momoDESIGN O.ME.R Umberto Pelizzari UP-X1 Installation and operation manual

General Guide
• Thank you for your purchase of this Watch.
• With this Watch, you can get your diving
information easily! In addition to the diving
function, this Watch can record your diving
information for your future review. Simply put on
the Watch with the Chest strap and dive with it,
the diving information like diving depth, diving
duration, water temperature, your heart rate and
etc. will be exhibited on the display and stored in
the watch! You can also use the USB connector
and the Diver Master to transfer all the Dive
records in the watch to your personal computer for
further storage and review.
• This Watch includes 6 functional modes; they are
Clock mode, Dive mode, Chronograph Mode,
Countdown Timer Mode, History Mode and Setup
Mode.
• Your watch is carefully designed and produced.
In order to utilize the features of your watch, it is
advisable to use the watch in conformity with the
notes mentioned below:
1.0 Introduzione
• Read this user manual carefully before you use the
Watch and keep this manual in a safe place for
future reference.
– Avoid exposing the Watch to extreme
conditions for an unreasonable time.
– Avoid rough usage or severe impacts on the
Watch.
– It is recommended to replace the battery by
a certified service agency because this watch
contains delicate electronic sensors and
components, and the water proof function and
standard can be maintained on your watch.
– Keep the Watch away from magnets
or appliances which contain magnetic
components such as mobile phones, speakers
or motors as these items may ruin the sensors.
– Clean the Watch occasionally with a soft cloth.
– DO NOT expose the Watch to strong
chemicals such as gasoline and alcohol as
they will damage the watch.

WARNING!
• Diving is one of the highest risk sports. Committing
a careless mistake may lead to serious injury or
fatal accident, hence safety is the first priority and
always remember that you are responsible for your
own safety.
• The Watch and the Chest Strap are a set of
supplementary devices for proper trained and
qualified divers in diving. They are NOT substitutes
for any professional diving or training gear.
1.0 Introduction
• Always get proper training, instruction and
qualification before starting diving. Make sure that
you fully understand the functions and limitations
of the Watch and you may have back-up devices
other than this watch in diving.
• DO NOT use the Watch for commercial or
professional purpose.

2.0 Buttons and Its Functions
Light
[ EL ]
Start/Stop
[ S/S ]
Mode
[ M ]
Lap/Reset
[ L/R ]
Sensors

2.1 Buttons and Its Functions
Mode [M]
• To select among the Clock, Dive, Chronograph, Timer, History and Setup modes, just press the [M] button until the
desired mode/icon appears on the screen and wait for 2 seconds, it will go to the main screen of the corresponding
mode automatically.
• To exit from the current status and return to the previous menu.
Start/Stop Button [S/S]
• To activate the ‘start’ or ‘stop’ chronograph function in the chronograph mode.
• To activate the ‘start’ or ‘stop’ timer function in the timer mode.
• To increase the value on the setting display or move up the cursor to the next item.
Lap / Reset [L/R]
• To activate the ‘lap’ or ‘reset’ chronograph function in the chronograph mode. To reset the Timer in the Timer mode.
• To decrease the value on the setting display or move down the cursor to the next item.
EL Button [EL]
• To turn on the EL back light for about 3 seconds. (Expect History mode & Setup mode)
• In History mode / Setup mode, hold [EL] for one second to turn on backlight.
• To select among the setting items on the setting display.
• To confirm the selected items on the setting display.
Sensors
• Sensors for the diving mode.
Note
NOTE: When you want to switch off the watch to the power down mode (the screen will be switched off – in this mode,
the clock is still running on the background), you simply press the [M] and [S/S] buttons simultaneously for 5 seconds in
Clock mode. To switch on the screen again, just press any key for 5 seconds, the screen will resume in normal status.

3.0 Major Function Modes
Clock Mode
Set Up Mode
Dive Mode
History Mode
Chronograph Mode
Countdown Timer Mode
[ M ] [ M ]
[ M ][ M ]
[ M ] [ M ]

4.0 Clock Mode
How to select the Current Time
• Select this mode by pressing the [M] button until
the CLOCK icon appears on the screen and wait
for 2 seconds, it will go to the Home time or Dual
time mode automatically.
• This watch has the Home time and Dual time
modes. You can select between these 2 modes by
pressing the [S/S] button in the Clock mode. When
you press the [S/S] button, the alternate display
will appear for 5 seconds and then return to the
original display. When the [S/S] button is pressed
and held for 2 seconds, the alternate display will
be kept as the current display.
Clock Mode
[ S/S]
Home Time Display Dual Time Display
Auto entry
after 2 seconds

Dual Time Display
4.1 Clock Mode - Dual Time Display
Dual Time Display
• The first row shows the name of this mode – DUAL
TIME mode.
• The second row shows the hour and minute of the
desired time zone.
• The third row shows the hour and minute of the
Home time with the “ ” icon.
1st row
2nd row
3rd row

5.0 Dive Mode
How to select the Dive Function
• Select this mode by pressing the [M] button until
the DIVE icon appears on the screen and wait for 2
seconds, it will go to the Dive mode automatically.
When the watch is in another mode, it will go to
the Dive mode automatically when the watch is
submerged in the water deeper than 1.0 meter
provided that the Dive mode setting has been
switched on (please check the chapter 9.1 setting
for details).
Dive Mode
[ S/S]
Depth Display Heart Rate Display
Auto entry
after 2 seconds

5.1 Dive Mode - Depth Display
Depth Display
• The first row shows either icon ‘ ’(Sea water) or
icon ‘ ’(Lake – fresh water) on the left and the
duration of an individual diving activity on the right;
• The second row shows the depth of the dive
reached with metric/imperial unit ( ‘ ’ – meter or
‘ ’- feet). When it reaches the maximum depth
pre-set by the user, the ‘ ’ icon above the unit
will flash and an audible alert alarm will beep for
30 seconds.
• The third rows shows the water temperature on the
left and your heart rate on the right with the ‘ ’
while you are wearing the Chest Strap. When the
heart rate field is flashing, the watch is searching
for the Heart Beat signal from the Chest Strap. If
no Heart Rate signal is picked for 60 seconds, it
will turn off automatically.
Depth Display
1st row
2nd row
3rd row

5.2 Dive Mode - Heart Rate Display
Heart Rate Display
• The first row shows either icon ‘ ’ (Sea water) or
icon ‘ ’ (Lake – fresh water) on the left, the ‘ ’
icon in the middle will appear and flash and an
audible alert alarm will beep for 30 seconds when
it reaches the maximum depth pre-set by the user
and the maximum depth of the dive reached on
the right.
• The second row shows the heart rate on the
left with the ‘ ’ icon and the %EMHR on the
right; when these 2 fields are flashing, the watch
is searching for the Heart Beat signal from the
Chest Strap. If no Heart Rate signal is picked for 5
minutes, it will turn off automatically.
• The Chest Strap comes with this watch is the
sensor for the heart rate, which transmits the heart
beat signal to the watch. The Heart Rate display
is functional provided that you put on the Chest
Strap. When you enter the Dive mode, the Heart
Rate (HR) reception will be turned on automatically
after 5 seconds. If no Heart Rate signal is picked
for 5 minutes, it will turn off automatically.
• The third row shows the duration of an individual
dive.
Heart Rate Display
1st row
2nd row
3rd row

5.3 Dive Mode - Precaution / Tips for Heart Rate Measurement
Heart Rate Features
• This Watch includes a chest strap, thus the Watch
can provide a continuous supply of heart rate data
to user for guiding them to achieve their fitness
goal.
Precautions / Tips
• There is two contacts located on the back of
the Chest Strap. These two contacts must be
firmly contacted with the user’s skin during
measurement.
• Clean the contacts occasionally by applying a few
drops of water, and wipe it dry with a paper towel
to remove any residual grease.
• DO NOT use hand cream; it will insulate the signal
between the skin and the contacts.
• Clean your skin with soap and water for better
signal transmission.
• For those with extremely dry skin, apply some
conductive gel or water may help.
• Adjust the Chest Strap with the supplied elastic
band until it is hold on your chest firmly to avoid
loosen it when doing exercise.
• Avoid doing any awkward motion during
measurement, otherwise error may be resulted.
Back View
Front View
TPU Black
Elastic Nylon
Band Black
Conductive
silicon rubber
PC+Glass
Fibre Black
ABS black
Silicon Rubber
Black
Silicon
Rubber Black

5.3.1 Dive Mode - Wearing the chest strap
How to Wear the Chest Strap
Refer to the below steps to wear the chest strap on
one’s chest:
1.Extend the elastic band for allowing a loose
fitting the chest strap on your chest.
2.Connect one connector with the chest strap.
Ensure that the connector is completely lodged
into the chest strap.
3.Fit the chest strap on your chest with one hand.
4.Connect the opposite connector to the chest
strap with the another hand.
5.Fasten the elastic band until it is fitted on your
chest comfortably.
6.Adjust the chest strap until the two contacts are
firmly contacted with your skin.
IMPORTANT: DO NOT wearing the chest strap over
your cloth, otherwise the chest strap CANNOT get
the heart rate signal.
NOTE: In dry seasons, wetting the contacts with
some water can make the signal transmission better.
1
2
3
4
5
6

5.4 Dive Mode - Heart Rate Alert
Heart Rate Alert
• When your heart rate is higher than the pre-set
heart rate, the icon ‘ ’ above the ‘ ’ appears
and the alert alarm will beep twice every 10
seconds. When your heart rate is lower than the
pre-set heart rate, the icon ‘ ’ underneath the
‘ ’ appears and the alert alarm will beep once
every 10 seconds. When the heart rate is within the
normal range, only the ‘ ’ appears on the screen.
Please check chapter 9.2.1 Setup menu for the
setting of the Heart Rate limits.
• The Chest Strap comes with this watch is the
sensor for the heart rate, which transmits the heart
beat signal to the watch. The Heart Rate Alert
can be functional provided that you put on the
Chest Strap and the Heart Rate Zone Alarms are
switched on. Please check the chapter 9.2 for the
H.R.Zone setup.
Heart rate
(beats per minute)
Visual
Indication
The Different Heart Rate Zones and
the Corresponding Indications
The Above Heart Rate Zone
The Desirable Heart Rate Zone
The Below Heart Rate Zone
‘ ’ indicator shown
‘ ’ indicator shown
‘ ’ indicator shown
The upper
limit
The lower
limit
Audio
Indication
beep twice
every 10 seconds
no sound
beep twice
every 10 seconds

5.4.1 Dive Mode - Estimated Maximum Heart Rate (EMHR) and %EMHR
Estimated Maximum Heart Rate (EMHR) and
%EMHR
• In doing exercise or sports, your heart naturally
speeds up in pumping blood to the body in
accordance with your increased energy level. This
watch can calculate that increase expressed in
terms of the number of beats per minute (bpm) to
determine a safe target heart rate for an individual.
Heart Rate Display
Heart rate
in bpm
Percentage
of estimated
maximum
heart rate
Estimated Maximum Heart Rate (EMHR):
• EMHR = 220 - user’s age.
• Example: What is Tom’s EMHR at the age of 27?
• EMHR = 220-30 = 193.
NOTE: This Watch can calculate the EMHR for the user
at his age up to 99. In order for the watch to calculate
the accurate EMHR and %EMHR, you have to input
your year of birth in the setup menu.
Percentage of Estimated Maximum Heart Rate
(%EMHR):
• %EMHR = Acquired heart rate / EMHR X 100%
• Example: What is Tom’s %EMHR when his heart
rate is 78 bpm?
• %EMHR= 78/193 X 100% = 40%

5.4.2 Dive Mode - What is Heart Rate Zone
What is Heart Rate Zone
• Some particular training/exercise objectives may require trainee/exerciser maintaining his/her heart rate (exercise
pace) within one particular heart rate zone (upper and lower limits) during the exercise. You may set your upper and
lower heart rate limits in the H.R. Zone Setup menu in Chapter 9.2.
• WARNING: Consult a doctor or trainer prior to setting the heart rate alert zone for a serious Cardio-fitness training.
How to Select upper and lower limits of your heart rate
• In general, user may get the cardio-fitness training advice from those prestigious organizations’ website, for
example:
http://www.heart.org/HEARTORG/Conditions/CongenitalHeartDefects/CareTreatmentforCongenitalHeartDefects/Con-
genital-Heart-Defects-and-Physical-Activity_UCM_307738_Article.jsp
by American Heart Association, and
http://en.wikipedia.org/wiki/Heart_rate#Training_zones
by Wikipedia.

5.5 Dive Mode - Countdown Diving duration
Countdown Diving Duration
• You may set your diving duration by using this
function. Pre-set the Countdown interval in the
Setup menu before using this function (please
check chapter 9.1.4 for the setting).
• Press and hold the [S/S] button for 2 seconds to
start the countdown in the Dive mode, “Countdown
Start!” will be shown on the screen for 2 seconds
and then return to the original dive mode display.
When it reaches zero, it will beep-beep-beep for 30
seconds. Press any key to stop the alarm. You may
stop the countdown by pressing and holding the
[S/S] button for 2 seconds. “Countdown Stop!” will
be shown on the screen for 2 seconds and then
return to the original dive mode display. When you
want to start the countdown again, it will reset and
start from the pre-set value.
Start Countdown
Diving
Duration Display
Stop Countdown
Diving
Duration Display
Depth Display Depth Display
Hold [S/S]
Auto return
after 2
seconds
Hold [S/S]
Auto return
after 2
seconds

5.6 Dive Mode - Interval Alarm
Interval Alarm
• This function can alert you the depth of your dive
in a multiply of the pre-set value. The value can be
set to 10m, 20m, 30m, 40m and 50m. It will beep
for 2 seconds when it reaches a multiply of the
pre-set value. When you set the value to 20m, it
will beep for 2 seconds when you reach 20m, 40m,
60m, 80m and 100m deep. This function can be
switched on/off. Please check the Setup menu in
Chapter 9.1.2 for more details.

5.7 Dive Mode - Surface Time Counter
Surface Time Counter
• When you emerge to the water surface from the
last dive and the depth is less than 1 meter, the
display of the watch will change to the surface
mode. The surface mode has 2 displays and will
switch alternatively in every 3 seconds and it
counts from zero and records the duration of your
stay in the water surface.
• The first row shows the ‘ ’ or ‘ ’ icon on the left
and the duration of the last dive OR the maximum
depth of the last dive on the right with the
maximum depth alert ‘ ’ in the middle when the
last dive reaches the pre-set depth.
• The second row shows the ‘ ’ icon Surface
mode on the left and the counter - the duration in
the water surface.
• The third row shows the water temperature and
the heart rate with ‘ ’ Icon. When the heart rate
field is flashing, the watch is searching for the
Heart Rate signal from the Chest Strap. If no Heart
Rate signal is picked for 5 minutes, it will turn off
automatically.
Surface Time
Counter Display

5.8 Dive Mode - Surface Time Counter
• When the surface time counter reaches the pre-set value (the pre-set value is set in the Setup menu, please check
the chapter 9.1.3 for more details), it will beep for 2 seconds. This alert function can be switched on/off in the Setup
menu.
• Note 1: The Dive mode is functional only if it is switched on in the Setup menu (Check Chapter 9.1 for the setting).
When you dive deeper than 1.0 meter, the Dive function will be activated and start recording your diving activity.
When you emerge in the water less than 1.0 meter deep and diving activity is more than 10 seconds, one diving
record is completed and saved.
• Note 2: The Dive mode is not functional at all when it is not switched on in the Setup menu (Check Chapter 9.1 for
the setting). After the Dive mode has been switched on, when you submerge the watch in the water less than 1.0
meter, this function will not be activated. This is to avoid the wrong trigger of this function.
• Note 3: The maximum number of diving records is 250 depending on the log rate. When the memory is full,
“Memory Full” will appear on the screen when you enter the Dive mode. In order to save the latest diving activities,
you may delete some old records to reserve space for the new records. Before deleting the dive records, you may
transfer the Dive records to the personal computer regularly in order to reserve space for the new diving activities.
(For data transfer, please check the chapter 10.0 for details.)
• Limitation of the Dive Mode:
– Diving Record: Maximum 250 diving records
– Maximum Logging Data Item: ~16,000
– Maximum Diving duration: 99 minutes 59 seconds
– Maximum Depth: 100 Meters or 328 Feet
– Resolution: 0.1 Meter/Feet
– Temperature Range: -20 to +70°C
– Heart Rate Range: 30 to 240 bpm

6.0 Chronograph Mode
Chronograph Display
• Select this mode by pressing the [M] button until
the CHRONO icon appears on the screen and wait
for 2 seconds, it will go to the Chronograph mode
automatically.
• In this mode, your heart rate can be shown on the
display when you put on the Chest Strap.
Chronograph Display
Chronograph Mode
Auto entry
after 2 seconds
