Introduction
Thank you for purchasing this Mitex two-way radio, a
truly professional and durable radio that will provide
reliable, high quality communication, even under
harsh and demanding conditions. Before operation
and to obtain the best performance please read this
manual carefully to become familiar with the radios
features and uses.

i
ii
Contents Contents
1 Safety Information ...........................................
2 Supplied Accessories .....................................
3 Battery Information .........................................
■ Caution ..................................................................
■ Battery Charging ...................................................
4 Accessories Installation .................................
1
2
3
3
3
4-6
■
Key Assignment..................................................... 11
■Time-out Timer(TOT) {set by Mitex}.......................... 11
■VOX Function {set by Mitex}.................................... 11
■Battery Save ......................................................... 11
■Low Battery Alert ................................................... 12
7 Troubleshooting and Maintenance...................... 13
■ Installing and Removing the BatteryPack ............ 4 ■ Troubleshooting ......................................................
13
■Installing/Removing the Antenna ..........................
5
■ Maintenance and Cleaning .....................................
13
■ Installing an Earpiece ..........................................
6
8 Specifications ....................................................
14
■Installing/Removing the Belt Clip ..........................
6
9 Sub-tone Table ...................................................
15
5
Getting Acquainted ..........................................
7
10 Channel Table …………… ......................................
16
■ Radio Diagram ......................................................
7
11 CE Declaration ....................................................
14
6
Function and Operation .................................
8-12
12 Warranty and Service ........................................
15
■ Power ON/OFF ....................................................
8
■ Channel Selection ................................................
8
■ Volume Adjustment ..............................................
8
■ Emergency Alarm ................................................
8
■ Receiving .............................................................
9
■ Transmitting .........................................................
9
■ TDR(Dual Standby) .............................................
9
■ Scan Function ......................................................
10
■ CTCSS/DCS ........................................................
10

1
2
Safety Information
Please read the following information carefully to become familiar with
your new Mitex two-way radio:
Do not attempt to repair, disassemble or re-assemble the radio.
Repair should only be carried out by a qualified RadioEngineer.
In order to avoid electromagnetic interference, please turn off the
radio in any areas where radio transmissions are not permittede.g.
Hospitals, Aircraft, etc.
Do not place a radio in any area over, or in the deployment area of
an Air Bag within a vehicle.
Never operate the radio in potentially flammable and explosive
atmospheres.
Never replace or charge batteries in potentially flammable and
explosiveatmospheres.
Do not operate the radio if its antenna isdamaged.
Do not expose the radio to long periods of direct sunlight, for
example on the dashboard of a vehicle or close to heating
appliances.
When using your radio, try to keep it vertical and at a distance of
5~10cm from your mouth.
Keep a distance of at least 2.5cm between the antenna and your
head and body whentransmitting.
Supplied Accessories
Please open the box carefully and check that the following items are
included. If you find any items are missing or have been damaged
during shipment, please contact your Mitex dealerimmediately.
Equipment and Accessories Supplied:
ITEM
QUANTITY
Two-way RadioBody
X2
Li-Ion Battery
X2
AC Adaptor
X2
Intelligent Charger Pod
X2
Antenna
X2
Wrist Strap
X2
Belt Clip
X2
User Manual & License application
x1

3
4
Battery Information
■ Caution
In order to avoid damage to the battery, only use the Mitex
charger provided. The supplied charger is an ‘intelligent’
charger and has automatic and overload-protect functions
builtin.
Do not short-circuit the battery pack or dispose of it in a fire.
The optimal charging temperature is between 10°C and 35°C.
When charging in temperatures below 10°C there may be a
leakage of electrolyte which will damage the battery. If charging
above 35°C, battery performance will bereduced.
■ Battery Charging
Connect the AC adaptor to the charger. The red LED will light.
Place the battery or the radio (switched off) with battery attached
into thecharger (check that the battery is properly in place). The
red light will begin to flash –indicating that charging is in progress.
The LED will turn green when the battery is fullycharged.
(see illustration1)
illustration
Accessories Installation
■ Installing and Removing the Battery Pack
Place the rechargeable battery pack onto the back of the radio. (It will
only fit in one way). Snap the battery pack into place until you hear a
click. Check that the battery pack fits tightly in place against the body
of the radio. (See illustration2)
Illustration
Toremove the battery pack, make sure the radio is off first, then pull
back on the release catch and lift the battery pack from the body of
the radio. (See illustration3)
Illustration

5
6
illustration
■ Installing/Removing the Antenna
Screw the antenna into the connector on the top of thetransceiver
by holding the antenna at its base and turning it clockwise until
secure. (See illustration4)
Toremove the antenna, hold the antenna at its base and turn it
counter-clockwise until it is released. (See illustration5)
■ Installing the Earpiece
First with the radio switched off release
the Speak/microphone cover then insert
the speaker/microphone plugs into the
SP/MICjacks. Reverse the above, radio
off to remove
(See illustration6)
■ Installing/Removing the Belt Clip
Attach the belt clip using the two supplied screws.
(See illustration7)
Toremove the belt clip, release the screws on the belt
clip. (See illustration8)
illustration4 illustration5
illustration illustration
Accessories Installation
Accessories Installation

7
8
Getting Acquainted
■ Radio Diagram
Antenna
Speaker
Microphone
Sub-PTT
(For TDRChannel)
PTT
(For Current Channel)
Side Key
Channel knob
Power switch/volume control
LED
SP/MIC jack
Rubber Cover
Battery pack
Charging Pole
Battery
release clip
Function and Operation
■ Power ON/OFF
Turn the On/Off/Volume knob clockwise to switch the radio ON.
Turn the On/Off/Volume knob counter-clockwise to switch theradio
OFF.
■ Channel Selection
Rotate the channel knob to select the required
channel.
■ Volume Adjustment
Rotate the Volume knob to adjust the volume, clockwise to increase
the volume and counter-clockwise to decreaseit.
If your dealer programmed Monitor onto the side
key, you can press the Monitor key to hear
background noise while adjusting the volume
level.
■ Emergency Alarm
Toactivate emergency alarm, short press or long press side key for
0.5-2.5 seconds until the transceiver emits alarm. Repeat the
procedure or re-power the transceiver to exitthealarm.

9
10
Function and Operation Function and Operation
■ Receiving
When radios receive any signal, the LED indicator will turn green. You
can hear the call if the tone is correct.
Note: If the transceiver is set to a higher squelch level, it may fail to
hear the call. If the LED indicator turns green but you cannot hear the
call, it means the signal has a matching carrier butdoes not have a
matching CTCSS/DCS code.
■ Transmitting
Hold【PTT】or 【Sub-PTT】to start transmitting. Please hold the
Scan Function
Turn the channel selector knob fully clockwise to reach channel16.
The radio will then begin to scan. When a busy channel is found,
the radio will remain in scan mode for 5 seconds after the transmit-
ion has ended. Toend the scan, rotate the channel selector to any
channel between 1 and15.
There are two kinds of scan modes: ordinary scan and priority scan
(a programmablesetting)
1.Ordinary scan
microphone approximately 2.5~5.0cm from your mouth, and then
speak into the microphone in your normal voice.
CH1 → CH2 → CH3 → → CH16
Note: The LED indicator will turnred whentransmitting,release PTT to
standbyor receivecalls.
2.Priority scan: provided that priority scan channel is set to Channel
3, the scan sequence is as follows:
■ TDR(Dual Standby) CH1 → CH3 → CH2 → CH3 → → CH16
■ CTCSS/DCS
Allows the user to select a specific CTCSS/DCS code per channel
–set by Mitex
Set by Mitex

11
12
Function and Operation Function and Operation
■ Key Assignment
The side key is assigned to the following function by the
programming and you can select “short press” or “Long press”.
Short press: Monitor
Long press: Monitor
■ Time-out Timer(TOT)
The feature allows for more efficient use of channels by limiting the
maximum time of each transmission. Once a continuous transmission
exceeds the preset time (programmed by your dealer), the radio will
automatically stop transmitting and sound a warning tone until the PTT
is released.
■ VOX Function
If this function is enabled, VOX will automatically transmit
(without pressing the PTT button) when the audio level is
higher than the configured VOX Gain Level. You must
connect a headset to the transceiver to use the VOX
function. The VOX function does not activate when a
headset is not connected to the accessory terminal of the
transceiver. Depending on the configuration of the VOX
GainLevel and the volume of your voice, the first part of
your voice may not be transmitted. If a headset is
connected to the transceiver while the VOX function is
switched ON and the VOX Gain Level is configured to a
higher, more sensitive level, louder received signal may
cause the transceiver to start transmission. SET TO VOX
OFF AS STANDARD -
■ Battery Save
If this function is programmed by your dealer, Battery Save will be
automatically activated once no activity on the channel or no operation is
performed (no key pressing or any knob selection).
Pressing any key or receiving a signal will restore the radio to normal
operation and exit Battery Save mode.
■ Low Battery Alert
The red LED flashes and the radio sounds every 30 seconds, to alert the
user to recharge the battery or replace it with a fresh one when the battery
power runs low.

13
14
Troubleshooting andMaintenance
■ Troubleshooting
Specifications
Problem
Solution
The transceiver does
not work when
switched on.
The battery is low. Please recharge the
battery pack and make sure the battery pack
is properly fitted or insert a fresh battery, refit
it if necessary. Swap the battery onto
another radio to check if one is available.
The battery runs out in
a short time.
The battery is no longer in good condition
and needs to be replaced with a newone.
The radio can’t
communicate with other
units in the same user
group.
The radio is out of usable range, is not on
the same channel, is not of the same model
type, or the CTCSS/DCS settings and/or
frequencies are incorrect and do not match.
The radio receives
unwanted
transmissions from
other radio users.
Change the channel of all the radios in the
required group to a quiet channel.
■ Maintenance and Cleaning
Do not carry the transceiver by the antenna or attached audio
accessories. Always turn the transceiver OFF when attaching or
detaching audio accessories. Clean the buttons, control knob and
radio body with a dry cloth when it has been unused for a longtime
or becomes dirty.
All stated specifications are subject to change without notice or obligation.
General
Frequency range
400-470MHz (Set by Mitex)
Channel capacity
16CH
Channel spacing
25Hz/12.5Hz (Set by Mitex)
Channel step
5/6.25/10/15/20/25KHz (Set by Mitex)
Operating voltage
7.2V DC ±10%
Battery capacity
Li-lon battery1500mAh
14/2 hours according to5-5-90
Operating temperature
-20°C to + 60°C
Frequency stability
±2.5ppm (-20°C to + 60°C)
Antenna impedance
50 Ω
Dimensions
53x28x116mm (excludeprojection)
Weight
about 216g (including battery andantenna)
Transmitting
Frequency error
≤5×10-6
RF poweroutput
≤5W
Audio distortion
≤5%
Modulation
±3dB
Adjacent channel power
SpuriousRFemissions
≥65dB
≤7.5μW
Usedbandwidth
≤16KHz
Receiving
Frequency sensitivity
12dB(SINAD)0.18μV
Audio distortion
≤5%
Common-channelrestraint
≥-8dB
Adjacent-channel selectivity
≥55 dB
Inter-modulation distortion
≥55 dB
Spurious response
≥55 dB
Jam-up
≥85 dB

15
16
Sub-tone Table Channel Table
50 Groups CTCSS
110 Groups DCS(N/I)
67.0
85.4
107.2
136.5
165.5
186.2
210.7
254.1
69.3
88.5
110.9
141.3
167.9
189.9
218.1
71.9
91.5
114.8
146.2
171.3
192.8
225.7
74.4
94.8
118.8
151.4
173.8
196.6
229.1
77.0
97.4
123.0
156.7
177.3
199.5
233.6
79.7
100.0
127.3
159.8
179.9
203.5
241.8
82.5
103.5
131.8
162.2
183.5
206.5
250.3
THE MITEX RADIO UHF FAMILY
CHANNEL
GENERAL/
GENERALX
SECURITY
SITE
1
Dedicated
General
Dedicated
Security
Dedicated
Site
2
3
4
5
6
7
8
9
10
11
12
13
Channels 13, 14 & 15 are common to all
Mitex UHF Transceivers
14
15
16
SCAN
SCAN
SCAN
017
053
122
165
246
311
371
455
546
664
023
054
125
172
251
315
411
462
565
703
025
065
131
174
252
325
412
464
606
712
026
071
132
205
255
331
413
465
612
723
031
072
134
212
261
332
423
466
624
731
032
073
143
223
263
343
431
503
627
732
036
074
145
225
265
346
432
506
631
734
043
077
152
226
266
351
445
516
632
743
047
114
155
243
271
356
446
523
645
754
050
115
156
244
274
364
452
526
654
760
051
116
162
245
306
365
454
532
662
765

15
16
CE Declaration
CE Declaration
CE version of the Mitex General which
display the CE symbol on the product
label, complies with the essential
requirements of the European Radio and
Telecommunications Terminal Directive
1999/5/CE.
Warranty and Service
Our warranty applies only to the purchaser if the radio has been properly used and maintained.
This warranty applies in lieu of any other warranty or guarantee expressed or implied and
variations of its terms are not authorized without express written consent from Mitex (UK) Ltd.
This Warranty will be effective unless you can produce upon request a dated receipt or invoice to
verify your proof of purchase within 12 months period. This Warranty is an additional benefit and
does not effect your statutory rights.
Conditions of Warranty
Mitex (UK) Ltd warrants this transceiver for 1 year to the customer (excluding Lithium battery pack
and other accessories) to be free from defects in materials and craftsmanship. Mitex (UK) Ltd
warrants for 6 months to the customer the lithium battery pack to be free from defects in materials
and craftsmanship. Please refer to the warranty information below or visit www.mitex.co.uk
Warranty Policy
We warrant this equipment against defects in material or workmanship, with the exception of
batteries and accessories, for a period of one year from the date of original purchase.
This warranty is limited to repair or replacement of defective parts only and is not valid if the
equipment has been tampered with, misused or damaged.
If service or repair is required within the warranty period, repair will be made free of charge by
Mitex (UK) Ltd only. If the owner requires any service or repair by anyone other than Mitex (UK)
Ltd, the repair/service cost must be paid by the owner and any such service or repair may
invalidate this warranty.
This warranty is valid if the enclosed card is properly filled in and returned to Mitex (UK) Ltd within
Ten days from the date of purchase and is limited to the terms and conditions contained herein.
Mitex (UK) Ltd retains the right to make changes or modifications without any notice or obligation
to the owner of this equipment.
Mitex (UK) Ltd
www.mitex.co.uk
This warning symbol indicates that this
equipment operates in non-harmonised
frequency bands and/ or may be subject
to licensing conditions in the country of
use. Be sure to check that you have the
correct programming of this radio, to
comply with your national licensing
requirements.
The European Union (EU) Waste of
Electrical and Electronic Equipment
(WEEE) directive requires that products
sold into the EU must have the crossed
trash bin label on the product or
packaging. This label means that end
users should not dispose of such goods in
household waste. Customers should
contact their local recycling center for
safe treatment or return the product to
Mitex (UK) Ltd for recycling.
This manual is special for transceiver Mitex General Xtreme
