Mitsubishi Electric NJ-EXSA10JH User manual
Before use, please read this Instruction
Manual carefully to ensure proper and safety
use.
Please make sure the date of purchase, retail
store name and other items are correctly filled
in the Warranty Card.
Please keep the Instruction Manual and
Warranty Card in a safe place.
.*546#*4)*&-&$53*$
45&".-&44
*)
3*$&$00,&3
'03)064&)0-%64&
.0%&- -5ZQF
/+&94"+)
*/4536$5*0/."/6"-
3&$*1&4
Table of Contents
This appliance is designed for use in Hong Kong
and Macau only and please do not use in any other
countries.
Before UseHow to Cook RiceTipsRecipes
Features ········································2
Inner Pot ········································2
Safety Precautions ····························3
Names and Functions of Parts···············6
How to Cook Tasty Rice·······················8
Points for Cooking by Rice Type ············9
Cooking Rice <Basics> ····················· 10
Cooking White Rice/Japanese White Rice (QUICK)
··· 12
Cooking Japanese Brown Rice ············ 14
Cooking Various Kinds of Rice ············ 16
• HOUZYUN • STICKY RICE • SUSHI
• MIXED • CONGEE • CONGEE
(1:7 ratio of rice to water)
Keeping Rice Warm························· 18
How to Adjust the Current Time ··········· 19
If Power Cut Occurs ························· 19
Using Timer to Cook Rice
• Set the finish time········································· 20
(TIMER1/TIMER2)
•
Set the finish time in 2–12 hours from now
········ 21
(Easy reservation)
Cleaning ······································ 22
When You Cannot Cook Rice Well ········ 25
Status Display································ 26
Troubleshooting ····························· 27
Specifications ································ 36
Sticky Rice···································· 29
Sushi ·········································· 30
Mixed Rice ··································· 32
Brown Rice ··································· 34
Congee ········································ 35
&OHMJTI
&
Before Use
1
Steamless
This feature makes continuous boiling possible without caring
about boiling over the steam vent and can cook fluffy rice that
tastes sweet.
Steam is processed inside the cooker and cooking odor is
eliminated by absorption in water.
<How Steam is Removed>
Cartridge
Inner
Pot Tank
1Steam generated inside the inner pot during rice cooking is
passed through the cartridge and led into water in the tank.
2Steam is cooled down by the water in the tank and converted
back to water.
NOTES
Small amount of steam may be discharged from the
cooker, but this does not cause high temperature or
condensation.
About 95% steam can be reduced compared with old
model. (This is our own research.)
2
Charcoal-coated Thick
Pot and Continuous-
boiling IH
A highly thermal efficient charcoal-coated
thick pot efficiently transfers heat to the
rice to cook fluffy rice that tastes sweet.
Continuous-boiling IH that continues to
cook at strong power without reducing
heat after reaching the boiling point which
maximizes the flavor of rice.
3
HOUZYUN Cooking
Advanced cooking mode enriches taste
and sweetness of rice by spending more
time on preparation to increase water
absorption effect.
Features
Inner Pot
Wash the pot with dishwashing liquid and a soft sponge, and then rinse it thoroughly.
The coating on the bottom surface of the pot may be peeled off depending on conditions of use, but this does not
effect its performance.
The pot surface is coated with fluorine.
Damage to the fluorine coating will increase the likelihood of
peeling off. Penetration of salt and vinegar through the fluorine
coating will increase the likelihood of erosion and rust.
Even if the fluorine resin and base material peel off
the pot, there will be no effect on performance and no
harm to human health.
When washing rice, lay a cloth under the inner pot to prevent damage to
the bottom. (Damage to the bottom will not affect the performance and
hygiene.)
Please purchase a new inner pot if any of the following applies.
• Rice sticks on the inner pot
• The inner pot has become deformed
• The fluorine coating has been damaged
Please pay attention to the following points:
Do not wash rice or drain the water with a
colander.
When putting rice in the inner pot, be careful
that a colander or the like does not come in
contact with the inner pot.
Do not try to remove rice grains stuck on
the rice scoop by pressing the rice scoop
against the edge of the inner pot.
Fluorine
coating on the
edge may be
damaged
Fluorine
coating on the
edge may be
damaged
Do not use hard objects (e.g. a metal rice
scoop, whisk, or crockery)
.
Do not wash dishes, spoons or utensils inside
the inner pot.
Do not use the inner pot for cooking
appliances (such as direct heating, microwave,
or electromagnetic cooking appliances) other
than this appliance.
Do not use a dish washer or dish dryer to clean the inner pot.
When seasonings are used, rinse immediately after use.
(
Cooking rice with vinegar or salt or mixing rice with vinegar in the inner
pot may damage the fluorine coating or cause corrosion and rust.
)
Do not wash the inner pot with a cleanser,
scrubbing brush, nylon surface of a cleaning
sponge, or cleaning sponge with nylon net.
Fluorine
coating may
be damaged
Fluorine
coating may
be damaged
Nylon
surface
Nylon
surface
Before Use
Before Use &
The meanings of the graphic symbols are as follows.
Safety Precautions
The following categories describe hazards caused by
mishandling and their levels.
WARNING
CAUTION
Indicates a hazard caused by mishandling that may
result in death or serious injury.
Indicates a hazard caused by mishandling that may result
in a minor injury or damage to the home and its contents.
Do not disassemble, repair, or
modify the appliance.
Doing so may cause electric shock, fire, injury,
or malfunction.
*
Please consult with your local dealer regarding repairs.
This appliance is not intended for
use by persons (including children)
with reduced physical, sensory
or mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision
or instruction concerning use of the
appliance by a person responsible
for their safety. Children should be
supervised to ensure that they do
not play with the appliance.
Doing so may cause a burn or injury.
Do not insert or pull out the
power plug with wet hands.
Doing so may cause electric shock.
Do not put the appliance in water
and do not pour water over it.
Doing so may cause electric shock or short-circuit.
Do not use the appliance for
purposes other than described in
the instruction manual.
Do not use for other types of
cooking (steaming, etc.).
• Do not put anything in the inner pot that may
block the hole in the heat sink.
Doing so may cause steam and contents to spill
out resulting in a burn, electric shock, or injury.
Do not allow a child to use the
appliance without supervision.
Do not use the appliance in a
place where an infant can reach it.
Doing so may cause a burn, electric shock, or injury.
Prohibited
No wet
hands
No
disassembly
No water
exposure
Observe
instructions
WARNING
Never open the lid or carry the
appliance during rice cooking.
Do not remove the tank during
rice cooking.
Doing so may cause a burn or injury.
Do not insert foreign objects
such as a pin, wire, or any other
metallic object into the air inlet,
air outlet, or any other gap.
Doing so may cause electric shock or injury.
Do not use a damaged power
cord and plug, or a loose outlet.
Doing so may cause electric shock, short-circuit, or fire.
Do not damage the power cord.
Putting a heavy object on the power cord,
bending it with excessive force, binding it
together, or stretching it may cause damage to
it, resulting in electric shock or fire.
•
If the power cord is damaged, it must be
replaced by the manufacturer, its service agent
or similarly qualified persons to avoid hazards.
Use an independent 220V AC
power outlet rated at 10A or
more.
Sharing an outlet with other appliances or using
an outlet on a desk or any furniture may cause
overheating resulting in ignition and fire.
*
Use an independent extension cord rated at 10A or more.
Remove dust from the power plug
pins and pin mounting surface.
A buildup of dust may cause a fire.
Insert the power plug fully into
the outlet.
Failing to do so may cause electric shock or
overheating resulting in a fire.
Before Use
Safety Precautions (Cont.)
WARNING
Close the lid firmly until it clicks.
To prevent a burn or injury caused by steam
leaking or the opening of the lid.
*To ensure that the lid can be closed, remove
rice grains or any other foreign object on the
top frame, lid packing, tank, and between the
main unit and lid.
Adjust the amount of water to the
water level scale mark suitable
for the rice type and menu.
To prevent boiling over or injury.
If the appliance is operating
abnormally or fails, stop using it
immediately.
Failing to do so may cause smoke, ignition, or
electric shock.
•The power cord and plug are abnormally hot.
•It smells like something is burning.
•Touching the appliance causes a sensation like an
electric shock.
•The cooling fan stops rotating.
•There is another abnormality or failure.
To prevent a failure or accident, pull out the power plug and
then inform Mitsubishi Electric.
CAUTION
Do not touch the hot parts during
cooking and immediately after use.
For example, the cartridge, inner pot, heat sink, tank,
tank lid, and the boundary between the side surface of
the main unit and the lid.
Doing so may cause a burn.
Do not use the appliance in
following locations.
Near a wall or furniture
Doing so may cause discoloration or deformation.
Allow the following distances when cooking rice and keeping
rice warm.
Front Left side Right side Back Top
3 cm (One of the surfaces must have
adequately open space)
3 cm 10 cm
(52 cm from the appliance is required to open the lid.)
* Even if the distances above are allowed, the wall may become
dirty or condensation may build up due to steam leak if foreign
objects such as rice grains are caught between the top frame
and the lid or the packing is deformed or deteriorates.
In an unstable location or on a non-heat
resistant carpet
Doing so may cause a fire or a failure to start cooking rice.
* Place the appliance on a level and stable surface.
In a place exposed to water or near open fire or
heating appliance
Doing so may cause electric shock, electric leakage, or fire.
In a place where the air inlet and outlet are blocked
(On paper, towel, cloth, aluminum sheet, carpet, etc.)
Doing so may cause discoloration, deformation, or failure.
On an aluminum sheet or electric carpet
(Doing so may cause the aluminum sheet to overheat.)
* When you want to use, for example, a kitchen storage rack, confirm
the load capacity of the rack before use. (Maximum weight of the
appliance including rice and water: Approx. 10 kg)
Do not touch the hook button
when you carry the appliance
around.
Doing so may cause the lid to open resulting in a
burn or injury.
Do not use any inner pot other
than the supplied one.
Doing so may cause overheating or malfunction.
Do not use any cord set other than
the supplied one. Also, do not use
the cord set for any other appliance.
Doing so may cause a failure or ignition.
Disconnect the power cord while
holding the plug.
Disconnecting the power cord while holding the
cord may cause electric shock, short-circuit, or
ignition.
A medical pacemaker user is
required to consult with a doctor
before using this appliance
The operation of this appliance may interfere with
the pacemaker.
Clean the appliance after the
main unit has cooled down.
To prevent a burn.
Disconnect the power cord when
the appliance is not used.
To prevent electric shock, electric leakage, or fire
caused by insulation deterioration.
Before Use &
ATTENTION This rice cooker is designed for household use. Please do not use it for
commercial use or any purposes other than cooking rice at home. *Inner Pot P. 2
Do not bring an object that is prone to
magnetic or electric wave interference
close to the appliance.
• Magnetic cards (cash card, commuter pass, etc.)
• Magnetic tapes (cassette tape, etc.)
• Wireless devices (TV, radio, phone, etc.)
Doing so may cause data loss, noise, or malfunction.
Do not lay a washcloth or put any other
object on the main unit during use.
Doing so may make the unit hot, resulting in deformation or
failure.
Be careful of steam when opening the lid
after rice cooking is finished.
To prevent a burn.
Do not turn on the appliance without rice
and water.
Doing so may cause a failure or malfunction.
Do not use the appliance in a place
exposed to direct sunlight.
Doing so may cause discoloration or deformation.
Keep the main unit and the area around it
clean
The entry of dust or an insect into the air inlet or outlet for
ensuring the appliance functions properly may cause a failure.
Do not use the appliance when there are
any foreign objects, rice grains, or water
droplets remaining on it.
Bottom
Flange
Bottom Sensor
Tank Lid
Water Temperature Sensor Tank Holder
Flange Contact
Part
Lid Packing
Latch
Doing so may cause a failure, poorly cooked rice, or the failure to
close the lid properly.
<Tank>
Do not scratch the water level sensor surface.
P.22
Doing so may cause a failure.
Do not carry the appliance around with water in the
tank.
Doing so may cause water to spill out.
Drain the water from the tank after it has cooled
down and wash the tank after every use.
To prevent mold and bacteria from growing.
Do not use a damaged tank.
Doing so may cause a failure.
Do not place the tank in a place exposed to direct
sunlight.
Doing so may cause a failure or discoloration.
<Tank Water>
Do not use other than tap water or do not put an
object in the tank.
Doing so may cause mold and bacteria to grow or
cause a failure.
Do not use hot water.
Doing so may cause poorly cooked rice.
Do not drink water in the tank.
Table of contents
Other Mitsubishi Electric Rice Cooker manuals
