MISA 12810 Manual

28.9.2023
ver. 8.2
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
FOR COMMERCIAL ELECTRIC SAUNA STOVES
12810, 12812, 12815, 12820, 12825, 12830 AND 12840
MANUFACTURER:
MISA OY tel. VAT
Punaportinkatu 15 [phone] FI0162038
54710 LEMI [email protected] Krnro 188.087
FINLAND www.misa.fi Alv rek.

2
Table of contents
TECHNICAL SPECIFICATIONS ............................................................................................................................. 2
SAFETY DISTANCES .......................................................................................................................................... 3
INSTALLATION ................................................................................................................................................. 3
PLACEMENT OF THE STOVE IN THE SAUNA ....................................................................................................... 3
SAUNA VENTILATION ....................................................................................................................................... 3
CONNECTION TO POWER SUPPLY .................................................................................................................... 4
POSITIONING OF THE CONTROL CENTRE, TEMPERATURE CONTROLLERS AND SENSORS ..................................... 4
OPERATION ..................................................................................................................................................... 4
SEMI-ANNUAL MAINTENANCE ......................................................................................................................... 4
WARRANTY ..................................................................................................................................................... 5
SAUNA STOVE STONES .................................................................................................................................... 5
WARNING ....................................................................................................................................................... 5
INSTRUCTIONS FOR FIRST INSTALLATION/SEMI-ANNUAL MAINTENANCE ......................................................... 6
SEMI-ANNUAL MAINTENANCE MEMO .......................................................................................................... 8-9
SPARE PARTS ................................................................................................................................................. 10
WIRING DIAGRAMS ………………………………………………………………………………………………………………………………… 11-18
TECHNICAL SPECIFICATIONS
Misa commercial electric sauna stoves are cost-effective and durable. For more
efficient utilisation of the commercial electric sauna stove, please read these
instructions with care and comply with them.
Stove Power
kW
Voltage Heating
elements
pc
s
/
W
Control
centre
Space
m³
min-max
Width.
cm
Dep.
cm
Heig.
cm
Weight
kg
Stone
quantity
kg
12810
10,2
400V3N~
6
x
1700
13735L
8
-
13
42,0
52,0
8
1,
0
3
6
50
12812 11,9 400V3N~ 7 x 1700 13735L 10 - 15 57,0 52,0 81,0 43 60
12815
15,3
400V3N~
9 x 1700
13735L
13
-
18
5
7,0
52,0
81,0
45
6
0
12820 20,4 400V3N~ 12 x 1700 13750L 18 - 23 72,0 52,0 81,0 54 70
12825
25,5
400V3N~
15
x 1700
13750
L
2
3
-
29
8
7,0
52
,
0
81,0
63
1
00
12830 30,6 400V3N~ 18 x 1700 13750L 28 - 34 102,0 52,0 81,0 72 120
12840
40,8
400V3N~
24 x 1700
13780L
3
4
-
48
13
2
,0
52,0
81,0
91
1
40

3
SAFETY DISTANCES
- to combustible material 15 cm (non-combustible material 5 cm) behind the stove
- to combustible material on either side 15 cm (non-combustible material 5 cm)
- to combustible material in the front 15 cm (non-combustible material 5 cm)
- From the top edge of the stove to the ceiling 130 cm
The vertical safety distance between a guard made of combustible material and the
surface of the stove must be at least 30 cm. If fire protective boards are used, the
minimum distance of the guard from the stove surface is 12 cm.
INSTALLATION
NOTE! Before stove installation, brush some CU copper paste to the threads of the
heating elements and the threads of the nuts (use paste, not spray!). For
instructions, see page 6. For the warranty of the stove to be valid, the first
maintenance upon stove installation must be carried out.
PLACEMENT OF THE STOVE IN THE SAUNA
The stove may not be installed in a floor recess and a closed protective cover may
not be assembled around the stove. When positioning the stove, consider the
safety distances to combustible materials. For the distances, see the nameplate of
the stove and the section “Safety distances” above. The instructions apply to all of
our commercial electric sauna stoves. The stove must be installed as upright as
possible. If necessary, a stove base with adjustable legs is available.
SAUNA VENTILATION
1. Supply air to the sauna is directed on top of the stove. 2. The supply air mixes
with the hot air rising from the stove, is very rich in oxygen and good for the sauna
user. 3. Hot and humid air spreads throughout the sauna. 4. Exhaust takes place
through floor valves while enjoying the sauna. The height from the floor is approx.
15 cm. 5. At the ceiling limit (above the benches), there should be exhaust valves
for hot air removal and drying the sauna after the sauna sessions.

4
CONNECTION TO POWER SUPPLY
Connection works may only be performed by an authorised skilled electrician, in
compliance with valid regulations. For the connection of the stove, only rubber
cables of the type H07RN-F or equivalent must be used. The use of PVC-insulated
cables is prohibited.
At the factory, the sauna stoves have been configured for 400V 3N~ voltage. The
voltage of the heating elements is 230V. Internal connection Y. The sauna stove
must be properly grounded using its grounding terminals.
SILICONE CABLES ARE RECOMMENDED FOR COMMERCIAL ELECTRIC
SAUNA STOVE CONNECTIONS IN SAUNA ROOMS.
POSITIONING OF THE CONTROL CENTRE, TEMPERATURE CONTROLLERS AND
SENSORS
The control centre, temperature controller and sensors are installed according to
the manual of the Logi Control Centre.
OPERATION
These commercial electric sauna stoves are controlled by a separate control centre.
Follow the manual of the control centre when using the sauna stove.
SEMI-ANNUAL MAINTENANCE
Misa commercial electric sauna stoves must undergo semi-annual maintenance
once in 6 months in accordance with the instructions. If the annual maintenance is
neglected, the sauna stove’s warranty expires.

5
WARRANTY
For the warranty of the commercial electric sauna stoves to be valid, the stoves
must have undergone the first installation-related maintenance and regular
maintenance every six months.
In commercial electric sauna stoves:
- Kerkes stove stones need to be used
- only fresh water may be thrown on the stones
- the stove or its surroundings may not be washed with pressure washer
- the Misa ERM control centre must be used to control the stove
The seller/manufacturer is not liable for damages caused by improper installation at
the site or by failure to follow the installation instructions.
In such cases, the company/installer that performed the installation is liable for
damages. IN ANY WARRANTY REPAIR CASES, THE SELLER WILL ONLY
COMPENSATE FOR SPARE PARTS, NOT INSTALLATION WORKS.
SAUNA STOVE STONES
Note! The commercial sauna stove must be pre-heated before the loading of the
stones. This way, any protective grease will burn away from the stove and heating
elements, and unpleasant odours will not stick to the stones.
First, load the round stove stones into both stone troughs, up to the “dorsal fin” of
the stove. Next, place the “tetra” stones on top of the round ones. Only one layer of
“tetra” stones should be laid on top of the round stones, so that the “dorsal fin” is no
longer visible.
Kerkes stove stones need not be washed before first use. We recommend
removing Kerkes stones from the stove and reloading them twice a year. Kerkes
stones can be treated with acid once a year to avoid lime deposits on the stones.
Good air circulation in the stone compartment is essential for efficient heating of the
sauna air and for the service life of heating elements.
WARNING
Using an insufficiently loaded stone compartment creates a fire hazard. An
insufficiently loaded stone compartment is not the same as a loosely loaded stone
compartment. Failure to comply with the specified minimum distances or other
installation requirements can cause a fire hazard. The sauna stove may not be
covered. Never hang combustible objects, such as towels, above the sauna stove
or in its vicinity, even after using the sauna. These will cause a fire hazard if the
sauna stove is switched on without inspecting the sauna first. Covering, short-
circuiting or otherwise restricting the functionality of the thermostat and temperature
limiter is prohibited, as this would create a fire hazard. If these components do not
work normally, the cause of the malfunctions must be identified and fixed before
using the sauna stove.
MANUFACTURER:
MISA OY Tel. VAT
Punaportinkatu 15 [phone] FI01620383
54710 LEMI [email protected] Krnro 188.087
FINLAND www.misa.fi Alv rek.

6
INSTRUCTIONS FOR FIRST INSTALLATION/SEMI-ANNUAL
MAINTENANCE
- Make sure the power supply to the sauna stove has been disconnected from the junction box!
- If necessary, remove the stones from the stove’s stone compartment.
- Lift the empty stove up so that the cable connector box is facing up.
- (In case of semi-annual maintenance, remove the Kerkes stove stones from the stove.)
- Open the sauna stove’s base plate (Photo 1)
- Brush CU-800 copper paste on the threads and mounting nuts, washers and wiring
connections at the ends of each heating element (Photo 2).
- Check the tightness of M4 coupling nuts.
- Reinstall the sauna stove base plate.
WHEN REPLACING HEATING ELEMENTS, THE INSTALLER MUST
APPLY CU-800 COPPER PASTE TO THE THREADS OF THE
ELEMENTS AS DESCRIBED ABOVE.
Photo 1 Photo 2

7
KERKES SAUNA STOVE STONE INSTALLATION INSTRUCTIONS FOR MISA COMMERCIAL
ELECTRIC SAUNA STOVES
 Load Kerkes round stones into the stone troughs of an empty sauna stove
up to the central ridge height (Photo 3)
 Mix large and small Kerkes “tetra” stones and place them on top of the
stove to form a small mound (Photo 4)
Photo 3 Photo 4
Stove Power Ball stone
diameter
Ball stone
weight kg
Small
tetra stone
kg
Big
tetra stone
kg
12810
10,2 kW
60 mm
30
20
12812
1
1
,
9 k
W
60 mm
4
0
20
128
15
15,3 kW
60 mm
40
20
12820
20,4 kW
80 m
m
4
0
30
12825
25,5 kW
80 mm
60
2
0
2
0
12830
30,6 kW
80 mm
80
20
20
12840
40,8 kW
80 mm
80
40
2
0
STONE QUANTITIES PER SAUNA STOVE ARE APPROXIMATE. THE
QUANTITIES ARE CERTAINLY SUFFICIENT FOR THIS SAUNA STOVE.
KERKES SAUNA STOVE STONE MAINTENANCE INSTRUCTIONS
Wash Kerkes sauna stove stones if the stones have become grey due to
calcareous water.
See instructions => www.kerkes.fi/ohjeet
NOTE! Kerkes sauna stove stones should always be dry before heating
the sauna stove. We recommend keeping the heating elements on for
approx. 15 minutes after the last sauna session. This significantly extends
the service life of the stones.
IF THE SAUNA STOVE IS COLD, KEEP WATER AWAY FROM THE
STONES!

8
MAINTENANCE RECORD
SAUNA STOVE SERIAL NUMBER:
COMMISSIONING DATE:
First installation maintenance /
commissioning
Copper paste application
Coupling nut tensioning
muut huoltotyöt:_____________
__________________________
day: mechanic :
Semi-annual maintenance, ½ year
Copper paste application
Coupling nut tensioning
muut huoltotyöt:_____________
__________________________
day: mechanic:
Semi-annual maintenance, 1 year
Copper paste application
Coupling nut tensioning
other maintenance works:
_____________
__________________________
day: mechanic:
Semi-annual maintenance, 1½ year
Copper paste application
Coupling nut tensioning
other maintenance works:
_____________
__________________________
day: mechanic:
Semi-annual maintenance, 2 year
Copper paste application
Coupling nut tensioning
other maintenance works:
_____________
__________________________
day: mechanic :
Semi-annual maintenance, 2½ year
Copper paste application
Coupling nut tensioning
other maintenance works:
_____________
__________________________
day: mechanic:
Semi-annual maintenance, 3 year
Copper paste application
Coupling nut tensioning
other maintenance works:
_____________
__________________________
day: mechanic:
Semi-annual maintenance, 3½ year
Copper paste application
Coupling nut tensioning
other maintenance works:
_____________
__________________________
day: mechanic:
Semi-annual maintenance, 4 year
Copper paste application
Coupling nut tensioning
other maintenance works:
_____________
__________________________
day: mechanic:
Semi-annual maintenance, 4½ year
Copper paste application
Coupling nut tensioning
other maintenance works:
_____________
__________________________
day: mechanic:

9
SELLER: Cihaus Oy, Pintiläntie 44, 53400 Lappeenranta, Finland
p. [phone] [email protected] www.cihaus.fi
MANUFACTURER:
MISA OY Tel. VAT
Punaportinkatu 15 [phone] FI01620383
54710 LEMI [email protected] Krnro 188.087
FINLAND www.misa.fi Alv rek.
Semi-annual maintenance, 5 year
Copper paste application
Coupling nut tensioning
other maintenance works:
_____________
__________________________
day: mechanic:
Semi-annual maintenance, 5½ year
Copper paste application
Coupling nut tensioning
other maintenance works:
_____________
__________________________
day: mechanic:
Semi-annual maintenance, 6 year
Copper paste application
Coupling nut tensioning
other maintenance works:
_____________
__________________________
day: mechanic:
Semi-annual maintenance, 6½ year
Copper paste application
Coupling nut tensioning
other maintenance works:
_____________
__________________________
day: mechanic:
Semi-annual maintenance, 7 year
Copper paste application
Coupling nut tensioning
other maintenance works:
_____________
__________________________
day: mechanic:
Semi-annual maintenance, 7½ year
Copper paste application
Coupling nut tensioning
other maintenance works:
_____________
__________________________
day: mechanic:
Semi-annual maintenance, 8 year
Copper paste application
Coupling nut tensioning
other maintenance works:
_____________
__________________________
day: mechanic:
Semi-annual maintenance, 8½ year
Copper paste application
Coupling nut tensioning
other maintenance works:
_____________
__________________________
day: mechanic:
Semi-annual maintenance, 9 year
Copper paste application
Coupling nut tensioning
other maintenance works:
_____________
__________________________
day: mechanic:
Semi-annual maintenance, 9½ year
Copper paste application
Coupling nut tensioning
other maintenance works:
_____________
__________________________
day: mechanic:

10
SPARE PARTS MISA ERM:
Code Part
VAS1723 Heating element 1,700W/230V for ERM sauna stove
CULIUSKA Copper strip for ERM sauna stove
T1 Temperature sensor with resettable overheating
protection for T1 Logi control centre, without cable
T2 Temperature sensor with fusible overheating protection
for T1 Logi control centre, without cable
43401 Sensor housing
KF11 Connection plate, 4-pole, 6mm²
JOH12810 Cable set ERM 10,2 kW sauna stove
JOH12812 Cable set ERM 11,9 kW sauna stove
JOH12815 Cable set ERM 15,3 kW sauna stove
JOH12820 Cable set ERM 20,4 kW sauna stove
JOH12825 Cable set ERM 25,5 kW sauna stove
JOH12830 Cable set ERM 30,6 kW sauna stove
JOH12840 Cable set ERM 40,8 kW sauna stove
KERKES10 Assorted Kerkes stones ERM 10,2 kW sauna stove
KERKES15 Assorted Kerkes stones ERM 11,9 kW and 15,3 kW
KERKES20 Assorted Kerkes stones ERM 20,4 kW sauna stove
KERKES25 Assorted Kerkes stones ERM 25,5 kW sauna stove
KERKES30 Assorted Kerkes stones ERM 30,6 kW sauna stove
KERKES40 Assorted Kerkes stones ERM 40,8 kW sauna stove
Only the manufacturer’s original spare parts must be used in the stoves
and control centres!
Spare part orders:
Cihaus Oy
p. [phone]
[email protected]

TUOTE NO.12810 10,2kW ERM SÄHKÖKIUAS
654321
NL3L2L1
1
1 SYÖTTÖ KIUKAALLE 400V 3N~
I RYHMÄ 10,2kW
Alv rek.
Krnro 188.087
0162038-3
Y-tunnus
E-mail: [email protected]
Kotipaikka: Lemi
020-710 9399
Telefax
Homepage: www.misa.fi
Int. [phone]
020-710 9390
Puh. (Tel)
FINLAND
54710 LEMI
Punaportinkatu 15
MISA OY

TUOTE NO.12812 11,9kW ERM SÄHKÖKIUAS
7654321
NL3L2L1
11
L1 L2 NL3
1 SYÖTTÖ KIUKAALLE 400V 3N~
I RYHMÄ 5,1kW
II RYHMÄ 6,8kW
Alv rek.
Krnro 188.087
0162038-3
Y-tunnus
E-mail: [email protected]
Kotipaikka: Lemi
020-710 9399
Telefax
Homepage: www.misa.fi
Int. [phone]
020-710 9390
Puh. (Tel)
FINLAND
54710 LEMI
Punaportinkatu 15
MISA OY

8 9
TUOTE NO.12815 15.3kW ERM SÄHKÖKIUAS
7654321
NL3L2L1
11
L1 L2 NL3
1 SYÖTTÖ KIUKAALLE 400V 3N~
I RYHMÄ 5,1kW
II RYHMÄ 10,2kW
Alv rek.
Krnro 188.087
0162038-3
Y-tunnus
E-mail: [email protected]
Kotipaikka: Lemi
020-710 9399
Telefax
Homepage: www.misa.fi
Int. [phone]
020-710 9390
Puh. (Tel)
FINLAND
54710 LEMI
Punaportinkatu 15
MISA OY

10 12118 9
TUOTE NO.12820 20,4kW ERM SÄHKÖKIUAS
7654321
NL3L2L1
11
L1 L2 NL3
1 SYÖTTÖ KIUKAALLE 400V 3N~
I RYHMÄ 10,2kW
II RYHMÄ 10,2kW
Alv rek.
Krnro 188.087
0162038-3
Y-tunnus
E-mail: [email protected]
Kotipaikka: Lemi
020-710 9399
Telefax
Homepage: www.misa.fi
Int. [phone]
020-710 9390
Puh. (Tel)
FINLAND
54710 LEMI
Punaportinkatu 15
MISA OY

10 12118 9
TUOTE NO.12825 25.5kW ERM SÄHKÖKIUAS
7654321
NL3L2L1
11
L1 L2 NL3
14 1513
1 SYÖTTÖ KIUKAALLE 400V 3N~
I RYHMÄ 10,2kW
II RYHMÄ 15,3kW
Piirtänyt MM 3.1.06
Alv rek.
Krnro 188.087
0162038-3
Y-tunnus
E-mail: [email protected]
Kotipaikka: Lemi
020-710 9399
Telefax
Homepage: www.misa.fi
Int. [phone]
020-710 9390
Puh. (Tel)
FINLAND
54710 LEMI
Punaportinkatu 15
MISA OY

17 181613 1514
L3 NL2L1
1 2
L1 L2 L3N
1234567
TUOTE NO.12830 30,6kW ERM SÄHKÖKIUAS
98 11 1210
1 SYÖTTÖ KIUKAALLE 400V 3N~
2 SYÖTTÖ KIUKAALLE 400V 3N~
I RYHMÄ 15,3kW
II RYHMÄ 15,3kW
Alv rek.
Krnro 188.087
0162038-3
Y-tunnus
Kotipaikka: Lemi
020-710 9399
Telefax
Int. [phone]
020-710 9390
Puh. (Tel)
FINLAND
54710 LEMI
Punaportinkatu 15
MISA OY

10 12118 97654321
NL3L2L1
1
L3 NL2L1
1
13 14 15 16 17 18 19 2120 23 2422
MISA OY
Punaportinkatu 15
54710 LEMI
FINLAND
Puh. (Tel)
020-710 9390
Int. [phone]
Homepage: www.misa.fi
Telefax
020-710 9399
Kotipaikka: Lemi
E-mail: [email protected]
Y-tunnus
0162038-3
Krnro 188.087
Alv rek.
II RYHMÄ 20,4kW SYÖTTÖKAAPELI 5x10mm²S
I RYHMÄ 20,4kW SYÖTTÖKAAPELI 5x10mm²S
1 SYÖTTÖ KIUKAALLE 400V 3N~
TUOTE NO.12840 40,8kW ERM SÄHKÖKIUAS
RIVILIITIN KEVI 10mm²
RIVILIITTIMET "L1 L2 L3 N" x2KPL 10mm²
DIN KISKO

10 12118 9
TUOTE NO.12840_4 40,8kW ERM SÄHKÖKIUAS 4-SYÖTTÖÄ
7654321
NL3L2L1
11
L1 L2 NL3 L3 NL2L1
1 1
L1 L2 L3N
13 14 15 16 17 18 19 2120 23 2422
1 SYÖTTÖ KIUKAALLE 400V 3N~
I RYHMÄ 10,2kW
II RYHMÄ 10,2kW
III RYHMÄ 10,2kW
IV RYHMÄ 10,2kW
I II III IV
Alv rek.
Krnro 188.087
0162038-3
Y-tunnus
E-mail: [email protected]
Kotipaikka: Lemi
020-710 9399
Telefax
Homepage: www.misa.fi
Int. [phone]
020-710 9390
Puh. (Tel)
FINLAND
54710 LEMI
Punaportinkatu 15
MISA OY
