Mimosa A6 User manual
A6
For instructions, videos and help visit:
Para obtener videos y ayuda, visite:
Pour obtenir des vidéos et de l’aide, visitez:
support.mimosa.co
Para obtener instrucciones, videos y ayuda, visite:
Pour obtenir des instructions, des vidéos et de l’aide, visitez:
setup.mimosa.co
Additional Required & Optional Items
• 10 AWG (5.26 mm2) ground cable with
pre-terminated ring terminal
• Small at head type screwdriver (for
direct 48VDC power terminal)
• 15, 13 and 10 mm socket or adjustable
wrench for mounting assembly
• Power Option A: 18 AWG 2-pin wire for
direct power wiring 48VDC input
• Power Option B: Shielded CAT6/6A &
compatible PoE injector (refer to A6
datasheet specications)
• Optional: SFP+ ber (non-copper)
module and preferred optical cabling
• Optional: 19mm (3/4”) exible conduit/
hose tubing and hose-clamps for
additional cable protection
1. Mounting
Tightly attach the supplied sliding & pivot
brackets to mounting pole in desired up or
downtilt orientation.
2. Grounding
Attach 10 AWG ground wire with pre-termi-
nated ring terminal to the grounding screw.
20
151050
20
15
10
5
0
PWR ETH 1
10
AWG
3. Dedicated 48VDC Power
• Thread an 18 AWG 2-pin cable through
one the supplied IP67 gland/cap.
• Strip the wire jackets approximately
6-7mm, and attach to the supplied
power connector terminals (+/- indicated
in diagram). Tighten the terminal screws.
Note: reverse polarization will not dam-
age the device, however proper +/- wir-
ing is required to apply power.
• Insert and snap the power plug and
cable into the PWR port.
• Attach and tighten gland, attach the
rubber insert to the cable, pushing it into
the gland, then tighten the cap.
4. Gigabit Ethernet or PoE
Insert a shielded CAT6/6A Ethernet cable
through the IP67 gland/cap. Connect the
cable to ETH port. Attach and tighten gland,
attach the rubber insert to the cable, pushing
it into the gland, then tighten the cap.
f
d
e
PWR ETH 1
18
AWG
b
a
c
PoE powering is optional and can be used as
primary or as redundant/backup power to
the 48VDC. Ethernet connection is NOT
required if SFP+ optical ber is being used.
5. Optional Flexible Conduit
The provided IP67 gland caps are designed
to accommodate optional 19mm (3/4”)
outdoor hose conduit/tubing, and hose-type
clamps to secure the tubing. Both can be
procured at most hardware stores.
a
b
c
d
CAT 6/6E
PWR ETH 1 2
6. Optional SFP+ Optical Fiber
Two SFP+ ports are provided to accom-
modate standard SFP+ 10 Gbps optical
modules, and bult-in switching between the
ports for interconnectivity to other devices.
Visit support for additional SFP+ module and
conguration information.
7. Seal All Unused Ports
For any unused ports, tightly screw in the
supplied port sealing caps to maintain envi-
ronmental integrity of the system.
8. Unlock and Congure
Visit start.mimosa.co to unlock the device.
Warnings, Warranty, Compliance
& Regulatory Statements
Mimosa by Airspan (“Mimosa”) products are provided by Airspan
Networks Inc. (“Airspan”).
Export Control
These commodities, technology, or software were exported from the
United States in accordance with the Export Administration Regulations.
Diversion contrary to U.S. law is prohibited.
Important Safety and Handling Information
Failure to follow any of the safety instructions in this guide, instructions
on any Airspan provided packaging, and heed WARNINGS (indicated
by ), could result in re, electric shock, other injury or death, and
incur damage to this product or other property and void the product’s
Limited Warranty.
There are no End User serviceable parts inside the equipment.
Read all operating and safety instructions contained herein and accom-
panying the product as provided by Airspan:
Electrical Safety Information
Do not operate this product in any location that can be sub-
merged by water.
Do not install or maintain this product during the presence of an
electrical storm to avoid risk of electric shock from lightning. Fail-
ure to ground the device according to the included instructions
using shielded CAT6/6A Ethernet cabling could lead to serious
injury or death.
Installation of the product must comply with local and national
electrical codes.
Power specications for connected devices are indicated on the
device’s own label or documentation. Connecting to any power
source that does not meet the voltage, frequency and current
requirements listed may damage the power supply or product,
and pose a re hazard.
Mandatory Grounding Instructions
IMPORTANT: Failure to properly ground the device using the following
instructions will violate the limited warranty conditions in this document.
Required Step 1- Direct Grounding on the Device:
A minimum grounding wire of 10 AWG (5.26 mm2) with a secured
grounding terminal, and shorter in length than 1 meter is required. It is
NOT supplied with the product.
1. Ensure that NO power is being supplied to the product.
2. Locate the Ground point screw next to the Ground icon on the
device
3. Remove the provided Ground Screw
4. Thread the ground wire terminal and ground wire meeting the above
specications over the screw removed in the previous step.
5. Replace and tighten the screw with the threaded ground terminal
and cable at the product Ground point.
6. Secure the other end of the grounding cable to the properly
grounded structure (pole, tower, mast, etc.) meeting local and national
electrical regulations and codes.
End User Product Warranty
The product is warranted against defects in material, and workmanship
for a period of twenty four (24) months from the date of rst unlock
of the product. Please go to www.mimosa.co/warranty to determine
whether your product is in warranty.
The sole responsibility of Airspan under this warranty shall be limited to
the repair or replacement of in-warranty defective product, at Airspan’s
sole option.
Out of warranty products shipped to Airspan will not be returned.
This warranty does not cover costs associated with the removal and/or
reinstallation of the product for repair nor for any parts that are readily
replaced in normal use.
Airspan or its designated partner will repair or replace product found to
be defective during the dened warranty period.
The End User is responsible for delivering defective product in
accordance with the Return Material Authorization (RMA) processes
published at www.mimosa.co/legal/RMA
Limitation of Warranty
The product warranty is invalidated if the RMA product is altered or
otherwise tampered with in a manner that modies the product from
its original shipping conguration and/or form factor, and could violate
the End User’s authority to operate the equipment, unless said activity
was performed by or with the written authorization of an Airspan
representative.
Modications include:
(a) External surfaces that have been painted, labeled, or otherwise
modied from the original shipping condition.
(b) Modications of the product with third party hardware, rmware,
and/or software.
(c) Any product subjected to abnormal physical or electric stress,
including, but not limited to, lightning strikes, negligence, accident,
or misuse.
(d) Any product damaged due to incorrect installation, including,
but not limited to, improper product mounting, cabling meeting
minimum requirements in this manual, cabling defects or connection
to power.
(e) Failure induced by connected third party products.
Installing the product outdoors without the use of minimum CAT6/6A
shielded Ethernet cable, improper grounding, or failure to ground
the product as instructed in this guide will void the End User Product
warranty.
Disclaimer
EXCEPT FOR ANY EXPRESS WARRANTIES PROVIDED HEREIN,
AIRSPAN AND ITS SUBSIDIARIES, LICENSORS AND AFFILIATES (
COLLECTIVELY, “AIRSPAN”), AND ANY THIRD PARTY DATA, SERVICE,
SOFTWARE AND HARDWARE PROVIDERS MAKE NO OTHER REPRE-
SENTATION OR WARRANTY OF ANY KIND AND HEREBY DISCLAIM
ALL WARRANTIES, EXPRESS OR IMPLIED, STATUTORY OR OTHER-
WISE, INCLUDING, BUT NOT LIMITED TO, ANY REPRESENTATIONS
OR WARRANTIES OF DESIGN, MERCHANTABILITY, ACCURACY,
QUALITY OF SERVICE OR RESULTS, AVAILABILITY, QUIET ENJOY-
MENT, FITNESS FOR A PARTICULAR PURPOSE, NON-INFRINGEMENT
AND ANY WARRANTIES ARISING FROM ANY COURSE OF DEALING,
USAGE OR TRADE PRACTICE IN CONNECTION WITH SUCH PROD-
UCTS AND SERVICES. YOU ACKNOWLEDGE THAT NEITHER AIRSPAN
NOR ITS THIRD PARTY PROVIDERS CONTROL YOUR EQUIPMENT OR
THE TRANSFER
OF DATA OVER COMMUNICATIONS FACILITIES, INCLUDING THE
INTERNET, AND THAT THE PRODUCTS AND SERVICES PROVIDED
BY AIRSPAN MAY BE SUBJECT TO LIMITATIONS, INTERRUPTIONS,
DELAYS, CANCELLATIONS AND OTHER PROBLEMS INHERENT IN
THE USE OF COMMUNICATIONS FACILITIES. AIRSPAN AND ANY
THIRD PARTY PROVIDERS ARE NOT RESPONSIBLE FOR ANY INTER-
RUPTIONS, DELAYS, CANCELLATIONS, DELIVERY FAILURES, DATA
LOSS, CONTENT CORRUPTION, PACKET LOSS, OR OTHER DAMAGE
RESULTING FROM ANY OF THE FOREGOING.
IN ADDITION, AIRSPAN MAKES NO WARRANTY OR UNDERTAK-
ING, AND MAKES NO REPRESENTATION OF ANY KIND THAT THE
LICENSED PRODUCTS WILL MEET YOUR REQUIREMENTS, ACHIEVE
ANY INTENDED RESULTS, BE COMPATIBLE OR WORK WITH ANY
OTHER APPLICATIONS, SYSTEMS OR SERVICES, OPERATE WITHOUT
INTERRUPTION, MEET ANY PERFORMANCE OR RELIABILITY STAN-
DARDS, BE ERROR FREE OR THAT ANY ERRORS OR DEFECTS CAN
OR WILL BE CORRECTED, OR THAT THE LICENSED PRODUCTS ARE
NOT VULNERABLE TO FRAUD OR UNAUTHORIZED USE.
Limitation of Liability
EXCEPT TO THE EXTENT PROHIBITED BY THE LAWS IN YOUR
JURISDICTION, IN NO EVENT WILL AIRSPAN OR ITS SUPPLIERS OR
LICENSORS BE LIABLE FOR SPECIAL, INCIDENTAL, CONSEQUENTIAL
OR OTHER DAMAGES (INCLUDING LOST PROFIT, LOST DATA, OR
DOWNTIME COSTS), NOR FOR DAMAGES BASED ON UNAUTHO-
RIZED USE OR ACCESS, ARISING OUT OF THE USE, INABILITY TO
USE, OR THE RESULTS OF USE OF THE PRODUCT, WHETHER BASED
IN WARRANTY, CONTRACT, TORT OR OTHER LEGAL THEORY,
AND WHETHER OR NOT ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. IN NO EVENT SHALL AIRSPAN, ITS SUPPLIERS’ OR ITS LI-
CENSORS’ DIRECT LIABILITY EXCEED THE VALUE OF THE LICENSED
PRODUCTS GIVING RISE TO SUCH LIABILITY. THESE LIMITATIONS
SHALL APPLY NOTHWITHSTANDING ANY FAILURE OF ESSENTIAL
PURPOSE OF ANY LIMITED REMEDY. IN NO EVENT SHALL AIRSPAN
BE RESPONSIBLE FOR DAMAGES OR CLAIMS OF ANY NATURE OR
DESCRIPTION RELATING TO NETWORK PERFORMANCE, INCLUDING
COVERAGE, YOUR SELECTION OF AIRSPAN PRODUCTS FOR YOUR
PARTICULAR APPLICATION AND/OR FAILURE OF AIRSPAN PROD-
UCTS TO MEET GOVERNMENT OR REGULATORY REQUIREMENTS.
Some legal jurisdictions do not allow exclusions of implied warranties or
conditions, or for the exclusion or limitation of liability for incidental or
consequential damages, so the above exclusion may not apply to you.
You may have other rights specic to your legal jurisdiction. EXCEPT
TO THE EXTENT ALLOWED BY THE LAW OF YOUR JURISDICTION,
THESE WARRANTY TERMS DO NOT EXCLUDE, RESTRICT OR
MODIFY, AND ARE IN ADDITION TO, ANY MANDATORY STATUTORY
RIGHTS APPLICABLE TO YOU IN THE LICENSE OF ANY EMBEDDED
SOFTWARE. The United Nations Convention on Contracts for the Inter-
national Sale of Goods shall not apply to any transactions regarding the
UNLOCK REQUIRED
This device requires
unlocking prior to
use. For all unlocking
instructions and
options prior to onsite
installation, please visit:
mimosa.co/start
5 & 6 GHz Fixed Wireless
WiFi 6E PTMP Access Point
Hose Tubing
3/4” (19 mm)
ETH 1 2
Hose Clamp
A6
For instructions, videos and help visit:
Para obtener videos y ayuda, visite:
Pour obtenir des vidéos et de l’aide, visitez:
support.mimosa.co
Para obtener instrucciones, videos y ayuda, visite:
Pour obtenir des instructions, des vidéos et de l’aide, visitez:
setup.mimosa.co
Additional Required & Optional Items
• 10 AWG (5.26 mm2) ground cable with
pre-terminated ring terminal
• Small at head type screwdriver (for
direct 48VDC power terminal)
• 15, 13 and 10 mm socket or adjustable
wrench for mounting assembly
• Power Option A: 18 AWG 2-pin wire for
direct power wiring 48VDC input
• Power Option B: Shielded CAT6/6A &
compatible PoE injector (refer to A6
datasheet specications)
• Optional: SFP+ ber (non-copper)
module and preferred optical cabling
• Optional: 19mm (3/4”) exible conduit/
hose tubing and hose-clamps for
additional cable protection
1. Mounting
Tightly attach the supplied sliding & pivot
brackets to mounting pole in desired up or
downtilt orientation.
2. Grounding
Attach 10 AWG ground wire with pre-termi-
nated ring terminal to the grounding screw.
20
151050
20
15
10
5
0
PWR ETH 1
10
AWG
3. Dedicated 48VDC Power
• Thread an 18 AWG 2-pin cable through
one the supplied IP67 gland/cap.
• Strip the wire jackets approximately
6-7mm, and attach to the supplied
power connector terminals (+/- indicated
in diagram). Tighten the terminal screws.
Note: reverse polarization will not dam-
age the device, however proper +/- wir-
ing is required to apply power.
• Insert and snap the power plug and
cable into the PWR port.
• Attach and tighten gland, attach the
rubber insert to the cable, pushing it into
the gland, then tighten the cap.
4. Gigabit Ethernet or PoE
Insert a shielded CAT6/6A Ethernet cable
through the IP67 gland/cap. Connect the
cable to ETH port. Attach and tighten gland,
attach the rubber insert to the cable, pushing
it into the gland, then tighten the cap.
f
d
e
PWR ETH 1
18
AWG
b
a
c
PoE powering is optional and can be used as
primary or as redundant/backup power to
the 48VDC. Ethernet connection is NOT
required if SFP+ optical ber is being used.
5. Optional Flexible Conduit
The provided IP67 gland caps are designed
to accommodate optional 19mm (3/4”)
outdoor hose conduit/tubing, and hose-type
clamps to secure the tubing. Both can be
procured at most hardware stores.
a
b
c
d
CAT 6/6E
PWR ETH 1 2
6. Optional SFP+ Optical Fiber
Two SFP+ ports are provided to accom-
modate standard SFP+ 10 Gbps optical
modules, and bult-in switching between the
ports for interconnectivity to other devices.
Visit support for additional SFP+ module and
conguration information.
7. Seal All Unused Ports
For any unused ports, tightly screw in the
supplied port sealing caps to maintain envi-
ronmental integrity of the system.
8. Unlock and Congure
Visit start.mimosa.co to unlock the device.
Warnings, Warranty, Compliance
& Regulatory Statements
Mimosa by Airspan (“Mimosa”) products are provided by Airspan
Networks Inc. (“Airspan”).
Export Control
These commodities, technology, or software were exported from the
United States in accordance with the Export Administration Regulations.
Diversion contrary to U.S. law is prohibited.
Important Safety and Handling Information
Failure to follow any of the safety instructions in this guide, instructions
on any Airspan provided packaging, and heed WARNINGS (indicated
by ), could result in re, electric shock, other injury or death, and
incur damage to this product or other property and void the product’s
Limited Warranty.
There are no End User serviceable parts inside the equipment.
Read all operating and safety instructions contained herein and accom-
panying the product as provided by Airspan:
Electrical Safety Information
Do not operate this product in any location that can be sub-
merged by water.
Do not install or maintain this product during the presence of an
electrical storm to avoid risk of electric shock from lightning. Fail-
ure to ground the device according to the included instructions
using shielded CAT6/6A Ethernet cabling could lead to serious
injury or death.
Installation of the product must comply with local and national
electrical codes.
Power specications for connected devices are indicated on the
device’s own label or documentation. Connecting to any power
source that does not meet the voltage, frequency and current
requirements listed may damage the power supply or product,
and pose a re hazard.
Mandatory Grounding Instructions
IMPORTANT: Failure to properly ground the device using the following
instructions will violate the limited warranty conditions in this document.
Required Step 1- Direct Grounding on the Device:
A minimum grounding wire of 10 AWG (5.26 mm2) with a secured
grounding terminal, and shorter in length than 1 meter is required. It is
NOT supplied with the product.
1. Ensure that NO power is being supplied to the product.
2. Locate the Ground point screw next to the Ground icon on the
device
3. Remove the provided Ground Screw
4. Thread the ground wire terminal and ground wire meeting the above
specications over the screw removed in the previous step.
5. Replace and tighten the screw with the threaded ground terminal
and cable at the product Ground point.
6. Secure the other end of the grounding cable to the properly
grounded structure (pole, tower, mast, etc.) meeting local and national
electrical regulations and codes.
End User Product Warranty
The product is warranted against defects in material, and workmanship
for a period of twenty four (24) months from the date of rst unlock
of the product. Please go to www.mimosa.co/warranty to determine
whether your product is in warranty.
The sole responsibility of Airspan under this warranty shall be limited to
the repair or replacement of in-warranty defective product, at Airspan’s
sole option.
Out of warranty products shipped to Airspan will not be returned.
This warranty does not cover costs associated with the removal and/or
reinstallation of the product for repair nor for any parts that are readily
replaced in normal use.
Airspan or its designated partner will repair or replace product found to
be defective during the dened warranty period.
The End User is responsible for delivering defective product in
accordance with the Return Material Authorization (RMA) processes
published at www.mimosa.co/legal/RMA
Limitation of Warranty
The product warranty is invalidated if the RMA product is altered or
otherwise tampered with in a manner that modies the product from
its original shipping conguration and/or form factor, and could violate
the End User’s authority to operate the equipment, unless said activity
was performed by or with the written authorization of an Airspan
representative.
Modications include:
(a) External surfaces that have been painted, labeled, or otherwise
modied from the original shipping condition.
(b) Modications of the product with third party hardware, rmware,
and/or software.
(c) Any product subjected to abnormal physical or electric stress,
including, but not limited to, lightning strikes, negligence, accident,
or misuse.
(d) Any product damaged due to incorrect installation, including,
but not limited to, improper product mounting, cabling meeting
minimum requirements in this manual, cabling defects or connection
to power.
(e) Failure induced by connected third party products.
Installing the product outdoors without the use of minimum CAT6/6A
shielded Ethernet cable, improper grounding, or failure to ground
the product as instructed in this guide will void the End User Product
warranty.
Disclaimer
EXCEPT FOR ANY EXPRESS WARRANTIES PROVIDED HEREIN,
AIRSPAN AND ITS SUBSIDIARIES, LICENSORS AND AFFILIATES (
COLLECTIVELY, “AIRSPAN”), AND ANY THIRD PARTY DATA, SERVICE,
SOFTWARE AND HARDWARE PROVIDERS MAKE NO OTHER REPRE-
SENTATION OR WARRANTY OF ANY KIND AND HEREBY DISCLAIM
ALL WARRANTIES, EXPRESS OR IMPLIED, STATUTORY OR OTHER-
WISE, INCLUDING, BUT NOT LIMITED TO, ANY REPRESENTATIONS
OR WARRANTIES OF DESIGN, MERCHANTABILITY, ACCURACY,
QUALITY OF SERVICE OR RESULTS, AVAILABILITY, QUIET ENJOY-
MENT, FITNESS FOR A PARTICULAR PURPOSE, NON-INFRINGEMENT
AND ANY WARRANTIES ARISING FROM ANY COURSE OF DEALING,
USAGE OR TRADE PRACTICE IN CONNECTION WITH SUCH PROD-
UCTS AND SERVICES. YOU ACKNOWLEDGE THAT NEITHER AIRSPAN
NOR ITS THIRD PARTY PROVIDERS CONTROL YOUR EQUIPMENT OR
THE TRANSFER
OF DATA OVER COMMUNICATIONS FACILITIES, INCLUDING THE
INTERNET, AND THAT THE PRODUCTS AND SERVICES PROVIDED
BY AIRSPAN MAY BE SUBJECT TO LIMITATIONS, INTERRUPTIONS,
DELAYS, CANCELLATIONS AND OTHER PROBLEMS INHERENT IN
THE USE OF COMMUNICATIONS FACILITIES. AIRSPAN AND ANY
THIRD PARTY PROVIDERS ARE NOT RESPONSIBLE FOR ANY INTER-
RUPTIONS, DELAYS, CANCELLATIONS, DELIVERY FAILURES, DATA
LOSS, CONTENT CORRUPTION, PACKET LOSS, OR OTHER DAMAGE
RESULTING FROM ANY OF THE FOREGOING.
IN ADDITION, AIRSPAN MAKES NO WARRANTY OR UNDERTAK-
ING, AND MAKES NO REPRESENTATION OF ANY KIND THAT THE
LICENSED PRODUCTS WILL MEET YOUR REQUIREMENTS, ACHIEVE
ANY INTENDED RESULTS, BE COMPATIBLE OR WORK WITH ANY
OTHER APPLICATIONS, SYSTEMS OR SERVICES, OPERATE WITHOUT
INTERRUPTION, MEET ANY PERFORMANCE OR RELIABILITY STAN-
DARDS, BE ERROR FREE OR THAT ANY ERRORS OR DEFECTS CAN
OR WILL BE CORRECTED, OR THAT THE LICENSED PRODUCTS ARE
NOT VULNERABLE TO FRAUD OR UNAUTHORIZED USE.
Limitation of Liability
EXCEPT TO THE EXTENT PROHIBITED BY THE LAWS IN YOUR
JURISDICTION, IN NO EVENT WILL AIRSPAN OR ITS SUPPLIERS OR
LICENSORS BE LIABLE FOR SPECIAL, INCIDENTAL, CONSEQUENTIAL
OR OTHER DAMAGES (INCLUDING LOST PROFIT, LOST DATA, OR
DOWNTIME COSTS), NOR FOR DAMAGES BASED ON UNAUTHO-
RIZED USE OR ACCESS, ARISING OUT OF THE USE, INABILITY TO
USE, OR THE RESULTS OF USE OF THE PRODUCT, WHETHER BASED
IN WARRANTY, CONTRACT, TORT OR OTHER LEGAL THEORY,
AND WHETHER OR NOT ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. IN NO EVENT SHALL AIRSPAN, ITS SUPPLIERS’ OR ITS LI-
CENSORS’ DIRECT LIABILITY EXCEED THE VALUE OF THE LICENSED
PRODUCTS GIVING RISE TO SUCH LIABILITY. THESE LIMITATIONS
SHALL APPLY NOTHWITHSTANDING ANY FAILURE OF ESSENTIAL
PURPOSE OF ANY LIMITED REMEDY. IN NO EVENT SHALL AIRSPAN
BE RESPONSIBLE FOR DAMAGES OR CLAIMS OF ANY NATURE OR
DESCRIPTION RELATING TO NETWORK PERFORMANCE, INCLUDING
COVERAGE, YOUR SELECTION OF AIRSPAN PRODUCTS FOR YOUR
PARTICULAR APPLICATION AND/OR FAILURE OF AIRSPAN PROD-
UCTS TO MEET GOVERNMENT OR REGULATORY REQUIREMENTS.
Some legal jurisdictions do not allow exclusions of implied warranties or
conditions, or for the exclusion or limitation of liability for incidental or
consequential damages, so the above exclusion may not apply to you.
You may have other rights specic to your legal jurisdiction. EXCEPT
TO THE EXTENT ALLOWED BY THE LAW OF YOUR JURISDICTION,
THESE WARRANTY TERMS DO NOT EXCLUDE, RESTRICT OR
MODIFY, AND ARE IN ADDITION TO, ANY MANDATORY STATUTORY
RIGHTS APPLICABLE TO YOU IN THE LICENSE OF ANY EMBEDDED
SOFTWARE. The United Nations Convention on Contracts for the Inter-
national Sale of Goods shall not apply to any transactions regarding the
UNLOCK REQUIRED
This device requires
unlocking prior to
use. For all unlocking
instructions and
options prior to onsite
installation, please visit:
mimosa.co/start
5 & 6 GHz Fixed Wireless
WiFi 6E PTMP Access Point
Hose Tubing
3/4” (19 mm)
ETH 1 2
Hose Clamp
A6
For instructions, videos and help visit:
Para obtener videos y ayuda, visite:
Pour obtenir des vidéos et de l’aide, visitez:
support.mimosa.co
Para obtener instrucciones, videos y ayuda, visite:
Pour obtenir des instructions, des vidéos et de l’aide, visitez:
setup.mimosa.co
Additional Required & Optional Items
• 10 AWG (5.26 mm2) ground cable with
pre-terminated ring terminal
• Small at head type screwdriver (for
direct 48VDC power terminal)
• 15, 13 and 10 mm socket or adjustable
wrench for mounting assembly
• Power Option A: 18 AWG 2-pin wire for
direct power wiring 48VDC input
• Power Option B: Shielded CAT6/6A &
compatible PoE injector (refer to A6
datasheet specications)
• Optional: SFP+ ber (non-copper)
module and preferred optical cabling
• Optional: 19mm (3/4”) exible conduit/
hose tubing and hose-clamps for
additional cable protection
1. Mounting
Tightly attach the supplied sliding & pivot
brackets to mounting pole in desired up or
downtilt orientation.
2. Grounding
Attach 10 AWG ground wire with pre-termi-
nated ring terminal to the grounding screw.
20
151050
20
15
10
5
0
PWR ETH 1
10
AWG
3. Dedicated 48VDC Power
• Thread an 18 AWG 2-pin cable through
one the supplied IP67 gland/cap.
• Strip the wire jackets approximately
6-7mm, and attach to the supplied
power connector terminals (+/- indicated
in diagram). Tighten the terminal screws.
Note: reverse polarization will not dam-
age the device, however proper +/- wir-
ing is required to apply power.
• Insert and snap the power plug and
cable into the PWR port.
• Attach and tighten gland, attach the
rubber insert to the cable, pushing it into
the gland, then tighten the cap.
4. Gigabit Ethernet or PoE
Insert a shielded CAT6/6A Ethernet cable
through the IP67 gland/cap. Connect the
cable to ETH port. Attach and tighten gland,
attach the rubber insert to the cable, pushing
it into the gland, then tighten the cap.
f
d
e
PWR ETH 1
18
AWG
b
a
c
PoE powering is optional and can be used as
primary or as redundant/backup power to
the 48VDC. Ethernet connection is NOT
required if SFP+ optical ber is being used.
5. Optional Flexible Conduit
The provided IP67 gland caps are designed
to accommodate optional 19mm (3/4”)
outdoor hose conduit/tubing, and hose-type
clamps to secure the tubing. Both can be
procured at most hardware stores.
a
b
c
d
CAT 6/6E
PWR ETH 1 2
6. Optional SFP+ Optical Fiber
Two SFP+ ports are provided to accom-
modate standard SFP+ 10 Gbps optical
modules, and bult-in switching between the
ports for interconnectivity to other devices.
Visit support for additional SFP+ module and
conguration information.
7. Seal All Unused Ports
For any unused ports, tightly screw in the
supplied port sealing caps to maintain envi-
ronmental integrity of the system.
8. Unlock and Congure
Visit start.mimosa.co to unlock the device.
Warnings, Warranty, Compliance
& Regulatory Statements
Mimosa by Airspan (“Mimosa”) products are provided by Airspan
Networks Inc. (“Airspan”).
Export Control
These commodities, technology, or software were exported from the
United States in accordance with the Export Administration Regulations.
Diversion contrary to U.S. law is prohibited.
Important Safety and Handling Information
Failure to follow any of the safety instructions in this guide, instructions
on any Airspan provided packaging, and heed WARNINGS (indicated
by ), could result in re, electric shock, other injury or death, and
incur damage to this product or other property and void the product’s
Limited Warranty.
There are no End User serviceable parts inside the equipment.
Read all operating and safety instructions contained herein and accom-
panying the product as provided by Airspan:
Electrical Safety Information
Do not operate this product in any location that can be sub-
merged by water.
Do not install or maintain this product during the presence of an
electrical storm to avoid risk of electric shock from lightning. Fail-
ure to ground the device according to the included instructions
using shielded CAT6/6A Ethernet cabling could lead to serious
injury or death.
Installation of the product must comply with local and national
electrical codes.
Power specications for connected devices are indicated on the
device’s own label or documentation. Connecting to any power
source that does not meet the voltage, frequency and current
requirements listed may damage the power supply or product,
and pose a re hazard.
Mandatory Grounding Instructions
IMPORTANT: Failure to properly ground the device using the following
instructions will violate the limited warranty conditions in this document.
Required Step 1- Direct Grounding on the Device:
A minimum grounding wire of 10 AWG (5.26 mm2) with a secured
grounding terminal, and shorter in length than 1 meter is required. It is
NOT supplied with the product.
1. Ensure that NO power is being supplied to the product.
2. Locate the Ground point screw next to the Ground icon on the
device
3. Remove the provided Ground Screw
4. Thread the ground wire terminal and ground wire meeting the above
specications over the screw removed in the previous step.
5. Replace and tighten the screw with the threaded ground terminal
and cable at the product Ground point.
6. Secure the other end of the grounding cable to the properly
grounded structure (pole, tower, mast, etc.) meeting local and national
electrical regulations and codes.
End User Product Warranty
The product is warranted against defects in material, and workmanship
for a period of twenty four (24) months from the date of rst unlock
of the product. Please go to www.mimosa.co/warranty to determine
whether your product is in warranty.
The sole responsibility of Airspan under this warranty shall be limited to
the repair or replacement of in-warranty defective product, at Airspan’s
sole option.
Out of warranty products shipped to Airspan will not be returned.
This warranty does not cover costs associated with the removal and/or
reinstallation of the product for repair nor for any parts that are readily
replaced in normal use.
Airspan or its designated partner will repair or replace product found to
be defective during the dened warranty period.
The End User is responsible for delivering defective product in
accordance with the Return Material Authorization (RMA) processes
published at www.mimosa.co/legal/RMA
Limitation of Warranty
The product warranty is invalidated if the RMA product is altered or
otherwise tampered with in a manner that modies the product from
its original shipping conguration and/or form factor, and could violate
the End User’s authority to operate the equipment, unless said activity
was performed by or with the written authorization of an Airspan
representative.
Modications include:
(a) External surfaces that have been painted, labeled, or otherwise
modied from the original shipping condition.
(b) Modications of the product with third party hardware, rmware,
and/or software.
(c) Any product subjected to abnormal physical or electric stress,
including, but not limited to, lightning strikes, negligence, accident,
or misuse.
(d) Any product damaged due to incorrect installation, including,
but not limited to, improper product mounting, cabling meeting
minimum requirements in this manual, cabling defects or connection
to power.
(e) Failure induced by connected third party products.
Installing the product outdoors without the use of minimum CAT6/6A
shielded Ethernet cable, improper grounding, or failure to ground
the product as instructed in this guide will void the End User Product
warranty.
Disclaimer
EXCEPT FOR ANY EXPRESS WARRANTIES PROVIDED HEREIN,
AIRSPAN AND ITS SUBSIDIARIES, LICENSORS AND AFFILIATES (
COLLECTIVELY, “AIRSPAN”), AND ANY THIRD PARTY DATA, SERVICE,
SOFTWARE AND HARDWARE PROVIDERS MAKE NO OTHER REPRE-
SENTATION OR WARRANTY OF ANY KIND AND HEREBY DISCLAIM
ALL WARRANTIES, EXPRESS OR IMPLIED, STATUTORY OR OTHER-
WISE, INCLUDING, BUT NOT LIMITED TO, ANY REPRESENTATIONS
OR WARRANTIES OF DESIGN, MERCHANTABILITY, ACCURACY,
QUALITY OF SERVICE OR RESULTS, AVAILABILITY, QUIET ENJOY-
MENT, FITNESS FOR A PARTICULAR PURPOSE, NON-INFRINGEMENT
AND ANY WARRANTIES ARISING FROM ANY COURSE OF DEALING,
USAGE OR TRADE PRACTICE IN CONNECTION WITH SUCH PROD-
UCTS AND SERVICES. YOU ACKNOWLEDGE THAT NEITHER AIRSPAN
NOR ITS THIRD PARTY PROVIDERS CONTROL YOUR EQUIPMENT OR
THE TRANSFER
OF DATA OVER COMMUNICATIONS FACILITIES, INCLUDING THE
INTERNET, AND THAT THE PRODUCTS AND SERVICES PROVIDED
BY AIRSPAN MAY BE SUBJECT TO LIMITATIONS, INTERRUPTIONS,
DELAYS, CANCELLATIONS AND OTHER PROBLEMS INHERENT IN
THE USE OF COMMUNICATIONS FACILITIES. AIRSPAN AND ANY
THIRD PARTY PROVIDERS ARE NOT RESPONSIBLE FOR ANY INTER-
RUPTIONS, DELAYS, CANCELLATIONS, DELIVERY FAILURES, DATA
LOSS, CONTENT CORRUPTION, PACKET LOSS, OR OTHER DAMAGE
RESULTING FROM ANY OF THE FOREGOING.
IN ADDITION, AIRSPAN MAKES NO WARRANTY OR UNDERTAK-
ING, AND MAKES NO REPRESENTATION OF ANY KIND THAT THE
LICENSED PRODUCTS WILL MEET YOUR REQUIREMENTS, ACHIEVE
ANY INTENDED RESULTS, BE COMPATIBLE OR WORK WITH ANY
OTHER APPLICATIONS, SYSTEMS OR SERVICES, OPERATE WITHOUT
INTERRUPTION, MEET ANY PERFORMANCE OR RELIABILITY STAN-
DARDS, BE ERROR FREE OR THAT ANY ERRORS OR DEFECTS CAN
OR WILL BE CORRECTED, OR THAT THE LICENSED PRODUCTS ARE
NOT VULNERABLE TO FRAUD OR UNAUTHORIZED USE.
Limitation of Liability
EXCEPT TO THE EXTENT PROHIBITED BY THE LAWS IN YOUR
JURISDICTION, IN NO EVENT WILL AIRSPAN OR ITS SUPPLIERS OR
LICENSORS BE LIABLE FOR SPECIAL, INCIDENTAL, CONSEQUENTIAL
OR OTHER DAMAGES (INCLUDING LOST PROFIT, LOST DATA, OR
DOWNTIME COSTS), NOR FOR DAMAGES BASED ON UNAUTHO-
RIZED USE OR ACCESS, ARISING OUT OF THE USE, INABILITY TO
USE, OR THE RESULTS OF USE OF THE PRODUCT, WHETHER BASED
IN WARRANTY, CONTRACT, TORT OR OTHER LEGAL THEORY,
AND WHETHER OR NOT ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. IN NO EVENT SHALL AIRSPAN, ITS SUPPLIERS’ OR ITS LI-
CENSORS’ DIRECT LIABILITY EXCEED THE VALUE OF THE LICENSED
PRODUCTS GIVING RISE TO SUCH LIABILITY. THESE LIMITATIONS
SHALL APPLY NOTHWITHSTANDING ANY FAILURE OF ESSENTIAL
PURPOSE OF ANY LIMITED REMEDY. IN NO EVENT SHALL AIRSPAN
BE RESPONSIBLE FOR DAMAGES OR CLAIMS OF ANY NATURE OR
DESCRIPTION RELATING TO NETWORK PERFORMANCE, INCLUDING
COVERAGE, YOUR SELECTION OF AIRSPAN PRODUCTS FOR YOUR
PARTICULAR APPLICATION AND/OR FAILURE OF AIRSPAN PROD-
UCTS TO MEET GOVERNMENT OR REGULATORY REQUIREMENTS.
Some legal jurisdictions do not allow exclusions of implied warranties or
conditions, or for the exclusion or limitation of liability for incidental or
consequential damages, so the above exclusion may not apply to you.
You may have other rights specic to your legal jurisdiction. EXCEPT
TO THE EXTENT ALLOWED BY THE LAW OF YOUR JURISDICTION,
THESE WARRANTY TERMS DO NOT EXCLUDE, RESTRICT OR
MODIFY, AND ARE IN ADDITION TO, ANY MANDATORY STATUTORY
RIGHTS APPLICABLE TO YOU IN THE LICENSE OF ANY EMBEDDED
SOFTWARE. The United Nations Convention on Contracts for the Inter-
national Sale of Goods shall not apply to any transactions regarding the
UNLOCK REQUIRED
This device requires
unlocking prior to
use. For all unlocking
instructions and
options prior to onsite
installation, please visit:
mimosa.co/start
5 & 6 GHz Fixed Wireless
WiFi 6E PTMP Access Point
Hose Tubing
3/4” (19 mm)
ETH 1 2
Hose Clamp
A6
For instructions, videos and help visit:
Para obtener videos y ayuda, visite:
Pour obtenir des vidéos et de l’aide, visitez:
support.mimosa.co
Para obtener instrucciones, videos y ayuda, visite:
Pour obtenir des instructions, des vidéos et de l’aide, visitez:
setup.mimosa.co
Additional Required & Optional Items
• 10 AWG (5.26 mm2) ground cable with
pre-terminated ring terminal
• Small at head type screwdriver (for
direct 48VDC power terminal)
• 15, 13 and 10 mm socket or adjustable
wrench for mounting assembly
• Power Option A: 18 AWG 2-pin wire for
direct power wiring 48VDC input
• Power Option B: Shielded CAT6/6A &
compatible PoE injector (refer to A6
datasheet specications)
• Optional: SFP+ ber (non-copper)
module and preferred optical cabling
• Optional: 19mm (3/4”) exible conduit/
hose tubing and hose-clamps for
additional cable protection
1. Mounting
Tightly attach the supplied sliding & pivot
brackets to mounting pole in desired up or
downtilt orientation.
2. Grounding
Attach 10 AWG ground wire with pre-termi-
nated ring terminal to the grounding screw.
20
151050
20
15
10
5
0
PWR ETH 1
10
AWG
3. Dedicated 48VDC Power
• Thread an 18 AWG 2-pin cable through
one the supplied IP67 gland/cap.
• Strip the wire jackets approximately
6-7mm, and attach to the supplied
power connector terminals (+/- indicated
in diagram). Tighten the terminal screws.
Note: reverse polarization will not dam-
age the device, however proper +/- wir-
ing is required to apply power.
• Insert and snap the power plug and
cable into the PWR port.
• Attach and tighten gland, attach the
rubber insert to the cable, pushing it into
the gland, then tighten the cap.
4. Gigabit Ethernet or PoE
Insert a shielded CAT6/6A Ethernet cable
through the IP67 gland/cap. Connect the
cable to ETH port. Attach and tighten gland,
attach the rubber insert to the cable, pushing
it into the gland, then tighten the cap.
f
d
e
PWR ETH 1
18
AWG
b
a
c
PoE powering is optional and can be used as
primary or as redundant/backup power to
the 48VDC. Ethernet connection is NOT
required if SFP+ optical ber is being used.
5. Optional Flexible Conduit
The provided IP67 gland caps are designed
to accommodate optional 19mm (3/4”)
outdoor hose conduit/tubing, and hose-type
clamps to secure the tubing. Both can be
procured at most hardware stores.
a
b
c
d
CAT 6/6E
PWR ETH 1 2
6. Optional SFP+ Optical Fiber
Two SFP+ ports are provided to accom-
modate standard SFP+ 10 Gbps optical
modules, and bult-in switching between the
ports for interconnectivity to other devices.
Visit support for additional SFP+ module and
conguration information.
7. Seal All Unused Ports
For any unused ports, tightly screw in the
supplied port sealing caps to maintain envi-
ronmental integrity of the system.
8. Unlock and Congure
Visit start.mimosa.co to unlock the device.
Warnings, Warranty, Compliance
& Regulatory Statements
Mimosa by Airspan (“Mimosa”) products are provided by Airspan
Networks Inc. (“Airspan”).
Export Control
These commodities, technology, or software were exported from the
United States in accordance with the Export Administration Regulations.
Diversion contrary to U.S. law is prohibited.
Important Safety and Handling Information
Failure to follow any of the safety instructions in this guide, instructions
on any Airspan provided packaging, and heed WARNINGS (indicated
by ), could result in re, electric shock, other injury or death, and
incur damage to this product or other property and void the product’s
Limited Warranty.
There are no End User serviceable parts inside the equipment.
Read all operating and safety instructions contained herein and accom-
panying the product as provided by Airspan:
Electrical Safety Information
Do not operate this product in any location that can be sub-
merged by water.
Do not install or maintain this product during the presence of an
electrical storm to avoid risk of electric shock from lightning. Fail-
ure to ground the device according to the included instructions
using shielded CAT6/6A Ethernet cabling could lead to serious
injury or death.
Installation of the product must comply with local and national
electrical codes.
Power specications for connected devices are indicated on the
device’s own label or documentation. Connecting to any power
source that does not meet the voltage, frequency and current
requirements listed may damage the power supply or product,
and pose a re hazard.
Mandatory Grounding Instructions
IMPORTANT: Failure to properly ground the device using the following
instructions will violate the limited warranty conditions in this document.
Required Step 1- Direct Grounding on the Device:
A minimum grounding wire of 10 AWG (5.26 mm2) with a secured
grounding terminal, and shorter in length than 1 meter is required. It is
NOT supplied with the product.
1. Ensure that NO power is being supplied to the product.
2. Locate the Ground point screw next to the Ground icon on the
device
3. Remove the provided Ground Screw
4. Thread the ground wire terminal and ground wire meeting the above
specications over the screw removed in the previous step.
5. Replace and tighten the screw with the threaded ground terminal
and cable at the product Ground point.
6. Secure the other end of the grounding cable to the properly
grounded structure (pole, tower, mast, etc.) meeting local and national
electrical regulations and codes.
End User Product Warranty
The product is warranted against defects in material, and workmanship
for a period of twenty four (24) months from the date of rst unlock
of the product. Please go to www.mimosa.co/warranty to determine
whether your product is in warranty.
The sole responsibility of Airspan under this warranty shall be limited to
the repair or replacement of in-warranty defective product, at Airspan’s
sole option.
Out of warranty products shipped to Airspan will not be returned.
This warranty does not cover costs associated with the removal and/or
reinstallation of the product for repair nor for any parts that are readily
replaced in normal use.
Airspan or its designated partner will repair or replace product found to
be defective during the dened warranty period.
The End User is responsible for delivering defective product in
accordance with the Return Material Authorization (RMA) processes
published at www.mimosa.co/legal/RMA
Limitation of Warranty
The product warranty is invalidated if the RMA product is altered or
otherwise tampered with in a manner that modies the product from
its original shipping conguration and/or form factor, and could violate
the End User’s authority to operate the equipment, unless said activity
was performed by or with the written authorization of an Airspan
representative.
Modications include:
(a) External surfaces that have been painted, labeled, or otherwise
modied from the original shipping condition.
(b) Modications of the product with third party hardware, rmware,
and/or software.
(c) Any product subjected to abnormal physical or electric stress,
including, but not limited to, lightning strikes, negligence, accident,
or misuse.
(d) Any product damaged due to incorrect installation, including,
but not limited to, improper product mounting, cabling meeting
minimum requirements in this manual, cabling defects or connection
to power.
(e) Failure induced by connected third party products.
Installing the product outdoors without the use of minimum CAT6/6A
shielded Ethernet cable, improper grounding, or failure to ground
the product as instructed in this guide will void the End User Product
warranty.
Disclaimer
EXCEPT FOR ANY EXPRESS WARRANTIES PROVIDED HEREIN,
AIRSPAN AND ITS SUBSIDIARIES, LICENSORS AND AFFILIATES (
COLLECTIVELY, “AIRSPAN”), AND ANY THIRD PARTY DATA, SERVICE,
SOFTWARE AND HARDWARE PROVIDERS MAKE NO OTHER REPRE-
SENTATION OR WARRANTY OF ANY KIND AND HEREBY DISCLAIM
ALL WARRANTIES, EXPRESS OR IMPLIED, STATUTORY OR OTHER-
WISE, INCLUDING, BUT NOT LIMITED TO, ANY REPRESENTATIONS
OR WARRANTIES OF DESIGN, MERCHANTABILITY, ACCURACY,
QUALITY OF SERVICE OR RESULTS, AVAILABILITY, QUIET ENJOY-
MENT, FITNESS FOR A PARTICULAR PURPOSE, NON-INFRINGEMENT
AND ANY WARRANTIES ARISING FROM ANY COURSE OF DEALING,
USAGE OR TRADE PRACTICE IN CONNECTION WITH SUCH PROD-
UCTS AND SERVICES. YOU ACKNOWLEDGE THAT NEITHER AIRSPAN
NOR ITS THIRD PARTY PROVIDERS CONTROL YOUR EQUIPMENT OR
THE TRANSFER
OF DATA OVER COMMUNICATIONS FACILITIES, INCLUDING THE
INTERNET, AND THAT THE PRODUCTS AND SERVICES PROVIDED
BY AIRSPAN MAY BE SUBJECT TO LIMITATIONS, INTERRUPTIONS,
DELAYS, CANCELLATIONS AND OTHER PROBLEMS INHERENT IN
THE USE OF COMMUNICATIONS FACILITIES. AIRSPAN AND ANY
THIRD PARTY PROVIDERS ARE NOT RESPONSIBLE FOR ANY INTER-
RUPTIONS, DELAYS, CANCELLATIONS, DELIVERY FAILURES, DATA
LOSS, CONTENT CORRUPTION, PACKET LOSS, OR OTHER DAMAGE
RESULTING FROM ANY OF THE FOREGOING.
IN ADDITION, AIRSPAN MAKES NO WARRANTY OR UNDERTAK-
ING, AND MAKES NO REPRESENTATION OF ANY KIND THAT THE
LICENSED PRODUCTS WILL MEET YOUR REQUIREMENTS, ACHIEVE
ANY INTENDED RESULTS, BE COMPATIBLE OR WORK WITH ANY
OTHER APPLICATIONS, SYSTEMS OR SERVICES, OPERATE WITHOUT
INTERRUPTION, MEET ANY PERFORMANCE OR RELIABILITY STAN-
DARDS, BE ERROR FREE OR THAT ANY ERRORS OR DEFECTS CAN
OR WILL BE CORRECTED, OR THAT THE LICENSED PRODUCTS ARE
NOT VULNERABLE TO FRAUD OR UNAUTHORIZED USE.
Limitation of Liability
EXCEPT TO THE EXTENT PROHIBITED BY THE LAWS IN YOUR
JURISDICTION, IN NO EVENT WILL AIRSPAN OR ITS SUPPLIERS OR
LICENSORS BE LIABLE FOR SPECIAL, INCIDENTAL, CONSEQUENTIAL
OR OTHER DAMAGES (INCLUDING LOST PROFIT, LOST DATA, OR
DOWNTIME COSTS), NOR FOR DAMAGES BASED ON UNAUTHO-
RIZED USE OR ACCESS, ARISING OUT OF THE USE, INABILITY TO
USE, OR THE RESULTS OF USE OF THE PRODUCT, WHETHER BASED
IN WARRANTY, CONTRACT, TORT OR OTHER LEGAL THEORY,
AND WHETHER OR NOT ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. IN NO EVENT SHALL AIRSPAN, ITS SUPPLIERS’ OR ITS LI-
CENSORS’ DIRECT LIABILITY EXCEED THE VALUE OF THE LICENSED
PRODUCTS GIVING RISE TO SUCH LIABILITY. THESE LIMITATIONS
SHALL APPLY NOTHWITHSTANDING ANY FAILURE OF ESSENTIAL
PURPOSE OF ANY LIMITED REMEDY. IN NO EVENT SHALL AIRSPAN
BE RESPONSIBLE FOR DAMAGES OR CLAIMS OF ANY NATURE OR
DESCRIPTION RELATING TO NETWORK PERFORMANCE, INCLUDING
COVERAGE, YOUR SELECTION OF AIRSPAN PRODUCTS FOR YOUR
PARTICULAR APPLICATION AND/OR FAILURE OF AIRSPAN PROD-
UCTS TO MEET GOVERNMENT OR REGULATORY REQUIREMENTS.
Some legal jurisdictions do not allow exclusions of implied warranties or
conditions, or for the exclusion or limitation of liability for incidental or
consequential damages, so the above exclusion may not apply to you.
You may have other rights specic to your legal jurisdiction. EXCEPT
TO THE EXTENT ALLOWED BY THE LAW OF YOUR JURISDICTION,
THESE WARRANTY TERMS DO NOT EXCLUDE, RESTRICT OR
MODIFY, AND ARE IN ADDITION TO, ANY MANDATORY STATUTORY
RIGHTS APPLICABLE TO YOU IN THE LICENSE OF ANY EMBEDDED
SOFTWARE. The United Nations Convention on Contracts for the Inter-
national Sale of Goods shall not apply to any transactions regarding the
UNLOCK REQUIRED
This device requires
unlocking prior to
use. For all unlocking
instructions and
options prior to onsite
installation, please visit:
mimosa.co/start
5 & 6 GHz Fixed Wireless
WiFi 6E PTMP Access Point
Hose Tubing
3/4” (19 mm)
ETH 1 2
Hose Clamp
A6
For instructions, videos and help visit:
Para obtener videos y ayuda, visite:
Pour obtenir des vidéos et de l’aide, visitez:
support.mimosa.co
Para obtener instrucciones, videos y ayuda, visite:
Pour obtenir des instructions, des vidéos et de l’aide, visitez:
setup.mimosa.co
Additional Required & Optional Items
• 10 AWG (5.26 mm2) ground cable with
pre-terminated ring terminal
• Small at head type screwdriver (for
direct 48VDC power terminal)
• 15, 13 and 10 mm socket or adjustable
wrench for mounting assembly
• Power Option A: 18 AWG 2-pin wire for
direct power wiring 48VDC input
• Power Option B: Shielded CAT6/6A &
compatible PoE injector (refer to A6
datasheet specications)
• Optional: SFP+ ber (non-copper)
module and preferred optical cabling
• Optional: 19mm (3/4”) exible conduit/
hose tubing and hose-clamps for
additional cable protection
1. Mounting
Tightly attach the supplied sliding & pivot
brackets to mounting pole in desired up or
downtilt orientation.
2. Grounding
Attach 10 AWG ground wire with pre-termi-
nated ring terminal to the grounding screw.
20
151050
20
15
10
5
0
PWR ETH 1
10
AWG
3. Dedicated 48VDC Power
• Thread an 18 AWG 2-pin cable through
one the supplied IP67 gland/cap.
• Strip the wire jackets approximately
6-7mm, and attach to the supplied
power connector terminals (+/- indicated
in diagram). Tighten the terminal screws.
Note: reverse polarization will not dam-
age the device, however proper +/- wir-
ing is required to apply power.
• Insert and snap the power plug and
cable into the PWR port.
• Attach and tighten gland, attach the
rubber insert to the cable, pushing it into
the gland, then tighten the cap.
4. Gigabit Ethernet or PoE
Insert a shielded CAT6/6A Ethernet cable
through the IP67 gland/cap. Connect the
cable to ETH port. Attach and tighten gland,
attach the rubber insert to the cable, pushing
it into the gland, then tighten the cap.
f
d
e
PWR ETH 1
18
AWG
b
a
c
PoE powering is optional and can be used as
primary or as redundant/backup power to
the 48VDC. Ethernet connection is NOT
required if SFP+ optical ber is being used.
5. Optional Flexible Conduit
The provided IP67 gland caps are designed
to accommodate optional 19mm (3/4”)
outdoor hose conduit/tubing, and hose-type
clamps to secure the tubing. Both can be
procured at most hardware stores.
a
b
c
d
CAT 6/6E
PWR ETH 1 2
6. Optional SFP+ Optical Fiber
Two SFP+ ports are provided to accom-
modate standard SFP+ 10 Gbps optical
modules, and bult-in switching between the
ports for interconnectivity to other devices.
Visit support for additional SFP+ module and
conguration information.
7. Seal All Unused Ports
For any unused ports, tightly screw in the
supplied port sealing caps to maintain envi-
ronmental integrity of the system.
8. Unlock and Congure
Visit start.mimosa.co to unlock the device.
Warnings, Warranty, Compliance
& Regulatory Statements
Mimosa by Airspan (“Mimosa”) products are provided by Airspan
Networks Inc. (“Airspan”).
Export Control
These commodities, technology, or software were exported from the
United States in accordance with the Export Administration Regulations.
Diversion contrary to U.S. law is prohibited.
Important Safety and Handling Information
Failure to follow any of the safety instructions in this guide, instructions
on any Airspan provided packaging, and heed WARNINGS (indicated
by ), could result in re, electric shock, other injury or death, and
incur damage to this product or other property and void the product’s
Limited Warranty.
There are no End User serviceable parts inside the equipment.
Read all operating and safety instructions contained herein and accom-
panying the product as provided by Airspan:
Electrical Safety Information
Do not operate this product in any location that can be sub-
merged by water.
Do not install or maintain this product during the presence of an
electrical storm to avoid risk of electric shock from lightning. Fail-
ure to ground the device according to the included instructions
using shielded CAT6/6A Ethernet cabling could lead to serious
injury or death.
Installation of the product must comply with local and national
electrical codes.
Power specications for connected devices are indicated on the
device’s own label or documentation. Connecting to any power
source that does not meet the voltage, frequency and current
requirements listed may damage the power supply or product,
and pose a re hazard.
Mandatory Grounding Instructions
IMPORTANT: Failure to properly ground the device using the following
instructions will violate the limited warranty conditions in this document.
Required Step 1- Direct Grounding on the Device:
A minimum grounding wire of 10 AWG (5.26 mm2) with a secured
grounding terminal, and shorter in length than 1 meter is required. It is
NOT supplied with the product.
1. Ensure that NO power is being supplied to the product.
2. Locate the Ground point screw next to the Ground icon on the
device
3. Remove the provided Ground Screw
4. Thread the ground wire terminal and ground wire meeting the above
specications over the screw removed in the previous step.
5. Replace and tighten the screw with the threaded ground terminal
and cable at the product Ground point.
6. Secure the other end of the grounding cable to the properly
grounded structure (pole, tower, mast, etc.) meeting local and national
electrical regulations and codes.
End User Product Warranty
The product is warranted against defects in material, and workmanship
for a period of twenty four (24) months from the date of rst unlock
of the product. Please go to www.mimosa.co/warranty to determine
whether your product is in warranty.
The sole responsibility of Airspan under this warranty shall be limited to
the repair or replacement of in-warranty defective product, at Airspan’s
sole option.
Out of warranty products shipped to Airspan will not be returned.
This warranty does not cover costs associated with the removal and/or
reinstallation of the product for repair nor for any parts that are readily
replaced in normal use.
Airspan or its designated partner will repair or replace product found to
be defective during the dened warranty period.
The End User is responsible for delivering defective product in
accordance with the Return Material Authorization (RMA) processes
published at www.mimosa.co/legal/RMA
Limitation of Warranty
The product warranty is invalidated if the RMA product is altered or
otherwise tampered with in a manner that modies the product from
its original shipping conguration and/or form factor, and could violate
the End User’s authority to operate the equipment, unless said activity
was performed by or with the written authorization of an Airspan
representative.
Modications include:
(a) External surfaces that have been painted, labeled, or otherwise
modied from the original shipping condition.
(b) Modications of the product with third party hardware, rmware,
and/or software.
(c) Any product subjected to abnormal physical or electric stress,
including, but not limited to, lightning strikes, negligence, accident,
or misuse.
(d) Any product damaged due to incorrect installation, including,
but not limited to, improper product mounting, cabling meeting
minimum requirements in this manual, cabling defects or connection
to power.
(e) Failure induced by connected third party products.
Installing the product outdoors without the use of minimum CAT6/6A
shielded Ethernet cable, improper grounding, or failure to ground
the product as instructed in this guide will void the End User Product
warranty.
Disclaimer
EXCEPT FOR ANY EXPRESS WARRANTIES PROVIDED HEREIN,
AIRSPAN AND ITS SUBSIDIARIES, LICENSORS AND AFFILIATES (
COLLECTIVELY, “AIRSPAN”), AND ANY THIRD PARTY DATA, SERVICE,
SOFTWARE AND HARDWARE PROVIDERS MAKE NO OTHER REPRE-
SENTATION OR WARRANTY OF ANY KIND AND HEREBY DISCLAIM
ALL WARRANTIES, EXPRESS OR IMPLIED, STATUTORY OR OTHER-
WISE, INCLUDING, BUT NOT LIMITED TO, ANY REPRESENTATIONS
OR WARRANTIES OF DESIGN, MERCHANTABILITY, ACCURACY,
QUALITY OF SERVICE OR RESULTS, AVAILABILITY, QUIET ENJOY-
MENT, FITNESS FOR A PARTICULAR PURPOSE, NON-INFRINGEMENT
AND ANY WARRANTIES ARISING FROM ANY COURSE OF DEALING,
USAGE OR TRADE PRACTICE IN CONNECTION WITH SUCH PROD-
UCTS AND SERVICES. YOU ACKNOWLEDGE THAT NEITHER AIRSPAN
NOR ITS THIRD PARTY PROVIDERS CONTROL YOUR EQUIPMENT OR
THE TRANSFER
OF DATA OVER COMMUNICATIONS FACILITIES, INCLUDING THE
INTERNET, AND THAT THE PRODUCTS AND SERVICES PROVIDED
BY AIRSPAN MAY BE SUBJECT TO LIMITATIONS, INTERRUPTIONS,
DELAYS, CANCELLATIONS AND OTHER PROBLEMS INHERENT IN
THE USE OF COMMUNICATIONS FACILITIES. AIRSPAN AND ANY
THIRD PARTY PROVIDERS ARE NOT RESPONSIBLE FOR ANY INTER-
RUPTIONS, DELAYS, CANCELLATIONS, DELIVERY FAILURES, DATA
LOSS, CONTENT CORRUPTION, PACKET LOSS, OR OTHER DAMAGE
RESULTING FROM ANY OF THE FOREGOING.
IN ADDITION, AIRSPAN MAKES NO WARRANTY OR UNDERTAK-
ING, AND MAKES NO REPRESENTATION OF ANY KIND THAT THE
LICENSED PRODUCTS WILL MEET YOUR REQUIREMENTS, ACHIEVE
ANY INTENDED RESULTS, BE COMPATIBLE OR WORK WITH ANY
OTHER APPLICATIONS, SYSTEMS OR SERVICES, OPERATE WITHOUT
INTERRUPTION, MEET ANY PERFORMANCE OR RELIABILITY STAN-
DARDS, BE ERROR FREE OR THAT ANY ERRORS OR DEFECTS CAN
OR WILL BE CORRECTED, OR THAT THE LICENSED PRODUCTS ARE
NOT VULNERABLE TO FRAUD OR UNAUTHORIZED USE.
Limitation of Liability
EXCEPT TO THE EXTENT PROHIBITED BY THE LAWS IN YOUR
JURISDICTION, IN NO EVENT WILL AIRSPAN OR ITS SUPPLIERS OR
LICENSORS BE LIABLE FOR SPECIAL, INCIDENTAL, CONSEQUENTIAL
OR OTHER DAMAGES (INCLUDING LOST PROFIT, LOST DATA, OR
DOWNTIME COSTS), NOR FOR DAMAGES BASED ON UNAUTHO-
RIZED USE OR ACCESS, ARISING OUT OF THE USE, INABILITY TO
USE, OR THE RESULTS OF USE OF THE PRODUCT, WHETHER BASED
IN WARRANTY, CONTRACT, TORT OR OTHER LEGAL THEORY,
AND WHETHER OR NOT ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. IN NO EVENT SHALL AIRSPAN, ITS SUPPLIERS’ OR ITS LI-
CENSORS’ DIRECT LIABILITY EXCEED THE VALUE OF THE LICENSED
PRODUCTS GIVING RISE TO SUCH LIABILITY. THESE LIMITATIONS
SHALL APPLY NOTHWITHSTANDING ANY FAILURE OF ESSENTIAL
PURPOSE OF ANY LIMITED REMEDY. IN NO EVENT SHALL AIRSPAN
BE RESPONSIBLE FOR DAMAGES OR CLAIMS OF ANY NATURE OR
DESCRIPTION RELATING TO NETWORK PERFORMANCE, INCLUDING
COVERAGE, YOUR SELECTION OF AIRSPAN PRODUCTS FOR YOUR
PARTICULAR APPLICATION AND/OR FAILURE OF AIRSPAN PROD-
UCTS TO MEET GOVERNMENT OR REGULATORY REQUIREMENTS.
Some legal jurisdictions do not allow exclusions of implied warranties or
conditions, or for the exclusion or limitation of liability for incidental or
consequential damages, so the above exclusion may not apply to you.
You may have other rights specic to your legal jurisdiction. EXCEPT
TO THE EXTENT ALLOWED BY THE LAW OF YOUR JURISDICTION,
THESE WARRANTY TERMS DO NOT EXCLUDE, RESTRICT OR
MODIFY, AND ARE IN ADDITION TO, ANY MANDATORY STATUTORY
RIGHTS APPLICABLE TO YOU IN THE LICENSE OF ANY EMBEDDED
SOFTWARE. The United Nations Convention on Contracts for the Inter-
national Sale of Goods shall not apply to any transactions regarding the
UNLOCK REQUIRED
This device requires
unlocking prior to
use. For all unlocking
instructions and
options prior to onsite
installation, please visit:
mimosa.co/start
5 & 6 GHz Fixed Wireless
WiFi 6E PTMP Access Point
Hose Tubing
3/4” (19 mm)
ETH 1 2
Hose Clamp
A6
For instructions, videos and help visit:
Para obtener videos y ayuda, visite:
Pour obtenir des vidéos et de l’aide, visitez:
support.mimosa.co
Para obtener instrucciones, videos y ayuda, visite:
Pour obtenir des instructions, des vidéos et de l’aide, visitez:
setup.mimosa.co
Additional Required & Optional Items
• 10 AWG (5.26 mm2) ground cable with
pre-terminated ring terminal
• Small at head type screwdriver (for
direct 48VDC power terminal)
• 15, 13 and 10 mm socket or adjustable
wrench for mounting assembly
• Power Option A: 18 AWG 2-pin wire for
direct power wiring 48VDC input
• Power Option B: Shielded CAT6/6A &
compatible PoE injector (refer to A6
datasheet specications)
• Optional: SFP+ ber (non-copper)
module and preferred optical cabling
• Optional: 19mm (3/4”) exible conduit/
hose tubing and hose-clamps for
additional cable protection
1. Mounting
Tightly attach the supplied sliding & pivot
brackets to mounting pole in desired up or
downtilt orientation.
2. Grounding
Attach 10 AWG ground wire with pre-termi-
nated ring terminal to the grounding screw.
20
151050
20
15
10
5
0
PWR ETH 1
10
AWG
3. Dedicated 48VDC Power
• Thread an 18 AWG 2-pin cable through
one the supplied IP67 gland/cap.
• Strip the wire jackets approximately
6-7mm, and attach to the supplied
power connector terminals (+/- indicated
in diagram). Tighten the terminal screws.
Note: reverse polarization will not dam-
age the device, however proper +/- wir-
ing is required to apply power.
• Insert and snap the power plug and
cable into the PWR port.
• Attach and tighten gland, attach the
rubber insert to the cable, pushing it into
the gland, then tighten the cap.
4. Gigabit Ethernet or PoE
Insert a shielded CAT6/6A Ethernet cable
through the IP67 gland/cap. Connect the
cable to ETH port. Attach and tighten gland,
attach the rubber insert to the cable, pushing
it into the gland, then tighten the cap.
f
d
e
PWR ETH 1
18
AWG
b
a
c
PoE powering is optional and can be used as
primary or as redundant/backup power to
the 48VDC. Ethernet connection is NOT
required if SFP+ optical ber is being used.
5. Optional Flexible Conduit
The provided IP67 gland caps are designed
to accommodate optional 19mm (3/4”)
outdoor hose conduit/tubing, and hose-type
clamps to secure the tubing. Both can be
procured at most hardware stores.
a
b
c
d
CAT 6/6E
PWR ETH 1 2
6. Optional SFP+ Optical Fiber
Two SFP+ ports are provided to accom-
modate standard SFP+ 10 Gbps optical
modules, and bult-in switching between the
ports for interconnectivity to other devices.
Visit support for additional SFP+ module and
conguration information.
7. Seal All Unused Ports
For any unused ports, tightly screw in the
supplied port sealing caps to maintain envi-
ronmental integrity of the system.
8. Unlock and Congure
Visit start.mimosa.co to unlock the device.
Warnings, Warranty, Compliance
& Regulatory Statements
Mimosa by Airspan (“Mimosa”) products are provided by Airspan
Networks Inc. (“Airspan”).
Export Control
These commodities, technology, or software were exported from the
United States in accordance with the Export Administration Regulations.
Diversion contrary to U.S. law is prohibited.
Important Safety and Handling Information
Failure to follow any of the safety instructions in this guide, instructions
on any Airspan provided packaging, and heed WARNINGS (indicated
by ), could result in re, electric shock, other injury or death, and
incur damage to this product or other property and void the product’s
Limited Warranty.
There are no End User serviceable parts inside the equipment.
Read all operating and safety instructions contained herein and accom-
panying the product as provided by Airspan:
Electrical Safety Information
Do not operate this product in any location that can be sub-
merged by water.
Do not install or maintain this product during the presence of an
electrical storm to avoid risk of electric shock from lightning. Fail-
ure to ground the device according to the included instructions
using shielded CAT6/6A Ethernet cabling could lead to serious
injury or death.
Installation of the product must comply with local and national
electrical codes.
Power specications for connected devices are indicated on the
device’s own label or documentation. Connecting to any power
source that does not meet the voltage, frequency and current
requirements listed may damage the power supply or product,
and pose a re hazard.
Mandatory Grounding Instructions
IMPORTANT: Failure to properly ground the device using the following
instructions will violate the limited warranty conditions in this document.
Required Step 1- Direct Grounding on the Device:
A minimum grounding wire of 10 AWG (5.26 mm2) with a secured
grounding terminal, and shorter in length than 1 meter is required. It is
NOT supplied with the product.
1. Ensure that NO power is being supplied to the product.
2. Locate the Ground point screw next to the Ground icon on the
device
3. Remove the provided Ground Screw
4. Thread the ground wire terminal and ground wire meeting the above
specications over the screw removed in the previous step.
5. Replace and tighten the screw with the threaded ground terminal
and cable at the product Ground point.
6. Secure the other end of the grounding cable to the properly
grounded structure (pole, tower, mast, etc.) meeting local and national
electrical regulations and codes.
End User Product Warranty
The product is warranted against defects in material, and workmanship
for a period of twenty four (24) months from the date of rst unlock
of the product. Please go to www.mimosa.co/warranty to determine
whether your product is in warranty.
The sole responsibility of Airspan under this warranty shall be limited to
the repair or replacement of in-warranty defective product, at Airspan’s
sole option.
Out of warranty products shipped to Airspan will not be returned.
This warranty does not cover costs associated with the removal and/or
reinstallation of the product for repair nor for any parts that are readily
replaced in normal use.
Airspan or its designated partner will repair or replace product found to
be defective during the dened warranty period.
The End User is responsible for delivering defective product in
accordance with the Return Material Authorization (RMA) processes
published at www.mimosa.co/legal/RMA
Limitation of Warranty
The product warranty is invalidated if the RMA product is altered or
otherwise tampered with in a manner that modies the product from
its original shipping conguration and/or form factor, and could violate
the End User’s authority to operate the equipment, unless said activity
was performed by or with the written authorization of an Airspan
representative.
Modications include:
(a) External surfaces that have been painted, labeled, or otherwise
modied from the original shipping condition.
(b) Modications of the product with third party hardware, rmware,
and/or software.
(c) Any product subjected to abnormal physical or electric stress,
including, but not limited to, lightning strikes, negligence, accident,
or misuse.
(d) Any product damaged due to incorrect installation, including,
but not limited to, improper product mounting, cabling meeting
minimum requirements in this manual, cabling defects or connection
to power.
(e) Failure induced by connected third party products.
Installing the product outdoors without the use of minimum CAT6/6A
shielded Ethernet cable, improper grounding, or failure to ground
the product as instructed in this guide will void the End User Product
warranty.
Disclaimer
EXCEPT FOR ANY EXPRESS WARRANTIES PROVIDED HEREIN,
AIRSPAN AND ITS SUBSIDIARIES, LICENSORS AND AFFILIATES (
COLLECTIVELY, “AIRSPAN”), AND ANY THIRD PARTY DATA, SERVICE,
SOFTWARE AND HARDWARE PROVIDERS MAKE NO OTHER REPRE-
SENTATION OR WARRANTY OF ANY KIND AND HEREBY DISCLAIM
ALL WARRANTIES, EXPRESS OR IMPLIED, STATUTORY OR OTHER-
WISE, INCLUDING, BUT NOT LIMITED TO, ANY REPRESENTATIONS
OR WARRANTIES OF DESIGN, MERCHANTABILITY, ACCURACY,
QUALITY OF SERVICE OR RESULTS, AVAILABILITY, QUIET ENJOY-
MENT, FITNESS FOR A PARTICULAR PURPOSE, NON-INFRINGEMENT
AND ANY WARRANTIES ARISING FROM ANY COURSE OF DEALING,
USAGE OR TRADE PRACTICE IN CONNECTION WITH SUCH PROD-
UCTS AND SERVICES. YOU ACKNOWLEDGE THAT NEITHER AIRSPAN
NOR ITS THIRD PARTY PROVIDERS CONTROL YOUR EQUIPMENT OR
THE TRANSFER
OF DATA OVER COMMUNICATIONS FACILITIES, INCLUDING THE
INTERNET, AND THAT THE PRODUCTS AND SERVICES PROVIDED
BY AIRSPAN MAY BE SUBJECT TO LIMITATIONS, INTERRUPTIONS,
DELAYS, CANCELLATIONS AND OTHER PROBLEMS INHERENT IN
THE USE OF COMMUNICATIONS FACILITIES. AIRSPAN AND ANY
THIRD PARTY PROVIDERS ARE NOT RESPONSIBLE FOR ANY INTER-
RUPTIONS, DELAYS, CANCELLATIONS, DELIVERY FAILURES, DATA
LOSS, CONTENT CORRUPTION, PACKET LOSS, OR OTHER DAMAGE
RESULTING FROM ANY OF THE FOREGOING.
IN ADDITION, AIRSPAN MAKES NO WARRANTY OR UNDERTAK-
ING, AND MAKES NO REPRESENTATION OF ANY KIND THAT THE
LICENSED PRODUCTS WILL MEET YOUR REQUIREMENTS, ACHIEVE
ANY INTENDED RESULTS, BE COMPATIBLE OR WORK WITH ANY
OTHER APPLICATIONS, SYSTEMS OR SERVICES, OPERATE WITHOUT
INTERRUPTION, MEET ANY PERFORMANCE OR RELIABILITY STAN-
DARDS, BE ERROR FREE OR THAT ANY ERRORS OR DEFECTS CAN
OR WILL BE CORRECTED, OR THAT THE LICENSED PRODUCTS ARE
NOT VULNERABLE TO FRAUD OR UNAUTHORIZED USE.
Limitation of Liability
EXCEPT TO THE EXTENT PROHIBITED BY THE LAWS IN YOUR
JURISDICTION, IN NO EVENT WILL AIRSPAN OR ITS SUPPLIERS OR
LICENSORS BE LIABLE FOR SPECIAL, INCIDENTAL, CONSEQUENTIAL
OR OTHER DAMAGES (INCLUDING LOST PROFIT, LOST DATA, OR
DOWNTIME COSTS), NOR FOR DAMAGES BASED ON UNAUTHO-
RIZED USE OR ACCESS, ARISING OUT OF THE USE, INABILITY TO
USE, OR THE RESULTS OF USE OF THE PRODUCT, WHETHER BASED
IN WARRANTY, CONTRACT, TORT OR OTHER LEGAL THEORY,
AND WHETHER OR NOT ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. IN NO EVENT SHALL AIRSPAN, ITS SUPPLIERS’ OR ITS LI-
CENSORS’ DIRECT LIABILITY EXCEED THE VALUE OF THE LICENSED
PRODUCTS GIVING RISE TO SUCH LIABILITY. THESE LIMITATIONS
SHALL APPLY NOTHWITHSTANDING ANY FAILURE OF ESSENTIAL
PURPOSE OF ANY LIMITED REMEDY. IN NO EVENT SHALL AIRSPAN
BE RESPONSIBLE FOR DAMAGES OR CLAIMS OF ANY NATURE OR
DESCRIPTION RELATING TO NETWORK PERFORMANCE, INCLUDING
COVERAGE, YOUR SELECTION OF AIRSPAN PRODUCTS FOR YOUR
PARTICULAR APPLICATION AND/OR FAILURE OF AIRSPAN PROD-
UCTS TO MEET GOVERNMENT OR REGULATORY REQUIREMENTS.
Some legal jurisdictions do not allow exclusions of implied warranties or
conditions, or for the exclusion or limitation of liability for incidental or
consequential damages, so the above exclusion may not apply to you.
You may have other rights specic to your legal jurisdiction. EXCEPT
TO THE EXTENT ALLOWED BY THE LAW OF YOUR JURISDICTION,
THESE WARRANTY TERMS DO NOT EXCLUDE, RESTRICT OR
MODIFY, AND ARE IN ADDITION TO, ANY MANDATORY STATUTORY
RIGHTS APPLICABLE TO YOU IN THE LICENSE OF ANY EMBEDDED
SOFTWARE. The United Nations Convention on Contracts for the Inter-
national Sale of Goods shall not apply to any transactions regarding the
UNLOCK REQUIRED
This device requires
unlocking prior to
use. For all unlocking
instructions and
options prior to onsite
installation, please visit:
mimosa.co/start
5 & 6 GHz Fixed Wireless
WiFi 6E PTMP Access Point
Hose Tubing
3/4” (19 mm)
ETH 1 2
Hose Clamp
A6
For instructions, videos and help visit:
Para obtener videos y ayuda, visite:
Pour obtenir des vidéos et de l’aide, visitez:
support.mimosa.co
Para obtener instrucciones, videos y ayuda, visite:
Pour obtenir des instructions, des vidéos et de l’aide, visitez:
setup.mimosa.co
Additional Required & Optional Items
• 10 AWG (5.26 mm2) ground cable with
pre-terminated ring terminal
• Small at head type screwdriver (for
direct 48VDC power terminal)
• 15, 13 and 10 mm socket or adjustable
wrench for mounting assembly
• Power Option A: 18 AWG 2-pin wire for
direct power wiring 48VDC input
• Power Option B: Shielded CAT6/6A &
compatible PoE injector (refer to A6
datasheet specications)
• Optional: SFP+ ber (non-copper)
module and preferred optical cabling
• Optional: 19mm (3/4”) exible conduit/
hose tubing and hose-clamps for
additional cable protection
1. Mounting
Tightly attach the supplied sliding & pivot
brackets to mounting pole in desired up or
downtilt orientation.
2. Grounding
Attach 10 AWG ground wire with pre-termi-
nated ring terminal to the grounding screw.
20
151050
20
15
10
5
0
PWR ETH 1
10
AWG
3. Dedicated 48VDC Power
• Thread an 18 AWG 2-pin cable through
one the supplied IP67 gland/cap.
• Strip the wire jackets approximately
6-7mm, and attach to the supplied
power connector terminals (+/- indicated
in diagram). Tighten the terminal screws.
Note: reverse polarization will not dam-
age the device, however proper +/- wir-
ing is required to apply power.
• Insert and snap the power plug and
cable into the PWR port.
• Attach and tighten gland, attach the
rubber insert to the cable, pushing it into
the gland, then tighten the cap.
4. Gigabit Ethernet or PoE
Insert a shielded CAT6/6A Ethernet cable
through the IP67 gland/cap. Connect the
cable to ETH port. Attach and tighten gland,
attach the rubber insert to the cable, pushing
it into the gland, then tighten the cap.
f
d
e
PWR ETH 1
18
AWG
b
a
c
PoE powering is optional and can be used as
primary or as redundant/backup power to
the 48VDC. Ethernet connection is NOT
required if SFP+ optical ber is being used.
5. Optional Flexible Conduit
The provided IP67 gland caps are designed
to accommodate optional 19mm (3/4”)
outdoor hose conduit/tubing, and hose-type
clamps to secure the tubing. Both can be
procured at most hardware stores.
a
b
c
d
CAT 6/6E
PWR ETH 1 2
6. Optional SFP+ Optical Fiber
Two SFP+ ports are provided to accom-
modate standard SFP+ 10 Gbps optical
modules, and bult-in switching between the
ports for interconnectivity to other devices.
Visit support for additional SFP+ module and
conguration information.
7. Seal All Unused Ports
For any unused ports, tightly screw in the
supplied port sealing caps to maintain envi-
ronmental integrity of the system.
8. Unlock and Congure
Visit start.mimosa.co to unlock the device.
Warnings, Warranty, Compliance
& Regulatory Statements
Mimosa by Airspan (“Mimosa”) products are provided by Airspan
Networks Inc. (“Airspan”).
Export Control
These commodities, technology, or software were exported from the
United States in accordance with the Export Administration Regulations.
Diversion contrary to U.S. law is prohibited.
Important Safety and Handling Information
Failure to follow any of the safety instructions in this guide, instructions
on any Airspan provided packaging, and heed WARNINGS (indicated
by ), could result in re, electric shock, other injury or death, and
incur damage to this product or other property and void the product’s
Limited Warranty.
There are no End User serviceable parts inside the equipment.
Read all operating and safety instructions contained herein and accom-
panying the product as provided by Airspan:
Electrical Safety Information
Do not operate this product in any location that can be sub-
merged by water.
Do not install or maintain this product during the presence of an
electrical storm to avoid risk of electric shock from lightning. Fail-
ure to ground the device according to the included instructions
using shielded CAT6/6A Ethernet cabling could lead to serious
injury or death.
Installation of the product must comply with local and national
electrical codes.
Power specications for connected devices are indicated on the
device’s own label or documentation. Connecting to any power
source that does not meet the voltage, frequency and current
requirements listed may damage the power supply or product,
and pose a re hazard.
Mandatory Grounding Instructions
IMPORTANT: Failure to properly ground the device using the following
instructions will violate the limited warranty conditions in this document.
Required Step 1- Direct Grounding on the Device:
A minimum grounding wire of 10 AWG (5.26 mm2) with a secured
grounding terminal, and shorter in length than 1 meter is required. It is
NOT supplied with the product.
1. Ensure that NO power is being supplied to the product.
2. Locate the Ground point screw next to the Ground icon on the
device
3. Remove the provided Ground Screw
4. Thread the ground wire terminal and ground wire meeting the above
specications over the screw removed in the previous step.
5. Replace and tighten the screw with the threaded ground terminal
and cable at the product Ground point.
6. Secure the other end of the grounding cable to the properly
grounded structure (pole, tower, mast, etc.) meeting local and national
electrical regulations and codes.
End User Product Warranty
The product is warranted against defects in material, and workmanship
for a period of twenty four (24) months from the date of rst unlock
of the product. Please go to www.mimosa.co/warranty to determine
whether your product is in warranty.
The sole responsibility of Airspan under this warranty shall be limited to
the repair or replacement of in-warranty defective product, at Airspan’s
sole option.
Out of warranty products shipped to Airspan will not be returned.
This warranty does not cover costs associated with the removal and/or
reinstallation of the product for repair nor for any parts that are readily
replaced in normal use.
Airspan or its designated partner will repair or replace product found to
be defective during the dened warranty period.
The End User is responsible for delivering defective product in
accordance with the Return Material Authorization (RMA) processes
published at www.mimosa.co/legal/RMA
Limitation of Warranty
The product warranty is invalidated if the RMA product is altered or
otherwise tampered with in a manner that modies the product from
its original shipping conguration and/or form factor, and could violate
the End User’s authority to operate the equipment, unless said activity
was performed by or with the written authorization of an Airspan
representative.
Modications include:
(a) External surfaces that have been painted, labeled, or otherwise
modied from the original shipping condition.
(b) Modications of the product with third party hardware, rmware,
and/or software.
(c) Any product subjected to abnormal physical or electric stress,
including, but not limited to, lightning strikes, negligence, accident,
or misuse.
(d) Any product damaged due to incorrect installation, including,
but not limited to, improper product mounting, cabling meeting
minimum requirements in this manual, cabling defects or connection
to power.
(e) Failure induced by connected third party products.
Installing the product outdoors without the use of minimum CAT6/6A
shielded Ethernet cable, improper grounding, or failure to ground
the product as instructed in this guide will void the End User Product
warranty.
Disclaimer
EXCEPT FOR ANY EXPRESS WARRANTIES PROVIDED HEREIN,
AIRSPAN AND ITS SUBSIDIARIES, LICENSORS AND AFFILIATES (
COLLECTIVELY, “AIRSPAN”), AND ANY THIRD PARTY DATA, SERVICE,
SOFTWARE AND HARDWARE PROVIDERS MAKE NO OTHER REPRE-
SENTATION OR WARRANTY OF ANY KIND AND HEREBY DISCLAIM
ALL WARRANTIES, EXPRESS OR IMPLIED, STATUTORY OR OTHER-
WISE, INCLUDING, BUT NOT LIMITED TO, ANY REPRESENTATIONS
OR WARRANTIES OF DESIGN, MERCHANTABILITY, ACCURACY,
QUALITY OF SERVICE OR RESULTS, AVAILABILITY, QUIET ENJOY-
MENT, FITNESS FOR A PARTICULAR PURPOSE, NON-INFRINGEMENT
AND ANY WARRANTIES ARISING FROM ANY COURSE OF DEALING,
USAGE OR TRADE PRACTICE IN CONNECTION WITH SUCH PROD-
UCTS AND SERVICES. YOU ACKNOWLEDGE THAT NEITHER AIRSPAN
NOR ITS THIRD PARTY PROVIDERS CONTROL YOUR EQUIPMENT OR
THE TRANSFER
OF DATA OVER COMMUNICATIONS FACILITIES, INCLUDING THE
INTERNET, AND THAT THE PRODUCTS AND SERVICES PROVIDED
BY AIRSPAN MAY BE SUBJECT TO LIMITATIONS, INTERRUPTIONS,
DELAYS, CANCELLATIONS AND OTHER PROBLEMS INHERENT IN
THE USE OF COMMUNICATIONS FACILITIES. AIRSPAN AND ANY
THIRD PARTY PROVIDERS ARE NOT RESPONSIBLE FOR ANY INTER-
RUPTIONS, DELAYS, CANCELLATIONS, DELIVERY FAILURES, DATA
LOSS, CONTENT CORRUPTION, PACKET LOSS, OR OTHER DAMAGE
RESULTING FROM ANY OF THE FOREGOING.
IN ADDITION, AIRSPAN MAKES NO WARRANTY OR UNDERTAK-
ING, AND MAKES NO REPRESENTATION OF ANY KIND THAT THE
LICENSED PRODUCTS WILL MEET YOUR REQUIREMENTS, ACHIEVE
ANY INTENDED RESULTS, BE COMPATIBLE OR WORK WITH ANY
OTHER APPLICATIONS, SYSTEMS OR SERVICES, OPERATE WITHOUT
INTERRUPTION, MEET ANY PERFORMANCE OR RELIABILITY STAN-
DARDS, BE ERROR FREE OR THAT ANY ERRORS OR DEFECTS CAN
OR WILL BE CORRECTED, OR THAT THE LICENSED PRODUCTS ARE
NOT VULNERABLE TO FRAUD OR UNAUTHORIZED USE.
Limitation of Liability
EXCEPT TO THE EXTENT PROHIBITED BY THE LAWS IN YOUR
JURISDICTION, IN NO EVENT WILL AIRSPAN OR ITS SUPPLIERS OR
LICENSORS BE LIABLE FOR SPECIAL, INCIDENTAL, CONSEQUENTIAL
OR OTHER DAMAGES (INCLUDING LOST PROFIT, LOST DATA, OR
DOWNTIME COSTS), NOR FOR DAMAGES BASED ON UNAUTHO-
RIZED USE OR ACCESS, ARISING OUT OF THE USE, INABILITY TO
USE, OR THE RESULTS OF USE OF THE PRODUCT, WHETHER BASED
IN WARRANTY, CONTRACT, TORT OR OTHER LEGAL THEORY,
AND WHETHER OR NOT ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. IN NO EVENT SHALL AIRSPAN, ITS SUPPLIERS’ OR ITS LI-
CENSORS’ DIRECT LIABILITY EXCEED THE VALUE OF THE LICENSED
PRODUCTS GIVING RISE TO SUCH LIABILITY. THESE LIMITATIONS
SHALL APPLY NOTHWITHSTANDING ANY FAILURE OF ESSENTIAL
PURPOSE OF ANY LIMITED REMEDY. IN NO EVENT SHALL AIRSPAN
BE RESPONSIBLE FOR DAMAGES OR CLAIMS OF ANY NATURE OR
DESCRIPTION RELATING TO NETWORK PERFORMANCE, INCLUDING
COVERAGE, YOUR SELECTION OF AIRSPAN PRODUCTS FOR YOUR
PARTICULAR APPLICATION AND/OR FAILURE OF AIRSPAN PROD-
UCTS TO MEET GOVERNMENT OR REGULATORY REQUIREMENTS.
Some legal jurisdictions do not allow exclusions of implied warranties or
conditions, or for the exclusion or limitation of liability for incidental or
consequential damages, so the above exclusion may not apply to you.
You may have other rights specic to your legal jurisdiction. EXCEPT
TO THE EXTENT ALLOWED BY THE LAW OF YOUR JURISDICTION,
THESE WARRANTY TERMS DO NOT EXCLUDE, RESTRICT OR
MODIFY, AND ARE IN ADDITION TO, ANY MANDATORY STATUTORY
RIGHTS APPLICABLE TO YOU IN THE LICENSE OF ANY EMBEDDED
SOFTWARE. The United Nations Convention on Contracts for the Inter-
national Sale of Goods shall not apply to any transactions regarding the
UNLOCK REQUIRED
This device requires
unlocking prior to
use. For all unlocking
instructions and
options prior to onsite
installation, please visit:
mimosa.co/start
5 & 6 GHz Fixed Wireless
WiFi 6E PTMP Access Point
Hose Tubing
3/4” (19 mm)
ETH 1 2
Hose Clamp
© 2022 Airspan Networks Inc. All rights reserved.
sale of the Products.
FCC
This device complies with part 15 of the FCC Rules. Operation is sub-
ject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio commu-
nications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to
correct the interference at his own expense.
The radiated output power of this device is below the FCC radio
frequency exposure limits. Nevertheless, the device should be used in
such a manner that the potential for human contact during the normal
operation is minimized. In order to avoid the possibility of exceeding
the FCC radio frequency exposure limit, human proximity to the anten-
na should be more than 3m.
When mounting the radio antenna, in accordance with the Part 15 UNII-
1 band requirements, the antenna must not exceed 125 mW (21 dBm)
e.i.r.p. at any elevation angle above 30 degrees as measured from the
horizon).
Important: Changes or modications to this product not authorized by
Mimosa Networks, Inc. could void the electromagneticcompatibility
(EMC) and wireless compliance and negate your authority to-
operate the product. The information in this guide may change without
notice. The manufacturer assumes no responsibility for any errors that
may appear in this guide.
Industry Canada
This Class A digital apparatus complies with Canadian CAN ICES-3(A).
Cet appareil numérique de la classe A est conforme à la norme NMB-
3(A) Canada.
Under Industry Canada regulations, this radio transmitter may only
operate using an antenna of a type and maximum (or lesser) gain
approved for the transmitter by Industry Canada. To reduce potential
radio interference to other users, the antenna type and its gain should
be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is
not more than that necessary for successful communication.
Pour réduire le risque d’interférence aux autres utilisateurs, le type
d’antenne et son gain doivent être choisies de façon que la puissance
isotrope rayonnée équivalente (PIRE) ne dépasse pas ce qui est néces-
saire pour une communication réussie.
This device complies with Industry Canada licence-exempt RSS stan-
dard(s). Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation
of the device.
Cet appareil est conforme à la norme RSS Industrie Canada exempts de
licence norme(s). Son fonctionnement est soumis aux deux conditions
suivantes:
(1) Cet appareil ne peut pas provoquer d’interférences et (2) Cet ap-
pareil doit accepter toute interférence, y compris les interférences qui
peuvent causer un mauvais fonctionnement du dispositif.
Australia & New Zealand
Warning: This is a Class A product. In a domestic environment
this product may cause radio interference in which case the user
may be required to take adequate measures.
European Compliance Statement
CE Marking on this product represents that this product com-
plies with all requirements that are applicable to it.
Europe EU Declaration of Conformity
This device can be used in the European Community. A copy of the EU Decla-
ration of Conformity is available at: www.mimosa.co/compliance.
Български (Bulgarian) - Airspan Networks Inc. декларира, че това Airspan
Networks Inc. приспособление е в съответствие със съществените
изисквания и другите приложими правила на Директива 2014/53/EU.
Česky (Czech) - Společnost Airspan Networks Inc. tímto prohlašuje, že tento
Airspan Networks Inc. zařízení je ve shodě se základními požadavky a dalšími
příslušnými ustanoveními směrnice 2014/53/EU.
Dansk (Danish) - Undertegnede Airspan Networks Inc. erklærer herved, at
følgende udstyr Airspan Networks Inc. enhed overholder de væsentlige krav
og øvrige relevante krav i direktiv 2014/53/EU.
Deutsch (German) - Hiermit erklärt Airspan Networks Inc., dass sich das
Airspan Networks Inc. Gerät in Übereinstimmung mit den grundlegenden
Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie
2014/53/EU benden.
Eesti (Estonian) - Käesolevaga kinnitab Airspan Networks Inc., et see Airspan
Networks Inc. seade vastab direktiivi 2014/53/EU põhinõuetele ja nimetatud
direktiivist tulenevatele teistele asjakohastele sätetele.
English - Hereby, Airspan Networks Inc. declares that this Airspan Networks
Inc. device is in compliance with the essential requirements and other relevant
provisions of Directive 2014/53/EU.
Español (Spanish) - Por medio de la presente Airspan Networks Inc. declara
que este Airspan Networks Inc. dispositivo cumple con los requisitos esen-
ciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva
2014/53/EU.
Ελληνικά (Greek) - Mε την παρούσα, η Airspan Networks Inc. δηλώνει ότι αυτή
η συσκευή Airspan Networks Inc. συσκευή συμμορφώνεται προς τις βασικές
απαιτήσεις και τις λοιπές σχετικές διατάξεις της Οδηγίας 2014/53/EU.
Français (French) - Par la présente Airspan Networks Inc. déclare que ce
Airspan Networks Inc. appareil est conforme aux exigences essentielles et aux
autres dispositions pertinentes de la directive 2014/53/EU.
Islenska (Icelandic) - Airspan Networks Inc. lýsir því hér með yr að þetta
Airspan Networks Inc. tæki fullnægir lágmarkskröfum og öðrum viðeigandi
ákvæðum Evróputilskipunar 2014/53/EU.
Italiano (Italian) - Con la presente Airspan Networks Inc. dichiara che questo
Airspan Networks Inc. dispositivo è conforme ai requisiti essenziali ed alle altre
disposizioni pertinenti stabilite dalla direttiva 2014/53/EU.
Latviski (Latvian) - Ar šo Airspan Networks Inc. deklarē, ka šī Airspan Networks
Inc. ierīce atbilst Direktīvas 2014/53/EU būtiskajām prasībām un citiem ar to
saistītajiem noteikumiem.
Lietuvių (Lithuanian) - Šiuo „Airspan Networks Inc.“ deklaruoja, kad šis Airspan
Networks Inc. atitinka esminius reikalavimus ir kitas 2014/53/EUB Direktyvos
nuostatas.
Magyar (Hungarian) - Alulírott, Airspan Networks Inc. nyilatkozom, hogy a Air-
span Networks Inc. eszköz megfelel a vonatkozó alapvetõ követelményeknek
és az 2014/53/EU irányelv egyéb elõírásainak.
Malti (Maltese) - Hawnhekk, Airspan Networks Inc., jiddikjara li dan Airspan
Networks Inc. tagħmir jikkonforma mal-ħtiġijiet essenzjali u ma provvedimenti
oħrajn relevanti li hemm d-Dirrettiva 2014/53/EU. 705-00034 REV A
Nederlands (Dutch) - Hierbij verklaart Airspan Networks Inc. dat dit Airspan
Networks Inc. toestel in overeenstemming is met de essentiële eisen en de
andere bepalingen van richtlijn 2014/53/EU.
Norsk (Norwegian) - Airspan Networks Inc. erklærer herved at dette Airspan
Networks Inc. apparatet er i samsvar med de grunnleggende kravene og
øvrige relevante krav i EU-direktivet 2014/53/EU.
Polski (Polish)- Niniejszym Airspan Networks Inc. oświadcza, że ten Airspan
Networks Inc. urządzenie są zgodne z zasadniczymi wymogami oraz pozos-
tałymi stosownymi postanowieniami Dyrektywy 2014/53/EU.
Português (Portugese) - Airspan Networks Inc. declara que este Airspan
Networks Inc. dispositivo está em conformidade com os requisitos essenciais
e outras disposições da Directiva 2014/53/EU.
Română (Romanian) - Prin prezenta, Airspan Networks Inc. declară că acest
Airspan Networks Inc. aparat este în conformitate cu cerinţele esenţiale şi cu
celelalte prevederi relevante ale Directivei 2014/53/EU.
Slovensky (Slovak) - Airspan Networks Inc. týmto vyhlasuje, že toto Airspan
Networks Inc. zariadenie spĺňa základné požiadavky a všetky príslušné ustano-
venia Smernice 2014/53/EU.
Slovensko (Slovene) - Airspan Networks Inc. izjavlja, da je ta Airspan Networks
Inc. naprava skladne z bistvenimi zahtevami in ostalimi ustreznimi določili
direktive 2014/53/EU.
Suomi (Finnish) - Airspan Networks Inc. vakuuttaa täten, että tämä Airspan
Networks Inc. tyyppinen laite on direktiivin 2014/53/EU oleellisten vaatimusten
ja sitä koskevien direktiivin muiden ehtojen mukainen.
Svenska (Swedish) - Härmed intygar Airspan Networks Inc. att denna Airspan
Networks Inc. apparat står i överensstämmelse med de väsentliga egenskapsk-
rav och övriga relevanta bestämmelser som framgår av direktiv 2014/53/EU.
RoHS & WEEE Compliance
User Information for Consumer Products Covered by EU Directive 2002/96/EC
on Waste Electric and Electronic Equipment (WEEE).
This document contains important information for users with re-
gards to the proper disposal and recycling of Airspan Networks Inc.
products. Consumers are required to comply with this notice for all
electronic products bearing this symbol.
English - Environmental Information for Customers in the European Union
European Directive 2002/96/EC requires that the equipment bearing this
symbol on the product and/or its packaging must not be disposed of with
unsorted municipal waste. The symbol indicates that this product should
be disposed of separately from regular household waste streams. It is your
responsibility to dispose of this and other electric and electronic equipment
via designated collection facilities appointed by the government or local
authorities. Correct disposal and recycling will help prevent potential negative
consequences to the environment and human health. For more detailed
information about the disposal of your old equipment, please contact your
local authorities, waste disposal service, or the shop where you purchased the
product.
Български (Bulgarian) - Информация относноопазването на околната
среда за потребители вЕвропейския съюз -Европейска директива
2002/96/EC изисква уредите, носещи този символ върху изделието и/
или опаковката му, да не се изхвърля т с несортирани битови отпадъци.
Символът обозначава, че изделието трябва да се изхвърля отделно
от сметосъбирането на обикновените битови отпадъци. Ваша е
отговорността този и другите електрически и електронни уреди да се
изхвърлят в предварително определени от държавните или общински
органи специализирани пунктове за събиране. Правилното изхвърляне
и рециклиране ще спомогнат да се предотвратят евентуални вредни за
околната среда и здравето на населението последствия. За по-подробна
информация относно изхвърлянето на вашите стари уреди се обърнете
към местните власти, службите за сметосъбиране или магазина, от който
сте закупили уреда.
Čeština (Czech) - Informace o ochraně životníhoprostředí pro zákazníky v
zemích Evropské unie - Evropská směrnice 2002/96/ES zakazuje, aby zařízení
označené tímto symbolem na produktu anebo na obalu bylo likvidováno s
netříděným komunálním odpadem. Tento symbol udává, že daný produkt musí
být likvidován odděleně od běžného komunálního odpadu. Odpovídáte za
likvidaci tohoto produktu a dalších elektrických a elektronických zařízení pros-
třednictvím určených sběrných míst stanovených vládou nebo místními úřady.
Správná likvidace a recyklace pomáhá předcházet potenciálním negativním
dopadům na životní prostředí a lidské zdraví. Podrobnější informace o likvidaci
starého vybavení si laskavě vyžádejte od místních úřadů, podniku zabývajícího
se likvidací komunálních odpadů nebo obchodu, kde jste produkt zakoupili.
Dansk (Danish) - Miljøinformation for kunder i EU - EU-direktiv 2002/96/EF
kræver, at udstyr der bærer dette symbol på produktet og/eller emballagen
ikke må bortskaffes som usorteret kommunalt affald. Symbolet betyder, at
dette produkt skal bortskaffes adskilt fra det almindelige husholdningsaffald.
Det er dit ansvar at bortskaffe dette og andet elektrisk og elektronisk udstyr
via bestemte indsamlingssteder udpeget af staten eller de lokale myndighed-
er. Korrekt bortskaffelse og genvinding vil hjælpe med til at undgå mulige
skader for miljøet og menneskers sundhed. Kontakt venligst de lokale myn-
digheder, renovationstjenesten eller den butik, hvor du har købt produktet,
angående mere detaljeret information om bortskaffelse af dit gamle udstyr.
Deutsch (German) - Umweltinformation für Kunden innerhalb der Eu-
ropäischen Union - Die Europäische Richtlinie 2002/96/EC verlangt, dass
technische Ausrüstung, die direkt am Gerät und/oder an der Verpackung mit
diesem Symbol versehen ist, nicht zusammen mit unsortiertem Gemeinde-
abfall entsorgt werden darf. Das Symbol weist darauf hin, dass das Produkt
von regulärem Haushaltmüll getrennt entsorgt werden sollte. Es liegt in Ihrer
Verantwortung, dieses Gerät und andere elektrische und elektronische Geräte
über die dafür zuständigen und von der Regierung oder örtlichen Behörden
dazu bestimmten Sammelstellen zu entsorgen. Ordnungsgemäßes Entsorgen
und Recyceln trägt dazu bei, potentielle negative Folgen für Umwelt und die
menschliche Gesundheit zu vermeiden. Wenn Sie weitere Informationen zur
Entsorgung Ihrer Altgeräte benötigen, wenden Sie sich bitte an die örtlichen
Behörden oder städtischen Entsorgungsdienste oder an den Händler, bei dem
Sie das Produkt erworben haben.
Eesti (Estonian) - Keskkonnaalane informatsioon Euroopa Liidus asuvatele kli-
entidele - Euroopa Liidu direktiivi 2002/96/EÜ nõuete kohaselt on seadmeid,
millel on tootel või pakendil käesolev sümbol keelatud kõrvaldada koos sort-
eerimata olmejäätmetega. See sümbol näitab, et toode tuleks kõrvaldada eral-
di tavalistest olmejäätmevoogudest. Olete kohustatud kõrvaldama käesoleva
ja ka muud elektri- ja elektroonikaseadmed riigi või kohalike ametiasutuste
poolt ette nähtud kogumispunktide kaudu. Seadmete korrektne kõrvaldamine
ja ringlussevõtt aitab vältida võimalikke negatiivseid tagajärgi keskkonnale
ning inimeste tervisele. Vanade seadmete kõrvaldamise kohta täpsema
informatsiooni saamiseks võtke palun ühendust kohalike ametiasutustega,
jäätmekäitlusrmaga või kauplusega, kust te toote ostsite.
Español (Spanish) - Información medioambiental paraclientes de la Unión
Europea - La Directiva 2002/96/CE de la UE exige que los equipos quel leven
este símbolo en el propio aparato y/o en su embalaje no deben eliminarse
junto con otros residuos urbanos no seleccionados. El símbolo indica que el
producto en cuestión debe separarse de los residuos domésticos conven-
cionales con vistas a su eliminación. Es responsabilidad suya desechar este y
cualesquiera otros aparatos eléctricos y electrónicos a través de los puntos de
recogida que ponen a su disposición el gobierno y las autoridades locales.
Al desechar y reciclar correctamente estos aparatos estará contribuyendo a
evitar posibles consecuencias negativas para el medio ambiente y la salud de
las personas. Si desea obtener información más detallada sobre la eliminación
segura de su aparato usado, consulte a las autoridades locales, al servicio de
recogida y eliminación de residuos de su zona o pregunte en la tienda donde
adquirió el producto.
Ελληνικά (Greek) - Στοιχεία περιβαλλοντικής προστασίας για πελάτες εντός
της ΕυρωπαϊκήςΈνωσης - Σύμφωνα με την Κοινοτική Οδηγία 2002/96/
EC, ο εξοπλισμός που φέρει αυτό το σύμβολο στο προϊόν ή/και τη
συσκευασία του δεν πρέπει να απορρίπτεται μαζί με τα μη διαχωρισμένα
αστικά απορρίμματα. Το σύμβολο υποδεικνύει ότι αυτό το προϊόν θα
πρέπει να απορρίπτεται ξεχωριστά από τα συνήθη οικιακά απορρίμματα.
Είστε υπεύθυνος για την απόρριψη του παρόντος και άλλου ηλεκτρικού
και ηλεκτρονικού εξοπλισμού μέσω των καθορισμένων εγκαταστάσεων
συγκέντρωσης απορριμμάτων, οι οποίες ορίζονται από το κράτος ή τις
αρμόδιες τοπικές αρχές. Η σωστή απόρριψη και ανακύκλωση συμβάλλει στην
πρόληψη ενδεχόμενων αρνητικών επιπτώσεων στο περιβάλλον και την υγεία.
Για περισσότερες πληροφορίες σχετικά με την απόρριψη του παλαιού σας
εξοπλισμού, επικοινωνήστε με τις τοπικές αρχές, τις υπηρεσίες αποκομιδής
απορριμμάτων ή το κατάστημα από το οποίο αγοράσατε το προϊόν.
Français (French) - Informations environnementales pour les clients de l’Union
européenne - La directive européenne 2002/96/CE exige que l’équipement
, sur lequel est apposé ce symbole sur le produit et/ou son emballage ne
soit pas jeté avec les autres ordures ménagères. Ce symbole indique que
le produit doit être éliminé dans un circuit distinct de celui pour les déchets
des ménages. Il est de votre responsabilité de jeter ce matériel ainsi que tout
autre matériel électrique ou électronique par les moyens de collecte indiqués
par le gouvernement et les pouvoirs publics des collectivités territoriales.
L’élimination et le recyclage en bonne et due forme ont pour but de lutter
contre l’impact néfaste potentiel de ce type de produits sur l’environnement
et la santé publique. Pour plus d’informations sur le mode d’élimination de
votre ancien équipement, veuillez prendre contact avec les pouvoirs publics
locaux, le service de traitement des déchets, ou l’endroit où vous avez acheté
le produit.
Italiano (Italian) - Informazioni relative all’ambiente per i clienti residenti
nell’Unione Europea - La direttiva europea 2002/96/EC richiede che le appare-
cchiature contrassegnate con questo simbolo sul prodotto e/o sull’imballaggio
non siano smaltite insieme ai riuti urbani non differenziati. Il simbolo indica
che questo prodotto non deve essere smaltito insieme ai normali riuti do-
mestici. È responsabilità del proprietario smaltire sia questi prodotti sia le altre
apparecchiature elettriche ed elettroniche mediante le speciche strutture di
raccolta indicate dal governo o dagli enti pubblici locali. Il corretto smaltimen-
to ed il riciclaggio aiuteranno a prevenire conseguenze potenzialmente nega-
tive per l’ambiente e per la salute dell’essere umano. Per ricevere informazioni
più dettagliate circa lo smaltimento delle vecchie apparecchiature in Vostro
possesso, Vi invitiamo a contattare gli enti pubblici di competenza, il servizio
di smaltimento riuti o il negozio nel quale avete acquistato il prodotto.
Latviešu valoda (Latvian) - Ekoloģiska informācija klientiem Eiropas Savienības
jurisdikcijā - Direktīvā 2002/96/EK ir prasība, ka aprīkojumu, kam pievienota
zīme uz paša izstrādājuma vai uz tā iesaiņojuma, nedrīkst izmest nešķirotā
veidā kopā ar komunālajiem atkritumiem (tiem, ko rada vietēji iedzīvotāji un
uzņēmumi). Šī zīme nozīmē to, ka šī ierīce ir jāizmet atkritumos tā, lai tā neno-
nāktu kopā ar parastiem mājsaimniecības atkritumiem. Jūsu pienākums ir šo un
citas elektriskas un elektroniskas ierīces izmest atkritumos, izmantojot īpašus
atkritumu savākšanas veidus un līdzekļus, ko nodrošina valsts un pašvaldību
iestādes. Ja izmešana atkritumos un pārstrāde tiek veikta pareizi, tad mazinās
iespējamais kaitējums dabai un cilvēku veselībai. Sīkākas ziņas par novecojuša
aprīkojuma izmešanu atkritumos jūs varat saņemt vietējā pašvaldībā, atkritumu
savākšanas dienestā, kā arī veikalā, kur iegādājāties šo izstrādājumu.
Lietuvškai (Lithuanian) - Aplinkosaugos informacija,skirta Europos Sąjungos
vartotojams - Europos direktyva 2002/96/EC numato, kad įrangos, kuri ir kurios
pakuotė yra pažymėta šiuo simboliu, negalima šalinti kartu su nerūšiuotomis
komunalinėmis atliekomis. Šis simbolis rodo, kad gaminį reikia šalinti atskirai
nuo bendro buitinių atliekų srauto. Jūs privalote užtikrinti, kad ši ir kita elektros
ar elektroninė įranga būtų šalinama per tam tikras nacionalinės ar vietinės
valdžios nustatytas atliekų rinkimo sistemas. Tinkamai šalinant ir perdirbant
atliekas, bus išvengta galimos žalos aplinkai ir žmonių sveikatai. Daugiau infor-
macijos apie jūsų senos įrangos šalinimą gali pateikti vietinės valdžios instituci-
jos, atliekų šalinimo tarnybos arba parduotuvės, kuriose įsigijote tą gaminį.
Malti (Maltese) - Informazzjoni Ambjentali għal Klijenti-Unjoni Ewropea
Id-Direttiva Ewropea 2002/96/KE titlob li t-tagħmir li jkun h is-simbolu fuq
il-prodott u/jew fuq l-ippakkjar ma jistax jintrema ma’ skart muniċipali li ma
ġiex isseparat. Is-simbolu jindika li dan il-prodott għandu jintrema separat-
ament minn ma’ l-iskart domestiku regolari. Hija responsabbiltà tiegħek li
tarmi dan it-tagħmir u kull tagħmir ieħor ta’ l-elettriku u elettroniku permezz
ta’ faċilitajiet ta’ ġbir appuntati apposta mill-gvern jew mill-awtoritajiet lokali.
Ir-rimi b’mod korrett u r-riċiklaġġ jgħin jipprevjeni konsegwenzi negattivi
potenzjali għall-ambjent u għas-saħħa tal-bniedem. Għal aktar informazzjoni
dettaljata dwar ir-rimi tat-tagħmir antik tiegħek, jekk jogħġbok ikkuntattja
lill-awtoritajiet lokali tiegħek, is-servizzi għar-rimi ta’ l-iskart, jew il-ħanut minn
fejn xtrajt il-prodott.
Magyar (Hungarian) - Környezetvédelmi információ azeurópai uniós vásárlók
számára - A 2002/96/EC számú európai uniós irányelv megkívánja, hogy
azokat a termékeket, amelyeken, és/vagy amelyek csomagolásán az alábbi
címke megjelenik, tilos a többi szelektálatlan lakossági hulladékkal együtt
kidobni. A címke azt jelöli, hogy az adott termék kidobásakor a szokványos
háztartási hulladékelszállítási rendszerektõl elkülönített eljárást kell alkalmazni.
Az Ön felelõssége, hogy ezt, és más elektromos és elektronikus berendezéseit
a kormányzati vagy a helyi hatóságok által kijelölt gyűjtõredszereken keresztül
számolja fel. A megfelelõ hulladékfeldolgozás segít a környezetre és az emberi
egészségre potenciálisan ártalmas negatív hatások megelõzésében. Ha
elavult berendezéseinek felszámolásához további részletes információra van
szüksége, kérjük, lépjen kapcsolatba a helyi hatóságokkal, a hulladékfeldolgo-
zási szolgálattal, vagy azzal üzlettel, ahol a terméket vásárolta.
Nederlands (Dutch) - Milieu-informatie voor klantenin de Europese Unie - De
Europese Richtlijn 2002/96/EC schrijft voor dat apparatuur die is voorzien van
dit symbool op het product of de verpakking, niet mag worden ingezameld
met niet-gescheiden huishoudelijk afval. Dit symbool geeft aan dat het
product apart moet worden ingezameld. U bent zelf verantwoordelijk voor de
vernietiging van deze en andere elektrische en elektronische apparatuur via
de daarvoor door de landelijke of plaatselijke overheid aangewezen inzamel-
ingskanalen. De juiste vernietiging en recycling van deze apparatuur voorkomt
mogelijke negatieve gevolgen voor het milieu en de gezondheid. Voor meer
informatie over het vernietigen van uw oude apparatuur neemt u contact op
met de plaatselijke autoriteiten of afvalverwerkingsdienst, of met de winkel
waar u het product hebt aangeschaft.
Norsk (Norwegian) - Miljøinformasjon for kunder i EU - EU-direktiv 2002/96/EF
krever at utstyr med følgende symbol avbildet på produktet og/eller paknin-
gen, ikke må kastes sammen med usortert avfall. Symbolet indikerer at dette
produktet skal håndteres atskilt fra ordinær avfallsinnsamling for husholdning-
savfall. Det er ditt ansvar å kvitte deg med dette produktet og annet elektrisk
og elektronisk avfall via egne innsamlingsordninger slik myndighetene eller
kommunene bestemmer. Korrekt avfallshåndtering og gjenvinning vil være
med på å forhindre mulige negative konsekvenser for miljø og helse. For
nærmere informasjon om håndtering av det kasserte utstyret ditt, kan du ta
kontakt med kommunen, en innsamlingsstasjon for avfall eller butikken der du
kjøpte produktet.
Polski (Polish) - Informacja dla klientów w Unii Europejskiej o przepisach
dotyczących ochrony środowiska - Dyrektywa Europejska 2002/96/EC
wymaga, aby sprzęt oznaczony symbolem znajdującym się na produkcie i/
lub jego opakowaniu nie był wyrzucany razem z innymi niesortowanymi
odpadami komunalnymi. Symbol ten wskazuje, że produkt nie powinien być
usuwany razem ze zwykłymi odpadami z gospodarstw domowych. Na Państwu
spoczywa obowiązek wyrzucania tego i innych urządzeń elektrycznych oraz
elektronicznych w punktach odbioru wyznaczonych przez władze krajowe lub
lokalne. Pozbywanie się sprzętu we właściwy sposób i jego recykling pomogą
zapobiec potencjalnie negatywnym konsekwencjom dla środowiska i zdrowia
ludzkiego. W celu uzyskania szczegółowych informacji o usuwaniu starego
sprzętu, prosimy zwrócić się do lokalnych władz, służb oczyszczania miasta lub
sklepu, w którym produkt został nabyty.
Português (Portuguese) - Informação ambiental paraclientes da União Euro-
peia - A Directiva Europeia 2002/96/CE exige que o equipamento que exibe
este símbolo no produto e/ou na sua embalagem não seja eliminado junto
com os resíduos municipais vnão separados. O símbolo indica que este pro-
duto deve ser eliminado separadamente dos resíduos domésticos regulares. É
da sua responsabilidade eliminar este e qualquer outro equipamento eléctrico
e electrónico através das instalações de recolha designadas pelas autoridades
governamentais ou locais. A eliminação e reciclagem correctas ajudarão a
prevenir as consequências negativas para o ambiente e para a saúde humana.
Para obter informações mais detalhadas sobre a forma de eliminar o seu
equipamento antigo, contacte as autoridades locais, os serviços de eliminação
de resíduos ou o estabelecimento comercial onde adquiriu o produto.
Română (Romanian) - Informaţii de mediu pentruclienţii din Uniunea Europe-
ană - Directiva europeană 2002/96/CE impune ca echipamentele care prezintă
acest simbol pe produs şi/sau pe ambalajul acestuia să nu e casate împreună
cu gunoiul menajer municipal. Simbolul indică faptul că acest produs trebuie
să e casat separat de gunoiul menajer obişnuit. Este responsabilitatea dvs. să
casaţi acest produs şi alte echipamente electrice şi electronice prin intermediul
unităţilor de colectare special desemnate de guvern sau de autorităţile locale.
Casarea şi reciclarea corecte vor ajuta la prevenirea potenţialelor consecinţe
negative asupra sănătăţii mediului şi a oamenilor. Pentru mai multe informaţii
detaliate cu privire la casarea acestui echipament vechi, contactaţi autorităţile
locale, serviciul de salubrizare sau magazinul de la care aţi achiziţionat
produsul.
Slovenčina (Slovak) - Informácie o ochrane životnéhoprostredia pre zákazníkov
v Európskej únii - Podľa európskej smernice 2002/96/ES zariadenie s týmto
symbolomna produkte a/alebo jeho balení nesmie byť likvidované spolu s
netriedeným komunálnym odpadom. Symbol znamená, že produkt by sa mal
likvidovať oddelene od bežného odpadu z domácností. Je vašou povinnosťou
likvidovať toto i ostatné elektrické a elektronické zariadenia prostredníctvom
špecializovaných zberných zariadení určených vládou alebo miestnymi orgán-
mi. Správna likvidácia a recyklácia pomôže zabrániť prípadným negatívnym
dopadom na životné prostredie a zdravie ľudí. Ak máte záujem o podrobnejšie
informácie o likvidácii starého zariadenia, obráťte sa, prosím, na miestne
orgány, organizácie zaoberajúce sa likvidáciou odpadov alebo obchod, v
ktorom ste si produkt zakúpili.
Slovenščina (Slovene) - Okoljske informacije za stranke v Evropski uniji - Ev-
ropska direktiva 2002/96/ES prepoveduje odlaganje opreme s tem simbolom
na izdelku in/ali na embalaži z nesortiranimi komunalnimi odpadki. Ta simbol
opozarja, da je treba izdelek zavreči ločeno od preostalih gospodinjskih
odpadkov. Vaša odgovornost je, da to in preostalo električno in elektronsko
opremo oddate na posebna zbirališča, ki jih določijo državne ustanove ali loka-
lne oblasti. S pravilnim odlaganjem in recikliranjem boste preprečili morebitne
škodljive vplive na okolje in zdravje ljudi. Če želite izvedeti več o odlaganju
stare opreme, se obrnite na lokalne oblasti, odlagališče odpadkov ali trgovino,
kjer ste izdelek kupili.
Suomi (Finnish) - Ympäristöä koskevia tietoja EU- alueen asiakkaille
EU-direktiivi 2002/96/EY edellyttää, että jos laitteistossa on tämä symboli itse
tuotteessa ja/tai sen pakkauksessa, laitteistoa ei saa hävittää lajittelematto-
man yhdyskuntajätteen mukana. Symboli merkitsee sitä, että tämä tuote on
hävitettävä erillään tavallisesta kotitalousjätteestä. Sinun vastuullasi on hävittää
tämä elektroniikkatuote ja muut vastaavat elektroniikkatuotteet viemällä
tuote tai tuotteet viranomaisten määräämään keräyspisteeseen. Laitteiston
mahdolliset kielteiset vaikutukset ympäristöön ja ihmisten terveyteen. Lisäti-
etoja vanhan laitteiston oikeasta hävitystavasta saa paikallisilta viranomaisilta,
jätteenhävityspalvelusta tai siitä myymälästä, josta ostit tuotteen
Svenska (Swedish) - Miljöinformation för kunder i Europeiska unionen - Det
europeiska direktivet 2002/96/EC kräver att utrustning med denna symbol på
produkten och/eller förpackningen inte får kastas med osorterat kommunalt
avfall. Symbolen visar att denna produkt bör kastas efter att den avskiljts
från vanligt hushållsavfall. Det faller på ditt ansvar att kasta denna och annan
elektrisk och elektronisk utrustning på fastställda insamlingsplatser utsedda av
regeringen eller lokala myndigheter. Korrekt kassering och återvinning skyddar
mot eventuella negativa konsekvenser för miljön och personhälsa. För mer
detaljerad information om kassering av din gamla utrustning kontaktar du dina
lokala myndigheter, avfallshanteringen eller butiken där du köpte produkten.
© 2022 Airspan Networks Inc. All rights reserved.
sale of the Products.
FCC
This device complies with part 15 of the FCC Rules. Operation is sub-
ject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio commu-
nications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to
correct the interference at his own expense.
The radiated output power of this device is below the FCC radio
frequency exposure limits. Nevertheless, the device should be used in
such a manner that the potential for human contact during the normal
operation is minimized. In order to avoid the possibility of exceeding
the FCC radio frequency exposure limit, human proximity to the anten-
na should be more than 3m.
When mounting the radio antenna, in accordance with the Part 15 UNII-
1 band requirements, the antenna must not exceed 125 mW (21 dBm)
e.i.r.p. at any elevation angle above 30 degrees as measured from the
horizon).
Important: Changes or modications to this product not authorized by
Mimosa Networks, Inc. could void the electromagneticcompatibility
(EMC) and wireless compliance and negate your authority to-
operate the product. The information in this guide may change without
notice. The manufacturer assumes no responsibility for any errors that
may appear in this guide.
Industry Canada
This Class A digital apparatus complies with Canadian CAN ICES-3(A).
Cet appareil numérique de la classe A est conforme à la norme NMB-
3(A) Canada.
Under Industry Canada regulations, this radio transmitter may only
operate using an antenna of a type and maximum (or lesser) gain
approved for the transmitter by Industry Canada. To reduce potential
radio interference to other users, the antenna type and its gain should
be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is
not more than that necessary for successful communication.
Pour réduire le risque d’interférence aux autres utilisateurs, le type
d’antenne et son gain doivent être choisies de façon que la puissance
isotrope rayonnée équivalente (PIRE) ne dépasse pas ce qui est néces-
saire pour une communication réussie.
This device complies with Industry Canada licence-exempt RSS stan-
dard(s). Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation
of the device.
Cet appareil est conforme à la norme RSS Industrie Canada exempts de
licence norme(s). Son fonctionnement est soumis aux deux conditions
suivantes:
(1) Cet appareil ne peut pas provoquer d’interférences et (2) Cet ap-
pareil doit accepter toute interférence, y compris les interférences qui
peuvent causer un mauvais fonctionnement du dispositif.
Australia & New Zealand
Warning: This is a Class A product. In a domestic environment
this product may cause radio interference in which case the user
may be required to take adequate measures.
European Compliance Statement
CE Marking on this product represents that this product com-
plies with all requirements that are applicable to it.
Europe EU Declaration of Conformity
This device can be used in the European Community. A copy of the EU Decla-
ration of Conformity is available at: www.mimosa.co/compliance.
Български (Bulgarian) - Airspan Networks Inc. декларира, че това Airspan
Networks Inc. приспособление е в съответствие със съществените
изисквания и другите приложими правила на Директива 2014/53/EU.
Česky (Czech) - Společnost Airspan Networks Inc. tímto prohlašuje, že tento
Airspan Networks Inc. zařízení je ve shodě se základními požadavky a dalšími
příslušnými ustanoveními směrnice 2014/53/EU.
Dansk (Danish) - Undertegnede Airspan Networks Inc. erklærer herved, at
følgende udstyr Airspan Networks Inc. enhed overholder de væsentlige krav
og øvrige relevante krav i direktiv 2014/53/EU.
Deutsch (German) - Hiermit erklärt Airspan Networks Inc., dass sich das
Airspan Networks Inc. Gerät in Übereinstimmung mit den grundlegenden
Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie
2014/53/EU benden.
Eesti (Estonian) - Käesolevaga kinnitab Airspan Networks Inc., et see Airspan
Networks Inc. seade vastab direktiivi 2014/53/EU põhinõuetele ja nimetatud
direktiivist tulenevatele teistele asjakohastele sätetele.
English - Hereby, Airspan Networks Inc. declares that this Airspan Networks
Inc. device is in compliance with the essential requirements and other relevant
provisions of Directive 2014/53/EU.
Español (Spanish) - Por medio de la presente Airspan Networks Inc. declara
que este Airspan Networks Inc. dispositivo cumple con los requisitos esen-
ciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva
2014/53/EU.
Ελληνικά (Greek) - Mε την παρούσα, η Airspan Networks Inc. δηλώνει ότι αυτή
η συσκευή Airspan Networks Inc. συσκευή συμμορφώνεται προς τις βασικές
απαιτήσεις και τις λοιπές σχετικές διατάξεις της Οδηγίας 2014/53/EU.
Français (French) - Par la présente Airspan Networks Inc. déclare que ce
Airspan Networks Inc. appareil est conforme aux exigences essentielles et aux
autres dispositions pertinentes de la directive 2014/53/EU.
Islenska (Icelandic) - Airspan Networks Inc. lýsir því hér með yr að þetta
Airspan Networks Inc. tæki fullnægir lágmarkskröfum og öðrum viðeigandi
ákvæðum Evróputilskipunar 2014/53/EU.
Italiano (Italian) - Con la presente Airspan Networks Inc. dichiara che questo
Airspan Networks Inc. dispositivo è conforme ai requisiti essenziali ed alle altre
disposizioni pertinenti stabilite dalla direttiva 2014/53/EU.
Latviski (Latvian) - Ar šo Airspan Networks Inc. deklarē, ka šī Airspan Networks
Inc. ierīce atbilst Direktīvas 2014/53/EU būtiskajām prasībām un citiem ar to
saistītajiem noteikumiem.
Lietuvių (Lithuanian) - Šiuo „Airspan Networks Inc.“ deklaruoja, kad šis Airspan
Networks Inc. atitinka esminius reikalavimus ir kitas 2014/53/EUB Direktyvos
nuostatas.
Magyar (Hungarian) - Alulírott, Airspan Networks Inc. nyilatkozom, hogy a Air-
span Networks Inc. eszköz megfelel a vonatkozó alapvetõ követelményeknek
és az 2014/53/EU irányelv egyéb elõírásainak.
Malti (Maltese) - Hawnhekk, Airspan Networks Inc., jiddikjara li dan Airspan
Networks Inc. tagħmir jikkonforma mal-ħtiġijiet essenzjali u ma provvedimenti
oħrajn relevanti li hemm d-Dirrettiva 2014/53/EU. 705-00034 REV A
Nederlands (Dutch) - Hierbij verklaart Airspan Networks Inc. dat dit Airspan
Networks Inc. toestel in overeenstemming is met de essentiële eisen en de
andere bepalingen van richtlijn 2014/53/EU.
Norsk (Norwegian) - Airspan Networks Inc. erklærer herved at dette Airspan
Networks Inc. apparatet er i samsvar med de grunnleggende kravene og
øvrige relevante krav i EU-direktivet 2014/53/EU.
Polski (Polish)- Niniejszym Airspan Networks Inc. oświadcza, że ten Airspan
Networks Inc. urządzenie są zgodne z zasadniczymi wymogami oraz pozos-
tałymi stosownymi postanowieniami Dyrektywy 2014/53/EU.
Português (Portugese) - Airspan Networks Inc. declara que este Airspan
Networks Inc. dispositivo está em conformidade com os requisitos essenciais
e outras disposições da Directiva 2014/53/EU.
Română (Romanian) - Prin prezenta, Airspan Networks Inc. declară că acest
Airspan Networks Inc. aparat este în conformitate cu cerinţele esenţiale şi cu
celelalte prevederi relevante ale Directivei 2014/53/EU.
Slovensky (Slovak) - Airspan Networks Inc. týmto vyhlasuje, že toto Airspan
Networks Inc. zariadenie spĺňa základné požiadavky a všetky príslušné ustano-
venia Smernice 2014/53/EU.
Slovensko (Slovene) - Airspan Networks Inc. izjavlja, da je ta Airspan Networks
Inc. naprava skladne z bistvenimi zahtevami in ostalimi ustreznimi določili
direktive 2014/53/EU.
Suomi (Finnish) - Airspan Networks Inc. vakuuttaa täten, että tämä Airspan
Networks Inc. tyyppinen laite on direktiivin 2014/53/EU oleellisten vaatimusten
ja sitä koskevien direktiivin muiden ehtojen mukainen.
Svenska (Swedish) - Härmed intygar Airspan Networks Inc. att denna Airspan
Networks Inc. apparat står i överensstämmelse med de väsentliga egenskapsk-
rav och övriga relevanta bestämmelser som framgår av direktiv 2014/53/EU.
RoHS & WEEE Compliance
User Information for Consumer Products Covered by EU Directive 2002/96/EC
on Waste Electric and Electronic Equipment (WEEE).
This document contains important information for users with re-
gards to the proper disposal and recycling of Airspan Networks Inc.
products. Consumers are required to comply with this notice for all
electronic products bearing this symbol.
English - Environmental Information for Customers in the European Union
European Directive 2002/96/EC requires that the equipment bearing this
symbol on the product and/or its packaging must not be disposed of with
unsorted municipal waste. The symbol indicates that this product should
be disposed of separately from regular household waste streams. It is your
responsibility to dispose of this and other electric and electronic equipment
via designated collection facilities appointed by the government or local
authorities. Correct disposal and recycling will help prevent potential negative
consequences to the environment and human health. For more detailed
information about the disposal of your old equipment, please contact your
local authorities, waste disposal service, or the shop where you purchased the
product.
Български (Bulgarian) - Информация относноопазването на околната
среда за потребители вЕвропейския съюз -Европейска директива
2002/96/EC изисква уредите, носещи този символ върху изделието и/
или опаковката му, да не се изхвърля т с несортирани битови отпадъци.
Символът обозначава, че изделието трябва да се изхвърля отделно
от сметосъбирането на обикновените битови отпадъци. Ваша е
отговорността този и другите електрически и електронни уреди да се
изхвърлят в предварително определени от държавните или общински
органи специализирани пунктове за събиране. Правилното изхвърляне
и рециклиране ще спомогнат да се предотвратят евентуални вредни за
околната среда и здравето на населението последствия. За по-подробна
информация относно изхвърлянето на вашите стари уреди се обърнете
към местните власти, службите за сметосъбиране или магазина, от който
сте закупили уреда.
Čeština (Czech) - Informace o ochraně životníhoprostředí pro zákazníky v
zemích Evropské unie - Evropská směrnice 2002/96/ES zakazuje, aby zařízení
označené tímto symbolem na produktu anebo na obalu bylo likvidováno s
netříděným komunálním odpadem. Tento symbol udává, že daný produkt musí
být likvidován odděleně od běžného komunálního odpadu. Odpovídáte za
likvidaci tohoto produktu a dalších elektrických a elektronických zařízení pros-
třednictvím určených sběrných míst stanovených vládou nebo místními úřady.
Správná likvidace a recyklace pomáhá předcházet potenciálním negativním
dopadům na životní prostředí a lidské zdraví. Podrobnější informace o likvidaci
starého vybavení si laskavě vyžádejte od místních úřadů, podniku zabývajícího
se likvidací komunálních odpadů nebo obchodu, kde jste produkt zakoupili.
Dansk (Danish) - Miljøinformation for kunder i EU - EU-direktiv 2002/96/EF
kræver, at udstyr der bærer dette symbol på produktet og/eller emballagen
ikke må bortskaffes som usorteret kommunalt affald. Symbolet betyder, at
dette produkt skal bortskaffes adskilt fra det almindelige husholdningsaffald.
Det er dit ansvar at bortskaffe dette og andet elektrisk og elektronisk udstyr
via bestemte indsamlingssteder udpeget af staten eller de lokale myndighed-
er. Korrekt bortskaffelse og genvinding vil hjælpe med til at undgå mulige
skader for miljøet og menneskers sundhed. Kontakt venligst de lokale myn-
digheder, renovationstjenesten eller den butik, hvor du har købt produktet,
angående mere detaljeret information om bortskaffelse af dit gamle udstyr.
Deutsch (German) - Umweltinformation für Kunden innerhalb der Eu-
ropäischen Union - Die Europäische Richtlinie 2002/96/EC verlangt, dass
technische Ausrüstung, die direkt am Gerät und/oder an der Verpackung mit
diesem Symbol versehen ist, nicht zusammen mit unsortiertem Gemeinde-
abfall entsorgt werden darf. Das Symbol weist darauf hin, dass das Produkt
von regulärem Haushaltmüll getrennt entsorgt werden sollte. Es liegt in Ihrer
Verantwortung, dieses Gerät und andere elektrische und elektronische Geräte
über die dafür zuständigen und von der Regierung oder örtlichen Behörden
dazu bestimmten Sammelstellen zu entsorgen. Ordnungsgemäßes Entsorgen
und Recyceln trägt dazu bei, potentielle negative Folgen für Umwelt und die
menschliche Gesundheit zu vermeiden. Wenn Sie weitere Informationen zur
Entsorgung Ihrer Altgeräte benötigen, wenden Sie sich bitte an die örtlichen
Behörden oder städtischen Entsorgungsdienste oder an den Händler, bei dem
Sie das Produkt erworben haben.
Eesti (Estonian) - Keskkonnaalane informatsioon Euroopa Liidus asuvatele kli-
entidele - Euroopa Liidu direktiivi 2002/96/EÜ nõuete kohaselt on seadmeid,
millel on tootel või pakendil käesolev sümbol keelatud kõrvaldada koos sort-
eerimata olmejäätmetega. See sümbol näitab, et toode tuleks kõrvaldada eral-
di tavalistest olmejäätmevoogudest. Olete kohustatud kõrvaldama käesoleva
ja ka muud elektri- ja elektroonikaseadmed riigi või kohalike ametiasutuste
poolt ette nähtud kogumispunktide kaudu. Seadmete korrektne kõrvaldamine
ja ringlussevõtt aitab vältida võimalikke negatiivseid tagajärgi keskkonnale
ning inimeste tervisele. Vanade seadmete kõrvaldamise kohta täpsema
informatsiooni saamiseks võtke palun ühendust kohalike ametiasutustega,
jäätmekäitlusrmaga või kauplusega, kust te toote ostsite.
Español (Spanish) - Información medioambiental paraclientes de la Unión
Europea - La Directiva 2002/96/CE de la UE exige que los equipos quel leven
este símbolo en el propio aparato y/o en su embalaje no deben eliminarse
junto con otros residuos urbanos no seleccionados. El símbolo indica que el
producto en cuestión debe separarse de los residuos domésticos conven-
cionales con vistas a su eliminación. Es responsabilidad suya desechar este y
cualesquiera otros aparatos eléctricos y electrónicos a través de los puntos de
recogida que ponen a su disposición el gobierno y las autoridades locales.
Al desechar y reciclar correctamente estos aparatos estará contribuyendo a
evitar posibles consecuencias negativas para el medio ambiente y la salud de
las personas. Si desea obtener información más detallada sobre la eliminación
segura de su aparato usado, consulte a las autoridades locales, al servicio de
recogida y eliminación de residuos de su zona o pregunte en la tienda donde
adquirió el producto.
Ελληνικά (Greek) - Στοιχεία περιβαλλοντικής προστασίας για πελάτες εντός
της ΕυρωπαϊκήςΈνωσης - Σύμφωνα με την Κοινοτική Οδηγία 2002/96/
EC, ο εξοπλισμός που φέρει αυτό το σύμβολο στο προϊόν ή/και τη
συσκευασία του δεν πρέπει να απορρίπτεται μαζί με τα μη διαχωρισμένα
αστικά απορρίμματα. Το σύμβολο υποδεικνύει ότι αυτό το προϊόν θα
πρέπει να απορρίπτεται ξεχωριστά από τα συνήθη οικιακά απορρίμματα.
Είστε υπεύθυνος για την απόρριψη του παρόντος και άλλου ηλεκτρικού
και ηλεκτρονικού εξοπλισμού μέσω των καθορισμένων εγκαταστάσεων
συγκέντρωσης απορριμμάτων, οι οποίες ορίζονται από το κράτος ή τις
αρμόδιες τοπικές αρχές. Η σωστή απόρριψη και ανακύκλωση συμβάλλει στην
πρόληψη ενδεχόμενων αρνητικών επιπτώσεων στο περιβάλλον και την υγεία.
Για περισσότερες πληροφορίες σχετικά με την απόρριψη του παλαιού σας
εξοπλισμού, επικοινωνήστε με τις τοπικές αρχές, τις υπηρεσίες αποκομιδής
απορριμμάτων ή το κατάστημα από το οποίο αγοράσατε το προϊόν.
Français (French) - Informations environnementales pour les clients de l’Union
européenne - La directive européenne 2002/96/CE exige que l’équipement
, sur lequel est apposé ce symbole sur le produit et/ou son emballage ne
soit pas jeté avec les autres ordures ménagères. Ce symbole indique que
le produit doit être éliminé dans un circuit distinct de celui pour les déchets
des ménages. Il est de votre responsabilité de jeter ce matériel ainsi que tout
autre matériel électrique ou électronique par les moyens de collecte indiqués
par le gouvernement et les pouvoirs publics des collectivités territoriales.
L’élimination et le recyclage en bonne et due forme ont pour but de lutter
contre l’impact néfaste potentiel de ce type de produits sur l’environnement
et la santé publique. Pour plus d’informations sur le mode d’élimination de
votre ancien équipement, veuillez prendre contact avec les pouvoirs publics
locaux, le service de traitement des déchets, ou l’endroit où vous avez acheté
le produit.
Italiano (Italian) - Informazioni relative all’ambiente per i clienti residenti
nell’Unione Europea - La direttiva europea 2002/96/EC richiede che le appare-
cchiature contrassegnate con questo simbolo sul prodotto e/o sull’imballaggio
non siano smaltite insieme ai riuti urbani non differenziati. Il simbolo indica
che questo prodotto non deve essere smaltito insieme ai normali riuti do-
mestici. È responsabilità del proprietario smaltire sia questi prodotti sia le altre
apparecchiature elettriche ed elettroniche mediante le speciche strutture di
raccolta indicate dal governo o dagli enti pubblici locali. Il corretto smaltimen-
to ed il riciclaggio aiuteranno a prevenire conseguenze potenzialmente nega-
tive per l’ambiente e per la salute dell’essere umano. Per ricevere informazioni
più dettagliate circa lo smaltimento delle vecchie apparecchiature in Vostro
possesso, Vi invitiamo a contattare gli enti pubblici di competenza, il servizio
di smaltimento riuti o il negozio nel quale avete acquistato il prodotto.
Latviešu valoda (Latvian) - Ekoloģiska informācija klientiem Eiropas Savienības
jurisdikcijā - Direktīvā 2002/96/EK ir prasība, ka aprīkojumu, kam pievienota
zīme uz paša izstrādājuma vai uz tā iesaiņojuma, nedrīkst izmest nešķirotā
veidā kopā ar komunālajiem atkritumiem (tiem, ko rada vietēji iedzīvotāji un
uzņēmumi). Šī zīme nozīmē to, ka šī ierīce ir jāizmet atkritumos tā, lai tā neno-
nāktu kopā ar parastiem mājsaimniecības atkritumiem. Jūsu pienākums ir šo un
citas elektriskas un elektroniskas ierīces izmest atkritumos, izmantojot īpašus
atkritumu savākšanas veidus un līdzekļus, ko nodrošina valsts un pašvaldību
iestādes. Ja izmešana atkritumos un pārstrāde tiek veikta pareizi, tad mazinās
iespējamais kaitējums dabai un cilvēku veselībai. Sīkākas ziņas par novecojuša
aprīkojuma izmešanu atkritumos jūs varat saņemt vietējā pašvaldībā, atkritumu
savākšanas dienestā, kā arī veikalā, kur iegādājāties šo izstrādājumu.
Lietuvškai (Lithuanian) - Aplinkosaugos informacija,skirta Europos Sąjungos
vartotojams - Europos direktyva 2002/96/EC numato, kad įrangos, kuri ir kurios
pakuotė yra pažymėta šiuo simboliu, negalima šalinti kartu su nerūšiuotomis
komunalinėmis atliekomis. Šis simbolis rodo, kad gaminį reikia šalinti atskirai
nuo bendro buitinių atliekų srauto. Jūs privalote užtikrinti, kad ši ir kita elektros
ar elektroninė įranga būtų šalinama per tam tikras nacionalinės ar vietinės
valdžios nustatytas atliekų rinkimo sistemas. Tinkamai šalinant ir perdirbant
atliekas, bus išvengta galimos žalos aplinkai ir žmonių sveikatai. Daugiau infor-
macijos apie jūsų senos įrangos šalinimą gali pateikti vietinės valdžios instituci-
jos, atliekų šalinimo tarnybos arba parduotuvės, kuriose įsigijote tą gaminį.
Malti (Maltese) - Informazzjoni Ambjentali għal Klijenti-Unjoni Ewropea
Id-Direttiva Ewropea 2002/96/KE titlob li t-tagħmir li jkun h is-simbolu fuq
il-prodott u/jew fuq l-ippakkjar ma jistax jintrema ma’ skart muniċipali li ma
ġiex isseparat. Is-simbolu jindika li dan il-prodott għandu jintrema separat-
ament minn ma’ l-iskart domestiku regolari. Hija responsabbiltà tiegħek li
tarmi dan it-tagħmir u kull tagħmir ieħor ta’ l-elettriku u elettroniku permezz
ta’ faċilitajiet ta’ ġbir appuntati apposta mill-gvern jew mill-awtoritajiet lokali.
Ir-rimi b’mod korrett u r-riċiklaġġ jgħin jipprevjeni konsegwenzi negattivi
potenzjali għall-ambjent u għas-saħħa tal-bniedem. Għal aktar informazzjoni
dettaljata dwar ir-rimi tat-tagħmir antik tiegħek, jekk jogħġbok ikkuntattja
lill-awtoritajiet lokali tiegħek, is-servizzi għar-rimi ta’ l-iskart, jew il-ħanut minn
fejn xtrajt il-prodott.
Magyar (Hungarian) - Környezetvédelmi információ azeurópai uniós vásárlók
számára - A 2002/96/EC számú európai uniós irányelv megkívánja, hogy
azokat a termékeket, amelyeken, és/vagy amelyek csomagolásán az alábbi
címke megjelenik, tilos a többi szelektálatlan lakossági hulladékkal együtt
kidobni. A címke azt jelöli, hogy az adott termék kidobásakor a szokványos
háztartási hulladékelszállítási rendszerektõl elkülönített eljárást kell alkalmazni.
Az Ön felelõssége, hogy ezt, és más elektromos és elektronikus berendezéseit
a kormányzati vagy a helyi hatóságok által kijelölt gyűjtõredszereken keresztül
számolja fel. A megfelelõ hulladékfeldolgozás segít a környezetre és az emberi
egészségre potenciálisan ártalmas negatív hatások megelõzésében. Ha
elavult berendezéseinek felszámolásához további részletes információra van
szüksége, kérjük, lépjen kapcsolatba a helyi hatóságokkal, a hulladékfeldolgo-
zási szolgálattal, vagy azzal üzlettel, ahol a terméket vásárolta.
Nederlands (Dutch) - Milieu-informatie voor klantenin de Europese Unie - De
Europese Richtlijn 2002/96/EC schrijft voor dat apparatuur die is voorzien van
dit symbool op het product of de verpakking, niet mag worden ingezameld
met niet-gescheiden huishoudelijk afval. Dit symbool geeft aan dat het
product apart moet worden ingezameld. U bent zelf verantwoordelijk voor de
vernietiging van deze en andere elektrische en elektronische apparatuur via
de daarvoor door de landelijke of plaatselijke overheid aangewezen inzamel-
ingskanalen. De juiste vernietiging en recycling van deze apparatuur voorkomt
mogelijke negatieve gevolgen voor het milieu en de gezondheid. Voor meer
informatie over het vernietigen van uw oude apparatuur neemt u contact op
met de plaatselijke autoriteiten of afvalverwerkingsdienst, of met de winkel
waar u het product hebt aangeschaft.
Norsk (Norwegian) - Miljøinformasjon for kunder i EU - EU-direktiv 2002/96/EF
krever at utstyr med følgende symbol avbildet på produktet og/eller paknin-
gen, ikke må kastes sammen med usortert avfall. Symbolet indikerer at dette
produktet skal håndteres atskilt fra ordinær avfallsinnsamling for husholdning-
savfall. Det er ditt ansvar å kvitte deg med dette produktet og annet elektrisk
og elektronisk avfall via egne innsamlingsordninger slik myndighetene eller
kommunene bestemmer. Korrekt avfallshåndtering og gjenvinning vil være
med på å forhindre mulige negative konsekvenser for miljø og helse. For
nærmere informasjon om håndtering av det kasserte utstyret ditt, kan du ta
kontakt med kommunen, en innsamlingsstasjon for avfall eller butikken der du
kjøpte produktet.
Polski (Polish) - Informacja dla klientów w Unii Europejskiej o przepisach
dotyczących ochrony środowiska - Dyrektywa Europejska 2002/96/EC
wymaga, aby sprzęt oznaczony symbolem znajdującym się na produkcie i/
lub jego opakowaniu nie był wyrzucany razem z innymi niesortowanymi
odpadami komunalnymi. Symbol ten wskazuje, że produkt nie powinien być
usuwany razem ze zwykłymi odpadami z gospodarstw domowych. Na Państwu
spoczywa obowiązek wyrzucania tego i innych urządzeń elektrycznych oraz
elektronicznych w punktach odbioru wyznaczonych przez władze krajowe lub
lokalne. Pozbywanie się sprzętu we właściwy sposób i jego recykling pomogą
zapobiec potencjalnie negatywnym konsekwencjom dla środowiska i zdrowia
ludzkiego. W celu uzyskania szczegółowych informacji o usuwaniu starego
sprzętu, prosimy zwrócić się do lokalnych władz, służb oczyszczania miasta lub
sklepu, w którym produkt został nabyty.
Português (Portuguese) - Informação ambiental paraclientes da União Euro-
peia - A Directiva Europeia 2002/96/CE exige que o equipamento que exibe
este símbolo no produto e/ou na sua embalagem não seja eliminado junto
com os resíduos municipais vnão separados. O símbolo indica que este pro-
duto deve ser eliminado separadamente dos resíduos domésticos regulares. É
da sua responsabilidade eliminar este e qualquer outro equipamento eléctrico
e electrónico através das instalações de recolha designadas pelas autoridades
governamentais ou locais. A eliminação e reciclagem correctas ajudarão a
prevenir as consequências negativas para o ambiente e para a saúde humana.
Para obter informações mais detalhadas sobre a forma de eliminar o seu
equipamento antigo, contacte as autoridades locais, os serviços de eliminação
de resíduos ou o estabelecimento comercial onde adquiriu o produto.
Română (Romanian) - Informaţii de mediu pentruclienţii din Uniunea Europe-
ană - Directiva europeană 2002/96/CE impune ca echipamentele care prezintă
acest simbol pe produs şi/sau pe ambalajul acestuia să nu e casate împreună
cu gunoiul menajer municipal. Simbolul indică faptul că acest produs trebuie
să e casat separat de gunoiul menajer obişnuit. Este responsabilitatea dvs. să
casaţi acest produs şi alte echipamente electrice şi electronice prin intermediul
unităţilor de colectare special desemnate de guvern sau de autorităţile locale.
Casarea şi reciclarea corecte vor ajuta la prevenirea potenţialelor consecinţe
negative asupra sănătăţii mediului şi a oamenilor. Pentru mai multe informaţii
detaliate cu privire la casarea acestui echipament vechi, contactaţi autorităţile
locale, serviciul de salubrizare sau magazinul de la care aţi achiziţionat
produsul.
Slovenčina (Slovak) - Informácie o ochrane životnéhoprostredia pre zákazníkov
v Európskej únii - Podľa európskej smernice 2002/96/ES zariadenie s týmto
symbolomna produkte a/alebo jeho balení nesmie byť likvidované spolu s
netriedeným komunálnym odpadom. Symbol znamená, že produkt by sa mal
likvidovať oddelene od bežného odpadu z domácností. Je vašou povinnosťou
likvidovať toto i ostatné elektrické a elektronické zariadenia prostredníctvom
špecializovaných zberných zariadení určených vládou alebo miestnymi orgán-
mi. Správna likvidácia a recyklácia pomôže zabrániť prípadným negatívnym
dopadom na životné prostredie a zdravie ľudí. Ak máte záujem o podrobnejšie
informácie o likvidácii starého zariadenia, obráťte sa, prosím, na miestne
orgány, organizácie zaoberajúce sa likvidáciou odpadov alebo obchod, v
ktorom ste si produkt zakúpili.
Slovenščina (Slovene) - Okoljske informacije za stranke v Evropski uniji - Ev-
ropska direktiva 2002/96/ES prepoveduje odlaganje opreme s tem simbolom
na izdelku in/ali na embalaži z nesortiranimi komunalnimi odpadki. Ta simbol
opozarja, da je treba izdelek zavreči ločeno od preostalih gospodinjskih
odpadkov. Vaša odgovornost je, da to in preostalo električno in elektronsko
opremo oddate na posebna zbirališča, ki jih določijo državne ustanove ali loka-
lne oblasti. S pravilnim odlaganjem in recikliranjem boste preprečili morebitne
škodljive vplive na okolje in zdravje ljudi. Če želite izvedeti več o odlaganju
stare opreme, se obrnite na lokalne oblasti, odlagališče odpadkov ali trgovino,
kjer ste izdelek kupili.
Suomi (Finnish) - Ympäristöä koskevia tietoja EU- alueen asiakkaille
EU-direktiivi 2002/96/EY edellyttää, että jos laitteistossa on tämä symboli itse
tuotteessa ja/tai sen pakkauksessa, laitteistoa ei saa hävittää lajittelematto-
man yhdyskuntajätteen mukana. Symboli merkitsee sitä, että tämä tuote on
hävitettävä erillään tavallisesta kotitalousjätteestä. Sinun vastuullasi on hävittää
tämä elektroniikkatuote ja muut vastaavat elektroniikkatuotteet viemällä
tuote tai tuotteet viranomaisten määräämään keräyspisteeseen. Laitteiston
mahdolliset kielteiset vaikutukset ympäristöön ja ihmisten terveyteen. Lisäti-
etoja vanhan laitteiston oikeasta hävitystavasta saa paikallisilta viranomaisilta,
jätteenhävityspalvelusta tai siitä myymälästä, josta ostit tuotteen
Svenska (Swedish) - Miljöinformation för kunder i Europeiska unionen - Det
europeiska direktivet 2002/96/EC kräver att utrustning med denna symbol på
produkten och/eller förpackningen inte får kastas med osorterat kommunalt
avfall. Symbolen visar att denna produkt bör kastas efter att den avskiljts
från vanligt hushållsavfall. Det faller på ditt ansvar att kasta denna och annan
elektrisk och elektronisk utrustning på fastställda insamlingsplatser utsedda av
regeringen eller lokala myndigheter. Korrekt kassering och återvinning skyddar
mot eventuella negativa konsekvenser för miljön och personhälsa. För mer
detaljerad information om kassering av din gamla utrustning kontaktar du dina
lokala myndigheter, avfallshanteringen eller butiken där du köpte produkten.
© 2022 Airspan Networks Inc. All rights reserved.
sale of the Products.
FCC
This device complies with part 15 of the FCC Rules. Operation is sub-
ject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio commu-
nications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to
correct the interference at his own expense.
The radiated output power of this device is below the FCC radio
frequency exposure limits. Nevertheless, the device should be used in
such a manner that the potential for human contact during the normal
operation is minimized. In order to avoid the possibility of exceeding
the FCC radio frequency exposure limit, human proximity to the anten-
na should be more than 3m.
When mounting the radio antenna, in accordance with the Part 15 UNII-
1 band requirements, the antenna must not exceed 125 mW (21 dBm)
e.i.r.p. at any elevation angle above 30 degrees as measured from the
horizon).
Important: Changes or modications to this product not authorized by
Mimosa Networks, Inc. could void the electromagneticcompatibility
(EMC) and wireless compliance and negate your authority to-
operate the product. The information in this guide may change without
notice. The manufacturer assumes no responsibility for any errors that
may appear in this guide.
Industry Canada
This Class A digital apparatus complies with Canadian CAN ICES-3(A).
Cet appareil numérique de la classe A est conforme à la norme NMB-
3(A) Canada.
Under Industry Canada regulations, this radio transmitter may only
operate using an antenna of a type and maximum (or lesser) gain
approved for the transmitter by Industry Canada. To reduce potential
radio interference to other users, the antenna type and its gain should
be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is
not more than that necessary for successful communication.
Pour réduire le risque d’interférence aux autres utilisateurs, le type
d’antenne et son gain doivent être choisies de façon que la puissance
isotrope rayonnée équivalente (PIRE) ne dépasse pas ce qui est néces-
saire pour une communication réussie.
This device complies with Industry Canada licence-exempt RSS stan-
dard(s). Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation
of the device.
Cet appareil est conforme à la norme RSS Industrie Canada exempts de
licence norme(s). Son fonctionnement est soumis aux deux conditions
suivantes:
(1) Cet appareil ne peut pas provoquer d’interférences et (2) Cet ap-
pareil doit accepter toute interférence, y compris les interférences qui
peuvent causer un mauvais fonctionnement du dispositif.
Australia & New Zealand
Warning: This is a Class A product. In a domestic environment
this product may cause radio interference in which case the user
may be required to take adequate measures.
European Compliance Statement
CE Marking on this product represents that this product com-
plies with all requirements that are applicable to it.
Europe EU Declaration of Conformity
This device can be used in the European Community. A copy of the EU Decla-
ration of Conformity is available at: www.mimosa.co/compliance.
Български (Bulgarian) - Airspan Networks Inc. декларира, че това Airspan
Networks Inc. приспособление е в съответствие със съществените
изисквания и другите приложими правила на Директива 2014/53/EU.
Česky (Czech) - Společnost Airspan Networks Inc. tímto prohlašuje, že tento
Airspan Networks Inc. zařízení je ve shodě se základními požadavky a dalšími
příslušnými ustanoveními směrnice 2014/53/EU.
Dansk (Danish) - Undertegnede Airspan Networks Inc. erklærer herved, at
følgende udstyr Airspan Networks Inc. enhed overholder de væsentlige krav
og øvrige relevante krav i direktiv 2014/53/EU.
Deutsch (German) - Hiermit erklärt Airspan Networks Inc., dass sich das
Airspan Networks Inc. Gerät in Übereinstimmung mit den grundlegenden
Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie
2014/53/EU benden.
Eesti (Estonian) - Käesolevaga kinnitab Airspan Networks Inc., et see Airspan
Networks Inc. seade vastab direktiivi 2014/53/EU põhinõuetele ja nimetatud
direktiivist tulenevatele teistele asjakohastele sätetele.
English - Hereby, Airspan Networks Inc. declares that this Airspan Networks
Inc. device is in compliance with the essential requirements and other relevant
provisions of Directive 2014/53/EU.
Español (Spanish) - Por medio de la presente Airspan Networks Inc. declara
que este Airspan Networks Inc. dispositivo cumple con los requisitos esen-
ciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva
2014/53/EU.
Ελληνικά (Greek) - Mε την παρούσα, η Airspan Networks Inc. δηλώνει ότι αυτή
η συσκευή Airspan Networks Inc. συσκευή συμμορφώνεται προς τις βασικές
απαιτήσεις και τις λοιπές σχετικές διατάξεις της Οδηγίας 2014/53/EU.
Français (French) - Par la présente Airspan Networks Inc. déclare que ce
Airspan Networks Inc. appareil est conforme aux exigences essentielles et aux
autres dispositions pertinentes de la directive 2014/53/EU.
Islenska (Icelandic) - Airspan Networks Inc. lýsir því hér með yr að þetta
Airspan Networks Inc. tæki fullnægir lágmarkskröfum og öðrum viðeigandi
ákvæðum Evróputilskipunar 2014/53/EU.
Italiano (Italian) - Con la presente Airspan Networks Inc. dichiara che questo
Airspan Networks Inc. dispositivo è conforme ai requisiti essenziali ed alle altre
disposizioni pertinenti stabilite dalla direttiva 2014/53/EU.
Latviski (Latvian) - Ar šo Airspan Networks Inc. deklarē, ka šī Airspan Networks
Inc. ierīce atbilst Direktīvas 2014/53/EU būtiskajām prasībām un citiem ar to
saistītajiem noteikumiem.
Lietuvių (Lithuanian) - Šiuo „Airspan Networks Inc.“ deklaruoja, kad šis Airspan
Networks Inc. atitinka esminius reikalavimus ir kitas 2014/53/EUB Direktyvos
nuostatas.
Magyar (Hungarian) - Alulírott, Airspan Networks Inc. nyilatkozom, hogy a Air-
span Networks Inc. eszköz megfelel a vonatkozó alapvetõ követelményeknek
és az 2014/53/EU irányelv egyéb elõírásainak.
Malti (Maltese) - Hawnhekk, Airspan Networks Inc., jiddikjara li dan Airspan
Networks Inc. tagħmir jikkonforma mal-ħtiġijiet essenzjali u ma provvedimenti
oħrajn relevanti li hemm d-Dirrettiva 2014/53/EU. 705-00034 REV A
Nederlands (Dutch) - Hierbij verklaart Airspan Networks Inc. dat dit Airspan
Networks Inc. toestel in overeenstemming is met de essentiële eisen en de
andere bepalingen van richtlijn 2014/53/EU.
Norsk (Norwegian) - Airspan Networks Inc. erklærer herved at dette Airspan
Networks Inc. apparatet er i samsvar med de grunnleggende kravene og
øvrige relevante krav i EU-direktivet 2014/53/EU.
Polski (Polish)- Niniejszym Airspan Networks Inc. oświadcza, że ten Airspan
Networks Inc. urządzenie są zgodne z zasadniczymi wymogami oraz pozos-
tałymi stosownymi postanowieniami Dyrektywy 2014/53/EU.
Português (Portugese) - Airspan Networks Inc. declara que este Airspan
Networks Inc. dispositivo está em conformidade com os requisitos essenciais
e outras disposições da Directiva 2014/53/EU.
Română (Romanian) - Prin prezenta, Airspan Networks Inc. declară că acest
Airspan Networks Inc. aparat este în conformitate cu cerinţele esenţiale şi cu
celelalte prevederi relevante ale Directivei 2014/53/EU.
Slovensky (Slovak) - Airspan Networks Inc. týmto vyhlasuje, že toto Airspan
Networks Inc. zariadenie spĺňa základné požiadavky a všetky príslušné ustano-
venia Smernice 2014/53/EU.
Slovensko (Slovene) - Airspan Networks Inc. izjavlja, da je ta Airspan Networks
Inc. naprava skladne z bistvenimi zahtevami in ostalimi ustreznimi določili
direktive 2014/53/EU.
Suomi (Finnish) - Airspan Networks Inc. vakuuttaa täten, että tämä Airspan
Networks Inc. tyyppinen laite on direktiivin 2014/53/EU oleellisten vaatimusten
ja sitä koskevien direktiivin muiden ehtojen mukainen.
Svenska (Swedish) - Härmed intygar Airspan Networks Inc. att denna Airspan
Networks Inc. apparat står i överensstämmelse med de väsentliga egenskapsk-
rav och övriga relevanta bestämmelser som framgår av direktiv 2014/53/EU.
RoHS & WEEE Compliance
User Information for Consumer Products Covered by EU Directive 2002/96/EC
on Waste Electric and Electronic Equipment (WEEE).
This document contains important information for users with re-
gards to the proper disposal and recycling of Airspan Networks Inc.
products. Consumers are required to comply with this notice for all
electronic products bearing this symbol.
English - Environmental Information for Customers in the European Union
European Directive 2002/96/EC requires that the equipment bearing this
symbol on the product and/or its packaging must not be disposed of with
unsorted municipal waste. The symbol indicates that this product should
be disposed of separately from regular household waste streams. It is your
responsibility to dispose of this and other electric and electronic equipment
via designated collection facilities appointed by the government or local
authorities. Correct disposal and recycling will help prevent potential negative
consequences to the environment and human health. For more detailed
information about the disposal of your old equipment, please contact your
local authorities, waste disposal service, or the shop where you purchased the
product.
Български (Bulgarian) - Информация относноопазването на околната
среда за потребители вЕвропейския съюз -Европейска директива
2002/96/EC изисква уредите, носещи този символ върху изделието и/
или опаковката му, да не се изхвърля т с несортирани битови отпадъци.
Символът обозначава, че изделието трябва да се изхвърля отделно
от сметосъбирането на обикновените битови отпадъци. Ваша е
отговорността този и другите електрически и електронни уреди да се
изхвърлят в предварително определени от държавните или общински
органи специализирани пунктове за събиране. Правилното изхвърляне
и рециклиране ще спомогнат да се предотвратят евентуални вредни за
околната среда и здравето на населението последствия. За по-подробна
информация относно изхвърлянето на вашите стари уреди се обърнете
към местните власти, службите за сметосъбиране или магазина, от който
сте закупили уреда.
Čeština (Czech) - Informace o ochraně životníhoprostředí pro zákazníky v
zemích Evropské unie - Evropská směrnice 2002/96/ES zakazuje, aby zařízení
označené tímto symbolem na produktu anebo na obalu bylo likvidováno s
netříděným komunálním odpadem. Tento symbol udává, že daný produkt musí
být likvidován odděleně od běžného komunálního odpadu. Odpovídáte za
likvidaci tohoto produktu a dalších elektrických a elektronických zařízení pros-
třednictvím určených sběrných míst stanovených vládou nebo místními úřady.
Správná likvidace a recyklace pomáhá předcházet potenciálním negativním
dopadům na životní prostředí a lidské zdraví. Podrobnější informace o likvidaci
starého vybavení si laskavě vyžádejte od místních úřadů, podniku zabývajícího
se likvidací komunálních odpadů nebo obchodu, kde jste produkt zakoupili.
Dansk (Danish) - Miljøinformation for kunder i EU - EU-direktiv 2002/96/EF
kræver, at udstyr der bærer dette symbol på produktet og/eller emballagen
ikke må bortskaffes som usorteret kommunalt affald. Symbolet betyder, at
dette produkt skal bortskaffes adskilt fra det almindelige husholdningsaffald.
Det er dit ansvar at bortskaffe dette og andet elektrisk og elektronisk udstyr
via bestemte indsamlingssteder udpeget af staten eller de lokale myndighed-
er. Korrekt bortskaffelse og genvinding vil hjælpe med til at undgå mulige
skader for miljøet og menneskers sundhed. Kontakt venligst de lokale myn-
digheder, renovationstjenesten eller den butik, hvor du har købt produktet,
angående mere detaljeret information om bortskaffelse af dit gamle udstyr.
Deutsch (German) - Umweltinformation für Kunden innerhalb der Eu-
ropäischen Union - Die Europäische Richtlinie 2002/96/EC verlangt, dass
technische Ausrüstung, die direkt am Gerät und/oder an der Verpackung mit
diesem Symbol versehen ist, nicht zusammen mit unsortiertem Gemeinde-
abfall entsorgt werden darf. Das Symbol weist darauf hin, dass das Produkt
von regulärem Haushaltmüll getrennt entsorgt werden sollte. Es liegt in Ihrer
Verantwortung, dieses Gerät und andere elektrische und elektronische Geräte
über die dafür zuständigen und von der Regierung oder örtlichen Behörden
dazu bestimmten Sammelstellen zu entsorgen. Ordnungsgemäßes Entsorgen
und Recyceln trägt dazu bei, potentielle negative Folgen für Umwelt und die
menschliche Gesundheit zu vermeiden. Wenn Sie weitere Informationen zur
Entsorgung Ihrer Altgeräte benötigen, wenden Sie sich bitte an die örtlichen
Behörden oder städtischen Entsorgungsdienste oder an den Händler, bei dem
Sie das Produkt erworben haben.
Eesti (Estonian) - Keskkonnaalane informatsioon Euroopa Liidus asuvatele kli-
entidele - Euroopa Liidu direktiivi 2002/96/EÜ nõuete kohaselt on seadmeid,
millel on tootel või pakendil käesolev sümbol keelatud kõrvaldada koos sort-
eerimata olmejäätmetega. See sümbol näitab, et toode tuleks kõrvaldada eral-
di tavalistest olmejäätmevoogudest. Olete kohustatud kõrvaldama käesoleva
ja ka muud elektri- ja elektroonikaseadmed riigi või kohalike ametiasutuste
poolt ette nähtud kogumispunktide kaudu. Seadmete korrektne kõrvaldamine
ja ringlussevõtt aitab vältida võimalikke negatiivseid tagajärgi keskkonnale
ning inimeste tervisele. Vanade seadmete kõrvaldamise kohta täpsema
informatsiooni saamiseks võtke palun ühendust kohalike ametiasutustega,
jäätmekäitlusrmaga või kauplusega, kust te toote ostsite.
Español (Spanish) - Información medioambiental paraclientes de la Unión
Europea - La Directiva 2002/96/CE de la UE exige que los equipos quel leven
este símbolo en el propio aparato y/o en su embalaje no deben eliminarse
junto con otros residuos urbanos no seleccionados. El símbolo indica que el
producto en cuestión debe separarse de los residuos domésticos conven-
cionales con vistas a su eliminación. Es responsabilidad suya desechar este y
cualesquiera otros aparatos eléctricos y electrónicos a través de los puntos de
recogida que ponen a su disposición el gobierno y las autoridades locales.
Al desechar y reciclar correctamente estos aparatos estará contribuyendo a
evitar posibles consecuencias negativas para el medio ambiente y la salud de
las personas. Si desea obtener información más detallada sobre la eliminación
segura de su aparato usado, consulte a las autoridades locales, al servicio de
recogida y eliminación de residuos de su zona o pregunte en la tienda donde
adquirió el producto.
Ελληνικά (Greek) - Στοιχεία περιβαλλοντικής προστασίας για πελάτες εντός
της ΕυρωπαϊκήςΈνωσης - Σύμφωνα με την Κοινοτική Οδηγία 2002/96/
EC, ο εξοπλισμός που φέρει αυτό το σύμβολο στο προϊόν ή/και τη
συσκευασία του δεν πρέπει να απορρίπτεται μαζί με τα μη διαχωρισμένα
αστικά απορρίμματα. Το σύμβολο υποδεικνύει ότι αυτό το προϊόν θα
πρέπει να απορρίπτεται ξεχωριστά από τα συνήθη οικιακά απορρίμματα.
Είστε υπεύθυνος για την απόρριψη του παρόντος και άλλου ηλεκτρικού
και ηλεκτρονικού εξοπλισμού μέσω των καθορισμένων εγκαταστάσεων
συγκέντρωσης απορριμμάτων, οι οποίες ορίζονται από το κράτος ή τις
αρμόδιες τοπικές αρχές. Η σωστή απόρριψη και ανακύκλωση συμβάλλει στην
πρόληψη ενδεχόμενων αρνητικών επιπτώσεων στο περιβάλλον και την υγεία.
Για περισσότερες πληροφορίες σχετικά με την απόρριψη του παλαιού σας
εξοπλισμού, επικοινωνήστε με τις τοπικές αρχές, τις υπηρεσίες αποκομιδής
απορριμμάτων ή το κατάστημα από το οποίο αγοράσατε το προϊόν.
Français (French) - Informations environnementales pour les clients de l’Union
européenne - La directive européenne 2002/96/CE exige que l’équipement
, sur lequel est apposé ce symbole sur le produit et/ou son emballage ne
soit pas jeté avec les autres ordures ménagères. Ce symbole indique que
le produit doit être éliminé dans un circuit distinct de celui pour les déchets
des ménages. Il est de votre responsabilité de jeter ce matériel ainsi que tout
autre matériel électrique ou électronique par les moyens de collecte indiqués
par le gouvernement et les pouvoirs publics des collectivités territoriales.
L’élimination et le recyclage en bonne et due forme ont pour but de lutter
contre l’impact néfaste potentiel de ce type de produits sur l’environnement
et la santé publique. Pour plus d’informations sur le mode d’élimination de
votre ancien équipement, veuillez prendre contact avec les pouvoirs publics
locaux, le service de traitement des déchets, ou l’endroit où vous avez acheté
le produit.
Italiano (Italian) - Informazioni relative all’ambiente per i clienti residenti
nell’Unione Europea - La direttiva europea 2002/96/EC richiede che le appare-
cchiature contrassegnate con questo simbolo sul prodotto e/o sull’imballaggio
non siano smaltite insieme ai riuti urbani non differenziati. Il simbolo indica
che questo prodotto non deve essere smaltito insieme ai normali riuti do-
mestici. È responsabilità del proprietario smaltire sia questi prodotti sia le altre
apparecchiature elettriche ed elettroniche mediante le speciche strutture di
raccolta indicate dal governo o dagli enti pubblici locali. Il corretto smaltimen-
to ed il riciclaggio aiuteranno a prevenire conseguenze potenzialmente nega-
tive per l’ambiente e per la salute dell’essere umano. Per ricevere informazioni
più dettagliate circa lo smaltimento delle vecchie apparecchiature in Vostro
possesso, Vi invitiamo a contattare gli enti pubblici di competenza, il servizio
di smaltimento riuti o il negozio nel quale avete acquistato il prodotto.
Latviešu valoda (Latvian) - Ekoloģiska informācija klientiem Eiropas Savienības
jurisdikcijā - Direktīvā 2002/96/EK ir prasība, ka aprīkojumu, kam pievienota
zīme uz paša izstrādājuma vai uz tā iesaiņojuma, nedrīkst izmest nešķirotā
veidā kopā ar komunālajiem atkritumiem (tiem, ko rada vietēji iedzīvotāji un
uzņēmumi). Šī zīme nozīmē to, ka šī ierīce ir jāizmet atkritumos tā, lai tā neno-
nāktu kopā ar parastiem mājsaimniecības atkritumiem. Jūsu pienākums ir šo un
citas elektriskas un elektroniskas ierīces izmest atkritumos, izmantojot īpašus
atkritumu savākšanas veidus un līdzekļus, ko nodrošina valsts un pašvaldību
iestādes. Ja izmešana atkritumos un pārstrāde tiek veikta pareizi, tad mazinās
iespējamais kaitējums dabai un cilvēku veselībai. Sīkākas ziņas par novecojuša
aprīkojuma izmešanu atkritumos jūs varat saņemt vietējā pašvaldībā, atkritumu
savākšanas dienestā, kā arī veikalā, kur iegādājāties šo izstrādājumu.
Lietuvškai (Lithuanian) - Aplinkosaugos informacija,skirta Europos Sąjungos
vartotojams - Europos direktyva 2002/96/EC numato, kad įrangos, kuri ir kurios
pakuotė yra pažymėta šiuo simboliu, negalima šalinti kartu su nerūšiuotomis
komunalinėmis atliekomis. Šis simbolis rodo, kad gaminį reikia šalinti atskirai
nuo bendro buitinių atliekų srauto. Jūs privalote užtikrinti, kad ši ir kita elektros
ar elektroninė įranga būtų šalinama per tam tikras nacionalinės ar vietinės
valdžios nustatytas atliekų rinkimo sistemas. Tinkamai šalinant ir perdirbant
atliekas, bus išvengta galimos žalos aplinkai ir žmonių sveikatai. Daugiau infor-
macijos apie jūsų senos įrangos šalinimą gali pateikti vietinės valdžios instituci-
jos, atliekų šalinimo tarnybos arba parduotuvės, kuriose įsigijote tą gaminį.
Malti (Maltese) - Informazzjoni Ambjentali għal Klijenti-Unjoni Ewropea
Id-Direttiva Ewropea 2002/96/KE titlob li t-tagħmir li jkun h is-simbolu fuq
il-prodott u/jew fuq l-ippakkjar ma jistax jintrema ma’ skart muniċipali li ma
ġiex isseparat. Is-simbolu jindika li dan il-prodott għandu jintrema separat-
ament minn ma’ l-iskart domestiku regolari. Hija responsabbiltà tiegħek li
tarmi dan it-tagħmir u kull tagħmir ieħor ta’ l-elettriku u elettroniku permezz
ta’ faċilitajiet ta’ ġbir appuntati apposta mill-gvern jew mill-awtoritajiet lokali.
Ir-rimi b’mod korrett u r-riċiklaġġ jgħin jipprevjeni konsegwenzi negattivi
potenzjali għall-ambjent u għas-saħħa tal-bniedem. Għal aktar informazzjoni
dettaljata dwar ir-rimi tat-tagħmir antik tiegħek, jekk jogħġbok ikkuntattja
lill-awtoritajiet lokali tiegħek, is-servizzi għar-rimi ta’ l-iskart, jew il-ħanut minn
fejn xtrajt il-prodott.
Magyar (Hungarian) - Környezetvédelmi információ azeurópai uniós vásárlók
számára - A 2002/96/EC számú európai uniós irányelv megkívánja, hogy
azokat a termékeket, amelyeken, és/vagy amelyek csomagolásán az alábbi
címke megjelenik, tilos a többi szelektálatlan lakossági hulladékkal együtt
kidobni. A címke azt jelöli, hogy az adott termék kidobásakor a szokványos
háztartási hulladékelszállítási rendszerektõl elkülönített eljárást kell alkalmazni.
Az Ön felelõssége, hogy ezt, és más elektromos és elektronikus berendezéseit
a kormányzati vagy a helyi hatóságok által kijelölt gyűjtõredszereken keresztül
számolja fel. A megfelelõ hulladékfeldolgozás segít a környezetre és az emberi
egészségre potenciálisan ártalmas negatív hatások megelõzésében. Ha
elavult berendezéseinek felszámolásához további részletes információra van
szüksége, kérjük, lépjen kapcsolatba a helyi hatóságokkal, a hulladékfeldolgo-
zási szolgálattal, vagy azzal üzlettel, ahol a terméket vásárolta.
Nederlands (Dutch) - Milieu-informatie voor klantenin de Europese Unie - De
Europese Richtlijn 2002/96/EC schrijft voor dat apparatuur die is voorzien van
dit symbool op het product of de verpakking, niet mag worden ingezameld
met niet-gescheiden huishoudelijk afval. Dit symbool geeft aan dat het
product apart moet worden ingezameld. U bent zelf verantwoordelijk voor de
vernietiging van deze en andere elektrische en elektronische apparatuur via
de daarvoor door de landelijke of plaatselijke overheid aangewezen inzamel-
ingskanalen. De juiste vernietiging en recycling van deze apparatuur voorkomt
mogelijke negatieve gevolgen voor het milieu en de gezondheid. Voor meer
informatie over het vernietigen van uw oude apparatuur neemt u contact op
met de plaatselijke autoriteiten of afvalverwerkingsdienst, of met de winkel
waar u het product hebt aangeschaft.
Norsk (Norwegian) - Miljøinformasjon for kunder i EU - EU-direktiv 2002/96/EF
krever at utstyr med følgende symbol avbildet på produktet og/eller paknin-
gen, ikke må kastes sammen med usortert avfall. Symbolet indikerer at dette
produktet skal håndteres atskilt fra ordinær avfallsinnsamling for husholdning-
savfall. Det er ditt ansvar å kvitte deg med dette produktet og annet elektrisk
og elektronisk avfall via egne innsamlingsordninger slik myndighetene eller
kommunene bestemmer. Korrekt avfallshåndtering og gjenvinning vil være
med på å forhindre mulige negative konsekvenser for miljø og helse. For
nærmere informasjon om håndtering av det kasserte utstyret ditt, kan du ta
kontakt med kommunen, en innsamlingsstasjon for avfall eller butikken der du
kjøpte produktet.
Polski (Polish) - Informacja dla klientów w Unii Europejskiej o przepisach
dotyczących ochrony środowiska - Dyrektywa Europejska 2002/96/EC
wymaga, aby sprzęt oznaczony symbolem znajdującym się na produkcie i/
lub jego opakowaniu nie był wyrzucany razem z innymi niesortowanymi
odpadami komunalnymi. Symbol ten wskazuje, że produkt nie powinien być
usuwany razem ze zwykłymi odpadami z gospodarstw domowych. Na Państwu
spoczywa obowiązek wyrzucania tego i innych urządzeń elektrycznych oraz
elektronicznych w punktach odbioru wyznaczonych przez władze krajowe lub
lokalne. Pozbywanie się sprzętu we właściwy sposób i jego recykling pomogą
zapobiec potencjalnie negatywnym konsekwencjom dla środowiska i zdrowia
ludzkiego. W celu uzyskania szczegółowych informacji o usuwaniu starego
sprzętu, prosimy zwrócić się do lokalnych władz, służb oczyszczania miasta lub
sklepu, w którym produkt został nabyty.
Português (Portuguese) - Informação ambiental paraclientes da União Euro-
peia - A Directiva Europeia 2002/96/CE exige que o equipamento que exibe
este símbolo no produto e/ou na sua embalagem não seja eliminado junto
com os resíduos municipais vnão separados. O símbolo indica que este pro-
duto deve ser eliminado separadamente dos resíduos domésticos regulares. É
da sua responsabilidade eliminar este e qualquer outro equipamento eléctrico
e electrónico através das instalações de recolha designadas pelas autoridades
governamentais ou locais. A eliminação e reciclagem correctas ajudarão a
prevenir as consequências negativas para o ambiente e para a saúde humana.
Para obter informações mais detalhadas sobre a forma de eliminar o seu
equipamento antigo, contacte as autoridades locais, os serviços de eliminação
de resíduos ou o estabelecimento comercial onde adquiriu o produto.
Română (Romanian) - Informaţii de mediu pentruclienţii din Uniunea Europe-
ană - Directiva europeană 2002/96/CE impune ca echipamentele care prezintă
acest simbol pe produs şi/sau pe ambalajul acestuia să nu e casate împreună
cu gunoiul menajer municipal. Simbolul indică faptul că acest produs trebuie
să e casat separat de gunoiul menajer obişnuit. Este responsabilitatea dvs. să
casaţi acest produs şi alte echipamente electrice şi electronice prin intermediul
unităţilor de colectare special desemnate de guvern sau de autorităţile locale.
Casarea şi reciclarea corecte vor ajuta la prevenirea potenţialelor consecinţe
negative asupra sănătăţii mediului şi a oamenilor. Pentru mai multe informaţii
detaliate cu privire la casarea acestui echipament vechi, contactaţi autorităţile
locale, serviciul de salubrizare sau magazinul de la care aţi achiziţionat
produsul.
Slovenčina (Slovak) - Informácie o ochrane životnéhoprostredia pre zákazníkov
v Európskej únii - Podľa európskej smernice 2002/96/ES zariadenie s týmto
symbolomna produkte a/alebo jeho balení nesmie byť likvidované spolu s
netriedeným komunálnym odpadom. Symbol znamená, že produkt by sa mal
likvidovať oddelene od bežného odpadu z domácností. Je vašou povinnosťou
likvidovať toto i ostatné elektrické a elektronické zariadenia prostredníctvom
špecializovaných zberných zariadení určených vládou alebo miestnymi orgán-
mi. Správna likvidácia a recyklácia pomôže zabrániť prípadným negatívnym
dopadom na životné prostredie a zdravie ľudí. Ak máte záujem o podrobnejšie
informácie o likvidácii starého zariadenia, obráťte sa, prosím, na miestne
orgány, organizácie zaoberajúce sa likvidáciou odpadov alebo obchod, v
ktorom ste si produkt zakúpili.
Slovenščina (Slovene) - Okoljske informacije za stranke v Evropski uniji - Ev-
ropska direktiva 2002/96/ES prepoveduje odlaganje opreme s tem simbolom
na izdelku in/ali na embalaži z nesortiranimi komunalnimi odpadki. Ta simbol
opozarja, da je treba izdelek zavreči ločeno od preostalih gospodinjskih
odpadkov. Vaša odgovornost je, da to in preostalo električno in elektronsko
opremo oddate na posebna zbirališča, ki jih določijo državne ustanove ali loka-
lne oblasti. S pravilnim odlaganjem in recikliranjem boste preprečili morebitne
škodljive vplive na okolje in zdravje ljudi. Če želite izvedeti več o odlaganju
stare opreme, se obrnite na lokalne oblasti, odlagališče odpadkov ali trgovino,
kjer ste izdelek kupili.
Suomi (Finnish) - Ympäristöä koskevia tietoja EU- alueen asiakkaille
EU-direktiivi 2002/96/EY edellyttää, että jos laitteistossa on tämä symboli itse
tuotteessa ja/tai sen pakkauksessa, laitteistoa ei saa hävittää lajittelematto-
man yhdyskuntajätteen mukana. Symboli merkitsee sitä, että tämä tuote on
hävitettävä erillään tavallisesta kotitalousjätteestä. Sinun vastuullasi on hävittää
tämä elektroniikkatuote ja muut vastaavat elektroniikkatuotteet viemällä
tuote tai tuotteet viranomaisten määräämään keräyspisteeseen. Laitteiston
mahdolliset kielteiset vaikutukset ympäristöön ja ihmisten terveyteen. Lisäti-
etoja vanhan laitteiston oikeasta hävitystavasta saa paikallisilta viranomaisilta,
jätteenhävityspalvelusta tai siitä myymälästä, josta ostit tuotteen
Svenska (Swedish) - Miljöinformation för kunder i Europeiska unionen - Det
europeiska direktivet 2002/96/EC kräver att utrustning med denna symbol på
produkten och/eller förpackningen inte får kastas med osorterat kommunalt
avfall. Symbolen visar att denna produkt bör kastas efter att den avskiljts
från vanligt hushållsavfall. Det faller på ditt ansvar att kasta denna och annan
elektrisk och elektronisk utrustning på fastställda insamlingsplatser utsedda av
regeringen eller lokala myndigheter. Korrekt kassering och återvinning skyddar
mot eventuella negativa konsekvenser för miljön och personhälsa. För mer
detaljerad information om kassering av din gamla utrustning kontaktar du dina
lokala myndigheter, avfallshanteringen eller butiken där du köpte produkten.
Table of contents
Other Mimosa Wireless Access Point manuals
Popular Wireless Access Point manuals by other brands
EnGenius
EnGenius Neutron EWS210AP user manual
RouterBOARD
RouterBOARD MikroTik mAP 2nD Quick setup guide and warranty information
BinTec
BinTec XAir Getting started
Kaba
Kaba Simplex Installation insrtuctions
Proxim
Proxim ORiNOCO AP-700 user guide
Cisco
Cisco WAP4410N - Small Business Wireless-N Access... user guide
