Mobile Warming MWV52 User manual
WWW.MOBILEWARMING.COM
FOLLOW US
12VOLT JACKETS AND VESTS
USER MANUAL
Welcome to Warmth.
Stay Warm, Stay Comfortable
Thank you for purchasing our battery powered Bluetooth® Performance
Heated Jacket or Vest. To ensure proper use and care of your garment and our
Mobile Warming batteries please read this user manual prior to use.
•One - 12v Heated Jacket or Vest
•One - 12v 5200 mAh Lithium-Ion batteries (Model#MWV52)
•One - 12v Single AC battery charger (Model# ASA16U17
Includes
Introduction
Patented Mobile Warming® technology is
specially engineered for cold environmental
conditions. Mobile Warming® comprehensive
heating solutions keep you warm and
comfortable. The exclusive Mobile Warming®
heating system utilizes F.I.R. (Far-Infrared) heat
and ultra-fine metal fiber heating elements
powered by lightweight, rechargeable, and
powerful Lithium-Ion batteries. As heat builds
Mobile Warming® advanced materials reflect
and direct heat back towards the body
ensuring that you stay warm. The combination of
unique materials, construction techniques, and
innovative design results in the most advanced
heated gear available.
REFLECTIVE LAYER
INSULATION LAYER
HEATED LAYER
F.I.R Technology
WWW.MOBILEWARMING.COM
WARNING
Only use the MW battery(s) provided with garment(s).
Only charge your battery with included compatible wall charger. Go to
www.mobilewarming.com/pages/battery-care for more information.
Do not attempt to disassemble or alter any part of this garment.
Do not store MW battery(s) below -4F(-20˚C).
Do not allow MW batteries or charger to come in contact with water or other
liquids. If water or other liquids enter the battery interior immediately unplug
the garment from the battery. Continued use of the garment may result in fire
or electrical shock.
Do not place this garment near a heat source or expose battery(s) to direct
flame or heat as the battery(s) may explode.
Disconnect MW battery pack from the garment(s) when not in use.
Garment(s) will discharge battery even when power is off.
•
•
•
•
•
•
•
Power Ratings Based on Fully Charged Battery and Ambient Temperature of 72°
135°F
(57.2°C)
2.8Hrs.
100%
120°F
(48.8°C)
3.5Hrs.
75%
105°F
(40.5°C)
5.5Hrs.
50%
90°F
(32.3°C)
11.0Hrs.
25%
WWW.MOBILEWARMING.COM
Battery Installation
12volt Jackets & Vests Heat Ratings
Use only
MWV52
Battery
3
4
Quick Start Guide
Do not use battery if you notice a
change of shape (lumps),
over-heating when charging or if
rust or corrosion on the battery
connectors is found.
Fully Charge battery to 100%.
Press and hold the power button on the battery for a few seconds. Once
it’s powered on LED will be Blue/100% heat.
Plug battery into the vest’s wire harness. Wire harness is located on the right
side pocket. (See drawing)
Slide battery into wire harness pocket. (See drawing)
Now that the battery is connected to jacket or vest, press and hold the
touch control button on for a few seconds. Once it’s powered on LED will
be Red/100% heat.
After the jacket or vest is on, push the control button to reach your desired
settings.
To power off jacket or vest, press and hold the touch control button until
light turns off. If you plan to not use the vest for more than a few days, unplug
battery from the jacket or vest.
1-
2-
3-
4-
5-
6-
7-
MW Connect App
MW Connect® Quick Start Guide
MW Connect® allows you to control Bluetooth®
—enabled Mobile Warming® garments with your
mobile device. MW Connect® App easily pairs and
syncs with your Mobile Warming garments. Through
the MW Connect® app you easily toggle through all
connected Mobile Warming® devices and adjust
individual heat levels to your liking. MW Connect®
allows you to get real time updates on battery levels,
register your product, and update your garments
when new firmware becomes available.
Go to the Apple App Store or Google play store and search “MW
Connect”.
Install the MW Connect® App. and enable Bluetooth on your mobile
device.
Power on 12v Jacket or Vest.
Launch the MW Connect® App. MW Connect will auto-scan for available
Mobile Warming Garments. MW Connect will list all available garments as
“Username.”
Select “Username.”
Rename “Username” to something unique to you, for example, “John’s Socks”
or “John’s Jacket.”
Select “Finish.” The pairing process is now complete and MW Connect will
store your garment’s information.
After you successfully pair, use MW Connect to remotely control heat
settings and monitor power levels to stay warm and comfortable for hours.
Free Download
1-
2-
3-
4-
5-
6-
7-
8-
WWW.MOBILEWARMING.COM
WWW.MOBILEWARMING.COM
Charging Instructions
To ensure the best battery performance and a
long battery life follow these steps. Battery Port
Charger Port
MWV52
12volt 5200mAh
Lithium-Ion
ASA16U17
• Output: 12.6v, 1.6A
• Input : AC 100v-240v
Replacement or additional batteries and chargers available at
www.mobilewarming.com
Plug Mobile Warming charger into AC wall
socket and connect battery(s) to AC charger
connectors.
When indicator light(s) are “Red” battery(s) are
charging.
When indicator light(s) turn “Green” battery(s)
are fully charged and ready for use or storage.
Always charge batteries indoors.
Always use Mobile Warming Chargers to charge
batteries. Failure to do so could result in bodily
injury, fire, or damaged batteries.
•
•
•
•
•
Always disconnect and remove MW battery(s) from the garment(s) power
lead wiring harness.
Do not machine tumble dry, iron, or dry clean.
Do not wring out the garment(s) as this may cause damage to the heating
elements and or wire harness.
Do not fully submerse in water or other liquids.
Please charge the battery fully before use.
If problems with the battery occurs refer to caution label marked on battery
case or contact us at www.mobilewarming.com
Care Instructions
•
•
•
•
•
•
CAUTION
•
•
It is important to maintain at least 25% of your battery power when
not in use. Failure to do so will result in performance issues and
reduced battery life. We recommend to charge your batteries every
3 months.
Recommended power settings of 50% is sufficient for temperatures
between 50°-64°F (10°-17.7°C) while at lower temperatures setting
the power at 75% or 100% is sufficient. It is not recommended to use
100% power setting for a long time as it may cause overheating and
/or bodily discomfort.
INPUT12.6V1.6A
OUTPUT9-12.6V MAX5A
USBOUTPUT
DC5VMAX2.1A
WWW.MOBILEWARMING.COM
Wash Instructions
•
•
•
Warranty Terms
*Our warranty applies only to the original purchaser and only for items purchased from an authorized
Mobile Warming Dealer or Authorized distributor retail partner.
Limited Two Year Warranty (Garment)
When you purchase a Mobile Warming brand product from an authorized Mobile Warming retailer
within the United States or Canada both the construction and electrical heating components of the
product are warranted to be completely free from factory defects in materials and workmanship for
two (2) year from the date of purchase. If any failure in the construction or the heating function of any
Mobile Warming product purchased from an authorized Mobile Warming dealer within the United
States and Canada occurs due to the manufacturer’s defect within two years of the purchase of the
product, the product will be repaired at no charge.*
90 Day Rechargeable Battery & Charger Warranty
Mobile Warming Gear rechargeable Lithium-ion battery packs and chargers are under warranty from
factory defect for 90 days from the initial purchase date. Mobile Warming will repair or replace any
battery or charger found to be defective under normal use within the 90 day warranty period.
*Costs associated with shipping the item in under warranty is the responsibility of the purchaser.
Warranty Exclusions
Any damage caused to any Mobile Warming products by misuse, abuse, improper care, accident,
normal wear and tear, use of non-mobile warming battery systems, and or the natural breakdown of
materials over an extended period of time and use are not covered in this warranty. Any alterations or
repairs (attempted or otherwise) performed on any Mobile Warming product voids any and all
warranties offered by Mobile Warming for that particular item. Mobile Warming products are technical
athletic apparel and is not intended for use as work wear or for use in strenuous or demanding
circumstances or extreme conditions.
How to initiate a Warranty Claim
First, please ensure that your product is covered under warranty according to the terms above. Then
simply have a digital copy of your dated proof of purchase ready and contact our friendly customer
for repair, briefly explaining the nature of your claim, with your dated proof of purchase attached. Our
customer service team will then follow up with you within two business days of receiving all of the
necessary information with an email containing a Return Authorization number, return instructions and
the return shipping address in order to return with your defective item.
Machine Wash Cold Only
Drip dry only. Do not machine dry.
Do Not Bleach. Do Not Iron, Do Not Dry Clean, Do Not Tumble Dry, Do Not Wring.
Duck Down Jackets and Vests
•
•
•
Hand Wash Only
Drip dry only. Do not machine dry.
Do Not Bleach. Do Not Iron, Do Not Dry Clean, Do Not Tumble Dry, Do Not Wring.
Softshell Jackets and Vests
To wash, disconnect the battery(s) from the power lead/wire harness, and
remove battery from garment(s).
