Mitsubishi Electric DLP WD-92A12 Installation and operating instructions

3D DLP
® HOME-CINEMA TELEVISION
MODELS
WD-92A12
Addendum OWNER’S GUIDE
®
This addendum is to add the model WD-92A12 to the 742/842 Series Basic Owner’s
Guide and on-line Supplemental Owner’s Guide.
•For questions:
- Visit our website at www.mitsubishi-tv.com.
- E-mail us at [e-mail].
- Call Consumer Relations at 800-332-2119 for operational or connection assistance.
•For information on System Reset, please see the back cover of the 742 Series Basic Owner’s Guide.
•To order replacement or additional remote controls, visit our website at www.mitsuparts.com or call
800-553-7278.
When using the WD-92A12, refer to the Basic Owner’s Guide operational and
connection instructions for the 742 Series. For use of additional features of
this television, please visit our website at www.Mitsubishi-tv.com to view or
download a Supplemental Owner’s Guide. Follow the support link to the Product
V47A
853B733A10
© 2012 Mitsubishi Electric Visual Solutions America, Inc.
Documents page.

2
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING: To reduce the risk of fire or electric shock,
do not expose this apparatus to rain or moisture.
This apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such as
vases, shall be placed on the apparatus.
En français
Cet appareil ne doit pas être exposé à des gouttes ou
à des éclaboussures et aucun objet rempli d’un liquide,
comme un vase, ne doit être placé sur l’appareil.
WARNING: This product contains chemicals known
to the State of California to cause cancer and/or birth
defects or other reproductive harm.
TV WEIGHT:This TV is heavy. Exercise extreme care
when lifting or moving it. Lift or move the TV with a
minimum of two adults. To prevent damage to the TV,
avoid jarring or moving it while it is turned on. Always
power off your TV, unplug the power cord, and discon-
nect all cables before moving it.
CAUTION:
When selecting a stand, base, or other furni-
ture to support the TV, please make sure it is designed with
the appropriate dimensions for stability and to support the
TV’s weight plus the weight of any additional equipment
you plan to store.
Custom cabinet installation must allow for proper
air circulation around the television.
MAINS DISCONNECTION:The mains plug is used
as the disconnect device. The mains plug shall remain
readily operable.
FCC Declaration of Conformity
Product: Projection Television Receiver
Models: WD-92A12
Responsible
Party:
Mitsubishi Electric Visual Solutions
America, Inc.
9351 Jeronimo Road
Irvine, CA 92618-1904
Telephone: [phone]
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursu-
ant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interfer-
ence in a residential installation. This equipment gener-
ates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television recep-
tion, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
the receiver.
- Connect the equipment into an outlet on a circuit dif-
ferent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV techni-
cian for help.
Changes or modifications not expressly approved by
Mitsubishi could cause harmful interference and would
void the user’s authority to operate this equipment.
The lightning flash with arrowhead symbol within
an equilateral triangle is intended to alert the
user of the presence of uninsulated “danger-
ous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral tri-
angle is intended to alert the user to the presence
of important operating and maintenance (servic-
ing) instructions in the literature accompanying the product.
Please refer to the Basic Owner’s Guide for the 742 Series and 842 Series Television and use the
instructions about the 742 Series for:
1. Connection information
2. Important Safety Instructions.
3. Setup and Operating instructions.
4. Care and Cleaning instructions.
5. Lamp Replacement Instructions.
6. Troubleshooting hints.
7. Software License Agreements,TV Warranties and Internet Applications Policy.
For assistance call 1(800) 332-2119
Note: Features and specifications described in this
owner’s guide are subject to change without notice.

3D DLP
® HOME-CINEMA TELEVISION
MODELS
742 Series
842 Series
BASIC OWNER’S GUIDE
®
This manual provides basic connection, setup, and operating instructions. For use of additional fea-
tures of this television, please visit our website at www.Mitsubishi-tv.com to view or download a sup-
plemental Owner’s Guide. Follow the Support link to the Product Documents page.
tFor questions:
- Visit our website at www.mitsubishi-tv.com.
- E-mail us at [e-mail].
- Call Consumer Relations at 800-332-2119 for operational or connection assistance.
tFor information on System Reset, please see the back cover.
tTo order replacement or additional remote controls, visit our website at www.mitsuparts.com or call
800-553-7278.

2
For assistance call 1(800) 332-2119
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING: To reduce the risk of fire or electric shock,
do not expose this apparatus to rain or moisture.
This apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such as
vases, shall be placed on the apparatus.
En français
Cet appareil ne doit pas être exposé à des gouttes ou
à des éclaboussures et aucun objet rempli d’un liquide,
comme un vase, ne doit être placé sur l’appareil.
WARNING: This product contains chemicals known
to the State of California to cause cancer and/or birth
defects or other reproductive harm.
TV WEIGHT: This TV is heavy. Exercise extreme care
when lifting or moving it. Lift or move the TV with a
minimum of two adults. To prevent damage to the TV,
avoid jarring or moving it while it is turned on. Always
power off your TV, unplug the power cord, and discon-
nect all cables before moving it.
CAUTION: When selecting a stand, base, or other furni-
ture to support the TV, please make sure it is designed with
the appropriate dimensions for stability and to support the
TV’s weight plus the weight of any additional equipment
you plan to store.
Custom cabinet installation must allow for proper
air circulation around the television.
MAINS DISCONNECTION: The mains plug is used
as the disconnect device. The mains plug shall remain
readily operable.
FCC Declaration of Conformity
Product: Projection Television Receiver
Models: WD-73742, WD-82742, WD-92742
WD-73842, WD-82842, WD-92842
Responsible
Party:
Mitsubishi Electric Visual Solutions
America, Inc.
9351 Jeronimo Road
Irvine, CA 92618-1904
Telephone: [phone]
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursu-
ant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interfer-
ence in a residential installation. This equipment gener-
ates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television recep-
tion, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
the receiver.
- Connect the equipment into an outlet on a circuit dif-
ferent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV techni-
cian for help.
Changes or modifications not expressly approved by
Mitsubishi could cause harmful interference and would
void the user’s authority to operate this equipment.
The lightning flash with arrowhead symbol within
an equilateral triangle is intended to alert the
user of the presence of uninsulated “danger-
ous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral tri-
angle is intended to alert the user to the presence
of important operating and maintenance (servic-
ing) instructions in the literature accompanying the product.
Note: Features and specifications described in this
owner’s guide are subject to change without notice.

3
For assistance call 1(800) 332-2119
Contents
Important Safety Instructions ................ 5
1 Basic Setup and Operation
Package Contents ....................... 6
Installing the Remote Control Batteries......... 6
TV Overview ........................... 6
Before You Begin ........................ 6
Remote Control ......................... 7
First-Time Power-On ...................... 8
Setting Up and Using TV Inputs .............. 8
Basic TV Operation...................... 10
TV Menus ............................ 12
2 TV Connections
Before You Begin ....................... 13
Connection Types and Audio/Video Quality .... 13
Input and Output Jacks................... 14
Connection Diagrams .................... 14
3 TV Features
StreamTV™ Internet ..................... 18
3D Video ............................. 21
Wireless Audio Playback (842 Series) ......... 24
Sound Projector (842 Series) ............... 25
Appendices
Appendix A: Auto Input Sensing ............ 28
Appendix B: Lamp-Cartridge Replacement .... 29
Appendix C: Troubleshooting .............. 31
Mitsubishi TV Software.................... 34
Warranty .............................. 40
MEVSA Internet Applications Policy .......... 42
TV Software
tDo not attempt to update the software of this TV
with software not provided by or authorized by
Mitsubishi Electric Visual Solutions America, Inc.
Non-authorized software may damage the TV and
will not be covered by the warranty.
tAutomatic software updates will be downloaded
over the Internet to the TV if StreamTV is set up and
connected to the Internet.
Cleaning Recommendations
Normally, light dusting with a dry, non-scratching
duster will keep your TV clean. If cleaning beyond this
is needed, please use the following guidelines:
First, turn off the TV and unplug the power cord from
the power outlet.
Occasionally clean dust build-up from the air-intake
grilles on the back and sides of the TV. Clean using a
vacuum cleaner with a brush attachment.
Top and Sides of the TV
tGently wipe down your TV with a soft, non-abrasive
cloth such as cotton flannel, microfiber, or a clean
cloth diaper, lightly moistened with water. Dry with
a second dry, soft, non-abrasive cloth.
tFor oily dirt, add a few drops of mild liquid deter-
gent, such as dishwashing detergent, to the water
used to moisten the cloth. Rinse with a second
cloth moistened only with water. Dry with a third
dry, soft, non-abrasive cloth.
Screen
tFollow the instructions for the top and sides, wiping
gently in an up and down motion.
tClean the entire screen evenly, not just sections of
the screen.
tDo not allow liquid to drip down the screen, as
some liquid may enter the TV through the gap
between the screen and screen frame.
tYou may purchase Mitsubishi Screen Cleaner,
part number CLEANER-VSS, by calling
1 [phone].
General Cleaning Precautions
tDO NOT allow liquid to enter the TV through the
ventilation slots or any crevice.
tDO NOT use any strong or abrasive cleaners, as
these can scratch the surfaces.
tDO NOT use any cleaners containing ammonia,
bleach, alcohol, benzene, or thinners, as these can
dull the surfaces.
tDO NOT spray liquids or cleaners directly on the
TV’s surfaces.
tDO NOT scrub or rub the TV harshly. Wipe it
gently.

4
For assistance call 1(800) 332-2119
Mitsubishi Electric Visual Solutions
America and the Environment
As part of its ongoing environmental efforts, Mitsubishi
Electric Visual Solutions America, Inc. (MEVSA) joined
the Electronic Manufacturers Recycling Management
Company’s (MRM) national recycling initiative. Your
MEVSA TV can be recycled at no charge to the con-
sumer through MRM’s growing infrastructure of drop-
off locations around the United States.
We encourage all of our customers to recycle their
used electronics. All waste computer monitors, por-
table computers, digital picture frames, televisions,
portable DVD players, desktop printers, VCRs, and
video game consoles should be recycled.
For a listing of MRM recycling drop-off locations,
please visit www.MRMrecycling.com. MRM can also be
reached toll free at 1-888-769-0149
For more information about Maine’s electronic waste
law, please visit the Maine Department of Environmen-
tal Protection website at www.maine.gov/dep/rwm/
ewaste/index.htm.
For other states please check your state or local gov-
ernment web sites for more information about local
laws and recycling options.
Lamp Replacement
For lamp-replacement instructions, see Appendix B.
To Order a Replacement Lamp Under Warranty
Call [phone]. Please have model number, serial
number, and TV purchase date available.
To Purchase a Replacement Lamp After Warranty
Visit our website at www.mitsuparts.com or call
[phone]. Order new lamp part number
915B455012.
Children and TV Viewing
The American Academy of Pediatrics discourages
media use by children younger than two years. For more
information, visit www.aap.org.

5
For assistance call 1(800) 332-2119
NOTE TO CATV SYSTEM INSTALLER: THIS REMINDER IS
PROVIDED TO CALL THE CATV SYSTEM INSTALLER’S ATTEN-
TION TO ARTICLE 820-40 OF THE NEC THAT PROVIDES
GUIDELINES FOR THE PROPER GROUNDING AND, IN PARTIC-
ULAR, SPECIFIES THAT THE CABLE GROUND SHALL BE CON-
NECTED TO THE GROUNDING SYSTEM OF THE BUILDING, AS
CLOSE TO THE POINT OF CABLE ENTRY AS PRACTICAL.
Important Safety Instructions
Please read the following safeguards for your TV and
retain for future reference. Always follow all warnings
and instructions marked on the television.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are
provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart,
stand, tripod, bracket,
or table specified
by the manufacturer,
or sold with the
apparatus. When
a cart is used, use
caution when moving
the cart/apparatus
combination to avoid
injury from tip-over.
13) Unplug this apparatus
during lightning storms or when unused for long
periods of time.
14) Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
ANT E NNA
LE AD IN W IR E
ANT E NNA
DIS C HAR G E U NIT
(NE C AR T IC L E 810-20)
G R O UNDING
C O ND UC T O R S
(NE C AR T IC L E 810-21)
G R O UND C LAMP S
P OW E R S E R V IC E G R OU NDING
E LE C TR ODE S Y S T E M
(NE C AR T 250, P AR T H)
G R O UND C LAMP
E LE C TR IC
S E R V IC E
E Q UIP ME NT
NE C — NAT IONAL E LE C T R IC AL C ODE
E XAMP LE O F ANT E NNA G R O UNDING
Outdoor Antenna Grounding
If an outside antenna or cable system is connected
to the TV, be sure the antenna or cable system is
grounded so as to provide some protection against
voltage surges and built-up static charges.
Replacement Parts
When replacement parts are required, be sure the
service technician has used replacement parts speci-
fied by the manufacturer or have the same character-
istics as the original part. Unauthorized substitutions
may result in fire, electric shock or other hazards.
To avoid the risk of injury to the eyes and face, do not
look directly into the air vents while the television is
operating.
To avoid the risk of fire, do not use flammable solvents
(such as benzene or paint solvents) or flammable aero-
sols (such as polishes, cleaners, or insecticides) near
the television while it is operating or cooling.

6
For assistance call 1(800) 332-2119
Basic Setup and Operation
1
Installing the Remote Control
Batteries
1. Remove the remote control’s back cover by
gently pressing in the tab and lifting off the cover.
2. Load the batteries, making sure the polarities
(+) and (-) are correct. For best results, insert
the negative (-) end first.
3. Snap the cover back in place.
2
1
The remote
control
requires two
AA batteries.
Package Contents
Please take a moment to review the following list of
items to ensure that you have received everything.
TV Overview
Remote
Control
AA
AA
Two AA
Batteries Basic
Owner’s
Guide
Quick
Setup
Guide
Product
Registration
Card
Before You Begin
1. Review the important safety, installation, and oper-
ating information at the beginning of this book.
2. Choose a location for your TV.
t"MMPXBUMFBTUGPVSJODIFTPGTQBDFPOBMMTJEFTof the TV to help prevent overheating. Over-
heating may cause premature failure of the TV.
t"WPJEMPDBUJPOTXIFSFMJHIUNBZSFGMFDUPGGUIFscreen.
3. Install the batteries in the remote control.
4. Plug the TV into an AC power outlet.
(120 V AC, 60 Hz)
TV Control Panel
Buttons on the control panel duplicate some keys on
the remote control.
To display the main menu, press INPUT and VOL+ simul-
taneously for about 10 seconds. Press and hold INPUT
and VOL+ for 10 seconds to clear the menu.
System Reset
If the TV fails to respond to the remote control, the
control-panel buttons, or will not power on/off, perform
System Reset. Press and hold the POWER button on the
control panel for ten seconds.
Sample TV controls and
location of the STATUS
indicator. See page 33.
Connection
Jacks Lamp-Compartment
Door

1. Basic Setup and Operation 7
For assistance call 1(800) 332-2119
Remote Control
Aim the remote control at the TV screen. The
TV can detect control signals over the entire
screen area.
Powers TV on or off.
Number/letter keys
Channel tuning, page 9
Pass-code entry
TOOLS key shortcuts
Sleep Timer. Automatically turns off
the TV after the number of minutes
you set.
GUIDE
Navigates through VUDU Apps, page
20.
INFO
TV status or TV help
( PAUSE )Freezes a broadcast TV picture
from the ANT (antenna) input.
Playback controls for StreamTV Internet
services. May apply to compatible devices
under HDMI control. See the supplemental
Owner’s Guide at www.mitsubishi-tv.com
for setup of HDMI control.
MUTE
Mutes the TV speakers.
TOOLS
Displays shortcuts for the number keys.
Press to check if shortcuts are available
for the current device.
VOL Controls volume of TV speakers.
CH
PAGE
Changes channels; moves to another
page in a menu or list.
Adds a separator in digital channel
numbers. Clears some menu entries.
AUDIO
Audio settings
VIDEO
Video settings
MENU
Displays or clears the TV
main menu (page 12). Also
steps back one menu.
EXIT
Clears all menus and on-
screen displays.
LAST
Returns to the previous channel.
In menus, steps back one
menu.
ENTER
Selects a channel number or menu item.
Navigation and adjustment controls
FAV
Displays up to nine favorite
sources.
FORMAT
Changes picture shape,
page 11.
INTERNET
Connects to the Internet
content, page 18.
INPUT
Press to select a TV input,
page 9.
F1–F4. Function keys for some
StreamTV Internet services.
Mitsubishi iPhone App
Visit the iTunes store for a free app
that turns your Apple iPhone, iPad,
or iTouch into a second remote
control for the TV.
The TOOLS Key and Menu
Press the TOOLS key to see the Tools menu. Press
number keys to activate shortcuts. Your Tools menu
may differ from the sample, depending on your setup.
tShortcuts specific to the current device are in the
third column.
tShortcuts may be available for a CEC-enabled
device. See the supplemental Owner’s Guide at
www.mitsubishi-tv.com.
Device-Specific Shortcuts
Availability varies, depend-
ing on equipment features
and setup.
3 CC. Turns closed cap-
tions on/off ( ANT and Y
composite inputs only)
PICTURE SOUND
TV
Picture shortcuts
Sound shortcuts
Sample Tools menu, 842 series

81. Basic Setup and Operation
For assistance call 1(800) 332-2119
1. Install batteries in the remote control. See page 6.
2. Aim the emitter (bulb) end
of the remote control at the
TV and press the POWER key
.Wait for the Welcome
screen.
3. If you wish to change the
menu language to Español,
press then ENTER .
4. Press to move to the
energy-mode selections.
Select Home.
5. Press to highlight EXIT.
Press ENTER to clear the menu.
First-Time Power-On
Setting Up and Using TV Inputs
Welcome Screen Energy Options
tMitsubishi recommends the Home setting,
which produces a picture suitable for home
viewing and uses less power.
tThe Retail setting looks best under the bright
lighting often found in commercial settings. In
this mode, the TV uses more power than when
in the Home setting.
This table compares energy choices offered in the
Welcome screen.
Home Retail
Picture Mode Bright
Brilliant
Lamp Energy Standard Bright
tUse the Picture > Video menu to change the
Picture Mode.
tUse the Setup > Energy menu to change
Lamp Energy.
Setting the lamp mode to Standard may extend the
life of the lamp.
The ANT (Antenna) Input
If using an antenna or direct cable service (no cable
box), connect the incoming coaxial cable to the TV’s
ANT input. Refer to page 16.
You must perform a channel scan to enable recep-
tion of digital channels. If you skip this step, the TV
can receive only analog channels. The channel scan
will search for high-definition and standard-definition
channels available in your area. Note: Direct cable
service will not include scrambled or premium chan-
nels.
Memorizing Channels with Channel Scan
1. Power on the TV.
2. Press MENU and open the Setup > Channel menu.
Start channel memorization from the Setup > Channel
menu.
3. Press to enter the menu.
4. Highlight Ant Air if connected to an
over-the-air antenna. Highlight Ant
Cable for service over direct cable
(no cable box). Press ENTER to add a
check.
5. Select the scan type.
tFor first-time setup, highlight All channels.
tTo scan for channels not already in memory,
highlight Add only new channels. Press
ENTER to add a check.
6. Highlight Scan and press ENTER .
Channel memorization may take up
to 15 minutes to complete.
To stop channel memorization before completion,
press CANCEL . The channels already memorized
before cancellation remain in the memory.
At any time after Channel Scan,
tUse the Setup > Channel > Edit menu to add or
delete individual channels from memory.
tRepeat the All channels scan if you reposition the
antenna or move the TV to a new geographic area
with a different channel line-up.

1. Basic Setup and Operation 9
For assistance call 1(800) 332-2119
Setting Up Inputs with Auto Input Sensing
Connection information starts on page 13. Learn more
about Auto Input Sensing on page 28.
1. Power on the TV.
2. Power on the devices to ensure detection.
3. Connect one device to the TV, making note of the
TV input jack.
The TV will display the New Device Found screen if
the connection type is detectable.
4. Highlight the device type in the on-screen list and
press ENTER . The name you select here will appear
in the Input Selection menu.
Sample New Device Found screen.
5. Press EXIT to close the New Device Found screen.
6. Repeat the preceding steps for each additional
device you want to add.
Setting Up and Using TV Inputs, continued
More About the Input Selection Menu
t5PBTTJHOIFMQGVMOBNFTUPUIFJDPOTTFFUIFInputs > Name menu.
t5PSFNPWFVOXBOUFE"OUFOOBBluetooth®, or HDMI
device icons from the Input Selection menu, see
the Inputs > Name menu.
t5PSFBSSBOHFUIFJDPOTVTFUIFInputs > Order
menu.
Detailed information on using these menus
is in the supplemental Owner’s Guide at
www.mitsubishi-tv.com.
Selecting an Input to Watch
1. Press INPUT .
2. Press and to highlight an
input icon.
Sample Input Selection menu, DVD input selected
3. Press ENTER to switch to the input.
Note: In most cases, to see a named icon for a con-
nected device (as in the samples), you must first
assign a name:
t8IFOUIFEFWJDFJTGJSTUDPOOFDUFEBOEUIFNew Device Found menu offers a choice
of names.
t#ZVTJOHUIFInputs > Name menu to
assign or change a name at any time after
the TV has detected the connection.
Watching Broadcast TV
TV Connected to an Antenna or Direct Cable
Service (no cable box)
Note: Perform channel memorization to enable recep-
tion of digital channels. See page 8.
1. Press INPUT to display the Input Selection menu.
2. Highlight the antenna or cable icon and press ENTER .
Sample Input Selection menu, antenna input selected
3. To tune to a channel from the ANT input, use any of
these methods.
tEnter the channel number using the number
keys on the remote control and press
ENTER
.
For a two-part digital channel, such as 3-1,
press
3
—
CANCEL
1
ENTER
.
tPress
CH
to change channels one channel at
a time.
tPress and hold
CH
to speed through channels.
tPress
LAST
to return to the previous channel.
tUse the Fav (Favorites) feature to tune to up to
nine favorite channels. See the supplemental
Owner’s Guide at www.mitsubishi-tv.com.

10 1. Basic Setup and Operation
For assistance call 1(800) 332-2119
Basic TV Operation
Picture Settings
To get the best picture under different viewing condi-
tions, set the Picture Mode first before changing other
video settings.
1. Press VIDEO.
2. Press until the Picture Mode
option displays.
3. Press to make one of these selections:
Name When to Use
Brilliant Under very bright lighting
Game With gaming consoles (inputs
named Game or PC only)
Bright For most daytime viewing
Natural For most nighttime viewing
4. Press to display the name of another adjustment.
5. Press to make the adjustment.
6. Wait a few seconds and the display will clear.
More picture adjustments can be found in these menus:
ōPicture > Video
ōPicture > Picture Plus
ōPicture > 3D Mode
ōPicture > Perfect (842 Series only)
Audio Controls
Controlling Sound Volume
Press VOL to adjust the sound level of
the TV speakers.
Changing Audio Settings (TV Speakers Only)
1. Press AUDIO .
2. Press to display the name of the
adjustment you want.
3. Press to change.
Using an External Sound System
To switch from the internal TV speakers to an external
sound system:
1. Press AUDIO .
2. Press to display the TV Speakers option.
3. Press to select either On (to hear sound from the
TV speakers) or Off (to hear sound from an external
sound system).
See page 17 for suggestions on connecting your sound
system to the TV.
Disconnecting an A/V Receiver
When you disconnect an A/V receiver, change the TV
Speakers setting to On to hear sound from the TV
speakers. Use the Sound > Audio > TV Speakers
menu.
HDMI Control (CEC-Enabled HDMI A/V Receiver)
The TV’s remote control may control some functions of
the A/V receiver. See the supplemental Owner’s Guide
at www.mitsubishi-tv.com.

1. Basic Setup and Operation 11
For assistance call 1(800) 332-2119
Basic TV Operation, continued
The FORMAT Key and Picture Shape
Important
Black bars at the edges of the
screen are common in HD pictures.
Black bars are not a defect of the
TV.
tBroadcasters add black bars to fill
the 16:9 screen area while pre-
serving the original aspect ratio
of older material not created for
modern HD TVs.
tYour cable box, satellite receiver,
or other device may also have
controls for altering the shape
of the broadcast picture. If your
device offers output in native
format, try using it with the TV
picture formats.
Sample Uses of the FORMAT Key
You can use the FORMAT key to display the image as originally intended or
to reduce or eliminate black areas at the edges.
Press
High-definition signal with
squarish 4:3 image embedded.
The image is narrower than the
16:9 screen; unused areas at
the sides are filled with black.
Wide Expand mode stretches
the picture sideways to fill the
screen.
Press
Standard 2.35:1 anamorphic
DVD image; unused areas at
the top and bottom are filled
with black (letterbox effect).
Zoom mode. The picture fills
the screen. All four edges are
cropped in this mode.
Press the FORMAT key
t o cycle through picture
shapes for the current
image. The TV will
remember the format you
last used on each input.
For more on TV formats and signal
types, see the supplemental Owner’s
Guide at www.mitsubishi-tv.com.
More TV Features
See the supplemental Owner’s Guide at
www.mitsubishi-tv.com for more on these and other
topics.
tParental controls (Lock menu). Requires first setting
a pass code.
tTV Clock (Setup > Clock menu). Set the TV Clock
if you plan to use the TV Timer or the TV’s Lock by
Time feature.
tChanging input names in the Input Selection menu
(Inputs > Name menu) tHDMI control of other A/V devices (CEC)
tUsing the TV with a computer
tAdditional Stream TVTM features
t842 Series. Using the TV speakers for center
channel sound for your external surround sound
system.
t842 Series. Adding external rear speakers to
complement the TV’s surround sound effect
t842 Series. Using an external subwoofer

12 1. Basic Setup and Operation
For assistance call 1(800) 332-2119
Video Basic picture settings
Picture+ Specialized picture controls
Reset Reset of sound and picture adjust-
ments for the current input
Perfect
842 Series. Fine-tuning of color settings
Advanced Highly customized picture adjust-
ments for each input. Mitsubishi
recommends these adjustments be
made only by a trained professional
installer.
3D Mode
Setup for 3D viewing. See page 21.
Sound
Audio Basic audio settings
842 Series. Also includes subwoofer
and center-channel controls.
Global
842 Series. Settings for the AVR/REAR
OUTPUT jack.
Auto SP
842 Series. Sound Projector settings.
See page 25.
SoundPro
Captions
Settings for closed captions
Setup
Language Menu language
Clock Set the TV clock to use the TV Timer or
to lock the TV by time.
Timer Setup for the TV Timer. The Timer tells
the TV to power on automatically at a
time you set. Set the TV clock before
using the TV Timer.
Channel Setup for a channel scan on the
ANT
input; addition to or deletion of chan-
nels from TV memory
Energy Controls for TV energy usage
TV Menus
Network Setup for the Internet connectivity. See
page 18.
Inputs
Name Name assignments for TV inputs
HDMI
Control
Setup for HDMI Control (CEC) of exter-
nal devices
Order Setup of icons in the Input Selection
menu
StreamTV Account deactivation; clears your per-
sonal data from the TV.
Demo Demonstrations of selected TV features
Update Instructions for updating TV software.
Lock
Parental Controls to limit TV use by content
ratings (composite video and antenna
inputs only)
Time Setup to lock the TV by time of day.
Set the TV clock before using this
menu.
Channel Setup to lock specific channels
(antenna input only)
Panel Control-panel lock
Other Controls to limit TV use based on rating
systems that may come into effect
in the future (digital channels on the
antenna input only)
Press MENU on the remote control to open
the main menu. Find detailed descriptions
of all menus in the supplemental Owner’s
Guide at www.mitsubishi-tv.com.

13
For assistance call 1(800) 332-2119
2TV Connections
Auto Input Sensing
The TV’s Auto Input Sensing feature automatically rec-
ognizes many connections and prompts you to identify
the type of device connected. See pages 9 and 28 for
more on Auto Input Sensing.
Connection Types
Use the connection types available on your input
devices that will give the best video quality. For
example, choose HDMI over component video; choose
component video over composite video.
Picture Quality
For best picture quality, route signals directly from the
source device to the TV.
Surround Sound
The TV accepts PCM stereo or Dolby Digital 5.1 over
the ANT and HDMI inputs and passes the audio out on
the DIGITAL AUDIO OUTPUT jack.
IMPORTANT
Accessories such as cables, adapters, splitters,
or combiners required for TV connections
are not supplied with the TV. These items are
available at most electronics stores.
Before You Begin
Connection Types and Audio/Video Quality
Component
GOODBEST GOODBEST
VIDEO QUALITY AUDIO QUALITY
DVI-to-HDMIHDMI Video Video
Composite L/R Analog Stereo
Mini
Plug
AudioCoaxial Audio
Digital
HDMI
High-definition or standard-definition video Dolby Digital 5.1,
PCM 2.0 (stereo) Stereo only
Standard-definition
video only
HDMI Cable Categories
HDMI cables are available as Standard and High-Speed types.
tHigh-Speed HDMI Cables. Blu-ray players, newer DVD
players, video games, 3D content, and set-top boxes
require High-Speed HDMI cables, suitable for clock
frequencies up to 340 MHz or data rates of up to 10.2
gigabits per second. Use high-speed cables for 1080p
HD signals carrying extended color encodings (i.e., 30 or
more bits, also called Deep Color). High-Speed HDMI
cables are also suitable for standard HDTV signals.
tStandard HDMI Cables. Standard HDMI cables may be
unmarked. They are suitable for standard HDTV 720p,
1080i, and 1080p signals with 8-bit color depth. Use
Standard HDMI cables for clock frequencies up to 74.25
MHz or data rates of up to 2.23 gigabits per second.

14 2. TV Connections
For assistance call 1(800) 332-2119
Input and Output Jacks
L Calibration
Microphone
(optional)
Input
(842 series,
page 25)
USB/USB-P
tThe left USB port can
accept a wireless network
adapter . See page 19.
t842 Series. The right
USB port can power a TV
accessory such as a wire-
less subwoofer.
DVI/PC
INPUT
Audio
input
(page 16)
DIGITAL
AUDIO
OUTPUT
(page 17)
Y
Composite
video input
(page 16)
Y Pb Pr
Component
video input
(page 15)
ANT
Coaxial antenna
input
(page 16)
3D
GLASSES
EMITTER
(page 21)
21 3 4
3D
GLASSES
EMITTER
ANT
HDMI
L
R
DIGITAL
AUDIO
OUTPUT
AUDIO/SURROUND
-OUTPUT-
RL
LANUSB-P
CENTER
INPUT
SUB WOOFER
OUTPUT
LAN
(Ethernet, port
page 18)
AUDIO/SURROUND OUTPUT
CENTER INPUT
SUBWOOFER OUTPUT
See the Supplemental Owner’s Guide at
www.mitsubishi-tv.com for use of these jacks.
t
The le
acce
adap
t
842 Se
USB
acce
less
HDMI-4 offered
on the 842 series.
L/R
Analog stereo
audio inputs
HDMI
(page 14, page 17)
Inputs are HDMI
HDCP compliant.
H DMI Device
Examples: HDTV Cable Box, Satellite Receiver,
or DVD/Blu-ray Player
Required: HDMI cable.
Connect an HDMI cable from the TV to the device’s
HDMI output. HDMI-connectable devices provide
video and audio through a single cable.
Mitsubishi recommends using high-speed HDMI cables
to connect newer devices incorporating HDMI technol-
ogy. See “HDMI Cable Categories” on the previous page
for more on HDMI cable types.
Note:
tThis connection carries high-definition video,
3D video, and Dolby Digital 5.1 audio signals.
tThis connection supports copy protection
(HDCP).
3D
GLASSES
EMITTER
ANT
DIGITAL
AUDIO
OUTPUT
AUDIO/SURROUND
-OUTPUT-
RL
LAN
CENTER
INPUT
SUB WOOFER
OUTPUT
USB-P
1234
HDMI
L
R
3D
GLASSES
EMITTER
DIGITAL
AUDIO
OUTPUT
AUDIO/SURROUND
-OUTPUT-
R
L
CENTER
INPUT
SUB WOOFER
OUTPUT
1
2
3
4
HDMI
L
R
R
1234
HDMI
HDMI
cable
TV jack panel
Any device with
HDMI output
CABLE IN or
SATELLITE IN
Incoming from
cable service or
satellite dish
Connection Diagrams
AUDI
Additional jacks
offered on the
842 series.

2. TV Connections 15
For assistance call 1(800) 332-2119
Pb
Y
Pr
AUDIO
L
R
3D
GLASSES
EMITTER
ANT
DIGITAL
AUDIO
OUTPUT
AUDIO/SURROUND
-OUTPUT-
RL
LAN
CENTER
INPUT
SUB WOOFER
OUTPUT
USB-P
1234
HDMI
L
R
3D
GLASSES
EMITTER
ANT
DIGITAL
AUDIO
OUTPUT
AUDIO/SURROUND
-OUTPUT-
R
L
LAN
CENTER
INPUT
SUB WOOFER
OUTPUT
USB-P
1
2
3
4
HDMI
L
R
R
TV jack panel
L
R
L
R
DIGITAL
AUDIO
OUTPUT
DIGITAL
AUDIO
OUTPUT
Incoming from
cable service or
satellite dish
Component
video cables
Component
video device
Audio
cables
CABLE IN or
SATELLITE IN
Y Pb Pr Component Video Device
Examples: HDTV Cable Box, Satellite Receiver,
or DVD/Blu-ray Player
If your source device has an HDMI output, use the con-
nections for an HDMI device described on the previous
page instead of component video.
Required:
Component video cables
RCA-type analog audio cables
Note:
tThis connection carries high-definition video
signals.
tTo hear digital surround sound from an A/V
receiver, connect the digital audio output from the
device directly to your digital A/V receiver.
VCR or DVD Recorder to an
Antenna or Wall Outlet Cable
Required:
tVideo cables
- Component video cables (red/
blue/green)
or
- Composite video cable (usually
yellow)
tRCA-type analog audio cables
tTwo-way RF splitter
tTwo coaxial cables
Note: t6TFDPNQPTJUFWJEFPPOMZif component video or
HDMI are unavailable. A
composite video connection
cannot carry high-definition
video signals.
t*GZPVSSFDPSEJOHEFWJDFIBTan analog-only tuner, you
must use a digital converter
box to enable recording of
digital broadcasts.
AUDIO OUT COMPOSITE
VIDEO OUT
COMPONENT
VIDEO OUT
L
R
3D
GLASSES
EMITTER
ANT
DIGITAL
AUDIO
OUTPUT
AUDIO/SURROUND
-OUTPUT-
RL
LAN
CENTER
INPUT
SUB WOOFER
OUTPUT
USB-P
1234
HDMI
L
R
3D
GLASSES
EMITTER
ANT
DIGITAL
AUDIO
OUTPUT
AUDIO/SURROUND
-OUTPUT-
R
L
LAN
CENTER
INPUT
SUB WOOFER
OUTPUT
USB-P
1
2
3
4
HDMI
L
R
R
ANT
L
R
DIGITAL
AUDIO
OUTPUT
DIGITAL
AUDIO
OUTPUT
ANT
L
R
ANTENNA
IN
or
TV panel
Incoming
cable
RF
Splitter
DVD Recorder
or VCR
Composite video cable
Component
video cables
Audio
cables

16 2. TV Connections
For assistance call 1(800) 332-2119
DVI OUT
3D
GLASSES
EMITTER
ANT
DIGITAL
AUDIO
OUTPUT
AUDIO/SURROUND
-OUTPUT-
RL
LAN
CENTER
INPUT
SUB WOOFER
OUTPUT
USB-P
1234
HDMI
L
R
3D
GLASSES
EMITTER
ANT
DIGITAL
AUDIO
OUTPUT
AUDIO/SURROUND
-OUTPUT-
R
L
LAN
CENTER
INPUT
SUB WOOFER
OUTPUT
USB-P
1
2
3
4
HDMI
L
R
R
1234
HDMI
TV panel
Digital DVI
device
DVI-to-HDMI
cable
Audio cable
AUDIO
OUT
DVI Video Device
Examples: Computer or Older A/V Device
Note:
t5IJTDPOOFDUJPODBODBSSZIJHIEFGJOJUJPOWJEFPsignals.
t5IF)%.*DPOOFDUJPOTVQQPSUTDPQZQSPUFDUJPO(HDCP).
Connect a DVI device (digital only) to one of the TV’s
HDMI input jacks.
Required:
Audio cable with stereo mini-plug
DVI-to-HDMI cable or DVI/HDMI adapter and HDMI
cable
Some devices require a connection using an analog
output first in order to view on-screen menus and to
select DVI as the output. Please review your equipment
instructions for DVI connectivity and compatibility.
Antenna or Cable TV Service
Connect the incoming cable to the TV’s ANT input.
Reception over direct cable (no box) is limited to non-
scrambled analog and digital channels.
IN OUT
3D
GLASSES
EMITTER
ANT
DIGITAL
AUDIO
OUTPUT
-OUTPUT-
RL
LAN
CENTER
INPUT
SUB WOOFER
OUTPUT
USB-P
1234
HDMI
L
R
3D
GLASSES
EMITTER
ANT
DIGITAL
AUDIO
OUTPUT
LAN
CENTER
INPUT
SUB WOOFER
OUTPUT
USB-P
1
2
3
4
HDMI
L
R
R
ANT
ANT
Cable
TV
service
UHF/VHF
antenna
TV panel
Not recommended. Other
connection types provide better
quality audio and video.
Direct cable (no cable box)
or
or
Older
cable
box
Composite Video Device
VCR or other device with composite video
output
Note: This connection does not support high-defini-
tion video signals.
Required:
Composite video cable (usually yellow)
RCA-type analog audio cables
3D
GLASSES
EMITTER
ANT
DIGITAL
AUDIO
OUTPUT
-OUTPUT-
RL
LAN
CENTER
INPUT
SUB WOOFER
OUTPUT
USB-P
1234
HDMI
L
R
3D
GLASSES
EMITTER
ANT
DIGITAL
AUDIO
OUTPUT
-OUTPUT-
R
L
LAN
CENTER
INPUT
SUB WOOFER
OUTPUT
USB-P
1
2
3
4
HDMI
L
R
R
TV jack panel
L
R
L
R
DIGITAL
AUDIO
OUTPUT
DIGITAL
AUDIO
OUTPUT
AUDIO OUT
COMPOSITE
VIDEO OUT
L
R
Audio
cables
VCR or other device
with composite
video output
Composite
video cable

2. TV Connections 17
For assistance call 1(800) 332-2119
A/V Receiver
Most setups require either a digital audio cable or
analog stereo audio cables. To send audio from TV
channels received on the ANT input or devices con-
nected directly to the TV, you must use one of the con-
nections shown below.
The TV makes all incoming audio available as an output:
tAnalog incoming audio is available as output in
digital stereo format on the DIGITAL AUDIO OUTPUT
jack. 842 Series. Analog incoming audio is also
available as analog stereo on the AUDIO/SUR-
ROUND OUTPUT jacks.
tDigital incoming audio is available as digital audio
on the DIGITAL AUDIO OUTPUT jack. 842 Series.
Digital incoming audio is also available as analog
output on the AUDIO/SURROUND OUTPUT jacks.
See page 10 for tips on using an external sound system.
3D
GLASSES
EMITTER
ANT
DIGITAL
AUDIO
OUTPUT
AUDIO/SURROUND
-OUTPUT-
RL
LAN
CENTER
INPUT
SUB WOOFER
OUTPUT
USB-P
1234
HDMI
L
R
3D
GLASSES
EMITTER
ANT
DIGITAL
AUDIO
OUTPUT
AUDIO/SURROUND
-OUTPUT-
R
L
LAN
CENTER
INPUT
SUB WOOFER
OUTPUT
USB-P
1
2
3
4
HDMI
L
R
R
DIGITAL
AUDIO
OUTPUT
AUDIO/SURROUND
-OUTPUT-
RL
AUDIO/SURROUND
-OUTPUT-
RL
DIGITAL
AUDIO
OUTPUT
OPTICAL
INPUT
OPTICAL
INPUT
COAXIAL
INPUT
842 Series
only
or
TV
A/V receiver back panel
Note: On rare occasions, an HDMI signal may be
copy-restricted and cannot be output from the
TV as a digital signal. To hear these copy-pro-
tected signals through the A/V receiver, use the
connection for an analog A/V receiver.
tCheck the A/V receiver’s Owner’s Guide for
information on use of the digital input and
switching between digital sound and analog
stereo sound from the TV.
A/V Receiver with HDMI Output
Required: One HDMI cable
This option allows you to view and hear content from
devices connected to an A/V receiver. The A/V receiver
can send audio and video to the TV over a single HDMI
cable.
You can add an optional audio connection from the
TV’s audio output. The optional audio connection
allows you to hear, through the A/V receiver, devices
connected to the TV only, e.g., an antenna on the ANT
input.
See page 10 for tips on using an external sound system.
VCR
Cable
box
DVD
player
If your A/V receiver converts
all video signals for output
on HDMI, you can use any
connection types from
external devices; content
can be HD or SD video.
HDMI OUT
DIGITAL
AUDIO IN
ANALOG AUDIO IN
LR
3D
GLASSES
EMITTER
ANT
DIGITAL
AUDIO
OUTPUT
AUDIO/SURROUND
-OUTPUT-
RL
LAN
CENTER
INPUT
SUB WOOFER
OUTPUT
USB-P
1234
HDMI
L
R
3D
GLASSES
EMITTER
ANT
DIGITAL
AUDIO
OUTPUT
AUDIO/SURROUND
-OUTPUT-
R
L
LAN
CENTER
INPUT
SUB WOOFER
OUTPUT
USB-P
1
2
3
4
HDMI
L
R
R
DIGITAL
AUDIO
OUTPUT
DIGITAL
AUDIO
OUTPUT
AUDIO/SURROUND
-OUTPUT-
RL
AUDIO/SURROUND
-OUTPUT-
RL
TV
HDMI
cable
Optional
analog or
digital audio
connection

18
For assistance call 1(800) 332-2119
TV Features
3
StreamTV™ Internet
About StreamTV
Internet services let you access many popular on-line
applications providing both free and paid content.
This section describes using VUDU Movies and VUDU
Apps. For additional Stream TV features, see the sup-
plemental Owner’s Guide at www.mitsubishi-tv.com.
Required for StreamTV Internet media:
tBroadband Internet service (at least 2 Mbps for SD,
4 Mbps for HD, and 8 Mbps for 1080p HDX)
tCategory-5 Ethernet cable or a wireless router
transmitting to an AzureWave AW-NU231 USB wire-
less adapter.
tComputer access to the websites of content provid-
ers when initial account activation is required for
service.
tA credit card to cover the cost of paid content.
2. Open the Setup > Network menu to review set-
tings.
Setup > Network, DHCP connection
3. Press
EXIT
to clear the menu.
4. Press the INTERNET key on the remote control to
begin using this feature.
Manual
Note: Manual setup is available only for a wired con-
nection.
1. Connect the TV to your network router with a Cat-
egory-5 Ethernet cable (not supplied).
2. In the Setup > Network menu, highlight Manual
and press
ENTER
.
3. Press to move to the Connection Data area.
4. Input the connection data.
5. After entering connection data, press
ENTER
to
connect.
6. Change any of the following if needed:
tDefault Gateway
tDNS
tSubnet Mask
Home Network Setup
Before using StreamTV Internet media, you must
connect the TV to the Internet using either an Ethernet
cable or a wireless connection as described here.
Note: Make sure the TV is on any input other than
Bluetooth® . Press the INPUT key to change.
Wired Ethernet Connection
DHCP (automatic)
1. Connect the TV to your network router with a Cat-
egory-5 Ethernet cable (not supplied).
3D
GLASSES
EMITTER
ANT
AUDIO
OUTPUT
LAN
CENTER
INPUT
SUB WOOFER
OUTPUT
USB-P
1234
HDMI
L
R
3D
GLASSES
EMITTER
ANT
OUTPUT
LAN
CENTER
INPUT
SUB WOOFER
OUTPUT
USB-P
1
2
3
4
HDMI
L
R
R
LAN
LAN
Ethernet
cable
Router or modem
providing high-speed
internet service
Incoming
internet
cable
TV Panel
