Mixx xBoost2 Administrator Guide

xBoost2
Wireless Party Speaker
HOW TO GUIDE

LET’S CHECK
What’s in the box?
xBoost2 Wireless Party Speaker
3.5mm
AUX to AUX Cable
Micro USB
Charging Cable
Mains Charge
Adapter

+
LET’S START
Control panel
Power Button
Play / Pause Button
Mode Button
Volume Down / Previous Button
Volume Up / Skip Button
Weather door cover
USB Port
LED Light
AUX Port (3.5mm)
Micro USB Charging Port (DC 5V)
Micro SD Card Port
1 2 3 4 5 6
1
2
3
4
5
6
7
8
9
10
11
7
11 10
8 9

LET’S POWER
LET’S SELECT A MODE
ON/OFF - Press and hold the Power Button until you hear
‘Power on/Power off’ and the LED Light will flash BLUE quickly.
There are four modes in which you can listen to your playlist.
1. Let’s Pair via Bluetooth
2. Let’s Play using a USB Stick*
3. Let’s Play using a Micro SD Card*
4. Let’s Go Wired using the AUX Port
* The Micro SD Card and the USB Stick are not included.
1
8
3

LET’S PAIR
Via Bluetooth
The first time you pair with the MIXX xBoost2 Wireless Speaker,
press and hold the Power Button until you hear ‘Power on,
pairing’ and the LED Light will flash BLUE quickly.
Go to the Bluetooth settings on your audio device and select
‘MIXX xBoost2’ from the list.
Once paired successfully your speaker will say ‘Connected’
and the LED Light will flash BLUE slowly.
You can now enjoy your music.
Your speaker will say ‘Connected’ when it automatically
reconnects to the last audio device it was paired with.
NOTE: In Bluetooth mode you can use the either your audio
device or the control panel on the MIXX xBoost2 speaker to
control your music.
1
8
8

LET’S PLAY
Using a USB stick*
Power on your speaker and insert your USB stick into the audio
input USB Port 7 . You should hear a ‘beep’ as confirmation.
Your music will begin to play automatically from your USB stick
and the LED Light will flash BLUE slowly.
Power off your speaker before you remove your USB stick.
* The USB stick is not included.
Using a Micro SD card*
Power on your speaker and insert your micro SD Card into the
audio input Micro SD Card Port . Push in the SD card so that
it locks into place. You should hear a ‘beep’ as confirmation.
Your music will begin to play automatically from the micro SD
card and the LED Light will flash BLUE slowly.
Power off your speaker before you remove your micro SD card.
Simply push in the SD card and it will release from the Micro SD
card Port .
* The Micro SD Card is not included.
7
8
11
11
8

NOTE: The speaker will switch from Bluetooth to Play mode when you
insert either the micro SD card or a USB stick into their relevant audio
input ports.
It will then automatically play your playlist from your media source.
You can short press the Mode Button at any time to return to
Bluetooth mode.
Power on your speaker, then using the 3.5mm AUX to AUX Cable supplied
insert it in to the audio input AUX Port . The speaker will confirm
with a ‘beep’. Now connect to an audio device* such as, a smartphone,
laptop, iPod or MP3 player with a 3.5mm output AUX socket.
The xBoost2 will automatically switch to AUX mode. This is the default
mode as long as the 3.5mm AUX to AUX Cable is connected.
Under AUX mode, all control functions can be controlled by the external
audio device that it is connected to.
NOTE: You cannot change play modes while using the AUX Port. You will
need to disconnect the AUX cable to revert back to Bluetooth.
* The audio device with 3.5mm audio socket is not included.
LET’S GO WIRED
3
9

LET’S CHARGE
Insert the Micro USB Charging Cable supplied into the Micro USB
Charging Port (DC 5V) and connect it to a suitable USB wall
charger (using the Main Adapter Charger included), USB port or
a power bank to begin charging your xBoost2.
While charging, the LED Light will remain RED and then switch
off when fully charged.
CONTROL FUNCTIONS
First time Press and hold theButton until you hear
pairing ‘Power on, pairing’. Select ‘MIXX xBoost2’ from the
Bluetooth menu of your audio device.The speaker
will confirm with ‘Connected’.
Play/Pause Short press the Button
Volume Up / Long press the / Buttons to adjust the volume
Down
Skip / Previous Short press the / Buttons to change tracks
Tracks
Power ON/OFF Press and hold the Button
10
8

It’s important that you read this section
completely, especially the ‘Warnings,
Caution and Safe Usage’ instructions.
For your protection
Ensure the product is correctly
connected using the manufacturer’s
original accessories included.
Please keep the product out of reach
from children and animals.
Do not listen to loud music for a long
duration of time. Adjust the volume
to a comfortable level before listening.
Do not use the product while operating
machinery, including cars.
Do not use in areas where the use of
hearing is required for safety.
Do not drop, short circuit, disassemble
or continue to use the product if
damaged.
We recommend
To refer all servicing to qualified
persons. Servicing may be required
when the product has been damaged in
any way, does not operate normally or
has been dropped.
The operating temperature range for
this product is 5°- 40° Celsius.
WARNING
The speaker, the 3.5mm AUX cable
connectors and micro USB charging
cable connector are not water resistant.
They should not be exposed to rain,
moisture, any splashing or liquid spills.
This may cause excessive heat and can
lead to fire damage or personal injury.
CAUTION: This product contains a
lithium battery. Incorrect disposal may
result in an explosion.
LET’S BE SAFE

LET’S RECYCLE
This product can be recycled.
Products bearing this symbol must NOT be thrown away
with normal household waste.
Take the product to a collection point designated for recycling
of electronic devices.
Find out more about return and collection points through your
local authority.
CONTACT US
Feedback is welcome simply email us on [email protected]
or visit mixxaudio.com for more information.

TECHNICAL SPECIFICATIONS
Product dimensions 297 x 127 x 141mm (L x W x H)
Audio inputs Bluetooth Version: V5.0+BR+EDR+BLE
Micro SD card port
USB audio port
3.5mm AUX port
Play time Up to 7 hours play at 50% volume level
Speaker configuration 4” full range speakers x2
Power supply 5V DC micro USB
Bass reflex port Yes
Output 9.5W, 4Ω
Frequency response 130Hz - 13kHz

XBS2 - HTG01
SAFE USAGE INFORMATION
Do not crush, puncture or incinerate the speaker
or the accessories that came with this product.
Only use a certified or device manufacturer’s cable.
[email protected]
mixxaudio.com
@
MIXX Limited
5 The Pavilions, Brighton Road, Pease Pottage,
West Sussex, RH11 9BJ. United Kingdom
