MIRO Humidifier
User's Manual
MIRO-NR07SR MIRO-NR07BR MIRO-NR07GR

Greeting for purchase
Thank you for purchasing the maze humidifier.
Be sure to read the User's Manual before using it. And on each page,
! Be sure to observe the information that is written with the mark.
The User's Manual contains the warranty. Purchase date and place of purchase, etc.
Please fill it out and keep it after you read it.
If you sign up for Miro's official website at(www.gomiro.com) and register the genuine product,
We offer free A/S and discount services for one year.

Table of Contents
1. Product Configuration
2. Name of each department
3. Connecting devices
4. Use
5. Cleaning
6. FAQ
7. Precautions for Safety
8. Product specifications
9. Quality Assurance Statment

Product Configuration
다음 제품이 들어있는지 확인해주세요.Please check to see if the following products are included.
The main body MIRO Con Remote
DC adapter
User's Manual
sleeping cap
directional cap Microcaps

The names of each department
directional cap
sleeping cap
spray cap
Microcaps
a watertight
seal
Body upper
part
a heavy pain
Humidification
engine
Lower body
Water tank
DC adapter
Remote
Mirocan
NR07GR NR07SR NR07BR

Device connection
1. Put the battery in the remote control (RC).
2. Press the pairing button on the miroccan.
3. Press the pairing button on the remote control (RC).
4. Press and hold the humidity button to turn on the humidifier.
* If it is not paired, D1 message will appear when the button is touched, and if it is paired but not powered on, C0 message will be released
when the button is touched.
1
2
3
4

To install
1. Cable bond
Attach the fixing part of the humidification engine to the groove of the lower
body.
*If not correctly fitted, the medium torso and the upper
body will not be assembled.
2. Combine Humidification Engine
Place the humidity engine in the lower body as shown
in the picture next to it.
*Please join me at 90 degrees as shown in the picture.
3. Waterproof Fan Combination
Install the side marked 'IN' in the
waterproof pan with the arrow pointing
downwards.
4. Cervical coupling
Fit the medium pain into the lower groove of the body.
Neodium magnets are applied to the main joint for easier assembly.
*If the medium is incorrectly coupled, it can
affect the amount of humidification.

5. BODY 1 TOP
Combine the upper part of the body and the lower part of the body as shown in
the photograph.
The 2018 labyrinthine magnets of the main body help you assemble more
conveniently.
.
6. Combine Spray Caps
Combine the desired spray cap on the upper part of the humidifier body.
- Holding the spray cap and lifting the body may cause damage.
- Vertical spray caps boast maximum humidification of the maze. Due to
the high volume of humidification, moisture may be generated around
the area.
- assemble the directional cap on the top of the noise cap.
*Using sleep caps, orientation caps, and microcaps
sleeping cap
# If you want a quieter use of sleep, put a sleeping cap on it
The maze humidifier is a high-capacity humidifier with high humidity.
Humidifier characteristics can cause noise, but if you assemble it on the water tank of the maze humidifier with a
sleeping cap, it will reduce noise.
Micro humidification cap
# For a finer humidification, please attach the microcaps as shown in
the following picture.
# The humidity drops slightly when the microcaps are fitted

- The amount of humidification is reduced when sleeping and directional caps are used.
- Water reservoirs are filled with water and use of sleep caps and direction caps to prevent air absorption and
reduce humidification significantly. In this case, remove the water and use it.
7. Watering in Water Tank
Put clean water, bottled water, or tap water in the tank.
- Recommended use of water purification or bottled water.
- Use of boiling water or hot water may cause product failure.
- In most countries except Korea and Japan, water containing lime may fail, so
be sure to use water or bottled water.
- Contaminated water such as lime water and rust may cause the fault.
- Please add an adequate amount of water. Too much water in the tank will reduce the amount of humidification.
8. Floating the main body
Place the assembled body in water.
- Recommended use of water purification or bottled water.
- Too much water in the tank may overflow.
- In most countries except Korea and Japan, water containing lime may fail, so
be sure to use water or bottled water.
9. Joining a Tubble
Combine the water tank cover in the water tank as shown in the picture.
When combining the cover, make sure that the power cable line does not
overlap the cover. Overlapping may result in low water levels during
humidification and may cause humidity to slide to one side.

*Be careful not to overlap or break the power cable when joining the cover.
*If you put too much water into the water tank, the water will submerge and the humidifier may not work
properly.
10. Power connection
Connect the cables and adapters of the main body to the regulator (micro-
conditioner).
When you connect the cable, make sure it's connected correctly.

Use
Start driving
Refer to the # device connection page and pair the remote control (RC) with the miocon before powering on.
After you connect the instrument, press and hold the Remote Control (RC) humidity button to turn on the power.
- When power is off: All display, button operation is disabled. (Except long humidification)
- All movements must be consistent with the micro-cans. (Miroconity changes when controlling the humidity level
of the remocan (RC)
- Once paired, automatic connection is achieved.
- Click briefly to pair, and click for 3 seconds to break the pairing. (You will also see the seconds in the segment
when you press and hold the pairing button.)
- RC display lasts for 3 seconds (micro-conditioner display continues) and is activated according to changes in the
touch/slope of the remote control (RC) button.
Adjusting the Humidity
[To adjust with remotes (RC)
-You can adjust the humidity by pressing the humidity button (water droplet shape) while power is on. Press the
humidity button briefly to adjust the humidity in the order of approximately – medium – river – off.
You can also adjust the power to ON/OFF by pressing and holding the humidity button.
*The initial value of post-power humidification is step 1.
[Mirochanically Adjusted]
You can adjust the humidity by pressing the humidity button briefly in the same way as in - RC Adjustment .
Press and hold the humidity button to turn off the power.
Setting Timer
Timer setting is possible with the timer button (clockwise). Pressing the timer button briefly allows the timer
function to be used in the order of OFF- 1H- 4H-8H.

*The above functions cannot be set in Mirochan.
Using Automatic Mode
With the RC set, press and hold the timer button to enable the AUTO function. The humidifier automatically
adjusts the humidity according to the indoor environment.
* The temperature display is only active when it is set at 45 to 90 degrees.
*The above functions cannot be set in Mirochan.
To convert warm humidity
Touch the hot humidity section to reveal the humidity. If the Remote Control (RC) is lying down, it will not be
moved, and if it is held up, a short push or a wobble can be seen crossing humidity/temperature.
* The temperature display is only active when it is set at 45 to 90 degrees.
Remotes(RC)
MIROcon

Using Mirrored (IOT)
MiroT is a new type of IoT module provided in maze.
1. To use IoT, connect the mirocon to the main body first.
2. Open the rubber cap on the right.
3. Plug in the IoT module and it's ready. Use IoT conveniently after plugging it in.
Cleaning
When cleaning the humidifier, it is recommended that the humidifier is sufficiently frothy with a soft sponge etc.
* Cautions for cleaning
- Do not clean remote control (RC) and micro-cans.
- Be sure to remove the power plug from the outlet before cleaning.
- Cleaning with sulphuric acid, hydrochloric acid or organic solvents may cause damage to the parts.
- Do not pull the line of the maze humidification engine strongly.
- Do not place it in a dishwasher or a sterilized income machine.
*Do not clean the ports of the humidification engine.
1
2
3

FAQ
If you experience problems with your product use, check the following questions and solutions first.
If the content below does not solve the problem or does not apply, please contact the labyrinthine customer
center.
Q. The humidity is not rising.
A. Did you leave the windows wide open or let the air flow well outside?
S. Humidity depends on room temperature and size sealing. It is recommended to close windows and block
exterior.
Q. The noise is too loud.
A. If the noise is too loud, use a sleeping cap. The sleeping cap has an additional reduction of about 8 to 10 dB,
and when assembled and used on a maze humidifier tank, the noise is reduced.
Q. It doesn't work.
A1. Is the power plug off?
S1. Plug in the power plug and try again.
A2. Is the maze humidification engine and waterproof fan cable well connected?
S2. Check the connection of the maze humidification engine and the waterproof fan cable.
A3. RC, does the remote control light up?
S3. Check the connection between the maze humidification engine and the adapter. Also, it may flash if it is not
humidified due to an abnormality in the maze humidification engine.
A4. Is the power cable well connected to the main body?
Would be within the body, 4 and adapters that worked well and to connect, please.

Q. Can I wash it with high temperature water?
A. Please be careful when using hot water, as there is a risk of product deformation.
Q. Spray is weak or not possible.
A1. Isn't the water in the tank frozen or too hot?
S1. Use water at a reasonable temperature.
A2. Isn't the water in the tank too shallow?
S2. Fill the tank with enough water.
A3. Is the maze humidification engine and waterproof fan seated as per the manual?
S3. Please assemble it according to the installation method.
A4. Is the waterproof pan correctly orientated?
S4. Please assemble it according to the installation method.
A5. Is the waterproof fan working well when you put a maze moisturizing engine in water and connect it to the
power source?
S5. Check if the waterproof fan is working and if it is not working, please contact the Customer Service Center
(1661-5796).
A6. Isn't the maze wet engine or waterproof pan covered with water?
S6. Clean the maze humidification engine and waterproof pan according to the cleaning method.
A7. Isn't there any oil in the maze humidification engine or waterproof pan?
S7. Clean the maze humidification engine and waterproof pan according to the cleaning method.
A8. Is the body of the humidifier clogged with foreign substances?
S8. Remove foreign substances and use them.
Q. After cleaning, it seems that there is a fault, a defect, or a problem.
A1. Did you clean the adapters, the remote control (RC), and the mirochan?
S1. Do not clean adapters, remote controls (RCs), and microcans. Please be aware that the component will not be
affected by free A/S in the event of a failure.
A2. Did you use a dishwasher?

S2. The use of dishwashers is not recommended because high water temperatures can deform the product.
A3. Did you use vinegar?
S3. Avoid using vinegar (acidic liquid) as the vibrating plates of the ultrasonic module may corrode and cause
failure.
Q. When using a maze humidifier, water droplets form on the bottom floor.
A. Just like dew on leaves in the morning, moist air comes from touching the cold floor.
S. Put soft cloth on the floor, or reduce the humidity to one level, and use a fine moisturizing cap is
recommended.
Q. My labyrinthine humidifier made my room feel foggy.
A. Is it a good place to insulate and block the air from
S. In the place above, continuous humidification can cause the humidity to rise too high and become foggy.
Too much moisture can cause molds, etc. Please lower the humidity level.
Q. Does the miroccan have a waterproof effect?
A. In the middle of LED lighting, the circular area is treated as a daily water treatment. However, if the water is
dirty, please wipe it immediately.
Q. What kind of water should I use?
A. The labyrinth humidifier is recommended to use clean water (purified water/water) with purified water. In case
of underground water, tap water, limestone, etc. may cause failure.
Q. When using the humidifier, the flame color of the gas stove changes.
A. Is the indoor humidity high and the flame color has changed from blue to red?
S. This is a phenomenon that often occurs on rainy days, which means humidity rises well, so you can use it with

confidence.
Q. Can I use aroma oil?
A. It is not recommended to use aroma oil. Oil may not clean well and cause discoloration and maze
humidification engine failure. In particular, some aromatherapy oils contain plastic emulsifiers that may cause the
product to melt.
Safety precautions
· When using maze humidifier, clean water or bottled water is recommended. You can also use tap water.
· Most countries except Korea and Japan have lime in tap water, which can cause a breakdown. Please use water,
water, etc.
· The maze humidifier boasts a rich amount of humidification. If the usually dry misfortune because he felt that a
lot of family and encourage the humidifier first stage briefly worked as a step 2, 3, please.
· Please be careful, as there may be moisture around the 2nd and 3rd stages of operation for a long time
· In case of Korea and Japan, water pipes age and rust can cause product failure.
· Please remove foreign substances from the tank and install them in a large horizontal area.
· Recommended for use in places where there are no other electronic products or items sensitive to moisture.
· The labyrinth humidifier is inspected according to strict quality standards when manufactured. There may be
water marks due to inspection, but you can use them with confidence since they are new products.
· Be careful to set the amount of spray to "Step 3" or the amount of moisture may cause moisture around the
area due to the strong spray volume.
· Do not place the remote control (RC) and the mirocon on a hot floor.
· Because maze humidifiers perform pre-packaging operational inspection, there may be signs of water on the
floor, scratches, etc. of maze humidification engine, but please use them safely as this product is new.
· Do not clean remote control (RC), mirochan, or adapter.
· The maze humidification engine, newly developed in humidifiers, is designed to generate some heat during
operation. It's normal to operate, so it's safe to use.
· When using a maze humidifier on a cold floor, moisture may cause water droplets on the floor. In this case, it is
good to use a soft cloth so that the air does not come into direct contact with the floor.

· The caregiver or supervisor must be thoroughly managed so that children do not play with them.
· The maze humidifier is left to slide in contact with the floor.
· Do not drag or push when moving the product. Make sure you lift it with both hands.
· Do not touch the power cord with wet hands.
· Do not use the power cord or plug in a damaged condition.
· Do not use near dangerous substances. You may experience an electric shock.
· Be careful not to damage the power cord by bending, tying, or pulling it too hard.
· When filling or emptying the machine, remove the power plug.
· Remove the plug from the outlet to prevent electric shock if it fails.
· When unplugging the power cord, do not hold the cord line and unplug it.
· Connect the humidity engine and regulator first and finally connect the adapter to the outlet. In reverse order,
sparks may occur when combined.
· The maze humidification engine increases the water temperature in the tank, creating a rich amount of
humidification.
