Air-Conditioners
SLZ-KA25, KA35, KA50VAQ(2)
KA25, KA35, KA50VAL(2)
INSTALLATION MANUAL
For safe and correct use, please read this manual and the outdoor unit installation manual thoroughly before install-
ing the air-conditioner unit.
РУКОВОДСТВО ПО УСТАНОВКЕ
Для обеспечения безопасной и надлежащей эксплуатации внимательно прочтите данное руководство и руко-
водство по установке наружного прибора перед установкой кондиционера.
INSTALLATIONSHANDBUCH
Aus Sicherheitsgründen und zur richtigen Anwendung vor Installation der Klimaanlage die vorliegende Bedienungs-
anleitung und das Installationshandbuch gründlich durchlesen.
MANUEL D’INSTALLATION
Avant d’installer le climatiseur, lire attentivement ce manuel, ainsi que le manuel d’installation de l’appareil extérieur
pour une utilisation sûre et correct.
INSTALLATIEHANDLEIDING
Lees deze handleiding en de installatiehandleiding van het buitenapparaat zorgvuldig door voordat u met het instal-
leren van de airconditioner begint.
MANUAL DE INSTALACIÓN
Para un uso seguro y correcto, lea detalladamente este manual de instalación antes de montar la unidad de aire
acondicionado.
MANUALE DI INSTALLAZIONE
Per un uso sicuro e corretto, prima di installare il condizionatore d’aria leggere attentamente il presente manuale ed
il manuale d’installazione dell’unità esterna.
EΓΧEIPIΔIO OΔHΓIΩN EΓKATAΣTAΣHΣ
Για σωστή και ασφαλή χρήση, διαβάστε προσεκτικά αυτό το εγχειρίδιο, καθώς και το εγχειρίδιο εγκατάστασης της
εξωτερικής μονάδας, πριν από την εγκατάσταση της μονάδας κλιματιστικού.
MANUAL DE INSTALAÇÃO
Para uma utilização segura e correcta, leia atentamente este manual e o manual de instalação da unidade exterior
antes de instalar o aparelho de ar condicionado.
INSTALLATIONSMANUAL
Läs bruksanvisningen och utomhusenhetens installationshandbok noga innan luftkonditioneringen installeras så att
den används på ett säkert och korrekt sätt.
Русский
English
Deutsch
Français
Nederlands
Español
Italiano
Eλληνικά
Português
Svenska
BG79U788H04_cover.indd 1 2012/08/27 (月) 午前 8:50:35

2
Contents
1. Safety precautions.....................................................................................2
2. Selecting the installation location ..............................................................2
3. Installation diagram ...................................................................................3
4. Installing the indoor unit ............................................................................3
5. Refrigerant piping work .............................................................................5
6. Drainage piping work.................................................................................6
7. Electrical work ...........................................................................................7
8. Installing the grille....................................................................................10
9. Test run....................................................................................................12
1. Safety precautions
• Be sure to read “Safety precautions” before installing the air conditioner.
• Besuretoobservethecautionsspeciedhereastheyincludeimportant
itemsrelatedtosafety.
• Theindicationsandmeaningsareasfollows.
Warning:
Could lead to death, serious injury, etc.
Caution:
Couldleadtoseriousinjuryinparticularenvironmentswhenoperatedincor-
rectly.
• Afterreadingthismanual,besuretokeepittogetherwiththeinstruction
manualinahandyplaceonthecustomer’ssite.
: Indicates a part which must be grounded.
Warning:
Carefullyreadthelabelsafxedtothemainunit.
Warning:
• Donotinstallitbyyourself(customer).
 Incompleteinstallationcouldcauseinjuryduetore,electricshock,theunit
fallingorleakageofwater.Consultthedealerfromwhomyoupurchasedthe
unit or special installer.
• Installtheunitsecurelyinaplacewhichcanbeartheweightoftheunit.
 Wheninstalled inan insufcientstrong place, theunit couldfall causing
injured.
• Usethespeciedwirestoconnecttheindoorandoutdoorunitssecurelyand
attachthewiresrmlytotheterminalboardconnectingsectionssothestress
ofthewiresisnotappliedtothesections.
 Incompleteconnectingandxingcouldcausere.
• Donotuseintermediateconnectionofthepowercordortheextensioncord
anddonotconnectmanydevicestooneACoutlet.
 Itcouldcauseareoranelectricshockduetodefectivecontact,defective
insulation,exceedingthepermissiblecurrent,etc.
• Checkthattherefrigerantgasdoesnotleakafterinstallationhascompleted.
• Performtheinstallationsecurelyreferringtotheinstallationmanual.
 Incomplete installation could cause a personal injury due to re, electric
shock,theunitfallingorleakageofwater.
• Performelectricalworkaccordingtotheinstallationmanualandbesureto
useanexclusivecircuit.
 Ifthecapacityofthepowercircuitisinsufcientorthereisincompleteelectri-
calwork,itcouldresultinareoranelectricshock.
• Attach the electrical part cover to the indoor unit and the service panel to the
outdoor unit securely.
If the electrical part cover in the indoor unit and/or the service panel in the
outdoorunitarenotattachedsecurely,itcouldresultinareoranelectric
shockduetodust,water,etc.
• Besuretousethepartprovidedorspeciedpartsfortheinstallationwork.
 Theuseofdefectivepartscouldcauseaninjuryorleakageofwaterduetoa
re,anelectricshock,theunitfalling,etc.
• Ventilatetheroomifrefrigerantleaksduringoperation.
 Ifthe refrigerant comesin contactwith aame, poisonousgases willbe
released.
• When installing or relocating, or servicing the air conditioner, use only the
speciedrefrigerant(R410A)tochargetherefrigerantlines.Donotmixitwith
anyotherrefrigerantanddonotallowairtoremaininthelines.
 Ifairismixedwiththerefrigerant,thenitcanbethecauseofabnormalhighpres-
sureintherefrigerantline,andmayresultinanexplosionandotherhazards.
 Theuseofanyrefrigerantotherthanthatspeciedforthesystemwillcause
mechanicalfailureor systemmalfunctionorunit breakdown.Intheworst
case,thiscouldleadtoaseriousimpedimenttosecuringproductsafety.
Caution:
• Performgrounding.
 Donotconnectthegroundwiretoagaspipe,waterpipearresterortelephone
groundwire.Defectivegroundingcouldcauseanelectricshock.
• Donotinstalltheunitinaplacewhereaninammablegasleaks.
 Ifgasleaksandaccumulatesintheareasurroundingtheunit,itcouldcause
anexplosion.
• Installagroundleakagebreakerdependingontheinstallationplace(where
itishumid).
 If aground leakagebreaker isnot installed,it couldcause anelectric
shock.
• Performthe drainage/piping worksecurely accordingto theinstallation
manual.
 Ifthereisadefectinthedrainage/pipingwork,watercoulddropfromtheunit
andhouseholdgoodscouldbewetanddamaged.
• Fastenaarenutwithatorquewrenchasspeciedinthismanual.
 Whenfastenedtootight,aarenutmaybrokenafteralongperiodandcause
aleakageofrefrigerant.
2. Selecting the installation location
2.1. Indoor unit
• Whereairowisnotblocked.
• Where cool air spreads over the entire room.
• Where it is not exposed to direct sunshine.
• At a distance 1 m or more away from your TV and radio (to prevent picture from
being distorted or noise from being generated).
• Inaplaceasfarawayaspossiblefromuorescentandincandescentlights(sothe
infrared remote control can operate the air conditioner normally).
• Wheretheairltercanberemovedandreplacedeasily.
Warning:
Mounttheindoorunitintoaceilingstrongenoughtowithstandtheweightof
the unit.
2.2. Wirelessremotecontrollermounting
 (ForSLZ-KA·VAL(2))
• Place of mounting
• Where it is easy to operate and easily visible.
• Where children can not touch.
• Mounting
 Selectapositionabout1.2mabovetheoor,checkthatsignalsfromtheremote
controller are surely received by the indoor unit from that position (‘beep’ or ‘beep-
beep’receivingtonesounds).Afterthat,attachremotecontrollerholdertoapillar
or wall and set the wireless remote controller.
Inroomswhereinverter typeuorescentlampsareused,thesignal fromthe
wireless remote controller may not be received.
Note:
Thephrase“Wiredremotecontroller”inthisinstallationmanualrefersonlytothePAR-21MAA.Ifyouneedanyinformationfortheotherremotecontroller,
pleaserefertoeithertheinstallationmanualorinitialsettingmanualwhichareincludedintheseboxes.
BG79U788H04_en.indd 2 2012/08/27 (月) 午前 8:51:06

3
3. Installationdiagram
3.1. Indoorunit(Fig.3-1)
ACeiling
BGrille
CObstacle
DMin. 1000 mm
EMin. 500 mm (Entire periphery)
If setting the maintenance space for E,besuretoleaveisaminimumof700mm.
Warning:
Mounttheindoorunitonaceilingstrongenoughtowithstandtheweightof
the unit.
3.2. Outdoor unit
Refer to the outdoor unit installation manual.
(mm)
Fig. 3-1
Fig.4-1
4. Installingtheindoorunit
4.2. Ceilingopeningsandsuspensionboltinstallation
locations(Fig.4-2)
• Using the installation template (top of the package) and the gauge (supplied as an
accessorywiththegrille),makeanopeningintheceilingsothatthemainunitcan
be installed as shown in the diagram. (The method for using the template and the
gauge are shown.)
* Before using, check the dimensions of template and gauge, because they
changeduetouctuationsoftemperatureandhumidity.
* The dimensions of ceiling opening can be regulated within the range shown in
followingdiagram;socenterthemainunitagainsttheopeningofceiling,en-
suring that the respective opposite sides on all sides of the clearance between
them becomes identical.
• Use M10 (3/8") suspension bolts.
* Suspensionboltsaretobeprocuredattheeld.
• Installsecurely,ensuringthatthereisnoclearancebetweentheceilingpanel&
grille,andbetweenthemainunit&grille.
AOuter side of main unit
BBolt pitch
CCeiling opening
DOuter side of Grille
EGrille
FCeiling
GMin. 500 mm (Entire periphery)
If setting the maintenance space for G,be
sure to leave is a minimum of 700 mm.
HMaintenance space
IFresh air intake
JAngle
KElectric component box
* Notethatthespacebetweenceilingpaneloftheunitandceilingslab,etc.,mustbe10to15
mm to be left.
* Leave the maintenance space at the electric component box end.
Fig.4-2
(mm)
23520
650
650





12
34
6
5
78
0
9
A
4.1. Checktheindoorunitaccessories(Fig.4-1)
The indoor unit should be supplied with the following accessories.
Accessory name Q’ty
1Installation template 1
2Washers (with insulation)
Washers (without insulation)
4
4
3
Pipe cover (for refrigerant piping joint)
small diameter (liquid)
large diameter (gas)
1
1
4Band (large)
Band (small)
6
2
5Screw with washer (M5 ×25) for mounting grille 4
6Drain socket 1
7Insulation 1
8Fixing screw for 93.5 ×16 (Black) (for SLZ-KA·VAL(2)) 2
9Remote controller holder (for SLZ-KA·VAL(2)) 1
0Battely (AAA) (for SLZ-KA·VAL(2)) 2
1Wireless remote controller (for SLZ-KA·VAL(2)) 1
BG79U788H04_en.indd 3 2012/08/27 (月) 午前 8:51:07

4


4. Installingtheindoorunit
4.3. Installationofduct(incaseoffreshairintake)
 (Fig.4-3)
Caution:
Linkageofductfanandairconditioner
lncasethataductfanisused,besuretomakeitlinkedwiththeairconditioner
whenoutsideairistaken.
Donotruntheductfanonly.Itcancausedewdrop.
Makingaductange(preparedlocally)
• Theshapeofductangeshownleftisrecommended.
Installationofductange
• Cut out the cutout hole. Do not knock it out.
• Installaductangetothecutoutholeoftheindoorunitwiththree4×10 tapping
screws which should be prepared locally.
Installationofduct(shouldbepreparedlocally)
• Prepare a duct of which inner diameter ts into the outer diameter of the duct
ange.
• Incasethattheenvironmentabovetheceilingishightemperatureandhighhumidity,
wrap the duct in a heat insulate to avoid causing dew drop on the wall.
ADuctangerecommendedshape
(Thickness:0.8 or more)
B3-ø5 hole
CDetail drawing of fresh air intake
DIndoor unit
ECeiling surface
F3-ø2.8 Burring hole
Gø73.4 cutout hole
HDuctange(Preparedlocally)
I4 ×10 Tapping screw (Prepared locally)
JDuct
4.4. Suspension structure (Give site of suspension
strongstructure)(Fig.4-4)
• The ceiling work differs according to the construction of the building. Building con-
structors and interior decorators should be consulted for details.
(1) Extent of ceiling removal: The ceiling must be kept completely horizontal and the
ceiling foundation (framework: wooden slats and slat holders) must be reinforced
in order to protect the ceiling from vibration.
(2) Cut and remove the ceiling foundation.
(3) Reinforce the ends of the ceiling foundation where it has been cut and add ceiling
foundation for securing the ends of the ceiling board.
(4)Wheninstallingtheunitonaslantingceiling,interlockapillowbetweentheceiling
and the grille and set so that the unit is installed horizontally.
1Wooden structures
• Usetiebeams(single-storyhouses)orsecondoorbeams(twostoryhouses)as
reinforcing members.
• Wooden beams for suspending air conditioners must be sturdy and their sides must
be at least 6 cm long if the beams are separated by not more than 90 cm and their
sides must be at least 9 cm long if the beams are separated by as much as 180
cm. The size of the suspension bolts should be ø10 (3/8"). (The bolts do not come
with the unit.)
2Ferroconcrete structures
Securethesuspensionboltsusingthemethodshown,orusesteelorwoodenhang-
ers,etc.toinstallthesuspensionbolts.
AUnit
BGrille
CPillow
DCeiling
ERafter
FBeam
GRoof beam
HUse inserts rated at 100-150 kg
each (procure locally)
ISuspension bolts M10 (3/8") (procure
locally)
JSteel reinforcing rod
12
Fig.4-4
ASuspension bolt (Procure locally)
BCeiling
CNut (Procure locally)
DWasher (with insulation) (Accessory)
Fig.4-5
4.5. Unitsuspensionprocedures(Fig.4-5)
Suspend the main unit as shown in the diagram.
1. Inadvance,setthepartsontothesuspensionboltsintheorderofthewashers
(withinsulation),washers(withoutinsulation)andnuts(double).
• Fit the washer with cushion so that the insulation faces downward.
• Incaseofusingupperwasherstosuspendthemainunit,thelowerwashers(with
insulation) and nuts (double) are to be set later.
2. Lift the unit to the proper height of the suspension bolts to insert the mounting
plate between washers and then fasten it securely.
3. Whenthemainunitcannotbealignedagainstthemountingholeontheceiling,
it is adjustable owing to a slot provided on the mounting plate. (Fig. 4-6)
• Make sure that step A is performed within 27-32 mm. Damage could result by
failing to adhere to this range.
4.6. Conrmingthepositionofmainunitandtightening
thesuspensionbolts(Fig.4-7)
• Usingthegaugeattachedtothegrille,ensurethatthebottomofthemainunitis
properlyalignedwiththeopeningoftheceiling.Besuretoconrmthis,otherwise
condensation may form and drip due to air leakage etc.
• Conrmthatthemainunitishorizontallylevelled,usingaleveloravinyltubelled
with water.
• Aftercheckingthepositionofthemainunit,tightenthenutsofthesuspensionbolts
securely to fasten the main unit.
• The installation template can be used as a protective sheet to prevent dust from
entering the main unit when the grilles are left unattached for a while or when the
ceilingmaterialsaretobelinedafterinstallationoftheunitisnished.
* Asforthedetailsoftting,refertotheinstructionsgivenontheInstallationtemplate.
AMain unit
BCeiling
CInstallation template (Accessory)
DScrew with washer (Accessory)
Fig.4-7
Fig.4-3
(mm)
Fig.4-6
*B: Suspension bolt pitch (see Fig. 4-2 Bfor details)
EMounting plate
FWasher (without insulation) (Accessory)
GCheck using the Installation gauge
AMain unit
BCeiling
CGauge (Grille accessory)
DCeiling opening dimensions

*B
*B

30
120
120
20
75
100
70
15




120
120
92
25
+5
27 0208
100




27
93
+5 0










Min. 30







A C
BG79U788H04_en.indd 4 2012/08/27 (月) 午前 8:51:07

5


1
0
/
2 3 4 5 6
7
5. Refrigerantpipingwork
AIndoor unit
BOutdoor unit
ø6.35
SLZ-KA25,KA35:ø9.52
SLZ-KA50: ø12.7
Fig.5-1
5.2. Flaringwork
• Maincauseofgasleakageisdefectinaringwork.
 Carryoutcorrectaringworkinthefollowingprocedure.
5.2.1. Pipecutting(Fig.5-2)
• Using a pipe cutter cut the copper tube correctly.
5.2.2. Burrsremoval(Fig.5-3)
• Completely remove all burrs from the cut cross section of pipe/tube.
• Put the end of the copper tube/pipe to downward direction as you remove burrs in
order to avoid burrs drop in the tubing.
5.2.3. Puttingnuton(Fig.5-4)
• Removearenutsattachedtoindoorandoutdoorunit,thenputthemonpipe/tube
having completed burr removal.
 (notpossibletoputthemonafteraringwork)
5.2.4. Flaringwork(Fig.5-5)
• Carryoutaringworkusingaringtoolasshownattheright.
Pipe diameter
(mm)
Dimension
A (mm)
B +0
-0,4 (mm)
When the tool for R410A is used
Clutch type
6.35 0 - 0.5 9.1
9.52 0 - 0.5 13.2
12.7 0 - 0.5 16.6
Firmly hold copper tube in a die in the dimension shown in the table at above.
5.2.5. Check(Fig.5-6)
• Comparethearedworkwithagureinrightsidehand.
• If are is noted to be defective, cut off the ared section and do aring work
again.
aSmooth all around
bInside is shining without any scratches
f Scratchonaredplane
gCracked
cEven length all around
dToo much
hUneven
iBad examples
eTilted
5.3. Refrigerantanddrainagepipinglocations(Fig.5-7)
ADrain pipe
BCeiling
CGrille
DRefrigerant pipe (liquid)
ERefrigerant pipe (gas)
FWater supply inlet
GMain unit
aCopper tubes
bGood
cNo good
dTilted
eUneven
fBurred
Fig.5-2
Fig.5-3
aBurr
bCopper tube/pipe
cSpare reamer
dPipe cutter
Fig.5-4
Fig.5-5
Fig.5-6
aFlare nut
bCopper tube
aFlaring tool
bDie
cCopper tube
dFlare nut
eYoke
A
As viewed from A
B
/2
10
3 4
90
2
1
0
/
0
/
/
0
3
0
1
2
1
A
5.1. Refrigerantpipe(Fig.5-1)
Piping preparation
• Refrigerantpipesof3,5,7,10and15mareavailableasoptionalitems.
(1)Tablebelowshowsthespecicationsofpipescommerciallyavailable.
Model Pipe Outside diameter Min. wall
thickness
Insulation
thickness
Insulation
materia
mm inch
SLZ-KA25
For liquid 6.35 1/4 0.8 mm 8 mm
Heat resist-
ing foam
plastic 0.045
specic
gravity
For gas 9.52 3/8 0.8 mm 8 mm
SLZ-KA35
For liquid 6.35 1/4 0.8 mm 8 mm
For gas 9.52 3/8 0.8 mm 8 mm
SLZ-KA50
For liquid 6.35 1/4 0.8 mm 8 mm
For gas 12.7 1/2 0.8 mm 8 mm
(2) Ensure that the 2 refrigerant pipes are well insulated to prevent condensation.
(3) Refrigerant pipe bending radius must be 100 mm or more.
Caution:
Usingcarefulinsulationofspeciedthickness.Excessivethicknessprevents
storagebehindtheindoorunitandsmallerthicknesscausesdewdrippage.
Fig.5-7
BG79U788H04_en.indd 5 2012/08/27 (月) 午前 8:51:08
