Multi-Function Handheld Transmitter
T–3 Operating Guide
Care and Handling
Failure to follow care and handling instructions will void the
warranty and could result in unsafe equipment operation.
Clean transmitter gently with a damp cloth or dry, compressed air.
Do not immerse transmitter in water, or spray with hose. Do not
store outside.
Do not drop transmitter or otherwise subject transmitter to
physical shock.
Do not expose transmitter to extreme temperatures.
Do not open transmitter enclosure. Transmitter contains no user
serviceable parts.
OPERATION
Controls
Transmitters are built-to-suit, and may be equipped with
potentiometers, pushbuttons, switches, and other customer-
specificed controls. Take time to familiarize the operation and
arrangement of the controls before operating equipment.
Batteries
is transmitter operates from 3 “AA” cell batteries. Long-range
transmitters operate from 4 “AAA” batteries. Alkaline batteries
generally provide longest life. If rechargeable batteries are used,
NiMH type are recommended. Batteries are accessible by removing
the thumbscrews that hold the battery compartment door on the
back of the housing. No tools are needed to replace batteries. To
ensure maximum battery life, be sure to turn the transmitter OFF
when not in use. Remove batteries prior to shipping or storing
transmitter.
Transmitter/Receiver Matching
Transmitters and receivers are shipped from the factory as matched
pairs. If a new transmitter is to be used, it must be trained to
operate the receiver.
Training procedure:
Transmitters with tether cables:
1. Connect transmitter to receiver using tether cable provided.
2. Operate transmitter to verify tether is connected.
3. Disconnect tether, and resume normal operation.
Transmitters without tether cables:
1. Power on transmitter and receiver.
2. Press “LEARN” button on receiver.
3. Operate transmitter normally.
Photo for reference only. Actual product appearance will vary.
IMPORTANT!
Read this manual completely before operating system.
Keep this manual available for future reference.
Make sure the area is safe for operating equipment before
turning power on or starting equipment.
If you encounter any problem or malfunction, discontinue
use immediately, and contact your equipment dealer for
service or replacement parts.
CAUTION
Improper operation of these controls could cause damage
to equipment. Do not allow anyone to operate this
equipment before completely reading all manuals.
NOTICE
Miratron, Inc. controls are not intended for life or safety
applications. Miratron, Inc. shall not accept responsibility
for installation, application, or safety of machine or systems
which utilize miratron, Inc. controls.

MIRATRON 866-417-5008 503-352-0654 www.miratron.com
SPECIFICATIONS
Transmitter Frequency 902-928MHz, Unlicensed ISM band standard models
2.4-2.4835GHz, Unlicensed ISM band international option
Type Frequency hopping spread spectrum
Frequency Control Direct FM
FCC id OUR9XCITE: Standard range
OUR9XTREAM: Extended range
OURXBEE: International version
Range (line of sight) Standard range = 500 feet
Extended range = 1500 feet
International = 500 feet
RF Power Output Standard range = 5mW
Extended range = 100mW
International = 60mW (100mW EIRP)
Battery Type 3 “AA” alkaline or rechargeable (4 “AAA”for TE3)
Battery Life (fully charged) Standard range = Standby, 40 hrs; Transmit, 16 hrs
Extended range = Standby, 10 hrs; Transmit, 4 hrs
International = Standby, 8 hrs; Transmit, 3 hrs
Controls User specied toggles, pushbuttons, potentiometers, trigger
Trigger (option) Non contact GMR type
Led Indicator Flashing = normal; Double blink = battery low
Enclosure Hand Grip High-impact polystyrene, UL94HB
Approximate size: 8”L (inc’l handle) x 4-1/2”W x 4”D
Sealing IP54 up to IP65
Environmental Storage -40ºC to 85ºC
Operating -10ºC to 60ºC
Troubleshooting:
ISSUE SOLUTIONS
Transmitter not working. LED not on or blinking. Install new batteries.
Make sure power switch is on.
Transmitter not working. LED on or blinking. Make sure E-Stop switch is out (if equipped.)
Install new batteries.
Make sure receiver is powered.
Check receiver fuse.
Make sure transmitter is in range of receiver.
Make sure transmitter and receiver are matched.
Poor range. Check receiver antenna and cable for loose connections or damage.
RInstall new batteries.
Obstructions, interference, and adverse weather can affect range.
One or more functions do not operate properly. Verify receiver wiring is correct.
Verify control device is operational (solenoid valve, pump, etc.)
Inspect transmitter, receiver, and cabling for damage. (Do not open.)
Some control systems feature special program logic that can disable
functions under certain conditions. Consult factory for specific details.
