miniClima EBC User manual

miniClima Schönbauer GmbH
Brunner Str. 21b, 2700 WIENER NEUSTADT, AUSTRIA, EU
Tel. | Phone: + 3 2622 2 96 , + 3 6991 2 96 01, Voicemail: + 3 6993 2 96 01, Fax: + 3 2622 2 96 15, E-Mail: [e-mail]
www.miniclima.com, twitter.com/miniClima, www.linkedin.com/company/miniclima-schönbauer-gmbh, www.google.com/+Miniclima, www.facebook.com/miniclima
UID | VAT-ID: ATU6199 35, EORI: ATEOS1000001229, DVR: 008782
Firmenbuchnummer | Trade Register Number: 267137z (Landesgericht | Regional Court of Wiener Neustadt)
miniClima Manual EBC
Topic: Complete instructions for the application, installation, usage, maintenance & care, deinstallation,
storage and packing-up of the respective devices.
Valid for: miniClima Constant Humidity Devices, Series EBC10/11/12 (Rev.3), Types EBC10, EBC11,
EBC12. The series is indicated on the back of the device, the type on the front behind the handle. Optional
accessories or extras are described in their respective supplement manuals.
THIS MANUAL CONTAINS IM ORTANT INFORMATION - LEASE READ IT CAREFULLY BEFORE
USING OR INSTALLING YOUR DEVICE!
The devices covered by this manual are not destined for being used by persons (including children) with
limited physical, sensory or intellectual abilities and/or by persons lacking the required experiences/skills,
except such persons are going to be supervised by a person that is responsible for their safety or such
persons have been thoroughly briefed beforehand about the usage of the device and it can be expected that
the persons will have comprehended the explanations and that they will also follow them. Children have to
be kept well away from the devices, ensuring that they will not play with them.
Applies analogously to the individual products of series EBC10/11/12 (Rev.3). As of 2 .11.201 . Subject
to modification.
miniClima - Manual_EBC10-11-12(Rev.3)_en
1 / 5

miniClima Schönbauer GmbH
Brunner Str. 21b, 2700 WIENER NEUSTADT, AUSTRIA, EU
Tel. | Phone: + 3 2622 2 96 , + 3 6991 2 96 01, Voicemail: + 3 6993 2 96 01, Fax: + 3 2622 2 96 15, E-Mail: [e-mail]
www.miniclima.com, twitter.com/miniClima, www.linkedin.com/company/miniclima-schönbauer-gmbh, www.google.com/+Miniclima, www.facebook.com/miniclima
UID | VAT-ID: ATU6199 35, EORI: ATEOS1000001229, DVR: 008782
Firmenbuchnummer | Trade Register Number: 267137z (Landesgericht | Regional Court of Wiener Neustadt)
TABLE OF CONTENTS
1 GENERAL INFORMATION........................................................................................................................... 4
1.1 What can be expected from the work of an EBC, what can't........................................................... 4
1.1.1 Primary purpose............................................................................................................................
1.1.2 Characteristic features...................................................................................................................
1.2 Risk of use, recommendations........................................................................................................... 5
1.3 ermissible ambient conditions......................................................................................................... 6
1.4 Further requirements for using EBCs................................................................................................ 6
1.5 Available types..................................................................................................................................... 6
2 IDENTIFYING YOUR UNIT AND ITS ACCESSORIES/O TIONS................................................................ 7
2.1 Delivered items (per EBC)................................................................................................................... 7
2.2 ossibly delivered other (optional) accessories (excerpt)...............................................................8
2.3 Verifying the series.............................................................................................................................. 8
2.4 Identifying the type (EBC10, EBC11, EBC12).................................................................................... 9
2.5 Identifying the serial number (S/N).................................................................................................... 9
2.6 Verifying the strength of the circulation fan...................................................................................... 9
2.7 Identifying the kind and number of the water level sensors for the bottle..................................... 9
3 INSTALLATION........................................................................................................................................... 10
3.1 ositioning the bottle........................................................................................................................ 10
3.2 Setting up the EBC, establishing the hosepipe connections........................................................ 12
3.2.1 Handling the hosepipe fittings...................................................................................................... 15
3.2.2 Connecting the hosepipes to the EBC......................................................................................... 18
3.3 Electrical connections....................................................................................................................... 18
3.3.1 Handling the ferrite core.............................................................................................................. 18
3.3.2 RH/T sensor................................................................................................................................. 19
3.3.3 Control lines................................................................................................................................. 20
3.3. Wirings for the external signals (Composite error alarm and on-off status).................................20
4 INITIAL AND CONTINUED O ERATION................................................................................................... 22
4.1 Initial step 1 - bottle........................................................................................................................... 22
4.2 Initial step 2 - mains connection...................................................................................................... 23
4.3 Stand-by mode................................................................................................................................... 23
4.4 Switching on and off......................................................................................................................... 24
4.5 Settings and read-outs - working with the menu............................................................................ 25
.5.1 Menu entry Setpoint..................................................................................................................... 26
.5.2 Menu entry AlarmMax.................................................................................................................. 27
.5.3 Menu entry AlarmMin................................................................................................................... 28
.5. Menu entry AlarmBeep................................................................................................................ 29
.5.5 Menu entry 1. Alarm..................................................................................................................... 30
.5.6 Menu entry for the display and menu language........................................................................... 31
.5.7 Menu entry t@Sensor.................................................................................................................. 32
.5.8 Menu entry t@Cond..................................................................................................................... 32
.5.9 Menu entry t@H-Sink.................................................................................................................. 33
.5.10 Menu entry OpHours................................................................................................................. 33
.5.11 Menu entry rH Corr.................................................................................................................... 3
.5.12 Menu entry Hyst......................................................................................................................... 35
4.6 rocedures during operation............................................................................................................ 36
4.7 Controlling, feeding, emptying and cleaning the bottle................................................................. 37
5 ALARMS - WHAT THEY MEAN AND HOW TO REACT............................................................................ 38
5.1 Humidity alarm................................................................................................................................... 38
5.1.1 Description of the alarm............................................................................................................... 38
5.1.2 Remaining EBC functions during this alarm................................................................................ 39
Applies analogously to the individual products of series EBC10/11/12 (Rev.3). As of 2 .11.201 . Subject
to modification.
miniClima - Manual_EBC10-11-12(Rev.3)_en
2 / 5

miniClima Schönbauer GmbH
Brunner Str. 21b, 2700 WIENER NEUSTADT, AUSTRIA, EU
Tel. | Phone: + 3 2622 2 96 , + 3 6991 2 96 01, Voicemail: + 3 6993 2 96 01, Fax: + 3 2622 2 96 15, E-Mail: [e-mail]
www.miniclima.com, twitter.com/miniClima, www.linkedin.com/company/miniclima-schönbauer-gmbh, www.google.com/+Miniclima, www.facebook.com/miniclima
UID | VAT-ID: ATU6199 35, EORI: ATEOS1000001229, DVR: 008782
Firmenbuchnummer | Trade Register Number: 267137z (Landesgericht | Regional Court of Wiener Neustadt)
5.1.3 Possible reasons and solutions................................................................................................... 39
5.2 ump alarm........................................................................................................................................ 40
5.2.1 Description of the alarm............................................................................................................... 0
5.2.2 Remaining EBC functions during this alarm................................................................................ 0
5.2.3 Possible reasons and solutions................................................................................................... 0
5.3 Bottle alarm........................................................................................................................................ 42
5.3.1 Description of the alarm............................................................................................................... 2
5.3.2 Remaining EBC functions during this alarm................................................................................ 3
5.3.3 Possible reasons and solutions................................................................................................... 3
5.4 Signal error alarm.............................................................................................................................. 43
5. .1 Description of the alarm...............................................................................................................
5. .2 Remaining EBC functions during this alarm................................................................................
5. .3 Possible reasons and solutions...................................................................................................
6 TROUBLESHOOTING................................................................................................................................ 45
6.1 The unit stops dehumidifying before it reaches the setpoint........................................................ 45
6.2 The desired humidity level is not reached at all............................................................................. 46
6.3 The humidity level displayed on the EBC is different to the one of a third party instrument that
has been put inside the case.................................................................................................................. 46
6.4 A red LED lights up on the front panel.............................................................................................46
6.5 When pulling or plugging in the sensor cable or the control line the EBC reacts in an
unexpected way....................................................................................................................................... 46
6.6 The bottle sensor for the high mark issues its alarm, despite the water level being far below
the sensor................................................................................................................................................ 46
6.7 The bottle sensor for the low mark won't issue its alarm, despite the water level being far
below the sensor..................................................................................................................................... 47
6.8 The device won't react in any sort of way anymore, neither the LED nor the display are on,
despite of the device being plugged on correctly................................................................................ 47
7 MAINTENANCE AND CARE....................................................................................................................... 47
7.1 Replacing the chip of the RH/T sensor............................................................................................ 47
7.2 Replacing the miniature fuses.......................................................................................................... 49
7.3 Cooling air in-/outlets........................................................................................................................ 50
7.4 Bottle.................................................................................................................................................. 51
7.5 General service.................................................................................................................................. 51
8 DEINSTALLING / ACKING U / STORING / SHI ING.......................................................................... 51
9 TECHNICAL DATA...................................................................................................................................... 53
9.1 Figures................................................................................................................................................ 53
9.2 Dimensions........................................................................................................................................ 53
Applies analogously to the individual products of series EBC10/11/12 (Rev.3). As of 2 .11.201 . Subject
to modification.
miniClima - Manual_EBC10-11-12(Rev.3)_en
3 / 5

miniClima Schönbauer GmbH
Brunner Str. 21b, 2700 WIENER NEUSTADT, AUSTRIA, EU
Tel. | Phone: + 3 2622 2 96 , + 3 6991 2 96 01, Voicemail: + 3 6993 2 96 01, Fax: + 3 2622 2 96 15, E-Mail: [e-mail]
www.miniclima.com, twitter.com/miniClima, www.linkedin.com/company/miniclima-schönbauer-gmbh, www.google.com/+Miniclima, www.facebook.com/miniclima
UID | VAT-ID: ATU6199 35, EORI: ATEOS1000001229, DVR: 008782
Firmenbuchnummer | Trade Register Number: 267137z (Landesgericht | Regional Court of Wiener Neustadt)
1 GENERAL INFORMATION
1.1 What can be expected from the work of an EBC, what can't
1.1.1 Primary purpose
The miniClima Constant Humidity Devices EBC are built for the regulation of the relative air-humidity in both
air- and steam-tight enclosed museum showcases, switchboards, deposit cupboards, containers and similar
applications (hereinafter only referred to as "cases"). The devices help in reaching and keeping a desired
level of relative air-humidity inside the cases. They are not built for the purpose of influencing or changing
any other state or condition of the air being processed (e.g. temperature, pollution, etc.), but further
equipment1 can be added to an EBC for filtering dust and particles out of the system air.
1.1.2 Characteristic features
Once set up correctly, the EBC, the case and the interconnections between EBC and case (hosepipes)
together form a tight air circulation system. As long as the EBC is turned on, the air circles continuously
through these three parts of the system. More in detail: The air is exhausted from the case, led to the EBC,
where it is going to be either humidified, dehumidified or left unchanged - depending on the set and actual
RH values. The conditioned air is then led back into the case. During all these times a digital sensor
measures the values for relative air humidity and temperature within the case. The EBC receives these
values and compares the measured RH value with the setpoint, the hysteresis and the threshold values,
which can all be set via the menu prompts on the front panel of the EBC.
Through the work of the EBC, the desired level of the air humidity in the case is constantly approached -
duration and speed depending on the initial values, on the conditions (temperature, humidity) the case is
exposed to, and on a number of further variables (like the temperature at the EBC's place of installation, the
size and shape of the case, the air/steam tightness of the case, the kind of materials stored inside the case,
the length of the hosepipes, whether or not the hosepipes are laid in many bends and turns etc). After the
setpoint range (=setpoint +/- hysteresis) has been reached, the RH is going to be kept on a constant level. A
negligible movement around the setpoint might be observed - the higher the setpoint the more distinct. This
behaviour is technically induced and does not constitute an error.
1See www.miniclima.com for our current products and available optional accessories.
Applies analogously to the individual products of series EBC10/11/12 (Rev.3). As of 2 .11.201 . Subject
to modification.
miniClima - Manual_EBC10-11-12(Rev.3)_en
/ 5

miniClima Schönbauer GmbH
Brunner Str. 21b, 2700 WIENER NEUSTADT, AUSTRIA, EU
Tel. | Phone: + 3 2622 2 96 , + 3 6991 2 96 01, Voicemail: + 3 6993 2 96 01, Fax: + 3 2622 2 96 15, E-Mail: [e-mail]
www.miniclima.com, twitter.com/miniClima, www.linkedin.com/company/miniclima-schönbauer-gmbh, www.google.com/+Miniclima, www.facebook.com/miniclima
UID | VAT-ID: ATU6199 35, EORI: ATEOS1000001229, DVR: 008782
Firmenbuchnummer | Trade Register Number: 267137z (Landesgericht | Regional Court of Wiener Neustadt)
1.2 Risk of use, recommendations
Our devices are first and foremost used for the regulation of the relative humidity of the air surrounding
precious and/or irreplaceable works of art or artefacts. It is therefore necessary to cover all possible
imponderables, when installing and using the EBCs. For this purpose, please do bear in mind the following
recommendations and risks of use.
A clean installation, carried out according to the instructions found in this manual, is the basis for a working
system. In particular essential are:
The use of a climate-ready case (air-tight, steam-tight).
The positioning of the miniClima RH/T sensor on a spot that features the same environmental conditions
as the one where the exhibit is placed (see section 3.3.2 "RH/T sensor", p. 19).
The design and positions of the air inlets and outlets on the case (see section 3.2 "Setting up the EBC,
establishing the hosepipe connections", p. 12).
That the air resistance within the air circuit is kept low (short hosepipe connections, avoidance of too
many bends and turns when laying the hosepipes etc. - see section 3.2 "Setting up the EBC, establishing
the hosepipe connections", p. 12).
Preventing different temperatures inside the case (light installations, solar radiation,...). The miniClima
RH/T sensor and the exhibit in particular need to be exposed to the very same temperature.
The temperature surrounding the EBC and the hosepipes (see section 3.2 "Setting up the EBC,
establishing the hosepipe connections", p. 12).
Regular visual inspection of the EBCs, regular maintenance and care of the EBCs (see section 7
"Maintenance and care", p. 7).
We recommend a beforehand verification by the user/customer that our product is going to be able to fulfil
the individual expectations and needs required for the specific case. Please don't hesitate to get in touch for
any questions.
It is further recommended to test the function of a completely installed system (consisting of the case, the
interconnections and the EBC(s)) before using it to control the relative air-humidity of sensitive exhibits or
components. In doing so, possible errors (i.e. wrong installations) can be discovered early enough to have
them corrected.
Please bear in mind that every technical device can break. So, to be on the safe side with respect to the
Applies analogously to the individual products of series EBC10/11/12 (Rev.3). As of 2 .11.201 . Subject
to modification.
miniClima - Manual_EBC10-11-12(Rev.3)_en
5 / 5

miniClima Schönbauer GmbH
Brunner Str. 21b, 2700 WIENER NEUSTADT, AUSTRIA, EU
Tel. | Phone: + 3 2622 2 96 , + 3 6991 2 96 01, Voicemail: + 3 6993 2 96 01, Fax: + 3 2622 2 96 15, E-Mail: [e-mail]
www.miniclima.com, twitter.com/miniClima, www.linkedin.com/company/miniclima-schönbauer-gmbh, www.google.com/+Miniclima, www.facebook.com/miniclima
UID | VAT-ID: ATU6199 35, EORI: ATEOS1000001229, DVR: 008782
Firmenbuchnummer | Trade Register Number: 267137z (Landesgericht | Regional Court of Wiener Neustadt)
lasting integrity of your sensitive and valuable exhibits or components, further actions should be considered:
Regular inspections of the case and the EBC through skilled personnel probably provide for the highest
possible safety against technical failures or breakdowns.
Installation of external signal devices for every EBC, to be alarmed in time when one of our devices
needs attention (see section 3.3. "Wirings for the external signals (Composite error alarm and on-off
status)" on p. 20).
Having a spare unit at hand if need be or when the regular inspection at our workshop becomes due. You
can save time and avoid delays during which your case might remain without humidity control. Those who
decide for this option should actually best have their EBCs rotate in regular intervals.
Please mind to install, use, maintain, deinstall, pack up, store and ship your EBC and all accessories
correctly and in accordance to the instructions.
1.3 ermissible ambient conditions
5-35°C, 15-80%RH, non-condensing (applies to the storage of the EBC as well as to the operation of the
completely installed system as a whole).
10-50ºC, 20-60%RH, non-condensing (applies to the storage of the RH/T sensor).
NOTE: The values 5-35°C and 15-80%RH refer to the air-conditions surrounding the EBC and the case
which are generally obligatory for operation (or damage-free storage) of the EBC. They do not refer to the
surrounding air-conditions were the full capacity with respect to the achievable setpoint range (inside the
case) will be given (see also section 9 "Technical data", p. 53).
1.4 Further requirements for using EBCs
Electric supply through a fuse-protected standard socket-outlet with earthing contact. Possible range of
voltage & frequency: 100-2 0VAC, 50-60Hz.
No pipework is required for the use of an EBC (all water is taken from and stored in the unit's own bottle).
1.5 Available types
EBC10 - device for air volumes of up to approx. 3m3.
EBC11 - device for air volumes of up to approx. 5m3.
Applies analogously to the individual products of series EBC10/11/12 (Rev.3). As of 2 .11.201 . Subject
to modification.
miniClima - Manual_EBC10-11-12(Rev.3)_en
6 / 5

miniClima Schönbauer GmbH
Brunner Str. 21b, 2700 WIENER NEUSTADT, AUSTRIA, EU
Tel. | Phone: + 3 2622 2 96 , + 3 6991 2 96 01, Voicemail: + 3 6993 2 96 01, Fax: + 3 2622 2 96 15, E-Mail: [e-mail]
www.miniclima.com, twitter.com/miniClima, www.linkedin.com/company/miniclima-schönbauer-gmbh, www.google.com/+Miniclima, www.facebook.com/miniclima
UID | VAT-ID: ATU6199 35, EORI: ATEOS1000001229, DVR: 008782
Firmenbuchnummer | Trade Register Number: 267137z (Landesgericht | Regional Court of Wiener Neustadt)
EBC12 - device for air volumes of up to approx. 10m3.
NOTE: The capacity of an EBC will differ depending on the ambient conditions, the tightness and
constitution of the case, the tightness and constitution of the connections between case and device, the kind
and consistency of the materials stored/presented inside the case, and the like.
Every EBC of the current series can be used as both a master unit and a slave. The decision for one of the
two hierarchic states is selected automatically dependant upon the type of cable connected to the EBC. If it
is the cable of a miniClima RH/T sensor then the EBC becomes a master controller; if it is the control line
coming from another EBC then the unit becomes a slave and will duplicate the function of the EBC that is the
first in the line (chain of EBCs).
With this it is possible to increase the max. volume of the air that can be conditioned: Every added EBC10
increases the capacity by approx. 3m3, every added EBC11 by about 5m3 and every added EBC12 by about
10m3. Mixing different types of EBCs (EBC10, EBC11, EBC12) within one chain is permissible. Furthermore
it does not matter which of those types is going to be used as the master of the chain and which as slave(s).
2 IDENTIFYING YOUR UNIT AND ITS ACCESSORIES/O TIONS
2.1 Delivered items (per EBC)
1 EBC.. (packed extra in order to avoid transport damages: 1 6pin plug-in connector).
1 Water bottle, 0.5l (default for EBC10/11) or 2.0l (option for EBC10/11, default for EBC12).
1 Flexible hosepipe (length as ordered or by default 3m for each EBC10, 5m for each EBC11 and 6m for
each EBC12).
2 Hosepipe fittings for affixing the hosepipes to the case. Depending on the make2 each hosepipe fitting
consists of 1 connector, 1 counter nut, 1 gasket ("GD.."), 1 slotted clamping ring3, 1 union nut .
1 Mains connection cable (1.8m) with plugs on either side.
Either (for EBCs sold as master units): 1 RH/T sensor with housing, cable (2.5m resp. 5.0m), RJ 5 plug
and a ferrite core ( IM ORTANT: Please see the printed note that has been added your delivery before
handling the sensor). Usually packed with the sensor: 1 free clip and screw for mounting the sensor.
Or (for EBCs sold as slave units): 1 control line (2.0m resp. 5.0m; category-5e patch cable, twisted
pair/non-crossed, with RJ 5 plugs and ferrite cores on either end).
2Current models are shipped with fittings of type 3 ("VE.._V3"). Type 2 (and partly its predecessor type 1) is still available, though.
3Type 1 only ("VE.._V1").
Type 1 and type 2 only ("VE.._V1" and "VE.._V2").
Applies analogously to the individual products of series EBC10/11/12 (Rev.3). As of 2 .11.201 . Subject
to modification.
miniClima - Manual_EBC10-11-12(Rev.3)_en
7 / 5

miniClima Schönbauer GmbH
Brunner Str. 21b, 2700 WIENER NEUSTADT, AUSTRIA, EU
Tel. | Phone: + 3 2622 2 96 , + 3 6991 2 96 01, Voicemail: + 3 6993 2 96 01, Fax: + 3 2622 2 96 15, E-Mail: [e-mail]
www.miniclima.com, twitter.com/miniClima, www.linkedin.com/company/miniclima-schönbauer-gmbh, www.google.com/+Miniclima, www.facebook.com/miniclima
UID | VAT-ID: ATU6199 35, EORI: ATEOS1000001229, DVR: 008782
Firmenbuchnummer | Trade Register Number: 267137z (Landesgericht | Regional Court of Wiener Neustadt)
CD-ROMs (1 set per order) with the relevant user manuals, information and the miniClima software
(further copies of the CDs on request).
Tool for unlocking a type-3-fitting5 (1 per order, more on request).
2.2 ossibly delivered other (optional) accessories (excerpt)
Aluminium flanges for fixing the hosepipe fittings on a case wall of more than 6mm thickness.
Air circulation filters FLT25/-32/- 0 (require EBCs equipped with ULV+/ULV++; see the additionally
delivered manual).
Air distribution boxes LVB25/-32/- 0 (see the additionally delivered manual).
Detached operating unit (cable-bound remote control; see the additionally delivered manual).
Serial data cable RS232 for plugging the EBC to a PC.
"Serial2USB" adapter with cable and driver6 for plugging the EBC to a PC without RS232 interface.
I2C Expander for enhancing the signal of the RH/T sensor if the latter is installed more than 7.5m away
from the EBC7 (see the additionally delivered manual).
Serial2IP converter for hooking the EBC to your local LAN or WiFi (see the additionally delivered manual).
Extern LED unit for displaying the alarm/on-off status of the EBC (see the additionally delivered manual).
Add. control lines and/or RH/T sensors.
2.3 Verifying the series
The series is indicated on the rating plate on the backside of the unit (see Fig. 1). It should read
"EBC10/11/12 (Rev.3)" or "EBC10/11 (Rev.3)". If not, please note the actual series and get in touch with us,
so that we can provide you with the appropriate manual.
5Orders with accordingly equipped EBCs only.
6 CAUTION: The driver CD might have a diameter of <12 cm. Such Mini-CDs are not applicable for slot-loading disc drives. Do check with your hardware documentation if
uncertain!
7Admissible max. length of the sensor cable (as of processor version V121107.02): 5+2.5=7.5m (earlier versions: 5m). The mentioned expanders are required for greater
distances.
Applies analogously to the individual products of series EBC10/11/12 (Rev.3). As of 2 .11.201 . Subject
to modification.
miniClima - Manual_EBC10-11-12(Rev.3)_en
8 / 5
