the lawn mower.
Avoid discharge of material toward roads,
footpaths, bystanders and the like. Also, avoid
discharging material against a wall or
obstruction, which may cause the material to
ricochet back toward the operator.
Plan the mowing pattern to avoid mowing up or
down slopes. Do not mow steep slopes.
You may lose control of the lawn
mower if the speed dial is set at a
speed that is too fast for your walking pace.
Release the self-propel paddle and bail bar if you
cannot keep up with the lawn mower.

9
Operation On A Slope
WARNING
Slopes are a major factor
related to slip and fall ac-
cidents that can result in severe injury.
•
•Operation on slopes requires extra caution. If
you feel unsure on a slope, do not mow it.
•Mow across slopes, not up and down. Do not
operate on steep slopes.
•
Always be sure of your footing. A slip and fall
cancauseserious personalinjury. Ifyoufeel you
are losing your balance, release the bail lever
immediately.
Exercise extreme caution when changing direc-
tion on slopes. Avoid starting and stopping on
slopes.Avoid making sudden changes in speed
or direction. Make turns slowly and gradually. -
ments.
•
•
•Avoid holes, ruts, rocks, hidden objects, or
bumps which can cause you to slip or trip. Tall
grass can hide obstacles. Remove all objects
such as rocks, tree limbs, etc., which could be
tripped over or thrown by the blade.
Emptying the Grass bag
1. Remove battery packs.
2. Lift rear door.
3.
4. Emptygrassclippingsand reinstall the grass bag.
Do not operate lawn mower under any
condition where traction, steering, or stability
is in question. Tyres could slide even if the
wheels are stopped.
Use extra care while operating lawn mower
with a grass bag. A heavy grass bag can affect
the stability of the lawn mower.
Lift the grass bag by its handle and pull up and
away from lawn mower.
MAINTENANCE
WARNING
WARNING
•
Transportation
•
•Keep tie-downs away from the controls and
adjustment levers.
•Remove grass bag before transport.
To reduce the risk of injury,
always unplug the charger and
remove the battery packs from the charger or
lawn mower before performing any
maintenance. Never disassemble the lawn
mower, battery pack or charger. Contact a
MILWAUKEE®service facility for ALL repairs.
Remove the battery packs before
transporting the lawn mower.
Always clear the area of obstructions before
transporting.
Use full width ramps for loading and unloading
a lawn mower for transport. If full width ramp is
not available, use two people to lift the lawn
mower.
Do not transport lawn mower in the upright
position.
MAINTENANCE
Removing/Installing the Cutting Blade
1. Remove battery packs.
2. Turn the lawn mower on its side.
3.
4.
5. Removethebladenut,washer, shear plate,blade,
blade motor fan, and spacer.
6. Use only mild soap and a damp cloth to clean the
components to remove grass clippings, leaves,
dirt, and any other accumulated debris.
Shear Plate
Square Washer
Blade
Nut
Blade
Blade Motor Fan
Spacer
Spindle
7.
Remove the blade nut by turning it anti-clockwise
(as viewed from bottom of lawn mower) using a
18 mm wrench or socket.
Inspect the blade. Discard the blade if it is bent,
cracked, or damaged. Sharpen the blade
according to "Sharpening the Cutting Blade".
WARNING
An unbalanced blade can cause
vibration that could damage the
lawn mower or cause personal injury.
Wedge a block of wood between the blade and
the lawn mower deck to prevent the blade from
turning.

Sharpening the Cutting Blade
WARNING
8.
9.
1. Clean the blade.
2. Sharpen a dull blade equally at each end to main-
shavings to achieve a sharp blade.
3. Check the blade's balance by supporting it on a
nail through its centre hole. Hold the nail horizon-
tally. If either end of the blade rotates downward,
remove some metal from the heavy or lower end.
Repeat until the blade is balanced evenly on the
nail. It is balanced when neither end drops.
Maintaining Lawn Mower
Keep cutting edges sharp and
clean for best and safest
performance. Use a recommended
MILWAUKEE®replacement blade only. Use
caution when servicing blade. Wrap the blade or
wear gloves. Replace damaged blade. Do not
repair damaged blade or alter blade mounting
holes.
Keep your lawn mower in good repair by adopting a
regular maintenance program. Inspect your lawn
mower for issues such as undue noise,
misalignment or binding of moving parts, breakage
of parts, or any other condition that may affect the
lawn mower operation. Return the lawn mower to a
MILWAUKEE®service facility for repair.
If the lawn mower does not start or operate at full
power with a fully charged battery pack, clean the
contacts on the battery pack. If the lawn mower still
does not work properly, return the lawn mower to a
MILWAUKEE®service facility for repairs.
10
WARNING
Storage
Cleaning
WARNING
Use only recommended accesso-
NOTICE
Repairs
ACCESSORIES
ries. Others may be hazardous.
To reduce the risk of personal
injury and damage, never
immerse your lawn mower, battery pack or
charger in liquid or allow a liquid to flow inside
them.
Do not wash with a hose;
avoid getting water in lawn
mower and electrical connections.
Clean dust and debris from any vents. Keep lawn
mower clean, dry and free of oil or grease. Use only
mild soap and a damp cloth to clean, since certain
cleaning agents and solvents are harmful to plastics
and other insulated parts. Some of these include
gasoline, turpentine, lacquer thinner, paint thinner,
chlorinated cleaning solvents, ammonia and
household detergents containing ammonia. Do not
wash with a hose; avoid getting water in lawn
mower and electrical connections. Never use
flammable or combustible solvents around lawn
mowers.
For repairs, return the lawn mower to the nearest
authorised service centre.
For a complete listing of accessories, go online to
milwaukeetool.com.au / milwaukeetool.co.nz or
contact a distributor.
Reattach the spacer and blade motor fan after
cleaning. Install a new or sharpened blade. The
circle and triangle holes of the blade must align
onto the circle and triangle posts of the blade
motor fan. The shear plate edges must wrap
around the blade. Attach the square washer and
blade nut.
Tighten the blade nut using a 18 mm wrench or
socket.
When not in use, lawn mower should be stored in
an indoor dry and locked-up place – out of reach of
children. Remove batteries for storage. When lawn
mower stored in upright position, ensure both
handle adjustment knobs are in the locked position
with pins engaged.
