ML Knightsbridge LEDAMP Instruction Manual

1
57
INSTALLATION & MAINTENANCE MANUAL
LEDAMP
IP
20
12/24
VDC

LEDAMP
These instructions should be read carefully and retained after installation by the end user for future reference and
maintenance.
These instructions should be used to aid installation of the following product:
LEDAMP
SAFETY
•Installation of this product should only be carried out by a qualified electrician or competent person to the
latest Building and current IEE Wiring Regulations (BS7671)
•Please isolate mains prior to installation/maintenance
•Check the total load on the circuit (including when this amplifier and LED load is fitted) does not exceed the
rating of the circuit cable, fuse or circuit breaker
•Please note the IP (Ingress of Protection) rating of this product when deciding the location for installation
•This unit is rated at IP20
•This product is Class II and does not require an earth
•This product is a subsidiary of LED lighting control system products and should be used in conjunction with
the RGB controller, RGB strip and power supply to enhance the system load ability
INSTALLATION
•Provide power to the required point of installation
•Connect the Amplifier to the circuit using the CONDC or wiring directly into + / - ensuring the correct polarity is
observed (see Fig 1)
Fig 1
2
These instructions should be read carefully and retained after installation by the end user for
future reference and maintenance.
These instructions should be used to aid installation of the following product:
LEDAMP
GENERAL INSTRUCTIONS
SAFETY
INSTALLATION
• Installation of this product should only be carried out by a qualified electrician or competent
person to the latest Building and current IEE Wiring Regulations (BS7671)
• Please isolate mains prior to installation/maintenance
• Check the total load on the circuit (including when this amplifier and LED load is fitted) does
not exceed the rating of the circuit cable, fuse or circuit breaker
• Please note the IP (Ingress of Protection) rating of this product when deciding the location for
installation
• This unit is rated at IP20
• This product is Class III
• This product is a subsidiary of LED lighting control system products and should be used in
conjunction with Knightsbridge LED Flex and power supply to enhance the system load ability
• Provide power to the required point of installation
• Connect the Amplifier to the circuit, via the 12V / 24V DC LED driver, using the CONDC or wiring
directly into + / - ensuring the correct polarity is observed (see Fig 1)
Fig 1

3
RGB Wiring diagram
RGBW Wiring diagram
Single colour LED flex wiring diagram
RGB Wiring diagram
RGBW Wiring diagram
Single colour LED flex wiring diagram
RGB Wiring diagram
RGBW Wiring diagram
Single colour LED flex wiring diagram
CCT LED Flex wiring diagram
•Depending on which type of LED strip is used, connect to the corresponding channels on the input side of the
amplifier using V+ as the common in as per wiring diagrams
•Connect a suitable LED load to the input and output side of the amplifier using V+ as the common out
•Switch on power supply and check for correct operation
WARNING
This product must be disconnected from the circuit if it subjected to any high voltage or insulation resistance testing.
Irreparable damage will occur if this instruction is not followed.
GENERAL
The unit should be recycled in the correct manner when it reaches the end of its life. Check local authorities for where
facilities exist.
WARRANTY
This product has a warranty of 1 year from date of purchase. Failure to install this product in accordance with the current
edition of the IEE Wiring Regulations, improper use, or removal of the batch codes will invalidate the warranty. If this
product should fail within its warranty period it should be returned to the place of purchase for a free of charge
replacement. ML Accessories does not accept responsibility for any installation costs associated with the replacement
product. Your statutory rights are not affected. ML Accessories reserve the right to alter product specification without prior
notice.
WARNING
This product must be disconnected from the circuit if it subjected to any high voltage or insulation
resistance testing. Irreparable damage will occur if this instruction is not followed.
• Depending on which type of LED strip is used, connect to the corresponding channels on the
input side of the amplifier using V+ as the common in as per wiring diagrams
• Connect a suitable LED load to the output side of the amplifier using V+ as the common out
• Switch on power supply and check for correct operation
GENERAL
The unit should be recycled in the correct manner when it reaches the end of its life. Check local
authorities for where facilities exist.

4
ML Accessories Limited
LU5 5TA
www.mlaccessories.co.uk SBDEC17_V1
WARRANTY
This product has a warranty of 1 year from date of purchase. Failure to install this product in
accordance with the current edition of the IEE Wiring Regulations, improper use, or removal of
the batch codes will invalidate the warranty. If this product should fail within its warranty period it
should be returned to the place of purchase for a free of charge replacement. ML Accessories does
not accept responsibility for any installation costs associated with the replacement product. Your
statutory rights are not affected. ML Accessories reserve the right to alter product specification
without prior notice.
