Mondial Designs Limited Aragon 8008X3 Technical manual

Congratulations on your purchase of the Aragon 8008X3 Three Channel Amplifier. The 8008X3
is a state-of-the-art component. Years of dedicated research, extensive testing, and engineering
refinement went into this Aragon exclusive.
Aragon components offer unparalleled flexibility and performance to the discriminating music
lover. Your 8008X3 incorporates many advanced design and construction features into a superbly crafted
amplifier.
We recommend playing your 8008X3 a minimum of 24 hours before performing any critical
listening. We do understand that most of you will not wait that long. Therefore, please note that your
8008X3 will improve sonicly over the course of the first week. During this time, you will notice the sound
from your 8008X3 will become richer, warmer and more open. After this first week of break-in the high
current bias of the 8008X3 will allow the amplifier to reach it's proper operating temperature within 20
minutes from turn on. We strongly recommend that you turn the amplifier OFF when not listening to
music.
UNPACKING YOUR NEW 8008X3 Three ChannelAmplifier
Your new 8008X3 Three Channel Amplifier was diligently hand-crafted, thoroughly tested and
carefully packed at our factory in California, USA. In the unlikely event that your 8008X3 is damaged
during shipment, be sure to save the carton as evidence for the freight carriers' inspection and call your
authorized dealer immediately. We strongly recommend that you always save the box and packing
materials should you have to transport your 8008X3 for any reason. This is a particularly good idea if you
wish to take full advantage of any future upgrades or options.
CAUTION:
Nevershipyour BOOBX3ThreeChannelAmplifier without theoriginal packing.
CONTENTS OF THIS CARTON:
This cartoncontains: your new 8008X3 Three Channel Amplifier, a UL approved power cord, a
Warranty Registration/Survey card, and of course, this Owner's Manual. Please follow the instructions
contained in this manual in order to derive the maximum performance, flexibility and enjoyment from your
8008X3 Three Channel Amplifier.
Be sure to complete and return your factory registration card immediately. This will entitle you to our
extended warranty as outlined on the warranty card.
@Mondial Designs LTD. 1996

CONTROLS AND FUNCTIONS
This section will help you to become familiar with each of the controls and functions found on your
8008X3 Three Channel Amplifier. Take a few moments to read the information presented in this section
in order to facilitate your understanding of the control options available.
FIGURE 1FRONT PANEL CONTROLS
CONNECTIONS
4. SPEAKER OUTPUTS
These are the speaker outputs for the three
channels.
5. A/C POWER CONNECTOR
This 3 prong connector is for the A/C power
input.
1. POWER ON/OFF
This rocker switch turns the A/C power ON
(press top) or OFF (press bottom.)
2. POWER INDICATOR
This light will be on whenever the 8008X3 is
in the on position.
3. INPUTS
These three inputs can be use for any
three channels in a home theatre system.
SYSTEM SETUP
This section provides you with the setup procedures to easily connect the 8008X3 Amplifier to
your system.
General Precautions
. Never allow the speaker cable termination's to touch at either the back of the amplifier or the speaker
terminals.AlwaysturnofftheBOOBX3whenconnectingormovingyourloudspeakers.
. Your 8008X3 is designed to be free standing, placed on an audio rack or stacked with other
components.
. Always be sure to provide enough space (at least 1Y2inches) at the top, sides and the rear of the
8008X3 to allow sufficient air flow through the ventilation slots. Failure to do this will cause severe
damage to the unit.
. Never place your 8008X3 directly on carpet. Always place on a hard flat surface to allow for proper
ventilation.

SETUP WITH A HOME THEATRE SYSTEM
1. PREPARATION
Before hooking up your 8008X3 you must decide if you will use it for the front channels; Left, Center,
Right or for the effects channels; Center, Left Surround, Right Surround.
Please note that the INPUTS (1,2,3) are assigned to the corresponding SPEAKER OUTPUTS (1,2,3)
and can be used for any three channels of a home theatre system.
2. INPUT CONNECTION
Using appropriate RCA cables, connect your surround sound source to the corresponding inputs on
the back of your 8008X3. Consult your authorized Aragon dealer for his or her recommendations on
cables and speaker wire.
3. OUTPUT CONNECTION
Before connecting your 8008X3 to the loudspeakers make sure that the power is off. For simple
connection your amplifier is equipped with five-way binding posts. Using appropriate speaker cable
(14 GA minimum in short runs and 12 GA in long runs over 25 ft.) connect each of the three outputs of
the 8008X3 to the corresponding speaker inputs. In home theatre it is particularly important to make
sure "+" is to "+" and "-" is to "-".
4. POWER CONNECTION
Plug the A/C power cord into the back of your 8008X3 and then into your A/C wall outlet.
Now that you are familiar with the controls and functions of your 8008X3 Three Channel Amplifier,
pick out your favorite movie and ENJOY! Happy listening from all of us at Mondial.
TROUBLESHOOTING
Simple Solutions to Simple Problems
NO LED INDICATOR
A. Check A/C Power connection on back of 8008X3 and A/C receptacle.
B. Check line fuse on back panel (replace only with same value fuse.)
LED INDICATOR ON BUT NO SOUND
A. Make sure that all components ore "on."
B. Verify connection of inputs and outputs.
C. Check source and preamp input selector.
D. Check speaker connections at both amp and speaker ends. On electrostatic speakers also
check the A/C power cords.
If all of this checks out, it is possiblethat an internal fuse needs replacement.
Your authorized Aragon dealer can replace it as well as answer other questions.
Do not attempt to do thisyourself!
For any additional information on your Aragon Power Amplifier, please your dealer or Mondial Designs Ltd.
Aragon Audio is a division of Mondial Designs Ltd.
CAUTION: To prevent electric shock, do not remove cover, no user serviceable parts inside. Refer
servicing to qualified personnel.WARNING: To prevent fire or shock hazard, do no expose this appliance
to rain or moisture.

SPECIFICATIONS
8008X3 Three Channel Amplifier
Power Output:
8 ohms
4 ohms
200 watts per channel continuous power all channels driven
5Hz - 20KHz at less than 0.05% THO
400 watts per channel continuous power all channels driven
5Hz-20KHz
Input Impedance:
Single Ended 22K ohms
Input Sensitivity:
1 Watt Output 120 mV
Full Output 1.68 V
Signal To Noise:
A Weighted
Damping Factor:
Slew Rate:
Voltage Gain:
Phase Inversion:
Weight:
Size:
>105 dB
>500
>120 V/I.1S
28 dB
No
681bs.
19 W x 16 5/8 D x 8 5/8 H
MONDIAL DESIGNS LIMITED
20 Livingstone Avenue, Dobbs Ferry, NY 10522. [phone]. Fax [phone]
