MINN KOTA EDGE User manual

EDGE
BOW-MOUNT TROLLING MOTOR
USER MANUAL

WARRANTY ON MINN KOTA FRESHWATER TROLLING MOTORS
Johnson Outdoors Marine Electronics, Inc. (“JOME”) extends the following limited warranty to the original retail purchaser only. Warranty coverage is not
transferable.
MINN KOTA LIMITED TWO-YEAR WARRANTY ON THE ENTIRE PRODUCT
JOME warrants to the original retail purchaser only that the purchaser’s new Minn Kota freshwater trolling motor will be materially free from defects in materials
and workmanship appearing within two (2) years after the date of purchase. JOME will (at its option) either repair or replace, free of charge, any parts found by
JOME to be defective during the term of this warranty. Such repair, or replacement shall be the sole and exclusive liability of JOME and the sole and exclusive
remedy of the purchaser for breach of this warranty.
MINN KOTA LIMITED LIFETIME WARRANTY ON COMPOSITE SHAFT
JOME warrants to the original retail purchaser only that the composite shaft of the purchaser’s Minn Kota trolling motor will be materially free from defects in
materials and workmanship appearing within the original purchaser’s lifetime. JOME will provide a new composite shaft, free of charge, to replace any composite
shaft found by JOME to be defective during the term of this warranty. Providing a new composite shaft shall be the sole and exclusive liability of JOME and the
sole and exclusive remedy of the purchaser for breach of this warranty; and purchaser shall be responsible for installing, or for the cost of labor to
install, any new composite shaft provided by JOME.
EXCLUSIONS & LIMITATIONS
This limited warranty does not apply to products that have been used in saltwater or brackish water, commercially or for rental purposes. This limited warranty
does not cover normal wear and tear, blemishes that do not affect the operation of the product, or damage caused by accidents, abuse, alteration, modification,
shipping damages, acts of God, negligence of the user or misuse, improper or insufficient care or maintenance. DAMAGE CAUSED BY THE USE OF
OTHER REPLACEMENT PARTS NOT MEETING THE DESIGN SPECIFICATIONS OF THE ORIGINAL PARTS WILL NOT BE COVERED BY
THIS LIMITED WARRANTY. The cost of normal maintenance or replacement parts which are not in breach of the limited warranty are the responsibility
of the purchaser. Prior to using products, the purchaser shall determine the suitability of the products for the intended use and assumes all related risk and
liability. Any assistance JOME provides to or procures for the purchaser outside the terms, limitations or exclusions of this limited warranty will not constitute
a waiver of the terms, limitations or exclusions, nor will such assistance extend or revive the warranty. JOME will not reimburse the purchaser for any expenses
incurred by the purchaser in repairing, correcting or replacing any defective products or parts, except those incurred with JOME’s prior written permission.
JOME’S AGGREGATE LIABILITY WITH RESPECT TO COVERED PRODUCTS IS LIMITED TO AN AMOUNT EQUAL TO THE PURCHASER’S
ORIGINAL PURCHASE PRICE PAID FOR SUCH PRODUCT.
MINN KOTA SERVICE INFORMATION
To obtain warranty service in the U.S., the product believed to be defective, and proof of original purchase (including the date of purchase), must be presented
to a Minn Kota Authorized Service Center or to Minn Kota’s factory service center in Mankato, MN. Any charges incurred for service calls, transportation or
shipping/freight to/from the Minn Kota Authorized Service Center or factory, labor to haul out, remove, re-install or re-rig products removed for warranty service,
or any other similar items are the sole and exclusive responsibility of the purchaser. Products purchased outside of the U.S. must be returned prepaid with
proof of purchase (including the date of purchase and serial number) to any Authorized Minn Kota Service Center in the country of purchase. Warranty service
can be arranged by contacting a Minn Kota Authorized Service Center or by contacting the factory at 1-800-227-6433 or email [e-mail].
Products repaired or replaced will be warranted for the remainder of the original warranty period [or for 90 days from the date of repair
or replacement, whichever is longer]. For any product that is returned for warranty service that JOME finds to be not covered by or not
in breach of this limited warranty, there will be a billing for services rendered at the prevailing posted labor rate and for a minimum of at
least one hour.
NOTE: Do not return your Minn Kota product to your retailer. Your retailer is not authorized to repair or replace products.
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THESE LIMITED WARRANTIES. IN NO EVENT SHALL ANY IMPLIED
WARRANTIES INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR PARTICULAR PURPOSE, EXTEND
BEYOND THE DURATION OF THE RELEVANT EXPRESS LIMITED WARRANTY. IN NO EVENT SHALL JOME BE LIABLE FOR PUNITIVE,
INDIRECT, INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES. Without limiting the foregoing, JOME assumes no responsibility for
loss of use of product, loss of time, inconvenience or other damage.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above
limitations and/or exclusions may not apply to you. This warranty gives you specific legal rights and you may also have other legal rights which vary from state
to state.
FEATURES
Specifications subject to change without notice.
*This diagram is for reference only and may differ from your actual motor.
Latch & Door
Depth Adjustment Knob
Directional Indicator
Mounting Bracket
Lifetime Warranty
Flexible Composite Shaft
Propeller
Momentary Switch
Mom/Off/Con Switch
Heel Block
Rotary Speed Control
Cool Quiet
Power Motor

TOOLS AND RESOURCES REQUIRED:
• Phillips Screw Driver
• Drill
• 9/32” Drill Bit
• 7/16” Box End Wrench
• A second person to help with the installation
1. Before you proceed, determine the desired mounting location for the motor. It is recommended that the motor be mounted as
close to the center line of the boat as possible as seen below.
CAUTION: Make sure the motor is mounted on a level surface and is not connected to a power source.
2. Verify the area under the chosen mounting location is clear and safe to drill through.
3. Place the motor on top of the desired mounting location while it is in the stowed position (for stow and deploy instructions,
see "Stowing and Deploying the Motor" on p. 11).
4. Verify the motor rest is positioned far enough beyond the edge of the boat so that the motor clears all obstructions while
deploying and stowing the motor.
MOUNT INSTALLATION

5. Deploy the motor and remove the motor assembly from the mount by loosening the Steering Tension Knob and opening the
door.
WARNING:
When raising or lowering motor, keep fingers clear of all hinge and pivot points and all moving parts.
6. Position the mount again in the stowed position.
7. Temporarily remove the Phillips screws that fasten the motor rest to the mounting bracket and remove the motor rest to
expose the motor mounting hole pattern.
8. Determine the mounting hole pattern you wish to use from the illustration to the
right. Using the mounting holes in the mount as your template, mark the top deck
of the boat with a pencil or an erasable marker.
9. Remove the mount from the deck of the boat and drill the holes that you marked
in the previous step using a 9/32” drill bit and drill. Be careful not to damage any
wiring or critical features that may exist under the surface you are drilling through.
10. Place the mount on the deck of the boat again and verify the hold down strap is
positioned 15 ¾” from the front of the bow mount as shown in the diagram.
11. Fasten the mount to the deck of the boat using the supplied ¼” – 20 X 2” bolts,
washers and nuts. Tighten the stainless mount hardware securely but slowly
to the deck of the boat using a 7/16” box end wrench. Tightening the stainless
hardware too fast may result in galling and or seizing of the bolts and nuts.
12. Reinstall the motor rest using the six original ¼” Phillips screws.
13. Reinstall the motor assembly into the mount and securely tighten the steering
tension knob.
15 3/4“
Motor Rest
©2014 Johnson Outdoors Marine Electronics, Inc.
MOUNT INSTALLATION
Depth Adjustment Knob
Motor Assembly

BOAT RIGGING & PRODUCT INSTALLATION
For safety and compliance reasons, we recommend that you follow American Boat and Yacht Council (ABYC) standards when
rigging your boat. Altering boat wiring should be completed by a qualified marine technician. The following specifications are for
general guidelines only:
CAUTION: These guidelines apply to general rigging to support your Minn Kota motor. Powering multiple motors or additional
electrical devices from the same power circuit may impact the recommended conductor gauge and circuit breaker size. If you are
using wire longer than that provided with your unit, follow the conductor gauge and circuit breaker sizing table below. If your wire
extension length is more than 25 feet, we recommend that you contact a qualified marine technician.
An over-current protection device (circuit breaker or fuse) must be used. Coast Guard requirements dictate that
each ungrounded current-carrying conductor must be protected by a manually reset, trip-free circuit breaker or fuse. The type
(voltage and current rating) of the fuse or circuit breaker must be sized accordingly to the trolling motor used. The table below gives
recommended guidelines for circuit breaker sizing.
Reference:
United States Code of Federal Regulations: 33 CFR 183 – Boats and Associated Equipment
ABYC E-11: AC and DC Electrical Systems on Boats
CONDUCTOR GAUGE AND CIRCUIT BREAKER SIZING TABLE
Motor Thrust /
Model Max Amp Draw Circuit Breaker Wire Extension Length *
5 feet 10 feet 15 feet 20 feet 25 feet
30 lb. 30 50 Amp @ 12 VDC 10 AWG 10 AWG 8 AWG 6 AWG 4 AWG
40 lb., 45 lb. 42 10 AWG 8 AWG 6 AWG 4 AWG 4 AWG
50 lb., 55 lb. 50 60 Amp @ 12 VDC 8 AWG 6 AWG 4 AWG 4 AWG 2 AWG
70 lb. 42 50 Amp @ 24 VDC 10 AWG 10 AWG 8 AWG 8 AWG 6 AWG
80 lb. 56 60 Amp @ 24 VDC 8 AWG 8 AWG 8 AWG 6 AWG 6 AWG
101 lb. 46 50 Amp @ 36 VDC 8 AWG 8 AWG 8 AWG 8 AWG 8 AWG
Engine Mount 101 50 60 Amp @ 36 VDC 8 AWG 6 AWG 4 AWG 4 AWG 2 AWG
112 lb. 52 60 Amp @ 36 VDC 8 AWG 8 AWG 8 AWG 8 AWG 8 AWG
Engine Mount 160 116 (2) x 60 Amp @ 24 VDC 2 AWG 2 AWG 2 AWG 2 AWG 2 AWG
E-Drive 40 50 Amp @ 48 VDC 10 AWG 10 AWG 10 AWG 10 AWG 10 AWG
This conductor and circuit breaker sizing table is only valid for the following assumptions:
1. No more than 3 conductors are bundled together inside of a sheath or conduit outside of engine spaces.
2. Each conductor has 105° C temp rated insulation.
3. No more than 5% voltage drop allowed at full motor power based on published product power requirements.
*Wire Extension Length refers to the distance from the batteries to the trolling motor leads.
BATTERY WIRING & INSTALLATION

BOAT RIGGING & PRODUCT INSTALLATION
For safety and compliance reasons, we recommend that you follow American Boat and Yacht Council (ABYC) standards when
rigging your boat. Altering boat wiring should be completed by a qualified marine technician. The following specifications are for
general guidelines only:
CAUTION: These guidelines apply to general rigging to support your Minn Kota motor. Powering multiple motors or additional
electrical devices from the same power circuit may impact the recommended conductor gauge and circuit breaker size. If you are
using wire longer than that provided with your unit, follow the conductor gauge and circuit breaker sizing table below. If your wire
extension length is more than 25 feet, we recommend that you contact a qualified marine technician.
An over-current protection device (circuit breaker or fuse) must be used. Coast Guard requirements dictate that
each ungrounded current-carrying conductor must be protected by a manually reset, trip-free circuit breaker or fuse. The type
(voltage and current rating) of the fuse or circuit breaker must be sized accordingly to the trolling motor used. The table below gives
recommended guidelines for circuit breaker sizing.
Reference:
United States Code of Federal Regulations: 33 CFR 183 – Boats and Associated Equipment
ABYC E-11: AC and DC Electrical Systems on Boats
CONDUCTOR GAUGE AND CIRCUIT BREAKER SIZING TABLE
Motor Thrust /
Model Max Amp Draw Circuit Breaker Wire Extension Length *
5 feet 10 feet 15 feet 20 feet 25 feet
30 lb. 30 50 Amp @ 12 VDC 10 AWG 10 AWG 8 AWG 6 AWG 4 AWG
40 lb., 45 lb. 42 10 AWG 8 AWG 6 AWG 4 AWG 4 AWG
50 lb., 55 lb. 50 60 Amp @ 12 VDC 8 AWG 6 AWG 4 AWG 4 AWG 2 AWG
70 lb. 42 50 Amp @ 24 VDC 10 AWG 10 AWG 8 AWG 8 AWG 6 AWG
80 lb. 56 60 Amp @ 24 VDC 8 AWG 8 AWG 8 AWG 6 AWG 6 AWG
101 lb. 46 50 Amp @ 36 VDC 8 AWG 8 AWG 8 AWG 8 AWG 8 AWG
Engine Mount 101 50 60 Amp @ 36 VDC 8 AWG 6 AWG 4 AWG 4 AWG 2 AWG
112 lb. 52 60 Amp @ 36 VDC 8 AWG 8 AWG 8 AWG 8 AWG 8 AWG
Engine Mount 160 116 (2) x 60 Amp @ 24 VDC 2 AWG 2 AWG 2 AWG 2 AWG 2 AWG
E-Drive 40 50 Amp @ 48 VDC 10 AWG 10 AWG 10 AWG 10 AWG 10 AWG
This conductor and circuit breaker sizing table is only valid for the following assumptions:
1. No more than 3 conductors are bundled together inside of a sheath or conduit outside of engine spaces.
2. Each conductor has 105° C temp rated insulation.
3. No more than 5% voltage drop allowed at full motor power based on published product power requirements.
*Wire Extension Length refers to the distance from the batteries to the trolling motor leads.
CONNECTING THE BATTERIES
12 VOLT SYSTEMS:
1.
Make sure that the motor is switched off (speed selector on “OFF” or “0”).
2.
Connect positive ( + ) red lead to positive ( + ) battery terminal.
3.
Connect negative ( – ) black lead to negative ( – ) battery terminal.
4.
For safety reasons do not switch the motor on until the propeller is in the water.
CAUTION:
For safety reasons, disconnect the motor from the battery/batteries when the motor is not in use or while the
battery/batteries are being charged.
SELECTING THE CORRECT BATTERIES
The motor will operate with any lead acid, deep cycle marine 12 volt battery/batteries. For best results, use a deep cycle, marine
battery with at least a 105 ampere hour rating. Maintain battery at full charge. Proper care will ensure having battery power
when you need it, and will significantly improve the battery life. Failure to recharge lead-acid batteries (within 12-24 hours) is the
leading cause of premature battery failure. Use a multi-stage charger to avoid overcharging. We offer a wide selection of chargers
to fit your charging needs. If you are using a crank battery to start a gasoline outboard, we recommend that you use a separate
deep cycle marine battery/batteries for your Minn Kota trolling motor.
Advice Regarding Batteries:
•
Never connect the (+) and the (–) terminals of the battery together. Take care that no metal object can fall onto the battery and
short the terminals. This would immediately lead to a short and extreme fire danger.
•
It is highly recommended that a circuit breaker or fuse be used with this trolling motor. Refer to “Conductor Gauge and Circuit
Breaker Sizing Table” in the previous section to find the appropriate circuit breaker or fuse for your motor. For motors requiring
a 60-amp breaker, the Minn Kota MKR-19 60-amp circuit breaker is recommended.
CONNECTING THE BATTERIES IN SERIES
(IF REQUIRED FOR YOUR MOTOR)
24 VOLT SYSTEMS:
1. Make sure that the motor is switched off (speed selector on “0”).
2. Two 12 volt batteries are required.
3. The batteries must be wired in series, only as directed in wiring
diagram, to provide 24 volts.
a. Connect a connector cable to the positive ( + ) terminal of
battery 1 and to the negative ( – ) terminal of battery 2.
b. Connect positive ( + ) red lead to positive ( + ) terminal on battery 2.
c. Connect negative ( – ) black lead to negative ( – ) terminal of battery 1.
4. For safety reasons do not switch the motor on until the propeller is in the water. If installing a leadwire plug, observe proper
polarity and follow instructions in your boat owner’s manual. See wiring diagram on following pages.
CAUTION
• For safety reasons, disconnect the motor from the battery or batteries when the motor is not in use or while
the battery/batteries are being charged.
• Improper wiring of 24/36 volt systems could cause battery explosion!
• Keep leadwire wing nut connection tight and solid to battery terminals.
• Locate battery in a ventilated compartment.
To trolling motor negative
24 Volt Connection
Battery #1 (Low Side)
Neg - Neg -Pos + Pos +
Battery #2 (High Side)
+24 Volts to trolling motor
positive (or circuit breaker)
24 Volt Series Connection
©2014 Johnson Outdoors Marine Electronics, Inc.
BATTERY WIRING & INSTALLATION

MOTOR WIRING DIAGRAM
w
Y
AB
R
+
MOT0R
BATTERY 1
BATTERY 1 BATTERY 2
MOM/OFF/CON SWITCH
BLACK/BLUE
RED+ YELLOW WHITE
BLACK-
FIVE SPEED SWITCH RED+
BLACK-
RED+
TERMINAL BLOCK
MOMENTARY SWITCH BLACK/WHITE
12v
24v
NOTE: This is a universal, multi-voltage diagram. Double-check your motor's voltage for proper connections. Over-Current
Protection Devices not shown in this illustration.

STOWING AND DEPLOYING THE MOTOR
WARNING:
When raising or lowering the motor, keep fingers clear of all hinge and pivot points and all moving parts.
MOUNT FEATURES
• The motor mount is designed to fold back and lock the motor flat on the deck when not in use and to
provide secure stowage for transport.
• The pull grip and rope releases the lock bar, which automatically engages when the unit is lowered or
raised into position. The pull grip and rope should be used to both lower and raise the unit.
• The motor rest positions the lower unit as it comes in contact with the nose of the mount and guides
it onto the motor rest.
• The tube lock captures the motor shaft and keeps the lower unit centered on the motor rest.
• The hold-down strap must be used to place pressure on the motor shaft to hold the lower unit
tightly against the motor rest when stowed.
• The pull grip and rope can be stored by placing the pull grip on top of the tube lock or into the
rope stow slot on the control box of the motor.
TO DEPLOY THE MOTOR
Simply pull back and lift the motor off of the mount with the pull grip and rope. Lower the motor into the water using the pull grip
and rope. The motor will lock into the deployed position automatically.
TO STOW THE MOTOR
Pull back and lift the motor out of the water with the pull grip and rope. Lower the lower unit onto the motor rest using the pull
grip and rope. The motor will lock into the stowed position automatically. Wrap the hold-down strap over top of the motor shaft
to secure the motor.
USING AND ADJUSTING THE MOTOR
Motor Rest
Hold Down Strap Tube Lock
Motor Shaft
Lower Unit
Rope Stow Slot
Pull Grip and Rope

Depth Adjustment Knob
Steering Tension Knob
Adjustable Depth Collar
Outer Shaft
Shaft
12” Minimum
Depth
12” Minimum
Depth
ADJUSTING THE DEPTH OF THE MOTOR
The propeller tip must be submerged at least 12” to avoid churning
or agitation of surface water.
1. With the motor deployed, firmly grasp the outer shaft or control
head and hold it steady.
2. Loosen the depth adjustment knob until the shaft slides freely.
3. Raise or lower the motor to the desired depth.
4. Turn the motor control head to the desired position.
5. Tighten depth adjustment knob to secure the motor in place.
ADJUSTING THE DEPTH OF THE MOTOR
The propeller tip must be submerged at least 12” to avoid churning
or agitation of surface water.
1. With the motor deployed, firmly grasp the shaft or control head
and hold it steady.
2. Loosen the adjustable depth collar and steering tension knob
until the shaft slides freely.
3. Raise or lower the motor to the desired depth.
4. Turn the motor control head to the desired position.
5. Tighten the adjustable depth collar and the steering tension knob
to secure the motor in place.
MANUAL EDITOR: SHOW TOP HALF OF PAGE FOR FOOT CONTROL
MANUAL EDITOR: SHOW BOTTOM HALF OF PAGE FOR HAND CONTROL
ADJUSTING THE STEERING CABLE
The steering cable tension is pre-set at the factory but will, through normal use, need occasional adjustment.
Adjust the tension of the cables by turning the cable tension adjustment screw (Phillips pan-head screw) located near the bottom
of the foot pedal, just under the steering cable cover.
Turn the screw clockwise to increase tension and counter-clockwise to decrease tension.
NOTE:
If the cable becomes too loose, it may disengage the wrap drum in the control box or the pulley in the foot pedal.
Cable Tension Adjustment Screw Stainless Steel Cable Cable Pulley
©2014 Johnson Outdoors Marine Electronics, Inc.
USING & ADJUSTING THE MOTOR

Toe End Speed Knob
Heel End
Mom/Off/Con Switch
Momentary Button
Directional
Indicator
CONTROLLING SPEED & STEERING WITH THE FOOT PEDAL
Most controls on the foot pedal are easy to operate by either foot or hand:
TO ADJUST MOTOR SPEED
Turn the speed knob clockwise to increase speed and counter-clockwise to decrease speed.
TO OPERATE THE MOTOR IN CONTINUOUS MODE
Press the Mom/Off/Con switch on the side of the pedal to the Con position.
TO OPERATE THE MOTOR IN MOMENTARY MODE
Press the Mom/Off/Con switch on the side of the pedal to the Mom position. A toe touch to the Momentary button on the foot
pedal will now turn the motor on. Removing downward force on the Momentary button will turn the motor off.
TO TURN LEFT OR RIGHT
Push the toe end of the foot pedal down to turn right and push the heel end of the foot pedal down to turn left. The indicator on
the motor head shows the direction of the motor. The motor will not maintain its own heading. You must keep your foot on the
pedal to control steering during operation.
TO REVERSE THE MOTOR
The motor always travels in the direction of the indicator. You can reverse the direction of the motor by turning the motor 180°
from straight ahead.
CAUTION:
• Switch the mom/off/con switch to “off” when not in use. If the motor control is left on and the propeller
rotation is blocked, severe motor damage can result.
• Be sure to turn the motor off after each use.
• For safety reasons, disconnect the motor from the battery/batteries when the motor is not in use or while the
battery/batteries are being charged.
©2014 Johnson Outdoors Marine Electronics, Inc.
USING & ADJUSTING THE MOTOR

Propeller
Slot End
Drive Pin
Prop Nut
Washer
PROPELLER REPLACEMENT
TOOLS AND RESOURCES REQUIRED:
• 7/16” Box End Wrench
• Screwdriver (optional)
CAUTION:
Disconnect the motor from the battery
before beginning any prop work or
maintenance.
NOTE: The propeller on your motor may differ from
the one pictured.
1. Disconnect the motor from all sources of power
prior to changing the propeller.
2. Hold the propeller and loosen the prop nut with pliers or a wrench.
3. Remove the prop nut and washer. If the drive pin is sheared or broken, you will need to hold the shaft stationary with a blade
screwdriver pressed into the slot on the end of the shaft.
4. Turn the old prop to horizontal (as illustrated) and pull it straight off. If drive pin falls out, push it back in.
5. Align the new propeller with the drive pin.
6. Install the prop washer and prop nut.
7. Tighten the prop nut 1/4 turn past snug [25-35 inch lbs.] Do not over tighten as this can damage the prop.
GENERAL MAINTENANCE
1. After use, the entire motor should be rinsed with freshwater, then wiped down with a cloth dampened with an aqueous based
silicone spray. This series of motors is not equipped for saltwater exposure.
2. The propeller must be inspected and cleaned from weeds and fishing line after every use.
Fishing line and weeds can get behind the prop, damage the seals and allow water to enter the motor.
3. Verify the prop nut is secure each time the motor is used.
4. To prevent accidental damage during transportation or storage, disconnect the battery whenever the motor is off of the water.
For prolonged storage, lightly coat all metal parts with an aqueous based silicone spray.
5. For maximum battery life recharge the battery(s) as soon as possible after use. For maximum motor performance restore
battery to full charge prior to use.
6. Keep battery terminals clean with fine sandpaper or emery cloth.
7. The propeller is designed to provide weed free operation with very high efficiency. To maintain this top performance, the
leading edge of the blades must be kept smooth. If they are rough or nicked from use, restore to smooth by sanding with fine
sandpaper.
SERVICE & MAINTENANCE

Propeller
Slot End
Drive Pin
Prop Nut
Washer
PROPELLER REPLACEMENT
TOOLS AND RESOURCES REQUIRED:
• 7/16” Box End Wrench
• Screwdriver (optional)
CAUTION:
Disconnect the motor from the battery
before beginning any prop work or
maintenance.
NOTE: The propeller on your motor may differ from
the one pictured.
1. Disconnect the motor from all sources of power
prior to changing the propeller.
2. Hold the propeller and loosen the prop nut with pliers or a wrench.
3. Remove the prop nut and washer. If the drive pin is sheared or broken, you will need to hold the shaft stationary with a blade
screwdriver pressed into the slot on the end of the shaft.
4. Turn the old prop to horizontal (as illustrated) and pull it straight off. If drive pin falls out, push it back in.
5. Align the new propeller with the drive pin.
6. Install the prop washer and prop nut.
7. Tighten the prop nut 1/4 turn past snug [25-35 inch lbs.] Do not over tighten as this can damage the prop.
GENERAL MAINTENANCE
1. After use, the entire motor should be rinsed with freshwater, then wiped down with a cloth dampened with an aqueous based
silicone spray. This series of motors is not equipped for saltwater exposure.
2. The propeller must be inspected and cleaned from weeds and fishing line after every use.
Fishing line and weeds can get behind the prop, damage the seals and allow water to enter the motor.
3. Verify the prop nut is secure each time the motor is used.
4. To prevent accidental damage during transportation or storage, disconnect the battery whenever the motor is off of the water.
For prolonged storage, lightly coat all metal parts with an aqueous based silicone spray.
5. For maximum battery life recharge the battery(s) as soon as possible after use. For maximum motor performance restore
battery to full charge prior to use.
6. Keep battery terminals clean with fine sandpaper or emery cloth.
7. The propeller is designed to provide weed free operation with very high efficiency. To maintain this top performance, the
leading edge of the blades must be kept smooth. If they are rough or nicked from use, restore to smooth by sanding with fine
sandpaper.
1. Motor fails to run or lacks power:
• Check battery connections for proper polarity.
• Make sure terminals are clean and corrosion free. Use fine sandpaper or emery cloth to clean terminals.
• Check battery water level. Add water if needed.
2. Motor loses power after a short running time:
• Check battery charge. If low, restore to full charge.
3. Motor is difficult to steer:
• Check steering cables for proper tension. Adjust as necessary.
4. You experience prop vibration during normal operation:
• Remove and rotate the prop 180°. See removal instructions in the Propeller Replacement Section.
5. Experiencing interference with your fishfinder:
TROUBLESHOOTING & REPAIR

1
2
5
6
7
8
19
18
20
21
23
24
15
12
10
30
3
22
4
28
25
29
27
9
63
64
65
66
67
66
68
69
71 71
73
74
75
76
139
140
141
77
79
78
80
81
82
107
113
115
114
121
129
51
126
127
142
84
26
128
131
132
133
41
50
40
36
35
49
42
44
55
60
61
59
57
56
58
147
54
37
73A
62
52
48
53
70
137
72
120
85
86
87
100
91
92
93
94
96
95 97
98
99
103
105
106
108
109
110
116
118
119
122
124
125
129
130
134
136
123
104
90
88
135
129
34
145
144
33
31
143
37
46
47
32
45
43
This page provides Minn Kota® WEEE compliance disassembly instructions.
For more information about where you should dispose of your waste equipment
for recycling and recovery and/or your European Union member state
requirements, please contact your dealer or distributor from which your product
was purchased.
Tools required, but not limited to: flat head screw driver, Phillips screw driver,
socket set, pliers, wire cutters.
EDGE 55
55 LBS THRU - 12 VOLT - 45”/52” SHA
2274996 rev H ECN 35972 7/14
PARTS DIAGRAM

EDGE 55
55 LBS THRU - 12 VOLT - 45”/52” SHA
ITEM QTY PART
NUMBER DESCRIPTION
1 1 2-100-117 ARM SEMBLY 12 V 3.625
2 1 788-015 RAINING RING
3 1 2-200-101 HOUSING SEMBLY
CENTER 3.65 TXT
4 1 2-300-199 HOUSING -SEMBLY
BRUSH END 3.65
12-300-195 HOUSING -SEMBLY
BRUSH END 3.65
5 1 2-400-101 PIN END HOUSING
SEMBLY
6 1 144-049 FNGE BEARING
[SERVICE ONLY]
7 1 880-003 SEAL
8 1 880-006 SEAL WITH SHIELD
9 1 140-010 BALL BEARING
10 2188-036 BRUSH SEMBLY
12 1738-036 BRUSH PTE
W/HOLDER 3.625
15 2975-040 TORSION SPRING
18 2701-008 O-RING
19 1701-081 O-RING MK406460
20 1337-036 GK
21 2830-007 SCREW — SELF-THREAD
#8-32X1.7
22 2830-042 THRU BOLT 8-32 X 8.96
23 1990-067 EEL THRU WHER
24 2990-070 NYTRON WHER
25 12097077 MTR SEMBLY 12V 3.625
12097076 MTR SEMBLY 12V 3.625
26 12032062 TUBE (COMP)W/K HOLE
12032061 TUBE (COMP)W/K HOLE
12032067 TUBE (COMP)W/K HOLE
n11378131 PROPELLER KIT
27 12061160 PROPELLER
28 12151726 WHER- 5/16 SS
29 12053101 NUT-PROP NYLOC
30 12092600 DRIVE PIN
31 12266507 BOWPTE, FW, LONG
12266502 BOWPTE, FW, D
32 12263905 BCK MOTOR R
33 62303430 SCREW 1/4-20 X 5/8
34 22265667 MOTOR R DEL, FW
n12991717 MOUNT, SY LONG FW
12991716 MOUNT, SY SHORT FW
35 12264377 LOWER ARM, FW, LONG
12264372 LOWER ARM, FW, D.
36 42266002 NYLINER 3/8” SHA
37 32260503 PIVOT PIN
40 12150405 PULL-GRIP
41 12151700 WHER-EYE SHA
.562 OD
n12993812 TCH RAP SY, LONG
12993811 TCH RAP SY, D
42 12263607 TCH RAP, LONG
12263605 TCH RAP, D
43 22261903 TCH BRACK
44 42268602 RIV 1/8” SS
45 12262709 SPRING-TCH PIN
46 22260501 TCH PIN
47 12261544 YOKE-TUBE
48 12264272 ARM-UPPER, LONG FW
12264271 ARM-UPPER, SHORT FW
49 22263510 BOLT-SHOULDER, SS
50 12251601 ROPE- 44.5”
ITEM QTY PART
NUMBER DESCRIPTION
12251603 ROPE- 48”
51 12263805 VELCRO RAP
52 12267302 BUSHING —LOWER 7/16”
ID, SS
53 12267303 BUSING — UPPER 3/8”
ID, SS
54 12263505 BOLT 3/8-16 X 4.25”
55 12263114 NYLOCK JAM NUT 3/8-16
56 12261892 HING BE, FW
57 12261897 HINGE DOOR, FW
58 12260905 SO GRIP HANDLE, L&D
59 12261728 RAINING WHER- 3/8”
60 22053415 SCREW #8-32 X 3/8” TRI
61 22261732 WHER #8, NYLON
62 22264703 THREADED INSERT
12992012 TUBE W/BEARING RACE
SEMBLY 21”
12992016 TUBE W/BEARING RACE
SEMBLY 24”
63 12272069 21” TUBE OUTER 4 HOL
12272067 24” TUBE OUTER 4 HOL
64 12266260 BEARING RACE
65 12266220 EEL BEARING RACE
66 22266000 EEL BEARING BALL
67 12266115 BEARING CONE
68 22261622 ALUMINUM HALF-COLR
69 22263453 SCREW — 1/4X20 X 1”
70 12260215 CONTROL BOX COVER
71 62372100 SCREW — 8-18 X 5/8 THD
72 12275613 DEL-COVER, EDGE
55/FC
73 12260153 POINTER DISC SHORT
YELLOW
73A 12261733 WHER-FOAM,
INDITOR
74 12265800 DEL-INDITOR
75 32053414 SCREW-8-32 X 1/2
TRI LOBE
76 12267800 GEAR-INDITOR
77 12372100 SCREW-8-18 X 5/8 THD
78 22375400 SHRINK TUBE-1/4OD X
1-3/4
79 22355410 SHRINK TUBE-3/8 OD X 2
80 12232360 PULLEY — BLE DRUM
81 12261730 NYLON A/T WHER
82 12996246 BEARING RACE/ PINION
SEMBLY
84 22263410 SCREW — #8-32 X 5/16
85 12994496 FOOT PEDAL/PLUG
SEMBLY
86 12283700 PUSH-BUTTON
87 12302732 LOWER PEDAL SPRING
88 12264040 MOMENTARY SWITCH
90 22262114 MOUNTING/SWITCH
SCREW
91 22233100 SWITCH MOUNT NUT
92 12264026 SWITCH — 5 SPEED
93 12261701 LOCKWHER-AR
94 12263105 HEX NUT
95 12261715 SPACER-SWITCH 5 SP
MODE
96 12280110 SPEED CONTROL KNOB
5SPD
97 12263000 E-RING TRU-ARC
ITEM QTY PART
NUMBER DESCRIPTION
98 12260730 CONNEOR 1/4 MALE
TAB
99 12332103 SCREW — #6-20 X 3/8
100 12266413 TENSION SCREW PTE
FOOT PEDAL
103 12260511 PIN-PIVOT A/T FOOT PEDAL
104 12992104 FOOT PEDAL BE/PIN
SEMBLY SONAR
105 12262301 PULLEY-FOOT PEDAL
106 12266401 COVER-PULLEY AMPING
107 42223430 SCREW-#8X 3/4
108 12254031 MOM/OFF/COM SWITCH
109 12266412 FOOT PEDAL SWITCH PTE
110 22332103 SCREW — #6-20 X 3/8 THD
113 12261208 WIRE HARNS, A/T
FOOT PEDAL
114 12267505 RIGHT BLE SEMBLY 5’
115 12267515 LE BLE SEMBLY 5’
116 12265430 BLE JACK 5’
118 12265115 BOOT-FOOT PEDAL BE
119 22372100 SCREW — #8-18 X 5/8 THD
120 22261714 FOOT PEDAL WHER
121 12261901 CONDUIT BRACK
122 22301310 SCREW — #8-18 X 3/4”
123 12263210 CONDUIT ADJUMENT
BRACK
124 12263140 NYLOCK KEEPER
125 12263466 SCREW — 1/4-20 X 2
126 12261235 LEADWIRE-BATTERY
127 22020700 TERMINAL RING, 3/8”
128 12256300 BCK TIE WRAP-5.5”
129 32263201 CMP WIRE HARNS
MICRO
130 12332103 SCREW — #6-20 X 3/8 THD
131 12260301 CONNEING WIRE
SWITCH
132 12260312 WIRE — BLK W/SHT- 19 1/2”
133 12260322 WIRE — BLK W/BLUE -12”
134 12263205 LEADWIRE CMP
135 29953104 SCREW — #8 X 1/2” SS
136 12301310 SCREW — #8 - 18 X 1/2” SS
137 12262515 CONTROL BOX BOTTOM
139 22267800 INDITOR GEAR
140 12262221 YELLOW DRIVE INDITOR
141 12269105 BRACK/INDITOR
142 12223430 SCREW — #8X 3/4 PPH
TYPE 25 SS
n12994838 BAG SEMBLY
*143 62263462 SCREW 1/4-20X2 SS
*144 62261713 WHER — 1/4 FT 18-18
*145 62263103 1/4-20 NYLOCK-JAM NUT
147 12262310 GUIDE ROPE
n12888460 SEAL & O-RING KIT
nTHIS ITEM IS PART OF AN SEMBLY.
*THIS ITEM IS PART OF A KIT AND ONLY LIED FOR
VIEWING PURPOS.
©2014 Johnson Outdoors Marine Electronics, Inc.
PARTS LIST

ENVIRONMENTAL COMPLIANCE STATEMENT:
It is the intention of JOME to be a responsible corporate citizen, operating in compliance with known and applicable
environmental regulations, and a good neighbor in the communities where we make or sell our products.
WEEE DIRECTIVE:
EU Directive 2002/96/EC “Waste of Electrical and Electronic Equipment Directive (WEEE)” impacts most distributors, sellers,
and manufacturers of consumer electronics in the European Union. The WEEE Directive requires the producer of consumer
electronics to take responsibility for the management of waste from their products to achieve environmentally responsible
disposal during the product life cycle.
WEEE compliance may not be required in your location for electrical & electronic equipment (EEE), nor may it be required
for EEE designed and intended as fixed or temporary installation in transportation vehicles such as
automobiles, aircraft, and boats. In some European Union member states, these vehicles are considered
outside of the scope of the Directive, and EEE for those applications can be considered excluded from the
WEEE Directive requirement.
This symbol (WEEE wheelie bin) on product indicates the product must not be disposed of with other
household refuse. It must be disposed of and collected for recycling and recovery of waste EEE. Johnson
Outdoors Inc. will mark all EEE products in accordance with the WEEE Directive. It is our goal to comply
in the collection, treatment, recovery, and environmentally sound disposal of those products; however, these requirement do
vary within European Union member states. For more information about where you should dispose of your waste equipment for
recycling and recovery and/or your European Union member state requirements, please contact your dealer or distributor from
which your product was purchased.
DISPOSAL:
Minn Kota motors are not subject to the disposal regulations EAG-VO (electric devices directive) that implements the WEEE
directive. Nevertheless never dispose of your Minn Kota motor in a garbage bin but at the proper place of collection of your local
town council.
Never dispose of battery in a garbage bin. Comply with the disposal directions of the manufacturer or his representative and
dispose of them at the proper place of collection of your local town council.
WARNING:
This product contains chemical(s) known to the state of California to cause cancer and/or reproductive toxicity.
COMPLIANCE STATEMENTS

• 60-Amp Circuit Breaker
• Mounting Brackets
• Stabilizer Kits
• Extension Handles
• Battery Connectors
• Battery Boxes
• Quick Connect Plugs
RECOMMENDED ACCESSORIES
ON-BOARD & PORTABLE BATTERY CHARGERS
Stop buying new batteries and start taking care of the ones you’ve got. Many chargers can actually damage your battery
over time – creating shorter run times and shorter overall life. Digitally controlled Minn Kota chargers are designed to provide the
fastest charge that protect and extend battery life.
TALON SHALLOW WATER ANCHOR
Talon deploys faster, holds stronger and runs quieter than any other shallow water anchor. Available in depths up to 12’ and bold color
options, it boasts an arsenal of features and innovations that no other anchor can touch:
MINN KOTA ACCESSORIES
We offer a wide variety of trolling motor accessories, including:
MK212DMK345PC MK105P
• Vertical, multi-stage deployment
• User-Selectable Anchoring Modes
• 2x Anchoring Force
• Fast Deploy
• Auto Up/Down
• Triple Debris shields*
• Built-In Wave Absorption
• Noise Dissipation
• Versatile Adjustments
*available on 10’ and 12’ models only
