Mission LX CONNECT User manual
User's Manual
LX CONNECT
1
Important Safety Instruction
AVIS: RISQUE DE CHOC ELECTRIQUE-NE PAS OUVRIR
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION!
WARNING: SHOCK HAZARD-DO NOT OPEN
This lightning flash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of non-insulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock.
WARNING: To reduce the risk of electric shock, do not
remove the cover (or back) as there are no
user-serviceable parts inside. Refer servicing to qualified
personnel.
This exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance instructions in the literature
accompanying the appliance.
WARNING: Only use attachments/accessories specified
or provided by the manufacturer (such as the
recommended battery - not supplied).
WARNING: The mains plug/appliance coupler/is usedas
disconnection device; the disconnection device shall
remain readily operable.
CAUTION: These servicing instructions are for use by
qualified service personnel only. To reduce the risk of
electric shock, do not perform any servicing other than
that contained in the operating instructions unless you
are qualified to do so.
Do not install this equipment in a confined or built-in
space such as a bookcase or similar unit, and keep well
ventilated in open space. The ventilation should not be
impeded by covering the ventilation openings with items
such as newspaper, table-cloths, curtains etc.
WARNING: To reduce the risk of fire or electric shock, do
not expose this apparatus to rain or moisture. The
apparatus shall not be exposed to dripping or splashing
and ensure that objects filled with liquids, such as vases,
shall not be placed on the apparatus. No naked flame
sources, such as lighted candles, should be placed on the
apparatus.
WARNING: Do not ingest the battery, Chemical Burn
Hazard. This product requires a coin/button cell battery
(not included). If the coin/button cell battery is
swallowed, it can cause severe internal burns in just 2
hours and can lead to death. Keep new and used
batteries away from children. If the battery compartment
does not close securely, stop using the product and keep
it away from children. If you think batteries might have
been swallowed or placed inside any part of the body,
seek immediate medical attention.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or
grounding plug. A grounding plug has two blades and a
third grounding prong. The wide blade or the third
prong is provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
Protect the power cord from being walked on or
pinched particularly at the plugs, convenience
receptacles, and at the point where they exit from the
apparatus.
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power supply cord or plug
is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been
dropped.
Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart or rack is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.
Ground protection terminal.This product
should be connected to a power outlet with
ground protection.
Denmark: Apparatets stikprop skal tilsluttes en
stikkontakt med jord, som giver forbindelse til
stikproppens jord.
Finland: Laite on liitettävä suojakoskettimilla
varustettuun pistorasiaan.
Norway: Apparatet må tilkoples jordet stikkontakt.
Sweden: Apparaten skall anslutas till jordat uttag.
WARNING: No naked flame sources, such as lighted
candles, should be placed on the apparatus.
WARNING: Attention should be drawn to environmental
aspects of battery disposal.
WARNING: Use of the apparatus in tropical climates.
2
No dealer or distributor may vary the terms of this warranty which is personal to the original purchaser and is not
transferable.
Please retain the sales receipt as proof of purchase.
Warranty claims must wherever possible be made through the Dealer from whom the equipment was purchased.
This warranty excludes:
Damage caused through neglect, accident, misuse, wear and tear, or through incorrect installation, adjustment or repair
by unauthorised personnel. Any unauthorised servicing will result in loss of warranty.
Liability for damage or loss occurring in the transit to or from the purchaser.
Consequent damage, loss or injury, arising from or in conjunction with this equipment.
Equipment for attention under warranty should be considered return carriage paid. If equipment is found to comply
with the published specification, Mission reserves the right to raise a charge.
The above conditions do not aect your statutory rights as a consumer.
The Bluetooth® word mark and logos are registered trademarks, owned by Bluetooth SIG, Inc. and any
use of such marks by IAG Group Ltd is under license. Other trademarks and trade names are those of
their respective owners.
WARNING: When an amplifier is driven beyond its power output capabilities it will produce
distorted waveforms which will quickly damage your speakers by overheating. Make sure that your
amplifier is not left unattended when playing, for example at parties, and turn the volume control
down at the first sign of audibledistortion.
aptX® software is copyright CSR plc. or its group companies. All rights reserved.
The aptX® mark and the aptX® logo are trademarks of CSR plc. or one of its group companies and may
be registered in one or more jurisdictions.
Being Roon Tested means that IAG Group Ltd and Roon have collaborated to ensure you have the best
experience using Roon, software and IAG Group Ltd equipment together, so you can just enjoy the music.
Unpacking Your Loudspeaker
Lift the loudspeaker carefully out of the packing. DO NOT try and lift the loudspeaker using the protective bag.
Unpack the accessories carefully.
If there is any sign of damage or if the contents are incomplete, report this to your dealer as soon as possible.
Retain the packing for future safe transport of the product. If you dispose of the packing, do so with respect to any
recycling provisions in your area.
For applicable power supplies see user instructions
3
Welcome to Mission!
General Information
Unpacking The Equipment
Mission is a brand that purveys lifestyle audio that fuses Hi-Fi heritage with contemporary design.
Music is the master, technology is the slave. Always.
Mission LX CONNECT, wireless speaker system couples innovative wireless technology, an award-winning
loudspeaker series and versatile Hi-Fi grade connectivity options for a ‘True Wireless’ speaker system and a new
level of convenience and performance that changes the game for wireless speaker systems.
LX CONNECT oers wireless connectivity via an advanced wireless hub which hosts all of the connectivity
options for your listening pleasure.
The LX CONNECT Hub intelligently transmits left and right audio signals to the appropriate speaker via
uncompressed 5.8GHz wireless audio signal transmission. There is no trailing cable between speakers or hub,
with no need for the speakers to be connected together via a cable, for ‘True Wireless’ audio. The speaker
system is based on the Mission LX-2 MKII speakers, with specially engineered, high-power digital amplification
modules, oering 50w from each cabinet (100w per system).
Following the LX MKII series design and performance, the LX CONNECT Speakers maintain the Mission trademark
‘Inverted Driver Geometry’ design and precision-tuned crossover to yield improved transient attack and
astonishing detail. Mission DiaDrive bass units oer superior control of the low-frequency diaphragm while a
refined high-frequency performance and a re-engineered cabinet bracing system further help create a
loudspeaker system that outperforms its price-class.
The carton contains:
The LX CONNECT Hub
The LX CONNECT Wireless Speakers (2 pieces)
Two IEC mains cable suitable for your area
One power adaptor for the hub
One plug for the adaptor suitable for your area
One remote controller
One user manual and a quick start guide
Please note: The remote control requires 1 x CR2025 type battery. Due to international shipping and courier
regulations with Lithium Ion batteries, the remote controller battery is not included in this package.
Consult the dealer from whom you purchased the equipment if any item is not present. Carefully unpack the unit and
accessories.
Retain the packing materials for future use. Retain the user manual and information concerning the date and place of
purchase of your equipment for future reference. If you transfer the unit to a third party please pass on this instruction
manual along with the equipment.
Please read these instructions carefully before installing your loudspeakers. A few minutes studying this
manual will ensure a superb performance from your loudspeaker for many years. Please attention to all
cautions printed on the pages marked with this symbol.
4
How It Works
USB Drivers & Firmware Updates
To download Windows Drivers for PC USB, please see the separate user guide included with this package.
Any firmware updates will also be available from www.mission.co.uk
Unlike other wireless and active speakers where controls and inputs are often placed awkwardly on the back panel,
Mission engineers have developed a unique hub, which works as the central console for your music. The LX CONNECT
Hub features optical, coaxial, PC USB, AV audio and RCA inputs on the rear panel with an additional Bluetooth aptX
connection for wireless integration of laptops, smart phones and tablet devices. It is controlled gracefully via the touch
sensitive display, or for even more convenience you can use the included remote control. Once connected to your
source, the hub works independently from the speakers using the 5.8GHz wireless frequency band. Place it on your TV
stand, desktop, or wherever you want, without the worry of speaker placement and trailing wires in-between the units.
The only wires needed for the speakers are the supplied power cables.
LX CONNECT Hub will also work as a stand-alone DAC with a built-in headphone output and pre-output. You can
connect it to your amplifier or existing system, for use as a Hi-Fi grade DAC.
The LX CONNECT Speakers and
Hub work wirelessly, completely
independently of each other with
no interconnects.
Change source / volume and
menu parameters with the
included remote.
Connect any Bluetooth device
and enjoy wireless playback with
the aptX codec for CD-like sound
quality.
Mission LX CONNECT Hub via
RCA, optical, coaxial, PC USB and
AV audio connections.
The units communicate between
each other on the 5.8GHz
frequency band for high quality,
lossless playback.
5
Remote Handset
Controls & Functions
1. MUTE Press to mute and unmute the sound
2. STANDBY Press to bring the unit in/out of standby
3. VOL+ Increase volume
4. Press to start/pause Bluetooth/USB
Press to confirm page or setting selected in menu
5. Press to the previous track
Press to move to previous page or setting in menu
6. Press to the next track
Press to move to next page or setting in menu
7. VOL- Decrease volume
8. MENU Press to enter or exit menu
9. DISPLAY Press to cycle through display options
10. Press to select previous source
11. Press to select next source
VOLUME UP
HEADPHONE OUT VOLUME DOWN STANDBY BUTTON
POWER LED
6
Plug each LX CONNECT Speaker in to the mains power supply and turn on the power switch to enter start up mode.
Upon initial power-on, the LED indicator will slowly flash green. This means the speakers are currently not
connected to any LX CONNECT Hub device - you will need to pair the speakers with hub (follow the LX CONNECT
Hub installation section).
After pairing, the LED light will remain illuminated green. After pairing for the first time, you will not need to do this
again when turning the system on or o.
Use the LEFT / MONO / RIGHT switch to assign each speaker’s output channel. LEFT / RIGHT options are designed
for a conventional stereo setup. Alternatively if you are placing the speakers around the room or living area in an
unconventional way, you can set the speakers both to mono if you wish.
The -6dB / 0 / 6dB switch attenuates the bass levels of the speakers. You can use this to adjust the sound to your
personal preference, and may find the bass will need reducing when placed near to a wall.
Please note:
- When the speakers are free standing on suitable stands, use the 0dB or +6dB bass setting
- When the speakers are placed close to a rear wall, use the 0dB setting
- When the speakers are shelf mounted, use the -6dB or 0dB setting
The UPDATE port is only used for updating the internal software or service purposes. This is a non-user serviceable
connection. Please refer to the Mission website or your Mission dealer concerning updates or service.
The PAIR button is used to connects the speakers and hub as a system. If you long press the button until the LED
indicator flashes then the software version will be displayed on the hub screen.
Installing & Operating the LX CONNECT Speakers
POWER /
PAIRING LED
PAIRING
BUTTON
UPDATE
SOCKET
AC INPUT
POWER
SWITCH
BALANCE
SYNC
BASS
SELECTOR
MODE
SELECTOR
7
Connect your playback device via the via the auxiliary, optical, coaxial, PC USB, or AV audio inputs on the rear panel.
Connect the LX CONNECT Hub mains supply.
When powered on, the LX CONNECT Hub indicator light will then illuminate dimly, which means it is now in standby
mode.
Either press the STANDBY button on the unit, or press the STANDBY button on the remote control and the standby
LED will turn on brightly. The screen will then briefly display the Mission logo, confirming the unit is powered on. To
return to standby, press the STANDBY button once more.
To pair the hub with the speakers, press the MENU button on the remote (or touch the MENU button on the unit) to
enter menu setting.
Select the 'Enter Pairing' option. The hub will then display 'Pairing'. Press the PAIR button on the rear of one of the
Mission LX CONNECT Wireless Speakers. The rear LED will change from flashing to staying on constantly once
paired. Display screen will show 'Connected'.
Please note pairing of the speakers needs to be done individually. Once your first speaker is paired, repeat the
process for the second speaker.
To adjust the volume, press the '+' and '-' buttons on the front panel of the hub or remote. Volume is adjustable from
0 to 50. When the system is restarted, the default volume is 25.
The DISPLAY button on the remote control will toggle the front panel display ON/ OFF. When the display is OFF, use
the front panel control or pressing any remote key will momentarily turn on the display. After 10 seconds, the display
will automatically turn o again.
Installing & Operating the LX CONNECT Hub
8
Connections for LX CONNECT Hub
Analogue Input
Connect your analogue sources to the line level input AUX IN.
Coaxial Digital Input
Connect your coaxial digital sources to COAX IN.
Optical Digital Input
Connect your optical digital sources to OPT IN.
The USB input enables you to connect a Mac or PC to the hub for playing audio files stored on a
computer. To use the USB input for the first time, a Windows PC will require the installation of the
USB driver. Download the driver via www.mission.co.uk. Please refer to the USB and DSD Setup Guide
supplied with the driver files. Connect your computer to the hub via USB cable (type A to Type B).
LX CONNECT has Roon Tested. Roon transforms the experience of browsing music; artist photos,
credits, bios, reviews, lyrics, tour dates; and composers are located automatically, then
interconnected by links to build a searchable digital magazine about your music collection. Roon finds
all the same links between your personal files and the millions of tracks available on TIDAL, so you
can start with the music you know, then explore and discover new music from the world beyond your
collection.
Please note: In order to ensure optimum performance of the LX CONNECT system, the LX CONNECT
Hub is limited to 32-bit / 192kHz operation when paired to the LX CONNECT Speakers. When the USB
DAC functionality is utilised for headphone amplifier or pre-out functionality, you can activate higher
resolution performance (DSD256 / 384kHz) by disabling 'Wireless' mode via the LX CONNECT Hub
control menu. This will enable DSD256 / 384kHz operation for headphone amplifier or pre-out
operation only.
USB Input
AV AUDIO function allows you to send audio from your ARC-compliant TV to LX CONNECT
through a single HDMI connection. To enjoy the AV AUDIO function, please ensure your TV is both
HDMI-CEC and ARC compliant and set up accordingly.
Please note: Your TV must support the HDMI-CEC and ARC function. HDMI-CEC and ARC must be
set to on. The configuration method of HDMI-CEC and ARC may dier depending on the brand or
model of your TV. For details about the ARC function, please refer to your TV owner's manual.
Only HDMI 1.4 cables can support the ARC function.
AV AUDIO
When selecting the Bluetooth input, the hub will display 'Pairing' which means the hub is not yet
connected to a Bluetooth device and is searching for one.
To connect, turn on the Bluetooth function on your smartphone, tablet or computer device.
Search for active Bluetooth devices. You will then see LX CONNECT as an option to connect.
Select the LX CONNECT option to pair to device and the hub will then display “Connected” to
confirm.
If you switch to an alternative input Bluetooth will disconnect automatically in 60 seconds,
however when you switch back, Bluetooth will connect automatically to your device once more.
Bluetooth Connection
Pre-Amplifier Output
Pre-amplifier (Pre Out) output for driving external power amplifiers, subwoofers or signal
processors.
A stereo 6.3mm (1/4") jack is provided on the front panel for connecting headphones. When
headphones are connected the Pre Out signal will auto cut o.
Headphone Output
LX CONNECT Hub UPDATE port is only used for updating the internal software or service purposes.
This is a non-user serviceable connection. Please refer to the Mission website or your Mission dealer
concerning updates or service.
Software Update
Menu
9
To access additional controls over the LX CONNECT system either press 'MENU' on your remote or touch the MENU
button on the front panel of the hub. This will give you dierent options: Speakers, Mode, Digital Filter, DSD BW, DPLL
BW, Balance, Pre Delay, Brightness, Default Channel, Auto Standby, Wireless, Pre Out Level, Default Volume, Factory
Reset, Update and Firmware. You can toggle through the dierent options by pressing the '+' or '-' controls on the hub
or left and right controls on the remote. The source button on hub toggles between menu select and the menu
parameter, or you can press the VOL+/VOL+ button on the remote. When you have selected a parameter to adjust,
press the '+'or'-' buttons on the hub, or left and right controls on the remote.
There are two performance modes for the LX CONNECT system:
Music (recommended for listening to music),
Movie (recommended for viewing movies).
Mode
Mode
Music
Mode
Movie
The DAC in the LX CONNECT has a choice of 3 digital filters to oer the best
performance and compatibility with your digital audio files and system:
Fast roll o: Standard flat response with fast frequency roll of above Fs/2
(half the sampling frequency).
Slow roll o: Starts rolling of at a lower frequency than the Fast filter but has
a more gentle rate of attenuation. This is the default filter for the LX
CONNECT Hub.
Minimum phase: Has a gentle attenuation slope similar to the Slow filter but
with minimum phase characteristics. It can be likened to an analogue filter
applied in the digital domain.
Digital Filter (DAC, Only for Pre Out) Digital Filter
slowrolloff
Digital Filter
Minimumphase
Digital Filter
fastrolloff
The DSD Bandwidth can be widened to suit high performance Hi-Fi
equipment and particular DSD audio files.
DSD BW DSD BW
Normal
OPT DPLL BW
Normal
OPT DPLL BW
Wide
DSD BW
50K
DSD BW
60K
DSD BW
70K
DPLL setting is used for changing the bandwidth of the digital phase lock
loop of the D/A converter to accommodate dierent levels of jitter on the
incoming SPDIF signal.
Normal mode should be selected for signals with low jitter, while Wide mode
should be selected for signals with abnormal jitter. For best audio quality
leave this setting at the default value Normal, only use Wide for a given input
if the system is having problems locking onto the source.
OPT DPLL BW
Balance
3.0dBL+ -R
Balance
3.0dBL+ -R
Balance
0.0dBL R
Balance of left and right channels can be adjusted in the hub's menu. The
setting is for all the speakers and Pre Out. The Balance setting ON/OFF can be
controlled by the BALANCE SYNC button on the rear panel of each speaker.
Balance
Pre Out delay time setting have 0ms, 20ms, 40ms, 60ms, 80ms and 100ms. If
the Pre Out to be used for a wired and powered subwoofer, please use 20ms
to sync with the wireless speakers to get the best performance.
Pre Delay PreDelay
0 ms
PreDelay
20ms (sub)
The brightness can be adjusted from a low level to a bright level, adjustable in
8 increments.
Brightness Brightness
Level1
Brightness
Level8
10
Default volume setting is for the max volume after you restart the system. The
default setting is 25, adjustable in 0 to 50.
Default Volume Default Volume
25
The final menu option displays the current firmware installed on the LX
CONNECT.
Firmware Firmware
HUB: 052.10
The LX CONNECT Hub UPDATE port is only used for updating the internal
software or service purposes. This is a non-user serviceable connection.
Please refer to the Mission website or your Mission dealer concerning updates
or service.
Update Update
No
Update
Yes
The LX CONNECT can be restored to factory default settings.
Factory Reset Factory Reset
No
Factory Reset
Yes
The Pre Out level can be set to adjustable or fixed.
Adjustable level output is for purposes where the output level should change
with the master level output (for instance, when connecting to powered
subwoofers).
Fixed level output is for use with sources with built-in volume control such as
AV processors, where the input signal from the hub should be constant.
Pre Out Level Pre Out Level
Adjustable
Pre Out Level
Fixed
LX CONNECT Hub can enable or disable the wireless transfer function on the
menu. While only using the hub as DAC (without speakers), please disable the
wireless to get the best performance.
Wireless Wireless
Enable
Wireless
Disable
LX CONNECT has three standby modes, editable via the menu.
Auto Standby Never: LX CONNECT will only enter standby through user
control.
Auto Standby 20 Minutes: If there is no input signal for 20 minutes, the
LX CONNECT will enter standby.
Auto Standby 1 Hour: If there is no input signal for 1 hour, the LX CONNECT
will enter standby.
Auto Standby Auto Standby
Never
Auto Standby
1 Hour
Auto Standby
20 Minutes
Any channel can be set as the default channel. Additionally, this can be set,
using the 'Recall Last Input' feature.
Default Channel Default Channel
USB
Default Channel
Recall Last Input
11
Specifications
Model
General Description
Design Philosophy And Core Technology
Analogue Input
Digital Input
Analogue Output
Pre Amplifier (hub)
Input Sensitivity
Input Impedance
Variable Output Voltage
Output Impedance
Frequency Response
Signal-to-noise Ratio (S/N)
Total Harmonic Distortion
Sampling Rate
Digital Filters
Active Speakers
Enclosure Type
Transducer Complement
Drive Unit
Bass Unit
Treble Unit
AV Shielded
Rated Power Output
Peak Power Output
Peak SPL
Frequency Response (+/-3dB)
Bass Extension (-6dB)
Crossover Frequency
Wireless Reception Distance
Cabinet Volume
Dimensions
Height (on feet)
Width
Depth (with terminals)
System
Carton Size
Net Weight
Gross Weight
Finish
Power Requirements
LX CONNECT
Wireless Speaker System
5.8GHz Wireless Uncompressed Technology
DAC ESS Sabre 9018
Support Music And Movie Mode
Headphone Amplifier
Support USB Upgrade
Pre Delay Setting
Roon Tested
Touch Control
RCA (AUX)
OPT, COAX, PC USB, Bluetooth, AV Audio
RCA Pre Out
300mV (AUX IN, volume = MAX)
13K (AUX IN)
0 – 3.2V
100 ohm
20Hz-20kHz (+/-0.3dB)
> 100dB (AUX IN, A-weighted)
> 110dB (digital Inputs, A-weighted)
< 0.001% (digital sources )
< 0.005% (analogue sources)
24bit - 192kHz (OPT, COAX)
32bit - 384kHz (USB, PCM)
2.8M for DSD64, 5.6M for DSD128, 11.2M for DSD256 (USB, DSD)
Fast Roll-o, Slow Roll-o, Minimum Phase
Bass Reflex
2-way
130mm Composite Fibre Cone
25mm Microfibre Dome
No
60W
100W
99dB
58Hz – 20kHz
52Hz
3.2kHz
20m
8.2L
Speaker Hub
305mm 55mm
200mm 225mm
(250+15)mm 231mm
545 x 440 x 400mm
6.55kg x 2 (speakers)
1.75kg (hub)
17.8kg
Walnut Pearl / Delux White / Delux Black (speakers); Black (hub)
Hub Adapter - Input: 100-240Vac (50/60Hz) Output: 12V 1A
Speakers - Input: 100-240Vac (50/60Hz)
Service Centre
Should a fault occur with your loudspeakers, please pack it correctly, using the original packing, so you can ship it
safely. Product for service should be returned to the appointed dealer from whom you purchased the product. If you
experience difficulties or there is no mission dealer in your area, contact the Mission distributor or the office below.
UK
IAG Service Dept, 13/14 Glebe Road, Huntingdon, Cambridgeshire PE 29 7DL, UK
Tel: +44 0 1480 452 561
Email: [email protected]
12
IAG House, 13/14 Glebe Road, Huntingdon, Cambridgeshire, PE29 7DL, UK
Tel: +44(0)1480 452561 Email: [email protected] www.mission.co.uk
IAG reserves the right to alter the design and specifications without notice. All rights reserved © IAG Group Ltd.
Mission is a member of the International Audio Group.
Table of contents
