MIXHITS AUDIO MRT-60AP User manual

Please follow the instructions in this manual to obtain the optimum results from this unit.
We also recommend that you keep this manual handy for future reference.
OPERATION MANUAL
MRT-60AP
MRT-120AP MIXER
AMPLIFIER
ON
OFF
MIC1
INPUT
BASS TREBLE
MIC1 MIC2 MIC3 AUX1 AUX 2 TEL MASTER
POWER
2
PROTTEMP
46810 12
OUTPUT LEVEL
MIXER AMPLIFIER
T-120AP
AUDIO

TABLE OF CONTENTS
1. SAFETY PRECAUTIONS .......................................................................................3
2.
T-60AP-120AP MIXER AMPLIFIER........................................................................5
2

Be sure to read the instructions in this section carefully before use.
Make sure to observe the instructions in this manual as the conventions of safety symbols and messages
regarded as very important precautions are included.
We also recommend you keep this instruction manual handy for future reference.
Safety Symbol and Message Conventions
Safety symbols and messages described below are used in this manual to prevent bodily injury and property
damage which could result from mishandling. Before operating your product, read this manual first and
understand the safety symbols and messages so you are thoroughly aware of the potential safety
Indicates a potentially hazardous situation which, if mishandled, could
result in death or serious personal injury.
Indicates a potentially hazardous situation which, if mishandled, could
result in moderate or minor personal injury, and/or property damage.
When Installing the Unit
•Do not expose the unit to rain or an environment
where it may be splashed by water or other liquids,
as doing so may result in fire or electric shock.
•Use the unit only with the voltage specified on
the unit. Using a voltage higher than that which is
specified may result in fire or electric shock.
•Do not cut, kink, otherwise damage nor modify the
power supply cord. In addition, avoid using the
power cord in close proximity to heaters, and never
place heavy objects including the unit itself on the
power cord, as doing so may result in fire or electric
shock.
•Be sure to replace the unit's terminal cover after
connection completion. Because high voltage is
applied to the speaker terminals, never touch these
terminals to avoid electric shock.
•Be sure to ground the safety ground (earth)
terminal to avoid electric shock. Never ground to a
gas pipe as a catastrophic disaster may result.
• Avoid installing or mounting the unit in unstable
locations, such as on a shaky table or a slanted
surface. Doing so may result in the unit falling
down, causing personal injury and/or property
damage.
When the Unit is in Use
Should the following irregularity be found during
use, immediately switch off the power, disconnect
the power supply plug from the AC outlet and
contact your Mixhits Audio dealer. Do not attempt to
operate the unit in this condition as this may cause
fire or electric shock.
•If you detect smoke or an odor from the unit.
•If water or any metallic object gets into the unit
•If the unit falls, or the unit case breaks
•If the power supply cord is damaged.
•If it is malfunctioning (no sound.)
• To prevent a fire or electric shock, never open or
remove the unit case as there are high voltage
components inside the unit. Refer all servicing to
your Mixhits Audio dealer.
•Do not place cups, bowls, or other containers of
liquid or metallic objects on top of the unit. If they
accidentally spill into the unit, this may cause a fire
or electric shock.
•Do not insert or drop metallic objects or flammable
materials in the ventilation slots of the unit's cover,
as this may result in fire or electric shock.
1. SAFETY PRECAUTIONS
3

An all-pole mains switch with a contact separation of at least 3 mm in each pole shall be incorporated in
the electrical installation of the building.
When Installing the Unit
•Never plug in nor remove the power supply
plug with wet hands, as doing so may cause
electric shock.
•When unplugging the power supply cord, be sure
to grasp the power supply plug. Never pull on the
cord itself. Operating the unit with a damaged
power supply cord may cause a fire or electric
shock.
•When moving the unit, be sure to remove its
power supply cord from the wall outlet. Moving the
unit with the power cord connected to the outlet
may cause damage to the power cord, resulting in
fire or electric shock. When removing the power
cord, be sure to hold its plug to pull.
•Do not block the ventilation slots in the unit's
cover. Doing so may cause heat to build up inside
the unit and result in fire.
• Avoid installing the unit in humid or dusty
locations, in locations exposed to the direct
sunlight, near the heaters, or in locations
generating sooty smoke or steam as doing
otherwise may result in fire or electric shock.
When the Unit is in Use
•Do not place heavy objects on the unit as this
may cause it to fall or break which may result in
personal injury and/or property damage. In
addition, the object itself may fall off and cause
injury and/or damage.
•Make sure that the volume control is set to the
minimum position before the power is switched on.
Loud noise produced at high volume when power is
switched on can damage hearing.
•Do not operate the unit for an extended period of time
with the sound distorting. This is an indication of a
malfunction, which in turn can cause heat to generate
and result in a fire.
•If dust is allowed to accumulate in the unit over a
long period of time, a fire or damage to the unit
may result. Contact your Mixhits Audio dealer to
schedule a cleaning of the unit.
•If dust accumulates on the power supply plug or
in the wall AC outlet, a fire may result. Clean it
periodically. In addition, insert the plug in the wall
outlet securely.
•Switch off the power, and unplug the power
supply plug from the AC outlet for safety
purposes when cleaning or leaving the unit
unused for several days. Doing otherwise may
cause a fire or electric shock.
4
SAFETY PRECAUTIONS

1. FEATURES
1. Rated Power:60W /120W.
2. 100V / 70V constant voltage outputs and 4~16Ohms constant resistance output.
3. Commercial-grade torroidal transformers produce high performance audio on a wide range of
frequencies with min noise and high fidelity, even at high volume.
4. Reliable protection against overload, short ciruit, and power fluctuation for optimum
reliability.
5. VOX feature mutes AUX inputs when input is detected on MIC 1. Time Adjust control allows
resumption of music to be sharp or gradual.
6. Phantom power available on MIC 1 input for condenser-type microphones.
7. TELpriority:Tel overridesAux1-2 and MIC(2-3)
5

2.1 60W/120W FRONT PANEL
1. MIC1 INPUT
MIC1 input 1/4" Microphone jack input
2. MIC1 \MIC2 \MIC3
MIC volume control (MIC1/MIC2/MIC3)
3. AUX1 \AUX2
AUX volume control(AUX 1/AUX 2)
4. TEL
TEL volume control
5. BASS
Adjust bass response. Rotate clockwise to increase
bass output and anticlockwise to reduce it.
6. TREBLE
Adjust treble response. Rotate clockwise to increase
treble output and anticlockwise to reduce it.
7. MASTER
Master volume control
8. POWER SWITCH
Push up for power on and down for power off.
2. FUNCTIONS
9. POWER
Power indicator
10. LEVEL INDICATORS
Level meters 6 output level indicators
11. PROT
When the Mixer/Ampl is in protection
status, this indicator will be lit: in normal
operation status, the LED is off. If the
product is in protection status due to
overheating, overload or direct current, the
indication LED will be lit while the output
relay will be disconnected. (Signal
indicator is just used to indicate the use of
input music signal. In the protection status,
signal indicator is still lit according to the
size of input signal.)
12. TEMP
Temperature Indicator
6
ON
OFF
MIC1
INPUT
BASS TREBLE
MIC1 MIC2 MIC3 AUX1 AUX2 TEL MASTER
POWER
2
PROTTEMP
46810 12
OUTPUT LEVEL
9
8
23457
6
10
1211
1

FUNCTIONS
2.2 60W/120W REAR PANEL
13.~ 120 Volt 60Hz POWER INPUT
14. SPEAKER TERMINALS
Connectors for 4-16 ohms or 70V and 100V
speaker
15. Mute adjustor
Adjust the mute level from 0-
20dB when MIC1 input overridesall
the other inputs.
16. MIC input with phantom power
MIC1 input compatible with XLR or
1/4" connector.
17.Phantom power button switch
18.(MIC 2/MIC 3) MIC input
MIC2/3 1/4" inputs
19.TEL INPUT
20.(AUX 1/AUX 2) AUX input
AUX 1/2 Line level input
21.Line output
Connect to other audio processing
equipments
7
14
13 15 16 18 19 20 21
17
MIC2 MIC3
MUTE
G
TEL INPUT AUX2AUX1
LINE
OUT
MIC 1
XLR/6.30 INPUT
BAL/UNBAL PHANTOM
OUTPUTS
COM 4-16 70V 100V
COM COM

70V 100V
COM 4-16 70V 100V
COM 4-16
(T-60AP)
167
100V LINE
70V 100V
COM 4-16
(T-60AP)
81
70V LINE
3.1 SPEAKER CONNECTIONS
4.2 XLR CONNECTIONS
4-16
3. CONNECTIONS
70V/
8
(T-120AP)
41 (T-120AP)
83
Be sure to reattach the supplied terminal cover after connecting speakers to avoid
risk of shock. Never touch the terminals.

MUTE FUNCTION
1.Tel has priority over all inputs.
2.MIC 1 is secondpriority and can override all
other input signal except tel signal.
1. Check all inputs and
mute functions.
2. Incorrect speaker
connections.
OPERATIONWARNING
Do not use 70V/100V and the 4/16 ohm outputs at the
same time. The wattage sum off all speakers when using
70V/100V should never exceed the rated total watts of
the Mixer / Amp. It is strongly suggested to only utilize
85% of the rated power to allow for headroom.
BASIC TROUBLESHOOTING
No audio output in
normal condition
All the wires are
connected but no
sound output.
Cause
1.No power.
2.Fuse is blown.
3.Volume is to low.
4.No input signal
Power on but
protection is
illuminated.
1.Overloading or
short circuit.
2.Overheating
3. AC is too high or low
Problem
4. MACHINE OPERATION
9

5. APPLICATIONS
10
AUDIO
OUT
R
L
COM
ADRESS TAG
AUDIO SOURCES
LINK
INPUTS
XLR BAL
1-GND
2-HOT+
3-COLD
1
2
3
12
3
OUTPUTS
INPUTS
POWER AMPLIFIER
SPEAKERS
MIC 2MIC1
MIC 3
TEL INPUT
MIC2 MIC3
MUTE
G
TEL INPUT AUX2AUX1
LINE
OUT
MIC 1
XLR/6.30 INPUT
BAL/UNBAL PHANTOM
OUTPUTS
COM 4-16 70V 100V
COM COM

6. BLOCK DIAGRAM
70V
COM
4
TO
PA
BASS/TREBLE
VOLUME
PROTECT
LEVEL INDICATOR
POWER
Z ~220-240V 50/60Hz
PT
COM
100V
COM
EB
EB
LINE
OUT
MIC1
MIC1
MIC2
MIC3
AUX1
AUX2
TEL
MUTE
MUTE
11

7. SPECIFICATIONS
MIXER MIXER AMPLIFIER
Model MRT-120AP
12
MRT-60AP
Speaker Line Input
Rated Power Output
Input sensitivity/impedance
S/N
Frequency response(At 1KHz Half power output,+3dB)
MIC 1~2 input section(CH1~2 in@1Khz, preamp out)
Input sensitivity/impedance
S/N
Tone control(Bass:100KHz,Treble:10KHz)
Phantom power
AUX 1 input section(AUX in@1Khz, preamp out)
Input sensitivity/impedance
S/N
Frequency Response(+3dB)
Tone control(Bass:100KHz,Treble:10KHz)
Pre AmpOut
Total harmonic distortion
Line level output
Cooling mode
Power source
Power consumption
Net weight
Dimensions(mm)
4~16 ,70V,100V
MIC 1/2/3 5mV/600ohms
AUX:350mV/10Kohms
Better than 90dB
50Hz~18KHz
5mV/600ohms
Better than 62dB
+12dB
+48VDC
350mV/10Kohms
Better than 76dB
50Hz~18KHz
+12dB
5dBV/600ohms
Less than 0.3%
~10dB/3Kohms
Air cooling
110-120V 60Hz
200W
7.8Kg
484 x303x88
100W
6.7Kg
60W 120W

UNIT:Inches
8. DIMENSIONAL DIAGRAM
0.2
3.3
3.3
12
3.5
3.7
17
19
13
ON
OFF
MIC1
INPUT
BASS TREBLE
MIC1 MIC2 MIC3 AUX1 AUX2 TEL MASTER
POWER
2
PROTTEMP
46810 12
OUTPUT LEVEL
MIC2 MIC3
MUTE
G
TEL INPUT AUX2AUX1
LINE
OUT
MIC 1
XLR/6.30 INPUT
BAL/UNBAL PHANTOM
OUTPUTS
COM 4-16 70V 100V
COM COM
ON
OFF
MIC1
INPUT
BASS TREBLE
MIC1 MIC2 MIC3 AUX1 AUX2 TEL MASTER
POWER
2
PROTTEMP
46810 12
OUTPUT LEVEL

WARRANTY
VersionV1.3
This warranty protects you for a specific period (“Warranty Period”) from your date of purchase as stated in your bill of sale or as otherwise
established by Mixhits Audio. The specific Warranty Period is three years. Any warranty replacement parts or product will assume only the remainder
of the Warranty Period of the original product.
Except as otherwise stated in this policy, this warranty covers defects in materials and workmanship if: (1) you purchased this product from a dealer
that is a Mixhits Audio authorized dealer with respect to this product at the time of your purchase; (2) your original, dated bill of sale is presented
whenever warranty service is required during the warranty period; and (3) unless Mixhits Audio states otherwise, you purchased this product in brand
new condition.
This policy does not cover damage or loss: caused by accident (including force majeure or natural forces), misuse, abuse, neglect, product
modification; occurring during shipment (even when Mixhits Audio has arranged or paid for shipping); caused by failure to follow instructions in the
owner’s guide, including failure to perform recommended periodic or routine maintenance or improper maintenance; resulting from repairs by
someone Mixhits Audio did not authorize; to the decorative surface of this product; caused by using this product for other than its intended purpose,
or covered under any of your (or your installer’s) insurance policy or coverage. The following are also excluded from this warranty: claims based
upon any misrepresentations by the seller; if this product’s serial number has been altered, defaced or removed; deterioration of component parts,
the nature of which is to become worn or depleted with use, even if supplied by Mixhits Audio; any installation, removal or re-installation; any set-up
calibration or adjustment; any performance variations due to installation-related circumstances, such as program source quality or AC power
fluctuations.
If this product has a defect covered by this warranty, Mixhits Audio will, at its sole option, either: (1) repair this product at no charge to you, using new
or refurbished replacement parts, (2) exchange this product with a product that is new or which has been manufactured from new or serviceable
used parts and is at least functionally equivalent to this product, or (3) refund the purchase price of the product.
This warranty protects only the original end-user (“you”), and is not transferable. Any attempt to transfer this warranty shall immediately make this
warranty void. This warranty is valid only for Mixhits Audio Professional products, as listed above, purchased from authorized Mixhits Audio
Professional dealers within the fifty United States, and it does not apply to products purchased or transferred elsewhere. If you purchased this
product (or have subsequently transferred it) outside the fifty United States, you should contact your local Mixhits Audio distributor for warranty
information.
You are responsible for transporting your product to (as well as from, in the event that Mixhits Audio finds no defect covered by this warranty) either
Mixhits Audio or an authorized service center and for payment of all shipping charges; however, Mixhits Audio will pay the return shipping charges
(in the event you return the product to Mixhits Audio) if the repairs are covered by warranty, provided that, Mixhits Audio reserves the right to choose
the mode, the carrier and the timing of such return shipping (if Mixhits Audio finds that there are no defects covered by this warranty, then you shall
be responsible for all shipping charges). If you experience difficulty in transporting your product or are in need of packing materials, please advise us
and we may be able (but have no obligation) to suggest alternative procedures and/or provide adequate packing materials.
THIS WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, REMEDIES AND
CONDITIONS, WHETHER ORAL OR WRITTEN, EXPRESS OR IMPLIED. Mixhits Audio SPECIFICALLY DISCLAIMS ANY AND ALL IMPLIED
WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
IF MIXHITS AUDIO CANNOT LAWFULLY DISCLAIM IMPLIED WARRANTIES UNDER THIS LIMITED WARRANTY, ALL SUCH WARRANTIES,
INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED IN DURATION TO THE
DURATION OF THIS WARRANTY.
No Mixhits Audio reseller, agent, or employee is authorized to make any modification, extension, or addition to this warranty.
MIXHITS AUDIO IS NOT RESPONSIBLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING
FROM ANY BREACH OF WARRANTY OR CONDITION, OR UNDER ANY OTHER LEGAL THEORY, INCLUDING BUT NOT LIMITED TO LOST
PROFITS, DOWNTIME, GOODWILL, DAMAGE TO OR REPLACEMENT OF ANY EQUIPMENT OR PROPERTY, ANY COSTS OF RECOVERING,
REPROGRAMMING, OR REPRODUCING ANY PROGRAM OR DATA STORED IN OR USED WITH Mixhits Audio PRODUCTS. Mixhits Audio’S
TOTAL LIABILITY IS LIMITED TO THE REPAIR OR REPLACEMENT OF THIS PRODUCT OR TO THE ORIGINAL PURCHASE PRICE
PURSUANT TO THE TERMS OF THIS WARRANTY.
SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES OR EXCLUSIONS OR
LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES OR CONDITIONS, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT
APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY BY
STATE OR (WHERE APPLICABLE IN THE COUNTRIES WHERE Mixhits Audio HAS NON-US/CANADIAN AUTHORIZED DEALERS) COUNTRY.
NO ACTION OR CLAIM TO ENFORCE THIS WARRANTY SHALL BE COMMENCED AFTER THE EXPIRATION OF THE WARRANTY PERIOD.
This manual suits for next models
1
Table of contents
Other MIXHITS AUDIO Amplifier manuals
