MOHOC MHDBK User manual

QUICK START GUIDE

OVERVIEW
Included in the box:
•1 MOHOCTM camera
•1 Li-Ion Rechargeable battery
•1 Lanyard
•1 Micro USB cable
•2 VelcroTM mounting patches
•1 MOHOCTM microfiber bag
•1 MOHOCTM sticker
The MOHOCTM Camera
Door
Rotating lens barrel
CurvelockTM base
Latch release
Lower latch
Upper latch
ON/OFF/RECORD toggle
Photo button
Lens level indicators
Lanyard anchor points
1
2
3
4
5
6
7
8
9
10

9
9
3
OVERVIEW
2
3
4
5
6
7
1
8
6
5
10 10
10

3. Release the upper
latch and pull the door
upwards.
2. Pull the lower
latch out.
INSTRUCTION TO OPEN DOOR
1. Squeeze both
latch releases
4. The door is
now open.

MICRO SD & BATTERY INSERT
CR123 Battery
Insert 2 CR123 batteries
(positive terminals to
the right).
Sold separately.
Micro SD Card
Insert micro SD Card
(Class 10, UHS-1 or
higher required).
Sold separately.
Li-Ion Rechargeable
Battery
Insert rechargeable
battery and connect
micro USB to charge.

CAMERA OPERATION
Rotate Toggle to desired position:
ON, OFF, or Record
3. Turns camera OFF.
2. Powers ON in
standby mode.
1. Powers ON and
starts recording.
4. Photo Button:
With toggle in
either ON or
Record position
press the photo
button to capture
still images.

VIBRATION RESPONSE
Powers ON 3 Short Vibrations
(•••)
Starts Recording/
Photo taken
1 Short Vibration
(•)
Stops Recording 2 Short Vibrations
(••)
Powers OFF 1 Long Vibration
( ----)
WARNINGS* 5 Short Vibrations
(•••••)
*Open door and view display screen for
specific warning message

Changing Camera Settings
Turn Camera to ON position to change camera
settings. Open door and use display to view setting.
Press menu to scroll through the settings options.
Hold menu for 3 seconds to return to STANDBY.
CAMERA SETTINGS
Settings: 1080p/60fps, 1080p/30fps, 720p/120fps,
720p/60fps, 720p/30fps, 60 sec lapse,
30 sec lapse, 5 sec lapse, 1 sec lapse
ON or OFF
Menu/Back
Scroll Left
Scroll Right
Select

CAMERA SETTINGS
Press to see the following ADDITIONAL OPTIONS
OFF, 10 MINUTE, MAX
NORMAL, UPSIDE DOWN,
or AUTO ADJUST
ON or OFF
ON or OFF
Your MOHOCTM MODEL #
and SERIAL #, FACTORY RESET
SD CARD DETAILS, ERASE, or
FORMAT SD CARD
SET DATE and TIME
TURN ON DATE/TIME STAMP
Then returns to STANDBY.

CAMERA MOUNTING
Rotating Camera Lens
MOHOCTM lens rotates up to 180⁰. If required, rotate
lens barrel to maintain horizontal field of view. Use
level lens indicators as a guide.
Apply VelcroTM mounting patch to desired position
on helmet. Firmly attach MOHOCTM to VelcroTM
mounting patch.
