Mitsubishi Electric WD-60C10 User manual

Version 16.0 04/13/2011
MITSUBISHI DIGITAL ELECTRONICS AMERICA, INC.
9351 Jeronimo Road, Irvine, CA 92618-1904
Copyright © 2010 Mitsubishi Digital Electronics America, Inc.
All Rights Reserved
CAUTION:
Before servicing this chassis, it is important that the service person read the "SAFETY PRECAUTIONS" and
"PRODUCT SAFETY NOTICE" contained in this manual.
DLP PROJECTION HDTV
V43C Chassis
WD-60C10
WD-65C10
WD-73C10
V43+ Chassis
WD-60738
WD-65738
WD-73738
WD-82738
V43 Chassis
WD-60638
WD-60638CA
WD-65638
WD-65638CA
WD-73638
V43++ Chassis
WD-65838
WD-73838
WD-82838
SPECIFICATIONS
• Power Input : AC 120V, 60Hz
• Light Engine : DLP™ (1080p)
• Light Source : 156W
• Antenna Input : RF 75unbalanced
• Tuning : NTSC/ATSC/QAM
: Analog Cable - 1~125
Digital Cable - 1~135
• Speakers : 10W x 2 (V43C, V43, V43+)
: 2W x 16 (V43++)
• Analog Input : Composite/Component
Level (RCA Type)
Y/Video: 1.0 Vp-p, Cr, Cb: 700mVp-p
75unbalanced
: AUDIO IN JACK (RCA Type)
-4.7dBm 43kunbalanced
• Analog Output : AUDIO / SUBWOOFER OUT JACK
Level (RCA Type)
-4.7dBm 4.7kunbalanced
• Digital : AC-3/PCM Digital Audio Output
Inputs/Outputs (RCA Type)
: HDMI™
:
USB
: PC - use HMDI™
:
Wired IR Input/Output (V43++)
: Ethernet (V43+, V43++)
: Bluetooth (V43++)
Manual
Service
• See Page 5 for additional specifications.
• Design specifications are subject to change without notice.
2010

Page 3
MODELS: WD-60C10 / WD-65C10 / WD-73C10 / WD-60638 / WD-60638CA / WD-65638 / WD-65638CA /
WD-73638 / WD-60738 / WD-65738 / WD-73738 / WD-82738 / WD-65838 / WD-73838 / WD-82838
CONTENTS
INTRODUCTION..................................................................................................................................5
Dimensions, weight, power usage, etc.............................................................................................5
PRODUCT SAFETY NOTICE..............................................................................................................5
SAFETY PRECAUTIONS....................................................................................................................6
DISASSEMBLY & PARTS REPLACEMENT......................................................................................7
Back Cover Removal........................................................................................................................7
Chassis Removal ............................................................................................................................8
Rear Terminal Cover Removal.........................................................................................................8
Power Supply Shield Removal.........................................................................................................9
PWB-POWER Removal...................................................................................................................9
Top Chassis Brackets Removal.....................................................................................................10
PWB-MAIN Removal......................................................................................................................10
PWB-BALLAST Removal...............................................................................................................12
Optical Engine Assembly Removal & Disassembly.......................................................................12
Duct Assembly Removal................................................................................................................13
Optical Engine Replacement..........................................................................................................15
Projection Lens Replacement ........................................................................................................16
Color Wheel Replacement .............................................................................................................17
Screen Replacement......................................................................................................................18
Mirror Replacement........................................................................................................................24
SERVICE PROCEDURES.................................................................................................................25
Remote Control ..............................................................................................................................25
Option Menu...................................................................................................................................26
Reset and Initialization...................................................................................................................29
LED Indications & Self Diagnostics................................................................................................30
Error Codes....................................................................................................................................31
Error Code Log...............................................................................................................................31
Sound Projector Transducer Test ..................................................................................................32
Service Adjustments.......................................................................................................................33
Equipment & Test Signals.....................................................................................................33
Service Menu ........................................................................................................................33
Horizontal & Vertical Position Adjustment.............................................................................35
Index Delay Adjustment ........................................................................................................36
Manual Geometry Alignment.................................................................................................37
Data Transfer Functions.................................................................................................................41
Using Lead Free Solder .................................................................................................................43
Chip Parts Replacement ................................................................................................................44
REPLACEMENT PARTS...................................................................................................................45
Parts Ordering................................................................................................................................45
Critical and Warranty Parts Designation........................................................................................45
Parts Tolerance Codes...................................................................................................................45
Parts Quick Reference...................................................................................................................46
Service Parts List ...........................................................................................................................47
Screen Parts...................................................................................................................................56
Mirror Kits & Preparation................................................................................................................58
CIRCUIT BLOCK DIAGRAMS ..........................................................................................................60
SCHEMATIC DIAGRAMS

Page 4
MODELS: WD-60C10 / WD-65C10 / WD-73C10 / WD-60638 / WD-60638CA / WD-65638 / WD-65638CA /
WD-73638 / WD-60738 / WD-65738 / WD-73738 / WD-82738 / WD-65838 / WD-73838 / WD-82838
Digital Light Processing®, Digital Micro Mirror Device and DLP® are Trademarks of Texas Instruments.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing, LLC..

Page 5
MODELS: WD-60C10 / WD-65C10 / WD-73C10 / WD-60638 / WD-60638CA / WD-65638 / WD-65638CA /
WD-73638 / WD-60738 / WD-65738 / WD-73738 / WD-82738 / WD-65838 / WD-73838 / WD-82838
INTRODUCTION
This service manual provides service instructions for the V43C, V43, V43+ and V43++ chassis types. The specific
models for each chassis type, dimensions and weight are listed below. Service personnel should read this manual
thoroughly before servicing these chassis.
This service manual includes:
1. Disassembly & replacement instructions for cabinet and chassis components.
2. Replacing the Lenticular Screen, Fresnel Lens and Mirror.
3. Initial setup and troubleshooting.
4. Service adjustments.
5. Using lead free solder.
6. Chip parts replacement procedures.
7. Replacement part Instructions
8. Replacement parts list
9. Circuit block diagrams
10. Schematic diagrams
PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in television receivers have special safety related characteristics. These char-
acteristics are often not evident from visual inspection nor can the protection afforded by them necessarily be ob-
tained by using replacement components rated for higher voltage, wattage, etc.
Replacement parts which have special safety characteristics are identified on the schematic diagrams and parts list
of this service manual. The replacement for any safety part should be identical in value and characteristics.
The PWBs used in this chassis are constructed using Lead-Free Solder. When servicing use
only recommended Lead-Free Solder. Refer to the section “Using Lead Free Solder.”
MODEL CHASSIS HEIGHT WIDTH DEPTH WEIGHT
POWER
USAGE
WD-60C10 V43C 36.7" 54.7" 14.4" 65.0 lbs 260W
WD-65C10 V43C 39.5" 58.2" 15.4" 72.3 lbs 260W
WD-73C10 V43C 43.6" 65.2" 17.5" 93.0 lbs 260W
WD-60638 V43 36.7" 54.7" 14.4" 65.0 lbs 260W
WD-65638 V43 39.5" 58.2" 15.4" 72.3 lbs 260W
WD-73638 V43 43.6" 65.2" 17.5" 93.0 lbs 260W
WD-60738 V43+ 36.7" 54.7" 14.4" 65.0 lbs 270W
WD-65738 V43+ 39.5" 58.2" 15.4" 72.3 lbs 270W
WD-73738 V43+ 43.6" 65.2" 17.5" 93.0 lbs 270W
WD-82738 V43+ 48.5" 73.2" 20.0" 139.7 lbs 270W
WD-65838 V43++ 39.5" 58.2" 15.8" 77.2 lbs 290W
WD-73838 V43++ 43.6" 65.2" 17.9" 97.9 lbs 290W
WD-82838 V43++ 48.5" 73.2" 20.4" 147.5 lbs 290W
WD-65638CA V43 39.5" 58.2" 15.4" 72.3 lbs 260W
WD-60638CA V43 36.7" 54.7" 14.4" 65.0 lbs 260W

Page 6
MODELS: WD-60C10 / WD-65C10 / WD-73C10 / WD-60638 / WD-60638CA / WD-65638 / WD-65638CA /
WD-73638 / WD-60738 / WD-65738 / WD-73738 / WD-82738 / WD-65838 / WD-73838 / WD-82838
SAFETY PRECAUTIONS
NOTICE:
Observe all cautions and safety related notes located inside the receiver cabinet and on the receiver chassis.
WARNING:
1. Operation of this receiver outside the cabinet or with the cover removed presents a shock hazard from
the receiver's power supplies. Work on the receiver should not be attempted by anyone who is not thoroughly
familiar with the precautions necessary when working on high voltage equipment.
2. When service is required, observe the original lead dress. Where a short-circuit has occurred, replace those
components that indicate evidence of overheating.
SAFETY PRECAUTION
To protect your eyes, do not look directly into the lamp, or light coming directly from the lamp, lens or
mirror.
Leakage current check
Before returning the receiver to the customer, it is recommended that leakage current be measured according to the
following methods.
1. Cold Check
With the alternating current (AC) plug removed from the AC source, place a jumper across the two AC plug
prongs. Connect one lead of an ohm meter to the AC plug and touch the other lead to each exposed metal
part (i.e. antennas, handle bracket, metal cabinet, screw heads, metal overlay, control shafts, etc.), particularly
any exposed metal part that has a return path to the chassis. The resistance of the exposed metal parts hav-
ing a return path to the chassis should be a minimum of 1Meg Ohm. Any resistance below this value indi-
cates an abnormal condition and requires corrective action.
2. Hot Check ...Use the circuit shown below to perform the hot check test.
1. Keep switch S1 open and connect the receiver to the measuring circuit. Immediately after connection,
and with the switching devices of the receiver in their operating positions, measure the leakage current
for both positions of switch S2.
2. Close switch S1, energizing the receiver. Immediately after closing switch S1, and with the switching
devices of the receiver in their operating positions, measure the leakage current for both positions of
switch S2. Repeat the current measurements of items 1 and 2 after the receiver has reached thermal
stabilization. The leakage current must not exceed 0.5 milliampere (mA).
GWG - Green Wire Ground
(Earth Ground)
S2
S1
OPEN
GROUND
SUPPLY CONNECTOR GROUND
RECEIVER
INSULATED TABLE
TOUCH ALL
EXPOSED
METAL PARTS
AC MA
METER
L
N

Page 7
MODELS: WD-60C10 / WD-65C10 / WD-73C10 / WD-60638 / WD-60638CA / WD-65638 / WD-65638CA /
WD-73638 / WD-60738 / WD-65738 / WD-73738 / WD-82738 / WD-65838 / WD-73838 / WD-82838
DISASSEMBLY & PARTS REPLACEMENT
BACK COVER REMOVAL
Back Cover Removal
1. Remove screws (A) from the back cover.
2. Remove the back cover from the TV.
A
A
A
A
A
A 73” & 82” Only
ASSEMBLY LOCATIONS
CHASSIS OPTICAL ENGINE ASSEMBLY
DMD FAN LAMP PWB-BALLAST

Page 8
MODELS: WD-60C10 / WD-65C10 / WD-73C10 / WD-60638 / WD-60638CA / WD-65638 / WD-65638CA /
WD-73638 / WD-60738 / WD-65738 / WD-73738 / WD-82738 / WD-65838 / WD-73838 / WD-82838
CHASSIS - REMOVAL & DISASSEMBLY
Chassis Removal
1. Remove screws (A).
2. Disconnect all cables connecting to the chassis.
3. Slide the chassis out of the cabinet.
A
A
Rear Terminal Cover Removal
1. Remove nut (A) from the ANT input.
2. Remove screws (B) and (C).
3. Disconnect the connector to the PWB-AUX (V43++).
4. Remove the Terminal Cover from the chassis.
A
ANT Location:
V43C, V43 Left Side
V43+, V43++ Right Side
B
V43++ Only
C
PWB-AUX
CONNECTOR
(ON REAR)

Page 9
MODELS: WD-60C10 / WD-65C10 / WD-73C10 / WD-60638 / WD-60638CA / WD-65638 / WD-65638CA /
WD-73638 / WD-60738 / WD-65738 / WD-73738 / WD-82738 / WD-65838 / WD-73838 / WD-82838
PWB-POWER Removal
1. Disconnect all cables from the PWB-POWER.
2. Remove screws (A).
3. Pinch the Retainers to release the PWB.
4. Lift the PWB-POWER from the chassis.
A
A
A
A
Power Supply Shield Removal
1. Remove screw (A).
A
POWER SUPPLY SHIELD
Retainers
(Pinch)

Page 10
MODELS: WD-60C10 / WD-65C10 / WD-73C10 / WD-60638 / WD-60638CA / WD-65638 / WD-65638CA /
WD-73638 / WD-60738 / WD-65738 / WD-73738 / WD-82738 / WD-65838 / WD-73838 / WD-82838
PWB-MAIN ACCESS
1. Remove screws (A).
2. Lift the Power Supply and Mounting Brackets from the chassis.
PWB-MAIN Removal (V43)
1. Disconnect all cables to PWB-MAIN.
2. Remove screws (B) from the top of the PWM-MAIN.
3. Pinch the Retainer to release the PWB.
4. Lift the PWB-MAIN out of the chassis.
B
B
B
Retainer
(Pinch)
A
A

Page 11
MODELS: WD-60C10 / WD-65C10 / WD-73C10 / WD-60638 / WD-60638CA / WD-65638 / WD-65638CA /
WD-73638 / WD-60738 / WD-65738 / WD-73738 / WD-82738 / WD-65838 / WD-73838 / WD-82838
PWB-MAIN Removal (V43+, V43++)
1. Disconnect all cables to PWB-MAIN.
2. Remove screws (A) from the Side Terminals (V43++ only).
A
B
B
B
B B
After PWB-MAIN Replacement
See Data Transfer in Service Procedures section.
1. V43C & V43: Perform “Restore Engine Data From Backup.”
2. V43+ & V43++: Perform “Restore Engine Data From Backup” and “Restore Geometry Data From Backup.”
V43+, V43++ IMPORTANT REPLACEMENT NOTE: If the customer has subscribed to VUDU (Internet program
provider), the customer must be instructed to contact VUDU to re-activate their account after the replacement
PWB has been installed. The original PWB cannot be installed in another TV. It must be returned to Mitsubishi
per policy.
3. Remove screws (B) from the top of the PWM-MAIN.
4. Lift the PWB-MAIN out of the chassis.
V43++ Only
V43+ Only

Page 12
MODELS: WD-60C10 / WD-65C10 / WD-73C10 / WD-60638 / WD-60638CA / WD-65638 / WD-65638CA /
WD-73638 / WD-60738 / WD-65738 / WD-73738 / WD-82738 / WD-65838 / WD-73838 / WD-82838
OPTICAL ENGINE ASSEMBLY - REMOVAL & DISASSEMBLY
Note: To remove the PWB-BALLAST, it is not necessary to remove the Engine or Lamp Cartridge.
1. Release the Latch to lift the PWB-BALLAST from the mounting bracket.
2. Slide the PWB-BALLAST out of the Engine Assembly.
3. Disconnect the electrical locking connectors indicated.
4. To reinstall, first connect the connectors. Then slide the PWB under the Retaining Hooks. Then press the rear
edge of the PWB down onto the guide pins to engage the latch.
LATCH
CJ1 (Lamp Power)
CJ3 (Lamp Control)
CJ4 (HV to Lamp)
RETAINING
HOOKS
A A A
PWB-BALLAST REMOVAL
CJ1 (Lamp Power) CJ3 (Lamp Control)
J12 (LVDS)
PE
(Engine Power) CD (Lamp Door Sw)
OPTICAL ENGINE ASSEMBLY REMOVAL
1. Remove 3 screws (A) from the Optical Engine Assembly.
2. Disconnect the electrical locking connectors indicated.
3. Slide the Optical Engine Assembly out of the cabinet.

Page 13
MODELS: WD-60C10 / WD-65C10 / WD-73C10 / WD-60638 / WD-60638CA / WD-65638 / WD-65638CA /
WD-73638 / WD-60738 / WD-65738 / WD-73738 / WD-82738 / WD-65838 / WD-73838 / WD-82838
DUCT ASSEMBLY - Removal and Disassembly
Upper Duct Removal
1. Loosen two screws (A) and remove the Lamp Cartridge.
2. Disconnect the Exhaust and Sirocco Fan Connectors (J4 and J8) from the back of the Engine and loosen the
wiring harnesses from the looms.
3. Remove screw (B) from the top of the Upper Duct and release the latches.
4. Remove the Upper Duct from the Optical Engine Assembly.
A
B
J4
(Exhaust Fan)
LATCH
J8
(Sirocco Fan)
UPPER DUCT
LOWER DUCT
LATCH
LATCH
LATCH
LATCH

Page 14
MODELS: WD-60C10 / WD-65C10 / WD-73C10 / WD-60638 / WD-60638CA / WD-65638 / WD-65638CA /
WD-73638 / WD-60738 / WD-65738 / WD-73738 / WD-82738 / WD-65838 / WD-73838 / WD-82838
Duct Interior Components
Duct Interior Components are shown below.
Notes:
 The Upper Duct must be removed to replace the Lamp Door Switch PWB, Sirocco Fan and Exhaust Fan.
 When replacing the Optical Engine, transfer all Duct and Duct Interior Components from the old Engine to the
new Engine.
 The Exhaust Fan must be installed so the Label is facing inside the Duct.
 The Sirocco Fan must be installed so the Label is facing up with the Flanges aligned onto the Guide Pins.
SIROCCO FAN
(Label Facing Up) (Label Facing In)
EXHAUST FAN
PWB-LAMP DOOR SW
Sirocco Fan Flanges
Align Onto Guide Pins

Page 15
MODELS: WD-60C10 / WD-65C10 / WD-73C10 / WD-60638 / WD-60638CA / WD-65638 / WD-65638CA /
WD-73638 / WD-60738 / WD-65738 / WD-73738 / WD-82738 / WD-65838 / WD-73838 / WD-82838
Lower Duct Removal
1. Remove the Lamp Cartridge, Upper Duct, Exhaust Fan and Sirocco Fan.
2. Disconnect the HV Lamp Wiring from the Ballast and loosen it from the guides.
3. Remove the 2 screws (C) one in front and one in the rear of the lower duct.
4. Carefully remove the Lower Duct from the Engine.
OPTICAL ENGINE REPLACEMENT
1. Install Duct Assembly on the new Engine.
2. Connect the HV Lamp Wiring to the Ballast and dress the wiring through the guides as shown.
3. Remove the Protective Lens Cover from the face of the Lens and place it on the old Engine for return.
4. Install the Engine Assembly in the cabinet.
5. After a new Engine is installed, perform the following procedures as described in the Data Transfer section of
the Service Procedures:
 “Restore Index Delay”
 “Save Engine and Geometry Setting to Backup”
5. If needed. perform the Horizontal and Vertical Centering Adjustment and Manual Geometry Alignment as de-
scribed in the Service Adjustments section of the Service Procedures.
C
C
Not Shown
(Rear of Engine)
HV Lamp Wiring
HV LAMP WIRING
Dress Through Guides as Shown

Page 16
MODELS: WD-60C10 / WD-65C10 / WD-73C10 / WD-60638 / WD-60638CA / WD-65638 / WD-65638CA /
WD-73638 / WD-60738 / WD-65738 / WD-73738 / WD-82738 / WD-65838 / WD-73838 / WD-82838
PROJECTION LENS REPLACEMENT
LENS
COLLAR
CAUTION: Any dust or fingerprints in the optics can cause abnormalities in the picture.
This procedure should be performed in a dust free environment.
Wear lint free cotton or rubber gloves while performing this procedure.
1. Remove Optical Engine Assembly.
2. Remove screws (A) and remove the Lens Collar.
3. Remove screws (B).
4. Lift out the Projection Lens.
5. Install the replacement lens so the key is oriented towards the top as shown.
A
KEY
LENS
B
B
B
B

Page 17
MODELS: WD-60C10 / WD-65C10 / WD-73C10 / WD-60638 / WD-60638CA / WD-65638 / WD-65638CA /
WD-73638 / WD-60738 / WD-65738 / WD-73738 / WD-82738 / WD-65838 / WD-73838 / WD-82838
CAUTION: This procedure should be performed in a dust free environment.
Any dust entering into the color wheel compartment can cause abnormalities in the picture.
1. Remove the Optical Engine Assembly.
2. Remove the Lens Collar and cover the projection lens to protect it from scratches. See previous page.
3. Disconnect the 2 connectors, J6 & J7, from the front side of the Light Engine. Note the orientation of the
ribbon cable for re-assembly (Silver Contacts towards the Lens).
4. Access the Color Wheel Compartment from the bottom of the Optical Engine
5. Remove 2 screws (A) and lift the cover off of the color wheel compartment.
6. Remove the 3 screws (B) from the Color Wheel Assembly.
7. Use the metal Handle to lift the Color Wheel from the compartment.
8. For installation, reverse the procedure above.
CAUTION: Avoid touching or scratching the Color Wheel.
9. After re-assembly, perform the Index Delay Adjustment described in the Service Adjustments section.
IMPORTANT: To prevent damage in return shipping, pack the original color wheel the same way the
replacement part was sent to you.
Color Wheel Compartment
COLOR WHEEL REPLACEMENT
J6 & J7
(Opposite Side of Formatter PWB)
LENS COLLAR
A
B
HANDLE

Page 18
MODELS: WD-60C10 / WD-65C10 / WD-73C10 / WD-60638 / WD-60638CA / WD-65638 / WD-65638CA /
WD-73638 / WD-60738 / WD-65738 / WD-73738 / WD-82738 / WD-65838 / WD-73838 / WD-82838
SCREEN REPLACEMENT 60”, 65” & 73” Models
Screen Assembly Removal and Replacement
1. V43C, V43 - Open the front control panel door.
2. V43+, V43++ - Remove the ORNAMENT LEFT & RIGHT first by pinching up and pulling away from the
bottom. Then remove the ORNAMENT CENTER using the same method.
3. Remove screws (A).
4. V43++ - Disconnect the PWB-SBL connector.
5. Remove screws (B) around the rear edge of the screen bezel.
6. During re-assembly replace screws in their original locations.
B
B
B
B
B
73 INCH
V43+ (65” 73”)
ORNAMENT LEFT & RIGHT
(Speaker Covers)
ORNAMENT CENTER
V43++
ORNAMENT
CENTER
(Speaker Cover)
ORNAMENT RIGHT
ORNAMENT LEFT
A A
A
A
(73” Only) (73” Only)
PWB-SBL
CONNECTOR
ADOOR
V43C,V43 (60” 65” 73”)
V43+ (60”)
A A
A (65” Only)
(65” Only)
Number and Location of
Screws Varies by Model
A

Page 19
MODELS: WD-60C10 / WD-65C10 / WD-73C10 / WD-60638 / WD-60638CA / WD-65638 / WD-65638CA /
WD-73638 / WD-60738 / WD-65738 / WD-73738 / WD-82738 / WD-65838 / WD-73838 / WD-82838
A
A
A
73 INCH
(Rear View)
A
60 & 65 INCH
A
A
(Rear View)
AA
Screen Removal From the Bezel-Front
1) Remove screws (A) and remove the top, bottom and side rails.
NOTE: The number and location of screws vary by model.
2) Lift the Fresnel Lens and Lenticular screen from the Bezel-Front.
3) During re-assembly replace screws in their original locations.
SCREEN REPLACEMENT 60”, 65” & 73” Models (continued)
Example Diagrams. The number and location of screws vary by model.

Page 20
MODELS: WD-60C10 / WD-65C10 / WD-73C10 / WD-60638 / WD-60638CA / WD-65638 / WD-65638CA /
WD-73638 / WD-60738 / WD-65738 / WD-73738 / WD-82738 / WD-65838 / WD-73838 / WD-82838
SCREEN REPLACEMENT 60”, 65” & 73” Models (continued)
CAUTION: Wear gloves when handling the Lenticular Screen and Fresnel Lens.
This prevents cuts and finger prints. Do not place Fresnel Lens in the sun.
This may cause fire and heat related injuries.
Lenticular Screen and Fresnel Lens Removal
1. After removing the top, bottom and side HOLDER-SCREEN rails and their cushions from the Bezel, lift the
screens as a single unit from the frame.
2. Separate the Lenticular Screen and Fresnel Lens.
Note: When separating the Lenticular Screen from the Fresnel Lens, use caution
while prying the Screen and Lens apart. Use a slot type screw driver, and
remove the pressure sensitive double sided tape.
Lenticular Screen and Fresnel Lens Replacement
1. Apply LENS-TAPE along the rear top edge of the Lenticular Screen.
2. Place the Fresnel Lens on top of the Lenticular Screen, and apply pressure along the top edge.
3. Place the screens in the screen frame and reinstall the cushions, top, bottom and side rails.
NOTE: The Lenticular Screen label must face the front and the Fresnel Lens label face the rear.
4. Reverse the Screen Removal Procedure and insert the screens in the Bezel.
BEZEL FRONT
LENS-TAPE
SCREEN
LENTICULAR
LENS
FRESNEL
COVER-HOLDER-T
HOLDER-SCREEN-S
HOLDER-SCREEN-B
LABEL
LABEL
HOLDER-SCREEN-T
SPACER-SCREEN-S
SPACER-SCREEN-B
SPACER-SCREEN-T
