MONISMS MNS-6A CS-1P Series User manual

MONISMS
COMMERCIAL AUDIO SYSTEMS
MNS-6A CS-1PXX
User Manual
Flush-Mount Stereo Celing Speakers
With DANTE/ AES67/ POE+
MNS-6A11CS-1P / MNS-6A12CS-1P / MNS-6A22CS-1P

Features:
▪ Network Enabled Loudspeaker by Dante™
▪ Power Supply via POE+ or 19V Power Supply [option]
▪ RJ45 Connection for Audio from POE+ Ethernet
▪ Frameless, Flat Design, Magnetic Ultra-thin Grilles
▪ AES67 Compatible
▪ Dante Domain Manager Ready
▪ CE Passed
This speaker is specially designed for PA systems based on Dante audio
networks. It is suitable for installation into a lightweight celing.
The MNS-6AXXCS-1P is ideal for hotels, conference rooms, shopping
center, education, hospitals, retail stores, performing art centers,
restaurants, airports, houses of worship, and board rooms.
The speaker features a Class-D amplier, With a maximum digital input
signal, the amplier will provide 30W power.
MONISMS MNS-6AXXCS-1P is a Dante™ audio network addressable and
self-amplied ceiling speaker system.
The speaker is Power supply via POE+ (Power over Ethernet) or DC19V
power supply, available at option. The speaker includes a Class-D
amplier which provides effective use of power.
This system will solve the issue of having to provide a separate amplier
or I/O interface for speaker installations.
The audio network system is also compatible with AES67 which makes
this speaker system to be exible with other audio network systems.
The network system is also Dante Domain Manager Ready.
The system comes with 6.25” coaxial 60W loudspeaker driver,
MNS-6AXXCS-1P that has excellent dispersion, wide bandwidth and
smooth frequency response which makes this the top choice for
today’s overhead commercial applications.
This assembly can be used in wide range of projects for paging and
background music applications.
This instructions are intended for installers with knowledge in network technology.
Please read the instructions carefully prior to operation and keep them for
later reference.
Applications
1

System Specications
Frequency Response
20 Hz - 20 KHz
Audio Input
Dante Audio via Ethernet
Output Power
30W
Signal to Noise Ratio
105dB
RJ45 Interface
1RJ45
Audio Network System
Compatibility
Dante / Dante Domain
Manager / AES67
Route switching control
Dante™ controller software
Power supply
Power supply via POE+ [Power
over Ethernet, IEEE 802.3at-
2009] or DC19 V [4.74A] power
supply, available at option
2

MONISMS DANTE/AES67 Ceiling Speaker Advantage
▪ No need to have separate dante enabled AMP or I/O interface.
▪ Cost effective simple one system solution.
▪ High quality digital audio.
▪ Simple and easy installation, maintenance and expansion.
▪ Easy conguration / adjustable the sound area through software.
▪ Compatible with DANTE/AES67 protocols.
Speaker Technical Specifications
Tweeter
1"swirl loaded dome tweeter
Woofer Cone
6.25"aluminium cone bass/midrange
Rated Power
60W
Rated impedance
8Ohm
Frequency Range
45Hz-20KHz
Sensitivity
91 dB
Hole Size
Ø206mm
Dimension
Ø235*155mm [Diameter*Thickness]
Material
ABS
Diameter of the Grille
Ø232mm
Protrusion
Grilles thickness only 4mm
3

4
Channel 1[Zone 1]
C
A
B
A
AA
B
C
FCat5 or above Cable
PC
POE+ Gigabit Switches
POE DANTE Speaker
More DANTE/AES67 speakers
MONISMS
F
F
F
[Model:MNS-6A11CS-1P] 1 Channel
Only Master DANTE Speaker
Channel zoning illustration
POE Gigabit Switches

5
Channel 1[Zone 1]Channel 1[Zone 2]
G
CD
A
B
A
AA
B
C
D
F
G
Cat5 or above Cable
PC
POE DANTE Speaker
Passive Speaker
Two conductor loudspeaker wires
More DANTE/AES67 speakers
MONISMS
F
F
F
[Model:MNS-6A12CS-1P] 1 Channel
Reserve Additional Passive Speaker Terminals
Channel zoning illustration
POE Gigabit Switches
POE+ Gigabit Switches

6
[Model:MNS-6A22CS-1P] 2 Channels
[One Channel for Master Speaker, Another Channel for
Passive Speaker], Reserve Additional Passive Speaker
Terminals.
Channel zoning illustration
Channel 1[Zone 1]Channel 2[Zone 2]
G
CD
A
B
A
AA
B
C
D
F
G
Cat5 or above Cable
PC
POE DANTE Speaker
Passive Speaker
Two conductor loudspeaker wires
E
More DANTE/AES67 speakers
MONISMS
F
F
F
POE+ Gigabit Switches
POE Gigabit Switches

Installation Dimensions
Mounting Hole
Ø 206mm
Ø 232mm
Ø 155mm
7
Grilles thickness only 4mm
4

The brand Dante® as well as the Dante® software which may have been
integrated into these products are licenced by Audinate Pty Ltd.
Common FAQs
We've collected the following FAQ's from years of helping clients
achieve success.
Https://www.monisms.com/en-us/common-faqs
Downloads
Download the latest software updates from MONISMS.
Product rmware, software upgrades and standalone applications.
Https://www.monisms.com/en-us/download
Support
Important Notes
The unit corresponds to all relevant directives of the EU is therefore marked with .
▪ The unit is suitable for indoor use only. Protect it against dripping water, splash
water and high air humidity. The admissible ambient temperature range is 0 – 40 °C.
▪ For cleaning only use a dry, soft cloth; never use water or chemicals.
▪ No guarantee claims for the unit and no liability for any resulting personal damage
or material damage will be accepted if the unit is used for other purposes than
originally intended, if it is not correctly installed, or if it is not repaired in an expert
way.
If the unit is to be put out of operation
denitively, take it to a local recycling
plant for a disposal which is not harmful
to the environment.
8

MONISMS
COMMERCIAL AUDIO SYSTEMS
MONISMS INTERNATIONAL LIMITED
MONISMS TECHNOLOGY (ZHUHAI) LIMITED
E-mail:[e-mail]
Website:www.monisms.com
MONISMS’s operates a policy of continuous research and development.
The introduction of new materials or manufacturing methods will always equal
or exceed the published specications.
All specications are subject to change without notice.
Copyright (c) 2019 MONISMS. All rights reserved.
