MobileDemand xTablet T7000 User manual

To ensure a proper connection
1. Cradle must be upright.
2. xTablet T7000 is secure in the cradle seat.
3. Top cradle latch is secured onto T7000.
4. Sliding lock mechanism pulled into place.
5. Key is turned to lock T7000 in place.
Right side view of xTablet T7000 locked into dock.
Care and Cleaning
Clean the surface contacts of the xTablet
T7000 every month or as needed if the contacts
seem overly tarnished or dirty.
Clean the docking surface contacts by using a
silver polish / cleanser wiped with a soft cloth.
Clean the gold contact pins of the cradle
communications module by using a soft
toothbrush to clean between the contact pins.
CAUTION: Do not use this computer system
while operating a motor vehicle.
WARNING: Use of this system while operating
a motor vehicle or heavy
equipment may be distracting,
dangerous, and prohibited based
on your location.
WARNING: Failure to pay attention to
operating the vehicle may cause
an accident resulting in serious
bodily injury and property damage.
4
To use this system safely, you must
Stop the vehicle in a safe location or have a
passenger use the system.
Safely operate the vehicle, obey all laws and
regulations, and use good judgment at all times.
User assumes sole responsibility for and all risks
in using this system.
Wiring Block Diagram
WIRE-KIT10
Grey main power cable
Fused adapter cable
Auxiliary power cable
AC power adapter and cable
DC power cable
Cable clamps
Find the latest updates in the Support section in the
MobileDemand website at: www.mobiledemand.com.
Questions? Call MobileDemand Support at 877-784-4338.
Copyright © 2010 MobileDemand, LC.
All Rights Reserved.
5
xTablet T7000
Vehicle Cradle
User Guide
Last Updated: August 11, 2011

Vehicle Cradle
The xTablet T7000 vehicle cradle mounts inside
a vehicle, is rugged, durable, and withstands
harsh user environments.
Vehicle Cradle with Communications Module
XTB-VMT5
Auto / Cigarette Lighter Adapter 500-104
Key Features
Sliding lock mechanism holds the xTablet
T7000 securely in the cab.
Adjustable for best visibility and use.
Integrated fans cool the xTablet T7000, turn off
when the lever arm is raised, and can be
manually turned off using a master fan switch.
Communications module provides charging
power and communications to peripherals and
other devices, such as printers.
Lever arm can also be used with tablets built
with integrated scanners.
Clear tubular stylus holder near the master fan
switch holds the stylus while the xTablet T7000
is secured in the cradle.
1
General Guidelines
A video version of this user guide is on the
MobileDemand website - tech support section.
Install the vehicle cradle in a non-obstructive,
safe location within the vehicle cab.
Avoid obstructing the following:
Vehicle operation
Visibility through windows
Safe entry or exit
Safety devices such as air bags
Firmly secure the cradle to stay in place despite
vibrations, shocks, bumps, or vehicle accidents.
The communications module on the cradle must
only be powered by the tablet auto / cigarette
lighter adapter.
Do not use this or any computer system while
operating a motor vehicle.
Using the T7000 Vehicle Cradle
You may want to store and charge the xTablet
T7000 in a vehicle cradle between stops.
To place the xTablet T7000 in the cradle
1. Turn the key counter-clockwise.
2. Pull the sliding lock mechanism away from the
grip to unlock the lever arm.
3. Carefully position the xTablet T7000 into the
communications module and let drop into
place.
Note: The communications module, with its
gold contact pins, is spring-loaded and sinks as
the xTablet T7000 is put in place. The spring
action of the module plus the spring-loaded
contact pins put force against the surface
contacts on the xTablet T7000 to ensure a
solid connection.
4. With your hand on the xTablet T7000, pull the
sliding lock mechanism firmly into place.
5. (Optional) Turn the key clockwise.
6. (Optional) Remove the key to fully secure.
2
To do electrical/communication connections
1. Using the tablet auto adapter, insert its
cigarette lighter connector end into the
bottom power socket on the right side of the
cradle. Use the top socket for other devices,
such as a cell phone.
2. Insert the other end of the tablet auto adapter
in the power connector on the bottom of the
communications module.
Note: The plug contains an 8-Amp, 3 AG fuse.
To replace this fuse when necessary
1. Unscrew the tip of the plug.
2. Remove the fuse from the plug.
3. Carefully insert the spare fuse – be
sure to keep its spring intact.
Note: The total current used must not exceed 8
Amps or you shorten the life of the plug.
The total current used by the vehicle
cradle, xTablet T7000, communications
module, and fans is about 4 Amps.
If you power another device with the other
socket, make sure the device does not
use any more than 2 Amps.
The last 2 Amps protect against surges.
To verify proper communication connections
When power is applied to the vehicle cradle, the
left LED lights a steady green. When the
xTablet T7000 is locked into the cradle, the right
LED blinks three times, then lights a steady
green.
The two green communications module LEDs
stay lit until either the xTablet T7000 is removed
from the cradle or until power is removed from
the communications module.
At the same time, the first LED indicator (power)
on the upper right corner of the xTablet T7000
display lights a steady green. This indicates that
the xTablet T7000 is correctly connected to data
and battery charge lines.
3 (OVER)
