Molnija Chameleon User manual

CHAMELEON
PASSPORT

2
3
45
II III IVI
1. WINDING
Automatic winding
Constant arm movements cause the rotor to pivot and then the self-
winding mechanism sets the watch in motion.
Manual winding
When using the watch for the first time or if it has not been worn for a
long period, it is recommended to wind the watch 8-10 times, rotating
the winding crown clockwise. For future reference, you need to rotate
the winding crown 40 times in order to fully wind the watch manually.
The power reserve is approximately 42 hours. Stop rotating the crown
as soon as you feel any resistance.
Before setting the current time, date or manually winding the watch,
release the winding crown from the safe/screwed-down position.
In order to do so, you need to turn the crown several times in a
counterclockwise direction until you hear a gentle click, which will let
you know it is now in the unscrewed position for winding.
The Chameleon is a wrist watch that has an automatic movement.
1 – hour hand
2 – minute hand
3 – second hand
4 – date aperture
5 – screw-down winding crown
I – screwed-down position
II – winding crown unscrewed
III – position for setting the date,
winding crown pulled out to the
first click
IV – position for setting the time,
the winding crown is pulled
out fully
DESCRIPTION, FUNCTIONS AND DISPLAYS
1

2. SETTING THE CURRENT DATE
Pull the winding crown of the movement out into position III.
Turn the winding crown counterclockwise to set the current date.
3. SET THE CURRENT TIME
Pull the winding crown of the watch movement out to position IV.
Turn the winding crown counterclockwise to set the current time.
Push the winding crown back into its original position. The second
hand will start moving.
After setting the current date, the time and having wound the watch,
return the winding crown to the neutral position by pressing it in
towards the case and return it to the safe/screwed-down position by
rotating it clockwise. The watch is only guaranteed water resistance
at a depth of 100 m when the winding crown is in this position.
INSTRUCTIONS FOR USE, CARE AND STORAGE
1. WATER RESISTANCE
Chameleon watches have a water resistance of 10 atm, this
water resistant mark is conditional and denotes a pressure of 10
atmospheres. This watch will not be damaged by splashes or rain,
and you can wash your hands without taking it off. You can swim with
this watch and it can be submerged in water. However, these watches
are not suitable for scuba diving.
Over time, seals will age and become worn, which will have a negative
impact on the water resistance of the watch. We recommend that you
have the condition of the gasket examined and the water resistance
checked once a year at an authorized service center and have the
seal replaced if necessary.
ATTENTION: IF YOU CONTINUE TO WIND THE WATCH AFTER YOU HAVE
FELT RESISTANCE, YOU RUN THE RISK OF BREAKING THE TIP OF THE
SPRING. IF THIS OCCURS, THE BARREL WHERE THE MAINSPRING IS
WILL NEED TO BE REPLACED AT THE OWNER’S OWN EXPENSE.
Do not set the date between 21.00 and 01.00. This could damage
the watch movement. ATTENTION: PLEASE REMEMBER THAT YOU MUST NOT PULL THE
CROWN OUT WHEN THE WATCH IS WET.

2. CARE
We recommend that you clean the watch regularly (except for the
leather strap) with a soft cloth moistened with warm soapy water.
Never attempt to open the case or remove the back cover by yourself.
The rubber gasket protecting the watch from water and dust should
be replaced every 2-3 years.
If the inside of the watch gets wet, you should bring it to an authorized
service center to have it checked immediately.
Do not expose the watch to extreme temperatures.
Treat the watch with care and avoid any hard impact (bumps, falls,
etc.).
Do not fasten the strap too tightly. You should be able to slide a
finger between your wrist and the strap.
The watch should be stored in a dry place.
Do not let it come in contact with gasoline, cleaning solvents, spray
aerosols, adhesives, paint, etc. These substances cause chemical
3. PRECAUTIONARY MEASURES
reactions which could damage the gasket, case and the polished
surfaces of the watch.
Sapphire crystal is quite durable, but it may crack if the watch is
dropped or hit.
Avoid storing your watch with precious jewelry, as diamonds can
damage sapphire crystal.
It is preferable to store the watch in a special separate box, lined with
soft protective material.

TECHNICAL SPECIFICATIONS
Case diameter
Case material
Strap width
Type of glass
Movement
Accuracy
Number of stones applied
Power reserve
46 mm
316L Steel
22 mm
Sapphire crystal
Miyota 8215 automatic winding movement
-20 ...+40 seconds per day
21
42 hours
In accordance with the Decree of the Government of the Russian
Federation No. 471 from 27.05.2016 «On amendments to certain acts of
the Government of the Russian Federation on the return or exchange
of technically sophisticated goods», this product is categorised as
a technically sophisticated, and therefore, the buyer does not have
the right to demand a free replacement for the repair period or a
demand it be replaced with a similar product, and the buyer does
not have the right to return or exchange the product with similar
products of a different size, shape, different dimensions, style, colour
or configuration.
The warranty only applies to products purchased from authorized
sales outlets.
The manufacturer’s warranty is valid for one (1) year from the date
of sale of the product. The warranty covers defects and faults in
assembly materials. If a problem should arise during the warranty
period, the manufacturer shall rectify any defects or repair any
malfunctions absolutely free of charge. If the quality of the watch is
not able to be restored through repairs, the manufacturer guarantees
the replacement of the watch with the same watch or a model
WARRANTY

LIMITATIONS AND RESTRICTIONS
The warranty does not cover:
glass and strap;
wear and tear or defects resulting from the use of the watch (e.g.
scratches on the glass, changes in the colour and/or material of non-
metallic straps and bracelets, etc.));
any damage to any part of the watch resulting from improper use,
lack of care, or careless handling of the watch (bumps, chips, dents,
cracks, etc.).);
any unauthorized repair or the owner’s own tampering with the
design of the watch and/or its appearance automatically excludes
these watches from warranty service.
with identical specifications. Repairs should only be carried out at
authorized service centres. The contact details for authorized service
centres are provided by authorized sales representatives.
name of trading
organization
Address and phone
number
(trading organization)
All warranty claims for repairs must be accompanied by a warranty card
which has been filled out by both the buyer and the vendor who sold
the watch.
STAMP HERE
ATTENTION! THE WARRANTY CARD IS NOT VALID
WITHOUT THE VENDOR’S STAMP!
BUYER
I have read and agree with the terms of use. I do not
have any complaints regarding the appearance or the
performance of the watch.
WARRANTY CARD
VENDOR
SERIAL NUMBER
DATE OF SALE

Name of the authorized service centre
(Signature, full name)
(Signature, full name)
The following steps have been taken in troubleshooting:
Service centre employee
Owner
Date
Date
NOTES

NOTES
